Basic Operation
Before Using
Attaching UIM/battery pack
After turning power OFF, close FOMA terminal
and hold it in your hand so that you can properly
attach UIM/battery pack.
✜
Removing back cover
✜
Attaching UIM
Point
･
The UIM (blue) is not available for this FOMA
terminal. If you have the UIM (blue), bring it to a
docomo Shop to replace.
✜
Installing battery pack
✜
Installing back cover
a
Slide the lever in the arrow
direction to lock
Back cover
b
Press and slide the back cover
in the arrow direction
by approx. 3 mm to remove
Tray
IC
Corner cut
UIM
a
Pull the tab of the tray out until it clicks
b
Hold UIM with the IC side down,
align the corner cut with the tray to
set in, and then push the tray
With the label side up, fit
the convex parts to the
concave parts of the
FOMA terminal and insert
in the
a
direction, then
push in the
b
direction
to set in.
Convex parts
Concave parts
c
a
b
a
Fit the 8 tabs to the notches of the
FOMA terminal and push in the
direction
a
not forming any
clearance, then slide in the
direction
b
.
b
Slide the lever in the arrow
direction to lock
F-10C_EN_ninshou
27
Basic Operation
Before Using
Charging
The battery pack does not have a full charge at time of purchase. Use AC adapter for FOMA terminal to
charge the battery before using FOMA terminal.
a
Insert the connector of AC adapter
horizontally to the accessory desktop
holder, with the arrows mark side
upward
b
Unfold the power plug and insert it
into a 100V AC outlet
c
Close FOMA terminal and insert it into
the desktop holder
d
Check that the charging light turns on
*
After charging is completed, remove FOMA
terminal from the desktop holder.
a
Open the external connection jack cap
(
a
), hold the connector horizontally
with the arrows side upward and
insert it to the jack (
b
)
b
Unfold the power plug and insert it
into a 100V AC outlet
c
Check that the charging light turns on
*
When charging is over, pull out the power plug
from the outlet, and pull out from FOMA terminal
horizontally while pressing the release buttons on
both sides of the connector.
Charging using desktop holder
Charging using AC adapter
a
b
c
d
AC adapter
AC 100V
outlet
Release
buttons
Connector
b
c
a
Connector
Release
buttons
External
connection jack
AC
adapter
F-10C_EN_ninshou
28
Basic Operation
Before Using
Turning power ON - Configuring default settin
g
Initial setting is an operation when FOMA terminal
is turned ON for the first time.
af
(2 sec. or more)
The Initial setting screen appears.
b
Set required items
eC
[Complete]
If you exit without setting Change security
code and Request permit/deny., Initial setting
screen reappears when the power is turned
ON the next time.
c
On a confirmation screen of software
update function,
g
The stand-by display appears.
Point
･
If no operation is performed, the display light is
automatically turned off according to the settings in
Light time-out or eco mode setting. The display light
turns on again if there is any operation or incoming
call.
･
The battery usage state is automatically recorded
while using the FOMA terminal. The record is used
only for repair diagnosis.
Turning power off : f
(2 sec. or more)
Changing the initial setting : mehib
Changing screen display to English :
mehbfce
Select "English"
Before Using
Caller ID notification
Set whether to notify your phone number (caller
ID) to the other party's terminal when making a
voice call. Caller ID notification is set to "ON" at the
time of subscription.
ameg
TEL function
ed
Dial/
Receive call setting
ec
Caller ID
notification
eb
Setting
ea
ON or
b
OFF
Point
･
If you hear an announcement of requesting caller ID
when making a call, set Caller ID notification or add
prefix "186" to the phone number to call again.
Before Using
Checking Profile
Check a model name or own phone number.
For details of checking/changing a mail address,
refer to "Mobile Phone User's Guide [i-mode]
FOMA version".
ame0
Profile
User information screen appears.
Point
Editing the profile :
On User information screen,
Ce
Authenticate
e
Set required items
eC
Checking a phone number during a call :
se0
F-10C_EN_ninshou
29
Basic Operation
Screen Explanation
Viewing display
The current state can be checked by the icon
appearing on the screen. Major icons are as
follows.
a Status area
Status icons appear. Select an area to display the
status menu.
