Enhanced Features
• Front, rear or dual service to satisfy any
installation environment
• Pool/Bulk Presenter
• On-board and remote diagnostics tools for
quickly diagnosing and resolving issues
• Configurable for 1-6 cassettes; field
upgradeable
• Highest capacities (up to 18,000 new
notes*) for most demanding high-volume
cash dispensing environments
Benefits
• Adjustable bill low sensor in each cassette
permits deployer to set the level for their
unique requirements
• Reject bill area in top cassette allows for
maximum number of cassettes flexibility in
limited amount of vertical space.
• Each cassette can reliably dispense mixed
new and used and paper and polymer notes
• Self-monitoring sensors can communicate
imminent problem allowing them to be
replaced before a failure
• Target applications include high-end ATMs,
bill breakers, bill payment kiosks, teller
assist units, gaming and media dispensers,
etc.
Data Sheet
Fujitsu F510
Multi Cassette Media/Currency Dispenser
High Performance Multi Cassette Bill Dispensing Unit
Best-in Class Multi-Cassette Media/Currency Dispenser
Data Sheet Fujitsu F510
Page 1 of 3 www.fujitsufrontechna.com
F510 Bill Dispensing Unit
F510 Multi Cassette Media Dispenser
With over 30-years’ experience in designing and building media
dispensing devices of legendary quality, Fujitsu has expanded the family
of products available to its OEM sales channel to meet the needs of a
greater number of applications.
The Fujitsu F510 is one of the most advanced media dispensers on the
market today, with the speed, capacity, reliability, and advanced
diagnostics for your most demanding environments.
At seven notes per second, the F510 is one of the fastest cash
dispensers in the industry. The unit is expandable up to six cassettes,
with each cassette capable of supporting up to 3,000 new notes. With a
total capacity of 18,000 new notes, it is the solution for high-volume
locations. The multimedia-capable F510 can dispense postage stamps,
coupons, pre-paid phone cards or other specialized media, making it
one of the most flexible dispensers in the industry.
Despite its advanced features, the F510 has been designed to drive
down your total cost of ownership.
F510 Solution Overview
Data Sheet Fujitsu F510
The unit features advanced on-board and remote diagnostics to help
detect problems before they occur. And its integrated reject bin
reduces maintenance needs. The F510 can be installed to support
front and rear service or can be configured for dual access. This
enables the OEM to support multiple applications, which reduces
support costs, lowers spare inventory, and minimizes maintenance
logistics.
Other high-end features on the F510 include a customer- adjustable
bill low and denomination sensors to ensure that you have cash at
peak times and dispensing the correct denomination to your
customers. In addition, the sensors on the F510 can alert your
customers or service organization when they need to be replaced
before they fail and cost you down time.
The F510 is backed by the Fujitsu team of experienced, dedicated
professionals who are committed to bringing you the devices you
need to create solutions that will help your customers succeed. Tell
us about your unique OEM requirements and make Fujitsu a part
your team.
Page 2 of 3 www.fujitsufrontechna.com
Currency Handling Solutions
F510 Product Specications
Data Sheet Fujitsu F510
Contact
FUJITSU
Fujitsu Frontech North America Inc.
Address: 27121 Towne Centre Drive, Suite 100 Foothill Ranch, CA 92610
Phone: 877-766-7545
Email: CHPS.FFNA@us.fujitsu.com
Website: http://www.fujitsu.com/us/oem/financial/atm
F510_DS_122716
Page 3 of 3 www.fujitsufrontechna.com
©2016 Copyright Fujitsu Frontech North America Inc. All rights reserved. Fujitsu and the Fujitsu logo are registered trademarks. All other trademarks are the property of their respective owners. Statements herein are
based on normal operating conditions and are not intended to create any implied warranty of merchantability or fitness for a particular purpose. Fujitsu Frontech North America Inc. reserves the right to modify, at any
time without notice, these statements, our services, products, and their warranty and performance specifications.
Dimensions 2-Denominations
(W x D x H) 280mm x 763mm x 405mm
Weight w/o media 72kg cassette
Maximum Capacity per Cassette 3,000 new notes (approx.)* 370mm
Maximum Dispense 60 notes per transaction
Service Area Front, rear or dual
Number of Cassettes 1-6 cassettes
Reject Area Capacity 150 notes
Acceptable Media Range Max. (mm) 82mm x 172mm
Mín. (mm) 60mm x 120mm
Thickness (mm) 0.07 ~ 0.3
Processing Speed 7 notes per second
Interface Specifications RS232C
Electrical Reuirements DC +24V +/- 10% Avg. 4A Peak 10A
Temperature Operation: 0°C - 40°C
Stop State:-5°C - 50°C
Relative Humidity Operation: 10% - 85%
Stop State: 8% - 95%
RoHS Compliance Yes
UL Compliance Yes
Fujitsu Frontech North America reserves the right to change specifications without notice
*Actual number of notes depends on fitness of currency, new versus used
