Introduction About FortiGate SSL VPN

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 7

Introduction

This section introduces you to FortiGate™ Secure Sockets Layer (SSL) VPN

technology and provides supplementary information about Fortinet™ publications.

The following topics are included in this section:

•About FortiGate SSL VPN

•About this document

•FortiGate documentation

•Related documentation

•Customer service and technical support

About FortiGate SSL VPN

FortiGate SSL VPN technology makes it safe to do business over the Internet. In

addition to encrypting and securing information sent from a web browser to a web

server, FortiGate SSL VPN can be used to encrypt most Internet-based traffic.

With the FortiGate unit’s built-in SSL VPN capabilities, small home offices,

medium-sized businesses, enterprises, and service providers can ensure the

confidentiality and integrity of data transmitted over the Internet. The FortiGate

unit provides enhanced authentication and restricted access to company network

resources and services.

The two modes of SSL VPN operation, supported in NAT/Route mode only, are:

• web-only mode, for thin remote clients equipped with a web browser only

• tunnel mode, for remote computers that run a variety of client and server

applications

When the FortiGate unit provides services in web-only mode, a secure web

connection between the remote client and the FortiGate unit is established using

the SSL VPN security in the FortiGate unit and the SSL security in the web

browser. After the connection has been established, the FortiGate unit provides

access to selected services and network resources through a web portal.

Where users have complete administrative rights over their computers and use a

variety of applications, tunnel mode allows remote clients to access the local

internal network as if they were connected to the network directly. In tunnel mode,

a secure SSL connection is established initially for the FortiGate unit to download

SSL VPN client software (an ActiveX plugin) to the web browser. After the user

installs the SSL VPN client software, they can initiate a VPN tunnel with the

FortiGate unit whenever the SSL connection is open.

When the SSL VPN feature is used, all client traffic is encrypted and sent to the

SSL VPN. This includes both traffic intended for the private network and Internet

traffic that is normally sent unencrypted. Split tunneling ensures that only the

traffic for the private network is sent to the SSL VPN gateway. Internet traffic is

sent through the usual unencrypted route. This conserves bandwith and alleviates

bottlenecks. The split tunneling feature is not enabled by default.

FortiOS v3.0 MR7 SSL VPN User Guide

801-30007-0348-20080718

About this document Introduction

Whether to use web-only or tunnel mode depends on the number and type of

applications installed on the remote computer. Access to any application not

supported through web-only mode can be supported through tunnel mode. For

more information about these modes of operation, see “Configuring a FortiGate

SSL VPN” on page 13.

About this document

This document explains how to configure SSL VPN operation using the web-

based manager and contains the following chapters:

•Configuring a FortiGate SSL VPN describes the two modes of operation,

recommends a deployment topology, and provides an overview of the

associated infrastructure dependencies. The high-level steps for configuring

each mode of operation are also included with cross-references to underlying

procedures. This chapter also details the basic administrative tasks needed to

support the two modes of operation, and describes the additional step-by-step

procedures needed to configure each mode.

•Working with the web portal introduces the web portal applications and

explains how to work with them. The chapter also explains how to install the

ActiveX plugin and initiate a VPN tunnel when tunnel mode is enabled.

Document conventions

The following document conventions are used in this guide:

• In the examples, private IP addresses are used for both private and public IP

addresses.

• Notes and Cautions are used to provide important information:

Note: Highlights useful additional information.

!

Caution: Warns you about commands or procedures that could have unexpected or

undesirable results including loss of data or damage to equipment.

Introduction FortiGate documentation

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 9

Typographic conventions

FortiGate documentation uses the following typographical conventions:

FortiGate documentation

The most up-to-date publications and previous releases of Fortinet product

documentation are available from the Fortinet Technical Documentation web site

at http://docs.forticare.com.

The following FortiGate product documentation is available:

• FortiGate QuickStart Guide

Provides basic information about connecting and installing a FortiGate unit.

• FortiGate Installation Guide

Describes how to install a FortiGate unit. Includes a hardware reference,

default configuration information, installation procedures, connection

procedures, and basic configuration procedures. Choose the guide for your

product model number.

• FortiGate Administration Guide

Provides basic information about how to configure a FortiGate unit, including

how to define FortiGate protection profiles and firewall policies; how to apply

intrusion prevention, antivirus protection, web content filtering, and spam

filtering; and how to configure a VPN.

• FortiGate online help

Provides a context-sensitive and searchable version of the Administration

Guide in HTML format. You can access online help from the web-based

manager as you work.

Convention Example

Keyboard input In the Name field, type admin.

Code examples config sys global

set ips-open enable

end

CLI command syntax config firewall policy

edit id_integer

set http_retry_count <retry_integer>

set natip <address_ipv4mask>

end

Document names FortiGate SSL VPN User Guide

File content <HTML><HEAD><TITLE>Firewall

Authentication</TITLE></HEAD>

<BODY><H4>You must authenticate to use this

service.</H4>

Menu commands Go to VPN > SSL > Config.

Program output Welcome!

Variables <group_name>

FortiOS v3.0 MR7 SSL VPN User Guide

10 01-30007-0348-20080718

Related documentation Introduction

• FortiGate CLI Reference

Describes how to use the FortiGate CLI and contains a reference to all

FortiGate CLI commands.

• FortiGate Log Message Reference

Available exclusively from the Fortinet Knowledge Center, the FortiGate Log

Message Reference describes the structure of FortiGate log messages and

provides information about the log messages that are generated by FortiGate

units.

• FortiGate High Availability User Guide

Contains in-depth information about the FortiGate high availability feature and

the FortiGate clustering protocol.

• FortiGate IPS User Guide

Describes how to configure the FortiGate Intrusion Prevention System settings

and how the FortiGate IPS deals with some common attacks.

• FortiGate IPSec VPN User Guide

Provides step-by-step instructions for configuring IPSec VPNs using the web-

based manager.

• FortiGate SSL VPN User Guide

Compares FortiGate IPSec VPN and FortiGate SSL VPN technology, and

describes how to configure web-only mode and tunnel-mode SSL VPN access

for remote users through the web-based manager.

• FortiGate PPTP VPN User Guide

Explains how to configure a PPTP VPN using the web-based manager.

• FortiGate Certificate Management User Guide

Contains procedures for managing digital certificates including generating

certificate requests, installing signed certificates, importing CA root certificates

and certificate revocation lists, and backing up and restoring installed

certificates and private keys.

• FortiGate VLANs and VDOMs User Guide

Describes how to configure VLANs and VDOMS in both NAT/Route and

Transparent mode. Includes detailed examples.

Related documentation

Additional information about Fortinet products is available from the following

related documentation.

FortiManager documentation

• FortiManager QuickStart Guide

Explains how to install the FortiManager Console, set up the FortiManager

Server, and configure basic settings.

• FortiManager System Administration Guide

Describes how to use the FortiManager System to manage FortiGate devices.

• FortiManager System online help

Provides a searchable version of the Administration Guide in HTML format.

You can access online help from the FortiManager Console as you work.

Introduction Related documentation

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 11

FortiClient documentation

• FortiClient Host Security User Guide

Describes how to use FortiClient Host Security software to set up a VPN

connection from your computer to remote networks, scan your computer for

viruses, and restrict access to your computer and applications by setting up

firewall policies.

• FortiClient Host Security online help

Provides information and procedures for using and configuring the FortiClient

software.

FortiMail documentation

• FortiMail Administration Guide

Describes how to install, configure, and manage a FortiMail unit in gateway

mode and server mode, including how to configure the unit; create profiles and

policies; configure antispam and antivirus filters; create user accounts; and set

up logging and reporting.

• FortiMail online help

Provides a searchable version of the Administration Guide in HTML format.

You can access online help from the web-based manager as you work.

• FortiMail Web Mail Online Help

Describes how to use the FortiMail web-based email client, including how to

send and receive email; how to add, import, and export addresses; and how to

configure message display preferences.

FortiAnalyzer documentation

• FortiAnalyzer Administration Guide

Describes how to install and configure a FortiAnalyzer unit to collect FortiGate

and FortiMail log files. It also describes how to view FortiGate and FortiMail log

files, generate and view log reports, and use the FortiAnalyzer unit as a NAS

server.

• FortiAnalyzer online help

Provides a searchable version of the Administration Guide in HTML format.

You can access online help from the web-based manager as you work.

Fortinet Tools and Documentation CD

All Fortinet documentation is available from the Fortinet Tools and Documentation

CD shipped with your Fortinet product. The documents on this CD are current at

shipping time. For up-to-date versions of Fortinet documentation see the Fortinet

Technical Documentation web site at http://docs.forticare.com.

Fortinet Knowledge Center

Additional Fortinet technical documentation is available from the Fortinet

Knowledge Center. The knowledge center contains troubleshooting and how-to

articles, FAQs, technical notes, and more. Visit the Fortinet Knowledge Center at

http://kc.forticare.com.

FortiOS v3.0 MR7 SSL VPN User Guide

12 01-30007-0348-20080718

Customer service and technical support Introduction

Comments on Fortinet technical documentation

Please send information about any errors or omissions in this document, or any

Fortinet technical documentation, to techdoc@fortinet.com.

Customer service and technical support

Fortinet Technical Support provides services designed to make sure that your

Fortinet systems install quickly, configure easily, and operate reliably in your

network.

Please visit the Fortinet Technical Support web site at http://support.fortinet.com

to learn about the technical support services that Fortinet provides.

Configuring a FortiGate SSL VPN Comparison of SSL and IPSec VPN technology

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 13

Configuring a FortiGate SSL VPN

This section provides a comparison of SSL and IPSec VPN technology, in addition

to an overview of the two modes of SSL VPN operation. The high-level steps for

configuring each mode are also included with cross-references to underlying

procedures.

The following topics are included in this section:

•Comparison of SSL and IPSec VPN technology

•SSL VPN modes of operation

•Topology

•Configuration overview

•Configuring SSL VPN settings

•Configuring user accounts and SSL VPN user groups

•Configuring firewall policies

•Configuring SSL VPN event-logging

•Monitoring active SSL VPN sessions

•Configuring SSL VPN bookmarks and bookmark groups

•SSL VPN host OS patch check

•Granting unique access permissions for SSL VPN tunnel user groups

•SSL VPN virtual interface (ssl.root)

•SSL VPN dropping connections

Comparison of SSL and IPSec VPN technology

The FortiGate unit supports both SSL and IPSec VPN technologies. Each

combines encryption and VPN gateway functions to create private communication

channels over the Internet, which helps to defray physical network costs. Both

enable you to define and deploy network access and firewall policies using a

single management tool. In addition, both support a simple client/user

authentication process (including optional X.509 security certificates). You have

the freedom to use both technologies; however, one may be better suited to the

requirements of your situation.

In general, IPSec VPNs are a good choice for site-to-site connections where

appliance-based firewalls are used to provide network protection, and company

sanctioned client computers are issued to users. SSL VPNs are a good choice for

roaming users who depend on a wide variety of thin-client computers to access

enterprise applications and/or company resources from a remote location.

SSL and IPSec VPN tunnels may operate simultaneously on the same FortiGate

unit.

FortiOS v3.0 MR7 SSL VPN User Guide

14 01-30007-0348-20080718

Comparison of SSL and IPSec VPN technology Configuring a FortiGate SSL VPN

Legacy versus web-enabled applications

IPSec is well suited to network-based legacy applications that are not web-based.

As a layer 3 technology, IPSec creates a secure tunnel between two host devices.

IP packets are encapsulated by the VPN client and server software running on the

hosts.

SSL is typically used for secure web transactions in order to take advantage of

web-enabled IP applications. After a secure HTTP link has been established

between the web browser and web server, application data is transmitted directly

between selected client and server applications through the tunnel.

Authentication differences

IPSec is a well-established technology with robust features that support many

legacy products such as smart cards and biometrics.

SSL supports sign-on to a web portal front-end, from which a number of different

enterprise applications may be accessed. The Fortinet implementation enables

you to assign a specific port for the web portal and to customize the login page if

desired.

Connectivity considerations

IPSec supports multiple connections to the same VPN tunnel—a number of

remote VPN devices effectively become part of the same network.

SSL forms a connection between two end points such as a remote client and an

enterprise network. Transactions involving three (or more) parties are not

supported because traffic passes between client and server applications only.

Relative ease of use

Although managing IPSec VPNs has become easier, configuring SSL VPNs is

simple in comparison. IPSec protocols may be blocked or restricted by some

companies, hotels, and other public places, whereas the SSL protocol is usually

unrestricted.

Client software requirements

Dedicated IPSec VPN software must be installed on all IPSec VPN peers and

clients and the software has to be configured with compatible settings.

To access server-side applications with SSL VPN, the remote user must have a

web browser (Internet Explorer, Netscape, or Mozilla/Firefox), and if Telnet//RDP

are used, Sun Java runtime environment. Tunnel-mode client computers must

also have ActiveX (IE) or Java Platform (Mozilla/Firefox) enabled.

