pc3000 FC
PC Adapter
Instruction Sheet
Introduction
The pc3000 FC PC Adapter is a USB device that receives and
transmits a radio signal between a Fluke Connect 3000 Series
Wireless Module and a computer. The Fluke Connect sw3000
application software uses the adapter to exchange data wirelessly with
3000 FC modules.
Fluke sw3000 FC is a Windows-based software application that allows
real-time display measurements from up to six 3000 FC modules for
each PC adapter. The software shows real-time graphs of individual
module readouts. A user can download logged data and adjust the
module parameters and settings, such as, module name, logging
interval, and logging duration.
gxh10.eps
Software Requirements:
• Windows XP or later.
• Fluke pc3000 FC PC Adapter must be connected to the USB
port to enable communication between the 3000 FC modules
and the software application.
• sw3000 FC supports up to two PC adapters.
How to Contact Fluke
To contact Fluke, call one of the following telephone numbers:
• USA: 1-800-760-4523
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31 402-675-200
• Japan: +81-3-6714-3114
• Singapore: +65-6799-5566
• Anywhere in the world: +1-425-446-5500
Or, visit Fluke’s website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.
Safety Information
Symbols
Symbol Description
Conforms to European Union directives
Conforms to relevant Australian EMC requirements
This product complies with the WEEE Directive
(2002/96/EC) marking requirements. The affixed label
indicates that you must not discard this
electrical/electronic product in domestic household
waste. Product Category: With reference to the
equipment types in the WEEE Directive Annex I, this
product is classed as category 9 "Monitoring and
Control Instrumentation" product. Do not dispose of this
product as unsorted municipal waste. Go to Fluke’s
website for recycling information.
Specifications
Operating Temperature ........ 10 °C to 30 °C
Storage Temperature ........... −40 °C to 60 °C
Relative Humidity ................. 0 % to 45 % (non-condensing)
Computer Interface............... USB 1.1/2.0
Wireless Frequency ............. 2.4 GHz ISM Band 20 meter range
Size (H x W x L) ..................... 1.3 cm x 2.5 cm x 7.9 cm
(0.5 in x 1.0 in x 3.1 in)
Weight .................................... 20 g (0.7 oz)
Connection to PC ................. USB Type A
