F-02D_EN_ninshou

Introduction

Waterproofness/Dustproofness

F-02D provides waterproofness of IPX5

, IPX8

and dustproofness of IP5X

with firmly closing

the external connection jack cap and installing

the back cover in a locked state.

IPX5 means that a phone keeps functioning after

applying a jet flow of 12.5 L/min. from every

direction from a distance of approximately 3 m for at

least 3 minutes using water nozzle in 6.3 mm inner

diameter.

For F-02D, IPX8 means that a phone keeps

functioning after F-02D is slowly submerged to

depth of 1.5m in static tap water at room

temperature, left there for 30 minutes and then taken

out, and the mobile phone keeps shooting still

images or moving pictures in approximately 30

minutes in static tap water at room temperature.

IP5X means a protection degree that a phone keeps

functioning and safety after it is placed in a device

with dust in diameter 75

or less for 8 hours,

agitated and then taken out.

✜

What you can do with waterproofness

of F-02D

・

You can talk or watch 1Seg programs without

using an umbrella in the rain (for rainfall of 20

mm or less per hour).

- When your hands or FOMA terminal are wet,

avoid installing/removing the back cover or

opening/closing the external connection jack

cap.

・

You can also shoot still images and moving

pictures in the pool depth of 1.5 m.

- Do not perform other operations underwater

than shooting still images and moving

pictures.

- If you put the terminal in water of swimming

pool, be sure to have it within 30 minutes.

- If FOMA terminal gets wet with water from the

swimming pool or soak in water of swimming

pool, wash it in specified procedure (

⇒

P23).

・

You can use FOMA terminal in a bathroom.

- Do not put the terminal in the bathtub. Do not

use the terminal in hot water. May cause

malfunction.

- Never put FOMA terminal in hot spring water

or water containing soap, detergent or bath

powder.

To ensure waterproofness/

dustproofness

To avoid water/dust ingress, be sure to observe

the following points.

・

Do not throw any liquid other than room-

temperature tap water on FOMA terminal, or

soak it in such liquid.

・

When using the external/HDMI connection jack,

put your finger into the groove as shown then

pull the cap up in the direction of the arrow.

Groove

F-02D_EN_ninshou

Introduction

After using the external/HDMI connection jack,

close the cap as the direction shown in the

illustration, and make sure that the cap is

completely closed without slack by pushing the

tabs in.

・

For installing the back cover, see "Installing back

cover" of "Attaching miniUIM/battery pack".

⇒

P26

・

Securely lock the back cover and firmly close the

external connection jack cap. Even a fine

obstacle (one hair, one grain of sand, tiny fiber,

etc.) put between contact surfaces may allow

water to enter.

・

Do not poke the microphone, earpiece or

speaker with a swab or sharp object.

・

Do not let FOMA terminal fall. It may become

scratched causing the waterproof/dustproof

performance to degrade.

・

The external connection jack cap and the rubber

packing of the rear side of the back cover play an

important role for keeping waterproof/dustproof

performance. Do not deform the back cover by

twisting etc. or peel off or damage the rubber

packing. Also, prevent dust from adhering to it.

To keep FOMA terminal waterproofness/

dustproofness, replacement of parts is required

every 2 years regardless of whether FOMA

terminal appears normal or abnormal.

DOCOMO replaces the parts as a chargeable

service. Bring FOMA terminal to a sales outlet

such as a DOCOMO-specified repair office.

Important precautions

Do not perform actions shown in the illustrations

below.

Observe the following precautions to use FOMA

terminal properly.

・

Accessories and optional devices are not

waterproof/dustproof. When watching 1Seg etc.

with FOMA terminal installed in the included

desktop holder, do not use it in a bathroom,

shower room, kitchen or lavatory even if it is not

connected to the AC adapter.

・

Do not apply water flow stronger than allowed (

⇒

P21) (e.g., such water flow that gives you pain

when applied to your skin directly from a faucet

or shower). F-02D provides IPX5 waterproof

performances. However, it causes malfunction.

・

If FOMA terminal gets wet with salt water, sea

water, refreshing beverage or mud or soil

adhered, wash it immediately. If they dry out, it

is hard to remove the dirt and it may cause

damage or malfunction.

・

Do not put FOMA terminal in hot water, use it in

a sauna or apply hot airflow (from a hair dryer

etc.) to it.

Using Soap/Detergent/

Bath powder

Soaking in

ocean water

Applying strong

water flow

Using in

hot spring

Machine-washing

Washing with

brush/sponge

F-02D_EN_ninshou

Introduction

・

Do not move in water or slam the terminal

against the surface of water with FOMA terminal

opened.

・

If you put the terminal in tap water or in water of

swimming pool, be sure to have it within 30

minutes.

・

When you use the terminal in swimming pool,

obey rules of the facility.

・

FOMA terminal does not float on water.

・

Do not leave water on FOMA terminal. May

short-circuit the power jacks, or in a cold region,

water may freeze causing malfunction.

・

Do not leave water on the microphone, earpiece

or speaker. Such water may interfere with

talking.

・

Do not leave water on the temperature/humidity

sensor. Measuring temperature and humidity

may not be correct.

・

If the back cover is damaged, replace it. Water

may enter inside from a damaged section

causing troubles such as electric shocks or

corrosion of the battery.

・

If FOMA terminal gets wet with water or other

liquids with the external connection jack cap or

the back cover open, the liquid may get inside

the terminal causing electric shocks or

malfunction. Stop using FOMA terminal, turn

the power OFF, remove the battery pack and

contact a DOCOMO-specified repair office.

・

If the external connection jack cap, or the rubber

gasket on the rear side of the back cover is

damaged or deformed, replace it at DOCOMO-

specified repair office.