Access control

IPSec VPNs provide secure network access only. Access to the network

resources on a corporate IPSec VPN can be enabled for specific IPSec peers

and/or clients. The amount of security that can be applied to users is limited.

Configuring a FortiGate SSL VPN SSL VPN modes of operation

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 15

SSL VPNs provide secure access to certain applications. Web-only mode

provides remote users with access to server applications from any thin client

computer equipped with a web browser. Tunnel-mode provides remote users with

the ability to connect to the internal network from laptop computers as well as

airport kiosks, Internet cafes, and hotels. Access to SSL VPN applications is

controlled through user groups.

Session failover support

In a FortiGate high availability (HA) cluster with session pickup enabled, session

failover is supported for IPSec VPN tunnels. After an HA failover, IPSec VPN

tunnel sessions will continue with no loss of data.

Session failover is not supported by SSL VPN tunnels, however cookie failover is

supported for communication between the SSL VPN client and the FortiGate unit.

This means that after a failover, the SSL VPN client can re-establish the SSL VPN

session without having to authenticate again. However, all sessions inside the

SSL VPN tunnel with resources behind the FortiGate unit will stop, and will

therefore have to be restarted.

SSL VPN modes of operation

When a remote client connects to the FortiGate unit, the FortiGate unit

authenticates the user based on user name, password, and authentication

domain. A successful login determines the access rights of remote users

according to user group. The user group settings specify whether the connection

will operate in web-only mode (see “Web-only mode” on page 15) or tunnel mode

(see “Tunnel mode” on page 17).

You can enable a client integrity checker to scan the remote client. The integrity

checker probes the remote client computer to verify that it is “safe” before access

is granted. Security attributes recorded on the client computer (for example, in the

Windows registry, in specific files, or held in memory due to running processes)

are examined and uploaded to the FortiGate unit.

You can enable a cache cleaner to remove any sensitive data that would

otherwise remain on the remote computer after the session ends. For example, all

cache entries, browser history, cookies, encrypted information related to user

authentication, and any temporary data generated during the session are

removed from the remote computer. If the client’s browser cannot install and run

the cache cleaner, the user is not allowed to access the SSL-VPN portal.

Web-only mode

Web-only mode provides remote users with a fast and efficient way to access

server applications from any thin client computer equipped with a web browser.

Web-only mode offers true clientless network access using any web browser that

has built-in SSL encryption and the Sun Java runtime environment.

Support for SSL VPN web-only mode is built into the FortiOS operating system.

The feature comprises an SSL daemon running on the FortiGate unit, and a web

portal, which provides users with access to network services and resources

including HTTP/HTTPS, telnet, FTP, SMB/CIFS, VNC, RDP and SSH.

FortiOS v3.0 MR7 SSL VPN User Guide

16 01-30007-0348-20080718

SSL VPN modes of operation Configuring a FortiGate SSL VPN

In web-only mode, the FortiGate unit acts as a secure HTTP/HTTPS gateway and

authenticates remote users as members of a user group. After successful

authentication, the FortiGate unit redirects the web browser to the web portal

home page and the user can access the server applications behind the FortiGate

unit.

Configuring the FortiGate unit involves selecting web-only-mode access in the

user group settings and enabling the feature through SSL VPN configuration

settings. The user group settings determine which server applications can be

accessed. SSL encryption is used to ensure traffic confidentiality.

Web-only mode client requirements

The remote client computer must be equipped with the following software:

• Microsoft Windows 2000/XP/2003/Vista, Linux, MacOS X, or UNIX operating

system

• Microsoft Internet Explorer 6.0 (or later), Netscape Navigator 7.0 (or later),

Mozilla Foundation/Firefox 1.5 (or later), or Apple Safari 1.3 (or later)

• If Telnet/ or RDP are used, Sun Java runtime environment 1.4 (or later), with

Java applet access, JavaScript access, and enabled cookie acceptance

Tunnel mode

Tunnel mode offers remote users the freedom to connect to the internal network

using the traditional means of web-based access from laptop computers, as well

as from airport kiosks, hotel business centers, and Internet cafés. If the

applications on the client computers used by your user community vary greatly,

you can deploy a dedicated SSL VPN client to any remote client through its web

browser. The SSL VPN client encrypts all traffic from the remote client computer

and sends it to the FortiGate unit through an SSL VPN tunnel over the HTTPS link

between the web browser and the FortiGate unit. Also available is split tunneling,

which ensures that only the traffic for the private network is sent to the SSL VPN

gateway. Internet traffic is sent through the usual unencrypted route. This

conserves bandwith and alleviates bottlenecks.

In tunnel mode, remote clients connect to FortiGate unit and the web portal login

page using Microsoft Internet Explorer, Mozilla Foundation/Firefox, MacOS, or

Linux. The FortiGate unit acts as a secure HTTP/HTTPS gateway and

authenticates remote users as members of a user group. After successful

authentication, the FortiGate unit redirects the web browser to the web portal

home page. The user can then download the SSL VPN client (an ActiveX or Java

plugin) and install it using controls provided through the web portal. SSL VPN

tunnel mode can also be initiated from a standalone application on

Windows/MacOS, and Unix.

Note: Web browsers offer different SSL security capabilities. The FortiGate unit offers an

SSL version 2 option through the CLI if required to support older browsers. In addition, the

FortiGate unit supports a range of cipher suites for negotiating SSL communications with a

variety of web browsers. The web browser must at least support a 64-bit cipher length.

Configuring a FortiGate SSL VPN Topology

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 17

When the user initiates a VPN connection with the FortiGate unit through the SSL

VPN client, the FortiGate unit establishes a tunnel with the client and assigns the

client a virtual IP address from a range of reserved addresses. The client uses the

assigned IP address as its source address for the duration of the connection. After

the tunnel has been established, the user can access the network behind the

FortiGate unit.

Configuring the FortiGate unit to establish a tunnel with remote clients involves

selecting tunnel-mode access in the user group settings and enabling the feature

through SSL VPN configuration settings. The firewall policy and protection profiles

on the FortiGate unit ensure that inbound traffic is screened and processed

securely.

Tunnel-mode client requirements

The remote computer must be equipped with the following software:

• Microsoft Windows 2000/XP/2003 or Vista (32 or 64-bit), MacOS X v10.3.9,

v10.4 “Tiger”, v10.5 “Leopard”, or Linux Distributions RedHat/Fedora,

Ubuntu/Debian, or Suse

• Microsoft Internet Explorer 6.0 (or later) with ActiveX enabled, or Mozilla

Foundation/Firefox (1.5 or later) with Java Platform enabled

Topology

In the most common Internet scenario, the remote client connects to an ISP that

offers connections with dynamically assigned IP addresses. The ISP forwards

packets from the remote client to the Internet, where they are routed to the public

interface of the FortiGate unit.

At the FortiGate unit, you configure user groups and firewall policies to define the

server applications and IP address range or network that remote clients will be

able to access behind the FortiGate unit.

For example, Figure 1 shows a FortiGate gateway (FortiGate_1) to two private

networks, Subnet_1 and Subnet_2.

Note: The browser requirements only apply if you use the tunnel mode client on Windows

through the browser interface. You do not need a browser if you use the standalone tunnel

client.

Note: The user account used to install the SSL VPN client on the remote computer must

have administrator privileges.

FortiOS v3.0 MR7 SSL VPN User Guide

18 01-30007-0348-20080718

Topology Configuring a FortiGate SSL VPN

Figure 1: Example SSL VPN configuration

To provide remote clients with access to all of the servers on Subnet_1 from the

Internet, you would configure FortiGate_1 as follows:

• Create an SSL VPN user group and include the remote users in the user

group. When you create the user group, you also specify whether the users

may access the web portal in web-only mode or tunnel mode.

• For tunnel-mode users, define the virtual IP addresses that the FortiGate unit

is to assign to remote clients when they connect.

• Create a firewall destination IP address of 172.16.10.0/24.

• Create a firewall policy to allow the SSL VPN user group members to connect

to Subnet_1 through the VPN. For more information, see “Configuring firewall

policies” on page 45.

If your user community needs access to Subnet_2, you would create a second

firewall destination IP address of 192.168.22.0/24 and create a second

firewall policy that binds the associated remote clients to the Subnet_2 destination

address.

Infrastructure requirements

• The FortiGate unit must be operating in NAT/Route mode and have a static

public IP address.

• The ISP assigns IP addresses to remote clients before they connect to the

FortiGate unit.

• If the remote clients need web-only mode access, see “Web-only mode client

requirements” on page 16.

• If the remote clients need tunnel-mode access, see “Tunnel-mode client

requirements” on page 18.

Subnet_2

192.168.22.0/24

internal

192.168.22.1

Subnet_1

172.16.10.0/24

HTTP/HTTPS

172.16.10.2

Telnet

172.16.10.3

FTP

172.16.10.4

SMB/CIFS

172.16.10.5

Internet

FortiGate_1

wan1

dmz

172.16.10.1

Remote client

Configuring a FortiGate SSL VPN Configuration overview

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 19

Configuration overview

Before you begin, install your choice of HTTP/HTTPS, telnet, SSH, FTP,

SMB/CIFS, VNC, and/or RDP server applications on the internal network. As an

alternative, these services may be accessed remotely through the Internet. All

services must be running. Users must have individual user accounts to access the

servers (these user accounts are not related to FortiGate user accounts or

FortiGate user groups).

To configure FortiGate SSL VPN technology, you should follow these general

steps:

1Enable SSL VPN connections and set the basic options needed to support SSL

VPN configurations. See “Configuring SSL VPN settings” on page 36.

2To use X.509 security certificates for authentication purposes, load the signed

server certificate, CA root certificate, and Certificate Revocation List (CRL) onto

the FortiGate unit, and load the personal/group certificates onto the remote

clients. For more information, see the FortiGate Certificate Management User

Guide.

3Create one FortiGate user account for each remote client, and assign the users to

SSL VPN type user groups. See “Configuring user accounts and SSL VPN user

groups” on page 42.

4Configure the firewall policy and the remaining parameters needed to support the

required mode of operation:

• For web-only mode operation, see “Configuring Web-only firewall policies” on

page 46.

• For tunnel-mode operation, see “Configuring tunnel-mode firewall policies” on

page 48.

5Define SSL VPN event-logging parameters. See “Configuring SSL VPN event-

logging” on page 50.

6You can also monitor active SSL VPN sessions. See “Monitoring active SSL VPN

sessions” on page 51.

Configuring the SSL VPN client

There are several configurations of SSL VPN applications available. The SSL

VPN tunnel client application installs a network driver on the client machine that

redirects all network traffic through the SSL VPN tunnel (it is necessary for the

driver to be OS-specific).

SSL VPN web-mode works on all OSs and browsers. The tunnel mode client can

be downloaded and installed from the browser interface on Windows platforms

through ActiveX for IE, or Firefox plug-ins. If you prefer not to initiate the tunnel

mode client function using a browser, standalone SSL VPN tunnel client

applications are available for Windows, Linux, and MacOS (see Tunnel-mode

client requirements for the specific versions that are supported). When a system

configuration must involve more secure disposal of cached data, the SSL VPN

Virtual Desktop should be used. (Windows XP only).

FortiOS v3.0 MR7 SSL VPN User Guide

20 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

SSL VPN Virtual Desktop application.

The virtual desktop application creates a virtual desktop on a user's PC and

monitors the data read/write activity of the web browser running inside the virtual

desktop. When the application starts, it presents a ‘virtual desktop’ to the user.

The user starts the web browser from within the virtual desktop and connects to

the ssl vpn web portal. The browser file/directory operation is redirected to a new

location, and the data is encrypted before it is written to the local disk. When the

virtual desktop application exits normally, all the data written to the disk is

removed. If the session terminates abnormally (power loss, system failure), the

data left behind is encrypted and unusable to the user. The next time you start the

virtual desktop, the encrypted data is removed.

Using the SSL VPN Virtual Desktop

On the FortiGate unit GUI under SSL VPN User Group Options, the 'Require

Virtual Desktop Connection' option is not selected by default. If you choose to use

the SSL VPN virtual desktop option, users are forced to use the virtual desktop to

initiate a SSL VPN session. The user must install the FortiClient SSL VPN virtual

desktop application on the client machine and run it. If a user attempts to establish

a VPN connection that does not use the virtual desktop, the connection is refused.

The most recent version of the SSL VPN virtual desktop application can be found

at:

http://support.fortinet.com/

Windows XP is supported in the current release.

To download and run the SSL VPN Virtual Desktop application

1Go to the Fortinet Technologies home page at http://support.fortinet.com/ and

select Support.

2Under Support, enter your user name and password.

This takes you to the Fortinet customer support site.

3Select Firmware Images and then FortiGate.

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 21

The FortiGate index page opens.

4Select v3.0 and then MR7.

This takes you to the page with firmware images for MR7.

5Select SSL VPN Clients.

