Standard Performance Evaluation Corporation

info@spec.org

http://www.spec.org/ Page 1

specSPEC CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Fujitsu

PRIMERGY RX350 S8, Intel Xeon E5-2667 v2, 3.30 GHz

SPECfp2006 = 113

SPECfp_base2006 = 109

CPU2006 license: 19 Test date: Sep-2013

Test sponsor: Fujitsu Hardware Availability: Oct-2013

Tested by: Fujitsu Software Availability: Sep-2013

410.bwaves

416.gamess

433.milc

434.zeusmp

435.gromacs

436.cactusADM

437.leslie3d

444.namd

447.dealII

450.soplex

453.povray

454.calculix

459.GemsFDTD

465.tonto

470.lbm

481.wrf

482.sphinx3

SPECfp2006 = 113

SPECfp_base2006 = 109

0 64020.0 50.0 80.0 100 120 140 160 180 200 220 240 260 280 300 320 340 360 380 400 420 440 460 480 500 520 540 560 580 600

492

37.6

43.3

77.0

78.0

185

50.0

634

331

27.5

28.1

63.5

53.9

53.0

63.5

52.8

57.4

210

224

44.1

54.3

577

121

87.4

Hardware

CPU Name: Intel Xeon E5-2667 v2

CPU Characteristics: Intel Turbo Boost Technology up to 4.00 GHz

CPU MHz: 3300

FPU: Integrated

CPU(s) enabled: 16 cores, 2 chips, 8 cores/chip, 2 threads/core

CPU(s) orderable: 1,2 chips

Primary Cache: 32 KB I + 32 KB D on chip per core

Secondary Cache: 256 KB I+D on chip per core

Software

Operating System: Red Hat Enterprise Linux Server release 6.4

(Santiago)

2.6.32-358.11.1.el6.x86_64

Compiler: C/C++: Version 14.0.0.080 of Intel C++ Studio XE

for Linux;

Fortran: Version 14.0.0.080 of Intel Fortran

Studio XE for Linux

Auto Parallel: Yes

File System: ext4

Continued on next page Continued on next page

Standard Performance Evaluation Corporation

info@spec.org

http://www.spec.org/ Page 2

specSPEC CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Fujitsu

PRIMERGY RX350 S8, Intel Xeon E5-2667 v2, 3.30 GHz

SPECfp2006 = 113

SPECfp_base2006 = 109

CPU2006 license: 19 Test date: Sep-2013

Test sponsor: Fujitsu Hardware Availability: Oct-2013

Tested by: Fujitsu Software Availability: Sep-2013

L3 Cache: 25 MB I+D on chip per chip

Other Cache: None

Memory: 256 GB (16 x 16 GB 2Rx4 PC3-14900R-13, ECC)

Disk Subsystem: 1 x SATA, 500 GB, 7200 RPM

Other Hardware: None

System State: Run level 5 (multi-user)

Base Pointers: 64-bit

Peak Pointers: 32/64-bit

Other Software: None

Results Table

Benchmark Seconds Ratio Seconds Ratio Seconds Ratio

Base Seconds Ratio Seconds Ratio Seconds Ratio

Peak

410.bwaves 27.2 499 27.6 492 27.6 492 27.2 499 27.6 492 27.6 492

416.gamess 523 37.5 520 37.6 521 37.6 451 43.4 453 43.3 452 43.3

433.milc 119 77.0 119 76.9 119 77.0 116 79.4 118 78.0 118 78.0

434.zeusmp 49.2 185 49.4 184 49.0 186 49.2 185 49.4 184 49.0 186

435.gromacs 143 49.9 143 50.0 143 50.0 143 49.9 143 50.0 143 50.0

436.cactusADM 18.8 634 19.0 628 18.8 634 18.8 634 19.0 628 18.8 634

437.leslie3d 28.4 331 28.4 331 28.0 335 28.4 331 28.4 331 28.0 335

444.namd 291 27.5 291 27.5 290 27.7 285 28.2 285 28.1 285 28.1

447.dealII 180 63.5 180 63.5 180 63.5 180 63.5 180 63.5 180 63.5

450.soplex 153 54.4 155 53.9 156 53.5 153 54.4 155 53.9 156 53.5

453.povray 100 53.0 101 52.8 97.7 54.4 83.9 63.4 83.8 63.5 81.2 65.5

454.calculix 156 52.8 156 52.8 157 52.6 144 57.4 145 57.0 144 57.4

459.GemsFDTD 50.8 209 50.6 210 50.4 211 47.3 224 46.9 226 47.5 223

465.tonto 222 44.3 223 44.1 224 44.0 181 54.3 184 53.6 181 54.3

470.lbm 24.2 567 23.6 582 23.8 577 24.2 567 23.6 582 23.8 577

481.wrf 92.2 121 91.4 122 92.4 121 92.2 121 91.4 122 92.4 121

482.sphinx3 223 87.4 222 87.9 225 86.7 223 87.4 222 87.9 225 86.7

Results appear in the order in which they were run. Bold underlined text indicates a median measurement.