DOCOMO does not guarantee actual operations

under all states. Malfunctions deemed to be

caused by inappropriate operation by the

customer are not covered by the warranty.

With pressing and holding the external

connection jack cap not to open, wash the

terminal in tap water without rubbing hard

・

Do not apply water flow stronger than allowed (

⇒

P21) (e.g., such water flow that gives you pain

when applied to your skin directly from a faucet

or shower).

・

In locked state with the back cover attached,

with pressing and holding the external

connection jack cap not to open, wash the

terminal in tap water in room temperature

without rubbing hard.

・

Do not use brush, sponge, soap, detergent, etc.

・

If mud or soil is adhered to the terminal, do not

open, close or rotate the terminal. Eliminate the

dirt first by shaking several times in tap water of

wash-basin and then wash the terminal with

running water.

・

After washing, wipe the surface with dry cloth

well, drain water by the following procedure and

let the terminal dry naturally.

Washing FOMA terminal

Press here

F-02D_EN_ninshou

Introduction

When FOMA terminal is wet, water may flow out

after wiping it off; drain the water in the following

steps.

Wipe off moisture on FOMA terminal surface

with dry, clean cloth etc.

Shake FOMA terminal approximately 20 times,

firmly holding its hinge section, until there is

no more water splattering.

Press lightly FOMA terminal against dry, clean

cloth etc. to wipe off water remaining in the

microphone, earpiece, speaker, keypad, hinges

or charging jack, etc.

Wipe off water drained from FOMA terminal

with dry, clean cloth etc., and dry naturally.

･

Water, if any, remaining in FOMA terminal

may ooze up after wiping off.

･

Do not wipe off water remaining in gaps

directly with a cotton swab etc.

Draining water from FOMA

terminal

Swing the FOMA terminal with the

speaker above to drain water off

F-02D_EN_ninshou

Introduction

Check the following before and after charging.

・

Check if FOMA terminal is not wet. Never try to

charge the battery pack when FOMA terminal is

wet.

・

Accessories and optional devices are not

waterproof/dustproof.

・

When charging the battery when or after FOMA

terminal is wet, adequately drain it and wipe off

water with a dry, clean cloth etc., before

connecting the accessory desktop holder or

opening the external connection jack cap.

・

When the external connection jack cap is

opened for charging, close the cap firmly after

charging. It is recommended to use the desktop

holder for charging to prevent water from

seeping inside from the external connection

jack.

・

Do not use the AC adapter or desktop holder in

a bathroom, shower room, kitchen, lavatory or

other highly humid area. May cause fire or

electric shock.

・

Do not touch the AC adapter or desktop holder

with wet hands. May cause electric shock.

Charging

F-02D_EN_ninshou

Basic Operation

Before Using

Attaching miniUIM/battery pack

After turning power OFF, close FOMA terminal

and hold it in your hand so that you can properly

attach UIM/battery pack.

✜

Removing back cover

✜

Attaching miniUIM

Point

･

A UIM or FOMA card is not available for this FOMA

terminal. Replace it with a miniUIM at a docomo

Shop.

✜

Installing battery pack

✜

Installing back cover

Press and slide the back cover

in the arrow direction approx.

2 mm to remove

Slide the back cover in the

arrow direction to unlock

Back cover

With facing IC side of the mini UIM down, insert

to the slot slowly and push it until it clicks

Corner cut

mini UIM

With the label side up, fit the

convex parts to the concave

parts of the FOMA terminal

and insert in the

direction,

then push in the

direction

to set in.

Convex parts

Concave parts

Slide the lever in the arrow direction

to lock

Fit the 8 tabs to the notches of the

FOMA terminal and push in the

direction

not forming any

clearance, then slide in the

direction

F-02D_EN_ninshou

Basic Operation

Before Using

Charging

The battery pack does not have a full charge at time of purchase. Use AC adapter for FOMA terminal to

charge the battery before using FOMA terminal.

Insert the connector of AC adapter

horizontally to the accessory desktop

holder, with the arrows mark side

upward

Unfold the power plug and insert it into

a 100V AC outlet

Close FOMA terminal and insert it into

the desktop holder

Check that the charging light turns on

After charging is completed, remove FOMA

terminal from the desktop holder.

Open the external connection jack cap

(

), hold the connector horizontally

with the arrows side upward and insert

it to the jack (

)

Unfold the power plug and insert it into

a 100V AC outlet

Check that the charging light turns on

When charging is over, pull out the power plug from

the outlet, and pull out from FOMA terminal

horizontally while pressing the release buttons on

both sides of the connector.

Charging using desktop holder

Charging using AC adapter

AC 100V

outlet

Release

buttons

Connector

Desktop Holder

AC adapter

AC 100V

outlet

Connector

Release

buttons

External

connection jackExternal connection jack cap

AC adapter

c b

F-02D_EN_ninshou

Basic Operation

Before Using

Power ON - Default setting

Initial setting is an operation when FOMA terminal

is turned ON for the first time.

(2 sec. or more)

The Initial setting screen appears.

Set required items

[Complete]

If you exit without setting Change security

code and Request permit/deny., Initial setting

screen reappears when the power is turned

ON the next time.

On a confirmation screen of software

update function,

On the

confirmation screen of Error info send

set.,

The stand-by display appears.

When a Machi-chara asks your name (user

name), press

twice to enter a user name.

Point

･

If no operation is performed, the display light is

automatically turned off according to the settings in

Light time-out or eco mode setting. The display light

turns on again if there is any operation or incoming

call.

･

The battery usage state is automatically recorded

while using the FOMA terminal. The record is used

only for repair diagnosis.

