SPREAD SPECTRUM WIRELESS DATA TRANSCEIVER INSTALLATION GUIDE
Copyright © 1995-2009 by FreeWave Technologies, Inc. All rights reserved. Published 2009.
900 MHz Wireless
Transceiver
Installation Guide
V6.0a
FreeWave Technologies, Inc.
1880 South Flatiron Court
Boulder, CO 80301
(303) 444-3862
(303) 786-9948 Fax
www.freewave.com
Spread Spectrum Modem Wireless Data Transceiver Installation Guide
LIG0003AD Rev A Version 6.0 2
This installation guide covers all models of the FreeWave Technologies 900 MHz spread
spectrum transceiver sold under FCC ID KNY-42182112519.
All transceiver models sold under FCC ID KNY-42182112519 must be installed
professionally. This transceiver is only approved for use when installed in devices
produced by FreeWave Technologies or third party OEMs approved by FreeWave
Technologies. The antenna(s) used must provide a separation distance of at least
23cm from all persons and must not be co-located or operating in conjunction with
any other antenna or transmitter. This transceiver must be installed in a NEMA
enclosure.
FCC Notification
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: 1) This device may not cause harmful interference and 2) this device
must accept any interference received, including interference that may cause undesired
operation.
This device must be operated as supplied by FreeWave Technologies, Inc. Any changes
or modifications made to the device without the express written approval of FreeWave
Technologies may void the user's authority to operate the device.
CAUTION: Models sold under FCC ID KNY-42182112519 of this device have a
maximum transmitted output power of 1000mW. It is required that the
transmit antenna be kept at least 23 cm away from nearby persons to
satisfy FCC RF exposure requirements.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates and
can radiate radio frequency energy. If the equipment is not installed and used in accordance with
the instructions, it may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
♦ Reorient or relocate the receiving antenna.
♦ Increase the separation between the equipment and receiver.
♦ Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
♦ Consult the dealer or an experienced radio/TV technician for help.
Note: Whenever any FreeWave Technologies module is placed inside an enclosure a label must
be placed on the outside of that enclosure which includes the module's FCC ID.
Spread Spectrum Modem Wireless Data Transceiver Installation Guide
LIG0003AD Rev A Version 6.0 3
UL Notification
Model# FGR2 is suitable for use in Class 1, Division 2, Groups A, B, C, and D or non-
hazardous locations only.. Input voltage for Model# FGR2 is 6 to 30 volts DC.
Spread Spectrum Modem Wireless Data Transceiver Installation Guide
LIG0003AD Rev A Version 6.0 4
A. Transceiver installation steps
To install the FGR2 series transceivers, follow the basic steps given below.
1. Mount the transceiver to the flat, stable surface using mounting holes in the corners of the
transceiver. Transceiver models sold under FCC ID KNY- 42182112519 are to be installed
professionally in NEMA enclosures.
2. Install the antenna and connect the antenna feed-line to the transceiver. If installing a
directional antenna, preset the antenna’s direction appropriately. The antenna must be
professionally installed on a fixed-mounted permanent outdoor structure for satisfying RF
exposure requirements.
3. Connect the serial port of a computer to the transceiver’s RS232 port (please refer to the part
C of this addendum for more information about the transceiver’s pin assignment). This
computer will be used to set the radio’s configurations.
4. Install the power for the radio.
5. Set the radio configuration according to the system topology and data terminal equipment
requirements. Default transceiver settings allow user to do a quick installation without major
changes in transceiver’s configuration. However, there is one parameter that must be
considered for a new installation – the transceiver’s power output setting. Transceiver
output power level must be set according to the tables given below to satisfy the FCC
maximum EIRP requirement. Per FCC regulations, any antenna used with FreeWave
transceivers must either be one of the approved antennas shown below or an antenna
approved by FreeWave Technologies with comparable performance parameters. FreeWave
Technologies offers a variety of Omni-directional and directional external antennas, with both
bracket and magnetic mounts. The complete list of antennas available from FreeWave
Technologies including antenna gains, antenna manufacturer’s information and antenna’s
characteristics are shown below:
The following antennas are approved for use with FreeWave transceivers:
900MHz Directional Antennas
Gain Manufacturer Manufacturer
Model Number FreeWave
Model Number
11dBi Larsen YA5900-W EAN0900YA
10dBi BlueWave BMY890K5502N4 EAN0900YC
6dBI BlueWave BMY890G5502N4 EAN0906YC
6dBi Larsen YA6-900 EAN0906YA
Spread Spectrum Modem Wireless Data Transceiver Installation Guide
LIG0003AD Rev A Version 6.0 5
900MHz Omni-directional Antennas
Gain Manufacturer Manufacturer
Model Number FreeWave
Model Number
6dBi Antennex FG9026 EAN0906NF
5dBi Antennex
Maxrad
EB8965C
BMEFC8985HD
EAN0905WC
5.15dBi Maxrad MAX-9053 EAN0900WC
2dBi Mobile Mark PSKN3-925S EAN0900SR
2dBi Mobile Mark PSTG0-915SE EAN0900SQ
2dBi Astron ADP91BM ---
WARNING: Any antennas placed outdoors must be properly grounded. Use extreme
caution when installing antennas and follow all instructions included with the antennas.
