Freescale Semiconductor WCT-5W1COILTX Wireless Charger Transmitter User Manual WCT1000 A11 Reference Design System User Guide
Freescale Semiconductor, Inc. Wireless Charger Transmitter WCT1000 A11 Reference Design System User Guide
RUN-WCT-5W1COILTX_User Manual_Rev1
Freescale Semiconductor Document Number: WCT1000SYSUG
User Guide Rev. 3.1, 01/2014
© Freescale Semiconductor, Inc., 2014. All rights reserved.
_______________________________________________________________________
WCT-5W1COILTX
User Guide
1 Introduction
This document describes how to use 5W low
power wireless charger transmitter
WCT-5W1COILTX designed by Freescale.
Figure-1 WCT-5W1COILTX
Contents
1 Introduction 1
2 System Features 2
3 Getting Started 2
4 Cautions 3
WCT-5W1COILTX Reference Design System User Guide, Rev. 3.1
2 Freescale Semiconductor
2 System Features
The WCT-5W1COILTX reference board has following features:
• Reference design compliant with low power WPC Qi version 1.1 Specification.
• Integrated digital demodulation in chip.
• Support multiple types Rx modulation signals (AC capacitor, AC resistor and DC resistor).
• Support FOD. Support four types of Foreign Object protection.
• Support Qi 1.1 receiver with 5 V DC@1A output power capability.
• Super low standby power by Freescale touch technology.
• Full bridge topology with freqency modulation power control strategy.
• LED for RX and TX alignment indication.
• Input voltage/current, coil current sensing for protection.
3 Getting Started
WCT-5W1COILTX is easy to use, and can convenience to charging the mobile equipment that support
the Qi wireless charging, below is the detail step to power up the system and use.
Step 1: power on the Transmitter, plug the 5V adaptor to the AC power line, and plug the adaptor USB
port to the transmitter input port, and the LED1 will be blanking.
Figure-2 WCT-5W1COILTX power on
Step 2: Place the wireless charging RX or some equipment that support the Qi wireless charger(such as
cell phone, battery and so on ) on the WCT-5W1COILTX’s coil surface, then the transmitter will charge
the equipment, under the normal charging states, LED1 will be turned on all the time, and LED2 will be
blanking, and the RX will powered on the equipment normally.
WCT-5W1COILTX User Guide
Freescale Semiconductor 3
Figure-3 WCT-5W1COILTX charging the equipments
Others Indicates: when the Transmitter get the end power communication information, it will stop the
charging and wait until the RX is removed, under this states LED1 will be turned off, and LED2 will be
turned on all the time. When some fault found, the transmitter will turn off LED1, and turn on LED2 until
the fault is removed, fault include the FOD fault, OVP, OTP and so on.
4 Cautions
• This device has been tested and found to comply with the limits pursuant to Part 18 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
• If this equipment does cause harmful interference to other electronic equipments, which can be
determined by turning the equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the equipment
• Increase the separation
• In order to use the equipment safely，please don’t open the case when powered on，and don’t touch
the PCB and components with hand.
• Don’t place some metal things between the TX surface and the RX surface, otherwise the metal
things will be heated, it the temperature is too high, the Transmitter will shut down for protection.
WCT-5W1COILTX Reference Design System User Guide, Rev. 3.1
4 Freescale Semiconductor
This device complies with Part15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
To satisfy FCC RF exposure requirements for mobile and base station transmission devices,
a separation distance of 20 cm or more should be maintained between the antenna of this
device and persons during operation. To ensure compliance, operation at closer than this
distance is not recommended. The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.