Turning power off :

(2 sec. or more)

Changing the initial setting :

mehib

Changing screen display to English :

mehdde

Select "English"

Before Using

Caller ID notification

Set whether to notify your phone number (caller

ID) to the other party's terminal when making a

voice call. Caller ID notification is set to "ON" at the

time of subscription.

ameg

TEL function

Dial/

Receive call setting

Caller ID

notification

Setting

ON or

OFF

Point

･

If you hear an announcement of requesting caller ID

when making a call, set Caller ID notification or add

prefix "186" to the phone number to call again.

Before Using

Checking Profile

Check a model name or own phone number.

ame0

Profile

User information screen appears.

Point

Editing the profile :

On User information screen,

Authenticate

Set required items

･

On the profile edit screen, select first mail address

then select "Acquire Auto" to obtain your mail

address from the i-mode center. For details of

changing a mail address, refer to "Mobile Phone

Users Guide [i-mode] FOMA version".

Checking a phone number during a call :

se0

F-02D_EN_ninshou

Basic Operation

Screen Explanation

Viewing display

New arrival information and current state can be

checked by the icon appearing on the screen.

Major icons are as follows.

Status area

Status icons are displayed. Select an area to

display the status menu.

⇒

P31

Battery level (Battery icon)

Signal strength (Antenna icon)

Self mode ON

In data transfer mode

Connecting to i-mode

Display off lock setting in Auto-key lock is set

Infrared communication in operation

Bluetooth ON

The total calls cost exceeds the limit

Communication using handsfree-compatible

device in progress

Handsfree ON

Femtocell available

Touch operation OFF

Positioning with GPS

Location request setting

Connecting to Wi-Fi

Unread Area Mail exists

In-area auto-send mail exists

Unread i-mode mail exists

Arrival i-concier information exists

Unreceived i-mode mail exists in the Center

くーまん

(Kuman)"

Dora communications

Ample

charge

Almost exhausted

(Charge the battery)

Strong

Out of service area or where

radio waves do not reach

Weak

F-02D_EN_ninshou

Basic Operation

Using Smart Browser

3D setting is ON

A phonebook entry, memo or schedule has

secret attribute

Music&Video Channel program obtaining

reservation exists

High-pitched alarm is "ON"

Kid-safe mode ON

During i-

ppli operation

ppli call exists

Communication mode ON (USB cable

connected)

Alarm is set

1Seg watching/recording reserved or alarm

of Memo is set

Inside OFFICEED area

Manner mode ON

Call alert volume OFF

Vibration mode for voice call ON

In Public mode (Drive mode)

Manner support ON

Record message setting ON

Keypad dial lock ON

Personal data lock ON

IC card lock ON

Recording 1Seg in the FOMA terminal

eco mode ON

microSD card inserted

Connected to external device using USB

cable

Pedometer/ACT monitor is set

Software update rewrite notice

Auto-update of latest pattern definition

failure

Machi-chara

Characters moving about the screen and giving

messages. In addition to the preinstalled

characters, you can obtain characters by

downloading.

Widget for Stand-by disp layout

Clock, weather forecast, thermo-hygrometers

(TempHmd), Pedometer/Physical Activity

Monitor, Calendar, Schedule, Memo, i-Channel

ticker, graffiti pasted on the stand-by display.

Touch and hold the screen for 1 second or more to

display stand-by elements palette/stand-by

handwriting palette, and edit freely with touch or

slide operations. You can move arrival

information icons.

New arrival

Starting from the left, i-

ppli call, unread ToruCa,

missed call, recorded message, message in voice

mail service, unread mail

Select an arrival information etc. on the stand-by

display using

and

to quickly display the

corresponding information (Focus mode).

Short cut icons (vertical view)/Function key

(horizontal view)

On the stand-by display (vertical view), select a

shortcut icon to activate a function. On the stand-

by display (horizontal view), select a function key

to display menu, activate phone, mail or Quick

search.

Task area

Icons indicating running features (tasks) appear.

F-02D_EN_ninshou

Basic Operation

Screen Explanation

Basic operations for screen and keys

On the stand-by display, select

and then

perform the functions from the menu. You can select

a menu item with shortcut operations, which use the

keypad, etc. or with multi-cursor operation, which

uses the multi-cursor key to move the cursor.

<Example> Selecting "Calculator"

Shortcut operations

ame6e2

Multi-cursor key operations

ame

Move the cursor to "

Tool"

[OK]

Move the cursor to

Calculator"

[OK]

Point

･

To return to the previous screen, press

. To

return to the stand-by display, press

Operations that

can be performed

by pressing

and

are

displayed in the

guide area.

Terms indicated

with [ ] in the

instructions of

this manual are items displayed in the guide area.

Select status area to display

the status menu. You can

check the status and change

the settings from the status

menu.

In the right and left area of the stand-by display

(vertical), up to 12 MyFACEs downloaded from

sites, etc. can be pinned. Flick left or right on the

stand-by display (vertical) to display MyFACE and

flick left or right on the stand-by displays

(horizontal) to display Redial/Received calls.

And flick the screen upwards to display shortcuts

list and flick downwards to display phonebook.

Menu operation

Guide area

Status menu

Flick operation on the stand-by

display and MyFACE

F-02D_EN_ninshou

Basic Operation

Screen Explanation

Using touch panel

Notes for using the touch panel

･

The touch panel is designed for being touched

lightly with fingers. Do not push it forcibly with

a finger or press it with sharp objects such as

nail, ballpoint pen, pin, etc.

･

Touching the touch panel may not work in the

following cases. Note that it may cause

malfunction.

- Operation with gloved hands

- Operation with tip of fingernail

- Operation with a foreign object on the display

- Operation with protective sheet or seal on the

display

- Operation with wet hand

- Operation under water

･

Do not press forcibly the frame part around the

display. The touch panel may malfunction.

Point

･

Depending on the operation or function, effective

range for the touch operation may be different or

invalid.

