manual part 4
![](/img.php?id=1231109&img=bg1.png)
F-04B_E1kou
24
Basic Operation
Before Using
Battery level
Battery level is always displayed on the display, but you can check
it by menu operation etc.
Display unit
ameh
LifeKit
eg
Clock & Other
ee
Info &
Reset
ed
Battery level
Keypad unit
ameh
LifeKit
ei
Keypad unit
ec
Remaining
keypad power
In separated style, while pressing
X
on QWERTY keypad,
press
b
. You can check it by the color of arch light.
Point
・
When FOMA terminal turns ON and the units are joined, if battery level of
either unit becomes 1 and the other unit is in battery level 3, power
feeding is executed automatically (interunit power feeding). A message
appears at the start of power feeding and the power feeding ends when
battery levels of both units become same.
Indication
Display unit
Keypad unit
Sounding by menu
operation
3 times Twice Once
Arch light
Green Yellow Red
Ample charge Almost exhausted
(Charge the battery)
Before Using
Turning power ON - Configuring default setting
Perform the following operations after turning the power ON for the first time.
a
On numeric keypad,
f
(2 sec. or
more) or on front keypad,
i
(2 sec.
or more)
b
"Yes" or "No" on a confirmation
screen of enlarged menu setting
The screen shown to the right appears.
c
Set required items
eC
[Complete]
Always set Password and Request permit/
deny. If you exit without setting, Initial
setting screen reappears when the power
is turned ON the next time.
d
g
on a confirmation screen of software update
function
The stand-by display appears.
Point
・
When FOMA terminal turn ON with the units joined, after initial settings,
keypad unit is automatically registered as Bluetooth device and
appears on the display.
・
In separated style, you can turn on or off the power per unit. However,
when the power is turned off by pressing front key or
i
while
connecting to Bluetooth, the power of keypad unit also turns off.
・
If no operation is performed, the display light is turned off automatically
according to the settings in Light time-out or Power saving mode. The
display light turns on again if there is any operation or incoming call.
Turning the power off :
On numeric keypad,
f
(2 sec. or more) or on
front keypad,
i
(2 sec. or more)
Changing initial settings :
mehgeg
Changing screen display to English :
mehbfce
Select "English"
<Initial setting screen>
![](/img.php?id=1231109&img=bg2.png)
F-04B_E1kou
25
Basic Operation
Before Using
Motion sensor
You can operate FOMA terminal by double-tapping (tapping it
twice) or tilting it.
✜
Stopping alarm sound
While alarm is sounding with FOMA terminal closed, double-tapping
the front or back side stops the sound. The alarm stops or starts
snooze.
✜
Auto rotation
In basic style or separated style, vertical and horizontal display, or
vertical/horizontal orientation or size of images (JPEG format)
switches according to the tilt of FOMA terminal or display unit.
✜
Auto switching of still images
When saving a shot still image, Sense orientation is executed and
vertically long/horizontally long or up side/down side switches
according to the tilt of the FOMA terminal.
✜
Scrolling Browser screen
By tilting FOMA terminal while pressing
Z
, the screen can be scrolled
up/down/right/left/slantwise. Scrolling speed becomes faster as the
FOMA terminal is tilted greatly.
✜
Varying Flash images
Motion sensor compatible Flash image which is set to stand-by
display varies according to the tilt of FOMA terminal.
・
You can disable Motion sensor, or select Valid/Invalid for each function.
【 モーションセンサー設定
(Setting Motion sensor)
】
Information
Before Using
User information
You can check your own phone number.
For details of checking/changing a mail address, refer to "Mobile
Phone User's Guide [i-mode] FOMA version".
ame0
User information
The screen shown to the right appears.
Point
Editing user information :
On User information edit screen,
Ce
Authenticate
e
Edit
eC
Checking a phone number during a call :
se0
<User information
screen>
![](/img.php?id=1231109&img=bg3.png)
F-04B_E1kou
26
Basic Operation
Screen Explanation
Viewing display
The current state can be checked by the icon appearing on the display. Major icons are as follows.
:
Battery level (Battery icon)
Signal strength (Antenna icon)
:
Self mode ON
:
In data transfer mode
:
Connecting to i-mode
:
Infrared communication in operation
:
Bluetooth ON
:
The total calls cost exceeds the limit
:
Bluetooth connection being
established
:
Communication using handsfree-
compatible device in progress
:
Handsfree ON
:
Femtocell setting available
:
Power saving mode activated
:
Positioning with GPS
:
Location request setting
:
Displaying SSL/TLS page etc.