Operating System Notes

Stack size set to unlimited using "ulimit -s unlimited"

Platform Notes

BIOS configuration:

Energy Performance = Performance

Utilization Profile = Unbalanced

General Notes

Environment variables set by runspec before the start of the run:

KMP_AFFINITY = "granularity=fine,compact,1,0"

LD_LIBRARY_PATH = "/SPECcpu2006/libs/32:/SPECcpu2006/libs/64:/SPECcpu2006/sh"

Continued on next page

Standard Performance Evaluation Corporation

info@spec.org

http://www.spec.org/ Page 3

specSPEC CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Fujitsu

PRIMERGY RX350 S8, Intel Xeon E5-2667 v2, 3.30 GHz

SPECfp2006 = 113

SPECfp_base2006 = 109

CPU2006 license: 19 Test date: Sep-2013

Test sponsor: Fujitsu Hardware Availability: Oct-2013

Tested by: Fujitsu Software Availability: Sep-2013

General Notes (Continued)

OMP_NUM_THREADS = "16"

Binaries compiled on a system with 1x Core i7-860 CPU + 8GB

memory using RedHat EL 6.4

Transparent Huge Pages enabled with:

echo always > /sys/kernel/mm/redhat_transparent_hugepage/enabled

runspec command invoked through numactl i.e.:

numactl --interleave=all runspec <etc>

This result was measured on the PRIMERGY RX350 S8.The PRIMERGY RX350 S8

and the PRIMERGY TX300 S8 are electronically equivalent.

For information about Fujitsu please visit: http://www.fujitsu.com

Base Compiler Invocation

C benchmarks:

icc -m64

C++ benchmarks:

icpc -m64

Fortran benchmarks:

ifort -m64

Benchmarks using both Fortran and C:

icc -m64 ifort -m64

Base Portability Flags

410.bwaves: -DSPEC_CPU_LP64

416.gamess: -DSPEC_CPU_LP64

433.milc: -DSPEC_CPU_LP64

434.zeusmp: -DSPEC_CPU_LP64

435.gromacs: -DSPEC_CPU_LP64 -nofor_main

436.cactusADM: -DSPEC_CPU_LP64 -nofor_main

437.leslie3d: -DSPEC_CPU_LP64

444.namd: -DSPEC_CPU_LP64

447.dealII: -DSPEC_CPU_LP64

450.soplex: -DSPEC_CPU_LP64

453.povray: -DSPEC_CPU_LP64

454.calculix: -DSPEC_CPU_LP64 -nofor_main

459.GemsFDTD: -DSPEC_CPU_LP64

465.tonto: -DSPEC_CPU_LP64

470.lbm: -DSPEC_CPU_LP64

481.wrf: -DSPEC_CPU_LP64 -DSPEC_CPU_CASE_FLAG -DSPEC_CPU_LINUX

482.sphinx3: -DSPEC_CPU_LP64

Standard Performance Evaluation Corporation

info@spec.org

http://www.spec.org/ Page 4

specSPEC CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Fujitsu

PRIMERGY RX350 S8, Intel Xeon E5-2667 v2, 3.30 GHz

SPECfp2006 = 113

SPECfp_base2006 = 109

CPU2006 license: 19 Test date: Sep-2013

Test sponsor: Fujitsu Hardware Availability: Oct-2013

Tested by: Fujitsu Software Availability: Sep-2013

Base Optimization Flags

C benchmarks:

-xAVX -ipo -O3 -no-prec-div -parallel -opt-prefetch -ansi-alias

C++ benchmarks:

-xAVX -ipo -O3 -no-prec-div -opt-prefetch -ansi-alias

Fortran benchmarks:

-xAVX -ipo -O3 -no-prec-div -parallel -opt-prefetch

Benchmarks using both Fortran and C:

-xAVX -ipo -O3 -no-prec-div -parallel -opt-prefetch -ansi-alias

Peak Compiler Invocation

C benchmarks:

icc -m64

C++ benchmarks:

icpc -m64

Fortran benchmarks:

ifort -m64

Benchmarks using both Fortran and C:

icc -m64 ifort -m64

Peak Portability Flags

Same as Base Portability Flags

Peak Optimization Flags

C benchmarks:

433.milc: -xAVX(pass 2) -prof-gen(pass 1) -ipo(pass 2) -O3(pass 2)

-no-prec-div(pass 2) -prof-use(pass 2) -auto-ilp32

-ansi-alias

470.lbm: basepeak = yes

482.sphinx3: basepeak = yes

C++ benchmarks:

Continued on next page

Standard Performance Evaluation Corporation

info@spec.org

http://www.spec.org/ Page 5

specSPEC CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Fujitsu

PRIMERGY RX350 S8, Intel Xeon E5-2667 v2, 3.30 GHz

SPECfp2006 = 113

SPECfp_base2006 = 109

CPU2006 license: 19 Test date: Sep-2013

Test sponsor: Fujitsu Hardware Availability: Oct-2013

Tested by: Fujitsu Software Availability: Sep-2013

Peak Optimization Flags (Continued)

444.namd: -xAVX(pass 2) -prof-gen(pass 1) -ipo(pass 2) -O3(pass 2)

-no-prec-div(pass 2) -prof-use(pass 2) -fno-alias

-auto-ilp32

447.dealII: basepeak = yes

450.soplex: basepeak = yes

453.povray: -xAVX(pass 2) -prof-gen(pass 1) -ipo(pass 2) -O3(pass 2)

-no-prec-div(pass 2) -prof-use(pass 2) -unroll4 -ansi-alias

Fortran benchmarks:

410.bwaves: basepeak = yes

416.gamess: -xAVX(pass 2) -prof-gen(pass 1) -ipo(pass 2) -O3(pass 2)

-no-prec-div(pass 2) -prof-use(pass 2) -unroll2

-inline-level=0 -scalar-rep-

434.zeusmp: basepeak = yes

437.leslie3d: basepeak = yes

459.GemsFDTD: -xAVX(pass 2) -prof-gen(pass 1) -ipo(pass 2) -O3(pass 2)

-no-prec-div(pass 2) -prof-use(pass 2) -unroll2

-inline-level=0 -opt-prefetch -parallel

465.tonto: -xAVX(pass 2) -prof-gen(pass 1) -ipo(pass 2) -O3(pass 2)

-no-prec-div(pass 2) -prof-use(pass 2) -inline-calloc

-opt-malloc-options=3 -auto -unroll4

Benchmarks using both Fortran and C:

435.gromacs: basepeak = yes

436.cactusADM: basepeak = yes

454.calculix: -xAVX -ipo -O3 -no-prec-div -auto-ilp32 -ansi-alias

481.wrf: basepeak = yes

The flags files that were used to format this result can be browsed at

http://www.spec.org/cpu2006/flags/Intel-ic14.0-official-linux64.20140128.html

http://www.spec.org/cpu2006/flags/Fujitsu-Platform.20130924.html

You can also download the XML flags sources by saving the following links:

http://www.spec.org/cpu2006/flags/Intel-ic14.0-official-linux64.20140128.xml

http://www.spec.org/cpu2006/flags/Fujitsu-Platform.20130924.xml

Standard Performance Evaluation Corporation

info@spec.org

http://www.spec.org/ Page 6

specSPEC CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Fujitsu

PRIMERGY RX350 S8, Intel Xeon E5-2667 v2, 3.30 GHz

SPECfp2006 = 113

SPECfp_base2006 = 109

CPU2006 license: 19 Test date: Sep-2013

Test sponsor: Fujitsu Hardware Availability: Oct-2013

Tested by: Fujitsu Software Availability: Sep-2013

Originally published on 24 September 2013.

Report generated on Thu Jul 24 16:10:40 2014 by SPEC CPU2006 PS/PDF formatter v6932.

Tested with SPEC CPU2006 v1.2.

For other inquiries, please contact webmaster@spec.org.

For questions about this result, please contact the tester.

holders.

this result are trademarks or registered trademarks of their respective

Evaluation Corporation. All other brand and product names appearing in

SPEC and SPECfp are registered trademarks of the Standard Performance