Basic operation on the touch panel

Tap

Touch the display lightly once and

release the finger. The operation

becomes effective when you release your

finger from the display. This operation is

mainly for selecting menus, items, etc.

On the smart browser screen, quickly tap

twice (double-tap) to zoom in/out.

Touch

(1 sec.

more)

Touch the display for 1 sec. or more and

release the finger. Some operations require to

perform the subsequent action with your

finger kept touching the screen.

Drag

Keep touching an item or icon on the

display, move your finger to the desired

direction. This operation is used for moving

items or entering handwriting characters.

Slide

Keep touching the display, move your

finger up/down/right/left. This operation

is used for scrolling screen.

Flick

Touch the screen and flick away. This

operation is for switching pages or images,

or moving to a different chapter or tune, etc.

Pinch

While touching the display with the two

fingers, widen and narrow the spacing

between the fingers. This operation is

mainly for zooming in/out the display.

Example: SlideExample: TouchExample: Pinch

F-02D_EN_ninshou

Basic Operation

Screen Explanation

Voice quick start

When you do not know a desired menu of function

or you want to activate the function quickly, the

function can be activated by voice sound input

from the stand-by display. (In Japanese only)

(1 sec. or more)

For the first activation, on the guidance

screen, select "

利用する

(Use)" or press

From the second time, "

それではどうぞ ★★

音声受付中★★

" (Please go ahead

★★

voice

input available

★★

) is displayed.

Speak a function name toward the

microphone within 10 seconds.

When a message "#

もう一度お話ください

appears, press

and speak again.

When the voice input is recognized, the

function activates. If the function is not

identified, the keyword list of

使いかたガイド

(Guide) appears.

Point

･

Speak clearly with natural conversation speed.

･

Depending on the environment or way of speaking,

recognition result may vary.

･

You can speak function name (

電卓

(Calculator),

ワン

セグ

(1Seg), etc.), keyword (

計算

(calculation),

テレビ

(TV),

アドレス交換

(address exchange), etc.) or

combination of keywords (

写真見る

(view photo),

メール問合せ

(mail check),

スケジュール

月

日

(schedule 25th November),

○○さん

にメール

(mail

to Mr.

○○

), etc.) to activate the function.

* Name registered to the phonebook

Screen Explanation

使いかたガイド

(Guide)

You can check outline of function, operations or

troubleshooting. (In Japanese only)

amef

Tool

Guide

Select a

search method

(Contents) :

Search from a list of

functions.

索引

(Index) :

Search from a list of words

sorted according to Japanese syllabary.

フリーワード検索

(Free word search) :

Enter a

keyword to search for.

ブックマーク

(Bookmark) :

Search from a list

of registered bookmarks.

困ったときには

(Troubleshooting) :

from lists of troubles or error messages.

その他のご案内

(More information) :

Access to

guide page introducing useful site.

Point

･

On a description screen, select "

この機能を使う

(Use

this function)" to perform a function. Selecting a link

item in "

関連機能

(related functions)" or "

→コチラ

(See more)" displays a corresponding description

screen.

F-02D_EN_ninshou

128

Others

Appendix

Specific Absorption Rate (SAR) of Mobile Phones

This model F-02D mobile phone complies with

Japanese technical regulations and international

guidelines regarding exposure to radio waves.

This mobile phone was designed in observance of

Japanese technical regulations regarding exposure to

radio waves (

) and limits to exposure to radio waves

recommended by a set of equivalent international

guidelines. This set of international guidelines was set

out by the International Commission on Non-Ionizing

Radiation Protection (ICNIRP), which is in collaboration

with the World Health Organization (WHO), and the

permissible limits include a substantial safety margin

designed to assure the safety of all persons, regardless

of age and health condition.

The technical regulations and international guidelines

set out limits for radio waves as the Specific

Absorption Rate, or SAR, which is the value of

absorbed energy in any 10 grams of tissue over a 6-

minute period. The SAR limit for mobile phones is 2.0

W/kg. The highest SAR value for this mobile phone

when tested for use at the ear is 0.683 W/kg. There may

be slight differences between the SAR levels for each

product, but they all satisfy the limit.

The actual SAR of this mobile phone while operating

can be well below that indicated above. This is due to

automatic changes to the power level of the device to

ensure it only uses the minimum required to reach the

network. Therefore in general, the closer you are to a

base station, the lower the power output of the device.

This mobile phone can be used in positions other than

against your ear. This mobile phone satisfies the

international guidelines when used with a carrying

case or a wearable accessory approved by NTT

DOCOMO, INC.(

) In case you are not using the

approved accessory , please use a product that does

not contain any metals, and one that positions the

mobile phone at least 1.5 cm away from your body.

The World Health Organization has stated that "a large

number of studies have been performed over the last

two decades to assess whether mobile phones pose a

potential health risk. To date, no adverse health effects

have been established as being caused by mobile

phone use."

Please refer to the WHO website if you would like more

detailed information.

http://www.who.int/docstore/peh-emf/publications/

facts_press/fact_english.htm

Please refer to the websites listed below if you would

like more detailed information regarding SAR.

Ministry of Internal Affairs and Communications Website:

http://www.tele.soumu.go.jp/e/sys/ele/index.htm

Association of Radio Industries and Businesses

Website: http://www.arib-emf.org/index02.html (in

Japanese only)

NTT DOCOMO, INC. Website: http://

www.nttdocomo.co.jp/english/product/sar/

FUJITSU LIMITED Website: http://www.fmworld.net/

product/phone/sar/

Technical regulations are defined by the Ministerial Ordinance

Related to Radio Law (Article 14-2 of Radio Equipment

Regulations).

