43/2
SERIES
8320
3-WAY
65
Features
• All NPT connections are in the valve body to allow
in-line piping
• No Minimum Operating Pressure Differential required
• Broadest range of applications
• Mountable in any position
Direct Acting
General Service Solenoid Valves
Brass or Stainless Steel Bodies
1/8" to 1/4" NPT
2
3
1
NC
NO
U
Solenoid Enclosures
Nominal Ambient Temp. Ranges
AC: 32˚F to 125˚F (0˚C to 52˚C)
DC: 32˚F to 104˚F (0˚C to 40˚C)
Note: Some stainless steel constructions are
rated -40˚F (-40˚C). See note in specifications table.
Refer to Engineering Section for details.
Approvals
CSA certified. UL listed General Purpose Valves.
Meets applicable CE directives.
SIL 3 capable per IEC 61508 on normally closed const.
Third party certification provided by EXIDA.
Refer to Engineering Section for details.
Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.
Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.
(To order, add prefix “EF” to the catalog number.)
See Optional Features Section for other available options.
% ^ )
Valve Parts in Contact with Fluids
Body Brass 303 Stainless Steel
Seals and Disc NBR or Cast UR, as Listed
Core Tube 305 Stainless Steel
Core and Plugnut 430F Stainless Steel
Core Springs 302 Stainless Steel
Shading Coil Copper Silver
Disc-Holder CA
Core Guide CA (10.1 and 17.1 Watt only)
Standard
Coil and
Class of
Insulation
Watt Rating and Power
Consumption Spare Coil Part Number
DC
Watts
AC General Purpose Explosionproof
Watts
VA
Holding
VA
Inrush AC DC AC DC
F 10.6 6.1 16 30 238210 238310 238214 238314
F - 9.1 25 40 238210 - 238214 -
F 11.6 10.1 25 50 238610 238710 238614 238714
F 22.6 17.1 40 70 238610 238710 238614 238714
Standard Voltages: 24, 120, 240, 480 volts AC, 60 Hz (or 110, 220 volts AC, 50 Hz).
6, 12, 24, 120, 240 volts DC. Must be specified when ordering. Other voltages are
available when required.
Construction
Electrical
3/2
SERIES
8320 4
3-WAY
66
Specifications (English units)
Pipe
Size
(in)
Orifice
Size
(in)
Cv
Flow
Factor
Operating Pressure
Differential (psi) Max. Fluid
Temp. ˚F
Brass Body Stainless Steel Body Watt Rating/
Class of Coil
Insulation
Max. AC Max. DC
Catalog Number
Const.
Ref. Catalog Number
Const.
Ref.
Air-Inert
Gas
Water
Lt. Oil
@ 300
SSU
Air-Inert
Gas
Water
Lt. Oil
@ 300
SSU AC DC AC DC
UNIVERSAL OPERATION (Pressure at any port)
1/8 3/64 0.06 175 175 175 125 125 125 140 120 8320G130 18320G140 1 9.1F 10.6F
1/8 1/16 0.09 100 100 100 65 65 65 180 120 8320G001 1 8320G041 1 9.1F 10.6F
1/8 1/16 0.09 175 175 175 125 125 125 200 150 8320G212 4 8320G221 4 17.1/F 22.6/F
1/8 3/32 0.12 50 50 50 50 50 50 180 120 8320G083 1 8320G087 16.1/F 10.6/F
1/8 3/32 0.12 100 100 100 60 60 60 200 150 8320G213 4 8320G222 4 17.1/F 11.6/F