:
Auto-send mail exists
:
A phonebook entry or schedule has
secret attribute
:
High-pitched alarm ON
:
Kid-safe mode ON
:
Unread Area Mail exists
:
Unread i-mode mail exists
:
Arrival i-concier information exists
:
Unreceived i-mode mail exists in i-
mode Center
:
During i-
α
ppli operation
:
i-
α
ppli call received
:
Interunit communication status
:
Alarm clock ON
:
Schedule reminder ON
:
Inside OFFICEED area
Top of the display
Strong Out of service area or where
radio waves do not reach
Weak
Arrival information (Starting from the left,
missed call, recorded message, voice mail
service, unread message, unread ToruCa,
i-
α
ppli call)
:
Silent mode ON
:
Call alert volume OFF
:
Vibrator for voice call ON
:
In Public mode (Drive mode)
:
Record message ON
:
Keypad dial lock ON
:
GPS Location request failed
:
Personal data lock ON
:
Music&Video Channel program
obtaining failure
:
Reading UIM
:
IC card lock ON
:
Available multi-cursor key
:
Recording 1Seg
:
i-
α
ppli Auto start failed
:
microSD card installed during
Communication mode
:
Connected to external device using
USB cable
:
Pedometer/ACT monitor is set
:
Software update rewrite notice
:
Auto-update of latest pattern definition
failure
Bottom of the display
![](/img.php?id=1231109&img=bg4.png)
F-04B_E1kou
27
Basic Operation
Task area
The icon indicating the
function (task) in progress
appears in the task area.
Guide area and key operation
Operations that can be performed by
pressing
m
,
I
,
g
,
C
and
a
are displayed in the guide area.
To perform an operation in the guide
area, press the corresponding key.
on the guide area corresponds to
multi-cursor keys
k
.
<Vertical display>
Task area
<Horizontal display>
Guide area
Screen Explanation
Status in separated style
In separated style, you can check the status of FOMA terminal by
indicator on the display or indicator light of keypad unit.
✜
Display
In addition to battery level of keypad unit (
⇒
P24), available functions
for keypad unit are displayed.
:
Only phone call available
:
Only key operation available
:
Phone call and key operation available
✜
Bluetooth light blink
Blue :
Connected to Bluetooth
Red :
Disconnected from Bluetooth
Yellow :
QWERTY keypad locked
✜
Arch light blink
Red purple :
Unit search activated
Ye l l o w
→
Green :
Game mode activated
Light blue
→
Blue
→
Purple :
Game mode ended
Red :
Display unit battery almost runs down
In addition, arch light turns on or blinks in conjunction with indicator
light of display for phone call or mail receiving.
![](/img.php?id=1231109&img=bg5.png)
F-04B_E1kou
28
Basic Operation
Screen Explanation
Menu operation
On the stand-by display, press
m
and then perform the
functions from the menu. You can select a menu item with
shortcut operations, which use the keypad,
*
and
#
, or with
multi-cursor operation, which uses the multi-cursor key to move
the cursor.
<Example> Selecting "Calculator"
Shortcut operations
ame7e4
Multi-cursor key operations
ame
Move the cursor to "
g
Accessory"
eg
[Select]
e
Move the cursor to "
d
Calculator"
eg
[Select]
Point
・
Even when a function is running, you can perform the same operation if
"MENU" is displayed on the guide area.
・
To return to the previous screen, press
c
. To return to the stand-by
display, press
f
.
・
On the stand-by display with Info/calendar layout, Shortcut icons set, or
with arrival information icon or i-concier information displayed, press
g
to change the display to Focus mode that allows you to quickly display the
related information.
You can switch among "Kisekae menu", the design of which can be
changed using Kisekae Tool (
⇒
P44), "Basic menu", which has the
fixed menu numbers, and "Custom menu", to which menu items
can be saved freely.
A Kisekae menu matched with the color of FOMA terminal is set by
default.
Point
・
In some types of Kisekae menus, the menu structure is changed according
to usage frequency, or the number assigned to menu item (item number)
may not be applicable.
・
The menu that appears when
m
is pressed on the stand-by display can
be changed from Select startup menu.
