Datasheet Fujitsu ETERNUS DX8700 S2 Disk Storage System

Page 1 of 5

www.fujitsu.com/eternus/

Datasheet

Fujitsu

ETERNUS DX8700 S2

Disk Storage System

The Flexible Data Safe for Dynamic Infrastructures.

ETERNUS DX S2 DISK STORAGE SYSTEMS

The Fujitsu

second generation of ETERNUS DX

disk stora

ge systems, ETERNUS DX S2, are ‘The

F

lexible Data Safe’ for Dynamic I

nfrastructures.

Enterprise

-proven capabilities protect data

assets across all types of IT infrastructure.

Redundant components, RAID protection

and

build

-in data protection provide the highest

system reliability to ensure business continuity

is maintained.

ETERNUS DX S2 models are comprehensive

disk storage platforms with superior scalability

to address the demands of intensive data

growth and hi

ghest performance. Free choice

of modular disk storage and state

-of-the-art

connectivity across the entire model range

delivers maximum configuration flexibility

allowing choice in performance and TCO

.

Th

e unified ET

ERNUS SF storage management

software e

nables single point administration,

easy data protection and efficient operation

across the entire ETERNUS DX range. In

virtualized IT environments in

particular,

ETERNUS SF perfectly integrates the powerful

ETERNUS DX disk storage with minimal

administrat

ion effort.

ETERNUS DX8700 S2

The ETERNUS DX8700 S2 enterprise disk

storage system, with Intel® Xeon® processors

is purpose

-built for large enterprises.

Enterprises are no longer forced to anticipate

future capacity demand levels and to select a

specifi

c high-end model with limited

data

-capacity range. The unique modular

architecture offers flexibly scaling according to

business needs. With minimum initial costs

customers can start with a two controller

module system and four drive enclosures.

Maximum pe

rformance with up to 128

front

-end host ports can be obtained by

scaling up to eight controller modules. FC,

FCoE and iSCSI host interfaces can operate in

mixed configurations.

Software license pricing is based on the

number of controllers used only. This

transparent licensing model allows gradual

capacity upgrading to the maximum drive

count without resulting in capacity based price

increases. Fujitsu’s Flexible Data Management

concept enables a higher level of automation

for storage tiering, including su

pport for SAS,

Nearline SAS and SSD drives that ensure

optimum service levels while reducing the

overall total cost of storage.

System robustness based on redundant

components and local data copy options

ensure high availability for today’s non

-stop

busine

ss. Multiple remote replication options

protect all valuable data assets against site

outages.

Datasheet Fujitsu ETERNUS DX8700 S2 Disk Storage System

Page 2 of 5

www.fujitsu.com/eternus/

Features and benefits

Main features

Benefits

High end storage for large data centers

■ Fail-safe system design reduces downtime to a minimum

■ Multi-dimensional scalability in terms of speed, capacity and

availability provides the headroom for huge data growth

■ High level of automation optimizes operational efficiency

Supports flexible growth without high pre-investments

■ Unique modular architecture that can be flexibly expanded

■ Start with minimum initial costs an grow flexibly with minimum

fix-stepped costs

■ No hidden software costs through simple, fixed-price license

scheme

Unique and consistent family concept

■

Seamless and fully compatible product family of disk storage

systems with uniform system components and unified

management software

■ Family concept reduces operations, maintenance, migration and

training efforts as well as costs

Datasheet Fujitsu ETERNUS DX8700 S2 Disk Storage System

Page 3 of 5

www.fujitsu.com/eternus/

Technical details

Installation Specification

Dimensions (W x D x H)

Controller enclosure (CE)

482 × 940 × 840 mm (19 x 37.0x 33.1 inch) (19U)

2.5" Drive enclosure (DE)

482 × 540 × 88 mm (19 x 21.3 x 3.5 inch) (2U)

3.5" Drive enclosure (DE)

482 × 555 × 88 mm (19 x 21.9 x 3.5 inch) (2U)