FortiOS v3.0 MR7 SSL VPN User Guide

22 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

6To download the SSL VPN Virtual Desktop, select

SSLVPNVirtualDesktopSetup_3.0.384.exe and follow the InstallShield

Wizard instructions.

Figure 2: FortiClient SSL VPN InstallShield Wizard welcome screen

7To run the SSL VPN Virtual Desktop application, select Start > All Programs >

FortiNet > SSL VPN Virtual Desktop > SSL VPN Virtual Desktop.

The FortiGate unit may offer you a self-signed security certificate. If you are

prompted to proceed, select Yes.

8When you are prompted for your user name and password:

• In the Name field, type your user name.

• In the Password field, type your password.

9Select Login.

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 23

The FortiGate unit will redirect your web browser to the FortiGate SSL VPN

Remote Access Web Portal home page automatically.

The fields in the Tools area enable you to specify the URL or IP address of a host

computer. If required, you can ping a host computer behind the FortiGate unit to

verify connectivity to that host.

To connect to a web server from the Tools area

1In the Connect to Web Server field, type the URL of the web server (for example,

http://www.mywebexample.com or https://172.20.120.101).

2Select Go.

The FortiGate unit replaces the URL with

https://<FG_IP_address>:<port_no>/proxy/http/<specified_URL> and

the requested page is displayed.

3To end the session, close the browser window.

To ping a host or server behind the FortiGate unit

1In the Test for Reachability (Ping) field, type the IP address of the host or server

that you want to reach (for example, 192.168.12.22).

2Select Go.

A message stating whether the IP address can be reached or not is displayed.

Using the SSL VPN standalone tunnel clients

SSL VPN standalone tunnel client applications are available for Windows, Linux,

and MacOS systems (see Tunnel-mode client requirements for the specific

versions that are supported). There are separate download files for each

operating system.

The most recent version of the SSL VPN standalone client applications can be

found at:

http://support.fortinet.com/

FortiOS v3.0 MR7 SSL VPN User Guide

24 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

To download the SSL VPN standalone tunnel client (Windows)

1Go to the Fortinet Technologies home page at http://support.fortinet.com/ and

select Support.

2Under Support, enter your user name and password.

This takes you to the Fortinet customer support site.

3Select Firmware Images and then FortiGate.

Figure 3: Firmware Images selection on Fortinet customer support site

The FortiGate index page opens.

Figure 4: FortiGate index page

4Select v3.0 and then MR7.

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 25

This takes you to the page with firmware images for MR7.

5Select SSL VPN Clients.

6To download the SSL VPN Windows client application, select

FortiClientSSLVPNSetup_3.0.384.exe or

FortiClientSSLVPN_3.0_384.msi and follow the InstallShield Wizard

instructions.

FortiOS v3.0 MR7 SSL VPN User Guide

26 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

To use the SSL VPN standalone tunnel client (Windows)

1Go to Start > All Programs > Fortinet > FortiClient SSL VPN >

FortiClient SSL VPN.

2Select Connect.

3To manually terminate the connection, select Exit.

To uninstall the SSL VPN standalone tunnel client (Windows)

1Go to Start > Control Panel.

2Select Add or Remove Programs.

3Select ‘FortiClient SSL VPN’ and then Remove.

Server Address Enter the IP address of the server you need to access.

Username Enter your user name.

Password Enter the password associated with your user account.

Expand button Select to expand the dialog box and display Client Certificate,

Save user name and password, and Keep connection alive

until manually stopped.

Client Certificate Select the authentication certificate from the drop-down list, if

required.

Save user name and

password Select to save the value in Username and Password for future

logins.

Keep connection

alive until manually

stopped

Select to have the connection stay up until you log out.

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 27

To download the SSL VPN standalone tunnel client (Linux)

1Go to the Fortinet Technologies home page at http://support.fortinet.com/ and

select Support.

2Under Support, enter your user name and password.

This takes you to the Fortinet customer support site.

3Select Firmware Images and then FortiGate.

The FortiGate index page opens.

4Select v3.0 and then MR7.

FortiOS v3.0 MR7 SSL VPN User Guide

28 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

This takes you to the page with firmware images for MR7.

5Select SSL VPN Clients.

6To download the SSL VPN standalone tunnel client (Linux), select

forticlientsslvpn_linux_3.0.384.tar.gz, extract the package file to a folder and run

the client program ‘forticlientsslvpn’.

When you run the install program for the first time, you will have to set up system

parameters (root privileges) before you run the program or before other users without

administrator privileges can use the application.

7In the First Run dialog, select OK.

The command line terminal window opens.

8Type your password and select Enter.

The License Agreement dialog appears in the command line terminal window.

9Accept the License Agreement, and select Enter.

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 29

The FortiClient SSL VPN tunnel client (Linux) opens.

After this initial setup is complete, a user with a normal (non-administrator)

account can establish a SSL VPN tunnel session.

FortiOS v3.0 MR7 SSL VPN User Guide

30 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

To use the SSL VPN standalone tunnel client (Linux)

1Go to the folder that you downloaded the Linux tunnel client application into, and

double-click on ‘forticlientsslvpn’.

The FortiClient SSL VPN tunnel client (Linux) opens.

Server Enter the IP address of the server you need to access.

User Enter your user name.

Password Enter the password associated with your user account.

Advanced settings

Save user name

and password Select to save the value in User and Password for future logins.

Keep connection

alive until manually

stopped

Select to have the connection stay up until you log out.

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 31

To uninstall the SSL VPN standalone tunnel client (Linux)

Remove/delete the folder containing all the SSL VPN client application files.

To download the SSL VPN standalone tunnel client (MacOS)

1Go to the Fortinet Technologies home page at http://support.fortinet.com/ and

select Support.

2Under Support, enter your user name and password.

This takes you to the Fortinet customer support site.

3Select Firmware Images and then FortiGate.

The FortiGate index page opens.

Use Client

Certificate (A PKCS

#12 File)

File Path Enter the path to the certificate file, or browse

to the location of the file.

File Password Enter the password associated with the

certificate file.

Use Proxy Select to make it necessary for the user to utilize a proxy server.

Proxy Enter the IP address of the proxy server and the port identifier.

User Enter the user name of the client using the proxy server.

Password Enter the user password for the client to access the proxy server.

Connect Initiate the SSL VPN tunnel connection.

FortiOS v3.0 MR7 SSL VPN User Guide

32 01-30007-0348-20080718

Configuring the SSL VPN client Configuring a FortiGate SSL VPN

4Select v3.0 and then MR7.

This takes you to the page with firmware images for MR7.

5Select SSL VPN Clients.

6To download the SSL VPN MacOS client application, double-click on the client file

forticlientsslvpn_macosx_3.0.384.dmg.

The Mac mounts the disk image as ‘forticlientsslvpn’.

7Double-click the forticlientsslvpn.pkg file inside the disk image and follow the

instructions.

The application installs the program ‘forticlientsslvpn’ in the Applications

folder

8Unmount the disk image by selecting the disk image file

‘forticlientsslvpn_macos_3.0.nnn.dmg’ and dragging it into the Trash

(nnn refers to the build number).

Configuring a FortiGate SSL VPN Configuring the SSL VPN client

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 33

To use the SSL VPN standalone tunnel client (MacOS)

1Go to the Applications folder and double-click on forticlientsslvpn.

The FortiClient SSL VPN tunnel client (MacOS) opens.

To uninstall the SSL VPN standalone tunnel client (MacOS)

2In the Applications folder, select ‘forticlientsslvpn’ and drag it into the

Trash.

After you empty the Trash folder, the installed program is removed from the user

computer.

FortiOS v3.0 MR7 SSL VPN User Guide

34 01-30007-0348-20080718

Configuring SSL VPN settings Configuring a FortiGate SSL VPN

Configuring SSL VPN settings

You can configure and manage the FortiGate unit through a secure HTTP

(HTTPS) connection from any computer running a web browser. For information

about how to connect to the web-based manager, see “Connecting to the web-

based manager” in the FortiGate Installation Guide.

Refer to the FortiGate Installation Guide and FortiGate Administration Guide to

change the password, configure the interfaces of the FortiGate unit, and assign

basic operating parameters, including a default gateway.

There are basic administrative tasks common to all modes of operation that must

be completed first, regardless of the connection mode you select.

The VPN > SSL > Config page contains basic SSL VPN settings including idle-

timeout values and SSL encryption preferences for compatibility with various web

browsers. You may also optionally enable authentication through X.509 security

certificates (for more information about security certificates, see the FortiGate

Certificate Management User Guide).

In addition to setting these preferences on the VPN > SSL > Config page, you

may choose to modify the following system settings:

• The FortiGate unit redirects web browsers to the web portal home page after

the remote client has been authenticated and the user has logged in

successfully. As an option, you can display a second HTML page in a popup

window for all members of a user group. For more information, see

“Redirecting a user group to a popup window” on page 40.

• You can customize the look of the web portal login page through replacement

messages. For more information, see “Customizing the web portal login page”

on page 41.

Enabling SSL VPN connections and editing SSL VPN settings

To enable SSL VPN connections and configure or edit SSL VPN settings, go to

VPN > SSL > Config and select Enable SSL-VPN. The FortiGate unit does not

accept web-only mode or tunnel-mode connections while SSL VPN operation is

disabled.

Note: As an alternative, you can connect the management computer to the Console

connector of the FortiGate unit directly using a serial cable and configure the FortiGate unit

through the Command Line Interface (CLI). The CLI can also be launched from within the

web-based manager. For more information, see “Connecting to the FortiGate console” in

the FortiGate CLI Reference.

Configuring a FortiGate SSL VPN Configuring SSL VPN settings

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 35

Figure 5: Edit SSL VPN settings

Enable SSL VPN Select to enable SSL VPN connections.

Tunnel IP Range Specify the range of IP addresses reserved for tunnel-

mode SSL VPN clients. Type the starting and ending

address that defines the range of reserved IP

addresses. See Specifying an IP address range for

tunnel-mode clients.

Server Certificate Select the signed server certificate to use for

authentication purposes. If you leave the default setting

(Self-Signed), the FortiGate unit offers its factory

installed (self-signed) certificate from Fortinet to remote

clients when they connect. See Enabling strong

authentication through security certificates.

Require Client Certificate If you want to enable the use of group certificates for

authenticating remote clients, select the option.

Afterward, when the remote client initiates a connection,

the FortiGate unit prompts the client for its client-side

certificate as part of the authentication process.

Encryption Key Algorithm

See Specifying the cipher suite

for SSL negotiations.

Select the algorithm for creating a secure SSL

connection between the remote client web browser and

the FortiGate unit.

Default - RC4(128

bits) and higher If the web browser on the remote client is capable of

matching a 128-bit or greater cipher suite, select this

option.

High - AES(128/256

bits) and 3DES If the web browser on the remote client is capable of

matching a high level of SSL encryption, select this

option to enable cipher suites that use more than 128

bits to encrypt data.

Low - RC4(64 bits),

DES and higher If you are not sure which level of SSL encryption the

remote client web browser supports, select this option to

enable a 64-bit or greater cipher suite.

FortiOS v3.0 MR7 SSL VPN User Guide

36 01-30007-0348-20080718

Configuring SSL VPN settings Configuring a FortiGate SSL VPN

When you finish making your selections, select Apply.

Specifying a port number for web portal connections

You can optionally specify a different TCP port number for users to access the

web portal login page through the HTTPS link. By default, the port number is

10443 and users can access the web portal login page using the following default

URL:

https://<FortiGate_IP_address>:10443/remote

where <FortiGate_IP_address> is the IP address of the FortiGate interface that

accepts connections from remote users.

1Go to System > Admin > Settings.

2In the SSLVPN Login Port field, type an unused port number.

3Select Apply.

Specifying an IP address range for tunnel-mode clients

The Tunnel IP Range fields on the VPN > SSL > Config page enable you to

reserve a range of IP addresses for remote SSL VPN clients. After the FortiGate

unit authenticates a request for a tunnel-mode connection, the SSL VPN client

connects to the FortiGate unit and is assigned an IP address from this range.

Afterward, the FortiGate unit uses the assigned address to communicate with the

SSL VPN client.

Idle Timeout Type the period of time (in seconds) to control how long

the connection can remain idle before the system forces

the user to log in again. The range is from 10 to 28800

seconds. This setting applies to the SSL VPN session.

The interface does not time out when web application

sessions or tunnels are up. See Setting the idle timeout

setting.

Portal Message If you want to display a custom caption at the top of the

web portal home page, type the message. See Adding a

custom caption to the web portal home page.

Advanced (DNS and WINS Servers) See Adding WINS and DNS services for clients.

DNS Server #1

DNS Server #2 Enter up to two DNS Servers to be provided for the use

of clients.

WINS Server #1

WINS Server #2 Enter up to two WINS Servers to be provided for the use

of clients.