⇒
P40
m 7 4
Switching menu screens
<Custom menu><Kisekae menu>
<Basic menu>
IC
![](/img.php?id=1231109&img=bg6.png)
F-04B_E1kou
29
Basic Operation
Screen Explanation
Using touch panel
You can use the display as touch panel. You can perform the same
operation by touch operation as on the screen to move the cursor
with key operation. Major touch operations are as follows.
Types of touch operations
Touch
Touch the display lightly once and release the finger. The
operation becomes effective when you release your finger
from the display. This operation is mainly for selecting
menus, items, etc.
Double-
touch
Touch the display lightly twice and release the finger. The
operation becomes effective when you release your finger
from the display. This operation is mainly for zooming in/
out or switching the display.
Slide
Keep touching the display, move your finger up, down,
right or left. This operation is for scrolling a screen,
rewinding/fast-forwarding a video, etc.
Slide
quickly
Touch the display lightly and flick your finger up, down,
right or left. This operation is for switching pages or
images, or moving to a different chapter or tune, etc.
e.g.: Slidee.g.: Touch
Touch-specific operations
Function selection from the
stand-by display
Use stand-by touch buttons (4
buttons at the bottom of the
screen) and stand-by launcher
(shown to the lower right).
Guidance button
Return to the previous screen
(
a
), exit a function (
b
), or
operate a function displayed in
the guide area (
c
).
Menu buttons for touch
operation
Buttons that correspond to a
function are displayed.
Moving focus and selecting
menu/item
Touch a menu or item to select,
move the focus for touch
operation, then touch the menu
or item again.
ab
c
Menu button for touch operation
e.g. : Outgoing call screen e.g. : My document
Slide on the list Touch an item
directly
![](/img.php?id=1231109&img=bg7.png)
F-04B_E1kou
30
Basic Operation
Link items or confirmation
screens
Directly touch an item.
Numeric value setting roller
Set numeric values
such as date and
time, rotate the roller
by slide operation.
Direction/Determination button
When using i-mode browser in
flip style, use the direction/
determination button to operate
menus or items on the screen.
Channel switch panel/Volume
adjust panel/Slider
While playing 1Seg or a moving
picture, slide vertically or
horizontally to display a panel,
and then touch or slide.
Touch or slide the slider to adjust
a value.
Switching tabs and scrolling
Switch tabs of phonebook etc. or
scroll by sliding.
Temporary zooming
In mail or Full Browser function
etc., double-touch the screen to
zoom in.
仮
仮
Screen Explanation
使いかたガイド
(Guide)
You can check overviews and operations of functions, and
troubleshooting. (In Japanese only)
amef
LifeKit
e0
Guide
e
Select
a search method
目次
(Contents) :
Search from a list of
functions.
索引
(Index) :
Search from a list of words
sorted according to Japanese syllabary.
フリーワード検索
(Free word search) :
Enter a keyword to search for.
ブックマーク
(Bookmark) :
Search from a
list of registered bookmarks.
困ったときには
(Troubleshooting) :
Search from lists of
troubles or error messages.
Point
・
On a description screen, select "
この機能を使う
(Use this function)" to
perform a function. Selecting a link item in "
関連機能
(Related functions)",
or "
→コチラ
(See more)" displays a corresponding description screen.
・
Terms indicated with
【】
in this manual are index terms in "Guide".
・
You can also access
フリーワード検索
from Quick search.
⇒
P121
<Guide screen>
Information
![](/img.php?id=1231109&img=bg8.png)
F-04B_E1kou
31
Basic Operation
You can notify your phone number (caller ID) to the other party's
terminal when making a voice call.
ameh
Settings&NWservices
eh
NW Services
e
d
Caller ID
ea
Caller ID notification
ea
Activate/
Deactivate
ea
Notify
Select "
b
Not notify" if you do not want to notify.
Point
・
Caller ID is your important personal information. Carefully consider
whether you want to include caller ID information when making a call.
・
If an announcement of requesting caller ID is heard when making a call,
make a call again after setting your caller ID to "Notify".
Caller ID notification
(Default : Notify)
![](/img.php?id=1231109&img=bg9.png)
F-04B_E1kou
156
Others
Appendix
Specific absorption rate (SAR) of mobile phone
This model phone FOMA F-04B meets the MIC's
*1
technical regulation
governing exposure to radio waves.
