This manual will show you how to use your FUJIFILM DIGITAL CAMERA

FinePix2800 ZOOM correctly. Please follow the instructions carefully.

BL00071-200 (1)

Warning

This symbol is intended to alert the user to

the presence of uninsulated “dangerous

voltage” within the product’s enclosure

that may be of sufficient magnitude to

constitute a risk of electric shock to

persons.

This symbol is intended to alert the user

to the presence of important operating

and maintenance (servicing)instructions

in the literature accompanying the

appliance.

For customers in the U.S.A.

FCC Statement

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions : (1)This device may not cause

harmful interference, and (2)this device must

accept any interference received, including

interference that may cause undesired

operation.

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The graphical symbols are located on the bottom

of the case.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

CAUTION

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses, and

can radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference to

radio communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to

try to correct the interference by one or more of

the following measures :

—Reorient or relocate the receiving antenna.

—Increase the separation between the

equipment and receiver.

—Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

Please read the Safety Notes (➡P.92)

and make sure you understand them

before using the camera.

—Consult the dealer or an experienced radio/TV

technician for help.

You are cautioned that any changes or

modifications not expressly approved in this

manual could void the user’s authority to operate

the equipment.

Notes on the Grant:

To comply with Part 15 of the FCC rules, this

product must be used with a Fujifilm-specified

ferrite-core USB cable and DC supply cord.

For customers in Canada

CAUTION

This Class B digital apparatus complies with

Canadian ICES-003.

4 5

4 Advanced Features Playback

PLAYING BACK MOVIES .................................. 52

■Playing Back Movies .................................... 53

PLAYING BACK VOICE CAPTIONING .............. 54

■Playing Back Voice Captioning .................... 55

ERASING SINGLE • ALL FRAMES/FORMATTING

... 56

HOW TO SPECIFY PRINT OPTIONS (DPOF)

... 58

fDPOF DATE SETTING ............................. 59

fDPOF SET FRAME ................................... 60

PLAYBACK MENU

5 Settings

6 PC Connection

SETTINGS .......................................................... 62

■List of Settings ............................................. 62

■SET–UP Menu Options ................................ 62

USING THE OPTION MENU .............................. 63

Using SET–UP ................................................ 63

dj SETTING THE FILE SIZE AND QUALITY

(COMPRESSION RATIO) .......................... 64

dLCD BRIGHTNESS/VOLUME ....................... 65

POWER SAVE .................................................... 66

SET–UP

eMOVIE ....................................................... 49

MOVIE MODE

System Expansion Options (Sold Separately)

... 74

Accessories Guide .......................................... 75

Notes on Using Your Camera Correctly ......... 77

Notes on the Power Supply ............................ 78

Applicable Batteries .................................. 78

Notes on the Batteries ............................... 78

Notes on Using the AC Power Adapter ..... 80

Notes on the SmartMedia™........................... 81

Warning Displays ............................................ 83

Troubleshooting .............................................. 86

Explanation of Terms ...................................... 89

Specifications .................................................. 90

Safety Notes ................................................... 92

EC Declaration of Conformity ......................... 95

IN PC (PERSONAL COMPUTER) CONNECTION

... 67

The first time you connect

the camera to your computer .......................... 67

DSC (Mass storage device) Mode .................. 67

PC-CAM (camera) Mode ................................ 67

CONNECTING AT DSC MODE .......................... 68

CONNECTING AT PC-CAMERA MODE ............ 70

DISCONNECTING FROM THE PC

(Important — always use this procedure.) .......... 72

Contents

1 Getting Ready

2 Basic Photography

3 Advanced Features Photography

PREFACE ........................................................... 11

Selecting the Language .................................. 11

Attaching the Lens Cap and Shoulder Strap .. 11

LOADING THE BATTERIES .............................. 13

LOADING THE SmartMedia™........................... 14

REMOVING THE SmartMedia™........................ 15

SWITCHING ON AND OFF ................................ 16

SETTING THE DATE AND TIME ....................... 17

USING THE OPTIONAL AC POWER ADAPTER

... 19

Warning ............................................................ 2

Preface ............................................................. 6

Camera Features and Accessories .................. 7

Nomenclature ................................................... 8

qTAKING PICTURES (AUTO MODE) .............. 20

■Indicator Lamp Display ................................ 24

Number of Available Shots ............................. 25

USING AF/AE LOCK .......................................... 26

DIGITAL ZOOM .................................................. 28

FRAMING GUIDELINE FUNCTION ................... 29

STILL IMAGE MODE

3VIEWING YOUR IMAGES (PLAYBACK) ........ 30

PLAYBACK ZOOM ............................................. 31

MULTI-FRAME PLAYBACK ............................... 32

ERASING SINGLE FRAME ................................ 33

PLAYBACK MODE

ADVANCED FEATURES PHOTOGRAPHY ....... 35

■Photography Mode Specifications ............... 35

SELECTING PHOTOGRAPHY MENU

(1/2/6) ... 36

PHOTOGRAPHY MENU OPERATION .............. 37

yFLASH ....................................................... 38

AUTO

Auto Flash Mode ................................. 38

:Red-Eye Reduction ............................. 39

yForced Flash ....................................... 39

uSuppressed Flash ............................... 40

;Slow Synchro ...................................... 40

MACRO (CLOSE-UP)PHOTOGRAPHY

... 41

oSELF-TIMER PHOTOGRAPHY ................ 42

7VOICE CAPTIONING ................................ 44

aEV (EXPOSURE COMPENSATION) ........ 46

WHITE BALANCE (SELECTING THE LIGHT SOURCE)

... 47

6CONTINUOUS SHOOTING ...................... 48

PHOTOGRAPHY MENU

STILL IMAGE MODE

Camera Features and Accessories

hSuperb image quality provided by the high-resolution

Fujinon 6×zoom lens and 2.0 million effective pixels

hMaximum number of recorded pixels: 1600 ×1200 pixels

(1.92 million pixels)

hCompact and lightweight body

hWide range of photography applications (includes Macro

function)

hIntelligent Auto White Balance and AE functions built in

hBuilt-in automatic flash with precise wide-range flash

control

h2.5×digital zoom photography and up to 5×zoom

playback functions

hEasy operation using the Mode switch, “g” buttons and

“a([) b(])” bar.

h1.8-inch 62,000-pixel amorphous silicon TFT LCD

monitor and 0.55-inch electronic viewfinder (EVF)

h2 frames/sec. continuous shooting function

hVoice Caption function records up to 30 seconds of

sound.

hMovie shooting function (320 × 240 pixels with sound)

hEasy high-speed image file transfer via the USB

connection (using the Interface Set provided with sound)

hBuilt-in PC Camera function

hConforms to the new standard for digital camera file

system✽

✽Design rule for Camera File system

Features Accessories

hLR6 AA-size alkaline batteries (4)

hSmartMedia (16MB, 3.3V) (1)

Supplied with:

•Anti-static case (1)

•Index label (1)

hLens Cap (1)

hShoulder Strap (1)

hInterface Set (1)

•CD-ROM (1)

•Special USB cable with Noise Suppression core (1)

•Software Quick Start Guide (1)

hOwner’s Manual (this manual)(

■Test Shots Prior to Photography

For particularly important photographs (such as weddings

and overseas trips), always take a test photograph and view

the image to make sure that the camera is functioning

normally.

hFuji Photo Film Co., Ltd. cannot accept liability for any

incidental losses (such as the costs of photography or the

loss of income from photography) incurred as a result of

faults with this product.

■Notes on Copyright

Images recorded using your digital camera system cannot be

used in ways that infringe copyright laws without the consent

of the owner, unless intended only for personal use. Note that

some restrictions apply to the photographing of stage

performances, entertainments and exhibits, even when

intended purely for personal use. Users are also asked to note

that the transfer of memory cards containing images or data

protected under copyright laws is only permissible within the

restrictions imposed by those copyright laws.

■Liquid Crystal

If the LCD monitor or viewfinder (EVF) panel is damaged,

take particular care with the liquid crystal in the monitor or

viewfinder. If any of the following situations arise, take the

urgent action indicated.

hIf liquid crystal comes in contact with your skin

Wipe the area with a cloth and then wash thoroughly with

running water and soap.

hIf liquid crystal gets into your eye

Flush the affected eye with clean water for at least

15 minutes and then seek medical assistance.

hIf liquid crystal is swallowed

Flush your mouth thoroughly with water. Drink large

quantities of water and induce vomiting. Then seek

medical assistance.

■Notes on Electrical Interference

If the camera is to be used in hospitals or aircrafts, please

note that this camera may cause interference to other

equipment in the hospital or aircraft. For details, please

check with the applicable regulations.

■Handling Your Digital Camera

This camera contains precision electronic components. To

ensure that images are recorded correctly, do not subject

the camera to impact or shock while an image is being

recorded.

■Trademark Information

hiMac and Macintosh are registered trademarks of Apple

Computer, Inc.

hWindows is a registered trademark of the Microsoft

Corporation of the U.S. registered in the U.S.A. and other

countries. Windows is an abbreviated term referring to the

Microsoft Windows Operating System.

hSmartMedia is a trademark of Toshiba Corporation.

hOther company or product names are trademarks or

registered trademarks of the respective companies.

Trademark Information.

Preface

MENU/OK button

button

Viewfinder(EVF)(P.20)

Indicator lamp(P.24)

EVF/LCD button(P.20)

LCD monitor

(P.20)

Tripod mount

DISP button(P.29,32)

BACK button

Strap mount

Battery cover(P.13)

( ) ( ) bar

Nomenclature ✽Refer to the pages in parentheses for information on using the camera features.

Self-timer

lamp(P.43)

Flash control

sensor

Flash(P.38)

(USB)socket

(P.68,70)

DC IN 5V(Power input)

socket (P.19)

Shutter button

Strap mount

POWER button(P.16)

Slot cover

SmartMedia slot

Microphone

Speaker

Lens

Movie mode(P.49)

Still image mode(P.20)

Playback mode(P.30)

Mode switch

You can use the “SET–UP” menu on this

camera to select “ENGLISH” or “FRANCAIS” as

the “LANGUAGE” used for screen display

(➡P.62, 63). The screens in this manual are

shown in “ENGLISH”.

1Pull the lens cap cord through the strap

mount.

2Fit and remove the lens cap by squeezing the

left and right sides of the cap.

Nomenclature

Example of screen Text Display:Still image

Playback frame number

Photography mode

Flash

Date

Zoom bar

Battery low warning

Playback mode

DPOF

Example of screen Text Display:Playback

White balance

Macro

Battery low warning

Number of remaining shots

File size/Image quality

Camera shake warning

AF Warning

AF frame

1Getting Ready PREFACE

Attaching the Lens Cap and Shoulder Strap

Selecting the Language

●

Attach the lens cap cord to avoid losing the lens cap.

10102

LOADING THE BATTERIES

Compatible batteries

●

Do not apply excessive force to the battery cover.

●

Take care not to drop the batteries when you open or

close the battery cover.

●

The settings are retained for approximately 60 minutes after

the batteries are removed. To keep the current settings,

ensure that the new batteries are fitted within 60 minutes.

●

You should carry a spare set of batteries (sold

separately) when taking pictures.

Use AA-size alkaline batteries (4 pcs.) or AA-size

nickel-metal hydride (Ni-MH) batteries (4 pcs.).

1Slide the battery cover out and lift it open.

2Insert the batteries correctly as indicated by the

polarity icons.

3Close the battery cover.

◆Notes on Handling Batteries ◆

hDo not use different types of batteries or old

and new batteries together.

hThe operating lives of alkaline batteries vary

between brands and the life of the batteries

may be shorter than the alkaline batteries

provided with the camera. Note also that due to

the nature of alkaline batteries, the time for

which they can be used is shorter in cold

locations (at temperatures of +10°C or below),

so the use of Ni-MH batteries is recommended.

hSoiling (fingerprints, etc) on the terminals of

batteries can greatly reduce the time for

which the batteries provide power.

hYou will need the optional battery charger

(➡P.75) to recharge Ni-MH batteries.

hSee P.78 for notes on using batteries.