Regarding the method of measuring SAR when using mobile

phones in positions other than against the ear, international

standards (IEC62209-2) were set in March of 2010. On the

other hand, technical regulation is currently being deliberated

on by national council. (As of October, 2011)

The product "F-02D" is declared to conform with the

essential requirements of European Union Directive

1999/5/EC Radio and Telecommunications Terminal

Equipment Directive 3.1(a), 3.1(b) and 3.2. The

Declaration of Conformity can be found on http://

www.fmworld.net/product/phone/doc/.

Declaration of Conformity

F-02D_EN_ninshou

129

Others

This mobile phone complies with the EU requirements

for exposure to radio waves.

Your mobile phone is a radio transceiver, designed and

manufactured not to exceed the SAR

limits

for

exposure to radio-frequency(RF) energy, which SAR

value, when tested for compliance against the

standard was 0.418 W/kg. While there may be

differences between the SAR

levels of various phones

and at various positions, they all meet

***

the EU

requirements for RF exposure.

* The exposure standard for mobile phones

employs a unit of measurement known as the

Specific Absorption Rate, or SAR.

** The SAR limit for mobile phones used by the

public is 2.0 watts/kilogram (W/Kg) averaged over

ten grams of tissue, recommended by The

Council of the European Union. The limit

incorporates a substantial margin of safety to

give additional protection for the public and to

account for any variations in measurements.

*** Tests for SAR have been conducted using

standard operation positions with the phone

transmitting at its highest certified power level in

all tested frequency bands. Although the SAR is

determined at the highest certified power level,

the actual SAR level of the phone while operating

can be well below the maximum value. This is

because the phone is designed to operate at

multiple power levels so as to use only the power

required to reach the network. In general, the

closer you are to a base station antenna, the

lower the power output.

･

This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions :

this device may not cause harmful interference, and

this device must accept any interference received,

including interference that may cause undesired

operation.

･

Changes or modifications made in or to the radio

phone, not expressly approved by the manufacturer,

will void the user's authority to operate the equipment.

This model phone meets the U.S. Government's

requirements for exposure to radio waves.

This model phone contains a radio transmitter and

receiver. This model phone is designed and manufactured

not to exceed the emission limits for exposure to radio

frequency (RF) energy as set by the FCC of the U.S.

Government. These limits are part of comprehensive

guidelines and establish permitted levels of RF energy for

the general population. The guidelines are based on

standards that were developed by independent scientific

organizations through periodic and thorough evaluation

of scientific studies.

The exposure standard for wireless mobile phones

employs a unit of measurement known as the Specific

Absorption Rate (SAR). The SAR limit set by the FCC is

1.6 W/kg. Tests for SAR are conducted using standard

operating positions as accepted by the FCC with the

phone transmitting at its highest certified power level

in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the

actual SAR level of the phone while operating can be

well below the maximum value. This is because the

phone is designed to operate at multiple power levels

so as to use only the power required to reach the

network. In general, the closer you are to a wireless

base station antenna, the lower the power output level

of the phone.

Federal Communications

Commission (FCC) Notice

FCC RF Exposure Information

F-02D_EN_ninshou

130

Others

Before a phone model is available for sale to the public,

it must be tested and certified to prove to the FCC that

it does not exceed the limit established by the U.S.

government-adopted requirement for safe exposure.

The tests are performed on position and locations (for

example, at the ear and worn on the body) as required

by FCC for each model. The highest SAR value for this

model phone as reported to the FCC, when tested for

use at the ear, is 0.542 W/kg, and when worn on the

body, is 0.519 W/kg. (Body-worn measurements differ

among phone models, depending upon available

accessories and FCC requirements).

While there may be differences between the SAR levels

of various phones and at various positions, they all

meet the U.S. government requirements.

The FCC has granted an Equipment Authorization for

this model phone with all reported SAR levels

evaluated as in compliance with the FCC RF exposure

guidelines. SAR information on this model phone is on

file with the FCC and can be found under the

Equipment Authorization Search section at http://

transition.fcc.gov/oet/ea/fccid/ (please search on FCC

ID VQK-F02D).

For body worn operation, this phone has been tested

and meets the FCC RF exposure guidelines when used

with an accessory designated for this product or when

used with an accessory that contains no metal and

which positions the handset at a minimum distance of

1.0 cm from the body.

In the United States, the SAR limit for wireless mobile phones

used by the general public is 1.6 Watts/kg (W/kg), averaged

over one gram of tissue. SAR values may vary depending upon

national reporting requirements and the network band.

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be determined

by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or

more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment

and receiver.

Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

F-02D_EN_ninshou

131

Others

AIRCRAFT

Switch off your wireless device when boarding an

aircraft or whenever you are instructed to do so by

airline staff. If your device offers flight mode or similar

feature consult airline staff as to whether it can be used

on board.

DRIVING

Full attention should be given to driving at all times

and local laws and regulations restricting the use of

wireless devices while driving must be observed.

HOSPITALS

Mobile phones should be switched off wherever you

are requested to do so in hospitals, clinics or health

care facilities. These requests are designed to prevent

possible interference with sensitive medical

equipment.

PETROL STATIONS

Obey all posted signs with respect to the use of

wireless devices or other radio equipment in locations

with flammable material and chemicals. Switch off

your wireless device whenever you are instructed to do

so by authorized staff.

INTERFERENCE

Care must be taken when using the phone in close

proximity to personal medical devices, such as

pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a

minimum separation of 15 cm be maintained between

a mobile phone and a pace maker to avoid potential

interference with the pacemaker. To achieve this use

the phone on the opposite ear to your pacemaker and

does not carry it in a breast pocket.

Hearing Aids

Some digital wireless phones may interfere with some

hearing aids. In the event of such interference, you

may want to consult your hearing aid manufacturer to

discuss alternatives.

For other Medical Devices :

Please consult your physician and the device

manufacturer to determine if operation of your phone

may interfere with the operation of your medical

device.