1/8 1/8 0.21 30 30 30 20 20 20 180 120 8320G003 1 8320G043 19.1/F 10.6/F
1/8 1/8 0.21 50 50 50 25 25 25 200 150 8320G214 4 8320G223 4 17.1/F 11.6/F
1/4 1/16 0.09 125 130 130 75 75 75 200 150 8320G172 2 - - 10.1/F 11.6/F
1/4 1/16 0.09 175 175 175 125 125 125 200 150 - - 8320G230 3 17.1/F 22.6/F
1/4 3/32 0.12 100 100 100 60 60 60 200 150 8320G174 2 8320G200 3 17.1/F 11.6/F
1/4 1/8 0.25 50 50 50 25 25 25 200 150 8320G176 2 8320G201 3 17.1/F 11.6/F
1/4 11/64 0.35 20 20 20 12 12 12 200 150 8320G178 2 - - 10.1/F 11.6/F
NORMALLY CLOSED (Closed when de-energized) – PFDAVG = 6.81 x 10-4
1/8 3/64 0.06 200 200 200 200 200 200 180 120 8320G132 1 8320G142 1 6.1F 10.6/F
1/8 1/16 0.09 150 125 125 125 125 125 180 120 8320G013 1 8320G045 1 6.1F 10.6/F
1/8 1/16 0.09 210 225 225 160 160 160 200 150 8320G215 4 8320G224 4 17.1/F 11.6/F
1/8 3/32 0.12 100 100 100 100 100 100 180 120 8320G015 1 8320G047 1 6.1F 10.6/F
1/8 3/32 0.12 150 150 150 115 115 115 200 150 8320G216 4 8320G225 4 10.1/F 11.6/F
1/8 1/8 0.21 40 40 40 40 40 40 180 120 8320G017 1 8320G049 1 6.1F 10.6/F
1/8 1/8 0.21 85 85 85 60 60 60 200 150 8320G217 4 8320G226 4 10.1/F 11.6/F
1/4 1/16 0.09 210 225 225 160 160 160 200 150 8320G182 2 8320G231 3 17.1/F 11.6/F
1/4 3/32 0.12 150 150 150 115 115 115 200 150 8320G184 2 8320G202 3 10.1/F 11.6/F
1/4 1/8 0.25 85 85 85 60 60 60 200 150 8320G186 2 8320G203 3 10.1/F 11.6/F
1/4 11/64 0.35 45 45 45 25 25 25 200 150 8320G188 2 - - 10.1/F 11.6/F
NORMALLY OPEN (Open when de-energized)
1/8 3/64 0.06 200 200 200 200 200 200 180 120 8320G136 1 8320G146 1 6.1F 10.6/F
1/8 1/16 0.09 150 125 125 125 125 125 180 120 8320G027 1 8320G051 1 6.1F 10.6/F
1/8 1/16 0.09 235 250 250 160 160 160 200 150 8320G218 4 8320G227 4 17.1/F 11.6/F
1/8 3/32 0.12 100 100 100 100 100 100 180 120 8320G029 1 8320G053 1 6.1F 10.6/F
1/8 3/32 0.12 150 140 140 100 100 100 200 150 8320G219 4 8320G228 4 10.1/F 11.6/F
1/8 1/8 0.21 40 40 40 40 40 40 180 120 8320G031 1 8320G055 1 6.1F 10.6/F
1/8 1/8 0.21 70 70 70 55 55 55 200 150 8320G220 4 8320G229 4 10.1/F 11.6/F
1/4 1/16 0.09 235 250 250 160 160 160 200 150 8320G192 2 8320G232 3 17.1/F 11.6/F
1/4 3/32 0.12 150 140 140 100 100 100 200 150 8320G194 2 8320G204 3 10.1/F 11.6/F
1/4 1/8 0.25 70 70 70 55 55 55 200 150 8320G196 2 8320G205 3 10.1/F 11.6/F
1/4 11/64 0.35 40 40 40 30 30 30 200 150 8320G198 2 - - 10.1/F 11.6/F
Supplied with cast UR disc.
On 50 hertz service, the watt rating for the 6.1/F solenoid is 8.1 watts; the watt rating for the 9.1/F solenoid is 11.1 watts.
Can be used for
dry
natural gas service with the EF prefix.
Constructions standard rated -40˚F (-40˚C) ambient temperature. EFX prefix and TPL # not required.
Water rating, CSA certified up to 232 psi.