PREFACE

To prevent the lens cap from appearing in the

shot when you take pictures, attach the lens cap

to the shoulder strap.

Attach the Lens Cap

●

Failure to attach the shoulder strap correctly can

result in the camera being dropped.

Attach the shoulder strap to the strap mounts on

the camera. Once you have attached both ends

of the strap, check carefully to ensure that the

strap is firmly secured.

✽You cannot use lithium, manganese or nickel-

cadmium (Ni-Cd) batteries.

REMOVING THE SmartMedia™

Grip the SmartMedia and pull it out.

1Check that the indicator lamp is green and

then switch the camera off.

2Open the slot cover in the direction indicated

by the arrow.

Never open the slot cover while the camera is

still switched on as this could corrupt the image

files on the SmartMedia or damage the

SmartMedia itself.

●

To protect the SmartMedia, always store it in the

special anti-static case.

101

hSee P.58, 74 for information on printing

images.

hSee P.67 – 73 for information on downloading

images to a PC.

◆Printing Images and Downloading

Images to a PC ◆

Gold marking

LOADING THE SmartMedia™

SmartMedia™(sold separately)

1Check that the camera is switched off (➡P.16)

and then open the slot cover in the direction

indicated by the arrow.

2Push the SmartMedia firmly into the

SmartMedia slot as far as it will go.

3Close the slot cover.

●

If you open the slot cover while the camera is still

switched on, the camera is automatically switched off to

protect the SmartMedia.

●

The SmartMedia will not slide fully into the slot if it is

inserted facing the wrong way. Be careful not to apply

undue force to the SmartMedia.

■Only use 3.3V SmartMedia

MG-4S ( 4MB), MG-16SW ( 16MB, ID)

MG-8S ( 8MB), MG-32SW ( 32MB, ID)

MG-16S (16MB), MG-64SW ( 64MB, ID)

MG-32S (32MB), MG-128SW (128MB, ID)

MG-64S (64MB)

●

Image files cannot be recorded or erased if a write-

protect sticker is affixed to the SmartMedia.

●

Operation of this camera is only guaranteed when it

is used with FUJIFILM SmartMedia.

●

Some 3.3V SmartMedia are labelled as “3V” or ID”

cards.

●

See P.81 for more information on SmartMedia.

0301

SETTING THE DATE AND TIME

1Press the “MENU/OK” button to display the

menu screen.

2Use “g” or “a([) b(])” to select

“SET–UP” from the “dOPTION” menu.

3Press the “MENU/OK” button.

1The “SET–UP” menu appears. Use “a([)”

or “b(])” to select “DATE/TIME”.

2Press “c”.

●

See P.62 for more information on the “dOPTION”

menu.

●

Change the batteries within approximately 60

minutes. The camera settings are only retained for

approximately 60 minutes once the batteries are

removed.

0102

21 0301

Blank

On Blinking

To switch the camera on and off, press the

“POWER” button. When you switch the camera on,

the indicator lamp turns green. If the date has been

cleared, a confirmation message appears.

In Still Image mode or Movie mode, the confirmation

message appears in the viewfinder (EVF). In

Playback mode, the message appears on the LCD

monitor.

H: The DATE/TIME setting menu appears (➡P.18).

J: The camera remains in Still image, Movie

or playback mode.

Switch the camera on and check the batteries

charge indicator.

1Batteries have ample charge (No indicator

displayed).

2The batteries charge is low. Have a new set of

batteries ready.

3The batteries are exhausted. The display will

shortly go blank and the camera will stop

working. Replace or recharge the batteries.

●

If you do not set the date and time, this confirmation

message will appear each time you switch the

camera on.

●

Take care not to touch the lens when you switch the

camera on.

SWITCHING ON AND OFF

◆Auto Power Off function ◆

If the camera is not used in any way for 2

minutes, the Auto Power Off function

automatically switches the camera off.

However, this function does not operate when

you are using a USB connection.

If the date was cleared and you selected “H”,

proceed from step (➡P.18).

DC IN 5V Socket

●

See P.80 for notes on using the AC power adapter.

●

Only connect or disconnect the AC power adapter

when the camera is switched off.

Connecting or disconnecting the AC power adapter

while the camera is switched on temporarily

interrupts the power supply to the camera, so that

images or movies being shot at the time are not

recorded. Failing to switch the camera off first can

also result in damage to the SmartMedia or

malfunctions during PC connection.

●

Install the equipment near a socket outlet for easy

accessibility.

●

The shapes of the AC power adapter, the plug and

socket-outlet depend on the country.

USING THE OPTIONAL AC POWER ADAPTER

AC power adapter (optional)

Always use a FUJIFILM AC Power Adapter AC-5V.

Use the AC power adapter in situations when a loss

of power will cause problems, such as during file

downloading (via the USB connection). Using the

AC power adapter also allows you to take pictures

and play back images without worrying about

depleting the batteries.

hCompatible AC power adapters

Model: AC-5VH/AC-5VHS Check that the camera is switched off. Plug the

AC power adapter connector into the “DC IN 5V”

socket and then plug the AC power adapter into

the power outlet.

Connecting the AC power adapter does not

allow you to charge the Ni-MH batteries. Use the

optional battery charger (➡P.75) to charge the

Ni-MH batteries.

1Use “d” or “c” to select the desired item and then

use “a([)”and “b(])”to correct the setting.

2When you have finished setting the date and time,

press the “MENU/OK” button to confirm the setting.

The “SET–UP” menu reappears. Press the

“MENU/OK” button to complete the settings.

●

If you hold down “a([)” or “b(])”, the numbers

change continuously.

●

When the time displayed passes “12:00:00”, the

AM/PM setting automatically switches.

●

You cannot set the seconds. To set the time

precisely, press the “MENU/OK” button when the

time signal reaches zero.

SETTING THE DATE AND TIME

0102

3 44

AC-5VH

If the date was cleared and you selected “H”,

the camera switches to photography or playback

mode without returning to the “SET–UP” menu.

Be careful to ensure that the lens, flash,

microphone and flash control sensor are not

obscured by your hands or the shoulder strap.

Put your arm through the shoulder strap so that

the strap is looped around your shoulder. Hold

the camera grip with your right hand and use

your left hand to support the camera (lens)

securely.

●

The camera may not be able to take successful

pictures if your fingers or the strap are in the way.

●

Check that the lens is clean. If it is dirty, clean the

lens as described on P.77.

●

The image will be blurred if the camera moves when

taking the picture (camera shake). When shooting in

low-light conditions, use the flash (➡P.38) or a tripod

to prevent blurred images due to camera shake.

●

You can specify individually whether the viewfinder

(EVF) or the LCD monitor is used in the Still Image,

Movie and Playback modes.

●

Take care not to press on the lens with your fingers

when the lens extends or when you are taking

pictures as this could cause a camera fault.

●

For subjects closer than 80 cm (2.6 ft.), use Macro

photography (➡P.41).

●

If “∞”, “–”or

“§” is displayed, first wipe the contact

surface on the SmartMedia (gold-colored area)

thoroughly with a soft, dry cloth and then reload the

SmartMedia.

Immediately after you select Photography mode,

the viewfinder (EVF) switches on. You can

choose whether to use the viewfinder (EVF) or

the LCD monitor to take pictures by pressing the

“EVF/LCD” button to switch between the two.

Set the Mode switch to “q”.

hFocal range: Approx. 80 cm (2.6 ft.) to infinity

2Basic

Photography q

TAKING PICTURES (AUTO MODE)

STILL IMAGE MODE

1 2 3

Mode

Still image mode

Movie mode

3Play back mode

Default setting

EVF

LCD monitor

EVF

After switching

✽ The selection reverts to the default setting when you

switch the camera off.

To take the picture, press the shutter button

down fully without lifting your finger off it. The

camera beeps and takes the picture, and the

data is then recorded.

●

When you press the shutter button, there is a very

short delay before the picture is actually taken.

●

Since the amount of image data recorded is not fixed

and varies depending on the subject (level of image

detail, etc.), the number of available shots may not

decrease after the image is recorded, or may

decrease by 2.

●

See P.83 – 85 for information on the warning displays.

Beep

Press the shutter button down halfway. The

camera is focused when the AF frame on the

screen shrinks and the green indicator lamp

stops blinking and stays lit.

Frame the shot so that the subject fills the entire

AF (Auto Focus) frame.

●

If you press the shutter button down fully in one

motion, the shot is taken without the AF frame

changing.

●

The indicator lamp flashes orange while the flash is

charging. The screen may go dark for a moment.

This is normal and does not indicate a fault.

●

The flash charging time may increase when the

battery charge gets ting lower.

●

In some conditions it may be difficult to see your

subject clearly on the screen (Such as in sunny

weather outdoors.). In such situations, use the

electronic viewfinder to take the shot.

●

If the subject is not in the AF frame, use AE/AF lock

to take the picture (➡P.26).

●

When you press the shutter button down halfway,

the video image on the screen freezes briefly.

However, this is not the image that is recorded.

●

If the shot is too dark to focus, try standing about 2

m (6.6 ft.) from your subject to take the picture.

The indicator lamp turns orange during image

recording and no further shots can be taken. Do

not switch the camera off or open the slot cover

during image recording as this could corrupt the

image files.

To zoom in on the subject, press “[” (TELE).

To zoom out, press “]” (WIDE). A “Zoom bar”

appears on the screen when you zoom in or out.

●Optical zoom focal distance (35mm camera

equivalent)

Approx. 38 mm to 228 mm

Maximum zoom scale: 6×

●

Zooming stops briefly when the camera switches

between optical zoom and digital zoom (➡P.28).

qTAKING PICTURES (AUTO MODE)

STILL IMAGE MODE

Zoom bar

Number of Available Shots

■Standard number of shots per SmartMedia™

The number of shots that can be recorded onto a SmartMedia card varies slightly depending on the type of

subject. Also, the difference between the standard number of shots and the actual number of available shots

increases for SmartMedia with a higher capacity.

The number of available shots appears on the

screen.

●

See P.64 for information on changing the File Size

(Image Size) and Quality setting.

●

At shipment, the default settings are “9” (file size)

and “N : NORMAL” (quality).

✽ The numbers of available shots are shown for formatted SmartMedia.

4MB (MG-4S)

8MB (MG-8S)

16MB (MG-16S/SW)

32MB (MG-32S/SW)

64MB (MG-64S/SW)

128MB (MG-128SW)

File Size

Quality

Image Data Size

81600 ✕1200

FINE

Approx.770KB Approx.390KB Approx.200KB Approx.620KB

49196

10 19 39 12

101

204

20 39 75

41 79 152

166

159

319

306

613

NORMAL BASIC FINE

Approx.320KB

198

398

NORMAL

Approx.130KB

122

247

497

997

NORMAL

91280 ✕960 0

640 ✕480

Color Status Meaning

■Indicator Lamp Display

Green

Lit

Blinking

Orange

Lit

Blinking

Red Blinking

Ready to shoot.

AF/AE in progress or camera

shake/AF warning.

Recording to the SmartMedia

(the next picture can be taken).

Flash charging.

hSmartMedia warning.

No SmartMedia loaded,

SmartMedia not formatted,

incorrect format, write-protect

sticker used, SmartMedia full,

SmartMedia error.

hLens operation error.

Image being recorded onto the

SmartMedia (the next picture

cannot be taken).

◆

Subjects Not Suitable for Autofocus

◆

✽ Detailed warning messages are displayed on the

screen (➡P.83).

Though the FinePix2800 ZOOM uses an accurate

autofocus mechanism, it may have difficulty

focusing or not be able to focus at all for the types

of subject and situation listed below. In such

cases, the image may be out of focus.

hVery shiny subjects such as a mirror or car body.

hSubjects photographed through glass.

hSubjects that do not reflect well, such as hair

or fur.

hSubjects with no substance, such as smoke or

flames.

hWhen the subject is distant and dark.

hWhen there is very little contrast between the

subject and the background (such as white

walls or subjects dressed in the same color as

the background).

hWhen a subject other than your main subject

is close to the AF frame, has good contrast

and is in front of or behind your main subject

(such as a strongly contrasting person

standing out against the background).

hSubjects moving at high speed.

