INSTRUCTION MANUAL
INSTRUCTION MANUAL ’11.5
F-07C
F-07C_EN_ninshou
DOCOMO W-CDMA, GSM/GPRS System
Thank you for purchasing "docomo PRO series F-07C" mobile terminal.
Before using F-07C, read this manual to ensure safe use and handling.
Instruction manuals for F-07C
The operations of F-07C are described in this manual, "
使いかたガイド
(Guide)” (installed in FOMA
terminal) and "Instruction manual (detailed version)" (PDF file).
･
In this "F-07C INSTRUCTION MANUAL", "F-07C" mobile terminal is usually referred to as "FOMA terminal".
･
The images or illustration used in this manual are examples. They may differ from the actual displays.
･
In this manual, "authenticate" indicates the operating procedure for entering the terminal security code in 4-
8 digits.
⇒
P35
Basic package
･
Unauthorized copying of parts of or this entire manual is prohibited.
･
The contents in this manual, URL and contents are subject to change without prior notice.
Instruction
manual (this
manual)
This manual provides information about screens and operations of basic
functions.
"
使いかたガイド
(Guide)"
(installed in FOMA
terminal)
This guide provides overviews and operations of frequently-used functions. (In
Japanese only)
In F-07C Stand-by display,
mef
LifeKit
e*
Guide
e
Select a search
method
"Instruction
manual (detailed
version)" (PDF file)
This manual provides detailed information and operations of all the functions.
(In Japanese only)
<From a PC> This manual can be downloaded from NTT DOCOMO website.
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html
*
The URL and contents are subject to change without prior notice.
F-07C
(including Back Cover F58 and warranty)
Compatible options
⇒
PXX
Instruction manual
Battery Pack F20 Earphone Plug Adapter F01 USB Cable F01
AC Adapter F04
F-07C_EN_ninshouF-07C_EN_ninshouF-07C_EN_ninshou
1
Introduction
Basic
Operation
Connect
Search
Enjoy
More
Convenient
Windows 7
Others
Contents
FOMA terminal ...........................
2
What you can do with F-07C.....
3
Part names and functions .........
4
Usage Styles...............................
7
Precautions (Always follow these
directions)...............................
8
Handling precautions ................
16
Before Using ...............................
20
Screen Explanation ....................
23
Character Entry ..........................
27
Sound/Screen Setting ..............
30
Lock/Security.............................
35
Call Telephone............................
47
Mail..............................................
57
Phonebook ..................................
61
i-mode/Full Browser ..................
63
i-Channel .....................................
65
Map/GPS.....................................
66
Camera ........................................
71
Music ...........................................
73
i-αppli ..........................................
75
i-motion/Movie..........................
76
Osaifu-Keitai ...............................
79
i-concier.......................................
81
Convenient tools ........................
82
Data Management.....................
85
Before Using ...............................
91
Screen Explanation ....................
95
Communications ........................
99
Sound/Saving Setting ...............
102
Maintenance ..............................
103
Recovery.....................................
106
Office...........................................
107
Support.......................................
108
Support .......................................
113
Appendix .....................................
125
Index............................................
141
F-07C_EN_ninshou
2
Introduction
FOMA terminal
･
Because your FOMA terminal uses wireless transmission, it may not function in locations where it is
difficult for radio waves to penetrate, such as tunnels, underground passages and some buildings, in areas
where radio waves are weak, or out of service area. Even when you are high up in a tall building or
condominium and nothing blocks your view outside, your FOMA terminal may not be able to receive or
transmit signals. Also, communication may be interrupted even when the signal meter on your FOMA
terminal indicates there are strong radio waves and you are not moving (traveling).
･
Use your FOMA terminal in a way that does not disturb others in public spaces, crowded locations or quiet
places.
･
Because your FOMA terminal uses radio waves to communicate, it is possible that a third party may
attempt to tap your calls. However, the W-CDMA, GSM/GPRS system automatically applies a confidential
communication function to all calls, so even if a third party could somehow tap a call, they only hear noise.