Note: The Tunnel IP Range fields are used to configure tunnel-mode access only. If you

are configuring web-only mode operation, leave 0.0.0.0 values in the Tunnel IP Range

fields. If you are configuring tunnel-mode operation, see “Specifying an IP address range

for tunnel-mode clients” on page 38. For information about enabling certificate-based

authentication through the Server Certificate and Require Client Certificate options, refer to

the FortiGate Certificate Management User Guide.

Note: Do not select port number 443 for user access to the web portal login page. Port

number 443 is reserved to support administrative connections to the FortiGate unit through

the web-based manager.

!

Caution: Take care to prevent overlapping IP addresses. Do not assign IP addresses that

are already in use on the private network. As a precaution, consider assigning IP

addresses from a network that is not commonly used (for example, 10.254.254.0/24).

Configuring a FortiGate SSL VPN Configuring SSL VPN settings

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 37

To reserve a range of IP addresses for tunnel-mode clients

1Go to VPN > SSL > Config.

2In the Tunnel IP Range fields, type the starting and ending IP addresses (for

example, 10.254.254.80 to 10.254.254.100).

3Select Apply.

Enabling strong authentication through security certificates

The FortiGate unit supports strong (two-factor) authentication through X.509

security certificates (version 1 or 3). Strong authentication can be configured for

SSL VPN user groups by selecting the Server Certificate and Require Client

Certificate options on the VPN > SSL > Config page. However, you must first

ensure that the required certificates have been installed.

To generate certificate requests, install signed certificates, import CA root

certificates and certificate revocation lists, and back up and/or restore installed

certificates and private keys, refer to the FortiGate Certificate Management User

Guide.

Specifying the cipher suite for SSL negotiations

The FortiGate unit supports a range of cryptographic cipher suites to match the

capabilities of various web browsers. The web browser and the FortiGate unit

negotiate a cipher suite before any information (for example, a user name and

password) is transmitted over the SSL link.

1Go to VPN > SSL > Config.

2In Encryption Key Algorithm, select one of the following options:

• If the web browser on the remote client is capable of matching a 128-bit or

greater cipher suite, select Default - RC4(128 bits) and higher.

• If the web browser on the remote client is capable of matching a high level of

SSL encryption, select High - AES(128/256 bits) and 3DES. This option

enables cipher suites that use more than 128 bits to encrypt data.

• If you are not sure which level of SSL encryption the remote client web

browser supports, select Low - RC4(64 bits), DES and higher. The web

browser must at least support a 64-bit cipher length.

3Select Apply.

Setting the idle timeout setting

The idle timeout setting controls how long the connection can remain idle before

the system forces the remote user to log in again. To improve security, keep the

default value of 300 seconds.

1Go to VPN > SSL > Config.

2In the Idle Timeout field, type an integer value. The valid range is from 10 to

28800 seconds.

3Select Apply.

FortiOS v3.0 MR7 SSL VPN User Guide

38 01-30007-0348-20080718

Configuring SSL VPN settings Configuring a FortiGate SSL VPN

Setting the client authentication timeout setting

The client authentication timeout setting controls how long an authenticated

connection will remain connected. When this time expires, the system forces the

remote client to authenticate again.

For example, to change the authentication timeout to 1800 seconds, enter the

following commands:

config vpn ssl settings

set auth-timeout 1800

end

Adding a custom caption to the web portal home page

You can add a custom caption (maximum 31 characters) to the top of the web

portal home page.

To add a custom caption

1Go to VPN > SSL > Config.

2In the Portal Message field, type the caption.

3Select Apply.

Adding WINS and DNS services for clients

You can specify the WINS or DNS servers that are made available to SSL-VPN

clients.

1Go to VPN > SSL > Config.

2Select the blue triangle to open the Advanced section.

3Enter the IP addresses of one or two DNS Servers to be provided for the use of

clients.

4Enter the IP addresses of one or two WINS Servers to be provided for the use of

clients.

Redirecting a user group to a popup window

The FortiGate unit redirects web browsers to the web portal home page after the

remote client has been authenticated and the user has logged in successfully.

As an option, you can have the FortiGate unit display a second HTML page in a

popup window when the client web browser is redirected to the web portal home

page. To support this feature, the level of security settings associated with the

Internet zone in the web browser must be set to permit popup windows.

The following procedure assumes that SSL VPN user groups have been defined

(see “Configuring user accounts and SSL VPN user groups” on page 42). A

different popup window can be specified per user group.

To display a custom popup window for a user group

1Go to User > User Group.

Note: The default value is 1500 seconds. You can only modify this timeout value in the CLI.

Configuring a FortiGate SSL VPN Configuring user accounts and SSL VPN user groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 39

2Select the Edit icon in the row that corresponds to the SSL VPN user group.

3Expand SSL-VPN User Group Options.

4In the Redirect URL field, type the URL of the web page that you want to display in

the popup window.

5Select OK.

Customizing the web portal login page

The HTML code making up the web portal login page can be edited. Before you

begin, copy the default text to a separate text file for safe-keeping. Afterward, if

editing produces unexpected results, you can restore the text to the original

version.

To edit the HTML code

1Go to System > Config > Replacement Messages.

2Expand the SSL VPN row and select the Edit icon that corresponds to the SSL

VPN login message.

3Edit the HTML text, subject to the restrictions given in the FortiGate Administration

Guide (see “Changing the authentication login page” in the “System Config”

chapter).

Select OK.

Configuring user accounts and SSL VPN user groups

Remote users must be authenticated before they can request services and/or

access network resources through the web portal. The authentication process

relies on FortiGate user group definitions, which can optionally use established

authentication mechanisms such as RADIUS and LDAP to authenticate remote

clients.

FortiOS v3.0 MR7 SSL VPN User Guide

40 01-30007-0348-20080718

Configuring user accounts and SSL VPN user groups Configuring a FortiGate SSL VPN

You can choose to use a plain text password for authentication through the

FortiGate unit (Local domain), forward authentication requests to an external

RADIUS or LDAP server, or utilize PKI certificate authentication. If password

protection will be provided through a RADIUS or LDAP server, you must configure

the FortiGate unit to forward authentication requests to the RADIUS or LDAP

server. In the case of certificate authentication, you must install the required

certificates.

The following procedures explain how to create a user account and user group in

the Local domain. For information about how to create RADIUS, LDAP or PKI

user accounts, refer to the “User” chapter of the FortiGate Administration Guide.

For information about certificate authentication, see the FortiGate Certificate

Management User Guide.

To create a user account in the Local domain

1Go to User > Local and select Create New.

2Select OK.

3Repeat this procedure for each remote user.

User Name Type or edit the remote user name (for example, User_1).

Disable Select Disable to prevent this user from authenticating.

Password Select Password to authenticate this user using a password stored on

the SSL VPN unit.

Type or edit the password to be associated with the user account. The

password should be at least six characters long.

LDAP Select LDAP to authenticate this user using a password stored on an

LDAP server. Select the LDAP server from the drop-down list.

RADIUS Select RADIUS to authenticate this user using a password stored on a

RADIUS server. Select the RADIUS server from the drop-down list.

Configuring a FortiGate SSL VPN Configuring user accounts and SSL VPN user groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 41

To create a user group

1Go to User > User Group and select Create New.

2In the Name field, type a name for the group (for example, Web-only_group).

3From the Type drop-down list, select SSL VPN.

4One at a time, select user names from the Available Users/Groups list, and select

the right-pointing arrow to move them to the Members list.

5Select the blue triangle to expand the SSL-VPN User Group Options.

6Select Enable SSL-VPN Tunnel Service if the remote clients associated with the

user group need to establish an SSL VPN tunnel with the FortiGate unit.

Note: If a user has been configured to use tunnel-mode only, when they log in, the tunnel is

brought up automatically. The split tunneling feature is not activated by default, it must be

selected.

FortiOS v3.0 MR7 SSL VPN User Guide

42 01-30007-0348-20080718

Configuring user accounts and SSL VPN user groups Configuring a FortiGate SSL VPN

7To activate the split tunnel feature, select Enable Split Tunneling. Split tunneling

ensures that only the traffic for the private network is sent to the SSL VPN

gateway. Internet traffic is sent through the usual unencrypted route.

8To override the Tunnel IP range defined in VPN > SSL > Config, enter the starting

and ending IP address range for this group in the Restrict tunnel IP range for this

group fields.

9If the user group requires web-only-mode access, select Enable Web Application

and then select the web applications and/or network file services that the user

group needs. The corresponding server applications can be running on the

network behind the FortiGate unit or accessed remotely through the Internet.

10 To enable client-integrity checking options, select from the following:

• Check FortiClient AV Installed and Running

• Check FortiClient FW Installed and Running

• Check for Third Party AV Software

• Check for Third Party Firewall Software

• Require Virtual Desktop Connection

The client-integrity checking options determine whether the FortiClient™ Host

Security application or other antivirus/firewall applications are running on the client

computer before a tunnel is established. The host-checking function is performed

by the ActiveX/Java Platform control, which is downloaded and installed on the

client computer the first time the client initiates the SSL VPN portal.

If there are no applications installed and enabled on the client computer, the

connection is refused. Table 1 lists the products supported for clients who have

Windows XP SP2. All other systems must have Norton (Symantec) AntiVirus or

McAfee VirusScan software installed and enabled.

Note: If you configure a user group and define Restrict tunnel IP range for this group, the

group range is used in the SSL VPN configuration. If you do not define a range of global IP

addresses, you must define a group range. If you define both IP address ranges, the group

level range is applied to the configuration.

Note: The user account used to install the SSL VPN client on the remote computer must

have administrator privileges. If the user account does not have administrator privileges,

the installation will fail (with Windows, there will be no error message with a failed

installation). After the ActiveX or Java Platform control is installed, the client computer can

be used by a user who does not have administrator privileges.

Configuring a FortiGate SSL VPN Configuring firewall policies

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 43

Require Virtual Desktop Connection prevents a user from establishing a SSL VPN

session without using the SSL VPN Virtual Desktop application. For more

information, see the SSL VPN User Guide.

11 To enable the FortiGate unit to remove residual information from the remote client

computer (for example, from the web browser cache) just before the SSL VPN

session ends, select Enable Cache Clean. When this feature is enabled, if the

client’s browser cannot install and run the cache cleaner, the user is not allowed to

access the SSL-VPN portal.

12 To allow the SSL VPN user group to use a pre-configured bookmark group,

enable Bookmarks and select the bookmark group from the drop-down list.

13 To have the FortiGate unit display a second HTML page in a popup window when

the web portal home page is displayed, type the URL of the web page into the

Redirect URL field.

14 To display a custom web portal home page caption for this group, enter the

message in the Customize portal message for this group field.

Note: This custom message overrides the portal message configured in VPN >

SSL > Config.

15 Select OK.

Configuring firewall policies

This section contains the procedures needed to configure firewall policies for web-

only mode operation and tunnel-mode operation. These procedures assume that

you have already completed the procedures outlined in “Configuring user

accounts and SSL VPN user groups” on page 42.

A firewall policy specifies the originating (source) IP address of a packet and the

destination address defines the IP address of the intended recipient or network.

In general, configuring a firewall policy involves:

• specifying the IP source and destination addresses

Table 1: AV/Firewall supported product detection

Product AV Firewall

Norton Internet Security 2006 YY

Trend Micro PC-cillin YY

McAfee YY

Sophos Anti-Virus YN

Panda Platinum 2006 Internet Security YY

F-Secure YY

Secure Resolutions YY

Cat Computer Services YY

AhnLab YY

Kaspersky YY

ZoneAlarm YY

FortiOS v3.0 MR7 SSL VPN User Guide

44 01-30007-0348-20080718

Configuring firewall policies Configuring a FortiGate SSL VPN

• specifying the level of SSL encryption to use and the authentication method

• binding the user group to the firewall policy

The following topics are included in this section:

•Configuring firewall addresses

•Configuring tunnel-mode firewall policies

•Configuring SSL VPN event-logging

•Monitoring active SSL VPN sessions

Configuring firewall addresses

Configuring the firewall addresses for web-only and tunnel mode connections

involves specifying the IP source/host and destination addresses:

Web-only mode:

• For the source address, select the predefined address “all” in the firewall

encryption policy to refer to web-only mode clients.

• The destination address corresponds to the IP address or addresses that

remote clients need to access. The destination address may correspond to

an entire private network (behind the FortiGate unit), a range of private IP

addresses, or the private IP address of a server or host.

Tunnel mode:

• The source address corresponds to the public IP address that can be

connected to the FortiGate unit. This address is used to restrict who can

access the FortiGate unit.

• The destination address corresponds to the IP address or addresses that

remote clients need to access. The destination address may correspond to

an entire private network (behind the FortiGate unit), a range of private IP

addresses, or the private IP address of a server or host.

Configuring Web-only firewall policies

To specify the destination IP address

1Go to Firewall > Address and select Create New.

2In the Address Name field, type a name that represents the local network,

server(s), or host(s) to which IP packets may be delivered (for example,

Subnet_1).

3From the Type list, select Subnet/IP Range.

