Users Manual
Flextronics User Guide
User Guide for the Flextronics phone
FCC/IC Notice
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THIS PHONE MODEL MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted
using standard operating positions specified by the FCC with the
phone transmitting at its highest certified power level in all tested
frequency bands.
Although the SAR is determined at the highest certified power level,
the actual SAR level of the phone while operating can be well below
the maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to reach
the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g., at
the ear and worn on the body) as required by the FCC for each model.
The highest SAR values for this model phone are:
AMPS mode-head: 1.6 mW/g; Body-worn: 1.6 mW/g with Flextronics
belt clip ODMCP09101001-100. (Body-worn measurements differ
among phone models, depending upon availability of accessories and
FCC requirements. The body-worn SAR values provided above were
obtained by using Flextronics Corporation supplied and approved
universal belt clip ODMCP09101001-100). While there may be
differences between the SAR levels of various phones and at various
positions, they all meet the government requirement for safe
exposure. The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in compliance
with the FCC RF emission guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section http://www.fcc.gov/oet/fccid after searching on FCC ID
Q3OODM-QB04. Additional information on SAR can be found on the
Cellular Telecommunications and Internet Association (CTIA) web-site
at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a substantial margin of safety to
give additional protection for the public and to account for any
variations in measurements.
User Guide for the Flextronics Phone
CONTENTS
1 Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . 1
Inserting your RUIM card . . . . . . . . . . . . . . . .1
Charging the battery . . . . . . . . . . . . . . . . . . .1
Getting to know your phone . . . . . . . . . . . . .3
Using the menus . . . . . . . . . . . . . . . . . . . . . .5
2 Making and Receiving Calls . . . . . . . . . . . . . 9
Making a call . . . . . . . . . . . . . . . . . . . . . . . . .9
Answering a call . . . . . . . . . . . . . . . . . . . . . .9
Dealing with missed calls . . . . . . . . . . . . . .10
Calls Forwarding . . . . . . . . . . . . . . . . . . . . .10
Setting up speed dialing . . . . . . . . . . . . . . .11
Setting up voicemail . . . . . . . . . . . . . . . . . .12
Locking the keypad . . . . . . . . . . . . . . . . . . .12
Emergency numbers . . . . . . . . . . . . . . . . . .13
Making calls using a headset . . . . . . . . . . .14
3 Entering Letters, Numbers, and Symbols . 15
Text entry modes . . . . . . . . . . . . . . . . . . . . .15
Switch between Upper and Lower case text
input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
4 Storing Contacts . . . . . . . . . . . . . . . . . . . . . . 19
Saving a phone number . . . . . . . . . . . . . . . .19
Saving addresses and notes . . . . . . . . . . . .20
Editing or erasing a contact . . . . . . . . . . . . .20
Editing a phone number . . . . . . . . . . . . . . . .20
Finding contact information . . . . . . . . . . . . .21
Viewing contacts . . . . . . . . . . . . . . . . . . . . .21
5 Sending and Receiving Text Messages. . 23
Sending text messages . . . . . . . . . . . . . . . . 23
Retrieving text messages . . . . . . . . . . . . . . 24
Erasing messages . . . . . . . . . . . . . . . . . . . . 25
Setting message alerts . . . . . . . . . . . . . . . . 25
Sending and editing preformatted
messages . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6 Customizing Your Phone. . . . . . . . . . . . . . . 27
Setting vibration mode . . . . . . . . . . . . . . . . 28
Keypad Lock . . . . . . . . . . . . . . . . . . . . . . . . 28
Adjusting volume . . . . . . . . . . . . . . . . . . . . 28
Alert Type . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setting the Ringer Type . . . . . . . . . . . . . . . 29
Key Beep . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Personalizing the screen . . . . . . . . . . . . . . . 29
Setting Alerts . . . . . . . . . . . . . . . . . . . . . . . 31
Creating a secure environment . . . . . . . . . . 31
7 Using Extras . . . . . . . . . . . . . . . . . . . . . . . . . 33
BlackJack . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Video Poker . . . . . . . . . . . . . . . . . . . . . . . . . 33
Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . 33
Scheduler . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8 Getting Help. . . . . . . . . . . . . . . . . . . . . . . . . . 37
User Guide for the Flextronics Phone 1
1G
ETTING STARTED
This document describes the Flextronics phone,
with CDMA digital service at 800 MHz and
analog service at 800 MHz.
Your phone comes with an integrated and
rechargeable Lithium Ion (LiIon) battery which is
not fully charged.
Inserting your RUIM card
The RUIM card is supplied by your service
provider when you register as a user. It contains
all the important data pertaining to your line.
1. Hold the phone face down.
2. Remove the RUIM card cover located at the
lower end of the phone by sliding it out.
3. Slide the RUIM card
into its compartment
with the metal
contacts facing
down and the cut
corner to the left.
4. Slide back the RUIM
card cover fully until
it latches, so that the
RUIM card can be
properly activated
during power on.
Important: Make sure that the phone is switched
off and is disconnected from the charger before
you insert and remove your RUIM card.
Charging the battery
The battery is not fully charged when you
purchase your phone. Fully charge the new
battery for approximately 12 hours before
using the phone for the first time.
To charge the battery,
connect the AC adapter to
the jack located at the
bottom left of the phone
(as shown), then connect
the adapter’s plug to an AC
wall outlet.