･
Your FOMA terminal encodes voice communication as digital data. When you are operating your FOMA
terminal while moving to a location subject to weaker radio wave conditions, the transmitted digital data
may not be correctly decoded and as a result the decoded voice may differ somewhat from the actual voice.
･
Maintain a separate record of the data (phonebook, schedule, notepad, recorded messages, voice memos,
moving picture memos, etc.) you registered in your FOMA terminal. Note that DOCOMO assumes no
responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the
model or other handling of FOMA terminal.
･
You are recommended to save important data to microSD card. Using DOCOMO keitai datalink, you can
transfer and save phonebook, mail, schedule and other data to a PC.
･
The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS.
Neither DOCOMO nor the certifier as listed herein makes any representation and warranty as for the
security in the use of SSL/TLS. If the data should be erased, DOCOMO assumes no responsibility for the
loss of any data.
Certifier : VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd.,
SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc.
･
This FOMA terminal supports FOMA Plus-Area and FOMA HIGH-SPEED Area.
･
FOMA terminal can be used only via the FOMA network provided by DOCOMO and DOCOMO's roaming
area.
F-07C_EN_ninshou
3
Introduction
What you can do with F-07C
Windows 7 mode
71
F-07C is equipped with "Keitai mode" for using as
a regular FOMA terminal and "Windows 7 mode".
To switch to Windows 7 mode, press
w
. You
can use the Internet via Full Browser, e-mail
"Office 2010 Personal" and electronic dictionaries.
In Windows 7 mode, you can also use Wi-Fi.
*
The functions of Windows 7 mode are described
in the chapter "Windows 7" other than common
portions to Keitai mode, such as part names. For
functions of Keitai mode used in Windows 7
mode, see "Windows 7".
使いかたガイド
(Guide)
26
Without Instruction manual at hand, you can
check the operations of desired functions
immediately with the FOMA terminal. By
searching from the function list or entering
keywords, you can view outlines and operating
procedures of the function, and also start the
function. (In Japanese only)
AUTO-GPS
67
AUTO-GPS function allows you to use convenient
services that deliver such information as weather,
neighboring shops, sightseeing, etc. around your
location.
International Roaming (WORLD WING)
55
While staying overseas, you can use the same
FOMA terminal, phone number and mail address
as those used in Japan (3G/GSM Areas are
supported).
High functionality camera
71
Camera offers approximately 5,11 million pixels
(effective pixels) and Auto scene recognition to
switch to the optimal scene mode, Face detection
to detect person's face and smile rate, Tracking
focus to track the subject, Whiteboard mode to
shoot text etc. on the whiteboard sharply, etc.
i-concier
81
A character on stand-by display (Machi-chara)
delivers useful information (Information) and
schedules are automatically downloaded from
sites (i-schedule) so that you can use the service
for your convenience. (In Japanese only)
F-07C_EN_ninshou
4
Introduction
Part names and functions
Part names of F-07C and major functions assigned to each part are as follows.
a
f
b
c
p
d
e
i
c
a
e
r
fgh
b
d
g
h
q
k
j
n
o
m
l
F-07C_EN_ninshou
5
Introduction
To use the function with *, press the key for 1
second or more.
a
Display (touch panel)
b
Light sensor for sensing the ambient
lightness to adjust the brightness of the
display
c
Indicator light for notifying the state of the
FOMA terminal
d
Earpiece
e
In-camera
f
Indicator light for notifying the state of
Windows 7 mode
g
Microphone for calling and recording
h
FOMA antenna (built into FOMA terminal)
i
Back cover
j
Out-camera
k
Infrared data port
l
Shooting indication light
m
Camera light
n
Speaker
o
mark for placing over IC card reader for
Osaifu-Keitai and iC transmission
p
microUSB connection jack for USB Cable
F01 and Earphone Plug Adapter F01
q
Strap opening
r
Cradle connection jack
⇒
P21
af
Exit a running function, or turn ON/OFF
the FOMA terminal by pressing for 2 seconds
or more
bc
Receive a voice call, delete a character,
return to the previous screen, or display i-Channel
list
c
QWERTY keypad
⇒
P6
d
Track ball for moving the cursor by rotating/for
performing the operations by pressing, or the same
operation as right-click of mouse pad by pressing in
Windows 7 mode
eN
Multitask key for starting another function
during a call or operation
fz
Turn ON/OFF the display or start/cancel
Silent mode
*
gw
Switch Windows 7 mode/Keitai mode or
force-quite Windows 7
*
hC
Perform operations while starting Camera or
start the still camera shooting
*
External
connection jack
Earphone plug
adapter
* AC adapter (charger) and Stereo Earphone Set 01
(earphone/microphone jack) use a common jack.