3/2
SERIES
8320
4
3-WAY
67
Specifications (Metric units)
Pipe
Size
(in)
Orifice
Size
(mm)
Kv Flow
Factor
(m3/h)
Operating Pressure
Differential (bar) Max.
Fluid
Temp. °C
Brass Body Stainless Steel Body Watt Rating/
Class of Coil
Insulation
Max. AC Max. DC
Catalog Number
Const.
Ref. Catalog Number
Const.
Ref.
Air-Inert
Gas
Water
Lt. Oil
@ 300
SSU
Air-Inert
Gas
Water
Lt. Oil
@ 300
SSU AC DC AC DC
UNIVERSAL OPERATION (Pressure at any port)
1/8 1.2 0.05 12 12 12 9 9 9 60 49 8320G130 18320G140 1 9.1F 10.6F
1/8 1.6 0.08 7 7 7 4 4 4 82 49 8320G001 1 8320G041 1 9.1F 10.6F
1/8 1.6 0.08 12 12 12 9 9 9 93 66 8320G212 4 8320G221 4 17.1/F 22.6/F
1/8 2.4 0.10 3 3 3 3 3 3 82 49 8320G083 1 8320G087 16.1/F 10.6/F
1/8 2.4 0.10 7 7 7 4 4 4 93 66 8320G213 4 8320G222 4 17.1/F 11.6/F
1/8 3.2 0.18 2 2 2 1 1 1 82 49 8320G003 1 8320G043 19.1/F 10.6/F
1/8 3.2 0.18 3 3 3 2 2 2 93 66 8320G214 4 8320G223 4 17.1/F 11.6/F
1/4 1.6 0.08 9 9 9 5 5 5 93 66 8320G172 2 - - 10.1/F 11.6/F
1/4 1.6 0.08 12 12 12 9 9 9 93 66 - - 8320G230 3 17.1/F 22.6/F
1/4 2.4 0.10 7 7 7 4 4 4 93 66 8320G174 2 8320G200 3 17.1/F 11.6/F
1/4 3.2 0.21 3 3 3 2 2 2 93 66 8320G176 2 8320G201 3 17.1/F 11.6/F
1/4 4.4 0.30 1 1 1 1 1 1 93 66 8320G178 2 - - 10.1/F 11.6/F
NORMALLY CLOSED (Closed when de-energized) – PFDAVG = 6.81 x 10-4
1/8 1.2 0.05 14 14 14 14 14 14 82 49 8320G132 1 8320G142 1 6.1F 10.6/F
1/8 1.6 0.08 10 9 9 9 9 9 82 49 8320G013 1 8320G045 1 6.1F 10.6/F
1/8 1.6 0.08 14 15 15 11 11 11 93 66 8320G215 4 8320G224 4 17.1/F 11.6/F
1/8 2.4 0.10 7 7 7 7 7 7 82 49 8320G015 1 8320G047 1 6.1F 10.6/F
1/8 2.4 0.10 10 10 10 8 8 8 93 66 8320G216 4 8320G225 4 10.1/F 11.6/F
1/8 3.2 0.18 3 3 3 3 3 3 82 49 8320G017 1 8320G049 1 6.1F 10.6/F
1/8 3.2 0.18 6 6 6 4 4 4 93 66 8320G217 4 8320G226 4 10.1/F 11.6/F
1/4 1.6 0.08 14 15 15 11 11 11 93 66 8320G182 2 8320G231 3 17.1/F 11.6/F
1/4 2.4 0.10 10 10 10 8 8 8 93 66 8320G184 2 8320G202 3 10.1/F 11.6/F
1/4 3.2 0.21 6 6 6 4 4 4 93 66 8320G186 2 8320G203 3 10.1/F 11.6/F
1/4 4.4 0.30 3 3 3 2 2 2 93 66 8320G188 2 - - 10.1/F 11.6/F
NORMALLY OPEN (Open when de-energized)
1/8 1.2 0.05 14 14 14 14 14 14 82 49 8320G136 1 8320G146 1 6.1F 10.6/F
1/8 1.6 0.08 10 9 9 9 9 9 82 49 8320G027 1 8320G051 1 6.1F 10.6/F