2Getting Started
The battery icon at the top-right corner of the
screen tells you whether the phone is:
• Charging (animated icon)
• Partially charged
• Fully charged
Recharging the battery
You can safely recharge the battery at any time,
even if it has a partial charge.
Caring for the battery
This section describes important safety
information and tips for improving battery
performance.
General safety guidelines
This phone contains integrated Li-Ion battery,
• Do not attempt to open the battery
compartment and dismantle, puncture, or
short-circuit the battery.
• If you have not used the battery for more than
a month, recharge it before using your phone.
• Avoid exposing the phone to extreme
temperatures, direct sunlight, or high
humidity.
• Never dispose of used batteries in or near a
fire. It could lead to explosion. Check with
your local regulations for proper disposal
instructions.
Common causes of battery drain
The following operations drain the battery more
quickly and thereby adversely affect talk and
standby times:
• Playing games frequently.
• Frequent use of the backlights.
• Using data cables or accessories, such as the
Hands-free headset.
• Operating when no service is available, or
service is available intermittently.
• High earpiece and ringer volume settings.
• Unacknowledged voicemail and text message
alerts.
User Guide for the Flextronics Phone 3
Getting to know your phone
Jack for Hands-free Headset with MUTE button (sold separately).
Display screen
S or Select key Selects a menu item or option.
Call or Send key Dials a number or answer a call.
Navigation key 4-way navigation for scrolling through lists and
positioning the cursor. Also accesses shortcuts from the home
screen.
Alphanumeric Keypad for entering enter numbers, letters, or
symbols.
Integrated Antenna.
C or Clear key Erases the last character in text entry, or returns
to the previous menu.
End/Power key Switches the phone on or off, ends a call, or
returns you to the home screen.
Jack for AC adapter (included).
# key inserts a space during text entry.
*key cswitches between upper and lower case during text entry.
Warning: Inserting an accessory into the incorrect jack will
damage the phone.
1
2
3
4
5
6
7
8
9
10
11
12
4Getting Started
Performing basic functions
To... From the home screen...
Switch on the phone Press the End/Power key.
Switch off the phone Press and hold the End key for approximately 3 seconds.
Make a call Enter the number using the alphanumeric keypad and press
the Call/Send key.
End a call Press the End/Power key.
Answer a call Press the Call/Send key.
Verify Own Number Press the S key to enter the Menu and scroll to Phone Info.
Access voicemail Press and hold the 1 and follow the system prompts.
Lock the keypad Press and hold the C/Clear key.
Unlock the keypad Press 123.
Access the All Contacts list Press the RIGHT navigation key.
Mute all sounds Press and hold the UP navigation key.
Access Recent Calls list Press the LEFT navigation key.
User Guide for the Flextronics Phone 5
Using the menus
The contents of the main menu are as follows:
Settings
Silence All
Auto Key Guard
Sound
Display
Alerts
Call Timers
Security
Accessories
Sys/Network
Call Control
Contacts
Find
View All
Business
Personal
Add New
Speed Dial List
Recent Calls
Missed Calls
Incoming Calls
Outgoing calls
SMS
Voice Mail
InBox
Create Message
Send Preformat
Outbox
Erase Messages
Message Settings
Extra
Games
Stop Watch
Alarm
Scheduler
Calculator
Phone Info
List Own Number
6Getting Started
The instructions in this guide assume that your
menu appears in Small Icons. To change your
menu display so that it appears as Large Icons,
see “Menu Format” on page 30.
Navigating the menus
Note: In this guide, the use of an arrow → tells
you to select an option from the menu. For
example, Menu → Settings means select Menu,
then select the Settings option.
• From the home screen, press the S key to
enter the Menu.
• Use the UP and DOWN navigation keys to
browse through the menus.
• To access soft keys located at the bottom of
the display screen, press the DOWN
navigation key and use the LEFT and RIGHT
navigation keys to select a soft key function.
The display texts relating to soft key functions
are indicated with a reverse white text in
solid background, example, Cancel
• Press the S key to select a menu or menu
item.
• Press the C key to return to the previous
screen.
• Press the End key to return to the home
screen.
User Guide for the Flextronics Phone 7
Understanding screen icons
These icons may appear on the screen of your phone.
Icon Function Description
Signal Strength Show the signal strength of the network at your current location.
The thicker the bars, the stronger the signal.
Roaming Indicates roaming when home network is not available.
Silence Indicates that the ringing tone is muted.
Vibrator Vibrator is activated.
SMS You have received one or more text messages.
SMS Memory is full, and there is no more space for new messages.
SMS Message has been read.
Voice mail You have one or more voice mails.
Battery Battery power indicator. Thicker bars indicate a higher power level.
Call Forwarding Unconditional call forwarding is activated.
Local city Time and date of local city.
DST Daylight saving time is on.
8Getting Started
Icon Function Description
Single call Indicates an active call.
Single call Indicates that a call is being put on hold.
Conference call Indicates an active conference call.
Conference call Indicates that a conference call is being put on hold.
Incoming call Indicates an incoming call.
Forwarded call Indicates that an incoming call is being forwarded.
Home city Time and date of home city.
Local city Time and date of local city.
DST Daylight saving time is on.
User Guide for the Flextronics Phone 9
2M
AKING AND RECEIVING CALLS
Making a call
1. Make sure you are in an area where the
signal can be received. Look for the
symbol on the home screen.
Note: The more bars you see in this symbol,
the stronger the reception. If there are no
bars, try to move to where the reception is
better. In some cases, this can be as simple
as changing the direction you are facing.