Use optional earphone compatible with external connection
jack. When using earphone imcompatible with external
connection jack, use optional plug adapter.
<Using earphone>
Example of connecting Earphone Plug Adapter for
External connector terminal 01 (optional)
AC adapter
仮
仮
F-07C_EN_ninshou
6
Introduction
a
q
-
o
,
p
,
g
,
h
Enter phone number
or symbols, select menu or item, or
perform each shortcut operation
b
!
Only in Windows 7 mode, select an item
or the same operation as left-click of
mouse pad
c
Z
Press with the other key to enter
symbols/numbers or to use the functions
marked on the key in blue
d
C
Press with the other key to enter
symbols or to use the functions marked
on the key in yellow-green
e
M
Display Start menu of Windows 7 (in
Windows 7 mode only)
f
8
Receive a voice call, delete a character,
return to the previous screen, or display
i-Channel list
g
U
Display Scheduler, move the cursor, or
display Alarm clock list
*
h
Guide keys
1
: Display the menu, or perform the
operation at upper-left of the guide area
2
: Display the outgoing call screen, or
perform the operation at upper-right of the
guide area
3
: Display the mail menu, perform the
operation at lower-left of the guide area, or
Check new message
*
4
: Display iMENU connecting to i-mode,
perform the operation at lower-right of the
guide area, or display i-
α
ppli folder list
*
i
[
Perform the operation or Focus mode
j
R
Display Redial, switch screens, move
the cursor, or start/cancel IC card lock
*
k
D
Display Phonebook, move the cursor, or
add phonebook entry
*
l
L
Display Received calls, switch screens,
move the cursor
QWERTY keypad
F-07C_EN_ninshou
7
Introduction
Usage Styles
You can use the FOMA terminal with two
styles: "basic style (closed state)" supports
touch operation, "slide style (opened state)"
supports touch operation and key operation.
･
Unless otherwise noted, operations in basic
style are mainly explained in this manual.
✜
Basic style
Touch operation is available with FOMA terminal
closed.
･
Vertical and horizontal views can be switched
according to tilt of the FOMA terminal by the auto
rotation in Motion sensor.
✜
Slide style
Key operation and touch operation are available
with FOMA terminal opened.
Point
･
In basic style, vertical and horizontal views can be
switched according to tilt of the FOMA terminal by
the auto rotation in Motion sensor.
･
In slide style, the display is switched automatically to
horizontal view.
･
In slide style, the display is switched automatically to
horizontal view.
･
Do not apply excessive force when opening/closing
the FOMA terminal. It may cause damages on the
keypad or the display.
･
For opening/closing the FOMA terminal, do not
touch the touch panel with your fingers to prevent
inadvertent operations.
･
Before carrying the FOMA terminal, change to basic
style and activate Operation lock to prevent
inadvertent operations or to save battery power
consumption.
F-07C_EN_ninshou
8
Introduction
Precautions (Always follow these directions)
・
Before using your FOMA terminal, or when
necessary, read the following precautions to
ensure safe use and handling. After reading this
manual, keep it in a safe place.
・
These precautions are intended to protect you
and others around you. Read and follow them
carefully to avoid injury, damage to the product
or damage to property.
・
The signs below differentiate between the
levels of danger that can occur if the product is
not used within the specified guidelines.
・
The symbols below show specific directions.
■
Precautions contain the descriptions below.
Handling FOMA terminal, battery pack, adapter and
UIM (common)
.....................................................................................9
Handling FOMA terminal ............................................10
Handling battery pack .................................................12
Handling adapter .........................................................13
Handling UIM...............................................................14
Handling mobile phones near electronic medical
equipment.................................................................14
DANGER
This sign denotes that
death or serious injury
may directly result from
improper use.