In situations of this sort, use the AF/AE lock

(➡P.26).

qTAKING PICTURES (AUTO MODE)

STILL IMAGE MODE

Without moving the camera, press the shutter

button down halfway (AF/AE lock). Check that

the AF frame on the screen has shrunk and the

green indicator lamp has stopped flashing and is

now lit.

Continue to hold the shutter button down

halfway. Move the camera back to the original

image and then fully press down on the shutter

button.

●

You can reapply the AF/AE lock as many times as

you like before releasing the shutter.

●

The AF/AE lock operates in all photography modes

and can be used to ensure excellent results.

Beep

In a shot with this type of composition, the

subjects (two people in this case) are not in the

AF frame. If the shot is taken at this point, the

subjects will not be in focus.

Move the camera slightly so that one of the

subjects in the AF frame.

1 2

USING AF/AE LOCK

◆AF (Autofocus)/AE (Auto exposure) Lock ◆

On the FinePix2800 ZOOM, when you press the shutter button down half way, the focus and exposure

settings are fixed (AF/AE lock). If you want to focus on a subject that is off to one side of the image or if

you want to set the exposure before you compose the final shot, lock the AF and AE settings and then

compose and shoot your picture to get the best results.

Text displayed

Framing Guideline displayed

No text displayed

You can select the Framing Guideline function in

the “q” still image mode. The screen display

changes each time you press the “DISP” button.

Press the “DISP” button until “Framing

Guideline” appears.

●

The framing guideline is not recorded on the image.

●

The lines in the scene frame roughly divide the

recorded pixels into three equal parts horizontally and

vertically. When the image is printed, the resulting

print may be shifted slightly from the scene frame.

FRAMING GUIDELINE FUNCTION

Scene

Use this frame when you want to position your

main subject in the center of the frame or when

you want to align your shot with the horizon.

This feature allows you to compose a shot that

captures the moment while focusing on the

subject size and the overall balance of the

shot.

Always use the AF/AE lock to compose your

picture.

Failing to use the AF/AE lock may result in the

image being out of focus.

◆Important ◆

If the file size (image size) setting is “9” or

“0”, you can use the digital zoom.

hDigital zoom focal distance (35 mm camera

equivalent)

9: Equivalent to approx. 228 mm – 285 mm

(Max. zoom scale 1.25×)

0: Equivalent to approx. 228 mm – 570 mm

(Max. zoom scale 2.5×)

Movie: Equivalent to approx. 38 mm – 95 mm

(Max. zoom scale 2.5×)

●

You cannot use the digital zoom for resolutions of

“8”.

●

See P.64 for information on changing the file size

setting.

●

If the image goes out of focus when you use the

zoom, press the shutter button down halfway to

refocus.

●

The optical zoom is equivalent to approximately

38 mm – 228 mm on a 35 mm camera.

The “

■

” on the zoom bar shows you the zoom

mode.

hIf the “

■

” is above the dividing line, the digital

zoom is being used. If it is below the line, the

optical zoom is being used.

hPress “[” or “]” to move the “

■

”.

hWhen you switch between digital zoom and

optical zoom, the “

■

” stops moving. When you

press the same button again, it starts moving

again and the zoom mode switches.

Optical zoom

Digital zoom

Zoom bar display

Movie

DIGITAL ZOOM

Pressing

“a([)”

“b(])”

during single-frame

playback zooms in (enlarges) or out on a still image.

When you use this function, a zoom bar is displayed.

hZoom scales:

1600 ×1200 pixel images: Max. zoom scale 5×

1280 ×960 pixel images: Max. zoom scale 4×

640 ×480 pixel images: Max. zoom scale 2×

After you have zoomed in on your image,

1Press the “DISP” button.

2Use “a([) b(]) g” to zoom in on different

parts of the image.

3Press the “DISP” button again to revert to

zoomed display.

●

Pressing “d” or “c” during zooming cancels

zooming and moves to the next image.

●

Press the “BACK” button to revert to the normal image

display scale.

●

You may not be able to use playback zoom for some

images shot on other camera models.

PLAYBACK ZOOM

This is useful for such things as checking the focus

after you take a shot.

Normal playback

No text displayed

Multi-frame playback

FRAME NO.

DPOF

If you have specified DPOF settings (➡P.58), the

“f” icon is displayed. The screen changes each

time you press the “DISP” button.

●

See P.65 for more information on adjusting the

brightness of the screen.

1Set the Mode switch to “3”.

2You can use “c” and “d” to move forward

and backward respectively through your

images.

●

When you set the Mode switch to “3”, the last

image shot is displayed.

You can use this camera to view (excluding some uncompressed data) images recorded on a

FinePix2800 ZOOM or images recorded onto a 3.3V SmartMedia using a FUJIFILM FinePix series, MX

series or DX series digital camera.

◆Images That Can be Viewed on the FinePix2800 ZOOM ◆

3VIEWING YOUR IMAGES (PLAYBACK)

PLAYBACK MODE

1 1

Zoom bar

203020101

ERASING SINGLE FRAME

1Set the Mode switch to “3”.

2Press the “MENU/OK” button to display the

Menu on the screen.

Select “FRAME” in the “gERASE” menu and

press the “MENU/OK” button.

●

See P.56 for more details of the “gERASE” menu.

1 2

0102

MULTI-FRAME PLAYBACK

●

You cannot use multi-frame playback while a menu

is displayed.

●

Playback zoom cannot be used with multi-frame

playback.

Pressing the “DISP” button during playback

switches the screen to the next display mode.

Press the “DISP” button several times to select

multi-frame (9 frames) playback.

You cannot display text during multi-frame

playback.

1Select a frame by using “a([) b(]) g”

to move the cursor (the orange box) to the

desired frame. Press “a([)”or “b(])”

several times to switch to the previous page or

the next page.

2Press the “DISP” button to view the currently

selected image at full size.

Normal playback

No text displayed

Multi-frame playback

1 2 0102

3534

The Advanced Features Photography section introduces a range of camera functions that you can

access by setting the Mode switch to “q” or “e”.

ADVANCED FEATURES PHOTOGRAPHY

Advanced Features

Photography

ERASING SINGLE FRAME

Press “d” or “c” to display the image to be

erased.

Press the “MENU/OK” button to erase the

displayed image. When erasing is complete, the

next image appears and the “¨”

message is displayed.

●

Press the “BACK” button to cancel frame erasing.

●

“¢” is displayed for frames with DPOF

settings and they cannot be erased (➡P.85).

●

If the “™” message appears, you

cannot erase the frame. Use the camera on which

the frame was protected to unprotect the frame.

To continue erasing images, repeat the

procedure from step .

qStill image

1Auto (➡P.36)

This is the easiest mode

for taking pictures and can

be used in a wide range of

conditions.

AUTO

OFF

eMovie (Video) —

eMovie (➡P.49)

In this mode, you can shoot

up to 60 seconds of video

at a time.

Mode swich Factory

default

Shared menu

settings

dOPTION

✽See P.62 for

more infor-

mation on

each of the

settings.

yFlash (➡P.38)

5Macro (➡P.41)

lSelf-timer (➡P.42)

7Voice captioning (➡P.44)

2Manual (➡P.36)

This mode allows you to

specify the “EV” and “WHITE

BALANCE” settings.

AUTO

OFF

AUTO

yFlash (➡P.38)

5Macro (➡P.41)

aEV (➡P.46)

sWhite Balance

(Selecting the light source)(➡P.47)

—

OFF

6Continuos shooting

(➡P.48)

This mode allows you to

take up to 4 shots in rapid

succession.

5Macro (➡P.41)

lSelf-timer (➡P.42)

Photography mode

■Photography Mode Specifications

Accessible menu settings

PHOTOGRAPHY MENU OPERATION

PHOTOGRAPHY MENU

1Press the “MENU/OK” button to display the

menu.

2Use “d” and “c” to select the menu item and

“a([)” and “b(])” to change the setting.

Press the “MENU/OK” button to confirm the

selection.

When you validate the settings, the respective

icons appear at the top of the screen.

●

The settings available in the menu screen differ

depending on the still image mode. See P.35 for

details.

1 2

0102

Settings icons

1Set the Mode switch to “q”.

2Press the “MENU/OK” button to display the

menu on the screen.

This is the easiest mode for taking pictures and

can be used in a wide range of conditions.

This mode allows you to set the “EV” and

“WHITE BALANCE” settings.

1Use “a([)”, “b(])”, “d” and “c” to select

“qAUTO”, “qMANUAL” and “6CONT.”

from the “dOPTION” menu.

2Press the “MENU/OK” button to confirm the

selection.

qAUTO

qMANUAL

In this mode, the camera shoots up to 4

continuous frames at intervals as short as 0.5

seconds.

6CONT.

1 2

01020102

●

See P.62 – 65 for more information on the

“QUALITY”, “SET–UP”, “LCD BRIGHTNESS”,

“VOLUME” settings.

SELECTING PHOTOGRAPHY MENU (1/2/6)

STILL IMAGE MODE

:Red-Eye Reduction

Use this mode to ensure that the subject’s eyes

appear natural when photographing people in

low-light conditions. The flash fires automatically

as required by the photography conditions.

The flash fires a pre-flash just before the picture

is taken and then fires again to take the actual

picture.

yForced Flash

Use this mode to photograph backlit scenes,

such as a subject against a window or in the

shade of a tree, or to obtain the correct colors

when you are shooting under lighting such as

fluorescent tubes. In this mode, the flash fires in

bright as well as dark conditions.

◆Red-Eye Effect ◆

When you use the flash to photograph people in low-light conditions, their eyes sometimes appear red in

the picture. This is caused by the light of the flash reflecting off the inside of the eye. Use Red-Eye

Reduction flash to effectively minimize the likelihood of the red-eye effect.

Take the following measures also to make Red-Eye Reduction more effective :

●Get the subjects to look at the camera. ●Get as close as possible to the subjects.

yFLASH

PHOTOGRAPHY MENU

This mode can be selected in the “1”,“2” still

image modes.

Use the flash mode that best suits your shot.

h5 modes: “

AUTO

, :, y, uand ;”

hEffective flash range (in “qAUTO” mode):

Wide-angle: Approx. 0.3 m to 3.5 m

(1.0 ft. to 11.5 ft.)

Telephoto : Approx. 0.8 m to 3.5 m

(2.6 ft. to 11.5 ft.)

●

The flash charging time may increase if the charge

remaining in the batteries is low.

●

When you take a shot using the flash, you may see

the video image disappear and the screen go dark

as the flash charges. The indicator lamp blinks

orange while the flash is charging.

●

If you use the flash in very dusty environments,

floating dust particles may appear as glowing white

dots on your image.

Use this mode for ordinary photography. The

flash fires automatically as required by the

shooting conditions.

AUTO

Auto Flash Mode

You can select Macro mode in the “1”, “2”

and “6” still image modes. Use Macro mode for

close-up shots.

hFocal range:

Approx. 10 cm/3.9 in. to 80 cm/2.6 ft.

(With flash:

Approx. 30 cm/11.8 in. to 80 cm/2.6 ft.)

●Digital zoom focal distance (35 mm camera

equivalent)

9: Equivalent to approx. 38 mm – 48 mm

(Max. zoom scale 1.25×)

0: Equivalent to approx. 38 mm – 95 mm

(Max. zoom scale 2.5×)

Selecting Macro mode specifies the following

camera settings:

hThe lens is fixed to the wide-angle zoom

setting and only digital zooming is available.

hSwitching the camera off cancels Macro

mode.

5MACRO (CLOSE-UP)PHOTOGRAPHY

PHOTOGRAPHY MENU

●

If you are shooting in dark conditions, use a tripod to

prevent camera shake.

●

If you use the flash to take a picture at distances of

less than 30 cm, the shadow of the lens may intrude

into the image.

This is a flash mode that uses a slow shutter

speed. This allows you to take pictures of people

at night that clearly show both your subjects and

the night time backdrop.

;Slow Synchro

●

The image may be overexposed when you shoot

bright scenes.