The phone will go into power save mode
when it is left idle for 5 minutes. If you see
the message “POWER SAVE” on the screen,
press any key to return to the idle screen.
2. Enter the phone number.
3. Press the Send/Call key to dial the number.
4. Press the End/Power key to end the call.
Redialing a number
To redial the last number called, press the Send/
Call key twice.
Calling a saved number
If you have already saved a phone number, you
can use the All Contacts list to find it quickly.
1. Press the RIGHT navigation key when in idle
screen.
This brings up a list of all saved contacts.
2. Scroll down the list, find the contact you
want, and press the Send/Call key to dial the
number.
Answering a call
When you receive a call, the phone rings,
vibrates, and/or lights up, and an animated phone
icon appears. The number of the caller also
appears if it is not restricted. If the number is
stored in your Contacts directory, the contact
name appears.
• To answer the call, press the Send/Call key.
• To mute the ringer or stop the vibration when
there is an incoming call, select Silence.
• To send the call to the voice mail, press the
End/Power key or select Voice Mail .
10 Making and Receiving Calls
• To put an incoming call on hold, select
Answer Hold.
• To forward the incoming call to another
number which you have defined under Call
Control settings menu, select Forward Call.
See “Calls Forwarding” on page 10.
Setting Any Key Answer
1. Select Menu → Settings→ Accessories→
Any Key Answer.
2. Select On or Off and press S to confirm.
All incoming calls can now be answered by
pressing any key press except END key, S key
and C key.
Answering calls hands-Free
If your phone is attached to an accessory such as
a hands-free headset (sold separately), you can
set the headset to answer your calls
automatically in 2, 5 or 10 seconds.
1. Select Menu → Settings→ Accessories→
Headset Autoanswer.
2. Select Off, 2 seconds, 5 seconds or 10
seconds and press S to confirm.
Dealing with missed calls
When you have missed a call, “Missed” appears
on your screen. This message remains, unless
the caller leaves a voicemail.
• Press XXX to clear the screen.
• To view the caller’s number or name, press
the LEFT navigation key to access the Recent
Calls list and select Missed Calls.
• If the caller left a voicemail message, select
Call. If you have not yet set up your
voicemail, the caller cannot leave a message.
Setting missed call alerts
You can set the alert to beep when you have
missed a call.
1. Select Menu → Settings → Alert →
Missed Call.
2. Select Enable or Disable and press S to
confirm your selection.
Calls Forwarding
You can forward your calls to another phone
number.
1. Select Menu → Settings→ Call Control →
Forwarding Number.
User Guide for the Flextronics Phone 11
2. Enter the number you wish to forward all your
calls to.
3. Press S twice to confirm or select OK and
press S.
Viewing recent call details
Details on the last 10 calls you have missed,
made or received are stored in the Recent Calls
list. You can get details on the caller’s name and
phone number, along with the time and length of
the call.
Viewing recent calls
1. Select Menu → Recent Calls.
2. Select an option from the list: Missed Calls,
Incoming Calls or Outgoing Calls .
3. Press S to confirm.
Alternatively, press LEFT navigation key when
you are in idle screen to call out the Recent Calls
menu.
4. Select a phone entry.
5. Select an option from the list.
–Call Number dials the phone number
–Time shows the time and duration of call
–View Number to view the phone number
–Edit Number to edit the phone number
–Delete Number to delete the phone
number
–Send SMS to send SMS messages to the
phone number
–Save To Existing to add the phone number
to the an existing contact.
–Save to R-UIM to add the contact to the R-
UIM card
Erase All Recent Call List
You can erase all recent call list from the Recent
Calls menu.
1. Select Menu → Settings → Security.
2. Enter your four-digit PIN code.
3. Select Erase All Recent Call List.
4. A message appears: “Erase All Recent Call
List?”
5. Select Yes to erase all.
Setting up speed dialing
Speed dialing allows you to quickly dial a stored
phone number by entering a one- or two-digit
speed dialing location.
1. Locate a saved contact from the Contacts list.
12 Making and Receiving Calls
2. Scroll to the phone number and press S to
select.
3. Select Add to Speed Dial. (Note: Location “1”
is reserved for your voicemail number.)
4. Scroll down to select the speed dial number
to which you wish to assign the phone
number to and press S to confirm. (Available
speed dial numbers for assignment are
marked as -empty-)
To speed dial
From the home screen, enter the one- or two-
digit speed dial number and press the Send/Call
key.
Using 1-Touch Dialing
To dial a phone number, simply press and hold
the assigned speed dial number for the phone
number. If it is a two-digit number, press the first
number, then press and hold the second. For
example, if the speed dialing number is 15, press
1, then press and hold 5.
Setting up voicemail
Before your phone can receive voicemail
messages, you must set up a password and
record a personal greeting with your service
provider. When you have set up your voicemail,
all unanswered calls to your phone are
automatically transferred to your voicemail, even
if your phone is in use or turned off.
Checking voicemail messages
When a voice message is received, your screen
will display XXXXXXXXXXXXXXX
Silencing an incoming call
• To mute the ringer or stop the vibration when
there is an incoming call, select Silence.
This action silences the current call only. The
next call will ring as normal.
Adjusting the volume during a call
• To adjust the earpiece volume during a call,
press the UP or DOWN navigation key.
Locking the keypad
The Keyguard locks your keypad to prevent
accidental keypresses when the phone is turned
on and a call is not in progress. You can still
answer or silence an incoming call.