⇒
P31
Battery level (Battery icon)
Signal strength (Antenna icon)
:
Self mode ON
:
In data transfer mode
:
Connecting to i-mode
:
AutoKeyLock ON
:
Infrared communication in operation
:
Bluetooth ON
:
The total calls cost exceeds the limit
:
Communication using handsfree-compatible
device in progress
:
Handsfree ON
:
Femtocell available
:
Touch operation OFF
:
Positioning with GPS
:
Location request setting
:
Unread Area Mail exists
:
In-area auto-send mail exists
:
Unread i-mode mail exists
:
Arrival i-concier information exists
Ample
charge
Almost exhausted
(Charge the battery)
Strong
Out of service area or where
radio waves do not reach
Weak
F-10C_EN_ninshou
30
Basic Operation
:
Unreceived i-mode mail exists in i-mode
Center
:
Using Smart Browser
:
A phonebook entry, memo or schedule has
secret attribute
:
Music&Video Channel program obtaining
reservation exists
:
High-pitched alarm is "ON"
:
Kid-safe mode ON
:
During i-
α
ppli operation
:
i-
α
ppli call exists
:
Communication mode ON (USB cable
connected)
:
Alarm is set
:
1Seg watching/recording reserved or alarm
of Memo is set
:
Inside OFFICEED area
:
Manner mode ON
:
Call alert volume OFF
:
Vibration mode for voice call ON
:
In Public mode (Drive mode)
:
Manner support ON
:
Record message setting ON
:
Keypad dial lock ON
:
Personal data lock ON
:
IC card lock ON
:
Recording 1Seg in the FOMA terminal
:
eco mode ON
:
microSD card inserted
:
Connected to external device using USB
cable
:
Pedometer/ACT monitor is set
:
Software update rewrite notice
:
Auto-update of latest pattern definition
failure
b Task area
Icons indicating running features (tasks) appear.
c New arrival
Starting from the left, missed call, recorded
message, message in voice mail service, unread
mail, unread ToruCa, i-
α
ppli call
d Machi-chara
Characters moving about the screen and giving
messages. In addition to the preinstalled
characters, you can obtain characters by
downloading.
e Stand-by disp layout
Clock, weather forecast, thermo-hygrometers
(TempHmd), Pedometer/Physical Activity
Monitor, Calendar, Schedule, Memo, icon to
activate i-concier, i-Channel ticker, graffiti pasted
on the stand-by display. Touch and hold the
screen for 1 second or more to display stand-by
elements palette/stand-by handwriting palette,
and edit freely with touch or slide operations.
f Stand-by launcher
Button to activate functions displayed on the
stand-by display (vertical).
⇒
P31
F-10C_EN_ninshou
31
Basic Operation
Screen Explanation
Basic operations for screen and keys
On the stand-by display, select
m
and then
perform the functions from the menu. You can select
a menu item with shortcut operations, which use the
keypad, etc. or with multi-cursor operation, which
uses the multi-cursor key to move the cursor.
<Example>
Selecting "Calculator"
Shortcut operations
ame6e2
Multi-cursor key operations
ame
Move the cursor to "
f
Tool"
e
g
[OK]
e
Move the cursor to "
b
Calculator"
eg
[OK]
Point
･
To return to the previous screen, press
c
. To
return to the stand-by display, press
f
.
Operations that
can be
performed by
pressing
m
,
a
,
g
,
C
and
I
are
displayed in the
guide area.
*
Terms
indicated with
[ ] in the
instructions of this manual are items displayed in
the guide area.
Select an arrival information etc. on the stand-by
display using
g
and
k
to quickly display the
corresponding information.
Menu operation Guide area
Focus mode
Guide area
F-10C_EN_ninshou
32
Basic Operation
Screen Explanation
Quick voice activation
When you do not know a desired menu of function
or you want to activate the function quickly, the
function can be activated by voice sound input
from the stand-by display. (In Japanese only)
an
(1 sec. or more)
For the first activation, on the guidance
screen, select "
利用する
(Use)" or press
C
.
From the second time, "
それではどうぞ ★★
音声受付中★★
" (Please go ahead
★★
voice
input available
★★
) is displayed.
b
Speak a function name toward the
microphone within 10 seconds.
When a message asking for re-entry appears,
press
g
and speak again.
When the voice input is recognized, the
function activates. If the function is not
identified, the keyword list of
使いかたガイド
(Guide) appears.
Point
･
Speak clearly with natural conversation speed.
