Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 1 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Data Sheet
FUJITSU Server PRIMERGY RX2530 M1 Dual socket
1U rack server
Maximum productivity in a 1U housing
PRIMERGY RX2530 M1
The FUJITSU Server PRIMERGY RX2530 M1 is a
rack server that provides high performance,
expandability and energy efciency in a 1U space
saving housing. The PRIMERGY RX2530 M1 is
ideal for virtualization, scale-out scenarios, and
small databases as well as for high performance
computing thanks to the high performance of the
new Intel® Xeon® processor E5-2600 v3 product
family with up to 18 cores and the latest DDR4
memory technology. Moreover, the RX2530 M1
delivers a great expandability by supporting up
to 1536 GB of DDR4 memory up to 10 hard disk
drives and optionally up to four high-speed PCIe
SSDs as well as exible DynamicLoM technology,
to ensure future requirements are met and
budgets are saved. The limited space of a 1U
chassis offers highly efcient power supply units,
their redundancy on demand and the optional
Cool-safe® Advanced Thermal Design this will
result in lower operational costs.
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 2 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Features & Benefits
Main Features Benefits
Versatile Performance to cope with data growth
Intel® Xeon® E5-2600 v3 product family with up to 18 cores
Up to 1536 GB DDR4 memory (24 DIMM slots)
Ideal scalability of either up to 8x 2.5-inch HDD/SSD + 1x ODD or up
to 10x 2.5-inch, thereof optionally up to 4x PCIe 2.5-inch SSD SFF
4x PCIe Gen3 slots
Ready for the future and data growth scenarios with the
performance of two processors – marking the standard of tomorrow
with an increase in computing power
DDR4 memory enables for higher bandwidth and lower
consumption, optimized for virtualization and clouds, small data
centers and high performance computing
Flexible expandability and diverse options for storage devices
permits for the integration of existing and new SSD and HDD as
needed. Less today, more in future – or vice versa.
Increased Energy Effciency
Fujitsu’s Cool-safe® Advanced Thermal Design for higher ambient
temperatures in the data center
Power supply units with 96% energy efciency
Higher ambient temperatures lead to lower costs for cooling the
data center
Highly efcient hot-plug power supplies save energy costs and
make it easy to maintain the running system and ensure a 99,997%
uptime
Foundation for Trust and Security
Fujitsu ServerView Suite including tools for installation and
deployment, permanent status monitoring and control
BIOS, rmware and selected software are updated free of charge
The comprehensive tools of the Fujitsu ServerView Suite eases the
administrators life
Updates are very important in a fast-paced world, especially
considering cyber crime
Innovations simplifying management and freeing up IT resources
DynamicLoM to select the network connector of your choice -
“plug&play-design” with 3 different port types, 3 different numbers
of ports, and 2 different speeds and no need to upgrade to a new
chip or new drivers.
RAID Controller embedded
DynamicLoM guarantees the highest exibility to integrate the
server into existing infrastructures – now and in future without
overhauling the existing infrastructure
For cost efcient and basic RAID requirements, support for the most
common congurations is conveniently embedded on the system
board and does not require a dedicated controller
Extended lifecycle
The PRIMERGY RX2530 M1 is available for an extended time frame.
While the regular lifecycle of PRIMERGY RX servers is around two
years, congurations with the „long lifecycle“ option however can be
ordered over ve years
The extended availability offers planning reliability for long-term
projects, integrated systems and public sector customers where a
server system has to stay the same over a longer period of time
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 3 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Technical details
PRIMERGY RX2530 M1
Base unit PRIMERGY RX2530 M1 LFF PRIMERGY RX2530 M1 SFF PRIMERGY RX2530 M1 SFF
Housing types Rack Rack Rack
Storage drive architecture 4x 3.5-inch SAS/SATA 8x 2.5-inch SAS/SATA 10x 2.5-inch SAS/SATA/PCIe
Power supply Hot-plug Hot-plug Hot-plug