User Guide for the Flextronics Phone 13
• To lock the keypad from the home screen,
press and hold the C key.
• To unlock the keypad, press 123 from the
home screen.
Call Timer
Your phone has three timers that count the
duration of the calls you have made and
received.
1. Select Menu → Settings → Call Timers.
2. Select an option from the list:
– Outgoing Calls — The duration of
outgoing calls made by the phone since
the timer was last reset.
– Incoming Calls — The duration of
incoming calls made to the phone since
the timer was last reset.
– All Calls— The duration of all outgoing
and incoming calls of the phone since it
was manufactured. This timer cannot be
reset.
To Reset Timer
You can reset the timer for both Incoming and
Outgoing Calls.
1. Select Menu → Settings →Calls Timer.
2. Select Incoming Calls or Outgoing Calls and
press Reset to reset the call timer.
Emergency numbers
Calling emergency numbers
To call 911
• Dial 911 and press the Send/Call key.
You can call 911 even if your phone is locked or
your account is restricted. However, when you
call, your phone enters Emergency mode. This
enables the emergency service exclusive access
to your phone to call you back, if necessary. To
make or receive regular calls after dialing 911,
you must exit this mode.
To exit Emergency mode
When you have completed the 911 call:
XXXXXXXXXXXXX
Call Roaming
To enable or disable call roaming.
1. Select Menu → Settings →Sys/Network.
2. Select either No Roaming or Automatic and
press S to confirm.
14 Making and Receiving Calls
Making calls using a headset
If you are using a hands-free headset (sold
separately), press the button on your headset to
answer or end a call.
User Guide for the Flextronics Phone 15
3E
NTERING LETTERS, NUMBERS, AND SYMBOLS
You may enter letters, numbers, and symbols in
the Contacts, SMS and other menu functions; for
example, when you create a personal banner for
your phone’s home screen.
Text entry modes
There are four text entry modes:
Multitap
Numbers
EZText
Symbols
Note: The mode you start in depends on the task
you are doing. For example, when entering a
phone number in the Contacts menu, the default
text mode is Numbers. When entering a name for
a contact, the default text mode is Multitap.
Entering numbers
• To enter a number while in Numbers mode,
press a number key once.
• To enter a number while in Multitap or EZText
mode, press and hold a number key until the
number appears on the screen.
Entering words letter by letter
Multitap mode:
1. Press the appropriate alphanumeric key once
to display the first letter that appears on the
keypad, twice for the second letter, and so
on.
2. Wait for the cursor to move right before you
enter the next letter.
Entering words quickly
EZText mode:
When you press a series of keys using EZText, it
checks the built-in dictionary for common words
and predict the word you are trying to spell.
1. For each letter of the word you wish to spell,
press the appropriate alphanumeric key once.
For example, to enter the word “any” press
the alphanumberic keys 2 → 6 → 1.
2. If the word suggested by EZText does not
match what you want, press the DOWN
navigation key to look at other word matches.
16 Entering Letters, Numbers, and Symbols
3. When you see the word you want, press S to
confirm your choice. .
Entering symbols
Use Symbol mode:
1. Press the DOWN navigation key to access the
soft key located at the bottom of the display
screen.
2. Scroll with the LEFT and RIGHT navigation
keys to locate the current input mode.
3. Press S to access the text input options.
4. Scroll down to Symbols and press S to enter
the menu.
You will be presented with a list of symbols, such
as :
5. Press the number corresponding to the
symbol of your choice.
Changing input modes
To change input modes, while in any text editor
do the following:
1. Press the DOWN navigation key to access the
soft key located at the bottom of the display
screen.
2. Scroll with the LEFT and RIGHT navigation
keys to locate the current input mode.
3. Press S to access the text input options.
4. Scroll to select your desired input mode and
press S to confirm.
Switch between Upper and
Lower case text input
Three settings are available in the Multitap and
EZText input mode.
To change settings for upper and lower case
input:
1. Press the * key while in Multitap or EZText
input mode.
2. Continue pressing until your desired input
case is displayed. For example,
MULTITAP - Upper case
multitap - Lower case
Multitap - Only the first input character is
in Upper case.
1 - 2 . 3 @
4 * 5 ( 6 )
7 _ 8 .9 ?
User Guide for the Flextronics Phone 17
Quick reference to text entry
This table gives general instructions for entering letters, numbers, and symbols.
To... Do this...
Enter a letter Press the appropriate alphanumeric key repeatedly until
the letter you want appears on the display.
Enter a number Press and hold the appropriate number key until it
appears on the display. If you are in Numbers mode, then
press the number key once.
Enter a symbol Enter the Symbol mode and enter the number
corresponding to the symbol you want.
Enter a space Press the # key.
Erase a character Press C.
Erase all characters Press and hold C.
Move the cursor right or left Use the RIGHT or LEFT navigation keys.
Change text entry modes Press DOWN to highlight the current input mode and
press S to access Text Mode. Scroll to the desired input
mode and press S.
Capitalize the next letter Press * repeatedly until the current input mode display
Multitap.
18 Entering Letters, Numbers, and Symbols
Capitalize every letter In Multitap mode, before you enter the text, press *
repeatedly until the current input mode displays
MULTITAP. In EZText mode, press * repeatedly until the
highlighted word in the text editor changes to upper
case.
Capitalize the first letter of each word In Multitap mode, before you enter the text, press *
repeatedly until the current input mode displays
Multitap. In EZText mode, press * repeatedly until the
first letter of the highlighted word in the text editor
changes to upper case.