●

Because a slow shutter speed is used, a tripod

should be used to prevent camera shake.

yFLASH

PHOTOGRAPHY MENU

uSuppressed Flash

Use this mode for photography using indoor

lighting, for shots taken through glass, and for

photography in venues such as theaters or at

indoor sporting events where the distance is too

great for the flash to be effective. When you use

Suppressed Flash, the Automatic White Balance

function (➡P.89) operates so that natural colors

are captured along with the ambience of the

available light.

●

If you are shooting in Suppressed Flash mode in dark

conditions, use a tripod to prevent camera shake.

●

See P.24, 84 for information on the camera shake

warning.

The self-timer lamp lights steadily for 5 seconds,

blinks for another 5 seconds and then takes the

shot.

The screen counts down the time until the shot

is taken.

Self-timer mode is automatically cancelled after

each shot.

●

To stop the self-timer once it has started running,

press the “BACK” button.

Beep

oSELF-TIMER PHOTOGRAPHY

PHOTOGRAPHY MENU

This mode can be selected in the “1”, “6” still

image modes.

In this mode, a timer runs for roughly 10

seconds before the shutter is released. Use this

mode for shots such as photographs of yourself.

Locate the subject in the screen and frame the

shot. Then press the shutter button to trigger the

self-timer.

●

You can also use the AF/AE lock (➡P.26).

●

Do not stand in front of the camera when you press

the shutter button as this will result in an incorrect

brightness (exposure) setting for the shot.

●

The self-timer is automatically cancelled in the

following situations:

iWhen you take a picture.

iWhen you switch between still image modes and

playback mode.

iWhen the camera is switched off.

1Press the “MENU/OK” button to start

recording the voice captioning.

2During audio recording, the remaining time is

shown on the screen and the self-timer lamp

blinks.

Face the microphone (➡P.8) on the front of the

camera to record your comment. Hold the camera

roughly 20 cm (7.8 in.) away for the best results.

When you have recorded 30 seconds of sound, the

“ø” message appears on the screen.

To finish: Press the “MENU/OK” button.

To re-record your comment: Press the “BACK”

button.

●

To end your comment during recording, press the

“MENU/OK” button.

●

The sound recording time may be shorter than

30 seconds depending on the available space on the

SmartMedia.

●

If you do not want to record a voice captioning, press

the “BACK” button. Note that the image will still be

recorded.

This function can be selected in the “1” still

image mode.

Voice Captioning allows you to record a voice

captioning (comment) up to 30 seconds long for

an image immediately after you take the shot.

●Recording format: WAVE

Audio file size: Approx. 240 KB

(for a 30 seconds voice captioning)

Take a picture as normal. The “º”

message then appears on the screen.

7VOICE CAPTIONING

PHOTOGRAPHY MENU

AUTO: Automatic adjustment

(Shooting to show the ambience of the

light source)

c: Shooting outdoors in fine weather

x: Shooting in shade

b: Shooting under “Daylight” fluorescent

lamps

n: Shooting under “Warm White” fluorescent

lamps

m: Shooting under “Cool White” fluorescent

lamps

z: Shooting in incandescent light

✽ Because the white balance setting is disabled during

flash photography, use “Suppressed Flash” mode

(➡P.40) if you want to achieve a particular effect in

your shot.

This mode can be selected in the “2” still

image mode.

In Auto mode, the correct white balance may not

be obtained for subjects such as close-ups of

people’s faces and shots taken under a special

light source.

Change the white balance setting when you

want to take a picture with the correct balance.

See P.89 for more information on the white

balance.

This mode can be selected in the “2” still

image mode.

Use the Brightness setting to obtain the optimum

image brightness (exposure) when the subject is

much brighter or darker than the background.

hCorrection range: 11 steps

(–1.5 EV to +1.5 EV in 0.3 EV increments)

See P.89 for information on EV.

●

The Brightness setting is disabled in the following

situations:

iWhen the flash is used in Auto or Red-Eye

Reduction mode.

iWhen dark scenes are shot in Forced Flash mode.

hCopying of printed text (black characters on

white paper) (+1.5 EV)

hBacklit portraits (+0.6 EV to +1.5 EV)

hVery bright scenes (such as snowfields) and

highly reflective subjects (+0.9 EV)

hShots made up predominantly of sky

(+0.9 EV)

hSpotlit subjects, particularly against dark

backgrounds (–0.6 EV)

hCopying of printed text (white characters on

black paper) (–0.6 EV)

hScenes with low reflectivity, such as shots of

pine trees or dark foliage (–0.6 EV)

Guide to using + (positive) compensation

Guide to using – (negative) compensation

◆

Subjects for Which Exposure

Adjustment is Particularly Effective

◆

aEV (EXPOSURE COMPENSATION)

PHOTOGRAPHY MENU

WHITE BALANCE (SELECTING THE LIGHT SOURCE)

PHOTOGRAPHY MENU

eMOVIE

MOVIE MODE

●

Because the audio is recorded as you shoot, take care

not to cover the microphone with your finger (➡P.8).

●

The shooting time per shot may be shorter than 60

seconds depending on the available space on the

SmartMedia.

●

In some cases, movies shot on the FinePix2800

ZOOM may not be playable on other camera

models.

The available shooting time and the “£”

message are shown on the screen.

Set the Mode switch to “e”.

This mode allows you to shoot up to 60 seconds

of movie at a time.

hMovie format: Motion JPEG (➡P.89)

320 ×240 pixels

10 frames per second

With sound

eMovie

Available shooting time

■SmartMedia standard shooting time

✽ These movie shooting times are for newly formatted

SmartMedia.

SmartMedia capacity

MG-4S (4MB) Approx. 23 sec.

MG-8S (8MB) Approx. 47 sec.

MG-16S/SW (16MB) Approx. 94 sec.

MG-32S/SW (32MB) Approx. 191 sec.

MG-64S/SW (64MB) Approx. 385 sec.

MG-128SW (128MB) Approx. 774 sec.

●

The screen may go dark during shooting. This is

normal and does not indicate a fault.

●

You cannot use the flash in this mode.

●

The continuous photography speed is the same

regardless of the quality and file size settings.

When you finish shooting, the photographed

images are displayed in order and automatically

saved.

●

The focus and exposure are determined for the first

frame and cannot be changed during shooting.

●

The time required to store file is approximately 5

seconds in “8•NORMAL” mode (for 4 frames

continuous shooting).

In this mode, the camera shoots up to 4

continuous frames at intervals as short as 0.5

seconds.

Shots are taken continuously while you hold the

shutter button down fully. If you release the

shutter button before shooting is completed,

between 1 and 3 consecutive shots will be

taken.

6CONT.

6CONTINUOUS SHOOTING

PHOTOGRAPHY MENU

●

Once the remaining time runs out, movie recording

automatically stops and the movie is stored on the

SmartMedia.

During shooting, “hREC” appears on the screen

with a counter showing the remaining time

displayed in the top-right corner.

●

The time required to store a 60 seconds movie

(roughly 9 MB) is approximately 9 seconds.

●

If you start shooting and then immediately end

shooting, only 3 seconds of movie is recorded onto

the SmartMedia.

If you press the shutter button during shooting,

shooting ends and the movie is stored on the

SmartMedia.

eMOVIE

MOVIE MODE

In Movie mode, the lens is locked at the wide-

angle setting and only the digital zoom can be

used. You can use “a([)” and “b(])” to

zoom in and out. A “zoom bar” is displayed on

the screen.

hDigital zoom focus distance (35 mm camera

equivalent)

Approx. 38 mm to 95 mm

Max. zoom scale: 2.5×

●

When you press the shutter button, there is a very

short delay before actual shooting begins.

●

You do not need to hold down the shutter button.

●

The focus is fixed 80 cm (2.6 ft.) to infinity.

●

The white balance is fixed during shooting, but the

exposure varies automatically to suit the scene being

shot.

Shooting begins when you fully depress the

shutter button.

The white balance is automatically set when you

press the shutter button down fully.

Zoom bar

◆Compatible Movie Files ◆

The movie automatically stops when playback ends.

Playback

Control Description

Pauses the movie during playback.

Press this button again to resume playback.

Pause/Resume

Stops playback.

✽Press “d” or “c” while movie playback is stopped to go back

to the previous file or advance to the next file respectively.

Stop

Press these during playback to “c” skip forwards or “d”

backwards through the movie.

Fast forward/Rewind

iEach time you press “d” or “c” when the movie is paused,

the movie advances or goes back one frame.

iHold down the button to move through the frames quickly.

Skip playback

When paused

■Playing Back Movies

1Press “b(])” to play the movie.

2The screen shows the playback time and a

playback progress bar.

●

If the subject of the movie is very bright, white

streaks may appear on the image during playback.

This is normal and is not a fault.

●

Movies cannot be played back using multi-frame

playback. Use the “DISP” button to revert to normal

playback.

1Set the Mode switch to “3”.

2Use “d” or “c” to select the movie file.

Movies are displayed somewhat smaller than

still images.

PLAYING BACK MOVIES

Advanced

Features Playback

21 010102

The FinePix2800 ZOOM can play back movie files shot on a FinePix2800 ZOOM and movie files up to

60 seconds long that were shot on a FUJIFILM digital camera and stored on a 3.3V SmartMedia. If you

attempt to play back a movie that is longer than 60 seconds, the “•” message appears and

playback fails.

Rewind Forward

PLAYING BACK VOICE CAPTIONING

■Playing Back Voice Captioning

The voice captioning automatically stops when playback

ends.

Playback

Control Description

Pauses the voice during playback. Press this button again

to resume playback.

Pause/Resume

Stops playback.

✽Press “d” or “c” while voice captioning playback is

stopped to go back to the previous file or advance to the

next file respectively.

Stop

Press these during playback to skip forwards or backwards

through the voice captioning.

Fast forward/Rewind

●

You cannot play back voice captioning using multi-

frame playback. Use the “DISP” button to revert to

normal playback.

Use “d” or “c” to select an image file that has a

voice captioning.

The “7” icon is displayed.

1Press “b” (]) to play the voice captioning.

2The screen shows the playback time and a

playback progress bar.

●

Take care not to block the speaker.

●

If the sound is difficult to hear, adjust the volume

(➡P.63, 65).

◆Compatible Voice Captioning Files ◆

✽You cannot use skip playback for voice captions.

✽See P.67 for information on playing back voice captions on your PC.

Rewind Forward

The FinePix2800 ZOOM can play back voice captioning files recorded on an FinePix2800 ZOOM and voice

captioning files up to 30 seconds long recorded on a 3.3V SmartMedia using a FUJIFILM digital camera.

●

To cancel the frame erase procedure, press the

“BACK” button.

A confirmation message appears.

In “FRAME” mode, use “d” or “c” to select the

file and then press the “MENU/OK” button.

When using “ALL FRAMES” or “FORMAT”,

press the “MENU/OK” button.

Formatting erases all the data on the

SmartMedia, including protected files.

All files are erased except those that are

protected or that have DPOF settings. Copy any

files that you want to keep to your hard disk

beforehand.

Erase only the selected file.

●

The file for which “™” was displayed

cannot be erased. Unprotect the frame using the

camera on which the protection was first applied.

●

“¢” is displayed for frames with DPOF

settings and they cannot be erased (➡P.85).

●

Press the “BACK” button to exit the menu.

1Press the “MENU/OK” button to display the

menu.

2Use “d” or “c” to select “gERASE” and then

use “a([)” or “b(])” to select “FRAME”,

“ALL FRAMES” or “FORMAT”.

3Press the “MENU/OK” button.

FRAME

ALL FRAMES

FORMAT

Formatting erases all the files. Take particular

care when formatting a SmartMedia as this

procedure also erases all protected files and all

files with DPOF settings. Copy any files that you

want to keep to your hard disk beforehand.

010302

ERASING SINGLE •ALL FRAMES/FORMATTING

PLAYBACK MENU

●

If a “

∞

”, “

•

”

or “

–

”message appears, see P.83, 84.

This function allows you to select whether or not

the date of shooting is included on the print.

1Press the “MENU/OK” button to display the

menu on the screen.