･
Depending on the environment or way of speaking,
recognition result may vary.
･
You can speak function name (
電卓
(Calculator),
ワン
セグ
(1Seg), etc.), keyword (
計算
(calculation),
テレビ
(TV),
アドレス交換
(address exchange), etc.) or
combination of keywords (
写真 見る
(view photo),
メール 問合せ
(mail check),
スケジュール
4
月
25
日
(schedule 25th April),
○○さん
*
にメール
(mail to Mr.
○○
), etc.) to activate the function.
* Name registered to the phonebook
Screen Explanation
使いかたガイド
(Guide)
You can check outline of function, operations or
troubleshooting. (In Japanese only)
amef
Tool
e#
Guide
e
Select a
search method
目次 (Contents) :
Search from a list of
functions.
索引 (Index) :
Search from a list of words
sorted according to Japanese syllabary.
フリーワード検索 (Free word search) :
Enter a keyword to search for.
ブックマーク (Bookmark) :
Search from a
list of registered bookmarks.
困ったときには (Troubleshooting) :
Search
from lists of troubles or error messages.
その他のご案内 (More information) :
Access to guide page introducing useful site.
Point
･
On a description screen, select "
この機能を使う
(Use
this function)" to perform a function. Selecting a link
item in "
関連機能
(related functions)" or "
→コチラ
(See more)" displays a corresponding description
screen.
<Guide screen>
F-10C_EN_ninshou
103
Others
Appendix
Specific Absorption Rate (SAR) of Mobile Phones
This model F-10C mobile phone complies with
Japanese technical regulations and international
guidelines regarding exposure to radio waves.
This mobile phone was designed in observance of
Japanese technical regulations regarding exposure to
radio waves (
*1
) and limits to exposure to radio waves
recommended by a set of equivalent international
guidelines. This set of international guidelines was set
out by the International Commission on Non-Ionizing
Radiation Protection (ICNIRP), which is in collaboration
with the World Health Organization (WHO), and the
permissible limits include a substantial safety margin
designed to assure the safety of all persons, regardless
of age and health condition.
The technical regulations and international guidelines
set out limits for radio waves as the Specific
Absorption Rate, or SAR, which is the value of
absorbed energy in any 10 grams of tissue over a 6-
minute period. The SAR limit for mobile phones is 2.0
W/kg. The highest SAR value for this mobile phone
when tested for use at the ear is 0.923 W/kg. There may
be slight differences between the SAR levels for each
product, but they all satisfy the limit.
The actual SAR of this mobile phone while operating
can be well below that indicated above. This is due to
automatic changes to the power level of the device to
ensure it only uses the minimum required to reach the
network. Therefore in general, the closer you are to a
base station, the lower the power output of the device.
This mobile phone can be used in positions other than
against your ear. This mobile phone satisfies the
international guidelines when used with a carrying
case or a wearable accessory approved by NTT
DOCOMO, INC.(
*2
) In case you are not using the
approved accessory , please use a product that does
not contain any metals, and one that positions the
mobile phone at least 1.5 cm away from your body.
The World Health Organization has stated that present
scientific information does not indicate that there are
harmful effects attributed to the use of mobile devices.
They recommend that if you are worried about your
exposure then you can limit your usage or simply use
a hands-free kit to keep the mobile device away from
the head and body.
Please refer to the WHO website if you would like more
detailed information.
http://www.who.int/docstore/peh-emf/publications/
facts_press/fact_english.htm
Please refer to the websites listed below if you would
like more detailed information regarding SAR.
Ministry of Internal Affairs and Communications Website:
http://www.tele.soumu.go.jp/e/sys/ele/index.htm
Association of Radio Industries and Businesses
Website: http://www.arib-emf.org/index02.html (in
Japanese only)
NTT DOCOMO, INC. Website: http://
www.nttdocomo.co.jp/english/product/sar/
FUJITSU LIMITED Website: http://www.fmworld.net/
product/phone/sar/
*1
Technical regulations are defined by the Ministerial Ordinance
Related to Radio Law (Article 14-2 of Radio Equipment
Regulations).