Highlight an option at the bottom of
the screen Press DOWN to highlight an option and press LEFT or
RIGHT to scroll through the other options available. To
confirm your selection, press S.
User Guide for the Flextronics Phone 19
4S
TORING CONTACTS
The Contacts menu of your phone is like a set of
phone index cards for you to store information
about a person or a company. Your phone can
hold, on average, about XXX phone numbers.
Each name, e-mail address, mailing address or
web address entry can contain up to 256
characters. The minimum length of RUIM phone
number is 10 digits.
Saving a phone number
To save a phone number, do the following:
1. From the home screen, enter the phone
number you wish to save.
2. Press the S key to select New.
3. Enter the name of the contact.
To learn how to enter letters, see page 17.
4. You can either save the contact now or
assign options such as a speed dial number
or number type. To save now, press the S key
twice and press the End key to exit.
-or-
To assign options, scroll to Options and press
S to access the options list.
5. Scroll p or down to select an option from the
list:
–Add New to add a new contact
–Edit Name to edit the name of the new
contact
–Classify Contact to classify the new
contact as Personal, Business or Neither
–Erase Contact to erase the new contact.
Adding a code or extension
When you save the phone number of an
automated service, you may include a pause
where you need to select an option or enter a
password. You can enter multiple pauses in a
phone number. A Pause will cause the phone to
stop dialling until you select the Release key.
1. Enter the first portion of the phone number.
2. Press RIGHT to scroll through the options at
the bottom of the screen.
3. Scroll to Pause and press S.
A letter P will appear just next to the last
digit of your phone entry.
4. Enter the remaining numbers.
20 Storing Contacts
5. Save the number accordingly. (See “Saving a
phone number” on page 19.”).
Saving addresses and notes
To save an email address, street address, or Web
page URL, follow these steps. To add one of
these items to a saved contact, see “Editing or
erasing a contact”
1. Select Menu → Contacts → Add New.
2. Scroll to Phone, Email, Address, or Web Page
and press S to select.
3. Enter the information.
(See “Quick reference to text entry” on
page 17.)
4. Press S twice to go to the next the next
screen.
5. Enter a contact name.
6. Press S twice to Save.
Editing or erasing a contact
1. Select Menu → Contacts.
2. Select View All or Find to locate the contact
you wish to edit.
3. Highlight the contact you wish to edit and
press S.
4. Select Options.
5. Highlight an option and press S to select it:
–Add New to add a phone number, email
address, street address, or Web page.
–Erase Contact to erase the entire contact.
–Edit Name of the contact.
–Classify Contact as persona, business or
neither.
6. Follow the screen prompts to enter new
information or delete the contact.
7. Press S to confirm your choice or Save where
necessary.
Editing a phone number
1. Select Menu → Contacts.
2. Select View All or Find to locate the contact
you want to edit.
3. Highlight the contact you wish to edit and
press S.
4. Press DOWN to highlight the phone number
you wish to edit and press S.
5. Highlight an option for the phone number and
press S:
User Guide for the Flextronics Phone 21
–Number Type to classify as Work, Home,
Mobile, Pager or Other.
–Edit phone number
–Erase phone number
–Add to speed dial to assign a speed dial
number
6. Follow the screen prompts to enter new
information or erase the phone number.
7. Press S to confirm your choice or to Save
where necessary.
Finding contact information
There are three main methods for finding a
phone number or contact details.
Quick Dial using All Contacts list
From the home screen, press LEFT to view All
Contacts list and scroll to highlight the contact
you wish to call and press the Call key to dial the
number. Otherwise, press S to edit the contact’s
information.
Viewing contacts
The following icons may appear next to
information in your Contact entries.
Personal Email
Business Address
Neither Web Page
22 Storing Contacts
User Guide for the Flextronics Phone 23
5S
ENDING AND RECEIVING TEXT MESSAGES
This chapter describes how to send, receive, and
erase text messages from your phone.
Important: The features and menus described in
this chapter may vary depending on services
available in your area. In addition, usage charges
may apply to each message. For clarification on
these issues, check with your service provider.
Sending text messages
Check with your service provider to find out if you
are able to send text messages from your phone.
You can only send text messages to phones that
are capable of receiving them.
Sending a simple message
To send a plain text message to a single
recipient:
1. Select Menu → SMS → Create Message.
2. Select a saved number from the All Contacts
List.
-or-
– Enter a the number manually.
3. Select Continue to enter your message. (See
“Quick reference to text entry” on page 17.)
Note: If your message exceeds 123
characters, you may be charged for more than
one message. For more information, see
“Understanding appended messages” below.
4. When you have completed the message,
select Continue and press S to Send.
Forwarding a saved message
You can reuse a message you have stored in your
Outbox. The Outbox contains all sent messages,
messages for which send attempts have been
made as well as messages with failed send
attempts.
1. Select Menu → SMS → Outbox.
2. Scroll through the list of messages and press
S to select.
3. Select an option from the list:
–Done to go back to previous screen
–Erase the message
–Send the message
–Forward the message to another recipient
4. Enter the phone number manually or select
from the All Contacts List.
24 Sending and Receiving Text Messages
5. Press S to continue.
6. To send the message as it is, press S again to
Send.
-or-
To edit the message, enter your text
accordingly.
When you have finished editing, press S to
send the message.
