The comfort and ease of a traditional notebook combined with the versatility of a tablet

best describes the eye-catching LifeBook® T4220 Tablet PC. Built-in modular bay,

integrated wireless access, and the latest Intel® Centrino® Duo Mobile Technology

or optional Wi-Fi® certied Atheros Super AG® means you can instantly input and

access information whenever, wherever, and however needed.

LifeBook T4220 Tablet PC

Product Versatility

The LifeBook T4220 Tablet PC is not only

perfect for project-based users that require the

power of inking or easy pen-driven navigation,

but also for mobile professionals who must

have a keyboard and integrated media drive all

included in one unit. Taking advantage of the

industry-rst bi-directional swivel hinge, you

can easily transform this standard notebook

into a tablet conguration by rotating (in either

direction) and folding the screen. Collect data

efciently and accurately using the stylus to

make handwritten notes and drawings with

digital ink. To enter data using the keyboard,

tilt up and rotate the screen (follow the arrow

indicator) to a notebook conguration. The

stylus and active digitizer

continue to work in

the notebook conguration.

Mobile Productivity

You can choose one of two 12.1" displays with

active digitizer to perfectly t your business

needs: An indoor XGA TFT display or an

indoor/outdoor XGA TFT display. With Intel

Centrino Duo Mobile Technology, and the full

power and enhanced functionality of Genuine

Windows XP Tablet PC Edition, or Genuine

Windows Vista® Business, the LifeBook

T4220 Tablet PC delivers mobility,

conve-

nience, and increased productivity. In the eld,

use the stylus to easily navigate forms-based

or menu-driven

applications. Use the powerful

inking capabilities

to take notes or capture a

signature, then easily convert your handwritten

notes into text. When you return to your

hotel or ofce, use the keyboard in standard

notebook mode to incorporate your notes

into a business proposal or summary report.

Boundless Connectivity

Connect to your ofce network or the Internet

with modem, Gigabit Ethernet, the latest Intel

Wireless WiFi Link 4965AGN (802.11.a/b/g/

draft-n) for up to 5X throughput improve-

ment,

or optional Atheros Super AG wireless

LAN. The LifeBook T4220 Tablet PC comes

equipped with diversity antennas mounted in

the display panel to achieve high data transfer

rates and strong connection reliability. If you

use a Bluetooth-enabled cellular phone or

PDA, your LifeBook T4220 Tablet PC can be

equipped with integrated Bluetooth (version

2.0) wireless technology for data synchronization

and swapping images.

Maximum Usability

The LifeBook T4220 Tablet PC is very

versatile: Use it in notebook mode or in tablet

mode, as your needs dictate. The built-in

modular bay allows you to have a second battery

for extra-long work days and plane trips

without adding much weight or increasing

the system thickness. It can also accommo-

date one of the modular bay optical drives to

handle all of your digital media needs: DVD

movies, CD audio, or burning data onto CDs

or DVDs. While in tablet mode, the exclusive

patent pending BayLock™ utility automati-

cally locks the media drive door closed and

stops the drive from spinning, protecting both

the drive and the media inside from accidental

ejection or potential damage. This is a key

feature for the mobile tablet PC user. All of

this functionality comes in a tablet PC that

weighs as little as 4.3 lbs., and still manages

to house an array of ports that allow you to

connect peripherals directly. An optional port

replicator with hot-docking capability gives

you immediate access to desktop peripherals.

Uncompromised Security

The LifeBook T4220 Tablet PC takes security

to the next level. Featuring a ngerprint sensor,

Trusted Platform Module (TPM) 1.2, dedicated

Smart Card slot, LifeBook Application/Security

Panel, two-level hard drive passwords, BIOS-

enabled Computrace/LoJack theft recovery

service option, and security lock slot, you can

be condent that your data is safe and secure.

OVERVIEW

Dual functionality for notebook and tablet use•

Intel Centrino Duo Mobile Technology for •

groundbreaking performance

Industry-first bi-directional LCD hinge•

Built-in modular bay supports optical drives •

or bay battery for extended productivity

without adding much weight or changing

the form factor

Integrated Wi-Fi Certified wireless LAN, •

modem, and Gigabit Ethernet; optional

Bluetooth 2.0 wireless

Most comprehensive security features including •

integrated fingerprint sensor, embedded TPM

1.2, dedicated Smart Card slot, Security Panel

Application, two-level hard drive password,

BIOS-enabled for Computrace/LoJack theft

recovery service, and security lock slot

LAMP(S) INSIDE THIS PRODUCT

CONTAIN MERCURY AND MUST

BE RECYCLED OR DISPOSED OF

ACCORDING TO LOCAL, STATE,

OR FEDERAL LAWS.