Important Safety Information

Appendix

Export Administration Regulations

This product and its accessories may be under

coverage of the Export Administration

Regulations of Japan ("Foreign Exchange and

Foreign Trade Control Laws" and the related laws

and regulations). And, they are also under

coverage of Export Administration Regulations of

the U.S. When exporting and reexporting this

product and its accessories, take necessary

procedures on your responsibility and expense.

For details, contact Ministry of Economy, Trade

and Industry of Japan or US Department of

Commerce.

F-02D_EN_ninshou

132

Others

Appendix

Intellectual Property Right

Except for the case protected by copyright laws such as

personal use, use of FOMA terminal to reproduce,

alter, or publicly transmit recorded pictures or sounds,

or copyrighted text, images, music or software

downloaded from websites without the copyright

holder's authorization is prohibited.

Note that taking photos or recordings at some

demonstrations, performances or exhibitions may be

prohibited even when only for personal use.

Avoid taking pictures of others with FOMA terminal

without their consent or disclosing recorded pictures

of others without their consent to general public

through Internet websites etc., because they may

infringe on portrait rights.

Company and product names mentioned in this

manual are trademarks or registered trademarks of

their respective holders.

･

"FOMA", "i-mode", "i-

ppli", "i-motion", "Deco-mail",

"Chara-den", "ToruCa", "mopera", "mopera U",

"WORLD CALL", "DCMX", "i-area", "WORLD WING",

"OFFICEED", "2in1", "docomo STYLE series" and

logos of "i-mode", "i-

ppli", "Music&Video Channel",

"iC" are trademarks or registered trademarks of NTT

DOCOMO.

･

"Catch Phone (Call waiting service)" is a registered

trademark of Nippon Telegraph and Telephone

Corporation.

･

McAfee

is registered trademarks or trademarks of

McAfee, Inc. and/or its affiliates in the US and/or

other countries.

･

Rovi, G-GUIDE, G-GUIDE MOBILE and G-

Guide related logos are trademarks or

registered trademarks of Rovi Corporation and/or its

subsidiaries in Japan.

･

Contains Adobe

Flash

Player, Adobe

Flash

Lite

and Adobe Reader

Mobile

technology by Adobe Systems Incorporated. Adobe

Flash Player Copyright

1996-2011 Adobe Systems

2003-2011 Adobe Systems

Mobile Copyright

1993-2011 Adobe Systems

Reader, Flash and Flash Lite are either registered

trademarks or trademarks of Adobe Systems

Incorporated in the United States and/or other

countries.

･

This product contains

NetFront Browser,

NetFront Document

Viewer and NetFront Sync Client of ACCESS CO.,

LTD.

ACCESS, the ACCESS logo and NetFront are

registered trademarks or trademarks of ACCESS

CO., LTD. in the United States, Japan and/or other

countries.

2011 ACCESS CO., LTD. All rights

reserved.

･

™

JBlend and JBlend-related trademarks are

trademarks or registered trademarks of Aplix

Corporation in Japan and other countries.

･

is a registered trademark of FeliCa Networks, Inc.

･

FeliCa is a registered trademark of Sony Corporation.

･

QR code is a registered trademark of Denso Wave

Inc.

･

microSDHC Logo is a trademark of SD-3C,

LLC.

Copyrights and portrait

rights

Trademarks

F-02D_EN_ninshou

133

Others

･

"Multitask" is a registered trademark of NEC

Corporation.

･

QuickTime is a registered trademark of Apple Inc., in

the US and other countries.

･

Microsoft

, Windows

, Windows Media

, Windows

Vista

and PowerPoint

are trademarks or

registered trademarks of "Microsoft Corporation" in

the US and other countries.

･

Microsoft Excel and Microsoft Word are product

names of Microsoft Corporation in the U.S.A. In this

manual, they may be described as Excel and Word.

･

The abbreviations of operating systems (Japanese

versions) below are used in this manual.

- Windows 7 stands for Microsoft

Windows

(Starter, Home Basic, Home Premium,

Professional, Enterprise and Ultimate).

- Windows Vista stands for Windows Vista

(Home

Basic, Home Premium, Business, Enterprise and

Ultimate).

- Windows XP indicates the Microsoft

Windows

XP Professional operating system or Microsoft

Windows

XP Home Edition operating system.

･

Google and Google Map for Mobile are trademarks

of Google Inc.

･

The Bluetooth word mark and logos are owned by

the Bluetooth SIG, INC. and any use of such marks by

NTT DOCOMO, INC. is under license. Other

trademarks and names are those of their respective

owners.

･

"CROSS YOU" is a trademark of Sony Corporation.

･

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol are

trademarks of Dolby Laboratories.

･

iWnn of OMRON SOFTWARE Co., Ltd. is used for

conversion methods for Japanese language, and for

phrase prediction methods for English.

iWnn

OMRON SOFTWARE Co., Ltd. 2008-2011 All

Rights Reserved.

･

"AXIS Font" is a trademark of AXIS Inc.,

and the "AXIS" font is a font developed by Type

Project Inc.

･

This product contains software licensed by Symbian

Foundation Limited.

Symbian is a registered trademark of Symbian

Foundation Limited.

･

"Privacy mode" is a registered trademark of FUJITSU

LIMITED.

･

"Uni-Type" is a universal designed font jointly-

developed by LIM Corp., Ltd. and Faculty of

Engineering, Chiba University.

Uni-Type is a registered trademark of LIM Corp., Ltd.

･

丸ゴシック

(Maru Gothic)", "

レイミン

(Reimin)" and

丸フォーク

(Maru Fork)" are provided by Morisawa

& Company, Ltd. and the copyrights of these font

data belong to them. Names of "

レイミン

(Reimin)"

and "

丸フォーク

(Maru Fork)" are their trademarks.