2Use “d” or “c” to select “fDPOF”.

1Use “b” (]) to select “kDATE”.

2Use “d” or “c” to specify “DATE ON” or

“DATE OFF”. The selected setting is then valid

for all frames with DPOF settings until the

camera is switched off.

Then specify the DPOF settings (➡P.60).

●

You must specify whether or not the date is included

before you specify the DPOF settings.

●

The “DPOF” menu options do not appear when a

movie file is selected.

●

You may not be able to specify DPOF settings for

some still shots taken on other cameras.

1 2

01020102

DPOF stands for Digital Print Order Format and refers to a format that is used for

recording printing specifications for images shot using a digital camera on media such as

SmartMedia. The recorded specifications include information on which frames are to be

printed and how many prints of each frame are required.

This section gives a detailed description of how to order your prints with the FinePix2800

ZOOM. On the FinePix2800 ZOOM, you can specify only one print per image in the

DPOF settings.

✽ Note that some printers do not support date and time imprinting or specification of the

number of prints.

✽ Note that the warnings shown below may be displayed while you are specifying the

prints.

¢(➡P.85)

If the “¢” message appears, you cannot erase the frame. Cancel the “DPOF”

settings and then try again

ˆ(➡P.85)

No more than 1000 frames can be specified on the same SmartMedia.

fHOW TO SPECIFY PRINT OPTIONS (DPOF)

PLAYBACK MENU

fDPOF DATE SETTING

PLAYBACK MENU

1Use “d” or “c” to display the frame for which you

want to specify DPOF settings.

2Use “a([)” or “b(])” to select the setting for

the frame to be printed. If you have selected the

date setting, the “k” icon is displayed.

When you have finished specifying the DPOF

settings, always press the “MENU/OK” button to

confirm the settings.

If you press the “BACK” button, no DPOF

settings are specified.

●

DPOF settings cannot be specified for movies.

●

Note that the “k” icon is not displayed during playback.

●

“TOTAL” shows the total number of frames for which

prints have been ordered.

●

You can only specify one print per frame in the

DPOF settings. Note also that you can specify prints

for up to 999 frames on the same SmartMedia.

To specify additional DPOF settings, repeat steps 01

and 02and select “SET” for the frames to be printed.

Pressing the “MENU/OK” button confirms all the

settings. You cannot reset a portion of the

settings without resetting them all.

0102

You can only specify one print per frame (image)

in the DPOF settings.

1Press the “MENU/OK” button to display the

menu.

2Use “d” or “c” to select “fDPOF”.

3With “EXECUTE” selected, press the

“MENU/OK” button.

1If you select a frame for which DPOF settings

have already been specified, the

“∑” message appears.

2Pressing the “MENU/OK” button erases all

the DPOF settings already specified. You

must then specify the DPOF settings again.

●

The DPOF menu options do not appear when a

movie file is selected.

●

You cannot specify printing for more than one print

per frame.

●

Press the “BACK” button to leave the previous

settings unchanged.

●

You can check the previous settings by playing back

the images (➡P.30).

01030201

fDPOF SET FRAME

PLAYBACK MENU

USING THE OPTION MENU

If you selected “SET–UP”, the “SET–UP” menu

appears.

1Use “a([)” or “b(])” to select the desired

setting.

2Use “d” or “c” to change the setting.

Press the “MENU/OK” button to exit “SET–UP”.

1Press the “MENU/OK” button to display the

menu screen.

2Use “d” or “c” to select “dOPTION” and “a

([)” or “b(])” to select the desired setting.

3Press the “MENU/OK” button to move to the

selected setting.

●

For “DATE/TIME” press “c”.

Using SET–UP

0302

0102

Photography Playback

POWER SAVE ON/OFF

This is a function that reduces power consumption to

prevent batteries depletion when the camera is not being

used. See P.66 for details.

OFF

SETTINGS

5Settings

The “Settings” chapter describes all at functions available from “dOPTION” in the “q” still

Image, “e” movie and “3” playback modes.

■List of Settings

■SET–UP Menu Options

qAUTO

qMANUAL

6CONT.

jQUALITY (P.64)

SET–UP

—

LCD BRIGHTNESS (P.65)

4Still Image mode

—

SET–UP

—

LCD BRIGHTNESS (P.65)

hMovie mode

—

SET–UP

VOLUME (P.65)

LCD BRIGHTNESS (P.65)

3Playback mode

Settings Display Explanation

USB MODE

DATE/TIME

DSC/PC CAM

SET

See P.67 for details.

You can use this to set the date and time. See P.17 for

details.

Factory

default

DSC

—

BEEP TLOW/HIGH/OFF This setting selects the volume of the beep emitted by the

camera during camera operation.

LOW

LANGUAGE

ENGLISH/FRANCAIS

Select English or French as the language used for screen

display.

ENGLISH

●

To exit this procedure without changing the settings,

press the “BACK” button.

●

Use “LCD BRIGHTNESS” to adjust the brightness of the screen

you are currently using. You can set separate brightness

settings for the LCD monitor and the electronic viewfinder.

iWhen you are using the LCD monitor →Adjust “LCD

BRIGHTNESS”.

iWhen you are using the electronic viewfinder →Adjust

“EVF BRIGHTNESS”.

When you select the “BRIGHTNESS” or “VOLUME”

menu option, an adjustment bar appears on the LCD

monitor or viewfinder (EVF).

1Use “d” and “c” to adjust the screen

brightness or speaker volume.

2Press the “MENU/OK” button to confirm the

new setting.

dLCD BRIGHTNESS/VOLUME

●

To exit this procedure without changing the settings,

press the “BACK” button.

1Use “a([)”or “b(])” to change the file

size setting and “d” or “c” to change the

quality setting.

2Press the “MENU/OK” button to confirm the

setting.

●

The number of available shots varies depending on

the combination of file size and quality settings you

select (➡P.25).

0102

You can choose any combination of 3 file sizes

and 3 image quality settings. Use the table below

as a guide to the best settings for your shots.

Select “FINE” for better image quality and

“BASIC” to increase the number of available

shots.

In most cases, the “NORMAL” setting provides

more than adequate image quality.

Quality (compression ratio)

!: For printing the whole image at A5 size or

printing a part of the image at A6 size

@: For printing at A6 size

#: For use via the Internet as an e-mail

attachment, etc.

BASICNORMALFINEFile size

8(1600 ×1200)

9(1280 ×960)

!!@

@@—

0(640 ×480) —#—

1 2 0102

SETTING THE FILE SIZE AND QUALITY (COMPRESSION RATIO)

DSC (Mass storage device)Mode

The first time you connect the camera to your computer

PC Connection describes how to set up a USB connection and provides an overview of the functions

available using a USB connection. Refer also to the Software Quick Start Guide booklet.

This mode provides a simple way to read

images from a SmartMedia and store images on

to a SmartMedia (➡P.68).

You must install all the software before

connecting the camera to your computer.

Refer to the Software Quick Start Guide booklet

also.

IN PC (PERSONAL COMPUTER)CONNECTION

PC Connection

POWER SAVE

SET–UP

Once you enable this function, the screen is

temporarily switched off to save power if you do

not use the camera for 30 seconds. Use this

function to gain the maximum possible run time

from your batteries.

●

The charging time for the flash increases slightly

because the flash charging power is reduced.

When the Power Save function is operating,

press the shutter button down halfway to return

the camera to the ready-to-shoot status. This is

a useful feature as it allows you to take pictures

more quickly than switching the camera off and

then on again.

●

When the Power Save function is operating,

pressing the shutter button down fully returns the

camera to the ready-to-shoot status and takes the

picture.

●

The camera does not automatically switch off when

a USB connection is being used.

●

Operation can also be restored by pressing buttons

other than the shutter button.

Though the Power Save function does not

operate while you are setting the file size or

when the camera is in SET–UP or Playback

mode, the camera still switches off automatically

if the camera controls are not used for 2

minutes.

PC-CAM (camera)Mode

This function allows you to conduct

videoconferencing sessions between PCs

connected to the Internet. This function can also

be used to record video on a PC (➡P.70).

●

Videoconferencing (“PictureHello”) is not

supported on Macintosh computers.

●

The PC Camera function cannot be used on Mac OS

X (including the Classic environment). Use a Mac

OS version between 8.6 and 9.2.

CD-ROM

(Software for FinePix) Software Quick Start Guide

●

Switch the camera off when you change the

SmartMedia (➡P.72).

●

Do not disconnect the USB cable when the camera

is communicating with the PC. See P.72 for

information on the disconnection procedure.

iThe indicator lamp alternately blinks green and

orange while the camera is communicating

with your PC.

i“DSC” appears on the screen.

iThe camera does not automatically switch off

when a USB connection is being used.

iFinePixViewer automatically starts up.

iA removable disk icon appears and you can

use your PC to transfer files to and from the

camera.

Camera Operation PC Operation

Windows Macintosh

✽

Screen for Windows 98 SE

If the above operations do not occur, you do not

have the required software programs or drivers

installed on your PC. Refer to the Software

Quick Start Guide booklet and complete the

required PC setup procedures. Then reconnect

the camera to your PC.

CONNECTING AT DSC MODE

(USB)

Socket PC

1Load a SmartMedia containing photographed

images into your camera.

2Press the “POWER” button to switch the

camera on.

3Set the “USB MODE” setting in the “SET–UP”

menu to “DSC” (➡P.62, 63).

4Press the “POWER” button to switch the

camera off.

1Switch your PC on.

2Use the special USB cable to connect the camera to

your PC.

3Switch the camera on.

1010402

Camera

(Special USB)

socket

(Special USB)

socket

DC IN 5V Socket

Always use the prescribed procedure when

disconnecting or switching off the camera (➡P.72).

On Windows PCs, if the “Add New Hardware”

wizard appears, close the wizard and switch off the

camera. You must install the software before

connecting the camera to your PC. (➡Software

Quick Start Guide booklet)

●

You should use the AC power adapter when the camera

is connected to your PC (➡P.19). Loss of power during

data transmission can prevent successful data

downloading.

●

On Windows XP and Mac OS X, you must specify the

automatic launch settings the first time you connect the

camera to your computer. (➡Software Quick Start Guide

booklet)

●

Take care to connect the plugs on the special USB cable

into the correct sockets, and ensure that the plugs are

inserted firmly.

●

Do not disconnect the USB cable when the camera

is communicating with the PC. See P.72 for

information on the disconnection procedure.

iThe indicator lamp alternately blinks green and

orange while the camera is communicating

with your PC.

iThe lens is fixed at the wide-angle zoom

setting.

i“PC CAM” appears on the screen.

iThe camera does not automatically switch off

when a USB connection is being used.

iFinePixViewer automatically starts up and the

Picture Hello window opens (Windows only).

You can use software

such as VideoImpression

to view live images.

Camera Operation PC Operation

✽Screen for Windows 98 SE

✽Screen for Macintosh

If the above operations do not occur, you do not

have the required software programs or drivers

installed on your PC. Refer to the Software

Quick Start Guide booklet and complete the

required PC setup procedures. Then reconnect

the camera to your PC.

CONNECTING AT PC-CAMERA MODE

(USB)

Socket PC

Camera

(Special USB)

socket

(Special USB)

socket

DC IN 5V Socket

1Remove the lens cap.

2Press the “POWER” button to switch the

camera on.

3Set the “USB MODE” setting in the “SET–UP”

menu to “PC CAM” (➡P.62, 63).

4Press the “POWER” button to switch the

camera off.

1Switch your PC on.

2Use the special USB cable to connect the camera to

your PC.

3Switch the camera on.

Always use the prescribed procedure when

disconnecting or switching off the camera (➡P.72).

●

You should use the AC power adapter when the camera

is connected to your PC (➡P.19). Loss of power during

data transmission can prevent successful data

downloading.

●

If you are using Windows XP, you must also refer to the

Software Quick Start Guide booklet.

●

Take care to connect the plugs on the special USB cable

into the correct sockets, and ensure that the plugs are

inserted firmly.