Software

Operating Systems Genuine Windows® XP Tablet PC Edition 2005 or Genuine Windows Vista® Business

Software

Microsoft® Office OneNote® 2007, Microsoft® Experience Pack for Tablet PC (Genuine Windows® XP

Tablet PC Edition only), Google Desktop, Adobe® Reader®, Norton Internet Security1, EverNote Plus,

Fujitsu Display Controls, Fujitsu HotKey Utility, Fujitsu Security Application Panel, Fujitsu Driver Update

Utility, Softex OmniPass Fingerprint Utility , Shock Sensor Utility, TPM Drivers and Application CD

Optional Software

Depending on your system configuration, you may also receive the following:

Microsoft

®

Office Small Business Edition 2007, Bluetooth Utility, CyberLink PowerDVD™,

Roxio Easy Media Creator, CyberLink PowerProducer™

Note: Microsoft® Office applications require product activation

Key Specications

Processor Intel® Core™ 2 Duo Processor T71002 (1.8 GHz, 2 MB L2 cache, 800 MHz FSB)

Intel® Core™ 2 Duo Processor T7250 (2 GHz, 2 MB L2 cache, 800 MHz FSB)

Intel® Core™ 2 Duo Processor T73002 (2 GHz, 4 MB L2 cache, 800 MHz FSB)

Intel® Core™ 2 Duo Processor T7500 (2.2 GHz, 4 MB L2 cache, 800 MHz FSB)

Intel® Core™ 2 Duo Processor T7700 (2.4 GHz, 4 MB L2 cache, 800 MHz FSB)

Chipset Intel® 965GM + ICH8M

Memory Two DIMM slots; max. 4 GB, (actual 3.24 GB) 200-pin SO-DIMM, DDR2 667 MHz with dual

channel support

Note: Minimum of 1 GB of system memory is required when choosing

Genuine Windows Vista® Business

Intel® Turbo Memory Optional 1 GB of Intel® Turbo Memory (factory installation option)

For Genuine Windows Vista® platform only, supports Windows® ReadyDrive™

and Windows® ReadyBoost™ features (Available after November 2007)

Display LCD

12.1" XGA TFT indoor (Transmissive) display with wide viewing angles;

12.1" XGA TFT indoor/outdoor (Transmissive) display with wide viewing angles;

Video Mobile Intel® GMA X3100 with Intel® Clear Video Technology enabling

Controller DX10 and MPEG-2; Dynamic Video Memory Technology (DVMT)

responds to application requirements and efficiently allocates the proper

amount of system memory (up to 256/384 MB) for optimal graphics

and system performance.

Resolution Maximum internal display resolution: XGA 1024x768, 16M colors;

External monitor resolution: 1600x1200, 16M colors;

Simultaneous display resolution: Same as default internal display resolution

Digitizer Electromagnetic (Active)

Hard Drive3

160 GB, 120 GB, 80 GB, 60 GB, or 40 GB; 5400 rpm; Serial-ATA 150; shock-mounted;

two-level password protection; Shock Sensor Utility locks the hard drive when detecting

sudden impact, freefall, or vibration (may have to install this application separately)

Optical Drive

Options include: Modular Dual-Layer Multi-Format DVD Writer (up to: 4x DVD-R/+R DL,

8x DVD-R/+R/+RW, 6x DVD-RW, 5x DVD-RAM, 8x DVD-ROM, 24x CD-R, 10x CD-RW,

24x CD-ROM), or, Modular DVD/CD-RW Combo Drive (up to: 8x DVD-ROM, 10x CD-RW, 24x

CD-R, 24x CD-ROM), or, Modular DVD-ROM Drive (up to: 8x DVD-ROM, 24x CD-ROM)

Audio

RealtekALC262 AC’97-compliant codec with 20-bit audio; built-in dual array digital

microphones with IntelliSonic™ noise cancellation and echo suppression software

Communication Multinational 56K4 V.905 modem and 10/100/1000 Gigabit Ethernet LAN

Wireless Communication

Intel

®

Wireless WiFi Link 4965AGN (802.11a/b/g/draft-n) or

Atheros Super AG

®

Wireless LAN (802.11a/b/g); Wi-Fi

®

certified; dual diversity antennas.