Table 1 below provides the maximum output power settings for FreeWave transceivers at given
antenna gain (10 dB and 6 dB Yagi antennas are given as an example) and cable loss
combinations. Please note that it is the installer’s responsibility to ensure that the emission
limits are not exceeded.
Table 1: Output Power Settings at given Antenna Gain &
Cable Loss combination.
Cable Loss
1dB 2dB 3dB 4dB
Antenna 10dB 5 6 7 9
Gain 6dB 9 9 9 9
Table 2 below shows how the RFXmitPower settings on the radio correspond to the EIRP of the
transceiver-cable-antenna combination for a 10dB Yagi antenna at different cable loss values.
Table 2: EIRP for 10dB Yagi Antenna Cable loss vs. RF
Xmit Power Setting.
Cable Loss
1dB 2dB 3dB 4dB
RF Xmit 10 39.00 38.00 37.00 36.00
Power 9 37.80 36.80 35.80 34.80
8 36.30 35.30 33.30 32.30
7 34.40 33.40 32.40 31.40
6 32.20 31.20 30.20 29.20
Shaded area indicates combinations where EIRP limitations exceed FCC regulations
and RF Xmit Power must be reduced.
Spread Spectrum Modem Wireless Data Transceiver Installation Guide
LIG0003AD Rev A Version 6.0 6
Table 3 below is similar to the Table 2, but shows the information for the 6 dB Yagi antenna.
Table 3: EIRP for 6dB Yagi Antenna Cable loss vs. RF
Xmit Power Setting.
Cable Loss
1dB 2dB 3dB 4dB
RF Xmit 10 35.00 34.00 33.00 32.00
Power 9 33.80 32.80 31.80 30.80
8 32.30 31.30 30.30 29.30
7 30.40 29.40 28.40 27.40
6 28.20 27.20 26.20 25.20
Follow the steps below to configure the Power Output Level:
Start HyperTerminal or any other terminal emulation program on the computer connected
to the transceiver’s RS232 port (refer to the User Manual for the HyperTerminal setup
instructions).
Invoke the setup menu on the transceiver.
Choose option number “3” from the Main Menu, as shown on the “Hyper Terminal”
window.
Choose option number “5” from the “Radio Modem Parameters” menu followed by the
settings an appropriate RFXmitPower value, as defined above. The RFXmitPower setting
may vary from site to site due to differing antennas and/or cable type or length.
6. Repeat the steps above for each transceiver in the network.
NOTE. Please, be advised that antennas other than listed in this section can potentially be used
with the transceiver provided that:
• these antennas are of a similar type to the listed above;
• antenna gain does not exceed 5dB for Omni-directional and 11dBi for directional antenna;
• overall system EIRP does not exceed 36dBm.
WARNING: Any antenna other than listed in this section needs to be approved by
FreeWave Technologies before it is used to assure that the transceiver in combination
with the new antenna meets FCC requirements.
B. Transceiver Location
Placement of the FreeWave transceiver is likely to have a significant impact on its performance.
With regard to FreeWave transceivers generally, the higher the placement of the antenna the
better the communication link - height is everything! In practice, you should also place the
transceiver away from computers, telephones, answering machines, and other similar equipment.
To improve the data link, FreeWave Technologies offers directional and Omni-directional
antennas with cable lengths ranging from 3 to 200 feet.
When using an external antenna, placement of that antenna is critical to a solid data link. Other
antennas in close proximity are a potential source of interference; use the Radio Statistics or
Diagnostics software to help identify potential problems. It is also possible that slight adjustments
in antenna placement (as little as 2 feet) will solve noise problems. In extreme cases, such as
when the transceiver is located close to Pager or Cellular Telephone transmission towers,
FreeWave offers a band pass filter to reduce the out of band noise.
Spread Spectrum Modem Wireless Data Transceiver Installation Guide
LIG0003AD Rev A Version 6.0 7
C. Board Level Pin Assignments
The board level transceiver uses standard RS232 polarity and voltage levels for all of the RS232
signal lines (DTR, Transmit Data, Receive Data, Carrier Detect, RTS, and Clear to Send).
Pin 1: B+ Power input.
Pin 2: Interrupt (INT) – Input – A 0 volt level on this pin will switch the radio into setup mode.
Table 4: Board Level
Transceiver Pin out
Pin Signal Assignment
1 Power B+ input
2 Input Interrupt (Ground to invoke)
3 Input DTR (Data Terminal Ready)
4 Ground
5 Output TXD (Transmit Data)
6 Ground
7 Input RXD (Receive Data)
8 Output CD (Carrier Detect)
9 Input RTS (Redy to Send)
10 Output CTS (Clear to Send)
Note: Pin 1 board level transceiver is the pin farthest from the three LEDs and pin 10 is closest to
the LEDs.
D. Power Connection
The FGR2 series transceivers can be operated from any well-filtered DC power source, input
voltages vary by model. The power source should be capable of providing at least 0.8 amperes of
continuous current. The pin #1 of the 10-pin connector on the transceiver is the positive lead; pin
#4 or pin #6 of this connector should be as a negative lead.
Transceiver is designed to operate in negative ground systems only.