1/8 1.6 0.08 16 17 17 11 11 11 93 66 8320G218 4 8320G227 4 17.1/F 11.6/F
1/8 2.4 0.10 7 7 7 7 7 7 82 49 8320G029 1 8320G053 1 6.1F 10.6/F
1/8 2.4 0.10 10 10 10 7 7 7 93 66 8320G219 4 8320G228 4 10.1/F 11.6/F
1/8 3.2 0.18 3 3 3 3 3 3 82 49 8320G031 1 8320G055 1 6.1F 10.6/F
1/8 3.2 0.18 5 5 5 4 4 4 93 66 8320G220 4 8320G229 4 10.1/F 11.6/F
1/4 1.6 0.08 16 17 17 11 11 11 93 66 8320G192 2 8320G232 3 17.1/F 11.6/F
1/4 2.4 0.10 10 10 10 7 7 7 93 66 8320G194 2 8320G204 3 10.1/F 11.6/F
1/4 3.2 0.21 5 5 5 4 4 4 93 66 8320G196 2 8320G205 3 10.1/F 11.6/F
1/4 4.4 0.30 3 3 3 2 2 2 93 66 8320G198 2 - - 10.1/F 11.6/F
Supplied with cast UR disc.
On 50 hertz service, the watt rating for the 6.1/F solenoid is 8.1 watts; the watt rating for the 9.1/F solenoid is 11.1 watts.
Can be used for
dry
natural gas service with the EF prefix.
Constructions standard rated -40˚F (-40˚C) ambient temperature. EFX prefix and TPL # not required.
Water rating, CSA certified up to 16 bar.
3/2
SERIES
8320 4
3-WAY
68
Dimensions: inches (mm)
1/2 NPT
.09 [2.3]
2 PLACES
2 MOUNTING
HOLES FOR
.164 [4] THD
CUTTING SCREW
.44 [11]
Ø 1.19 [30]
R.090 [2.3]
4 PLACES
FOR MOUNTING
.44 [11]
1.30 [33]
.63 [16]
1.69 [43]
2.18
[55]
1.32
[34] 3.15
80]
1/8 NPT
3 PLACES
Const. Ref. 1
MOUNTING
BRACKET* WITH
Ø.28 [7] HOLES
2 PLACES
* MOUNTING BRACKET
IS STANDARD ON THIS
CONSTRUCTION
1.81 [46]
.72 [18]
1/4 NPT
3 PLACES
1/2 NPT
1.95 [50]
2.74 [70]
3.73 [95]
1.76 [45]
Ø 1.44 [37]
Const. Ref. 3
1/2 NPT
2 MOUNTING HOLES
.31 [8] DEEP FOR .164 [4]
THD CUTTING SCREW
1.75
[45]
.37 [9]
1.69 [43]
.44 [11]
1.40 [36]
.81 [21]
1.95 [50]
3.74
[95]
2.73
[69]
1/4 NPT
3 PLACES
Const. Ref. 2
21
3
21
3
21
3
21
3
21
3
21
3
Press.
Exh.
Cyl. Press.
Exh.
Cyl.
Press.
Exh. Cyl.
Press.
Exh. Cyl.
Energized
Energized
Energized
De-Energized
De-Energized
De-Energized
Universal
Normally Closed
Normally Open
FLOW DIAGRAMS
.090 [2.3]
2 PLACES
212299-001
CUTTING SCREW
FOR .164 [4.2] THREAD
2 MOUNTING HOLES
212299-001
SHOWING MOUNTING BRACKET ONLY
1.30 [33]
3
2
2
1
1/2 NPT
1.95
[50]
3.64
[93]
2.03
[52]
3.03
[77]
1/8 NPT
3 PLACES
1.19
[30]
1.69
[43] 2.66
[68]
.440 [11.2]
.440 [11.2]
R.090 [2.3]
Const. Ref. 4