4In the Subnet/IP Range field, type the corresponding IP address and subnet mask

(for example, 172.16.10.0/24).

Note: In tunnel mode, it is necessary to create a DENY firewall policy that immediately

follows the SSL VPN policy. If this policy is not created, SSL VPN tunnels will use other

ACCEPT firewall policies. See the order of the Firewall policies below:

Configuring a FortiGate SSL VPN Configuring firewall policies

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 45

5Select OK.

To define the firewall policy for web-only mode connections

1Go to Firewall > Policy and select Create New.

2Enter these settings in particular:

3Select OK.

4If the user group requires access to another server or network, create the IP

destination address (see “To specify the destination IP address” on page 46) and

repeat this procedure to create the required firewall policy.

5Create additional IP destination addresses and firewall policies if required for

each additional user group.

Note: To provide access to a single host or server, you would type an IP address like

172.16.10.2/32. To provide access to two servers having contiguous IP addresses, you

would type an IP address range like 172.16.10.[4-5].

Source Interface/Zone

Select the FortiGate interface that accepts connections from remote

users.

Address Name

Select all.

Destination Interface/Zone

Select the FortiGate interface to the local private network (for example,

dmz).

Address Name

Select the IP destination address that you defined previously (for

example, Subnet_1).

Service Select ANY.

Action Select SSL-VPN.

SSL Client

Certificate

Restrictive

Select to allow traffic generated by holders of a (shared) group

certificate, for example, a user group containing PKI peers/users. The

holders of the group certificate must be members of an SSL VPN user

group, and the name of that user group must be present in the Allowed

list.

Cipher Strength Select one of the following options to determine the level of SSL

encryption to use. The web browser on the remote client must be

capable of matching the level that you select:

• To use any cipher suite, select Any.

• To use a 164-bit or greater cipher suite, select High >= 164.

• To use a 128-bit or greater cipher suite, select Medium >= 128.

User

Authentication

Method

Select one of the following options to bind user groups to authentication

methods:

• If the user group contains only local users, select Local.

• If the remote clients will be authenticated by an external RADIUS

server, select Radius.

• If the remote clients will be authenticated by an external LDAP server,

select LDAP.

• If the user group contains Local, RADIUS, and LDAP users, select

Any to enable all of the authentication methods. Local is attempted

first, then RADIUS, then LDAP.

Available

Groups Select the name of the user group requiring SSL VPN access, and then

select the right-pointing arrow. Do not select more than one user group

unless all members of the selected user groups have identical access

requirements.

FortiOS v3.0 MR7 SSL VPN User Guide

46 01-30007-0348-20080718

Configuring firewall policies Configuring a FortiGate SSL VPN

Configuring tunnel-mode firewall policies

Follow the procedures in this section to complete a tunnel-mode configuration.

These procedures assume that you have already completed the procedures found

in “Configuring user accounts and SSL VPN user groups” on page 42.

When a remote client initiates a connection to the FortiGate unit, the FortiGate

unit authenticates the client and determines which mode of operation is in effect

for the user. When tunnel mode is enabled, the user can access the server

applications and network services on the internal network if required and/or

download and install an ActiveX plugin from the web portal. The ActiveX control

provides SSL VPN client software.

After the user adds the ActiveX plugin to the web browser on the remote client, the

user can start the SSL VPN client software to initiate an SSL VPN tunnel with the

FortiGate unit. The FortiGate unit establishes the tunnel with the SSL client and

assigns the client a virtual IP address. Afterward, the SSL client uses the assigned

virtual IP address as its source address for the duration of the session.

To configure the FortiGate unit to support tunnel-mode access, you perform the

following configuration tasks on the FortiGate unit:

• Specify the IP address(es) that can be assigned to the SSL VPN client when

they establish tunnels with the FortiGate unit.

• Define a firewall policy to support tunnel-mode operations.

A firewall policy specifies the originating (source) IP address of a packet and the

destination address defines the IP address of the intended recipient or network. In

this case, the source address corresponds to the IP address of the remote user

that will connect to the FortiGate unit, and the destination address corresponds to

the IP address(es) of the host(s), server(s), or network behind the FortiGate unit.

Configuring the firewall policy involves:

• specifying the source and destination IP addresses:

• The source address corresponds to the IP address of the remote user.

• The destination address corresponds to the IP address or addresses that

remote clients need to access. The destination address may correspond to

an entire private network, a range of private IP addresses, or the private IP

address of a server or host.

• specifying the level of SSL encryption to use and the authentication method

• binding the user group to the firewall policy

To specify the source IP address

1Go to Firewall > Address and select Create New.

2In the Address Name field, type a name that represents the IP address that is

permitted to set up SSL VPN connection.

Note: On the web browser, ensure that the security settings associated with the Internet

zone permit ActiveX controls to be downloaded and run.

Note: If your destination address, SSL encryption, and user group are the same

as for your web-only mode connection, you do not need to create a firewall policy

for tunnel mode. The FortiGate unit uses the web-only mode policy settings

except for the source address range, which it obtains from the tunnel IP range

settings.

Configuring a FortiGate SSL VPN Configuring firewall policies

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 47

3From the Type list, select Subnet/IP Range.

4In the Subnet/IP Range field, type the corresponding IP address and subnet mask

(for example, 172.16.10.0/24). If the remote client’s IP address is unknown,

the Subnet/IP Range should be “all”, with 0.0.0.0/0.0.0.0 as the address used.

5In the Interface field, select the interface to the internal (private) network.

6Select OK.

To specify the destination IP address

1Go to Firewall > Address and select Create New.

2In the Address Name field, type a name that represents the local network,

server(s), or host(s) to which IP packets may be delivered (for example,

Subnet_2).

3In the Subnet/IP Range field, type the corresponding IP address (for example,

192.168.22.0/24 for a subnet, or 192.168.22.2/32 for a server or host), or

IP address range (192.168.22.[10-25]).

4In the Interface field, select the interface to the external (public) network.

5Select OK.

To define the firewall policy for tunnel-mode operations

1Go to Firewall > Policy and select Create New.

2Enter these settings:

Note: To provide access to a single host or server, you would type an IP address like

172.16.10.2/32. To provide access to two servers having contiguous IP addresses, you

would type an IP address range like 172.16.10.[4-5].

Source Interface/Zone

Select the FortiGate interface that accepts connections from

remote users (for example, external).

Address Name

Select the name that corresponds to the IP address of the remote

user.

Destination Interface/Zone

Select the FortiGate interface to the local private network (for

example, internal).

Address Name

Select the IP destination address that you defined previously for

the host(s), server(s), or network behind the FortiGate unit (for

example, Subnet_2).

Service Select ANY.

Action Select SSL-VPN.

SSL Client Certificate

Restrictive Select to allow traffic generated by holders of a (shared) group

certificate, for example, a user group containing PKI peers/users.

The holders of the group certificate must be members of an SSL

VPN user group, and the name of that user group must be present

in the Allowed field.

FortiOS v3.0 MR7 SSL VPN User Guide

48 01-30007-0348-20080718

Configuring SSL VPN event-logging Configuring a FortiGate SSL VPN

3Select OK.

4If the user group requires access to another server or network, create the IP

destination address (see “To specify the destination IP address” on page 46) and

repeat this procedure to create the required firewall policy.

5Create additional IP destination addresses and firewall policies if required for each

additional user group.

Configuring SSL VPN event-logging

You can configure the FortiGate unit to log SSL VPN events. For information

about how to interpret log messages, see the FortiGate Log Message Reference.

To log SSL VPN events

1Go to Log&Report > Log Config > Log Setting.

2Enable the storage of log messages to one or more of the following locations:

• a FortiAnalyzer unit

• the FortiGate system memory

• a remote computer running a syslog server

3If the options are concealed, select the blue arrow beside each option to reveal

and configure associated settings.

Cipher Strength Select one of the following options to determine the level of SSL

encryption to use. The web browser on the remote client must be

capable of matching the level that you select:

• To use any cipher suite, select Any.

• To use a 164-bit or greater cipher suite, select High >= 164.

• To use a 128-bit or greater cipher suite, select Medium >= 128.

User Authentication

Method Select one of the following options to bind user groups to

authentication methods:

• If the user group contains only local users, select Local.

• If the remote clients will be authenticated by an external

RADIUS server, select Radius.

• If the remote clients will be authenticated by an external LDAP

server, select LDAP.

• If the user group contains Local, RADIUS, and LDAP users,

select Any to enable all of the authentication methods. Local is

attempted first, then RADIUS, then LDAP.

Available Groups Select the name of the user group requiring SSL VPN access, and

then select the right-pointing arrow. Do not select more than one

user group unless all members of the selected user groups have

identical access requirements.

Note: If you apply a protection profile in a SSL VPN firewall policy, it will only apply to

tunnel-mode operations.

Note: If available on your FortiGate unit, you can enable the storage of log messages to a

system hard disk. In addition, as an alternative to the options listed above, you may choose

to forward log messages to a remote computer running a WebTrends firewall reporting

server. For more information about enabling either of these options through CLI commands,

see the “log” chapter of the FortiGate CLI Reference.

Configuring a FortiGate SSL VPN Monitoring active SSL VPN sessions

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 49

4If logs will be written to system memory, from the Log Level list, select Information.

For more information, see the “Log & Report” chapter of the FortiGate

Administration Guide.

5Select Apply.

To filter SSL VPN events

1Go to Log&Report > Log Config > Event Log.

2Select Enable, and then select one or more of the following options:

• SSL VPN user authentication event

• SSL VPN administration event

• SSL VPN session event

3Select Apply.

To view SSL VPN event logs

1Go to Log&Report > Log Access.

2If the option is available from the Type list, select the log file from disk or memory.

You can modify the settings in the top row to meet your requirements. Log

messages are displayed beneath the top row.

Monitoring active SSL VPN sessions

You can display a list of all active SSL VPN sessions. The list displays the user

name of the remote user, the IP address of the remote client, and the time that the

connection was made. The list also identifies which services are being provided

(see Figure 6).

To view the list of active sessions, go to VPN > SSL > Monitor.

Figure 6: Monitor list: Web-only mode connections

When a tunnel-mode user is connected, the Description field displays the IP

address that the FortiGate unit assigned to the remote host (see Figure 7).

No. The identifier of the connection.

User The user names of all connected remote users.

Source IP The IP addresses of the host devices connected to the FortiGate unit.

Begin Time The starting time of each connection.

Description Information about which services are being provided.

FortiOS v3.0 MR7 SSL VPN User Guide

50 01-30007-0348-20080718

Configuring SSL VPN bookmarks and bookmark groups Configuring a FortiGate SSL VPN

Figure 7: Monitor list: Tunnel-mode connection

If required, you can end a session/connection by selecting the Delete button in the

row that corresponds to the connection.

Configuring SSL VPN bookmarks and bookmark groups

If you create a user account that permits web-only mode access, you can create

hyperlinks to frequently accessed server applications that the user can use to start

any session from the home page through the hyperlinks. The FortiGate unit

forwards client requests to servers on the Internet or internal network. To use the

web-portal applications, you add the URL, IP address, or name of the server

application to the Bookmarks list. The bookmarks are available when the user

starts an active SSL VPN session.

Viewing the SSL VPN bookmark list

You can display a list of all existing SSL VPN bookmarks created using the

FortiGate unit. The list details the name of the bookmark, type of bookmark, and

the link details.

To view the list of predefined SSL VPN bookmarks, go to VPN > SSL >

Bookmark.

Figure 8: Bookmark list

See also

•Configuring SSL VPN settings

•Monitoring active SSL VPN sessions

•Configuring SSL VPN bookmarks and bookmark groups

•Configuring SSL VPN bookmarks

Delete

Bookmark Name The type/names of links to remote server applications and network

services.

Link The URL, host, or folder of the bookmark link.

Delete and Edit

icons Delete or edit an entry in the list.

Edit

Delete

Configuring a FortiGate SSL VPN Configuring SSL VPN bookmarks and bookmark groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 51

•Viewing the SSL VPN Bookmark Groups list

•Configuring SSL VPN bookmark groups

Configuring SSL VPN bookmarks

Go to VPN > SSL > Bookmark and select Create New to create hyperlinks to

frequently accessed server applications.

Figure 9: Create New Bookmark

See also

•Configuring SSL VPN settings

•Monitoring active SSL VPN sessions

•Configuring SSL VPN bookmarks and bookmark groups

•Viewing the SSL VPN bookmark list

Bookmark Name Type the text to display in the hyperlink. The name is displayed in the

Bookmarks list.

Application Type Select the abbreviated name of the server application or network

service from the drop-down list:

•Web

•Telnet

•FTP

•SMB/CIFS

•VNC

•RDP

•SSH

URL/Host/Folder Type the information that the FortiGate unit needs to forward client

requests to the correct server application or network service:

•If the application type is Web, type the URL of the web server (for

example, www.fortinet.com).

•If the application type is Telnet, type the IP address of the telnet

host (for example, 10.10.10.10).

