Foshan Lanchiya Digital Technology 000MD201 WIRELESS BLUETOOTH SPEAKER User Manual USERS MANUAL
Foshan Lanchiya Digital Technology Co., Ltd. WIRELESS BLUETOOTH SPEAKER USERS MANUAL
USERS MANUAL
MD2
6.Re-pairing: To touch the PAIR button on the control panel for re-pairing,
meanwhile the indicator will flash, and there is voice prompt” Waiting for
the pairing”. then you can pair the MD2 with your Mobile, the voice prompt
【pairing completed】after paired.
8.AUX input play: touch the INPUT button on the control panel till the indicator
turn red and the un it will be connected to the AUX channel play. You can
play music via 3.5mm from Mobile, MP3, and PC.
MADE IN CHINA
Address : hongtu RD,Songxia lndustry Park,Songgang Nanhai District,Foshan,
Guangdong Province,China
Manufacturer:Foshan LANCHIYA Digital Technology Co., Ltd China
SPECIFICATIONS
A m pl if ie r o ut pu t p ow er : 4W ( RM S) X 2
A m pl if ie r i np ut s e ns it iv i ty : ≤4 0 0 m V
: ≤ %
A m pl if ie r S NR : ≥ 75 d B
F r eq ue nc y r es po n se :7 0H z ~2 0K Hz
D C i np ut : D C 5 V 0.5 - 1 A
B a tt er y: 3 . 7V 2 20 0 mA h
B a tt er y ti m e 6- 10 h ou rs
B a tt er y ch a rg in g ti m e: 4 -6 h ou rs
B l ue t oo th r a ng e: 7 - 10 M
B l ue to ot h v er si on : 2 .1+E D R S u p p o r t A 2 D P
D i s t o r t i o n 1
56
9.Built -in bat tery us e: when usi ng the bu ilt-in battery to play music, the
unit will mana g e th e ba t t e r y use automa tically, when the power is low,
the unit wil l decre ase the volume to ensure the sound qu ality and longer
play time, and voice prompt(the battery is low please recharge) once in 1 minutes,
the front indicator will be red and flash, When battery cannot support normal
used unit will be power off after red indicator flash for 5 times
7.Please recharge on time when battery is low, for the device can work as well
8.Please recharge the batter in every three months if long times no use.
9.The speaker has high capacity batter inside please avoid the heat, wet,
do not disassemble the battery or put in into water or fire.
10.If you have problem with NFC, please check:
1)Make sure the mobile has NFC function,
2)Make sure the NFC and Bluetooth is ON
3)Make sure the NFC can activate the Bluetooth and audio in you mobile
4)Make sure the mobile is unlocked
5)Remove the phone case
6)Use the right part of NFC on your mobile
7)If the NFC found AMETHYST MD2 but can't connect, make sure MD2 is
on and under Bluetooth mode
11.if you can not connect with speaker as well, please power it off for 3s then
turn it on.
12.The USB port only used for supplying elec t ri ca l voltage for operational
power or recharging the internal batteries, not any data transfer between
the PC
NOTE
*
1.The Bluetooth device can't find the speaker, the speaker may still connect
with last Blue tooth device or another device are searching and connecting
with speaker at same time. Now you need to operate as Step 6 to re-connect it
2. If you hear intermittent sound or no sound from speaker after connection
Please check if the distance from you and speakers are in communication
range (8-10M without barrier)
3.Don't let Opposite close to speaker when you use speaker phone function
to avoid Echo
4.Please use default music player with your blue tooth device system like,
iPod, Samsung player, Windows media player. As lots of third party music
player does not support smooth song change function, to avoid “pu”sound.
5.Not work with NFC: please make sure the mobile has NFC function and turn
it on.
6.The phon e case may influence the NFC function, please remove if you
cannot connect NFC as well.
7.TF card: Insert the TF card when MD2 is on, the MD2 will play music from
TF card automatically, or you can press input to select TF card, the front
indicator will be orange, follow the step 4 to control the music playing.
PAIR
INPUT
10.Charging: please use the supplied USB cable to connect USB port on PC
(USB 2.0 ) or adaptor (output 1A), the red indicator on the back of the
unit will flash when charging. When the battery is fully-charged, the green
indicator will stop flash.
带NFC 带插卡版英 文说明书 MD2-G01- 0
INPUT
1
1.MD2 machine
2. Power adapter
3.Audio cable 4 User manual.
PACKAGE CONTENTS
Brief Operation Introduction
PROPERTY RIGHTS INFORMATION:
The trademark amethyst lanchiya and all the developed products with this label
are registered patents,and belong to Foshan LANCHIYA digitai Technology Co.,Ltd.
Our company reservesall rights,and no t allow rep ri nt ing.O th er con ce rned
trademar ks al l b el o n g t o t h e i r p r o p riet o r s .As to th e co n s t a nt upd at e and
development of the products,our company reserves the right to change and
rework our products without notice.
