Fudakang TP100 Digital thermomter User Manual TP100
Fudakang Industrial Co., LTD Digital thermomter TP100
Fudakang >
User Manual
Storage Case
QUICK START GUIDE
Overview
Adhesive Silicone Battery Cap
Patches (5) Patches (7) Opener
ON/OFF Button
Sensing Probe
Holder (2)
Battery Compartment
Definition of Terms
0 Thermometer/Device: GuardiAngel thermometer
for single or continuous temperature measurement.
0 Portable Device: Any iOS or Android device that
supports Bluetooth function for monitoring your child’s
body temperature remotely.
Getting Started
Step 1: Insert the Battery
First Time Use
• Pull the plastic tab to open the
battery compartment. Then discard
the plastic tab.
a) Use the battery cap opener to remove the battery cap.
b) Install the battery into the compartment and replace the
battery cap. Then lock the cap back using the battery cap
o
p
ener.
Step 2: Power On the Thermometer
Long press the ON/OFF button until the
power indicator starts blinking red.
Note
Step 3: Download the GuardiAngel App
0 To power off the thermometer, long press the ON/OFF button
until the power indicator turns off.
a) In your portable device, open App Store (for iOS device) or
Play Store (for Android device).
b) Search for GuardiAngel app and then install it on your
portable device.
Step 4: Complete the Bluetooth Pairing
a) Make sure the Bluetooth is enabled on your portable device.
b) Tap to open the GuardiAngel app.
c) Login using your Facebook or Google account.
The app automatically detects the thermometer and pairs your
portable device with the thermometer.
Note
0 If the pairing process is successful, the power indicator on
the thermometer starts blinking blue.
d) Ta p Confirm to
complete the
Bluetooth pairing.
The thermometer is now ready for
Wearing the Thermometer
0 The thermometer is safe to use on children of all
ages, beginning with the newborns.
0 Do not wear the thermometer intact with the skin
for more than 24 consecutive hours.
0 The supplied adhesive patches are for single use
only.
0 We recommend using only these types of adhesive
and silicone patches that came with the package.
0 Although the material of the adhesive patches is
considered nonallergic and nontoxic, in case your
child still develops an allergic reaction, please consult
with your physician for finding alternative patches.
0 In order to avoid inaccurate measurement data,
check the thermometer regularly to make sure the
sensing probe is firmly intact with the armpit.
0 Clean the surface of the thermometer with the
concentrated medical alcohol before and after use.
Important!
TP100 USER’S MANUAL
The thermometer can be worn as:
0 Patched On: The sensing probe and the main unit are
both attached to the skin directly or
0 Clipped On: The sensing probe is attached to the skin
directly but the main unit is attached to the shirt.
Patched On Method
a) Remove the film from one side of the adhesive patch and
place the patch on top of the holder. Then place the holder
on the battery cap.
b) Remove the film from the other side of the
adhesive patch.
c) Remove the film from the silicone patch. Then attach the
silicone patch to the opposite side of the sensing probe as
illustrated below.
d) Gently lift your child’s arm. Attach the main unit under the
shirt, closer to the armpit. Then attach the sensing probe to
the armpit. Carefully place your child’s hand down.
Clipped On Method
b) Gently lift your child’s arm. Place the main unit
under the shirt near the armpit and secure it with the
holder on top of the shirt so that the cloth is between
the main unit and the holder. Attach the sensing
probe to the armpit. Carefully place your child’s hand
down.
a) Remove the film from the silicone patch. Then
attach the silicone patch to the opposite side of the
sensing probe as illustrated below.
Measure Page
Measure/
A
ctivity
Graphic
c) Tap any of the menu items:
0 My Guardi Angel: View the
paired thermometers.
0 My Kids: Modify your child’s
profile or add a new child.
0 Add Events: Modify an existing
event or create a new event
and assign a category.
0 History: Tap on the day in the
calendar marked with pink dot ( ) to view
the measurement history on that day.
0 Measure: Measure the currently selected child’s
temperature. See more in Measuring the Temperature.
0 Add thermometer: Add more Bluetooth thermometers.
0 Settings: Read the regulatory information, log out the
current user and clear the data, and/or switch the temperature
measurement unit between Celsius (ºC) and Fahrenheit (ºF).
Measuring the Temperature
The GuardiAngel app allows you to measure the body
temperature of multiple children. You can take a single
measurement and/or continuously monitor the temperature of
each child.
a) Make sure the thermometer is firmly attached to your
child's body.
b) Open the GuardiAngel app.
c) Tap the thermometer icon,
for example .
d) Select the child’s profile you want to
measure his/her body temperature.
e)Ta p and select Measure.
f) Select the measurement method:
0 Single Measurement: Tap and
follow the on-screen instructions.
- Continuous Measurement:
Continuous measurement is turned on
by default. To stop continuous
measurement, tap Stop.
g) Tap to view the measurements
and activity in a graph. Tap
to return to the Measure page.
h) Tap for additional information
i) on measuring the body temperature.
j) Tap for alarm temperature configuration.
k) Ta p to disconnect the thermometer.
changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures: --
Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
Using the GuardiAngel App
a) After the Bluetooth pairing is
complete, tap the thermometer logo
( ). You are then prompted to enter
your child’s personal information as
well as set the high and low body
temperature for the alarm
configuration. After entering the
required information, tap Create.
b) Tap or swipe the screen to the
right to access the GuardiAngel main
