Datasheet Fujitsu ETERNUS DX80 S2 Disk Storage System
Page 1 of 6
www.fujitsu.com/eternus/
Datasheet
Fujitsu
ETERNUS DX80 S2
Disk Storage System
The Flexible Data Safe for Dynamic Infrastructures.
ETERNUS DX S2 DISK STORAGE SYSTEMS
The Fujitsu
second generation of ETERNUS DX
disk storage systems, ETERNUS DX S2, are
The
F
lexible Data Safe for Dynamic I
nfrastructures.
Enterprise
-proven capabilities protect data
assets across all types of IT infrastructure.
Redundant components, RAID protection
and
build
-in data protection provide the highest
system reliability to ensure business continuity
is maintained.
ETERNUS DX S2 models are comprehensive
disk storage platforms with superior scalability
to address the demands of intensive data
growth and hi
ghest performance. Free choice
of modular disk storage and state
-of-the-art
connectivity across the entire model range
delivers maximum configuration flexibility
allowing choice in performance and TCO
.
Data
-in-place upgrade options are also
available throu
ghout the system’s lifecycle to
ensure maximum investment protection.
Th
e unified
ETERNUS SF storage management
software enables single point administration,
easy data protection and efficient operation
across the entire ETERNUS DX range. In
virtualized I
T environments in particular,
ETERNUS SF perfectly integrates the powerful
ETERNUS DX disk storage with minimal
administration effort.
ETERNUS DX80 S2
The ETERNUS DX80 S2 with Intel® Xeon®
processors is a reliable and flexible disk
storage system for med
ium-sized IT
environments. It offers an outstanding
price/performance ratio and is easy to
manage, thus reducing operational effort. It
provides remarkable scalability with storage
capacity of up to
48
0 TB, thus offering enough
headroom for future growth.
The flexible
support for different network connectivity and
disk types (SAS, Nearline SAS and SSD)
provides a choice between cost and
performance optimization. The ETERNUS DX80
offers Thin Provisioning allowing a more
cost
-efficient use of storage capacity
right from
the start. Data
-in-place upgrades lead
seamlessly to the next higher ETERNUS DX
system, thus ensuring flexibility and
investment protection. The enclosed ETERNUS
SF Express software reduces administration
work and provides data safety functiona
lity.
Datasheet Fujitsu ETERNUS DX80 S2 Disk Storage System
Page 2 of 6
www.fujitsu.com/eternus/
Features and benefits
Main features
Benefits
Data center functionality already in the Entry class
■ Flexible configuration of drives and connectivity; enables flexible
balancing of performance, capacity and costs
■ Ensures data safety and high availability through comprehensive
features like encryption, redundancy, copy functions and
snapshots
■ Efficient operations through technologies such as Tiering, Thin
Provisioning and Eco-mode
Richly featured management suite at no extra costs
■ Free of charge ETERNUS SF Express Storage Management
■ Snapshot functionality already included
■ Easy and efficient operation
Unique and consistent family concept
■
Seamless and fully compatible product family of disk storage
systems with uniform system components and unified
management software
■ Family concept reduces operations, maintenance, migration and
training efforts as well as costs
■
Migration path to the next bigger model
Datasheet Fujitsu ETERNUS DX80 S2 Disk Storage System
Page 3 of 6
www.fujitsu.com/eternus/
Technical details
General Specification
2.5” Base Model
3.5” Base Model
Single Controller
Dual Controller
Single Controller
Dual Controller
Supported RAID Levels
0, 1, 1+0, 5, 5+0, 6
Host Interfaces
Fibre Channel (16/8/4/2 Gbit/s)
FCoE (10 Gbit/s)
iSCSI (10 Gbit/s) or iSCSI (1 Gbit/s)
SAS (6/3 Gbit/s)
Number of controllers
1
2
1
2
Number of host interfaces
2/4 ports
4/8 ports
2/4 ports
4/8 ports
- Notes
Mixed configurations are possible.
Number of hosts
Max. 1,024
Cache memory capacity
2 GB
4 GB
2 GB
4 GB
Number of drive enclosures
Max. 4 (2.5”) / Max. 9 (3.5”)
Number of drives
Max. 120
Storage capacity
Physical capacity
Max. 480.0 TB
Logical capacity
Max. 356.0 TB
Drives
3.5-inch
SAS disk drives
600 GB/450 GB/300 GB (15,000 rpm)
Nearline SAS disk drives
4 TB/3 TB/2 TB/1 TB (7,200 rpm)
SSD (Solid State Drives)
800 GB/400 GB/200 GB/100 GB
- Notes
3.5” drives are available only for 3.5” drive enclosures.
