Flir BelgiumBA WFBT5 Marine Multifunctional Display with 802.11b/g & Bluetooth User Manual supplement
Raymarine UK Ltd. Marine Multifunctional Display with 802.11b/g & Bluetooth supplement
Contents
User Manual supplement
NewaSeries—Supplementaryinformation
NewaSeriespartssupplied
Thefollowingitemsaresuppliedwithyourmultifunctiondisplay.
D12583-2
1
4
7
56
8
23
x4
1Frontbezel
2Multifunctiondisplay
3Mountinggasket
4Suncover
5Trunnionbracketkit
6Documentationpack
7Powercable
84xNuts,bolts,springwashersandwashers(canbeusedforeithersurfaceorbracketmounting.)
Documentnumber:82262-2Date:01-2013
Displayvariants
NewaSeriesmultifunctiondisplaysareavailableinthefollowingvariants:
Non-
sonar
variant
Sonar
variantControlsFeatures
a65
(E70076)
a67(E70077)
Touchscreenonly
•Bluetooth.
•InternalGPS.
a65WiFI
(E70162)
a67WiFi
(E70163)
Touchscreenonly
•Bluetooth.
•InternalGPS.
•Wi-Fi
NewaSeriesphysicalspecications
Dimensions•Width:163.57mm(6.44in)
•Height(NOTincludingbracket):143.47mm(5.65in)
•Height(includingbracket):162.72mm(6.41in)
•Depth(NOTincludingcables):74.1mm
•Depth(includingcables):167.5mm(6.6in)
Weight(bareunit)0.715kg(1.58lbs)
NewaSeriespowerspecication
Nominalsupplyvoltage12Vdc
Operatingvoltagerange10.8Vdcto15.6Vdc
Fuse/BreakersTheunitincludesaninternalfuse.Itisrecommendedthatyout
anadditionalthermalbreakerorfuseatthedistributionpanel.
Thesuitablefuseratingforthethermalbreakerisdependenton
thenumberofdevicesyouareconnecting.Ifindoubtconsultan
authorizedRaymarinedealer
PowerconsumptionFullbrightness:
•a65/a65WiFi—8.6W
•a67/a67WiFi—12.2W
PowerSavemode:
•a65/a65WiFi—3.8W
•a67/a67WiFi—9W
LEN(RefertoSeatalkngreferencemanualforfurtherinformation).1
Environmentalspecication
Environmentalspecicationsbelowapplytoalldisplayvariants
Operatingtemperature-25ºCto+55ºC(-13ºFto131ºF)
Storagetemperature-30ºCto+70ºC(-22ºFto158ºF)
2NewaSeries—Supplementaryinformation
RelativehumidityMaximum75%
Waterproofrating•IPX6andIPX7
NewaSeriesdisplayspecication
Size5.7in
TypeTFTbacklitLED
Colordepth24–bit
Resolution640x480VGA
Aspect4:3
Viewingangle•Left/Right:60degrees
•Top/Bottom:60/50degrees
Maximumallowablewronglyilluminatedpixels5
Dataconnections
Wiredconnections
Network(SeaTalkhs)•1xSeaTalkhsport.100Mbits/s.RayNettypeconnection.
SeaTalkng1xSeaTalkngconnection.
Wirelessconnections
Wi-Fi802.11b/g
Note:Wi-Ficonnectiononlyappliestothea65WiFianda67WiFivariants.
BluetoothAVRCP2.1+EDRpowerclass1.5
InternalGPSspecication
Channels50
Coldstart<2minutes
ReceiverICSensitivity163dBmTracking
SatelliteBasedAidingSystem(SBAS)WAAS+EGNOS+MSAS
SpecialfeaturesActiveJammingReduction
Operatingfrequency1575.42MHz
SignalAcquisitionAutomatic
AlmanacUpdateAutomatic
GeodeticDatumWGS-84,alternativesavailablethroughRaymarinedisplays.
UpdateRate1second
AntennaCeramicchip
Accuracy•WithoutSBAS:<=15metres95%ofthetime
•WithSBAS:<=5metres95%ofthetime
NewaSeries—Supplementaryinformation3
Internalsonarspecication
Theinternalsonarspecicationsonlyapplytosonarvariantmultifunctiondisplayvariants.
Operatingfrequencies50/83/200KHz
TransmitpowerUpto600WRMS,dependingontransducer
DepthrangeUpto3000ft,dependingontransducer
Conformancespecication
Conformancecerticationappliestoalldisplayvariants
Conformance•NMEA2000certication
•WiFiAlliancecertication
•Bluetoothcertication
•Europe:1999/5/EC
•AustraliaandNewZealand:C-Tick,ComplianceLevel2
•FCC47CFRpart15
•IndustryCanadaRSS210
4NewaSeries—Supplementaryinformation