WARING: To prev e n t a n y fi r e or el e ct r i ca l ha zards, do not remove
or dissemble any parts from this unit. Ple as e ensure that you use a
qualified technician to service it.
• Do not expose the unit to rain, water or moisture
• Do not place liquid on or close to unit
• Do not place unit on or near an open fire such as candles or light
• Keep away from heat and dust
• Place unit on a stable and level platform
• Do not place any items on top of unit
• Do not use excessive force when pushing the unit buttons
• Do not attempt to pull the power cord from a distance to shut the power
Children and dispose in appointed place for battery
• Secure all cords and connections and do not use pinched or defective one
• Unplug the power cable if the unit is left unused for extended periods
• Clean with a damp cloth only
•
• Blue tooth device can't be found: probably, the Speaker has been connected by
other Blue tooth device. Press Pair button to search it again. If you still cannot
find the speaker, please Turn Off the speaker for 5second then turn it on.
• Blue tooth signal intermittently: the effective distance between speaker and
Device is 10M, the signal will be intermittent if the distance more than 10M.
• If there are more than 1 Speaker are switch on, the Bluetooth device will find
more than 1 speaker, if you want to connect one of them please turn off the others
• If your Bluetooth device on searching and find many other Bluetooth device,
please wait for the searching finished and select Speaker to pair.
The unit with Lithium Battery in please don't burn,bite,Keep away from
234
1.
Power-on Operation: After switching MD2 on, the Music and voice prompt
(The Blue tooth mode is on) the indicate light on the front panel is flashing
between blue and red, MD2 starts to search the device that connected last
time. If the searching is successful, MD2 will connect automatically with
the device, and voices prompt ”paired”. MD2 will play the music through
the device. If the MD2 can't find the last paired device in 5s, MD2 will be in
the status of being searched by other devices, and the indicator will be blue
3
4
2
1
3.Connecting by Bluetooth: Search and find 【AMETHYST MD2】 with your
Bluetooth device after turn it on connect it The voice Prompt “paired” .Then
you can play music from your Bluetooth device . If your device can not find
the MD2, Press “Pair” on the top of MD2, voice prompt “Waiting for the pair” ,
then you can try to pair it.
4. Music-playing operation: When MD2 has successfully connected to the
Bluetooth device properly, you can control the music-playing of the mobiles
through touching the VOL+, VOL- PREV,NEXT,PLAY/PAUSE button on the
touching panel
PREV,NEXT,PLAY/PAUSE
AMETHYST MD2
ON
PAIR
【PHONE】
5.Incoming-call operation: When the call comes in during playing music, answer
the call by touching the button 【PHONE】on the touching panel and talk facing
the top panel; or dial the receiver button on the mobile and choose to use mobile
to answer the call
2. NFC
1).
2).Make sure the Cell phone have NFC communication which can activate
the Bluetooth to pair and audio connection.
3)Make sure the screen of cell phone is unlocked.
4)Make sure the NFC and Bluetooth in your cell phone is on
5)
Connecting by :
Make sure the MD2 is On and in Bluetooth channel.
Make the NFC parts of cell phone and MD2 touch each other for 2second
(if you can't make sure where is NFC part of your cell phone please google
it, or move your cell phone on MD2 NFC part until it connected) the cell
phone will show connect it or not on screen, press yes then you can move
the cell phone and wait 5-8s, the cell phone will connect it with speaker
and voice prompt Paired, then you can play music from your cell phone,
(Note: of the cell phone has paired with MD2, it won't show connect it or
not but connected or disconnected)
PRESS YES
AMETHYST MD2
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are
designed topro vid e reas ona ble prote ction aga inst h a r m f u l inter feren ce
in a r esi dent ial installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instruct ion s, m ay ca u s e h a r m f ul interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
insta l l a t i o n . If t h i s equipment doe s c aus e h a rmful interference to radio
or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equi pment int o an outl et on a circuit different fro m that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equ ipment complies with FCC’s RF radiation exposure limits set forth
for an uncontrolled environment. The antenna(s) used for this transmitter
must be installed and operated to provide a separation distance of at least
20 cm from all persons and must not be collocated or operating in conjunction
wi th an y ot her ant enn a o r t r an smitter.Inst all ers must ensure that 20cm
separation di sta nce wi ll be mainta ine d between the device (excluding its
handset) and users.
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
”batteries shall not be exposed to excessive heat such as sunshine, fire or
the like.”“the apparatus shall not be exposed to dripping or splashing and
that no objects filled with liquids, such as vases, shall be placed on the
apparatus.”
“CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.”
where the MAINS plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable
Caution: The user is cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void the user's
authority to operate the equipment.
The user manual for an intentional or unintentional radiator shall caution the
us er tha t c h an g es or mod ifi c at i ons not exp re s sly approved by the party
responsi ble fo r comp lia nce co uld vo id the user ’s authority to operate the
equipment.
Th is equ ipm e nt com pli es w it h F C C r adi ati o n e xp o sur e l imi t s s et for th for an
uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