The technical regulation established permitted levels of radio frequency
energy, based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies.
The regulation employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)
*2
averaged
over 10 grams of tissue. The limit includes a substantial safety margin designed
to assure the safety of all persons, regardless of age and health. The value of
the limit is equal to the international guidelines recommended by ICNIRP.
*3
All phone models should be confirmed to comply with the regulation, before
they are available for sale to the public. The highest SAR value for this FOMA
F-04B is 1.440 W/kg. It was taken by the Telecom Engineering Center (TELEC).
The test for SAR was conducted according to the MIC testing procedure using
standard operating positions with the phone transmitting at its highest
permitted power level in all tested frequency bands. While there may be
differences between the SAR levels of various phones and at various positions,
they all meet the MIC's technical regulation. Although the SAR is determined at
the highest certified power level, the actual SAR of the phone during operation
can be well below the maximum value.
For further information about SAR, please see the websites below.
World Health Organization (WHO) :
http://www.who.int/peh-emf/
ICNIRP :
http://www.icnirp.de/
MIC :
http://www.tele.soumu.go.jp/e/ele/body/index.htm
TELEC :
http://www.telec.or.jp/ENG/Index_e.htm
NTT DOCOMO :
http://www.nttdocomo.co.jp/english/product/
FUJITSU LIMITED :
http://www.fmworld.net/product/phone/sar/
*1
Ministry of Internal Affairs and Communications.
*2
The technical regulation is provided in Article 14-2 of the Ministry Ordinance
Regulating Radio Equipment.
*3
International Commission on Non-Ionizing Radiation Protection.
The product "F-04B" is declared to conform with the essential requirements of
European Union Directive 1999/5/EC Radio and Telecommunications Terminal
Equipment Directive 3.1(a), 3.1(b) and 3.2. The Declaration of Conformity can
be found on http://www.fmworld.net/product/phone/doc/.
This mobile phone complies with the EU requirements for exposure to radio
waves.
Your mobile phone is a radio transceiver, designed and manufactured not to
exceed the SAR
*
limits
**
for exposure to radio-frequency(RF) energy, which
SAR
*
value, when tested for compliance against the standard was 1.26 W/Kg.
While there may be differences between the SAR
*
levels of various phones and
at various positions, they all meet
***
the EU requirements for RF exposure.
* The exposure standard for mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR.
** The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/
Kg) averaged over ten grams of tissue, recommended by The Council of the
European Union. The limit incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
*** Tests for SAR have been conducted using standard operation positions with
the phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a base station antenna, the lower the
power output.
Declaration of Conformity
![](/img.php?id=1231109&img=bga.png)
F-04B_E1kou
157
Others
・
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions :
a
this device may not cause harmful interference, and
b
this device must accept any interference received, including interference
that may cause undesired operation.
・
Changes or modifications made in or to the radio phone, not expressly
approved by the manufacturer, will void the user's authority to operate the
equipment.
This model phone meets the U.S. Government's requirements for exposure to
radio waves.
This model phone contains a radio transmitter and receiver. This model phone
is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy as set by the FCC of the U.S. Government. These
limits are part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate (SAR). The SAR limit set
by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating
positions as accepted by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless
base station antenna, the lower the power output level of the phone.
Before a phone model is available for sale to the public, it must be tested and
certified to prove to the FCC that it does not exceed the limit established by the
U.S. government-adopted requirement for safe exposure. The tests are
performed on position and locations (for example, at the ear and worn on the
body) as required by FCC for each model. The highest SAR value for this model
phone as reported to the FCC, when tested for use at the ear, is 0.978 W/kg, and
when worn on the body, is 0.147 W/kg. (Body-worn measurements differ
among phone models, depending upon available accessories and FCC
requirements).
While there may be differences between the SAR levels of various phones and
at various positions, they all meet the U.S. government requirements.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on file with the FCC and
can be found under the Equipment Authorization Search section at http://
www.fcc.gov/oet/ea/fccid/ (please search on FCC ID VQK-F04B).
For body worn operation, this phone has been tested and meets the FCC RF
exposure guidelines when used with an accessory designated for this product
or when used with an accessory that contains no metal and which positions the
handset at a minimum distance of 1.5 cm from the body.
*
In the United States, the SAR limit for wireless mobile phones used by the general public
is 1.6 Watts/kg (W/kg), averaged over one gram of tissue. SAR values may vary
depending upon national reporting requirements and the network band.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation.