101

0204

On Windows PCs (excluding Windows XP), if the

“Add New Hardware” wizard appears, close the

wizard and switch off the camera. You must install

the software before connecting the camera to your

PC. (➡Software Quick Start Guide booklet)

1Switch the camera off.

2Unplug the special USB cable from the

camera.

Camera

(Special USB)

socket

(Special USB)

socket

DC IN 5V Socket

Macintosh

DISCONNECTING FROM THE PC (Important — always use this procedure.)

1Quit all applications (FinePixViewer,

VideoImpression, etc.) that are using the

camera.

2Check that the indicator lamp is glowing green

(that the camera is not communicating with

the PC).

Perform the steps shown below before you

switch the camera off. This procedure

differs depending on the operating system

software (or PC) you are using.

No PC operation is needed.

2Left-click the Eject icon in the taskbar and

eject “USB disk”.

●

Even after the “Copying...” message is no longer

displayed on your PC, communication with the

camera may still be in progress. Always check that

the indicator lamp on the camera is glowing green

and is no longer flashing.

Windows 98 or 98 SE

Windows Me/2000 Professional/XP

For a DSC connection, proceed to step .

For a PC CAMERA connection, proceed to step .

1Right-click the removable

disk icon in the "My

Computer" window and

select Eject.

✽ This step is only required in Windows Me.

✽ Screen for Windows Me

3The menu item shown below appears. Click

the mouse again.

4The “Eject hardware” dialog box appears.

Click the [OK] button or the close button.

✽ Screen for Windows Me

●

When you drag the icon to the Trash, “REMOVE OK”

appears on the camera’s LCD monitor.

Drag the “Removable drive” icon on the desktop

to the Trash.

7574

Accessories Guide

eThe optional accessories (sold separately) can make taking pictures with the FinePix2800 ZOOM

even easier. For information on how to attach and use the accessories, refer to the instructions

provided with the accessory used.

hSmartMedia™

These are separately available SmartMedia cards.

Use the following SmartMedia:

hMG-4S: 4MB, 3.3V hMG-8S: 8MB, 3.3V hMG-16S/SW: 16MB, 3.3V

hMG-32S/SW: 32MB, 3.3V hMG-64S/SW: 64MB, 3.3V hMG-128SW: 128MB, 3.3V

✽Some 3.3V SmartMedia are labelled as “3V” or “ID” cards.

hAC Power Adapter AC-5VH/AC-5VHS

Use the AC-5VH/AC-5VHS when taking pictures for a long period of time or

when the FinePix2800 ZOOM is connected to your PC.

✽

The shape of the AC power adapter, the plug and socket outlet depend on the country.

hFujifilm Rechargeable Battery 2HR-3UF (2×)

The 2HR-3UF includes 2 pieces of high-capacity AA-size Nickel Metal Hydride batteries.

hFujifilm Battery Charger with Battery BK-NH (Not Available in U.S.A. / Canada)

The BK-NH includes the quick battery charger BCH-NH and 2 Ni-MH batteries.

The BCH-NH can charge 4 Ni-MH batteries in approximately 180 minutes.

Up to 4 Ni-MH or Ni-Cd batteries can be charged simultaneously.

hSC-FX28 Soft Case

This is a special case made of polyester that protects the camera against soiling,

dust and minor impacts when it is being carried.

System Expansion Options (Sold Separately)

FinePix2800 ZOOM

Digital Camera

PC CARD

ADAPTER

(PC card slot)

Personal Computer

(commercially available)

(Floppy disk drive)

(USB)

(IEEE 1394)

(USB)

SmartMedia

PC Card Adapter

Image Memory Card Reader

Digital Photo Printer

Floppy Disk Adapter (FlashPath)

TV monitor

(commercially available)

eBy using the FinePix2800 ZOOM together with other optional FUJIFILM products, your system can

be expanded to fill a wide range of uses.

7776

Notes on Using Your Camera Correctly

■ Places to Avoid

Do not store or use the camera in the following types of

locations:

hIn the rain or in very humid, dirty or dusty places.

hIn direct sunlight or in places subject to extreme

temperature rises, such as in a closed car in summer.

hExtremely cold places.

hPlaces subject to strong vibration.

hPlaces affected by smoke or steam.

hPlaces subject to strong magnetic fields (such as near

motors, transformers or magnets).

hIn contact with chemicals such as pesticides or next to

rubber or vinyl products for long periods of time.

■ Notes on Immersion in Water or Sand

The FinePix2800 ZOOM is particularly adversely affected

by water and sand. When you are at the beach or close to

water, ensure that the camera is not exposed to water or

sand. Take care also not to place the camera on a wet

surface. Water or sand inside the camera can cause faults

that may be irreparable.

■ Notes on Condensation

If the camera is carried suddenly from a cold location into a

warm place, water droplets (condensation) may form on

the inside of the camera or on the lens. When this occurs,

switch the camera off and wait an hour before using the

camera. Condensation may also form on the SmartMedia

card. In this event, remove the SmartMedia and wait a

short time before using it again.

■ When the Camera is Unused for Long Periods

If you do not intend to use the camera for a long period, of

time remove the batteries and the SmartMedia card before

storing the camera.

■ Cleaning Your Camera

hUse a blower brush to remove dust from the lens, LCD

monitor screen or viewfinder as these surfaces, and then

wipe lightly with a soft, dry cloth. If any soiling remains,

apply a small amount of lens cleaning liquid to a piece of

FUJIFILM lens cleaning paper and wipe gently.

hDo not scratch hard objects against the lens, LCD

monitor screen or viewfinder as these surfaces are easily

damaged.

hClean the body of the camera with a soft, dry cloth. Do

not use volatile substances such as thinners, benzine or

insecticide, as these may react with camera body and

cause deformation or remove the coating.

■ Using the Camera Overseas

When travelling overseas, do not place your camera in the

check-in baggage. Baggage handling at airports may

subject baggage to violent shocks, and the camera may be

damaged internally even when no external damage is

visible.

eBe sure to read this information in conjunction with “Safety Notes” (➡P.92), to ensure that you use

your camera correctly.

hSM-R2 Image Memory Card Reader

The SM-R2 provides a quick and easy way to transfer images back and forth

between your PC and an image memory card (SmartMedia). The SM-R2 uses the

USB interface for high-speed file transfer.

hCompatible with Windows 98/98SE, Windows Me, Windows 2000 Professional,

iMac or Power Macintosh PCs which support USB as standard.

Accessories Guide

hPC-AD3 PC Card Adapter

The PC Card Adapter allows the SmartMedia to be used as a PC Card Standard

ATA-compliant (PCMCIA 2.1) PC card (Type II ).

hCompatible with SmartMedia of 5V/3.3V, 2MB to 128MB.

hFD-A2 Floppy Disk Adapter (FlashPath)

This adapter is the same size and shape as a 3.5-inch floppy disk. You can copy

the images on a SmartMedia to your PC simply by loading the SmartMedia into the

floppy disk adapter and then inserting the adapter into your floppy disk drive.

hDM-R1 Image Memory Card Reader

This device provides a simple way to transfer image data in either direction

between your PC and an image memory card (SmartMedia or CompactFlash

Type II (Microdrive-compatible)).

The IEEE 1394 interface provides high-speed data transfer.

hCompatible with Windows 98SE, Windows 2000 Professional (read-only), iMacDV

and Power Macintosh PCs with FireWire as a standard feature. Mac OS 8.5.1 to 9.1

Compatible OS Compatible SmartMedia

Windows 95/98/ 98SE/Me/NT4.0

Mac OS 7.6.1 to 9.1 5V/3.3V, 2MB to 128MBFD-A2

PC CARD

ADAPTER

7978

Soil (such as fingerprints) on the battery terminals can

markedly reduce the number of available shots. Carefully

wipe the battery terminals clean with a soft dry cloth before

loading the batteries.

If any liquid at all leaks from the batteries, wipe the battery

compartment thoroughly and then load new batteries.

f any battery fluid comes into contact with your hands or

clothing, flush the area thoroughly with water. Note that

battery fluid can cause loss of eyesight if it gets into your

eyes. If this occurs, do not rub your eyes. Flush the fluid out

with clean water and contact your physician for treatment.

■Disposing of Batteries

When disposing of batteries, do so in accordance with your

local waste disposal regulations.

■Notes on Small Rechargeable Batteries (Ni-MH

batteries)

hAlways use the special battery charger to charge AA-size

Ni-MH batteries. Charge the batteries as described in the

instructions provided with the battery charger.

hDo not use the battery charger to charge batteries other

than those specified for use with the charger.

hNote that the batteries may feel warm immediately after

being charged.

hNi-MH batteries are not charged at shipment. Be sure to

charge the batteries before using them.

hThe camera mechanism is such that it draws a minute

amount of current even when the camera is switched off.

Take particular care not to leave Ni-MH batteries in the

camera for a long period of time as they can become

excessively discharged and may no longer be usable

even when charged.

hNi-MH batteries self-discharge even when not used.

Always charge Ni-MH batteries before using them. If the

time for which a battery provides power shortens

markedly when it has been correctly charged, this

indicates that the battery has reached the end of its

effective life and should be replaced.

hSoiling (fingerprints, etc) on the terminals of Ni-MH

batteries can greatly reduce the number of available

shots. When this occurs, clean the terminals carefully

with a soft dry cloth. Then use up the remaining charge in

the batteries and recharge them.

hNewly purchased batteries or batteries that have been

left unused for an extended period may not be fully

charged. (This is indicated by the immediate display of

the battery low warning or a low number of available

shots.) This is a normal characteristic of the batteries and

does not indicate a fault. Repeatedly charging and using

the batteries 3 or 4 times will restore them to a normal

condition.

hIf you repeatedly charge a Ni-MH battery before it is fully

discharged, it will suffer from the "memory effect"*,

causing the battery low warning to appear while there is

still ample charge remaining in the battery. To restore the

batteries to their normal condition, use up all the charge

in the batteries before recharging them.

✽Memory effect: A phenomenon affecting the battery

characteristics such that the apparent

battery capacity decreases.

hAA-size alkaline, Ni-MH (nickel-metal hydride) can be

used with this camera.

Do not use AA-size manganese, lithium batteries in your

FinePix2800 ZOOM because the heat generated by the

batteries could damage the camera or cause

malfunctions.

hThe operating lives of alkaline batteries vary between

brands and the life of batteries you purchase may be

shorter than the alkaline batteries provided with the

camera.

hDo not use the batteries that are leaking, deformed,

discolored or exhibit any other obvious abnormality.

hDo not store the batteries in very warm or moist locations.

hKeep the batteries out of reach of infant and young

children.

When loading the batteries into the camera, ensure that the

battery polarity (

and

) is as indicated on the camera.

hDo not use new batteries together with used batteries. In

the case of rechargeable batteries, do not use charged

and discharged batteries together. Do not use batteries

of different types or brands together.

hIf you do not intend to use the camera for a long period of

time, remove the batteries from the camera. (Note that if

the camera is left with the batteries removed, the time

and date settings are cleared.)

hThe batteries may feel warm immediately after being

used. Before removing the batteries, switch the camera

off and wait until the batteries cool down.

When replacing the batteries, always fit 4 new batteries.

Here, 'new batteries' refers to either recently purchased

unused alkaline batteries, or Ni-MH (nickel metal hydride)

batteries that have recently been fully recharged together.

In cold locations (at temperatures of +10°C/+50°F or below),

battery performance deteriorates and the time for which they

can be used shortens markedly. This is particularly true of

alkaline batteries. In cold conditions, put the batteries in your

pocket or a similar place to warm them before loading them

into the camera. If you use a body warmer to warm the

batteries, ensure that they are not in direct contact with the

warmer.

Applicable Batteries

Notes on the Power Supply

Incorrect use of the batteries could cause them to leak,

become hot, ignite or burst. Always observe the

precautions given below.

hDo not heat the batteries or throw them into a fire.

hDo not carry or store the batteries with metal objects

such as necklaces or hairpins that could come into

contact with the metal positive =and negative -poles

of the battery.

hDo not expose the batteries to fresh or sea water, and

take particular care to keep the terminals dry.

hDo not attempt to deform, disassemble or modify the

batteries.

hDo not attempt to peel off or cut the battery casing.

hDo not drop, strike or otherwise subject the batteries to

strong impacts.