*2
Regarding the method of measuring SAR when using mobile
phones in positions other than against the ear, international
standards (IEC62209-2) were set in March of 2010. On the
other hand, technical regulation is currently being deliberated
on by national council. (As of September, 2010)
F-10C_EN_ninshou
104
Others
The product "F-10C" is declared to conform with the
essential requirements of European Union Directive
1999/5/EC Radio and Telecommunications Terminal
Equipment Directive 3.1(a), 3.1(b) and 3.2. The
Declaration of Conformity can be found on http://
www.fmworld.net/product/phone/doc/.
This mobile phone complies with the EU requirements
for exposure to radio waves.
Your mobile phone is a radio transceiver, designed and
manufactured not to exceed the SAR
*
limits
**
for
exposure to radio-frequency(RF) energy, which SAR
*
value, when tested for compliance against the
standard was 0.938W/kg. While there may be
differences between the SAR
*
levels of various phones
and at various positions, they all meet
***
the EU
requirements for RF exposure.
* The exposure standard for mobile phones
employs a unit of measurement known as the
Specific Absorption Rate, or SAR.
** The SAR limit for mobile phones used by the
public is 2.0 watts/kilogram (W/Kg) averaged over
ten grams of tissue, recommended by The
Council of the European Union. The limit
incorporates a substantial margin of safety to
give additional protection for the public and to
account for any variations in measurements.
*** Tests for SAR have been conducted using
standard operation positions with the phone
transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level,
the actual SAR level of the phone while operating
can be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the
closer you are to a base station antenna, the
lower the power output.
･
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions :
a
this device may not cause harmful interference, and
b
this device must accept any interference received,
including interference that may cause undesired
operation.
･
Changes or modifications made in or to the radio
phone, not expressly approved by the manufacturer,
will void the user's authority to operate the equipment.
Declaration of Conformity
Federal Communications
Commission (FCC) Notice
F-10C_EN_ninshou
105
Others
This model phone meets the U.S. Government's
requirements for exposure to radio waves.
This model phone contains a radio transmitter and
receiver. This model phone is designed and manufactured
not to exceed the emission limits for exposure to radio
frequency (RF) energy as set by the FCC of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on
standards that were developed by independent scientific
organizations through periodic and thorough evaluation
of scientific studies.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is
1.6 W/kg. Tests for SAR are conducted using standard
operating positions as accepted by the FCC with the
phone transmitting at its highest certified power level
in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output level
of the phone.
Before a phone model is available for sale to the public,
it must be tested and certified to prove to the FCC that
it does not exceed the limit established by the U.S.
government-adopted requirement for safe exposure.
The tests are performed on position and locations (for
example, at the ear and worn on the body) as required
by FCC for each model. The highest SAR value for this
model phone as reported to the FCC, when tested for
use at the ear, is 0.980W/kg, and when worn on the
body, is 0.310W/kg. (Body-worn measurements differ
among phone models, depending upon available
accessories and FCC requirements).
While there may be differences between the SAR levels
of various phones and at various positions, they all
meet the U.S. government requirements.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Equipment Authorization
Search section at http://www.fcc.gov/oet/ea/fccid/ (please
search on FCC ID VQK-F10C).
For body worn operation, this phone has been tested
and meets the FCC RF exposure guidelines when used
with an accessory designated for this product or when
used with an accessory that contains no metal and
which positions the handset at a minimum distance of
1.5 cm from the body.
*
In the United States, the SAR limit for wireless mobile phones
used by the general public is 1.6 Watts/kg (W/kg), averaged
over one gram of tissue. SAR values may vary depending upon
national reporting requirements and the network band.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
-
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
FCC RF Exposure Information
F-10C_EN_ninshou
106
Others
AIRCRAFT
Switch off your wireless device when boarding an
aircraft or whenever you are instructed to do so by
airline staff. If your device offers flight mode or similar
feature consult airline staff as to whether it can be used
on board.
DRIVING
Full attention should be given to driving at all times
and local laws and regulations restricting the use of
wireless devices while driving must be observed.
HOSPITALS
Mobile phones should be switched off wherever you
are requested to do so in hospitals, clinics or health
care facilities. These requests are designed to prevent
possible interference with sensitive medical
equipment.
PETROL STATIONS
Obey all posted signs with respect to the use of
wireless devices or other radio equipment in locations
with flammable material and chemicals. Switch off
your wireless device whenever you are instructed to do
so by authorized staff.
INTERFERENCE
Care must be taken when using the phone in close
proximity to personal medical devices, such as
pacemakers and hearing aids.