Federal Communications Commission (FCC)
Notice
FCC RF Exposure Information
![](/img.php?id=1231109&img=bgb.png)
F-04B_E1kou
158
Others
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
AIRCRAFT
Switch off your wireless device when boarding an aircraft or whenever you are
instructed to do so by airline staff. If your device offers flight mode or similar
feature consult airline staff as to whether it can be used on board.
DRIVING
Full attention should be given to driving at all times and local laws and
regulations restricting the use of wireless devices while driving must be
observed.
HOSPITALS
Mobile phones should be switched off wherever you are requested to do so in
hospitals, clinics or health care facilities. These requests are designed to
prevent possible interference with sensitive medical equipment.
PETROL STATIONS
Obey all posted signs with respect to the use of wireless devices or other radio
equipment in locations with flammable material and chemicals. Switch off your
wireless device whenever you are instructed to do so by authorized staff.
INTERFERENCE
Care must be taken when using the phone in close proximity to personal
medical devices, such as pacemakers and hearing aids.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 15 cm be
maintained between a mobile phone and a pace maker to avoid potential
interference with the pacemaker. To achieve this use the phone on the opposite
ear to your pacemaker and does not carry it in a breast pocket.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
For other Medical Devices :
Please consult your physician and the device manufacturer to determine if
operation of your phone may interfere with the operation of your medical
device.
Important Safety Information
![](/img.php?id=1231109&img=bgc.png)
F-04B_E1kou
159
Others
Appendix
Export Administration Regulations
This product and its accessories may be under coverage of the Export
Administration Regulations of Japan ("Foreign Exchange and Foreign Trade
Control Laws" and the related laws and regulations). And, they are also under
coverage of Export Administration Regulations of the U.S. When exporting
and reexporting this product and its accessories, take necessary procedures
on your responsibility and expense. For details, contact Ministry of Economy,
Trade and Industry of Japan or US Department of Commerce.
Appendix
Intellectual Property Right
Except for the case protected by copyright laws such as personal use, use of
FOMA terminal to reproduce, alter, or publicly transmit recorded pictures or
sounds, or copyrighted text, images, music or software downloaded from
websites without the copyright holder's authorization is prohibited.
Note that taking photos or recordings at some demonstrations, performances
or exhibitions may be prohibited even when only for personal use.
Avoid taking pictures of others with FOMA terminal without their consent or
disclosing recorded pictures of others without their consent to general public
through Internet websites etc., because they may infringe on portrait rights.
Company and product names mentioned in this manual are trademarks or
registered trademarks of their respective holders.
・
"FOMA", "i-motion", "i-mode", "i-
α
ppli", "mopera", "WORLD CALL", "WORLD
WING", "Deco-mail", "Chara-den", "i-Channel", "Dual Network", "Security
Scan", "Public mode", "ToruCa", "2in1", "DCMX", "OFFICEED", "docomo
PRIME series" and logos of "FOMA", "i-mode", "i-
α
ppli", "Music&Video
Channel" are trademarks or registered trademarks of NTT DOCOMO.
・
Microsoft
®
, Windows
®
, Windows Vista
®
, Windows 7
™
, Windows Media
™
and PowerPoint
™
are trademarks or registered trademarks of "Microsoft
Corporation" in the US and other countries.
・
Microsoft Excel and Microsoft Word are product names of Microsoft
Corporation in the U.S.A. In this manual, they may be described as Excel and
Word.
・
"Multitask" is a registered trademark of NEC Corporation.
・
"Catch Phone (Call Waiting Service)" is a registered trademark of Nippon
Telegraph and Telephone Corporation.
・
Free Dial logo mark is a registered trademark of NTT Communications
Corporation.
・
Java and all Java-related trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the US and other countries.
Copyrights and portrait rights
Trademarks
![](/img.php?id=1231109&img=bgd.png)
F-04B_E1kou
160
Others
・
This product contains NetFront Browser,
NetFront Sync Client of ACCESS CO., LTD.
ACCESS, the ACCESS logo and NetFront are registered trademarks or
trademarks of ACCESS CO., LTD. in the United States, Japan and/or other
countries.
Copyright
©
2009 ACCESS CO., LTD. All rights reserved.
・
Powered by JBlend
™
Copyright 2002-2009 Aplix Corporation. All
rights reserved.
