Fujitsu
2.4G
Mesh
Radio
Module And
NIC (Network Interface Card)
User
Manual
V1.0
–
25
June,
2014
Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
Revision
History
Page 1 Copyright 2014 Fujitsu Limited
Ve
r
Category
Description
of
Change
Date
Author
1.0
1.1
First version
Update content
-
1. Add operating Voltage and Temperature 2. Add warning.
25.06.2014
25.06.2014
Fujitsu
WNC
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
Legal
Notice
This document contains proprietary information protected by copyright.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the
prior written permission of Fujitsu Limited.
This document is furnished for informational use only, is subject to change without notice, and
should not be construed as a commitment by Fujitsu Limited. Fujtsu Limited assumes no
responsibility or liability for any errors or inaccuracies that may appear in this document.
Copyright 2014 Fujitsu Limited All Rights Reserved
Page 2 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
Trademark
Acknowledgements
Company names and product names in this manual are trademarks or registered trademarks of
respective companies. Note that system names and product names in this manual are not always
followed by trademark symbols such as Ⓡ or TM.
Page 3 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
CONTENTS
1. About This Manual................................................................................................... 5
1-1. Covered Product ................................................................................................................ 5
2. Product Description ................................................................................................. 6
2-1. General .............................................................................................................................. 6
2-2. Technology ......................................................................................................................... 6
3. Product Installation And Use ................................................................................... 7
3-1. Installation .......................................................................................................................... 7
3-2. Use ..................................................................................................................................... 7
4. Product Information ................................................................................................. 8
4-1. Technical Specification....................................................................................................... 8
4-2. Regulatory Compliances (EN) ........................................................................................... 8
4-3. Regulatory Compliances (FCC)......................................................................................... 8
4-4. Product Label (Sample) ..................................................................................................... 9
4-5. NIC Block Diagram ............................................................................................................ 9
Page 4 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
1.
About
This
Manual
1-1.
Covered
Product
This User Manual contains information on how to install and use Fujitsu 2.4G Mesh Radio Module and
Fujitsu 2.4G Mesh Radio NIC (Network Interface Card). Specifically below products are covered.
- Part Number WR-H1R0WM1 (Fujitsu Intelligent Society Solution Smart Grid Communications
2.4GHz Mesh Radio Module)
- Part Number WR-H2R0WN1 (Fujitsu Intelligent Society Solution Smart Grid Communications
2.4GHz Mesh Radio Interface Card)
Page 5 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
2.
Product
Description
2-1.
General
Fujitsu 2.4G Mesh Radio Module and Fujitsu 2.4G Mesh Radio NIC (Network Interface Card) provide
future-proof communications features to smart and advanced multi-functional static single/poly-phase
revenue meter from Siemens, IM100 and IM300.
The NIC, in an integrated form with IM100/300 as filed replaceable extended communications module,
are essential components in Fujitsu Intelligent Society Solution Smart Grid Communications
infrastructure solution for electricity, gas and water utility service providers.
The Module is integral part of the NIC.
2-2.
Technology
Fujitsu RF Mesh technology – DFF (Depth-First Forwarding) – is Fujitsu’s wireless ad hoc mesh
networking technology which enables autonomous formation of large scale networks and self-healing
by application of artificial intelligence. Its scalability and reliability is proven by large utility provider’s
deployment of more than one million smart meters in remotely reading power consumptions in real time
through the Fujitsu RF Mesh network.
DFF is a global standard adopted by IETF (Internet Engineering Task Force) as RFC 6971 and works
upon standard wireless media such as IEEE802.11 (Wi-Fi) and conveys standard IPv4/v6 packets with
advanced over-the-air security of AES, robust authentication and intrusion prevention mechanism.
Most importantly, DFF enables users to enjoy future-proof communications performance. For it
heuristically adapts to environment, over-the-air data rate is utilized at maximum so that DFF can
perform in ultra-low latency and high bandwidth which are essential to deliver other smart grid
applications such as Distribution Automation.
Page 6 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
3.
Product
Installation
And
Use
3-1.
Installation
Fujitsu 2.4G Mesh Radio NIC is designed to work only with smart and advanced multi-functional static
single/poly-phase revenue meter from Siemens, IM100 and IM300.
Fujitsu 2.4G Mesh Radio NIC into iM100 (left) and into iM300 (right)
3-2.
Use
Fujitsu 2.4G Mesh Radio NIC is powered from IM100 and IM300 through connector cable. When
IM100/300 is turned on, the NIC is also booted up and start wireless communications.
As network settings are pre-configured in the factory, users do not have to do anything to use the NIC in
Fujitsu RF Mesh network system.
Page 7 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
4.
Product
Information
4-1.
Technical
Specification
This device is a Wireless LAN Module which operate at 2.4G band support IEEE 802.11 b/g/n operating
mode. It has 2 chain that max can support 2T2R. Inside this module has an WiFi SoC and 2 PA, 2 LNA,
2 RF Switch, 1 DDR2, 1 SPI Flash and 1 Switching regulator. Because of highly integration, this module
is easy to be use by simply adding few external components.
4-2.
Regulatory
Compliances
(EN)
Fujitsu 2.4G Mesh Radio Module and Fujitsu 2.4G Mesh Radio NIC complies with the essential
requirements of Article 3 of the R&TTE 1999/5/EC Directive, if used for its intended use and that the
following standards have been applied:
1. Health (Article 3.1(a) of the R&TTE Directive)
Applied Standard(s): EN 62311 : 2008
2. Safety (Article 3.1(a) of the R&TTE Directive)
Applied Standard(s): EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011
3. Electromagnetic compatibility (Article 3.1 (b) of the R&TTE Directive)
Applied Standard(s): EN 301 489-1 V1.9.2 / -17 V2.2.1
4. Radio frequency spectrum usage (Article 3.2 of the R&TTE Directive)
Applied Standard(s): EN 300 328 V1.8.1
4-3.
Regulatory
Compliances
(FCC)
This device, FCC ID: O4D-IC400, Model Name: Fujitsu 2.4G Mesh Radio NIC, is declared to be of
conformance does not support any non-US channels in all the operational mode(s) in North America.
Page 8 Copyright 2014 Fujitsu Limited
Standard
IEEE802.11b/g/n compliant
Frequency Range
2412-2462MHz (1-11ch)
Modulation
DSSS (CCK, DQPSK, DBPSK) for IEEE802.11b
OFDM (64QAM, 16QAM, DQPSK, DBPSK) for IEEE802.11g/n
Data Rate
Default: 1Mbps for 11b, 6Mbps for 11g/n (configurable)
Transmission Power
100mW (20dBm)
Antenna
On-board Chip Antenna
Operating Voltage
Module: 3.3 VDC, NIC: 5 VDC
Operating Temperature
Working temperature: 0 ~ 70°C
Storage temperature: -40 ~ 85°C
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
All non-US frequencies and Country code selection are disabled through proprietary software and is not
user changeable.
4-4.
Product
Label
(Sample)
4-5.
NIC
Block
Diagram
Page 9 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Page 10 Copyright 2014 Fujitsu Limited
Fujitsu 2.4G Mesh Radio Module And NIC User Manual
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users,
and the maximum antenna gain allowed for use with this device is 3.12 dBi.
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the
OEM integrator is still responsible for testing their end-product for any additional compliance
requirements required with this module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID can not be used on the final product. In these circumstances, the
OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed
such that 20 cm may be maintained between the antenna and users. The final end product must be
labeled in a visible area with the following: “Contains FCC ID: O4D-IC400”. The grantee's FCC ID can
be used only when all FCC compliance requirements are met.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user’s manual of the end
product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
