Fortify Technologies FD800 2G Sync Station User Manual Trio Activity Tracker
Fortify Technologies, LLC. 2G Sync Station Trio Activity Tracker
User Manual-revised
Page 1
GSM 2G Sync Station User Manual
Model: FD800
June 1, 2015
Version 1.1
Page 2
Table of Contents
Introduction .................................................................................................................................................. 3
Package Content ........................................................................................................................................... 3
Device Layout ............................................................................................................................................... 3
Unboxing of the Device ................................................................................................................................ 4
Charging Port ................................................................................................................................................ 4
Plugging of the Device .................................................................................................................................. 5
FCC Notice ..................................................................................................................................................... 5
Copyright ...................................................................................................................................................... 6
Trademarks ................................................................................................................................................... 6
Page 3
Introduction
FD-800 GSM 2G Sync Station is a compact and lightweight wireless electronic data
reception and transmission device in box form. It serves as a gateway between Activity Trackers
and the web server. This device is plugged on the wall and is used to synchronize and uploads
the user’s activities (for example: steps activity) to the cloud service in the background. Unlike
the Sync Mobile Apps (iOS and Android) and Desktop Apps (Windows PC, Mac), FD-800
synchronizes data without user intervention, silently in the background. Target customers are
the elderly population in the United States of America.
Package Content
Check the product box for the following item:
GSM 2G Sync Station
Device Layout
Page 4
Unboxing of the Device
1. Open the box cover.
2. Remove the polyethylene foam (3).
3. Remove the device from the plastic tray (4).
Charging Port
WARNING It is only intended for Trio® Trackers. No other devices should be connected other
than these as this might damage the internal circuits if drawing more current than it can
provide.
Page 5
Plugging of the Device
1. Plug the device to the wall socket (1).
2. Once plugged, the Green LED starts to blink.
3. After successful initialization (20-30 seconds), the Blue LED turns on which means it is
now ready to sync any supported Trackers (2).
4. All Trio® Tracker Models are now supported and can be synced to the FD800 Sync
Station (3).
FCC Notice
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
WARNING Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Page 6
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment must be installed and operated in accordance with provided instructions and
the antenna(s) used for this transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter. End-users and installers must be provided with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.
Copyright
Copyright 2015 Fortify Technologies Asia, Inc.
No part of this document, including illustrations, labels, images, exercises or attachments may
be produced or transmitted in any form or by any means, electronic or mechanical, including
photocopying, recording, or by any information storage and retrieval system, without
permission in writing from Fortify Technologies, Inc.
Trademarks
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