•If the application type is FTP, type the IP address of the FTP host

as a root directory/folder (for example, //server/folder/).

•If the application type is SMB/CIFS, type the IP address of the SMB

host and the root directory/folder associated with your account (for

example, //server/folder/).

•If the application type is VNC, type the IP address of the host (for

example, 10.10.10.10).

•If the application type is RDP, type the IP address of the RDP host

(for example, 10.10.10.10).

•If the application type is SSH, type the IP address of the SSH host

(for example, 10.10.10.10).

FortiOS v3.0 MR7 SSL VPN User Guide

52 01-30007-0348-20080718

Configuring SSL VPN bookmarks and bookmark groups Configuring a FortiGate SSL VPN

•Viewing the SSL VPN Bookmark Groups list

•Configuring SSL VPN bookmark groups

Viewing the SSL VPN Bookmark Groups list

You can create a group of specific bookmarks that can be included in the

configuration of an SSL VPN user group.

To view a list of bookmark groups, go to VPN > SSL > Bookmark Group.

Figure 10: Bookmark Group list

See also

•Configuring SSL VPN settings

•Monitoring active SSL VPN sessions

•Configuring SSL VPN bookmarks and bookmark groups

•Viewing the SSL VPN bookmark list

•Configuring SSL VPN bookmarks

•Configuring SSL VPN bookmark groups

Configuring SSL VPN bookmark groups

Go to VPN > SSL > Bookmark Group and select Create New to create a group of

selected bookmarks.

Figure 11: Create New Bookmark Group

Group Name Name of bookmark group

Bookmarks List of bookmarks that are components of the bookmark group in Group

Name.

Delete and Edit

icons Delete or edit an entry in the list.

Configuring a FortiGate SSL VPN Configuring SSL VPN bookmarks and bookmark groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 53

See also

•Configuring SSL VPN settings

•Monitoring active SSL VPN sessions

•Configuring SSL VPN bookmarks and bookmark groups

•Viewing the SSL VPN bookmark list

•Configuring SSL VPN bookmarks

•Viewing the SSL VPN Bookmark Groups list

Assigning SSL VPN bookmark groups to SSL VPN users

To assign a bookmark group to a user group, go to User > User Group, and

select/create a SSL VPN user group to assign the bookmark group to. Expand the

SSL-VPN User Group Options, enable Bookmarks and select a bookmark group

from the drop-down list. When you assign a bookmark group to a SSL VPN user

group, all the bookmarks included in the group are available to the SSL VPN

users in the selected SSL VPN user group.

Figure 12: Assigning a bookmark group to a user

Name Type the name of the bookmark group. The name is displayed in the

Bookmark Group list, and is a selection in the Bookmarks list in an SSL

VPN user group.

Available

Bookmarks The list of bookmarks available for inclusion in the bookmark group.

Lists bookmarks under appropriate category (FTP, RDP, SMB, Telnet,

VNC, Web, or SSH).

Used Bookmarks The list of bookmarks that belong to the bookmark group.

Right arrow

button Add a bookmark to the Used Bookmarks list.

Select a bookmark name in the Available Bookmarks list and select the

right arrow button to move it to the Used Bookmarks list.

Left arrow button Remove a bookmark from the Used Bookmarks list.

Select a bookmark in the Used Bookmarks list and select the left arrow

button to move it to the Available Bookmarks list.

Create New... Select to create a new bookmark for inclusion in the Available

Bookmarks list.

FortiOS v3.0 MR7 SSL VPN User Guide

54 01-30007-0348-20080718

SSL VPN host OS patch check Configuring a FortiGate SSL VPN

SSL VPN host OS patch check

SSLVPN Client OS Patch Check feature allows a client with a specific OS patch to

access SSL VPN services. The host check only works on Windows platforms.

This means that MacOS/Linux users can always logon (assuming they have the

correct user name and password) as the patch check is not applied to them.

Options defined in the SSL VPN user group settings support this function (CLI

only):

Configuration Example

The following configuration allows a Windows 2000 user with patch level 2

(latest-patch-level minus tolerance) and above permission to access SSL

VPN services, as well as any Windows XP users.

config vpn ssl settings

set sslvpn-enable enable

set tunnel-endip 10.1.1.10

set tunnel-startip 10.1.1.1

end

config user group

edit "g1"

set group-type sslvpn

set sslvpn-tunnel enable

set sslvpn-tunnel-startip 10.1.1.1

set sslvpn-tunnel-endip 10.1.1.10

set sslvpn-webapp enable

set sslvpn-os-check enable

config sslvpn-os-check-list "windows-2000"

set action check-up-to-date

set latest-patch-level 3

Variable Description

set sslvpn-os-check

{disable | enable} Enable or disable SSL VPN OS patch level check.

Default disable.

config sslvpn-os-check-

list {windows-2000 |

windows-xp}

Configure the OS of the patch level check.

Available when set sslvpn-os-check is set to

enable.

set action {allow |

check-up-to-date | deny} Specify how to perform the patch level check.

•allow - any level is permitted

•check-up-to-date - some patch levels are permitted,

make selections for latest-patch-level and

tolerance

•deny - OS version does not permit access

Available when set sslvpn-os-check is set to

check-up-to-date.

set latest-patch-level

{disable | 0 - 255} Specify the latest allowed patch level. Default 4 for

Windows 2000, 2 for Windows XP.

Available when action is set to enable.

set tolerance

{tolerance_num} Specify the lowest allowable patch level tolerance.

Equals latest-patch-level minus tolerance

and above. Default for Windows 2000 and Windows XP

is 0.

Available when action is set to check-up-to-date.

Configuring a FortiGate SSL VPN Granting unique access permissions for SSL VPN tunnel user groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 55

set tolerance 1

end

config sslvpn-os-check-list "windows-xp"

set action allow

end

set member "u1"

set sslvpn-split-tunneling enable

set sslvpn-http enable

next

end

config firewall policy

edit 1

set srcintf "internal"

set dstintf "external"

set srcaddr "all"

set dstaddr "172.18.8.0/24"

set action ssl-vpn

set schedule "always"

set service "ANY"

set groups "g1"

next

end

Granting unique access permissions for SSL VPN tunnel user

groups

For situations where there is a requirement for more than one user to be permitted

tunnel mode access, the key is to split the tunnel IP range into sub-IP ranges,

where each user group (with the user as a member) is assigned a dedicated IP

range (with no overlap) and therefore can have different access permissions.

Figure 13: SSL VPN configuration for unique access permissions

FortiOS v3.0 MR7 SSL VPN User Guide

56 01-30007-0348-20080718

Granting unique access permissions for SSL VPN tunnel user groups Configuring a FortiGate SSL VPN

Sample configuration for unique access permissions with tunnel mode user

groups

In this sample configuration, there are two user groups, each one with a dedicated

IP address range.

First, you establish the tunnel IP range.

Go to VPN > SSL, and enable SSL-VPN.

Enter the Tunnel IP Range corresponding to the range of IP addresses available

for the users/user groups, in this case 10.1.1.1 - 10.1.1.100.

Figure 14: Enable SSL-VPN Settings

After enabling SSL VPN, you must create the users and then the user groups that

require SSL VPN tunnel mode access.

Go to User > Local and create user1 and user2 with password authentication.

After you create the users, you must create the SSL VPN user groups. In order to

configure each user with different access permissions, you must create separate

user groups and designate specific IP ranges for each group.

Note: The source address for both SSL VPN firewall policies can be left as ‘all’ when the

users do not have static public IPs.

Note: user1 only has permission to access the Linux server, while user2 only has

permission to access the Windows PC.

Configuring a FortiGate SSL VPN Granting unique access permissions for SSL VPN tunnel user groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 57

Go to User > User Group. Create group1 as an SSL VPN user group with user1

as the member and 10.1.1.1 - 10.1.1.50 as the values in ‘Restrict tunnel IP range

for this group’.

Figure 15: group1 user group attributes

Create group2 as an SSL VPN user group with user2 as the member and

10.1.1.51 - 10.1.1.100 as the values in ‘Restrict tunnel IP range for this group’.

Figure 16: group2 user group attributes

After you create the user groups, you need to define the firewall policies to

support tunnel-mode operations.

The firewall policy specifies the originating (source) IP address of a packet and

the destination address that defines the IP address of the intended recipient or

network. In this configuration, the source address corresponds to the public IP

address that can connect to the FortiGate unit, and the destination address

corresponds to the IP address of the Linux server/Windows PC behind the

FortiGate unit.

Before you create the firewall policy, you must define the source and destination

addresses to include in the policy.

Go to Firewall > Address to create the source and destination addresses to

specify in the firewall policies.

FortiOS v3.0 MR7 SSL VPN User Guide

58 01-30007-0348-20080718

Granting unique access permissions for SSL VPN tunnel user groups Configuring a FortiGate SSL VPN

Figure 17: Source/destination firewall addresses - Public IP

Figure 18: Source/destination firewall addresses - Linux/Windows PC

After creating the source and destination addresses, go to Firewall > Policy to

create the firewall policies.

The policy for user1 is an SSL-VPN firewall policy that includes the applicable

source and destination addresses, and has group1 as the user group attached to

the policy.

Configuring a FortiGate SSL VPN Granting unique access permissions for SSL VPN tunnel user groups

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 59

Figure 19: user1 firewall policy

The user2 policy is also an SSL-VPN firewall policy that includes the applicable

source and destination addresses, and has group2 as the user group attached to

the policy.

Figure 20: user2 firewall policy

To view the SSL VPN policies, go to Firewall > Policy.

FortiOS v3.0 MR7 SSL VPN User Guide

60 01-30007-0348-20080718

SSL VPN virtual interface (ssl.root) Configuring a FortiGate SSL VPN

Figure 21: Firewall policy list

To avoid overlap with other firewall policies, add a DENY policy below the SSL

VPN policies (the source is the SSL VPN tunnel IP range). See Configuring

firewall policies for more information.

SSL VPN virtual interface (ssl.root)

Configuration of the SSL VPN tunnel service involves a virtual interface,

ssl.<vdom_name>, which functions much like an ipsec-virtual interface. In non-

vdom implementations, this appears as ssl.root. The ssl.root interface appears in

the firewall policy interface lists and static route interface lists. The ssl-root

interface allows remote user access to additional networks. For example, the

interface facilitates the remote user´s ability to browse the Internet using the

FortiGate unit.

The SSL VPN tunnel-mode access requires the following firewall policies:

• External > Internal, with the action set to SSL, with an SSL user group

• ssl.root > Internal, with the action set to Accept

• Internal > ssl.root, with the action set to Accept

This also requires a new static route and should appear as follows:

• Destination network - <ssl tunnel mode assigned range> interface ssl.root

If you are configuring Internet access through an SSL VPN tunnel, the following

configuration must be added:

• ssl.root > External, with the action set to Accept, with NAT enabled

Configuring a FortiGate SSL VPN SSL VPN virtual interface (ssl.root)

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 61

Go to Firewall > Policy and select Create New to create a firewall policy.

For a standard configuration, set up the firewall policies listed below.

To allow ssl users to browse the Internet through the FortiGate unit:

To allow SSL-tunnel users to access a policy-based VPN peer network:

Authentication policy

Source wan1

Source address all

Destination internal

Destination address internal subnet

Action sslvpn

Authentication ssl user group(s)

Inbound access policy

Source ssl.root

Source address ip address of remote client

Destination internal

Destination address internal subnet

Action accept

Authentication No authentication set

Outbound policy

Source internal

Source address internal subnet

Destination ssl.root

Destination address ssl assigned range

Action Accept

Authentication No authentication set

Static route

Destination network <ssl-assigned subnet>

Destination interface ssl.root

Internet browsing policy

Source ssl.root

Source address ssl-assigned range

Destination wan1

Destination address all

Action accept

NAT enabled Yes

Protection profile Recommended

Peer network policy

Source ssl.root

Source address ssl-assigned range

FortiOS v3.0 MR7 SSL VPN User Guide

62 01-30007-0348-20080718

SSL VPN dropping connections Configuring a FortiGate SSL VPN

SSL VPN dropping connections

When a FortiGate unit has multiple internet connections, the SSLVPN client can

connect to the SSLVPN web portal, but when attempting to click Connect to start

tunnel mode SSLVPN, the tunnel will start up for a few seconds, then shut down.

This issue occurs when there are multiple interfaces connected to the Internet, for

example, a dual wan configuration.

To resolve this issue, upgrade the FortiGate unit to at least 3.0 MR4 or higher.

Use following commands in CLI to resolve the issue:

config vpn ssl settings

set route-source-interface enable

end

Destination wan1

Destination address remote VPN subnet

Action ipsec

VPN tunnel <vpn phase1 name>

Note: This CLI command is only available in FortiOS 3.00 MR4 and higher.