WARNING
This sign denotes that
death or serious injury
may result from
improper use.
CAUTION
This sign denotes that
minor injury or damage
to property may result
from improper use.
This symbol denotes that the action
is prohibited.
This symbol denotes that
disassembling the phone or its
components is not allowed.
Don’t
No disassembly
This symbol denotes that using the
phone or its components with wet
hands is not allowed.
This symbol denotes that using the
phone or its components in a
bathroom or other highly humid
area is not allowed.
This symbol denotes that an
instruction must be obeyed at all
times.
This symbol denotes that the
equipment should be unplugged.
No wet hands
No liquids
Do
Unplug
F-07C_EN_ninshou
9
Introduction
DANGER
Do not use, store, or leave the
equipment in hot areas such as near
flames or in areas under strong direct
sunlight such as inside a vehicle.
May cause fire, burns or injuries.
Do not put the terminal into heating
cooking device such as microwave oven
or high-pressure container.
May cause fire, burns, injuries or electric shock.
Do not disassemble or remodel the
equipment.
May cause fire, burns, injuries or electric shock.
Do not let the terminal get wet with
water, drinking water, urine of pet
animals, etc.
May cause fire, burns, injuries or electric shock.
Use the battery pack and adapter
specified by NTT DOCOMO for your
FOMA terminal.
Failure to do so may cause fire, burns, injuries or
electric shock.
WARNING
Do not throw the equipment or give
hard shock to it.
May cause fire, burns, injuries or electric shock.
Keep conductive materials (metal
pieces, pencil lead, etc.) from coming in
contact with the microUSB or cradle
connection jack. Do not put those
materials inside the connection jack.
May cause fire, burns, injuries or electric shock.
Do not cover or wrap the terminal with
a blanket, etc while using or charging.
May cause fire or burns.
Turn FOMA terminal OFF and stop
charging if you charge the battery
before entering a place such as a gas
station where flammable gases are
generated.
The gas may catch fire.
When using Osaifu-Keitai in a place as a gas
station, turn OFF the terminal before using it.
(When IC card lock is activated, deactivate it
before turning OFF the terminal.)
If the equipment starts giving off a
strange smell, overheats, becomes
discolored or deformed during use,
charging or in storage, immediately
perform the following operations.
･
Remove the power plug from the wall
outlet or cigarette lighter socket.
･
Turn FOMA terminal OFF.
･
Remove the battery pack from FOMA
terminal.
Failure to do so may cause fire, burns, injuries or
electric shock.
Handling FOMA terminal, battery
pack, adapter and UIM (common)
Don’t
Don’t
No disassembly
No liquids
Do
Don’t
Don’t
Don’t
Do
Do
F-07C_EN_ninshou
10
Introduction
CAUTION
Do not leave the equipment on unstable
or sloping surfaces.
The euipment may fall and cause injuries.
Do not store the equipment in
extremely humid, dusty or hot areas.
May cause fire, burns or electric shock.
Children using the equipment should be
instructed in proper operation by an
adult. Do not allow them to use the
equipment without adult supervision.
May cause injuries.
Store the equipment out of reach of
small children.
May be accidentally swallowed or cause
injuries.
Be careful especially when using FOMA
terminal connected to the adapter
continuously for a long time.
If you use i-
α
ppli or a videophone call while
charging the battery for a long time, FOMA
terminal, battery pack and adapter may be
heated.
Directly touching a hot part for a long time, you
may have redness, itching or rash on your skin,
or it may result in low-temperature burns
depending on your constitution and/or health
condition.
WARNING
Do not direct the infrared data port
toward your eye and transmit signals.
May cause harmful effect on eyes.
Do not direct the infrared data port
toward home electric appliances etc.
equipped with infrared device when
using infrared communication.
May cause an accident because of malfunction
of infrared device.
Do not turn on the light by getting the
lighting part closer to other person's
eyes.
May impair eyesight. And may cause accidents
like injury etc., by dazzling or astounding other
people.
Do not put foreign objects such as liquid
like water, metal pieces or burnable
things into UIM or microSD card slot.