･

Wi-Fi

, Wi-Fi Alliance

, and logos of Wi-Fi and Wi-Fi

CERTIFIED are registered trademarks of Wi-Fi

Alliance.

･

Wi-Fi CERTIFIED

™

, WPA

™

, WPA2

™

and Wi-Fi

Protected Setup

™

are trademarks of Wi-Fi Alliance.

･

AOSS

™

is a trademark of BUFFALO INC.

･

DLNA

, the DLNA Logo and DNLA

CERTIFIED

™

are trademarks, service marks, or

certification marks of the Digital Living Network

Alliance.

･

OBEX

™

, IrSimple

™

, IrSS

™

and

IrSimpleShot

™

are trademarks of Infrared

Data Association

･

Blu-ray Disc and its logo are trademarks.

･

HDMI, HDMI logo and

High-Definition

Multimedia Interface are

trademarks and registered trademarks of HDMI

Licensing, LLC.

･

DVM

™

is a trademark of microphone

directionality control technology of

DiMAGIC (DiMAGIC Co., Ltd.).

･

くーまん

" is a trademark of Dora communications

CO.,LTD.

･

Other company and product names mentioned in

this manual are trademarks or registered trademarks

of their respective holders.

F-02D_EN_ninshou

134

Others

･

This product contains a module developed by the

Independent JPEG Group.

･

FeliCa is a contactless IC card technology developed

by Sony Corporation.

･

OMRON Corporation's Mobile OmCR is used for a

character recognition engine.

･

This product contains software licensed based on

Apache License V2.0. and altered as necessary by

NTT DOCOMO, INC.

This product contains software licensed complying

with GNU Lesser General Public License (LGPL),

Eclipse Public License (EPL), etc.

For more details, on the FOMA terminal,

⇒

6#1

⇒

その他

(Others)" to see in "

オープ

ンソースライセンス

(Open source license)".

The source code of the used open source software is

disclosed according to the rules of LGPL (http://

www.gnu.org/licenses/). For more details, refer to

the information on this product in the following site.

http://www.fmworld.net/product/phone/fp/sb/

develop/

･

This product is licensed based on MPEG-4 Visual

Patent Portfolio License. The use of MPEG-4 Video

Codec function is allowed for personal and nonprofit

use only in the cases below.

- Recording moving pictures and i-motion that

conform to MPEG-4 Visual Standard (hereinafter

referred to as MPEG-4 Video)

- Playing MPEG-4 Videos recorded personally by

consumers not engaged in profit activities

- Playing MPEG-4 Video supplied from the provider

licensed from MPEG-LA

For further utilizing such as promotion, in-house

use or profit-making business, please contact

MPEG LA, LLC in U.S.

･

Content owners use Windows Media digital rights

management technology (WMDRM) to protect their

intellectual property, including copyrights. This

device uses WMDRM software to access WMDRM-

protected content. If the WMDRM software fails to

protect the content, content owners may ask

Microsoft to revoke the software's ability to use

WMDRM to play or copy protected content.

Revocation does not affect unprotected content.

When downloading licenses for protected content,

you agree that Microsoft may include a "Revocation

List" with the licenses. Content owners may require

you to upgrade WMDRM to access their content. If

you decline an upgrade, you cannot access a content

that requires the upgrade.

･

The HMM-Based Speech Synthesis Engine

embedded in this product uses the Simplified BSD

License.

--------------------------------------------

The HMM-Based Speech Synthesis System (HTS)

hts_engine API developed by HTS Working Group

http://hts-engine.sourceforge.net/

--------------------------------------------

2001-2010 Nagoya Institute of

Technology, Department of Computer Science

2001-2008 Tokyo Institute of Technology,

Interdisciplinary Graduate School of Science and

Engineering

Redistribution and use in source and binary forms,

with or without modification, are permitted provided

that the following conditions are met:

- Redistributions of source code must retain the

above copyright notice, this list of conditions and

the following disclaimer.

- Redistributions in binary form must reproduce the

above copyright notice, this list of conditions and

the following disclaimer in the documentation and/

or other materials provided with the distribution.

- Neither the name of the HTS working group nor the

names of its contributors may be used to endorse

or promote products derived from this software

without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT

HOLDERS AND CONTRIBUTORS "AS IS" AND ANY

EXPRESS OR IMPLIED WARRANTIES, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A

Others

F-02D_EN_ninshou

135

Others

PARTICULAR PURPOSE ARE DISCLAIMED. IN NO

EVENT SHALL THE COPYRIGHT OWNER OR

CONTRIBUTORS BE LIABLE FOR ANY DIRECT,

INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR

CONSEQUENTIAL DAMAGES (INCLUDING, BUT

NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE

GOODS OR SERVICES; LOSS OF USE, DATA, OR

PROFITS; OR BUSINESS INTERRUPTION)

HOWEVER CAUSED AND ON ANY THEORY OF

LIABILITY, WHETHER IN CONTRACT, STRICT

LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR

OTHERWISE) ARISING IN ANY WAY OUT OF THE

USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGE.

･

Attached

電子辞書データ

DVD (Electronic dictionary

data DVD) (Sample) contains following dictionary

data (27 dictionaries

＋

6 searches by category).

岩波書店

(Iwanami Shoten, Publishers)>

広辞苑

第六版

DVD-ROM

版

分野別検索（慣用句・漢

字・人名・地名・作品名・季語）（新村出編）

(KOJIEN 6th

edition, DVD-ROM version + 6-category search)

研究社

(KENKYUSYA)>

リーダーズ英和辞典

第

版（松田徳一郎編）

(Reader's

English-Japanese dictionary 2nd edition)

新和英中辞典

第

版（

Martin Collick

、

David P.