If you cannot send messages
You may not be able to send or receive messages
if your phone’s memory is nearly full, or if digital
service is not available at the time. To free up
memory, erase old messages. See “Erasing
messages” on page 25.
Receiving incoming calls while
creating messages
• If you don’t wish to answer the call, select
XX.
• To answer the call, press XX. The message
you were working on will be saved in the
Outbox folder. To return to the message,
select
Menu → SMS → Outbox and select it.
Viewing the OutBox
You can check the status of messages you have
sent as long as they have been saved to the
OutBox. To check the OutBox setting, see
“Saving messages to the OutBox” on page 5.
1. Select Menu → SMS → OutBox.
2. Scroll through the list of messages and press
S to read the message.
Retrieving text messages
When a text message is received, your screen
will display text similar to: “New message 1 Text
Msg”. This text will remain for about five
minutes. After that, look for the symbol at
the top of your screen. The symbol flashes if the
message is urgent.
If your phone is set to Direct View, the body of
the message will appear on the phone screen
automatically. (To activate this setting, see
page 11.)
Reading the message
You may read the message on the display and
call back the number in the message. The screen
shall auto scroll the screen page by page unless
the LEFT or RIGHT navigation key is pressed.
User Guide for the Flextronics Phone 25
Setting message alerts
You can set your phone to alert you of incoming
text messages. For more information, see
“Setting message alerts” on page 6.
Erasing messages
Your phone is designed to store 99 text
messages and pages. It is a good idea to erase
old messages, as messages take up memory in
your phone.
You have the option of erasing text messages
and pages as you send or read them, erasing
them one-at-a-time from the list in the OutBox or
InBox, or erasing them all at once.
Erasing single messages
1. Select Menu → SMS.
2. Scroll down to select the type of text
message you want to erase (InBox, or
OutBox).
3. Press S to select the message to erase.
4. Select Erase to erase the message. A
notification appears: “Erase this message?”
5. Select Yes to erase the message.
Auto Erase Old Inbox
1. Select Menu → SMS → Message
Settings→ Auto Erase Old Inbox.
2. Scroll to Enable and press S to confirm.
Setting message alerts
You can choose how you want be alerted of
incoming voicemail, pages, or text messages.
1. Select Menu → SMS → Message Settings
→ Message Alert
2. Select an option from the list:
–None - no alert
– Vibrate Once - phone will vibrate once
when you receive a message
– Vibrate & Remind - phone will vibrate
every minute until you read the message
– Beep Once - phone will beep once when
you receive a message
– Beep & Remind - phone will beep every
minute until you read the message
3. Scroll to type of alert you want and press S to
select.
26 Sending and Receiving Text Messages
Sending and editing
preformatted messages
Your phone comes with preformatted messages,
such as “Call me”, “Emergency”, “I’ll be there in
15 minutes”, etc. which you can insert into the
body of a text message. You can edit these
messages and create new ones. Your phone canl
store up to 20 AutoText messages, with up to
100 characters per message.
1. Select Menu → SMS →
Send Preformat.
2. Scroll through the list of preformatted
messages and press S to select.
3. Enter the phone number manually or select
from the All Contacts list and press S to
continue.
4. Enter or edit the text and press S to
continue.For help entering text, see page 19.
5. Select Send and press S to send the message
or Save to save the message to the Outbox.
User Guide for the Flextronics Phone 27
6C
USTOMIZING YOUR PHONE
The contents of the Settings menu are as follows.
Silence AllNormal/Vibe Only/Lights
Only
Call Timers Outgoing Calls/Incoming
Calls/All Calls
Auto Key GuardOn/Off/30 secs/2 mins/5
mins
Security Enter PIN:
Sound Volume/Alert Type/Ringer
Type/Key Beep/Key Tone
Length
Accessories Ext Power Backlight/
Headset Ringing/Headset
Autoanswer/Any Key
Answer
Sys / Network Roaming opt
Display Back Lighting/Banner/
Language/Contrast/Menu
Format/Time Format/
Screensaver
Call Control Forwarding Number
Alert Missed Call/Roaming/
Service/Minute Alert
28 Customizing Your Phone
Setting vibration mode
You can set your phone to vibrate or to vibrate
and then ring when you receive an incoming call.
1. Select Menu → Settings → Sound→ Alert
Type.
2. Select Vibration or Vibe + Ringer and press S
to confirm your choice.
Keypad Lock
You can lock the keypad to protect the phone
from accidental key presses.
1. Select Menu → Settings → Auto Key
Guard.
2. Select an option from the list:
–On — This option shall immediately lock
the keypad.
–Off — This option shall disable the
keyguard.
–30 Sec — This option shall lock the
keypad after 30 seconds of inactivity.
–2 mins — This option shall lock the
keypad after 2 minutes of inactivity.
–5 mins — This option shall lock the
keypad after 5 minutes of inactivity.
Pressing and holding the CLEAR key shall also
lock the keypad, which then can be unlocked by
pressing 123.
Adjusting volume
You can adjust the volume of the ringer, earpiece
and the key beeps.
1. Select Menu → Settings → Sound→
Volume.
2. You can adjust the volume of the Ringer,
Earpiece or Key Beep.
3. Press the UP navigation key to increase the
volume or press the DOWN navigation key to
reduce the volume.
4. Press S to confirm your choice.
Alert Type
You can choose the alert type as Off, Ringer,
Vibration or Vibe+Ringer.
1. Select Menu → Settings → Sound→ Alert
Type.
2. Select an option from the list:
–Off—
The phone will not ring.
