Foxda Technology ARM2 Portable High Fidelity High Resolution Music Player) User Manual Rev

Foxda Technology Industrial (Shenzhen) Co., Ltd. Portable High Fidelity High Resolution Music Player) Users Manual Rev

Contents

Users Manual Rev

Getting Started
1. Charging your Player with provided AC/DC adapter
• Connect the USB port of the included AC/DC power
adapter to the Player
• Plug the other end of the adapter to any standard
100-240V AC wall outlet. Charging should be started
automatically
• It should be charged for at least 6 hours before
using for the rst time
• Alternatively, the Player charges automatically every
time you connect it to your computer. Charging
process may be slower and the charging time
depends on the current output of the USB port
2. Install or remove microSD card
• Open the protection cover of the microSD expansion slot. Gently insert a microSD card* into the
microSD expansion slot. Close the protection cover
• Before removing a microSD card, tap on SD card connected - Touch to unmount sdcard on the
notication bar. After that, open the protection cover and gently push the card to release it
Acoustic Research AR-M2
www.acoustic-research.com
Congratulations on purchasing your new Acoustic Research High Resolution Music Player.
Please read these instructions for quick tips on using the Player.
QuickStartGuide
3. Transfer audio les to your Player
Windows 7/Windows 8:
• Connect your Player to the computer
• Open Windows Explorer, select Computer, open AR-M2 under Portable Devices
• Open the desired storage media Internal SD card or SD card (Optional, only if microSD card is installed)
• Drag-and-drop audio les (or folders containing audio les) to the desired destination**
Mac OS X (10.5 or above):
• Download and install Android File Transfer from www.android.com/letransfer/
(First time installation only)
• Connect your Player to the computer
• Run Android File Transfer if it does not pop up autoatically
• Select the desired storage media by clicking on the tab Internal SD card or SD card (Optional , only if
microSD card is installed)
• Drag-and-drop audio les (or folders containing audio les) to the desired destination**
4. Disconnect the Player from the computer and enjoy media on the go.
* Up to 128 GB microSD card is supported
Need more help? Do not return this product to the store.
Visit www.acoustic-research.com for the latest rmware, user manual and FAQ’s.
v1.0 (1.0.0.0) (EN)
Switch on the Player
Switch o the Player
Switch o the display and lock the touch display
Switch on the display and unlock the touch display
Go to the Home screen
Go to the APPS menu
Navigate to an audio le
Play an audio le
Pause playback
Show the Option menu
Adjust the volume
Skip to the next le
Skip to the previous le
Delete les from the Player
Force shutdown the Player
(if it is not responding)
Press and hold the Power button for 3 seconds.
Press and hold the Power button for 3 seconds.
Select Power o.
When the display is on, press the Power button.
The display will also switch o automatically after a
period of inactivity (1 minute by default)
When the display is o, press the Power button.
Swipe the lock icon towards any edges of the screen.
Tap on the Home icon to reached the Home screen
At Home screen, tap on the APPS icons at the lower
right corner
In APPS menu, tap on AR Music Player
In AR Music Player, tap on your desired view by
selecting the corresponding tab
Tap the music le in any view
Press the Play/Pause button during music playback,
press again to resume.
In any navigation view, tap and hold at any media item
Rotate the volume knob clockwise to reduce the
volume or counter clockwise to increase it.
Press .
Press within the beginning 4 seconds of the current
audio le.
Tap at the le and hold until the option menu appear
Select Delete and conrm the action
Press and hold Power button for 10 seconds to force
shutdown the Player.
General controls
©2015 VOXX Accessories Corporation
A wholly-owned subsidiary of VOXX
International Corporation
Indianapolis, IN
Trademark Registered
Printed in China
Touch
Display
Volume
Power on/off button
LINE
OUT
Headphones
Jack
USB PortLine out
www.acoustic-research.com
LINE
OUT
Player
100-240 V AC wall
outlet
AC/DC power
adapter
USB connector cable
* Use only the provided AC/DC adapter
* Image is for reference only, the AC/DC adapter shown in the image
may vary from the actual product
* Music playback during battery charging is possible, but it will slow
down the charging process
Skip back
Play/pause
Skip forward
microSD expansion slot
** Music les are automatically organized under dierent views according to embedded music tags in
5. The device can be used on the hand, also can be used in the pocket.
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information
SAR tests are conducted using standard operating positions accepted by the FCC with the
device transmitting at its highest certified power level in all tested frequency bands, although
the SAR is determined at the highest certified power level, the actual SAR level of the device
while operating can be well below the maximum value, in general, the closer you are to a
wireless base station antenna, the lower the power output.
For body worn operation, this model device has been tested and meets the FCC RF exposure
guidelines that positions the handset a minimum of 5mm from the body.
Non-compliance with the above restrictions may result in violation of RF exposure guidelines.
IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement
7.1.4 Radio Apparatus Containing Digital Circuits (ICES-003)
IC SAR Waring
The device has been tested and compliance with SAR limits, users can obtain Canadian information on
RF exposure and compliance
Le présent appareil est conforme
Après examen de ce matériel aux conformité aux limites DAS et/ou aux limites d’intensité de champ RF,
les utilisateurs peuvent sur l’exposition aux radiofréquences et la conformité and compliance d’acquérir
les informations correspondantes
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
The minimum distance from body to use the device is 5mm.
La distance minimale du corps à utiliser le dispositif est de 5mm.