2.5-inch
SAS Non-Encrypting drives
900 GB/600 GB/450 GB/300 GB (10,000 rpm), 300GB (15,000 rpm)
SAS Self-Encrypting drives
900 GB/600 GB/450 GB/300 GB (10,000 rpm)
Nearline SAS disk drives
1 TB (7,200 rpm)
SSD (Solid State Drives)
800 GB/400 GB/200 GB/100 GB
- Notes
2.5” drives are available only for 2.5” drive enclosures.
Drive interface
Serial Attached SCSI (6 Gbit/s)
Back-End Disk Connectivity
1 pair of four-lane x 6 Gbit/s Serial Attached SCSI buses (SAS 2.0 wide)
Redundancies
RAID Controller
No
Yes
No
Yes
Fan
Yes
Yes
Yes
Yes
Power Supply
Yes
Yes
Yes
Yes
Number of LUN
Max. 2,048
LUN capacity
Max. 128 TB
Number of Snapshots
Standard (built-in)
8
Maximum (option)
1,024
- Note
Local Copy License must be purchased to maximize the number of Snapshots
Number of copy generations
256
Remote Copy feature
No
Installation Specification
2.5” Base Model
3.5” Base Model
Dimensions (Standard)
Controller enclosure (CE)
CE: 482 × 645 × 88 mm (2U)
CE: 482 × 670 × 88 mm (2U)
(W x D x H)
CE: 19 × 25.4 × 3.5 inch (2U)
CE: 19 × 26.4 ×3.5 inch (2U)
Drive enclosure (DE)
DE: 482 × 540 × 88 mm (2U)
DE: 482 × 555 × 88 mm (2U)
DE: 19 × 21.3 × 3.5 inch(2U)
DE: 19 × 21.9x 3.5 inch (2U)
Service Area
Front
800 mm (31.5 inch) or more
Rear
800 mm (31.5 inch) or more
Maximum Weight
175 kg (35 kg per single enclosure)
350 kg (35 kg per single enclosure)
385 lb (77 lb per single enclosure)
770 lb (77 lb per single enclosure)
Installation Specification (Continued)
2.5” Base Model
3.5” Base Model
Datasheet Fujitsu ETERNUS DX80 S2 Disk Storage System
Page 4 of 6
www.fujitsu.com/eternus/
Power
Voltage
AC 100 – 120 V / AC 200 – 240 V
Phase
Single
Frequency
50 Hz / 60 Hz
Maximum Power Consumption
AC 100 - 120V
CE
630 W (640 VA)
620 W (630 VA)
DE
570 W (580 VA)
550 W (560 VA)
Max
2,910 W (CE+2.5”DEx4)
5,570 W (CE+3.5”DEx9)
2,960 VA (CE+2.5”DEx4)
5,670 VA (CE+3.5”DEx9)
AC 200 - 240V
CE
630 W (640 VA)
610 W (620 VA)
DE
570 W (580 VA)
550 W (560 VA)
Max
2,910 W (CE+2.5”DEx4)
5,560 W (CE+3.5”DEx9)
2,960 VA (CE+2.5”DEx4)
5,660 VA (CE+3.5”DEx9)
Maximum Heat Generation
AC 100 - 120V
10,700 kJ/h (10,200 BTU/h)
20,300 kJ/h (19,300 BTU/h)
AC 200 - 240V
10,700 kJ/h (10,200 BTU/h)
20,200 kJ/h (19,200 BTU/h)
Environmental Conditions
Temperature
10 – 40°C (Operating)
50 – 104°F (Operating)
Humidity
20 – 80% RH (Operating)
Altitude
3,000 m (10,000 ft.)
Operating environment
FTS 04230 Guideline for Data Center (installation locations)
Management
Interfaces
Ethernet (1000 Base-T / 100 Base-TX / 10 Base-T)
Supported protocols
SNMP (version1, 2C, 3), SMI-S 1.4
Administration
Web-Environment, CLI (Command Line Interface), ETERNUS SF Express
Supported OS For ETERNUS SF Express
Operation Management Server
Microsoft® Windows Server®2008 Standard (32-bit) (64-bit) including R2
Microsoft® Windows Server® 2008 Enterprise (32-bit) (64-bit) including R2
Microsoft® Windows Server® 2008 Datacenter (32-bit) (64-bit) including R2
Operation Management Client
Microsoft® Windows® 7 Home Premium
Microsoft® Windows® 7 Professional
Microsoft® Windows® 7 Ultimate
Windows Vista® Home Basic
Windows Vista® Home Premium
Windows Vista® Business
Windows Vista® Enterprise
Windows Vista® Ultimate
Windows® XP Home Edition
Windows® XP Professional
Microsoft® Windows Server®2008 Standard (32-bit) (64-bit)
Microsoft® Windows Server® 2008 Enterprise (32-bit) (64-bit)
Microsoft® Windows Server® 2008 Datacenter (32-bit) (64-bit)
Options
License
ETERNUS SF Local Copy License
Datasheet Fujitsu ETERNUS DX80 S2 Disk Storage System
Page 5 of 6
www.fujitsu.com/eternus/
Noise Emission
2.5” Base Model
3.5” Base Model
Sound Power Level (LWAd)
6.6 B
Sound Pressure Level (LpAm)
49 dB(A)
- Notes
measured with single enclosure according to ISO7779 and declared according to
ISO9296
Warranty
Global Base Warranty
3 years
Compliance With Standards
Product safety
UL60950-1, CSA-C22.2 No. 60950-1, EN60950-1, IEC60950-1, GOST-R
Electromagnetic Compatibility
CNS13438(C6357) Class A, FCC CFR47 part 15 Class A, ICES-003 Class A,
EN55022 Class A, VCCI Class A, AS/NZS CISPR22 Class A
Electromagnetic Immunity
EN55024
CE certification
Electromagnetic Compatibility Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Environmental compliance
RoHS-compliant (Restriction of hazardous substances)
WEEE-compliant (Waste electrical and electronic equipment)
- Notes
There is general compliance with the safety requirements of all European
countries and North America. National approvals required in order to satisfy
statutory regulations or for other reasons can be applied
for on request.