–Ringer — The phone shall ring during the
entire alert.
User Guide for the Flextronics Phone 29
–Vibration — The phone shall vibrate
during the entire alert.
–Vibe+Ringer — The phone shall vibrate
during the first half of the alert, and ring
afterwards, during the second half of the
alert.
Setting the Ringer Type
There are 15 different programmed ringer types
(one of which is the default ringer).
1. Select Menu → Settings → Sound →
Ringer Type.
2. Scroll down the list to hear the different rings
tones.
3. Press S to select a ringer from the list.
Key Beep
You can set the keys to make Clicks or Tones.
Changing Key Tone Length
You can change the duration of the tones the
phone makes when you press the keys.
1. Select Menu → Settings → Sound → Key
Tone Length.
2. Select an option from the list:
–Normal — A short fixed length DTMF
burst shall be produced.
–Long — A longer DTMF burst shall be
produced. The DTMF burst shall be
determined by the key press.
Personalizing the screen
Adjusting the backlighting
Your screen lights up while you are in a call or
when you press a key on the keypad. However,
you can change when and how backlighting
lights up.
1. Select Menu → Settings → Display →
Backlighting.
2. Select an option from the list:
–Off
–10s
–30s
– 10s in call
– 30s in call
3. Press S to confirm your choice.
Note: Keeping backlighting on during a call
consumes more energy and thereby drains the
battery more quickly, reduces talk as well as
standby times.
30 Customizing Your Phone
Changing your banner
You can set up your personal greeting that is
displayed when the phone is in Idle State.The
banner is the personal label for your phone. It
appears on the home screen.
1. Select Menu → Settings → Display →
Banner.
2. Select Edit.
3. Press C to clear the screen.
4. Enter your new text.
5. Press S twice to save or select Save and
press S.
Choosing a different language
Your phone may support languages in addition
to English.
1. Select Menu → Settings → Display →
Language.
2. Select a language, and press S to confirm.
Changing the display contrast
1. Select Menu → Settings → Display →
Contrast.
2. Use the LEFT or RIGHT navigation keys to
increase or reduce the Contrast. Changing the
menu view
Menu Format
You can change the icon size of the top level
menu.
1. Select Menu → Settings → Display →
Menu Format.
2. Select an option from the list:
– Large Icons
– Small Icons
3. Press S to confirm your choice.
Choosing a different time format
1. Select Menu → Settings → Display →
Time Format.
2. Select an option from the list:
–AM/PM
–24 HR
3. Press S to confirm your choice.
Screen Saver
1. Select Menu → Settings → Display →
Screen Saver.
User Guide for the Flextronics Phone 31
2. You will be able to select the Type and
Timeout for the Screen Saver.
Setting Alerts
You can choose to Enable or Disable alert tones
during various circumstances.
1. Select Menu → Settings → Alert.
2. Select an option from the list:
– Missed Call— If set to Enable, the phone
shall emit an alert tone when there is a
missed call.
– Roaming— If set to Enable, the phone
shall emit an alert tone when the roaming
state changes.
–Service —
If set to Enable, the phone
shall emit an alert tone when the phone
registers itself to a service or lost the
connection with a service.
– Minute Alert— If set to Enable, the
phone shall emit an alert tone every 10
seconds before the end of a minute during
a call.
Setting power backlighting
You can set backlighting to remain on when an
external power source, such as the AC adapter,
is used with the phone.
1. Select Menu → Settings →
Accessories → Ext Power Backlight.
2. Select On to keep backlighting on. (The
battery charges more slowly when power
backlighting is on.
Creating a secure environment
This section describes all the features involved in
securing your phone and preventing access to
personal information. All security features are
shielded by a four-digit lock code. The lock code
is typically 0000 or the last 4 digits of your phone
number.
Changing your PIN code
1. Select Menu → Settings → Security.
2. Enter your four-digit PIN code and press S to
confirm.
3. Scroll to Pin Change and enter your new PIN
code and press S to confirm.
Erasing all contacts
You can erase all contacts from the Contacts
directory.
1. Select Menu → Settings → Security.
2. Enter your four-digit lock code.
32 Customizing Your Phone
3. Select Erase All Contacts.
4. A message appears: “Erase All contacts?”
5. Select Yes to erase all contacts.
Restoring Factory Default
1. Select Menu → Settings → Security.
2. Enter your four-digit PIN code.
3. Select Phone Reset.
4. A message appears: “Restore Factory
Default?”
5. Select Yes to restore factory default.
Setting alerts for your headset
When a headset (sold separately) is attached to
the phone, you can set alert sounds to originate
from the headset.
1. Select Menu → Settings → Accessories
→ Headset Ringing.
2. Select On to have alerts originating from the
headset.
Setting headset Autoanswer
When a headset (sold separately) is attached to
the phone, you can set the headset to
autoanswer when there is an incoming call.
1. Select Menu → Settings → Accessories
→ Headset Autoanswer.
2. You can choose switch off autoanswer, 2
seconds, 5 seconds or 10 seconds.
3. Scroll to your desired option and press S to
select.
User Guide for the Flextronics Phone 33
7U
SING EXTRAS
Your phone offers you 2 enjoyable games.
BlackJack
This is a card game.
Video Poker
This is also a card game.
1. Select Menu → Extra → Games.
A temporary greeting screen shall be displayed
followed by the rule of the game when any of the
game is selected.