JBlend and JBlend-related trademarks are trademarks or registered
trademarks of Aplix Corporation in Japan and other countries.
・
This product contains Adobe
®
Flash
®
Lite
®
and Adobe Reader
®
LE
technology of Adobe Systems Incorporated.
Adobe Flash Lite Copyright
©
2003-2009 Adobe Systems Incorporated. All
rights reserved.
Adobe Reader Mobile Copyright
©
1993-2009 Adobe Systems Incorporated.
All rights reserved.
Adobe, Adobe Reader, Flash and Flash Lite are either
registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
・
QR code is a registered trademark of Denso Wave Inc.
・
microSDHC Logo is a trademark.
・
FeliCa is a registered trademark of Sony Corporation.
・
"CROSS YOU" is a trademark of Sony Corporation.
・
is a registered trademark of FeliCa Networks, Inc.
・
Word, Excel and PowerPoint file display technologies
are powered by Picsel Technologies.
Picsel, Picsel File Viewer and the Picsel cube logo are trademarks or
registered trademarks of Picsel Technologies.
・
McAfee
®
is registered trademarks or trademarks of McAfee, Inc. and/or its
affiliates in the US and/or other countries.
・
G-GUIDE, G-GUIDE MOBILE and their logos are registered
trademarks in Japan of U.S. Gemstar-TV Guide International, Inc.
and/or its affiliates.
・
QuickTime is a registered trademark of Apple Inc. in the US and other
countries.
・
ATOK + APOT of Justsystem Corporation is installed in this product as
Japanese character conversion function.
"ATOK" "APOT (Advanced Prediction Optimization Technology)" are
registered trademarks of Justsystem Corporation.
・
T9
®
is a trademark or registered trademark of Nuance
Communications, Inc. in US and of Nuance corporations in other
countries.
・
This equipment is provided with the software licensed by Symbian Software
Ltd. or the licensor
©
1998-2009. and Symbian OS are trademarks of
Symbian Ltd. or the licensor.
・
"Privacy mode" is a registered trademark of FUJITSU LIMITED.
・
Bluetooth
®
and its logo are registered trademarks of Bluetooth SIG, Inc., and
NTT DOCOMO uses them under license. Other trademarks and names inhere
to their respective owners.
・
Napster is a registered trademark of Napster, LLC. and/or its affiliates in the
US and/or other countries.
・
Manufactured under license from Dolby Laboratories. Dolby and the double-
D symbol are trademarks of Dolby Laboratories.
・
"Uni-Type" is a registered trademark of LIM Corp., Ltd.
・
FrameSolid is the registered trademark of Morpho, Inc. in Japan and other
countries.
・
The auto object tracking technology utilized is TrackSolid
™
, a product of
Morpho, Inc. TrackSolid
™
is trademark of Morpho, Inc.
・
Google is registered trademark of Google Inc.
・
ズーキーパー
(Zookeeper) is a trademark or registered trademark of
KITERETSU Inc.
・
"
日英版しゃべって翻訳
for F (J-E Speech Translation for F)" is trademark of
ATR-Trek.
・
Other company and product names mentioned in this manual are
trademarks or registered trademarks of their respective holders.
・
The abbreviations of operating systems (Japanese versions) below are used
in this manual.
- Windows Vista stands for Windows Vista
®
(Home Basic, Home Premium,
Business, Enterprise and Ultimate).
![](/img.php?id=1231109&img=bge.png)
F-04B_E1kou
161
Others
- Windows XP indicates the Microsoft
®
Windows
®
XP Professional
operating system or Microsoft
®
Windows
®
XP Home Edition operating
system.
- Windows 2000 indicates the Microsoft
®
Windows
®
2000 Professional
operating system.
・
FeliCa is a contactless IC card technology developed by Sony Corporation.
・
This product contains a module developed by the Independent JPEG Group.
・
The image interpolation technology utilized is FrameSolid, a product of
Morpho, Inc.
・
This product is equipped with the technologies of GestureTek, Inc.
Copyright
©
2006-2009, GestureTek, Inc. All Rights Reserved.
・
"
学研モバイル国語辞典
(Gakken Mobile JpnDic)", "
学研モバイル和英辞典
(Gakken Mobile JE Dic)", "
学研モバイル英和辞典
(Gakken Mobile EJ Dic)", "
今
日は何の日
(Today's trivia)" and "
今日の歴史
(Today in history)" are
copyrighted by GAKKEN CO., LTD.