Pacemakers
Pacemaker manufacturers recommend that a
minimum separation of 15 cm be maintained between
a mobile phone and a pace maker to avoid potential
interference with the pacemaker. To achieve this use
the phone on the opposite ear to your pacemaker and
does not carry it in a breast pocket.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may want to consult your hearing aid manufacturer to
discuss alternatives.
For other Medical Devices :
Please consult your physician and the device
manufacturer to determine if operation of your phone
may interfere with the operation of your medical
device.
Important Safety Information
Appendix
Export Administration Regulations
This product and its accessories may be under
coverage of the Export Administration
Regulations of Japan ("Foreign Exchange and
Foreign Trade Control Laws" and the related laws
and regulations). When exporting this product
and its accessories, take necessary procedures on
your responsibility and expense. For details,
contact Ministry of Economy, Trade and Industry
of Japan.
F-10C_EN_ninshou
107
Others
Appendix
Intellectual Property Right
Except for the case protected by copyright laws such as
personal use, use of FOMA terminal to reproduce,
alter, or publicly transmit recorded pictures or sounds,
or copyrighted text, images, music or software
downloaded from websites without the copyright
holder's authorization is prohibited.
Note that taking photos or recordings at some
demonstrations, performances or exhibitions may be
prohibited even when only for personal use.
Avoid taking pictures of others with FOMA terminal
without their consent or disclosing recorded pictures
of others without their consent to general public
through Internet websites etc., because they may
infringe on portrait rights.
Company and product names mentioned in this
manual are trademarks or registered trademarks of
their respective holders.
･
"FOMA", "i-mode", "i-
α
ppli", "i-motion", "Deco-mail",
"Chara-den", "ToruCa", "mopera", "WORLD CALL",
"WORLD WING", "OFFICEED", "2in1", "docomo
PRIME series" and logos of "FOMA", "i-mode", "i-
α
ppli", "Music&Video Channel", "iC" are trademarks
or registered trademarks of NTT DOCOMO.
･
"Catch Phone (Call waiting service)" is a registered
trademark of Nippon Telegraph and Telephone
Corporation.
･
McAfee
®
is registered trademarks or trademarks of
McAfee, Inc. and/or its affiliates in the US and/or
other countries.
･
Rovi, G-GUIDE, G-GUIDE MOBILE and G-
Guide related logos are trademarks or
registered trademarks of Rovi Corporation and/or its
subsidiaries in Japan.
･
Contains Adobe
®
Flash
®
Player, Adobe
®
Flash
®
Lite
®
and Adobe Reader
®
Mobile
technology by Adobe Systems Incorporated. Adobe
Flash Player Copyright
©
1996-2011 Adobe Systems
Incorporated. All rights reserved. Adobe Flash Lite
Copyright
©
2003-2011 Adobe Systems
Incorporated. All rights reserved. Adobe Reader
Mobile Copyright
©
1993-2011 Adobe Systems
Incorporated. All rights reserved. Adobe, Adobe
Reader, Flash and Flash Lite are either registered
trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other
countries.
･
This product contains
NetFront Browser,
NetFront Document
Viewer and NetFront Sync Client of ACCESS CO.,
LTD.
ACCESS, the ACCESS logo and NetFront are
registered trademarks or trademarks of ACCESS
CO., LTD. in the United States, Japan and/or other
countries.
Copyright
©
2011 ACCESS CO., LTD. All rights
reserved.
･
Powered by JBlend
™
Copyright 2002-2011
Aplix Corporation. All rights reserved.
JBlend and JBlend-related trademarks are
trademarks or registered trademarks of Aplix
Corporation in Japan and other countries.
Copyrights and portrait rights
Trademarks
F-10C_EN_ninshou
108
Others
･
is a registered trademark of FeliCa Networks, Inc.
･
FeliCa is a registered trademark of Sony Corporation.
･
QR code is a registered trademark of Denso Wave
Inc.
･
microSDHC Logo is a trademark of SD-3C,
LLC.
･
"Multitask" is a registered trademark of NEC
Corporation.
･
QuickTime is a registered trademark of Apple Inc., in
the US and other countries.
･
Microsoft
®
, Windows
®
, Windows Media
®
, Windows
Vista
®
and PowerPoint
®
are trademarks or
registered trademarks of "Microsoft Corporation" in
the US and other countries.