May cause fire, burns, injuries or electric shock.
Do not turn on the light aiming directly
at the driver of the car etc.
May disturb driving and cause an accident.
Don’t
Don’t
Do
Do
Do
Handling FOMA terminal
Don’t
Don’t
Don’t
Don’t
Don’t
F-07C_EN_ninshou
11
Introduction
Turn FOMA terminal OFF in areas where
use is prohibited, such as in airplanes
and hospitals.
Failure to do so may cause electronic equipment
or electronic medical equipment to fail or
malfunction. If the function which automatically
turns the power ON is set, cancel the setting
before turning the power OFF.
When using the phone in a medical facility, be
sure to observe the regulations of the facility.
If you do prohibited act such as using the phone
in an airplane, you may be punished according
to law.
When you talk by setting handsfree or
ring alert is sounding, keep FOMA
terminal away from your ear.
And, when connecting the earphone/
microphone etc. to FOMA terminal and
play a game or music, adjust the volume
moderately.
Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around you
clearly, it may cause an accident.
If you have weak heart, be careful when
setting the Vibrate alert (vibration) or
alert volume setting.
May cause harmful effect on heart.
When you use electronic medical
equipment, check with the equipment
manufacturer to determine how the
device is affected by radio waves before
using.
May cause harmful effect on electronic medical
equipment etc.
Turn FOMA terminal OFF near high-
precision electronic control equipment
or electronic equipment using low-
power signals.
Failure to do so may cause the equipment to fail
or malfunction.
* Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or defibrillators,
other electronic medical equipment, fire alarms,
automatic doors and other automatic control
equipment.
Users wearing implanted pacemakers or defibrillators
or other electronic medical equipment should check
with the manufacturer or sales outlet about the effect
of radio frequencies on the equipment.
When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.
Surfaces of display and camera lens are made of
plastic panels and they are structured for the
glass not to scatter, however, if you mistakenly
touch broken or exposed parts, you may be
injured.
To sound the high-pitched alarm,
always keep FOMA terminal away from
your ears.
Failure to do so may cause hearing defect.
CAUTION
Do not swing FOMA terminal by its
strap.
May cause accident such as injury to yourself or
others by hitting.
Do not use damaged FOMA terminal.
May cause fire, burns, injuries or electric shock.
Do
Do
Do
Do
Do
Do
Do
Don’t
Don’t
F-07C_EN_ninshou
12
Introduction
When using the motion tracking or
motion sensor, check the safety around
you, hold FOMA terminal firmly, and do
not shake it unnecessarily.
May cause accident such as injuries.
If the display part is accidentally broken
and the liquid crystal leaks out, do not
make the substance contact with your
skin of face or hands.
May cause loss of sight or skin problems.
If the liquid gets into your eyes or mouth, rinse it
with clean water and see a doctor immediately.
And, if the liquid adheres to skin or clothing, use
alcohol etc. to wipe it off, then wash with soap.
To use the terminal in car, check with
automobile manufacturer or dealer to
determine how the device is affected by
radio waves before using.
In rare cases, using the phone in some vehicle
models can cause the vehicle's electronic
equipment to malfunction. In that case, stop
using the terminal immediately.
Mobile phones can give some users skin
problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.
⇒
"Material list (P15)".
When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.
May cause accident such as injuries.
When watching the display, take a
certain distance from the display in a
fully bright place.
May reduce visual acuity.
■
Check that the battery type matches the type
displayed on the battery pack label.
DANGER
Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like a
metal necklace.
May cause the battery pack to ignite, burst, heat
or leak.
Check the orientation of battery pack to
install it to FOMA terminal, and do not
try to force the battery pack onto FOMA
terminal if you are having trouble
installing it.
May cause the battery pack to ignite, burst, heat
or leak.
Do not throw the battery pack into the
fire.
May cause the battery pack to ignite, burst, heat
or leak.
Do not nail the battery pack, hit with
a hammer or step on it.
May cause the battery pack to ignite, burst, heat
or leak.
If the battery pack's fluid contacts eyes,
immediately flush the eyes with clean
water and see a doctor right away. Do
not rub the eyes.
May cause loss of sight.