Product Type Dual Socket Rack Server Dual Socket Rack Server Dual Socket Rack Server
Mainboard
Mainboard type D3279
Chipset Intel® C612
Processor quantity and type 1 - 2 x Intel® Xeon® processor E5-2600 v3 product family
Intel® Xeon® processor E5-2603v3 (6C/6T, 1.60 GHz, TLC: 15 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,600 MHz, 85 W, AVX Base 1.30 GHz)
Processor Intel® Xeon® processor E5-2609v3 (6C/6T, 1.90 GHz, TLC: 15 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,600 MHz, 85 W, AVX Base 1.90 GHz)
Intel® Xeon® processor E5-2620v3 (6C/12T, 2.40 GHz, TLC: 15 MB, Turbo: 2.60 GHz, 8.0 GT/s, Mem bus: 1,866 MHz, 85 W, AVX Base
2.10 GHz, AVX Turbo 2.60 GHz)
Intel® Xeon® processor E5-2623v3 (4C/8T, 3.00 GHz, TLC: 10 MB, Turbo: 3.30 GHz, 8.0 GT/s, Mem bus: 1,866 MHz, 105 W, AVX Base
2.70 GHz, AVX Turbo 3.30 GHz)
Intel® Xeon® processor E5-2630Lv3 (8C/16T, 1.80 GHz, TLC: 20 MB, Turbo: 2.10 GHz, 8.0 GT/s, Mem bus: 1,866 MHz, 55 W, AVX Base
1.50 GHz, AVX Turbo 2.10 GHz)
Intel® Xeon® processor E5-2630v3 (8C/16T, 2.40 GHz, TLC: 20 MB, Turbo: 2.60 GHz, 8.0 GT/s, Mem bus: 1,866 MHz, 85 W, AVX Base
2.10 GHz, AVX Turbo 2.60 GHz)
Intel® Xeon® processor E5-2637v3 (4C/8T, 3.50 GHz, TLC: 15 MB, Turbo: 3.60 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 135 W, AVX Base
3.20 GHz, AVX Turbo 3.50 GHz)
Processor Intel® Xeon® processor E5-2640v3 (8C/16T, 2.60 GHz, TLC: 20 MB, Turbo: 2.80 GHz, 8.0 GT/s, Mem bus: 1,866 MHz, 90 W, AVX Base
2.20 GHz, AVX Turbo 2.80 GHz)
Intel® Xeon® processor E5-2643v3 (6C/12T, 3.40 GHz, TLC: 20 MB, Turbo: 3.60 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 135 W, AVX Base
2.80 GHz, AVX Turbo 3.40 GHz)
Intel® Xeon® processor E5-2650Lv3 (12C/24T, 1.80 GHz, TLC: 30 MB, Turbo: 2.10 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 65 W, AVX Base
1.50 GHz, AVX Turbo 2.10 GHz)
Intel® Xeon® processor E5-2650v3 (10C/20T, 2.30 GHz, TLC: 25 MB, Turbo: 2.60 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 105 W, AVX Base
2.00 GHz, AVX Turbo 2.60 GHz)
Intel® Xeon® processor E5-2660v3 (10C/20T, 2.60 GHz, TLC: 25 MB, Turbo: 2.90 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 105 W, AVX Base
2.20 GHz, AVX Turbo 2.90 GHz)
Intel® Xeon® processor E5-2667v3 (8C/16T, 3.20 GHz, TLC: 20 MB, Turbo: 3.40 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 135 W, AVX Base
2.70 GHz, AVX Turbo 3.30 GHz)
Intel® Xeon® processor E5-2670v3 (12C/24T, 2.30 GHz, TLC: 30 MB, Turbo: 2.60 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 120 W, AVX Base
2.00 GHz, AVX Turbo 2.60 GHz)
Processor Intel® Xeon® processor E5-2680v3 (12C/24T, 2.50 GHz, TLC: 30 MB, Turbo: 2.90 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 120 W, AVX Base
2.10 GHz, AVX Turbo 2.80 GHz)
Intel® Xeon® processor E5-2683v3 (14C/28T, 2.00 GHz, TLC: 35 MB, Turbo: 2.50 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 120 W, AVX Base
1.70 GHz, AVX Turbo 2.50 GHz)
Intel® Xeon® processor E5-2690v3 (12C/24T, 2.60 GHz, TLC: 30 MB, Turbo: 3.10 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 135 W, AVX Base
2.30 GHz, AVX Turbo 3.00 GHz)
Processor Intel® Xeon® processor E5-2695v3 (14C/28T, 2.30 GHz, TLC: 35 MB, Turbo: 2.80 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 120 W, AVX Base
1.90 GHz, AVX Turbo 2.60 GHz)
Intel® Xeon® processor E5-2697v3 (14C/28T, 2.60 GHz, TLC: 35 MB, Turbo: 3.10 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 145 W, AVX Base
2.20 GHz, AVX Turbo 2.90 GHz)
Intel® Xeon® processor E5-2698v3 (16C/32T, 2.30 GHz, TLC: 40 MB, Turbo: 2.80 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 135 W, AVX Base
1.90 GHz, AVX Turbo 2.50 GHz)
Intel® Xeon® processor E5-2699v3 (18C/36T, 2.30 GHz, TLC: 45 MB, Turbo: 2.80 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 145 W, AVX Base
1.90 GHz, AVX Turbo 2.60 GHz)
Memory slots 24 (12 DIMMs per CPU, 4 channels with 3 slots per channel)
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 4 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Memory slot type DIMM (DDR4)
Memory capacity (min. - max.) 8 GB - 1.536 GB
Memory protection Advanced ECC
Memory Scrubbing
SDDC
Rank sparing memory support
Memory Mirroring support
Memory notes Memory Mirroring with identical modules in both channel pairs of a bank (4 modules per bank), Rank sparing or
Performance Mode with identical modules in all four channels (4 modules per bank).