･
Microsoft Excel and Microsoft Word are product
names of Microsoft Corporation in the U.S.A. In this
manual, they may be described as Excel and Word.
･
The abbreviations of operating systems (Japanese
versions) below are used in this manual.
- Windows 7 stands for Microsoft
®
Windows
®
7
(Starter, Home Basic, Home Premium,
Professional, Enterprise and Ultimate).
- Windows Vista stands for Windows Vista
®
(Home
Basic, Home Premium, Business, Enterprise and
Ultimate).
- Windows XP indicates the Microsoft
®
Windows
®
XP Professional operating system or Microsoft
®
Windows
®
XP Home Edition operating system.
･
Google and Google Map for Mobile are trademarks
of Google Inc.
･
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by
NTT DOCOMO, Inc. is under license. Other
trademarks and names are those of their respective
owners.
･
"CROSS YOU" is a trademark of Sony Corporation.
･
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
･
iWnn of OMRON SOFTWARE Co., Ltd. is used for
conversion methods for Japanese language, and for
phrase prediction methods for English.
iWnn
©
OMRON SOFTWARE Co., Ltd. 2008-2011 All
Rights Reserved.
･
"AXIS Font" is a trademark of AXIS Inc.,
and the "AXIS" font is a font developed by Type
Project Inc.
･
This product contains software licensed by Symbian
Foundation Limited.
Symbian is a registered trademark of Symbian
Foundation Limited.
･
"Privacy mode" is a registered trademark of FUJITSU
LIMITED.
･
"Uni-Type" is a universal designed font jointly-
developed by LIM Corp., Ltd. and Faculty of
Engineering, Chiba University.
Uni-Type is a registered trademark of LIM Corp., Ltd.
･
"
丸ゴシック
(Maru Gothic)", "
レイミン
(Reimin)" and
"
丸フォーク
(Maru Fork)" are provided by Morisawa
& Company, Ltd. and the copyrights of these font
data belong to them. Names of "
レイミン
(Reimin)"
and "
丸フォーク
(Maru Fork)" are their trademarks.
･
OBEX
™
, IrSimple
™
, IrSS
™
and
IrSimpleShot
™
are trademarks of Infrared
Data Association
®
.
･
Blu-ray Disc and its logo are trademarks.
･
DVM
™
is a trademark of microphone
directionality control technology of
DiMAGIC (DiMAGIC Co., Ltd.).
･
Other company and product names mentioned in
this manual are trademarks or registered trademarks
of their respective holders.
F-10C_EN_ninshou
109
Others
･
This product contains a module developed by the
Independent JPEG Group.
･
FeliCa is a contactless IC card technology developed
by Sony Corporation.
･
This product is equipped with the technologies of
GestureTek, Inc.
Copyright
©
2006-2010, GestureTek, Inc. All Rights
Reserved.
･
OMRON Corporation's Mobile OmCR is used for a
character recognition engine.
･
This product contains software licensed based on
Apache License V2.0. and altered as necessary by
NTT DOCOMO, INC.
This product contains software licensed complying
with GNU Lesser General Public License (LGPL), etc.
For more details, on the FOMA terminal,
m
⇒
6#1
⇒
"
その他
" to see in "
オープンソース
ライセンス
".
The source code of the used open source software is
disclosed according to the rules of LGPL (http://
www.gnu.org/licenses/). For more details, refer to
the information on this product in the following site.
http://www.fmworld.net/product/phone/
●●●●●
●●●
･
This product is licensed based on MPEG-4 Visual
Patent Portfolio License. The use of MPEG-4 Video
Codec function is allowed for personal and nonprofit
use only in the cases below.
- Recording moving pictures and i-motion that
conform to MPEG-4 Visual Standard (hereinafter
referred to as MPEG-4 Video)
- Playing MPEG-4 Videos recorded personally by
consumers not engaged in profit activities
- Playing MPEG-4 Video supplied from the provider
licensed from MPEG-LA
For further utilizing such as promotion, in-house
use or profit-making business, please contact
MPEG LA, LLC in U.S.
･
Content owners use Windows Media digital rights
management technology (WMDRM) to protect their
intellectual property, including copyrights. This
device uses WMDRM software to access WMDRM-
protected content. If the WMDRM software fails to
protect the content, content owners may ask
Microsoft to revoke the software's ability to use
WMDRM to play or copy protected content.
