EUT Host Specifications
FCC ID: EJE-WL0001 (IC: 337J-WL0001) Report No. M030725_Certification_Mace_Calexico
EMC Technologies Pty Ltd. 57 Assembly Drive, Tullamarine VIC 3043 Australia
www.emctech.com
EMC Technologies Pty Ltd - Report No. M030725_Certification_Mace_Calexico
ANNEX K – EUT HOST SPECIFICATIONS
28 Jul 03 Rev 3.0
(FJ Spec Rev 1.4)
Mace
Latest Intel Centrino Mobile Technology
Seamless Wi-Fi Connectivity
12.1" XGA TFT Active Digitizer
2GB Maximum Memory support
Programmable Security Feature
Mace T3010
CPU Intel® Pentium® M Processor 1.4GHz
Secondary Cache 1MB
Chipset Intel 855GM
Memory 256MB SDRAM, Max. 2GB (DDR266)
Hard Disk Drive 40GB (Ultra DMA/100 and S.M.A.R.T. Support)
Display 12.1" XGA TFT Colour (Max 1024x768 dots)
LCD Type Transmissive
Digitizer Active (Electromagnetic)
Graphics Integrated Intel® Graphics w/ Dynamic Video Memory Technology
with 3D Graphics Accelerator and AGP and MPEG-2 Support (for DVD)
Sound AC Link Audio (AC97 compliance: ALC202)
with Internal Speaker, Internal Microphone
Communication V.90 Modem & 10/100Mbps LAN
Wireless LAN Intel® PRO/Wireless 2100 - 802.11b with Dual Antenna OR Broadcom Wireless 11b/11g
External I/O Interface 1xVGA, 2xUSB 2.0, 1xRJ11, 1xRJ45,
Audio (Headphone-out, Microphone-in), Docking for Port Replicator, AC Adapter Power Input
Port Replicator 1xVGA, 2xUSB 2.0, 1xRJ45, AC Adapter Power Input
Security Panel Application Mode:
Application Launch Buttons and 2 programmable buttons
Security Mode:
Unique Numeric Buttons for Security Lock (More than 800,000 possible password combinations)
Keyboard 82-key w/ 19mm Key Pitch, 3mm Key Stroke
Pointing Device Touch Pad with Scroll button
Card Slot PC Card Slot Type I/II x 2
IR Interface IrDA1.1 ( Max. 4Mbps )
AC Adapter Input: AC100-240V, Output: DC16V 60W
Battery* Approx. 4.4 hours, Lithium-Ion
OS Supported Microsoft® Windows® XP Tablet PC Edition
Other Software Bundled Norman Virus Control
Norman Personal FireWall
Dimensions 293mm(W) x 236mm(D) x 27.4mm min. (H)
Weight Approx. 1.9Kg