・
This product is equipped with the copyright protection technology protected
by US Patent and other intellectual property right, and approved for use by
Rovi Corporation.
The copyright protection technology is used for the function of link this
product with projector, and permitted for use only in domestic and limited
viewing purpose.
Reverse engineering and disassembly of this product are prohibited.
U.S. Patent Nos. 5,315,448; 5,583,936; 6,516,132; 6,836,549; and 7,492,896.
・
This product is licensed based on MPEG-4 Visual Patent Portfolio License.
The use of MPEG-4 Video Codec function is allowed for personal and
nonprofit use only in the cases below.
- Recording moving pictures and i-motion that conform to MPEG-4 Visual
Standard (hereinafter referred to as MPEG-4 Video)
- Playing MPEG-4 Videos recorded personally by consumers not engaged in
profit activities
- Playing MPEG-4 Video supplied from the provider licensed from MPEG-LA
For further utilizing such as promotion, in-house use or profit-making
business, please contact MPEG LA, LLC in U.S.
・
Content owners use Windows Media digital rights management technology
(WMDRM) to protect their intellectual property, including copyrights. This
device uses WMDRM software to access WMDRM-protected content. If the
WMDRM software fails to protect the content, content owners may ask
Microsoft to revoke the software's ability to use WMDRM to play or copy
protected content. Revocation does not affect unprotected content. When
downloading licenses for protected content, you agree that Microsoft may
include a "Revocation List" with the licenses. Content owners may require
you to upgrade WMDRM to access their content. If you decline an upgrade,
you cannot access a content that requires the upgrade.
Others
![](/img.php?id=1231109&img=bgf.png)
* Unavailable from land-line phones, etc.
Repairs
■
From DOCOMO mobile phones
(In Japanese only)
■
From land-line phones
(In Japanese only)
0120-800-000
(toll free)
(No prefix)
151
(toll free)
●
Please confirm the phone number before you dial.
●
For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo shop etc. near you on the NTT DOCOMO website or the i-mode site.
NTT DOCOMO website http://www.nttdocomo.co.jp/english/ i-mode site iMenu⇒お客様サポート (user support)⇒ドコモショップ (docomo Shop) * In Japanese only
* Service available in: English, Portuguese, Chinese, Spanish, Korean.
* Available from mobile phones and PHSs.
General Inquiries <docomo Information Center>
0120-005-250 (toll free)
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※If you use F-04B, you should dial the number +81-3-5366-3114 (to enter '+',
press and hold the '0' key for at least one second).
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※If you use F-04B, you should dial the number +81-3-6718-1414 (to enter '+',
press and hold the '0' key for at least one second).
Loss or theft of FOMA terminal or payment of cumulative cost overseas
<docomo Information Center>
(available 24 hours a day)
■
From DOCOMO mobile phones
(available 24 hours a day)
■
From DOCOMO mobile phones
International call access code
for the country you stay
■
From land-line phones <Universal number>
International prefix number
for the universal number
■
From land-line phones <Universal number>
-81-3-5366-3114* (toll free) International call access code
for the country you stay -81-3-6718-1414* (toll free)
-800-0120-0151*International prefix number
for the universal number -800-5931-8600*
Don't forget your mobile phone ・・・ or your manners!
When using your mobile phone in a public place, don't forget to
show common courtesy and consideration for others around you.
■
From DOCOMO mobile phones
(In Japanese only)
■
From land-line phones
(In Japanese only)
0120-800-000
(toll free)
(No prefix)
113
(toll free)
* Unavailable from land-line phones, etc.
* Available from mobile phones and PHSs.
* Available from mobile phones and PHSs.
●
If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.
●
If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.
*
You might be charged a domestic call fee according to the call rate for the country you stay.
※
For international call access codes for major countries/international prefix numbers
for the universal number, refer to DOCOMO International Services website.
*
You might be charged a domestic call fee according to the call rate for the country you stay.
※
For international call access codes for major countries/international prefix numbers
for the universal number, refer to DOCOMO International Services website.
Failures encountered overseas
<Network Support and Operation Center>
CA92002-5792
2010.X (1st Edition)
To prevent damage to the environment,
bring used battery packs to a docomo
service counter, a docomo agent or a
recycle center.