Revocation does not affect unprotected content.
When downloading licenses for protected content,
you agree that Microsoft may include a "Revocation
List" with the licenses. Content owners may require
you to upgrade WMDRM to access their content. If
you decline an upgrade, you cannot access a content
that requires the upgrade.
･
The HMM-Based Speech Synthesis Engine
embedded in this product uses the Simplified BSD
License.
--------------------------------------------
The HMM-Based Speech Synthesis System (HTS)
hts_engine API developed by HTS Working Group
http://hts-engine.sourceforge.net/
--------------------------------------------
Copyright
©
2001-2010 Nagoya Institute of
Technology, Department of Computer Science
2001-2008 Tokyo Institute of Technology,
Interdisciplinary Graduate School of Science and
Engineering
All rights reserved.
Redistribution and use in source and binary forms,
with or without modification, are permitted provided
that the following conditions are met:
- Redistributions of source code must retain the
above copyright notice, this list of conditions and
the following disclaimer.
- Redistributions in binary form must reproduce the
above copyright notice, this list of conditions and
the following disclaimer in the documentation and/
or other materials provided with the distribution.
Others
F-10C_EN_ninshou
110
Others
- Neither the name of the HTS working group nor the
names of its contributors may be used to endorse
or promote products derived from this software
without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT
HOLDERS AND CONTRIBUTORS "AS IS" AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO
EVENT SHALL THE COPYRIGHT OWNER OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE
GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT
LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT OF THE
USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
International call access code
for the country you stay
Repairs
General Inquiries
<docomo Information Center>
Failures encountered overseas
<Network Support and Operation Center>
Loss or theft of FOMA terminal or payment of cumulative cost overseas
<docomo Information Center>
* Service available in: English, Portuguese, Chinese, Spanish, Korean.
* Unavailable from part of IP phones.
(Business hours : 9:00 a.m. to 8:00 p.m. (open all year round))
0120-005-250 (toll free)
(Business hours : 9:00 a.m. to 8:00 p.m.)
* Unavailable from part of IP phones.
■
From land-line phones (In Japanese only)
0120-800-000 (toll free)
* Unavailable from land-line phones, etc.
(No prefix) 151 (toll free)
■
From DOCOMO mobile phones (In Japanese only)
●
Please confirm the phone number before you dial.
●
For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo
shop etc. near you on the NTT DOCOMO website or the i-mode site.
(available 24 hours a day)
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※
If you use F-10C, you should dial the number 㧗81-3-6832-6600
(to enter '㧗', press and hold the '0' key for at least one second).
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※
If you use F-10C, you should dial the number 㧗81-3-6718-1414
(to enter '㧗', press and hold the '0' key for at least one second).
■
From land-line phones <Universal number>
●
If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.
●
If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.
* You might be charged a domestic call fee according to the call rate for the country
you stay.
※
For international call access codes for major countries and universal number
international prefix, refer to DOCOMO International Services website.
Universal number
international prefix -8000120-0151
*
CA92002-XXXX
2011.X (1st Edition)
To prevent damage to the environment, bring
used battery packs to a docomo service counter,
a docomo agent or a recycle center.
-81-3-6832-6600
*
(toll free)
(Business hours : 24 hours (open all year round))
* Unavailable from part of IP phones.
■
From land-line phones (In Japanese only)
0120-800-000 (toll free)
* Unavailable from land-line phones, etc.
(No prefix) 113 (toll free)
■
From DOCOMO mobile phones (In Japanese only)
■
From land-line phones <Universal number>
* You might be charged a domestic call fee according to the call rate for the country
you stay.
※
For international call access codes for major countries and universal number
international prefix, refer to DOCOMO International Services website.
Universal number
international prefix -8005931-8600
*
NTT DOCOMO website http://www.nttdocomo.co.jp/english/
■
From DOCOMO mobile phones
i-mode site iMenu
⇒お客様サポート
(user support)
⇒ドコモショップ
(docomo Shop) * In Japanese only
International call access code
for the country you stay
(available 24 hours a day)
-81-3-6718-1414
*
(toll free)
■
From DOCOMO mobile phones
Don't forget your mobile phone ･･･ or your manners!
When using your mobile phone in a public place, don't forget to
show common courtesy and consideration for others around you.