Service Area

Front

850 mm (31.5 inch) or more

Rear

850 mm (31.5 inch) or more

Maximum Weight

Controller enclosure

225 kg

2.5" Drive enclosure

35 kg (77 lb)

3.5" Drive enclosure

35 kg (77 lb)

Power

Voltage

AC 200 – 240 V

Phase

Single

Frequency

50 Hz / 60 Hz

Maximum Power Consumption

Max configuration

76,450 W (78,030 VA)

Maximum Heat Generation

281,350 kJ/h (267,850 BTU/h)

Environmental Conditions

Temperature

10 – 35°C (Operating)

50 – 95°F (Operating)

Humidity

20 – 80% RH (Operating)

Altitude

3,000 m (10,000 ft.)

GENERAL SPECIFICATION

DX8700 S2

Supported RAID Levels

0, 1, 1+0, 5, 5+0, 6

Host Interfaces

Fibre Channel (16/8/4/2Gbit/s)

FCoE (10Gbit/s)

iSCSI (10/1Gbit/s)

Number of controllers

2 - 8

Number of host interfaces

4 – 128 ports

- Notes

Mixed configurations are possible.

Number of hosts

Max. 8,192

Cache memory capacity

Max. 1,152 GB

Number of drive enclosures

Max. 128 (3.5", 2.5")

Number of drives

Max. 3,072 (2.5") / Max. 1,536 (3.5")

Storage capacity

Physical capacity

Max. 6,144.0 TB

Logical capacity

Max. 4,785.3 TB

Drives

3.5-inch

SAS disk drives

600 GB/450 GB/300 GB (15,000 rpm)

Nearline SAS disk drives

4 TB/3 TB/2 TB/1 TB (7,200 rpm)

SSD (Solid State Drives)

800 GB/400 GB/200 GB/100 GB

2.5-inch

SAS Non-Encrypting drives

900 GB/600 GB/450 GB/300 GB (10,000 rpm), 300GB (15,000 rpm)

SAS Self-Encrypting drives

900 GB/600 GB/450 GB/300 GB (10,000 rpm)

Nearline SAS disk drives

1 TB (7,200 rpm)

SSD (Solid State Drives)

800 GB/400 GB/200 GB/100 GB

Drive interface

Serial Attached SCSI (6Gbit/s)

Back-End Disk Connectivity

32 pairs of four-lane x 6 Gbit/s SAS buses (SAS 2.0 Wide)

Redundancies

RAID Controller, Fan, Power Supply

Number of LUN

Max. 65,535

LUN capacity

Max. 128TB

Number of Snapshots

Max. 32,768

Number of copy generations

256

Remote Copy feature

Yes

Datasheet Fujitsu ETERNUS DX8700 S2 Disk Storage System

Page 4 of 5

www.fujitsu.com/eternus/

Installation Specification (Continued)

Operating environment

FTS 04230 Guideline for Data Center (installation locations)

Management

Interfaces

Ethernet (1000 Base-T / 100 Base-TX / 10 Base-T)

Supported protocols

SNMP (version1, 2C, 3), SMI-S 1.4

Administration

Web-Environment, CLI (Command Line Interface)

Compliance With Standards

Product safety

UL60950-1, CSA-C22.2 No. 60950-1, EN60950-1, IEC60950-1, GOST-R

Electromagnetic Compatibility

FCC CFR47 part 15 Class A, ICES-003 Class A,

EN55022 Class A, VCCI Class A, AS/NZS CISPR22 Class A

Electromagnetic Immunity

EN55024

CE certification

Electromagnetic Compatibility Directive 2004/108/EC

Low Voltage Directive 2006/95/EC

Environmental compliance

RoHS-compliant (Restriction of hazardous substances)

WEEE-compliant (Waste electrical and electronical equipment)

- Notes

There is general compliance with the safety requirements of all European

countries and North America. National approvals required in order to satisfy

statutory regulations or for other reasons can be applied for on request.