Don’t
Don’t
Do
Do
Do
Do
Handling battery pack
Display Battery type
Li-ion 00 Li-ion battery
Don’t
Don’t
Don’t
Don’t
Do
F-07C_EN_ninshou
13
Introduction
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to falling, never use it.
May cause the battery pack to ignite, burst, heat
or leak.
If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.
The vapors from leaking battery pack fluid may
ignite or explode.
Be careful not to let your pet bite the
battery pack.
May cause the battery pack to ignite, burst, heat
or leak.
CAUTION
Do not discard old battery packs
together with other garbage.
May cause igniting or environmental
destruction. Tape the terminals of old battery
packs to insulate them, and then bring them into
a sales outlet such as docomo Shop. If your local
municipality has a battery recycling program,
dispose of them as provided for.
Do not use or charge a wet battery pack.
May cause the battery pack to ignite, burst, heat
or leak.
If fluid etc. leaks out from the battery
pack, do not make the fluid contact with
your skin of face or hands.
May cause loss of sight or skin problems.
If the fluid etc. put into your eyes or mouth, or
contacts skin or clothes, immediately flush the
contacted area with clean water.
If the fluid put into the eyes or mouth,
immediately see a doctor after flushing.
WARNING
Do not use the adapter cord if it gets
damaged.
May cause fire, burns, electric shock.
Do not use the AC adapter or cradle
holder in a bathroom or other highly
humid area.
May cause fire, burns, electric shock.
When it starts to thunder, do not touch
adapter.
May cause electric shock.
Do not short the charging jack while it is
connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.
May cause fire, burns or electric shock.
Do not place heavy objects on the
adapter cord.
May cause fire, burns or electric shock.
When you insert and remove AC
adapter from power outlet, do not
contact a metal strap or other metal
objects with the jack.
May cause fire, burns or electric shock.
Do not touch the adapter cord or outlet
with wet hands.
May cause fire, burns or electric shock.
Don’t
Do
Do
Don’t
Don’t
Do
Handling adapter
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
No wet hands
F-07C_EN_ninshou
14
Introduction
Only use with the specified power
source and voltage.
When charging FOMA terminal
overseas, use AC Adapter for global use.
If incorrect voltage is used, this may cause fire,
burns or electric shock.
AC adapter : AC100V
AC adapter for global use : Between 100V and
240V AC (connect to the AC outlet for internal
household use)
Wipe off any dust that accumulates on
the power plug.
Failure to do so may cause fire, burns or electric
shock.
When you connect the AC adapter to an
outlet, firmly connect to the outlet.
Failure to do so may cause fire, burns or electric
shock.
When you disconnect the adapter from
the outlet or cigarette lighter socket, do
not pull the adapter cord with excessive
force. Instead, hold the power plug to
disconnect.
Failure to do so may cause fire, burns or electric
shock.
Always remove the power plug from
the outlet or cigarette lighter when not
using the adapter for an extended
period.
Failure to do so may cause fire, burns or electric
shock.
Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.
Failure to do so may cause fire, burns or electric
shock.
Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.
Failure to do so may cause fire, burns or electric
shock.
CAUTION
Be careful of the cut surface when
removing UIM.
Failure to do so may cause injuries.
■
These precautions are based on the guidelines
produced at the Electromagnetic Compatibility
Conference Japan, regarding the protection of
electronic medical equipment from radio waves
emitted by mobile phone units.
WARNING
Obey the following rules inside medical
facilities.
･
Do not bring FOMA terminal into operating
rooms (ORs), intensive care units (ICUs) or
coronary care units (CCUs).
･
Turn FOMA terminal OFF in hospital wards.
･
Turn FOMA terminal OFF in hospital lobbies
and corridors if electronic medical equipment
could be nearby.
･
If the medical facility has specified zones
where use or possession of mobile devices is
prohibited, obey those instructions.
･
If the function to automatically turn ON the
power is set, cancel the setting before turning
the power OFF.
Do
Do
Do
Do
Unplug
Unplug
Handling UIM
Handling mobile phones near
electronic medical equipment
Unplug
Do
Do
F-07C_EN_ninshou
15
Introduction
Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
Wearers of implanted pacemakers or
defibrillators must carry and use FOMA
terminal at least 22 cm away from the
implanted device.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.
