FrSky Electronic V5825T 5.8G AV Transmitter User Manual

User Manual

The manual of VS025

Model name:VS025

Operation:

The module is 5.8G AV Transmitter,it through camera, gathering information to the receiving part after

dealing with the internal launch.This product is mainly applied to all kinds of model aircraft products.

Specifications:

1、Size: 20 mm(L)× 30mm(W)×20 mm(H)

2、Weight:3.2g

3、Transmitting frequency: 5732~5866 MHz

4、Power: 5V/150mA

5、Antenna Gain:

2 dBi.

6、Video Format: NTSC

FCC Statement

Any Changes or modifications not expressly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This

equipment should be installed and operated with minimum distance 20cm between the radiator& your

body.

FCC Label and location Instructions

FCC ID:XYFV5825T

This device is too samal to show the FCC ID. So FCC ID is place on the user manual and device packaging.

The outside of final products that contains this module device must display a label referring to the

enclosed module. This exterior label can use wording such as: “Contains Transmitter Module

FCC ID: XYFV5825T" or “Contains FCC ID: XYFV5825T” Any similar wording that expresses the

same meaning may be used.