Configuring a FortiGate SSL VPN SSL VPN dropping connections

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 63

FortiOS v3.0 MR7 SSL VPN User Guide

64 01-30007-0348-20080718

SSL VPN dropping connections Configuring a FortiGate SSL VPN

Working with the web portal Connecting to the FortiGate unit

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 65

Working with the web portal

This section introduces the web portal features and explains how to configure

them.

The following topics are included in this section:

•Connecting to the FortiGate unit

•Web portal home page features

•Launching web portal applications

•Starting a session from the Tools area

•Tunnel-mode features

•Logging out

•Adding a bookmark to the My Bookmarks list

•Working with the ActiveX/Java Platform plug-in

•Uninstalling the ActiveX/Java Platform plugin

•URL re-writing

Connecting to the FortiGate unit

You can connect to the FortiGate unit using a web browser. The URL of the

FortiGate interface may vary from one installation to the next. If required, ask your

FortiGate administrator for the URL of the FortiGate unit, and obtain a user name

and password.

In addition, if you will be using a personal or group security (X.509) certificate to

connect to the FortiGate unit, your web browser may prompt you for the name of

the certificate. Your FortiGate administrator can tell you which certificate to select.

To log in to the FortiGate secure HTTP gateway

1Using the web browser on your computer, browse to the URL of the FortiGate unit

(for example, https://<FortiGate_IP_address>:10443/remote).

2The FortiGate unit may offer you a self-signed security certificate. If you are

prompted to proceed, select Yes.

3A second message may be displayed to inform you that the FortiGate certificate

distinguished name differs from the original request. This message is displayed

because the FortiGate unit is attempting to redirect your web browser connection.

You can ignore the message.

FortiOS v3.0 MR7 SSL VPN User Guide

66 01-30007-0348-20080718

Web portal home page features Working with the web portal

4When you are prompted for your user name and password:

• In the Name field, type your user name.

• In the Password field, type your password.

5Select Login.

The FortiGate unit will redirect your web browser to the FortiGate SSL VPN

Remote Access Web Portal home page automatically.

Web portal home page features

The FortiGate SSL VPN Remote Access Web Portal home page is displayed after

you log in.

Working with the web portal Web portal home page features

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 67

Figure 22: FortiGate SSL VPN Remote Access Web Portal page

If your user account permits web-only mode access, and your administrator has

set up pre-defined bookmarks for you, they will appear in a list under Pre-defined

Bookmarks. You can start any session from these hyperlinks, but you cannot

change them. Also, you can create your own hyperlinks to frequently accessed

server applications and start any session from the home page through these

hyperlinks. See “Launching web portal applications” and “Adding a bookmark to

the My Bookmarks list”.

If your user account permits tunnel-mode connections, you can install/uninstall

Fortinet SSL VPN client software and/or initiate an SSL VPN tunnel with the

FortiGate unit. Selecting the Activate SSL-VPN Tunnel Mode link at the top of the

home page displays the Fortinet SSL VPN Client area. See “Tunnel-mode

features”.

DeleteEdit

Help

Logout

FortiOS v3.0 MR7 SSL VPN User Guide

68 01-30007-0348-20080718

Launching web portal applications Working with the web portal

In the Tools area, you can connect to a web server or start a telnet session. You

can also check connectivity to a host or server on the network behind the

FortiGate unit. For more information, see “Starting a session from the Tools area”.

Launching web portal applications

The FortiGate unit forwards client requests to servers on the Internet or internal

network. To use the web-portal applications, you add the URL, IP address, or

name of the server application to the My Bookmarks list (see “Adding a bookmark

to the My Bookmarks list”).

One or more of the following server applications may be available to you,

depending on whether they were installed by the server administrator:

• Web servers (HTTP/HTTPS) download HTML pages in response to web

browser requests.

• Telnet servers (TCP/IP Terminal Emulation Protocol) enable you to use your

computer as a virtual terminal to log in to a remote host.

• FTP (File Transfer Protocol) servers enable you to transfer files between your

computer and a remote host.

• SMB/CIFS servers implement the Server Message Block (SMB) protocol to

support file sharing between your computer and a remote server host.

• VNC (Virtual Network Computing) servers enable you to remotely control

another computer, for example, accessing work from your home computer.

• RDP (Remote Desktop Protocol) servers have a multi-channel protocol that

allows users to connect to computers running Microsoft Terminal Services.

• SSH (Secure Shell) servers enable you to exchange data between two

computers using a secure channel.

When you access any of these server applications, the server may prompt you for

a user name and password. To log in, you must have a user account created by

the server administrator.

URL re-writing

When a FortiGate unit forwards client requests to servers on the Internet or

internal network, there may be a requirement to access a site with a name or

address that should not be exposed. For HTTP/HTTPS, the FortiGate unit

employs an obfuscation technique that encrypts the hostname with a random key

using AES-128, then the corresponding hex value plus ‘Z’ is added at the

beginning to form the encoded name.

For example, in the case of the URL http://test.org/index.html, the FortiGate unit

would translate to the following:

https://<sslvpn_host:port>/proxy/http/Z<encrypted hex value>/index.html

Note: If you want to access a web server or telnet server without first adding a bookmark to

the My Bookmarks list, type the URL or IP address of the server into the appropriate field

under Tools instead (see “Starting a session from the Tools area”).

Note: Windows file sharing through SMB/CIFS is supported through shared directories.

Working with the web portal Launching web portal applications

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 69

The encryption key is only valid for the current user session. Once the user logs

out, the key is no longer valid.

In the case of FTP and SMB, the path/filename is translated into its hex value for

internal encoding purposes. The actual host ip is displayed. Other protocols are

not supported.

The CLI command related to the obfuscation technique is url-obscuration in

config vpn ssl settings.

Adding a bookmark to the My Bookmarks list

You can add a list of frequently used connections to the web portal home page.

Afterward, select any hyperlink from the My Bookmarks list to initiate a session.

Figure 23: Frequently used connections in the My Bookmarks list

Figure 24: New Bookmark dialog box

Add Bookmark Create a hyperlink.

Bookmark The names of links to remote server applications and network

services.

Details The information that the FortiGate unit needs to forward client

requests to servers on the Internet or a private network behind the

FortiGate unit.

Delete and Edit icons Delete or edit an entry in the list.

Delete

Edit

FortiOS v3.0 MR7 SSL VPN User Guide

70 01-30007-0348-20080718

Launching web portal applications Working with the web portal

To add an HTTP or HTTPS connection and access the web server

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select Web.

4In the URL field, type the URL of the web server (for example,

http://www.mywebexample.com or https://172.20.120.101).

5Select OK.

6To connect to the web server, select the hyperlink that you created.

Title Type the text to display in the hyperlink. The name is displayed in

the My Bookmarks list.

Application Type Select the abbreviated name of the server application or network

service from the drop-down list:

•Web

•Telnet

•FTP

•SMB/CIFS

•VNC

•RDP

•SSH

URL,

Host Name/IP, or

Shared File Folder

Type the information that the FortiGate unit needs to forward client

requests to the correct server application or network service:

•If the application type is Web, type the URL of the web server

(for example, http://www.google.com or

https://172.20.120.101).

•If the application type is Telnet, type the IP address of the

telnet host (for example, 10.10.10.10).

•If the application type is FTP, type the IP address of the FTP

host as a root directory (for example,

//10.10.10.10/share/).

•If the application type is SMB/CIFS, type the IP address of the

SMB host and the root directory associated with your account

(for example, //10.10.10.10/share/).

•If the application type is VNC, type the IP address of the VNC

host (for example, 10.10.10.10).

•If the application type is RDP, type the IP address of the RDP

host (for example, 10.10.10.10).

•If the application type is SSH, type the IP address of the SSH

host (for example, 10.10.10.10).

Working with the web portal Launching web portal applications

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 71

The FortiGate unit replaces the URL with

https://<FG_IP_address>:<port_no>/proxy/http/<specified_URL> and

the requested page is displayed.

7To end the session, close the browser window.

To add a telnet connection and start a telnet session

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select Telnet.

4In the Host Name/IP field, type the IP address of the telnet host (for example,

10.10.10.10).

5Select OK.

6To start a telnet session, select the hyperlink that you created.

7Select Connect.

8A telnet session starts and you are prompted to log in to the remote host. You

must have a user account to log in. After you log in, you may enter any series of

valid telnet commands at the system prompt.

Note: The FortiGate unit may offer you its self-signed security certificate. Select Yes to

proceed. A second message may be displayed to inform you of a host name mismatch.

This message is displayed because the FortiGate unit is attempting to redirect your web

browser connection. Select Yes to proceed.

FortiOS v3.0 MR7 SSL VPN User Guide

72 01-30007-0348-20080718

Launching web portal applications Working with the web portal

9To end the session, select Disconnect (or type exit) and then close the TELNET

connection window.

To add an FTP connection and start an FTP session

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select FTP.

4In the Shared File Folder field, type the IP address of the FTP host as a root

directory (for example, //10.10.10.10/).

5Select OK.

6To start the ftp session, select the hyperlink that you created.

7When you are prompted to log in to the remote host, type your user name and

password. You must have a user account on the remote host to log in.

8Select Login.

Working with the web portal Launching web portal applications

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 73

After you log in, the files and subdirectories in the root directory are displayed.

You can switch to a subdirectory from the root directory. For example, the

following image shows the contents of a subdirectory named share.

The view enables you to navigate through the file system and manipulate files in

the following ways:

• To download a file from the current directory, select the file link in the Name

column.

• To create a subdirectory in the current directory, select New directory.

• To delete a file or subdirectory from the current directory, select Delete.

• To rename a file in the current directory, select Rename.

• To upload a file from the remote directory to the current directory on your client

computer, select the file link in the Name column.

• To access a subdirectory, select the file link in the Name column.

• When the current directory is a subdirectory, you can select Up to switch to the

parent directory.

9To end the FTP session, select Logout.

To add a SMB/CIFS connection and start a SMB session

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select SMB/CIFS.

4In the Shared File Folder field, type the IP address of the SMB host and the root

directory associated with your account (for example, //10.10.10.10/share/).

Logout

New Directory

Rename

Delete

FortiOS v3.0 MR7 SSL VPN User Guide

74 01-30007-0348-20080718

Launching web portal applications Working with the web portal

5Select OK.

6To start a SMB/CIFS session, select the hyperlink that you created.

7When you are prompted to log in to the remote host, type your user name and

password. You must have a user account on the remote host to log in.

8Select Login.

After you log in, the root directory associated with your user or group account is

displayed. For example, in the figure below, the files and subdirectories in the root

directory share are displayed.

The view enables you to navigate through the file system and manipulate files in

the following ways:

• To download a file from the current directory, select the file link in the Name

column.

• To create a subdirectory in the current directory, select New directory.

• To delete a file or subdirectory from the current directory, select Delete.

• To rename a file in the current directory, select Rename.

• To upload a file from the remote directory to the current directory on your client

computer, select the file link in the Name column.

• To access a subdirectory, select the file link in the Name column.

• When the current directory is a subdirectory, you can select Up to switch to the

parent directory.

9To end the SMB/CIFS session, select Logout.

Logout

New Directory

Rename

Delete

Working with the web portal Launching web portal applications

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 75

To add a VNC connection and start a VNC session

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select VNC.

4In the Host Name/IP field, type the IP address of the VNC host (for example,

10.10.10.10/).

5Select OK.

6To start a VNC session, select the hyperlink that you created.

7When you are prompted to log in to the remote host, type your user name and

password. You must have a user account on the remote host to log in.

8Select OK.

9To end the VNC session, select Disconnect.

FortiOS v3.0 MR7 SSL VPN User Guide

76 01-30007-0348-20080718

Launching web portal applications Working with the web portal

To add a RDP connection and start a RDP session

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select RDP.

4In the Shared File Folder field, type the IP address of the RDP host (for example,

10.10.10.10).

5Select OK.

Note: You can specify a keyboard layout setting as a parameter when setting up the RDP

connection. The format to enter the setting in “RDP to Host” is:

•“yourserver.com -m fr”

where ‘fr’ selects French as the Windows environment. Select the code that matches your

local installation of Windows - for example, if your local machine has the Turkish version of

Windows installed, select ‘tr’, regardless of the version of Windows installed on the server

you connect to.

The codes are as follows:

•ar: Arabic

•da: Danish

•de: German

•en-bg: English, Great Britain

•en-us: English, US

•es: Spanish

•fi: Finnish

•fr: French

•fr-be: French, Belgian

•hr: Croatian

•it: Italian

•ja: Japanese

•lt: Lithuanian

•lv: Latvian

•mk: Macedonian

•no: Norwegian

•pl: Polish

•pt: Portuguese

•pt-br: Brazilian Portuguese

•ru: Russian

•sl: Slovenian

•sv: Sudanese

•tk: Turkmen

•tr: Turkish

Working with the web portal Launching web portal applications

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 77

6To start a RDP session, select the hyperlink that you created.

7When you see a screen configuration dialog, click OK.

8When you are prompted to log in to the remote host, type your user name and

password. You must have a user account on the remote host to log in.