Maintenance and Support Services

The perfect extension of the product specific base warranty for optimized operation.

Recommended Service: 24 x 7 Fujitsu support for enterprise class

services.

Please check your specific service level with your FUJITSU sales organization or partner.

Supported configurations

A wide range of host operating systems, servers as well as applications is supported.

For a detailed support matrix check

:

http://www.fujitsu.com/global/services/computing/storage/eternus/products/diskstorage/dx

8000/supported-device/

Datasheet Fujitsu ETERNUS DX8700 S2 Disk Storage System

Page 5 of 5

www.fujitsu.com/eternus/

About Fujitsu

America

Fujitsu America, Inc., is a leading ICT solutions provider for organizations in the U.S., Canada and the Caribbean. Fujitsu e

nables clients to meet

their business objectives through integrated offerings and solutions, including consulting, systems

integration, managed services, outsourcing

and cloud services for infrastructure, platforms and applications; data center and field services; and server, storage, softw

are and mobile/tablet

technologies. For more information, please visit:

http://solutions.us.fujitsu.com/ and http://twitter.com/fujitsuamerica

In addition to Fujitsu ETERNUS DX, Fujitsu

provides a range of platform solutions. They

combine reliable Fujitsu products with the

best in services, know-how and worldwide

partnerships.

Dynamic Infrastructures

With the Fujitsu Dynamic Infrastructures

approach, Fujitsu offers a full portfolio of IT

products, solutions and services, ranging

from clients to datacenter solutions,

Managed Infrastructure and

Infrastructure-as-a-Service. How much you

benefit from Fujitsu technologies and

services depends on the level of cooperation

you choose. This takes IT flexibility and

efficiency to the next level.

Computing products

www.fujitsu.com/global/services/computing/

- PRIMERGY: Industry standard server

- SPARC Enterprise: UNIX server

- PRIMEQUEST: Mission-critical IA server

- ETERNUS: Storage system

Software

www.fujitsu.com/software/

- Interstage: Application infrastructure

software

- Systemwalker: System management

softwar

e

Contact

FUJITSU AMERICA, INC.

Address: 1250 East Arques Avenue, Sunnyvale, CA

94085

-3470,USA

Tel: 800 3180 or 408 746 6000

Web:

http://solutiions.us.fujitsu.com

Contact Form: http:..

solutions.us.fujitsu.com/contact

Have a question? Email us at

: AskFujitsu@us.fujitsu.com

More information

Learn more about Fujitsu ETERNUS DX8700

S2, please contact your Fujitsu sales

representative, Fujitsu business partner, or

visit our website.

http://solutions.us.fujitsu.com/www/content/

products/storage/ETERNUS/index.php

Fujitsu green policy innovation

Fujitsu Green Policy Innovation is our

worldwide project for reducing burdens on

the environment. Using our global

know-how, we aim to resolve issues of

environmental energy efficiency through IT.

Please find further information at:

www.fujitsu.com/global/about/environment/

Copyright

Fujitsu, the Fujitsu logo ETERNUS, PRIM

EQUEST, Interstage and Systemwalker are

trademarks or registered trademarks of

Fujitsu Limited in the United States and

other countries. PRIMERGY is a trademark or

registered trademark of Fujitsu Technology

Solutions in the United States and other

countries. SPARC Enterprise is a trademark or

registered trademark of SPARC International,

Inc. in the United States and other countries.

All other trademarks mentioned herein are

the property of their respective owners.

Product description data represents Fujitsu

design objectives and is provided for

comparative purposes; actual results may

vary based on a variety of factors.

Specifications are subject to change without

notice.

Copyright ©2013 Fujitsu America, Inc.

All rights reserved.

FPC58-3004-06 08/13

13.0964

Disclaimer

Technical data subject to modification and

delivery subject to availability. Any liability

that the data and illustrations are complete,

actual or correct is excluded. Designations

may be trademarks and/or copyrights of the

respective manufacturer, the use of which by

third parties for their own purposes may

infringe the rights of such owner.