2. Select OK to start the game.
Stopwatch
1. Select Menu → Extra → Stopwatch.
2. Select Start to have the stopwatch begin
counting.
3. Select Stop to stop counting.
4. Select Reset to set the counter back to zero
and begin counting again.
Alarm Clock
You can set the phone to alarm at a specified
time.The alarm clock will only trigger an alert if
the phone is switched on.
To access this menu, digital service is required.
To set an alarm:
1. Select Menu → Extras→ Alarm → Set.
2. Use the UP and DOWN navigation keys to set
the time for the alarm.
3. Select Once, Daily, or Weekdays.
When the alarm triggers, select Off to turn off
the alarm or Snooze to silence the alarm for
10 minutes.
Scheduler
The Scheduler allows you to schedule events,
such as meetings or appointments, and keep
track of special occasions, such as birthdays or
wedding anniversaries.
To access this menu, digital service is required.
34 Using Extras
Adding an event
1. To find the day of the event.
2. Select Menu → Extra → Scheduler
– For a day in the current month, select
View Day. Press the LEFT or RIGHT
navigation keys to scroll through days.
– For a day in a different month, select
View Month. Press the UP or DOWN
navigation keys to scroll through months,
and LEFT or RIGHT to scroll through days.
3. Press the S key to confirm the day and month.
4. Select Menu → Extra → Scheduler → Add
Event and press the S key.
5. Enter event name. For help on entering text,
see page 18.
6. Press the S key twice when you are done
entering the letters.
7. Select Next to set the event Start time,
Duration, and Alarm frequency.
–Press the UP or DOWN navigation keys to
set alarm fields.
–Press
LEFT or RIGHT navigation keys to
move between fields.
8. Press the S key twice when you are done.
9. Select Next to add a Note.
10. Press the S key twice when you are done
Viewing, editing, or erasing an event
1. Select Menu → Extra → Scheduler.
2. Select View Day or View Month to find the
event you want to view, edit, or erase.
3. XXXXXXXXXXXXXXX
User Guide for the Flextronics Phone 35
Calculator
Use the calculator for basic arithmatical
calculations.
1. Select Menu → Extra → Calculator.
2. Use the keypad to enter numbers.
3. Select the arithmetical or memory operators
using the left/right navigation keys.
4. Continue to enter the second number.
5. Select = and press S to display the result.
=equal +add xmultiply
÷divide -subtract .decimal point
CClear all numbers entered and display a
zero.
MR Display the value currently stored in
memory.
M+ Add the displayed digit to the value
stored in memory.
MC Clear the value currently stored in
memory.
±Change the sign of the displayed number.
36 Using Extras
User Guide for the Flextronics Phone 37
8G
ETTING HELP
Customer support
Your service provider’s customer support
department may be accessible directly from your
phone when you dial a number (check with your
service provider). They can answer questions
about your phone, phone bill, call coverage area,
and specific features available to you, such as
call forwarding or voicemail.
Before requesting support, please try to
reproduce and isolate the problem. When you
contact the Customer Care Center, be ready to
provide the following information:
• The name of your service provider.
• The actual error message or problem you are
experiencing.
• The steps you took to reproduce the problem.
• The phone’s electronic serial number (ESN).
To find the ESN:
a. Remove the battery.
b. Locate the white label on the back of the
phone. Your phone’s ESN begins is
located on the label.
38 Getting Help
User Guide for the XXXXXX Phone 39
INDEX
Numerics
NumericsNumerics
Numerics
911 calls 13
A
AA
A
adjusting 29
alerts
for headsets 32
for messages 25
for missed calls 10
AutoText 26
B
BB
B
backlighting 29
banner 30
battery 1
drain 2
safety guidelines 2
C
CC
C
Calculator 35
calling emergency numbers 13
calls
making and answering 4, 9
missed 10
timing 13
contacts
calling 9
classifying 20
editing 20
erasing 20
finding 21
storing 19
contrast 30
D
DD
D
display contrast 30
E
EE
E
emergency
911 calls 13
making calls after dialing 911 13
erasing
all contacts 11, 31
text messages 25
external devices
hands-free car kit 10
F
FF
F
finding a saved phone number 21
H
HH
H
hands-free car kit
answering using voice 10
purchasing 37
hands-free headset
and phone ringer 32
button 14
jack 3
purchasing 37
40
I
III
icons 7
K
KK
K
keyguard
setting 12
keypad, locking 12
L
LL
L
language 30
lights
backlighting 29
power backlighting 31
locking
keypad 12
M
MM
M
memory
saving 25
menu view 30
messages
see
voicemail
or
text messages
minutes
counting 13
missed calls 10
O
OO
O
OutBox 24
P
PP
P
phone numbers
editing 20
power backlighting 31
R
RR
R
recent calls timer 13
redialing a number 9
resetting the phone 41
ringers
for different calls 31
S
SS
S
saved phone numbers
editing 20
Scheduler 33
screen contrast 30
screen icons 7
security 31
silencing all sounds 28
silent mode
setting 28
speed dialing 12
Stopwatch 33
symbol mode 16
T
TT
T
technical support 37
text entry
changing text modes 16
text messages
erasing 25
pre-written (AutoText) 26
retrieving 24
sending new 23
sending saved 23
viewing the outbox 24
time format 30
User Guide for the XXXXXX Phone 41
timers
recent calls 13
V
VV
V
vibrate
setting phone to 28
silence all 28
voicemail
accessing 12
setting up 4, 12
volume
earpiece 12
key beep 29
Back cover