9Select Login.

10 To end the RDP session, select Logout.

Note: The FortiGate unit may offer you its self-signed security certificate. Select Yes to

proceed. A second message may be displayed to inform you of a host name mismatch.

This message is displayed because the FortiGate unit is attempting to redirect your web

browser connection. Select Yes to proceed.

FortiOS v3.0 MR7 SSL VPN User Guide

78 01-30007-0348-20080718

Launching web portal applications Working with the web portal

To add a SSH connection and start a SSH session

1Select Add Bookmark.

2In the Title field, type a name to represent the connection.

3From the Application Type list, select SSH.

4In the Host Name/IP field, type the IP address of the SSH host (for example,

192.168.1.3).

5Select OK.

6To start a SSH session, select the hyperlink that you created.

7Select Connect.

Note: The FortiGate unit may offer you its self-signed security certificate. Select Yes to

proceed. A second message may be displayed to inform you of a host name mismatch.

This message is displayed because the FortiGate unit is attempting to redirect your web

browser connection. Select Yes to proceed.

Working with the web portal Launching web portal applications

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 79

8A SSH session starts and you are prompted to log in to the remote host. You must

have a user account to log in. After you log in, you may enter any series of valid

commands at the system prompt.

9To end the session, select Disconnect (or type exit) and then close the SSH

connection window.

See also

•Connecting to the FortiGate unit

•Web portal home page features

•Launching web portal applications

•Starting a session from the Tools area

•Tunnel-mode features

•Logging out

•Adding a bookmark to the My Bookmarks list

•URL re-writing

•Working with the ActiveX/Java Platform plug-in

•Uninstalling the ActiveX/Java Platform plugin

FortiOS v3.0 MR7 SSL VPN User Guide

80 01-30007-0348-20080718

Starting a session from the Tools area Working with the web portal

Starting a session from the Tools area

You can connect to any web server or telnet server without adding a bookmark to

the My Bookmarks list. The fields in the Tools area enable you to specify the URL

or IP address of the host computer. If required, you can ping a host computer

behind the FortiGate unit to verify connectivity to that host.

To connect to a web server from the Tools area

1In the Connect to Web Server field, type the URL of the web server (for example,

http://www.mywebexample.com or https://172.20.120.101).

2Select Go.

The FortiGate unit replaces the URL with

https://<FG_IP_address>:<port_no>/proxy/http/<specified_URL> and

the requested page is displayed.

3To end the session, close the browser window.

To ping a host or server behind the FortiGate unit

1In the Test for Reachability (Ping) field, type the IP address of the host or server

that you want to reach (for example, 192.168.12.22).

2Select Go.

A message stating whether the IP address can be reached or not is displayed.

To start a telnet session from the Tools area

1In the Telnet to Host field, type the IP address of the telnet host (for example,

192.168.5.238).

2Select Go.

3Select Connect.

4A telnet session starts and you are prompted to log in to the remote host. You

must have a user account to log in. After you log in, you may enter any series of

valid telnet commands at the system prompt.

5To end the session, select Disconnect (or type exit) and then close the TELNET

connection window.

Tunnel-mode features

The FortiGate SSL VPN Remote Access Web Portal page is displayed after you

log in. Selecting the Activate SSL-VPN Tunnel Mode link at the top of the home

page displays the Fortinet SSL VPN Client area.

If your user account permits tunnel-mode connections, you can install/uninstall

SSL VPN client software and/or initiate an SSL VPN tunnel with the FortiGate unit.

(see Figure 25)For more information, see “Working with the ActiveX/Java Platform

plug-in”.

Note: The FortiGate unit may offer you its self-signed security certificate. Select Yes to

proceed. A second message may be displayed to inform you of a host name mismatch.

This message is displayed because the FortiGate unit is attempting to redirect your web

browser connection. Select Yes to proceed.

Working with the web portal Tunnel-mode features

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 81

Figure 25: Fortinet SSL VPN Client 1.0 page (tunnel mode)

Working with the ActiveX/Java Platform plug-in

The ActiveX/Java Platform plug-ins provide the software that your client computer

needs to establish an SSL VPN tunnel with the FortiGate unit. You have to

download the ActiveX/Java Platform plugin from the FortiGate unit and install the

plugin on your client computer before your computer can establish a VPN tunnel

with the FortiGate unit. Controls for downloading and installing the ActiveX/Java

Platform plug-ins are displayed in the Fortinet SSL VPN Client area of the web

portal.

You only have to install the ActiveX/Java Platform plug-ins once. Afterward, you

can use the SSL VPN client software to initiate a VPN tunnel with the FortiGate

unit whenever you access the web portal.

Link Status The state of the SSL VPN tunnel:

•Up is displayed when an SSL VPN tunnel with the FortiGate

unit has been established.

•Down is displayed when a tunnel connection has not been

initiated.

Bytes Sent The number of bytes of data transmitted from the client to the

FortiGate unit since the tunnel was established.

Bytes Received The number of bytes of data received by the client from the

FortiGate unit since the tunnel was established.

Install Download the SSL VPN client software from the FortiGate unit

and add the ActiveX/Java Platform plugin to the local web

browser.

Uninstall Uninstall the ActiveX/Java Platform plugin.

Connect Initiate a session and establish an SSL VPN tunnel with the

FortiGate unit.

Disconnect End the session and close the tunnel to the FortiGate unit.

Refresh Now Refresh the Fortinet SSL VPN Client page.

Note: On your web browser, ensure that the security settings associated with the Internet

zone permit you to download and run ActiveX/Java Platform controls. You must also have

administrator rights on your computer to install the ActiveX/Java Platform controls.

FortiOS v3.0 MR7 SSL VPN User Guide

82 01-30007-0348-20080718

Tunnel-mode features Working with the web portal

To download and install the ActiveX/Java Platform plugin

1At the top of the web portal home page, select the Activate SSL-VPN Tunnel

Mode link.

2The FortiGate unit may prompt you to install a Fortinet SSL VPN Client plugin.

Follow the instructions provided to install ActiveX or Java Platform.

The Fortinet SSL VPN Client 1.0 page is displayed.

3Select Install.

To initiate a VPN tunnel with the FortiGate unit

The IP address of the public FortiGate interface and the TCP port number through

which SSL VPN connections are made are displayed in the Server IP field of the

Fortinet SSL VPN Client page.

1At the top of the web portal home page, select the Activate SSL-VPN Tunnel

Mode link.

The Fortinet SSL VPN Client page opens.

Note: With Windows XP Service Pack 2, a yellow bar is displayed at the top of the screen.

You must click on the bar (accept) and follow the instructions to install the ActiveX control.

Note: If client security checks are configured for your account, they must complete

successfully before the Connect button is enabled.

Working with the web portal Logging out

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 83

2Select Connect.

Figure 26: Tunnel established

After the “Fortinet SSL VPN client connected to server” message is displayed and

the Disconnect button is enabled (see Figure 26), you have direct access to the

network behind the FortiGate unit, subject to the conditions of the FortiGate

firewall policy. For example, using a client application on your computer, you could

connect to a server application on the network behind the FortiGate unit and

download information.

To stop the SSL VPN session and disconnect from the FortiGate unit, select

Disconnect. You must log out from the web portal to disconnect from the FortiGate

unit (see “Logging out”). You can use the Connect button to re-establish the

tunnel.

Uninstalling the ActiveX/Java Platform plugin

To uninstall the ActiveX/Java Platform plugin

1At the top of the web portal home page, select the Activate SSL-VPN Tunnel

Mode link.

2Select Uninstall.

Logging out

To log out from the web portal, select the Logout button in the top right corner of

the web portal home page.

Note: You do not have to uninstall the SSL VPN client software if you wish to install an

updated version. If the FortiGate unit has a newer version of the ActiveX/Java Platform

plugin, it will install it automatically.

Logout

FortiOS v3.0 MR7 SSL VPN User Guide

84 01-30007-0348-20080718

Logging out Working with the web portal

Index

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 85

Index

A

ActiveX plugin

downloading 81

uninstalling 83

applications, web-portal 68

authentication timeout setting 40

B

bookmarks

user-defined 69

C

certificates

allow group certificate 47

self signed 65

X.509 20

cifs session, establishing 73

cipher suite, SSL negotiations 39

client

Linux 28

MacOS 32

standalone 24

uninstalling Linux 32

uninstalling MacOS 35

uninstalling Windows 27

using Linux 31

using MacOS 34

using Windows 27

Windows 25

client requirements

tunnel mode 18

web-only mode 16

comments, documentation 12

configuration, general steps 20

configuring

SSL VPN client 20

connecting

to ftp server 72

to secure HTTP gateway 65

to telnet server 71, 78, 80

to web portal 66

to web server 24, 70, 80

to web-based manager 36

connections

defining bookmarks to 69

enabling SSL VPN 36

connectivity, testing for 24, 80

customer service 12

D

deployment topology 19

documentation

commenting on 12

Fortinet 9

downloading

Linux client 28

MacOS client 32

Windows client 25

E

establishing cifs session 73

establishing ftp session 72

establishing rdp session 76

establishing smb session 73

establishing vnc session 75

F

firewall policy

tunnel-mode access 48

web-only mode access 46

FortiGate documentation

commenting on 12

Fortinet customer service 12

Fortinet documentation 9

Fortinet Knowledge Center 11

Fortinet SSL VPN Client area 80, 82

ftp server, connecting to 72

ftp session, establishing 72

H

home page, web portal features 66

host check

OS 56

host OS

patch check 56

I

idle timeout setting 40

infrastructure requirements 19

overall 19

tunnel-mode clients 18

web-only mode clients 16

introduction

deployment topology 18

FortiGate SSL VPN technology 7

Fortinet documentation 9

general configuration steps 20

tunnel mode 7

web-only mode 7

IP address range, tunnel mode 38

IPSec VPN

comparison to SSL 13

FortiOS v3.0 MR7 SSL VPN User Guide

86 01-30007-0348-20080718

Index

K

keyboard setting, rdp 76

L

logging

filtering SSL VPN events 51

setting event-logging parameters 50

viewing SSL VPN event logs 51

logging in

to FortiGate secure HTTP gateway 65

logging out

from web portal page 83

M

modes of operation 7, 15

tunnel mode 17

web-only mode 15

My Bookmarks list 69

N

network configuration 19

recommended 18

O

obfuscation 68

OS host patch check 56

P

patch check

host OS 56

ping host from remote client 24, 80

port number

for web-portal connections 38

R

rdp keyboard setting 76

rdp session, establishing 76

redirection, to popup window 40

replacement message, to customize web portal login

page 41

S

security certificate

allow group certificate 47

sessions, monitoring 51

smb session, establishing 73

split tunneling 7

SSL VPN

bookmark 52

bookmark group 54

checking client certificates 37

comparison to IPSec VPN 13

configuration overview 20

configuring client 20

deployment topology 18

downloading client software 81

downloading Linux client 28

downloading MacOS client 32

downloading Windows client 25

enabling connections 36

event logging 50

host OS patch check 56

introduction to FortiGate 7

modes of operation 7

monitoring sessions 51

setting the cipher suite 37

specifying server certificate 37

specifying timeout values 38

split tunneling 7

standalone client 24

tunnel IP range 37

tunnel-mode user groups 57

uninstalling Linux client 32

uninstalling MacOS client 35

uninstalling Windows client 27

using Linux client 31

using MacOS client 34

using Windows client 27

SSL VPN client

installing 81

uninstalling 83

SSL VPN Virtual Desktop 21

downloading 21

running 21

using 21

T

technical support 12

telnet server, connecting to 71, 78, 80

telnet session, starting 71, 78

Tools area 68, 80

tunnel mode 17

client requirements 18

configuring FortiGate server 48

firewall policy for 48

Fortinet SSL VPN Client area 80, 82

introduction 7

IP address range 38

user group, unique access permissions 57

web portal features 80

tunnel, initiating 82

U

unique access permissions

configuring user groups 57

granting 57

SSL VPN tunnel mode 57

URL

for user log in 65

URL obfuscation 68

URL re-writing 68

user accounts, creating 42

user groups

configuring SSL VPN tunnel-mode 57

creating unique access permissions 57

user groups, creating 42

Index

FortiOS v3.0 MR7 SSL VPN User Guide

01-30007-0348-20080718 87

V

Virtual Desktop 21

downloading 21

running 21

using 21

vnc session, establishing 75

VPN tunnel, initiating 82

W

web portal 69

adding caption to home page 40

applications 68

customizing login page 41

Fortinet SSL VPN Client area 80, 82

home page features 66

redirecting to popup window 40

setting login page port number 38

Tools area 68

tunnel mode features 80

web server

connecting to 24, 70, 80

web-based manager

connecting to 36

web-only mode 15

client requirements 16

firewall policy for 46

introduction 7

X

X.509 security certificates 39

FortiOS v3.0 MR7 SSL VPN User Guide

88 01-30007-0348-20080718

Index

www.fortinet.com

www.fortinet.com