Notes on the Batteries

8180

■SmartMedia

The SmartMedia card supplied with your FinePix2800

ZOOM camera is a new image recording medium

developed especially for use in digital cameras. Each

SmartMedia card contains a built-in semiconductor

memory chip (NAND flash memory) which is used for

storing digital image data.

Because the data is stored electronically, the stored

image data can be erased from the card and new data

recorded.

■SmartMedia with IDs

The SmartMedia ID is a SmartMedia that has an

individually assigned identification number. SmartMedia

ID cards can be used with devices that use ID numbers

for copyright protection or other purposes. This camera

accepts SmartMedia ID cards in the same way as

conventional SmartMedia cards.

■Storing Data

In the situations listed below, recorded data may be

erased (destroyed). Please note that Fuji Photo Film

Co., Ltd. accepts no responsibility whatsoever for the

loss (destruction) of recorded data.

✽When the SmartMedia is used incorrectly by the

owner or a third party

✽When the SmartMedia is exposed to static electricity

or electrical noise

✽When the SmartMedia cover is opened or the

SmartMedia removed, or when the camera is

switched off during data recording, during data

erasing/formatting, or during frame advance when

images are being played back.

Back up important data onto another medium.

(MO disk, floppy disk, hard disk, etc.)

■Notes on Handling SmartMedia

hTake care to hold the SmartMedia straight when you

load it into your camera.

hNever remove the SmartMedia or switch the camera

off during data recording, during data erasing

(SmartMedia formatting) or during frame advance

when images are being played back. These actions

could result in damage to the SmartMedia.

hUse only the SmartMedia specified for use with the

FinePix2800 ZOOM. The use of other SmartMedia

could damage the camera.

hSmartMedia are precision electronic devices. Do not

bend, drop, or subject SmartMedia to excessive

shocks.

hDo not use or store SmartMedia in environments

likely to be affected by strong static electricity or

electrical noise.

hDo not use or store SmartMedia in very hot, humid or

corrosive environments.

hTake care not to touch the SmartMedia’s contact area

or allow the area to become soiled. Use a dry lint-free

cloth to wipe away any soiling that does occur.

hTo avoid damage caused by static electricity, always

use the special static-free case provided during

transportation or storage, or keep the SmartMedia in

a storage case if available.

Notes on the SmartMedia™

Notes on the Power Supply

Always use the AC-5VH/AC-5VHS AC Power Adapter with

the FinePix2800 ZOOM Camera.

The use of an AC power adapter other than the AC-5VH/

AC-5VHS could result in damage to your FinePix2800

ZOOM Digital Camera.

hThis AC power adapter is designed exclusively for indoor

use.

hPlug the connection cord plug securely into the DC input

terminal of the FUJIFILM Digital camera.

hTurn off the power switch of the FUJIFILM Digital camera

before disconnecting the connection cord from the

FUJIFILM Digital camera’s DC input terminal. To

disconnect, take hold of the plug and pull it out (do not

disconnect it by pulling on the cord).

hDo not use this AC power adapter with any device except

the specified device.

hDuring use, this AC power adapter will become hot to

touch, but this is normal.

hDo not disassemble the AC power adapter. Doing so

could be dangerous.

hDo not use this device in a place with high temperature

and high humidity.

hDo not drop or subject this device to strong shocks.

hThis device may emit a humming noise, but this is

normal.

hIf used near a radio, this device may cause static, so play

the radio in a distant place.

Notes on Using the AC Power Adapter

8382

(Lit red) (Flashing red)

Warning Displays eThe table below lists the warnings that are displayed on the screen

Warning Displayed Explanation Remedy

The batteries in the camera are fully

depleted or very low on charge.

There is no SmartMedia loaded, or

the SmartMedia loaded is a 5 volt

card.

iThe SmartMedia is not formatted.

iThe SmartMedia contact area is

soiled.

iCamera fault.

iThe SmartMedia contact area is

soiled.

iThe SmartMedia is damaged.

The SmartMedia format is incorrect.

iCamera fault.

The SmartMedia is fully recorded.

The SmartMedia is write-protected.

Replace the batteries or have replacement

batteries ready.

Load a SmartMedia (3.3 volt).

iWipe the contact area on the SmartMedia with

a soft dry cloth. It may be necessary to format

the SmartMedia. If the error message is still

displayed, replace the SmartMedia.

iContact your FUJIFILM dealer.

iWipe the contact area on the SmartMedia with

a soft dry cloth. It may be necessary to format

the SmartMedia. If the error message is still

displayed, replace the SmartMedia.

iContact your FUJIFILM dealer.

Use a SmartMedia that is not write-protected.

Erase some images or use a SmartMedia that

has ample free space.

Notes on the SmartMedia™

hDo not carry SmartMedia in locations such as a

trouser pocket. This could subject the SmartMedia to

excessive force when you sit down, thereby

damaging the SmartMedia.

hThe SmartMedia may feel warm when it is removed

from the camera after extended periods of picture

taking or image viewing. This is normal and does not

indicate a fault.

hInserting a SmartMedia that is charged with static

electricity into your camera may result in a camera

malfunction. If this occurs, switch the camera off and

then on again.

hAffix the label onto the designated area of the card.

Do not use third-party labels as this can lead to

problems when the card is inserted or removed.

hWhen you attach the label, take care that it does not

cover any of the write-protect area.

■Notes on Using SmartMedia with a PC

hIf you intend to take photos using a SmartMedia that

has been used on a PC, format the SmartMedia on

your camera.

hWhen you format a SmartMedia in the camera and

then shoot and record images, a directory (folder) is

automatically created. Image data is then recorded in

this directory.

hDo not change or delete the directory (folder) names

or file names on the SmartMedia from your PC as this

will make it impossible to use the SmartMedia in your

camera.

hAlways use the camera to erase image data on a

SmartMedia.

hTo edit image data, copy the image data to the PC’s

hard disk and then edit the copied data.

Be sure to use your PC’s disk eject function

(right-click the removable disk icon in the “My

Computer” window and then click “Eject”) when

you eject a SmartMedia from the PC card reader

or PC card adapter.

When you are using a USB connection, you

should also select and left-click the eject button

for “USB disc/mass storage” in the taskbar.

If you do not use the correct eject procedure,

the SmartMedia may be damaged due to write-

behind caching.

■Specifications

Type

Image memory card for digital

cameras (SmartMedia)

Operating voltage 3.3V

Conditions for use Temperature:

0°C to +40°C (+32°F to +104°F)

Humidity:

80% or less (no condensation)

Dimensions 37 mm ×45 mm ×0.76 mm

(1.45 in. ×1.77 in. ×0.03 in.) (W ×H ×D)

8584

There is a strong likelihood of

camera shake because the shutter

speed is slow.

A protected frame was erased. Protected files cannot be erased.

Unprotect the frame using the camera on which

the protection was first applied.

Use flash photography. However, a tripod

should be used for some scenes and modes.

iThe data could not be recorded

due to a SmartMedia error or a

connection error between the

SmartMedia and camera.

iThe photographed image cannot

be recorded as it is too large to fit

in the available space on the

SmartMedia.

iRe-insert the SmartMedia or switch the

camera off and then on again.

iUse a new SmartMedia.

Warning Displays eThe table below lists the warnings that are displayed on the screen

Warning Displayed Explanation Remedy

The playback frame number has

reached 999–9999.

Take the shot using a formatted SmartMedia.

DPOF settings are specified for an

image you tried to erase.

To erase the image, cancel the DPOF settings

and try again.

The AF (auto focus) cannot work

effectively.

iIf the image is too dark, take the picture at a

distance of around 2 m (6.6 ft.) from the

subject.

iUse AF lock to take the picture.

Prints were specified for more than

1000 frames in the DPOF frame

settings.

The maximum number of frames for which

prints can be specified on the same

SmartMedia is 999.

Warning Displayed Explanation Remedy

Outside the AE continuous range. The shot can be taken, but the exposure will not

be correct.

The voice captioning file is faulty. The voice captioning cannot be played back.

Camera malfunction or fault. iSwitch the camera on again, taking care not to

touch the lens.

iTurn the camera off and on again a few times.

An attempt was made to playback

a frame not recorded on this

camera.

iThe SmartMedia contact area is

soiled.

iCamera fault.

iYou attempted to play a movie

with a recording time longer than

60 seconds.

iImages cannot be played back.

iWipe the contact surface on the SmartMedia

thoroughly with a soft, dry cloth. In some cases,

you may have to format the SmartMedia.

iContact your FUJIFILM dealer.

iYou cannot play movies that are more than 60

seconds long.

8786

Problem Cause Remedy

Can’t use the flash to

take pictures.

iThe flash is set to Suppressed Flash

mode.

iYou pressed the shutter button while the

flash was charging.

iThe battery is exhausted.

iSet the flash to Auto, Red-Eye Reduction

or Forced Flash mode.

iWait until charging is completed before

pressing the shutter button.

iReplace the batteries.

The playback image is

too dark even though

the flash was used.

iThe subject is too far away.

iYour fingers are obscuring the flash or

flash control sensor.

iMove closer to the subject.

iHold the camera correctly.

The image is blurred. iThe lens is dirty.

iThe lens is zoomed to telephoto in Macro

mode.

iThe photographed subject was too dark.

iClean the lens.

iCancel Macro mode.

iTry standing about 2 m (6.6 ft.) from your

subject to take the picture.

There is speckling on

the image.

iThe shot was taken with a slow shutter

speed (long exposure) in a high-

temperature environment.

iThis is a characteristic of CCDs and

does not indicate a camera fault.

I can’t format the

SmartMedia.

iThe SmartMedia is write-protected. iRemove the write-protection.

Peel off the write-protect sticker)

The playback image is

faded when I used the

flash to take a picture.

iThere is dust on the flash control sensor. iUse an applicator such as a cotton swab

to clean the flash control sensor.

Troubleshooting eIf you think the camera is faulty, check the following once more

Problem Cause Remedy

No power. iThe battery is exhausted.

iThe AC power adapter plug has come out

of the power outlet.

iReplace the batteries.

iPlug the adapter back in.

Power cuts out during

operation.

iThe battery is exhausted. iReplace the batteries.

Battery runs out quickly. iYou are using the camera in extremely

cold conditions.

iThe terminals are soiled.

iThe battery is flat.

iPut the battery in your pocket or another

warm place to heat it and then load it into

the camera just before you take a picture.

iWipe the battery terminals with a clean,

dry cloth.

iReplace the batteries.

No photograph is taken

when the shutter button

is pressed.

iNo SmartMedia is loaded.

iThe SmartMedia is fully recorded.

iThe SmartMedia is write-protected.

iThe SmartMedia is not formatted.

iThe SmartMedia contact area is soiled.

iThe SmartMedia is damaged.

iThe Power Save function has switched

the camera off.

iThe battery is exhausted.

iLoad a SmartMedia.

iInsert a new SmartMedia or erase some

unwanted frames.

iRemove the write-protection.

iFormat the SmartMedia.

iWipe the SmartMedia contact area with

a clean dry cloth.

iLoad a new SmartMedia.

iSwitch the camera on.

iReplace the batteries.

Explanation of Terms

DPOF: Digital Print Order Format

DPOF is a format used for recording information on a storage media (image memory card, etc.) that allows

you to specify which of the frames shot using a digital camera are printed and how many prints are made of

each image.

EV:

A number that denotes exposure. The EV is determined by the brightness of the subject and sensitivity (speed) of

the film or CCD. The number is larger for bright subjects and smaller for dark subjects. As the brightness of the

subject changes, a digital camera maintains the amount of light hitting the CCD at a constant level by adjusting

the aperture and shutter speed. When the amount of light striking the CCD doubles, the EV increases by 1.

Likewise, when the light is halved, the EV decreases by 1.

JPEG:

Joint Photographics Experts Group

A file format used for compressing and saving color images. The compression ratio can be selected, but the higher the

compression ratio, the poorer the quality of the expanded image.

