Enhanced Functional Features
• Reliable currency recycling at a lower price,
broadening the array of potential
applications while ensuring a more rapid ROI
• Quickly and accurately verifies currency
denominations, detects and separates
counterfeit and unfit currency with the best-
in-class bill validator.
• Greater capacity, 5 cassettes, (4 recycling
cassettes and 1 deposit cassette) and an
optional 6th cassette for beginning of day
replenishment, added capacity or additional
denominations when necessary
• Higher performance with the fastest deposit
and dispense transactions in the industry
• Supports major world currencies including
mixed and used notes, paper and polymer
notes
• CEN XFS service provider is available to
enable easy development of application
software
Benefits
• Lower cost of ownership by more efficiently
managing currency requirements and cash-
in-transit costs
• Increased up time with the flexibility of
adding a loading cassette for increased
capacities, start of day replenishment or
additional denominations
• Supports provisional credit on questionable
items by capturing the entire image of the
note with the bill validator, providing greater
flexibility to OEM providers.
• Manages the quality of notes by accepting
and separating unfit currency, while
dispensing only fit currency to end
customers.
• OEMs can demonstrate ROI to customers
with Asset Planning Tool™, which enables
customers to enter their unique currency
handling data and calculate replenishment
benchmarks vs. usage.
Data Sheet
Fujitsu G60
Multi-Cassette Currency Recycling Module
Evolve Your Currency Management with the G60 Recycler
G60 Combines Slim, Compact Design with High-Capacity and Versatility
Data Sheet Fujitsu G60
Page 1 of 3 www.fujitsufrontechna.com
G60 Dimensional Schematic
The G60 recycling unit by Fujitsu is a real game- changer for the OEM
sales channel.
For the first time there is true reliability smaller recycling unit. Built to
Fujitsu’s exacting standards, the G60 does not compromise features or
capabilities for a smaller footprint.
The G60s lower price point now makes currency recycling a viable option
in a greater number of applications. With 4 recycle cassettes, 1 deposit
box and 1 optional loading cassette, the G60 has the highest currency
capacity in the industry. With greater capacities, the G60 may be the
ideal OEM solution for teller assist, ATMs, self-checkout, bill payment or
retail cash management environments.
With Fujitsu’s best-in-class bill validator, mixed denominations can be
deposited in a bundle of up to 20 notes with the complete image of
each note captured (front and back), and used to support provisional
credit on “questionable” items in addition, the bill validator verifies the
notes denomination, checks for counterfeit, can be separated by degree
of fitness and store in a secured cassette where it can then be dispensed
to another customer.
As a value added feature, the G60 can support mixed new and used
currency and mixed paper and polymer notes.
G60 Solution Overview
Data Sheet Fujitsu G60
The G60 can be installed for front or rear access and provides easy
access to the pooling area and the entire length of the transport
system to clear jammed notes or foreign objects.
The G60 protects your investment by using many of the same Fujitsu
components found in other applications. For example, the F53
casette from a self-checkout application can be loaded into the G60
to count, sort and replenish funds for a secondary application like bill
payment.
To make the G60 as user-friendly and secure as possible there are
optional LED displays to prompt and guide customers through a
transaction. In addition, there are optional locks for all cassettes and
an optional locking bar that can secure all of the recycle cassettes in
place.
If you are unsure if the G60 is the right investment for your customer,
Fujitsu has developed the Asset Planning Tool™ (APT). An Excel®-
based tool, APT will enable you to enter your customers currency
handling data, and calculate replenishment benchmarks vs. usage
patterns.
Page 2 of 3 www.fujitsufrontechna.com
= = =
=
= =
=Front ViewLeft-side View
Loading Cassette Option
Currency Handling Solutions
G60 Product Specications
Data Sheet Fujitsu G60
Contact
FUJITSU
Fujitsu Frontech North America Inc.
Address: 27121 Towne Centre Drive, Suite 100 Foothill Ranch, CA 92610
Phone: 877-766-7545
Email: CHPS.FFNA@us.fujitsu.com
Website: http://www.fujitsu.com/us/oem/financial/atm
G60_DS_101117
Page 3 of 3 www.fujitsufrontechna.com
©2017 Copyright Fujitsu Frontech North America Inc. All rights reserved. Fujitsu and the Fujitsu logo are registered trademarks. All other trademarks are the property of their respective owners. Statements herein are
based on normal operating conditions and are not intended to create any implied warranty of merchantability or fitness for a particular purpose. Fujitsu Frontech North America Inc. reserves the right to modify, at any
time without notice, these statements, our services, products, and their warranty and performance specifications.
Dimensions (W x D x H) 160mm x 340mm x 680mm
Weight (without bills) Approx. 25kg
Bill Transaction (deposit) 20 Bills
Bill Transaction (dispense) 20 Bills
Recycle Stacker Capacity 100 Bill (Approx.)* x 4 Stackers
Deposit Cassette Capacity 1,000 Bills (Approx.)*
Loading Cash Cassette Capacity
(Option) 500 Bills (Approx.)*
Acceptable Media Range Maximum (mm) - 78mm x 166mm (TBD)
Minimum (mm) - 60mm x 120mm
Thickness (mm) 0.09 ~ 0.20
Processing Performance Deposit 1 Bill/1.5 sec - 20 Bills/10 sec
Dispense 1 Bill/2.0 sec - 20 Bills/12 sec
Interface Specifications USB 2.0 Full Speed CEN / XFS
Electrical Reuirements DC +24V +/- 10% MA X 15A
Temperature Operation: Operation: 0°C to 50°C
Stop State: -5°C to 50°C
Relative Humidity Operation: 10% - 85%
Stop State: 8% - 95%
RoHS-compliant unit Yes
Fujitsu Frontech North America reserves the right to change specifications without notice
*Actual number of notes depends on fitness of currency, new versus used