Dutcher

、田辺宗一、金子稔編）

(New Japanese-

English-Chinese dictionary 5th edition)

自由国民社

(Jiyukokuminsya)>

現代用語の基礎知識

2011

年版（自由国民社編）

(Basic

knowledge of modern term for 2011)

大修館書店

(Daisyukan Shoten)>

新漢語林

（鎌田正、米山寅太郎著）

(New Chinese

origin words MX)

みんなで国語辞典

あふれる新語（北原保雄編著／

「もっと明鏡」委員会編集）

(Minna de Kokugo jiten

Afureru shingo)

式日本語（北原保雄編著／「もっと明鏡」委員会編

集）

(KY style Japanese)

問題な日本語（北原保雄編（北原保雄、小林賢次、砂

川有里子、鳥飼浩二、矢澤真人執筆））

(Problematic

Japanese)

築地魚河岸ことばの話（生田與克、冨岡一成著）

(TSUKIJI fish market word stories)

三省堂

(SANSEIDO)>

デイリー日仏英・仏日英辞典（村松定史監修／三省堂

編修所編）

(Daily Japanese-French-English/French-

Japanese-English dictionary)

デイリー日独英・独日英辞典（渡辺学監修／三省堂編

修所編）

(Daily Japanese-German-English/German-

Japanese-English dictionary)

デイリー日中英・中日英辞典（池田巧監修／三省堂編

修所編）

(Daily Japanese-Chinese-English/Chinese-

Japanese-English dictionary)

デイリー日西英・西日英辞典（上田博人、アントニ

オ・ルイズ・ティノコ監修／三省堂編修所編）

(Daily

Japanese-Spanish-English/Spanish-Japanese-

English dictionary)

デイリー日伊英・伊日英辞典（藤村昌昭監修／三省堂

編修所編）

(Daily Japanese-Italian-English/Italian-

Japanese-English dictionary)

デイリー日韓英・韓日英辞典（福井玲・尹亭仁監修／

三省堂編修所編）

(Daily Japanese-Korean-English/

Korean-Japanese-English dictionary)

デイリー日仏英

か国語会話辞典（村松定史監修／三

省堂編修所編）

(Daily Japanese-French-English

conversation dictionary)

デイリー日独英

か国語会話辞典（渡辺学監修／三省

堂編修所編）

(Daily Japanese-German-English

conversation dictionary)

デイリー日中英

か国語会話辞典（池田巧・胡興智監

修／三省堂編修所編）

(Daily Japanese-Chinese-

English conversation dictionary)

デイリー日西英

か国語会話辞典（山村ひろみ監修／

三省堂編修所編）

(Daily Japanese-Spanish-English

conversation dictionary)

デイリー日伊英

か国語会話辞典（藤村昌昭監修／三

省堂編修所編）

(Daily Japanese-Italian-English

conversation dictionary)

デイリー日韓英

か国語会話辞典（尹亭仁監修／三省

堂編修所編）

(Daily Japanese-Korean-English

conversation dictionary)

International call access code

for the country you stay

Repairs

General Inquiries

Failures encountered overseas

Loss or theft of FOMA terminal or payment of cumulative cost overseas

* Service available in: English, Portuguese, Chinese, Spanish, Korean.

* Unavailable from part of IP phones.

(Business hours : 9:00 a.m. to 8:00 p.m. (open all year round))

0120-005-250 (toll free)

(Business hours : 9:00 a.m. to 8:00 p.m.)

* Unavailable from part of IP phones.

■

From land-line phones (In Japanese only)

0120-800-000 (toll free)

* Unavailable from land-line phones, etc.

(No prefix) 151 (toll free)

■

From DOCOMO mobile phones (In Japanese only)

●

Please confirm the phone number before you dial.

●

For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo

shop etc. near you on the NTT DOCOMO website or the i-mode site.

(available 24 hours a day)

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※

If you use F-02D, you should dial the number 㧗81-3-6832-6600

(to enter '㧗', press and hold the '0' key for at least one second).

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※

If you use F-02D, you should dial the number 㧗81-3-6718-1414

(to enter '㧗', press and hold the '0' key for at least one second).

■

From land-line phones <Universal number>

●

If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.

●

If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.

* You might be charged a domestic call fee according to the call rate for the country

you stay.

※

For international call access codes for major countries and universal number

international prefix, refer to DOCOMO International Services website.

Universal number

international prefix -8000120-0151

CA92002-7682

2011.10 (1st Edition)

To prevent damage to the environment, bring

used battery packs to a docomo service counter,

a docomo agent or a recycle center.

-81-3-6832-6600

(toll free)

(Business hours : 24 hours (open all year round))

* Unavailable from part of IP phones.

■

From land-line phones (In Japanese only)

0120-800-000 (toll free)

* Unavailable from land-line phones, etc.

(No prefix) 113 (toll free)

■

From DOCOMO mobile phones (In Japanese only)

■

From land-line phones <Universal number>

* You might be charged a domestic call fee according to the call rate for the country

you stay.

※

For international call access codes for major countries and universal number

international prefix, refer to DOCOMO International Services website.

Universal number

international prefix -8005931-8600

NTT DOCOMO website http://www.nttdocomo.co.jp/english/

■

From DOCOMO mobile phones

i-mode site iMenu

⇒お客様サポート

(user support)

⇒ドコモショップ

(docomo Shop) * In Japanese only

International call access code

for the country you stay

(available 24 hours a day)

-81-3-6718-1414

(toll free)

■

From DOCOMO mobile phones

Don't forget your mobile phone ･･･ or your manners!

When using your mobile phone in a public place, don't forget to

show common courtesy and consideration for others around you.

Fujitsu F02D Mobile phone User Manual manual part 2

Fujitsu Limited Mobile phone manual part 2

Contents

manual part 2

Navigation menu

Namespaces

Views

Navigation