Motion JPEG:

A type of AVI (Audio Video Interleave) file format that handles images and sound as a single file. Images in

the file are recorded in JPEG format. Motion JPEG can be played back by QuickTime 3.0 or later.

PC Card:

A generic term for cards that meet the PC Card Standard.

PC Card Standard:

A standard for PC cards determined by the PCMCIA.

PCMCIA:

Personal Computer Memory Card International Association (US).

White Balance:

Whatever the kind of the light, the human eye adapts to it so that a white object still looks white. On the other

hand, devices such as digital cameras see a white subject as white by first adjusting the color balance to suit

the color of the ambient light around the subject. This adjustment is called matching the white balance. A

function that automatically matches the white balance is called an Automatic White Balance function.

Troubleshooting eIf you think the camera is faulty, check the following once more

Problem Cause Remedy

Frame erase does not

erase the frame.

Nothing happens when I

use the Mode switch.

iCamera malfunction.

iThe battery exhausted.

iBriefly remove the batteries or

disconnect the AC power adapter. Then

reload the batteries or reconnect the AC

power adapter and try again.

iReplace the batteries.

When the camera is

connected to a personal

computer (PC), the shot

image appears on the

camera's LCD monitor.

iThe special USB cable is not connected

correctly to the PC or camera.

iThe PC is not switched on.

iSet up the camera and USB cable

correctly.

iSwitch the PC on.

The camera no longer

works correctly.

iThe camera has suffered an unforeseen

problem.

iRemove the battery briefly and then

reload the battery and try again.

The ERASE ALL function

does not erase all the

frames.

iThe frame is protected.

iDPOF settings are specified for some

frames.

iUnprotect the frame using the camera on

which the protection was first applied.

iCancel the DPOF settings for the frame

and try again.

9190

hPower supply

Use one of the following:

• 4 ×AA-size alkaline batteries

• 4 ×AA-size Ni-MH (nickel-metal hydride) batteries (sold

separately)

• AC Power Adapter AC-5VH/AC-5VHS (sold separately)

hNo. of available shots using batteries Using (battery life)

✽ With fully charged battery

This indicates the number of available frames shot

consecutively at room temperature with a flash use rate of

50%. Note that these figures may vary depending on the

ambient temperature and the amount of charge in the

battery. The number of available shots or available

shooting time will be lower in cold conditions.

Input/Output Terminals

Power Supply and Others

h(USB) socket

USB (1) for image data output with a personal computer

hDC IN 5V (Power input) socket

Socket for specified AC power adapter

✽ These specifications are subject to change without notice.

FUJIFILM shall not be held liable for damages resulting

from errors in this Owner’s Manual.

✽ The LCD monitor on your digital camera is manufactured

using advanced high-precision technology. Even so, small

bright points and anomalous colors (particularly around

text) may appear on the monitor and viewfinder. These are

normal display characteristics and do not indicate a fault

with the monitor. This phenomenon will not appear on the

recorded image.

✽ Strong radio interference (i. e. electric fields, static

electricity, line noise, etc.) may cause operation error in a

digital camera.

hConditions for use

Temperature: 0°C to +40°C (+ 32°F to +104°F); 80%

humidity or less (no condensation)

Using EVF

Using LCD monitor

Battery type

Alkaline batteries

Ni-MH batteries

HR-3UF

Approx. 200 frames✽

Approx. 270 frames✽

Approx. 350 frames✽

hCamera dimensions (W/ H/D)

95 mm × 77 mm × 71 mm/3.7 in. × 3.0 in. × 2.8 in.

(not including accessories and attachments)

hCamera mass (weight)

Approx. 270 g/ 9.5 oz.

(not including accessories, batteries or SmartMedia)

hWeight for photography

Approx. 390 g/ 13.8 oz.

(including batteries, SmartMedia, lens cap and shoulder

strap)

hAccessories

See P.7

hOptional Accessories

See P.75, 76

Movie

Approx. 23 sec.

Approx. 47 sec.

Approx. 94 sec.

Approx. 191 sec.

—

Approx. 385 sec.

Approx. 774 sec.

—

MG-4MB (MG-4S)

MG-8MB (MG-8S)

MG-16MB (MG-16S/SW)

MG-32MB (MG-32S/SW)

MG-64MB (MG-64S/SW)

File Size

Quality

Image Data Size

81600 ×1200 91280 ×960 0

640 ×480

Approx.770KB

FINE

159

Approx. 390KB

NORMAL

MG-128MB (MG-128S/SW)

166 319

101

FINE

198

Approx. 320KB

NORMAL

204 398

122

247

497

Approx. 130KB

NORMAL

997

152

306

Approx. 200KB Approx. 620KB

BASIC

613

Specifications

System

hModel: Digital Camera FinePix2800 ZOOM

hNumber of effective pixels: 2.0 million pixels

hCCD sensor

1/2.7-inch square pixel CCD with RGB Filter

Number of total pixels: 2.1 million pixels

hNumber of recorded pixels

1600 × 1200 pixels/ 1280 × 960 pixels/640 × 480 pixels

hFile format

Still image: JPEG (Exif Ver.2.1), DPOF-compatible

Movie: AVI format, Motion JPEG

✽Design rule for Camera File system Complian

hViewfinder

0.55 inch 110,000 pixels electronic viewfinder

hLens

Fujinon 6×optical zoom lens F2.8/F4.8/ F8.2

hStorage media

SmartMedia (3.3V)

hFocus distance

f=6 – 36 mm (equivalent to 38 – 228 mm on a 35 mm camera)

hExposure control

64 zones TTL metering, Program AE

(exposure compensation available in Manual mode)

hSensitivity

Equivalent to ISO 100

hWhite balance

Auto (7 positions selectable in Manual mode)

hFocal range

Normal: Approx. 80 cm/2.6 ft. to infinity

Macro: Approx. 10 cm – 80 cm/3.9 in. – 31.5 in.

hShutter speeds

Variable-speed, 1/2 sec. to 1/ 1500 sec. (using AE)

hFlash (Auto flash using flash control sensor)

Effective range: Wide Approx. 0.3 m – 3.5 m (1.0 ft. – 11.5 ft.)

Tele Approx. 0.8 m – 3.5 m (2.6 ft. – 11.5 ft.)

Flash modes : Auto, Red-Eye Reduction, Forced Flash,

Suppressed Flash, Slow Synchro

hLCD monitor

1.8-inches, 62,000 pixels amorphous silicon TFT

hSelf-Timer

Approx 10 sec. timer clock

hNumber of frames recorded

9392

Never attempt to modify or disassemble

the camera. (Never open the casing.)

Do not use the camera when it has been

dropped or the casing is damaged.

This can cause a fire or electric shock.

●Contact your FUJIFILM dealer.

Never attempt to take pictures while in

motion.

Do not use the camera while you are

walking or operating a moving car or other

vehicle.

This can result in you falling down or being

involved in a traffic accident.

Do not heat, modify or attempt to

disassemble the batteries.

Do not drop or subject the batteries to

impacts.

Do not attempt to recharge lithium or

alkaline batteries.

Do not store the batteries with metallic

products.

Any of these actions can cause the

batteries to burst or leak and cause fire or

injury as a result.

Do not touch any metal parts of the

camera during a thunderstorm.

This can cause an electric shock due to

induced current from the lightning discharge.

Do not use the batteries except as

specified.

Load the batteries with correct polarity as

indicated by the =and -marks.

Use only the batteries or AC power

adapter specified for use with this

camera.

The use of other power sources can cause a fire.

If the battery leaks and fluid gets into

your eyes or comes into contact with

your skin or clothing, this can cause

injury or loss of eyesight. Immediately

flush the affected area thoroughly with

clean water and seek medical treatment.

When discarding or storing batteries,

cover the battery terminals with

insulation tape.

hContact with other metallic objects or

batteries could cause the batteries to

ignite or burst.

WARNING

Do not

disassemble.

WARNING

When a fault arises, switch the camera

off and then remove the batteries and

disconnect the AC power adapter.

Continued use of the camera when it is

emitting smoke, is emitting any unusual

odor, or is in any other abnormal state can

cause a fire or electric shock.

hContact your FUJIFILM dealer.

Do not allow water or foreign objects to

enter the camera.

If water or foreign objects get inside the

camera, switch the camera off, remove the

battery and disconnect and unplug the AC

power adapter.

Continued use of the camera can cause a

fire or electric shock.

hContact your FUJIFILM dealer.

Do not place the camera on an unstable

surface.

This can cause the camera to fall or tip over

and cause injury.

Do not use the camera in the bathroom

or shower.

This can cause a fire or electric shock.

hTo ensure that you use your FinePix2800 ZOOM camera

correctly, read these Safety Notes and your Owner’s

Manual carefully beforehand.

hAfter reading these Safety Notes, store them in a safe

place.

About the Icons

The icons shown below are used in this document to

indicate the severity of the injury or damage that can result

if the information indicated by the icon is ignored and the

product is used incorrectly as a result.

WARNING

This icon indicates that death or

serious injury can result if the

information is ignored.

CAUTION

This icon indicates that personal

injury or material damage can

result if the information is ignored.

The icons shown below are used to indicate the nature of

the information which is to be observed.

Triangular icons notify the user of information

requiring attention (“Important”).

Circular icons with a diagonal bar notify the user

that the action indicated is prohibited

(“Prohibited”).

Filled circles with an exclamation mark notify the

user of an action that must be performed

(“Required”).

Safety Notes

WARNING

Unplug from

power socket.

Do not use in the

bathroom or shower.

9594

EC Declaration of Conformity

Name :Fuji Photo Film (Europe)G.m.b.H.

Address :Heesenstrasse 31

40549 Dusseldorf, Germany

declare that the product

Product Name : FUJIFILM DIGITAL CAMERA FinePix2800 ZOOM

Manufacture’s Name : Fuji Photo Film Co., Ltd.

Manufacture’s Address : 26-30, Nishiazabu 2-chome, Minato-ku,

Tokyo 106-8620, Japan

is in conformity with the following Standards

Safety :EN60950

EMC :EN55022 :1998 Classe B

EN55024 :1998

EN61000-3-2 :1995 +A1:1998 +A2:1998

following the provision of the EMC Directive (89/336/EEC, 92/31/EEC and

93/68/EEC)and Low Voltage Directive (73/23/EEC).

Dusseldorf, Germany October 1, 2001

Place Date Signature/Managing Director

Bij dit produkt zijn batterijen geleverd. Wanneer deze leeg zijn, moet u ze niet

weggooien maar inleveren als KCA

Keep out of the reach of small children.

This product could cause injury in the hands

of a child.

Do not use this camera in locations

severely affected by oil fumes, steam,

humidity or dust.

This can cause a fire or electric shock.

Do not leave this camera in places

subject to extremely high temperatures.

Do not leave the camera in locations such

as a sealed vehicle or in direct sunlight.

This can cause a fire.

Do not place heavy objects on the

camera.

This can cause the heavy object to tip over

or fall and cause injury.

Do not move the camera while the AC

power adapter is still connected.

This can damage the power cord or cables

and cause a fire or electric shock.

CAUTION

Safety Notes

Do not cover or wrap the camera or the

AC power adapter in a cloth or quilt.

This can cause heat to build up and distort

the casing or cause a fire.

Remove the batteries and disconnect the

AC power adapter when you are

cleaning the camera or if you intend to

leave the camera unused for a long

period.

Failure to do so can cause a fire or electric

shock.

Using a flash too close to a person’s

eyes may temporarily affect the eyesight.

Take particular care when photographing

infants and young children.

Request regular internal testing and

cleaning for your camera.

Build-up of dust in your camera can cause

a fire or electric shock.

hContact your FUJIFILM dealer to request

internal cleaning every 2 years.

CAUTION

Printed in Japan FGS-103108-FG

Printed on recycled paper.

26-30, Nishiazabu 2-chome, Minato-ku, Tokyo 106-8620, Japan

Fujifilm Finepix 2800 Zoom Users Manual FinePix2800 Owner's

2800 Zoom to the manual 002b4626-37e5-4835-8139-893cb8fa932b

Navigation menu

Versions of this User Manual:

Views

Navigation