Maintenance and Support Services
The perfect extension of the product specific base warranty for optimized operation.
Recommended Service: 24 x 7 Fujitsu support for enterprise class services.
Please check your specific service level with your FUJITSU sales
organization or partner.
Supported configurations
A wide range of host operating systems, servers as well as applications is supported.
For a detailed support matrix check
:
http://www.fujitsu.com/global/services/computing/storage/eternus/products/diskstorage/dx
-entry/supported-device/
Datasheet Fujitsu ETERNUS DX80 S2 Disk Storage System
Page 6 of 6
www.fujitsu.com/eternus/
About Fujitsu America
Fujitsu America, Inc.,
is a leading ICT solutions provider for organizations in the U.S., Canada and the Caribbean. Fujitsu enables clients to meet
their business objectives through integrated offerings and solutions, including consulting, systems integration, managed serv
ices, outsourcing
and cloud services for infrastructure, platforms and applications; data center and field services; and server, storage, softw
are and mobile/tablet
technologies. For more information, please visit:
http://solutions.us.fujitsu.com/ and http://twitter.com/fujitsuamerica
Fujitsu platform solutions
In addition to Fujitsu ETERNUS DX, Fujitsu
provides a range of platform solutions. They
combine reliable Fujitsu products with the
best in services, know-how and worldwide
partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions,
Managed Infrastructure and
Infrastructure-as-a-Service. How much you
benefit from Fujitsu technologies and
services depends on the level of cooperation
you choose. This takes IT flexibility and
efficiency to the next level.
Computing products
www.fujitsu.com/global/services/computing/
- PRIMERGY: Industry standard server
- SPARC Enterprise: UNIX server
- PRIMEQUEST: Mission-critical IA server
- ETERNUS: Storage system
Software
www.fujitsu.com/software/
- Interstage: Application infrastructure
software
- Systemwalker: System management
software
More information
Learn more about Fujitsu ETERNUS DX80 S2,
please contact your Fujitsu sales
representative, Fujitsu business partner, or
visit our website.
http://solutions.us.fujitsu.com/www/content/
products/storage/ETERNUS/index.php
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on
the environment. Using our global
know-how, we aim to resolve issues of
environmental energy efficiency through IT.
Please find further information at:
www.fujitsu.com/global/about/environment/
Copyright
Fujitsu, the Fujitsu logo ETERNUS, PRIM
EQUEST, Interstage and Systemwalker are
trademarks or registered trademarks of
Fujitsu Limited in the United States and
other countries. PRIMERGY is a trademark or
registered trademark of Fujitsu Technology
Solutions in the United States and other
countries. SPARC Enterprise is a trademark
or registered trademark of SPARC
International, Inc. in the United States and
other countries. All other trademarks
mentioned herein are the property of their
respective owners.
Product description data represents Fujitsu
design objectives and is provided for
comparative purposes; actual results may
vary based on a variety of factors.
Specifications are subject to change without
notice.
Copyright ©2013 Fujitsu America, Inc.
All rights reserved.
FPC58-2949-07 07/13
13.0696
Disclaimer
Technical data subject to modification and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which by
third parties for their own purposes may
infringe the rights of such owner.
Contact
FUJITSU AMERICA, INC.
Address: 1250 East Arques Avenue, Sunnyvale, CA
94085
-3470,USA
Tel: 800 3180 or 408 746 6000
Web:
http://solutiions.us.fujitsu.com
Contact Form: http:..solutions.us.fujitsu.com/contact
Have a question? Email us at AskFujitsu@us.fujitsu.com

Navigation menu