FOMA terminal's signals may affect the
performance of electronic medical equipment.
Material list
Part Material Surface
treatment
Exterior
case
Movable
part Display
PC+ABS resin
Back case PC+ABS resin
Back cover ABS resin
Fixed part
Slide pad
POM
Fixed part
Upper cover
PC+ABS resin
Fixed part
Middle
frame
PC+ABS resin
Do
Do
Do
Keypad PC resin
Camera
panel
Out-camera PMMA resin
In-camera PC resin
Display panel PA+GF45
resin
Light sensor panel PC resin
Indicator light panel PC resin
Light panel PC resin
Connection
jack cap
microUSB
connection
jack cap
PC+ABS resin
Cradle
connection
jack cap
PC+ABS resin
UIM tray POM resin
Part Material Surface
treatment
F-07C_EN_ninshou
16
Introduction
Handling precautions
・
Keep water away from FOMA terminal.
- FOMA terminal, battery pack, adapter, UIM are not
waterproof. Do not use FOMA terminal in bathrooms
or other high-humidity areas, or in the rain. When
carrying FOMA terminal in a pocket near your body,
sweat may corrode the inner components, causing
malfunction. Malfunctions deemed to be caused by
water are not covered by the warranty, and may be
impossible to repair. Since these conditions are
outside the scope of the warranty, a repair, if at all
possible, is charged.
・
Clean FOMA terminal with a dry soft cloth (such as a
cloth for eyeglasses).
-
Rubbing it roughly with a dry cloth can scratch the
display.
- Drops of water or dirt left on the display may cause
stains.
- If FOMA terminal is wiped with alcohol, paint thinner,
benzine or detergent, the printing may disappear or
color may fade.
・
Clean the jack occasionally with a dry cotton swab etc.
- If the jack is soiled, connection gets worse and it may
cause power to be turned off or insufficient battery
charge, so clean the jack with a dry cotton swab etc.
Also, be careful never to damage the jack when
cleaning it.
・
Do not place FOMA terminal near an air-conditioner
outlet.
- The rapid change in temperature may cause
condensation, causing internal corrosion and
malfunction.
・
When using, be careful not to subject excessive force
to FOMA terminal or the battery.
- If FOMA terminal is crammed into a brimming bag or
placed in a pocket and sat on, display, internal PCBs or
battery pack may be damaged or malfunction. And, if
USB Cable F01 etc. are plugged into the microUSB
connection jack, the breakage of the connector or
malfunction may result.
・
Do not rub or scrape the display with a metal piece
etc.
- It may scratch the display, causing malfunction or
damage.
・
Carefully read the separate instructions that come
with battery pack, adapter and cradle.
・
Do not press the surface of the touch panel strongly or
operate it with sharp objects such as a nail, a ballpoint
pen and a pin.
- It may damage the touch panel.
・
Avoid extreme temperature.
- Use FOMA terminal where the temperature ranges
between 5 and 35
℃
and humidity ranges between 45
and 85%.
・
FOMA terminal may affect land-line phones, TVs or
radios in use nearby, so use it as far as possible from
these appliances.
・
Maintain a separate record of the data you saved in
your FOMA terminal.
- If the data is deleted, DOCOMO assumes no
responsibility for the loss of any data.
・
Do not drop FOMA terminal or subject it to shocks.
- May cause malfunction or damage.
・
Do not plug USB Cable F01 etc. into the microUSB
connection jack at a slant, or do not pull it forcibly
while it is plugged.
- May cause malfunction or damage.
・
Do not close FOMA terminal with the strap etc. held
inside.
- May cause malfunction or damage.
・
It is normal for FOMA terminal to become warm
during use or charging. Continue to use it.
・
Do not leave FOMA terminal with the camera in areas
under strong direct sunlight.
- May cause discoloring or burn-in of materials.
・
FOMA terminal should normally be used with the
microUSB connection jack cap closed.
- Dust and/or water brought into FOMA terminal cause
troubles.
General
FOMA terminal