Optional Bluetooth (v2.0) Personal Area Network (PAN) for file transfer

and data synchronization with other Bluetooth devices

User Interface 82-key keyboard, spill-resistant; touch pad with left, right, and scroll buttons

Ports

Three USB 2.0, Infrared port (IrDA 1.1-compatible, 4 Mbps), External monitor/VGA,

modem (RJ-11), Gigabit Ethernet (RJ-45), SD/Memory Stick PRO slot, docking connector,

headphone/line-out jack, and microphone/line-in jack

Card Slots One Type I/II PCMCIA slot, 32-bit PC CardBus architecture;

One Smart Card slot;

One shared slot for Memory Stick®, Memory Stick PRO™, or Secure Digital (SD) card

Security LifeBook Application/Security panel

AuthenTec Fingerprint Sensor with TruePrint Technology; 15cm/sec slide speed

Trusted Platform Module (TPM), TCG 1.2-compliant

Dedicated Smart Card slot

Hard drive and BIOS passwords

BIOS support for Computrace/LoJack theft recovery system (Service required)

Security lock slot

Battery6 Main battery: Lithium ion (6-cell, 10.8V, 5200 mAh, 56.16 WHr)

Modular Bay battery: Lithium ion (6-cell, 10.8V, 3800 mAh, 41 WHr)

Bridge battery for warm swapping of primary battery

XGA model: up to 4.25 hrs. with main battery; up to 8 hrs. using both main and modular bay battery

AC Adapter Autosensing 100-240V AC, 80W, supplying 19V DC, 4.22A

Dimensions/Weight 11.5" x 9.3" x 1.1/1.4"; approx. 4.3 lbs. with weight saver

Operating Temperature

41°F to 95°F/5°C to 35°C (ambient temperature); 20% to 85% relative humidity, non-condensing

Non-Operating Temperature

5°F to 140°F/-15°C to 60°C, 8% to 85% relative humidity, non-condensing

Key Accessories For a full list of accessories, visit www.shopfujitsu.com or call 1-800-FUJITSU

Port Replicator: Power/Suspend/Resume button, four USB 2.0, external video, DVI-D,

modem (RJ-11), Gigabit Ethernet (RJ-45), docking connector, audio line-out

Compliance and Service Information

Compliance FCC Part 15B Class B, and FCC Part 15C, and FCC Part 15E; IC ICES-003 Class B

and RSS-210

UL-cUL Listed

FCC Part 68; IC CS-03

CE Marking (Not supported when configured with the WLAN module)

Warranty7 One- or three-year International Limited Warranty on select corporate configurations;

24/7 technical support; Fujitsu extended service plans available.

Fujitsu Computer Systems Corporation

Enterprise Sales:

1.800.831.3183

us.fujitsu.com/computers

Consumer Sales (24/7):

1.800.FUJITSU

www.shopfujitsu.com

1) Preinstalled with a free 90-day trial version of

Symantec Norton Internet Security 2007. The

90-day trial version is activated upon user’s

acceptance of software license agreement. After 90

days, the user must purchase a subscription from

Symantec to download latest virus definitions.

2) Limited availability.

3) One gigabyte (GB) = one billion bytes; accessible

capacity will be less and actual capacity depends on

the operating environment and formatting.

4) The internal modems on all Fujitsu mobile computers

from Fujitsu Computer Systems Corporation are only

qualified for use with telephone systems in selected

countries, including the United States and Canada.

For a list of certified countries, please check

http://www.computers.us.fujitsu.com/modems.

5) Actual speeds over U.S. telephone lines vary, and are

less than 56 Kbps due to the current FCC regulations

and line conditions.

6) Battery life estimates reflect the results of BAPCo

MobileMark2005 Productivity Workloads performed

upon systems with battery life setting enabled on

Windows® XP operating systems. Actual battery life

will vary based on screen brightness, applications

used, features selected, power management settings,

battery conditioning, and other customer

preferences. DVD/CD-RW, DVD Writer, LAN, wireless

LAN or hard drive usage may also have a significant

impact on battery life.

7) Service and warranty turnaround time may vary by

country and product. The International warranty is only

valid for products purchased in North, Central, and

South America.

Fujitsu, the Fujitsu logo, and LifeBook are registered

trademarks of Fujitsu Limited. Genuine Windows

Vista, Microsoft, Windows, ReadyDrive, and

ReadyBoost are trademarks or registered trademarks

of Microsoft Corporation in the United States

and/or other countries. Centrino, Intel, Intel

Core, the Centrino logo and the Intel logo are

trademarks or registered trademarks of Intel

Corporation or its subsidiaries in the United States

and other countries. Atheros, the Atheros logo and

Super AG are all registered trademarks of Atheros

Communications. Memory Stick is a registered

trademark and Memory Stick PRO is a trademark of

Sony Corporation and/or its affiliates. Adobe Reader is

a registered trademark of Adobe Systems, Inc. Wi-Fi

is a trademark of the Wireless Ethernet Compatibility

Alliance (WECA). Norton AntiVirus is a registered

trademark of Symantec Corporation. All other

trademarks mentioned herein are the property of

their respective owners Product description data

represents Fujitsu design objectives and is provided for

comparative purposes; actual results may vary based

on a variety of factors. Specifications are subject to

change without notice.

©2007 Fujitsu Computer Systems Corporation.

All rights reserved. FPC58-1695-09 9/08.

08.0916

LifeBook T4220 Tablet PC