8 GB (1 8 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133R, DIMM, 1Rx4
8 GB (1 8 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133R, DIMM, 2Rx8
Memory options 16 GB (1 module(s) 16 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133R, DIMM, 2Rx4
32 GB (1 32 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133R, DIMM, 2Rx4
Memory options 32 GB (1 module(s) 32 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133P, LRDIMM, 4Rx4
64 GB (1 64 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133P, LRDIMM, 4Rx4
Interfaces
USB 2.0 ports 1 x USB 2.0 (1x rear)
USB 3.0 ports 5 x USB 3.0 (2x front, 2x rear, 1x internal) - for base unit with 10x 2.5” drives 1x USB2.0 at front only
Graphics (15-pin) 2 x VGA (thereof 1x front optional - not for base unit with 10x 2.5” drives)
Serial 1 (9-pin) 1 x optional (occupies PCIe slot)
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S4 (10/100/1000 Mbit/s)
Management LAN trafc can be switched to shared onboard LAN controller port, speed and connector is related to
installed interface card.
Onboard or integrated Controller
RAID controller All hardware storage controller options are described under Components
SATA Controller Intel® C612, 1 x SATA channel for ODD
LAN Controller DynamicLoM based on Emulex XE100 series
2 x 1 Gbit/s Dynamic LoM
4 x 1 Gbit/s Dynamic LoM
2 x 10 Gbit/s 10GBASE-T Dynamic LoM
2 x 10 Gbit/s SFP+ Dynamic LoM
All supported features are described in relevant system congurator.
PXE-Boot via LAN from PXE server, iSCSI / FCoE boot (also diskless).
Extra LAN controller(PCIe Cards) are listed below. (i210 LAN card via project release possible)
Remote management controller Integrated Remote Management Controller (iRMC S4, 256 MB attached memory incl. graphics controller)
IPMI 2.0 compatible
Onboard controller notes Onboard 8x S-ATA 6Gbit/s RAID Controller (RAID 0,1) for up to 8x S-ATA drives available.
Trusted Platform Module (TPM) Inneon / TPM 1.2 module; TCG compliant (option)
Slots
PCI-Express 3.0 x8 2 x Low prole
PCI-Express 3.0 x16 2 x Low prole (2nd processor required for slot 4); 1x16 if fh slot selected
Slot Notes Slot 1 (internal): PCIe Gen3 x8 @CPU1 is dedicated for the modular RAID Controller.
Slot 2: PCIe Gen3 x8 @CPU1 for low prole cards with up to 167mm length
Slot 3: PCIe Gen3 x16 @CPU1 for low prole cards with up to 167mm length
Slot 4 standard: PCIe Gen3 x16 @CPU2 for low prole cards with up to 167mm length
Slot 4 option: PCIe Gen3 x16 @CPU2 for full height cards with up to 167mm length (!in this case, slot 3 is not
available)
Drive bays (Base unit specic)
Storage drive bays up to 8 x 2.5-inch, 10 x 2.5-inch or 4 x 3.5-inch baseunit
Accessible drive bays 1 x 5.25/0.4-inch for CD-RW/DVD
Notes accessible drives Not for 10 x 2.5-inch base unit. All possible options described in relevant system congurator.
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 5 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Drive bays (Base unit specic)
Storage drive bays up to 4x 3.5” (LFF) hot plug drives
(SAS/SATA)
up to 4x 2.5” (SFF) hot plug drives
(SAS/SATA); option for upgrade to 8x
2.5” (SFF) hot plug drives
up to 10x 2.5” (SFF) hot plug drives
(SAS/SATA); therein up to 4x bays are
prepared for 2.5” PCIe Flash SSD.
Optional accessible drives Ultra slim 9.5mm optical drive
(optional)
Ultra slim 9.5mm optical drive
(optional)
-o-
Fan Conguration
Number of fans 8
Fan conguration redundant / hot-plug
Fan notes 3+1 double-fans for 1 CPU conguration; 7+1 double-fans for 2 CPU conguration
Operating panel
Operating buttons On/off switch
Reset button
NMI button
ID button
Status LEDs System status (orange / yellow)
Identication (blue)
Hard disks access (green)
Power (amber / green)
At system rear side:
System status (orange / yellow)
Identication (blue)
LAN connection (green)
LAN speed (green / yellow)
BIOS
BIOS features UEFI compliant
Legacy BIOS compatibility customer conguration option
Secure boot support
ROM based setup utility
GPT support for boot drives larger than 2.2 TB
Memory Redundancy support (Mirroring, Sparing)
IPMI support
Recovery BIOS
BIOS settings save and restore
Local BIOS update from USB device
Online update tools for main Linux versions
Local and remote update via ServerView Update Manager
IPv4/IPv6 remote PXE & iSCSI boot support
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 6 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Operating Systems and Virtualization Software
Certied or supported operating
systems and virtualization software
Microsoft® Hyper-V Server 2012 R2
Microsoft® Windows Server® 2012 R2 Datacenter
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Essentials
Microsoft® Windows Storage Server 2012 R2 Standard
Microsoft® Hyper-V Server 2012
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Essentials
Microsoft® Windows Storage Server 2012 Standard
Microsoft® Windows Server® 2008 R2 Datacenter
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2008 R2 Standard
VMware vSphere™ 6.5
VMware vSphere™ 6.0
VMware vSphere™ 5.5
VMware vSphere™ 5.1 Embedded
VMware vSphere™ 5.1
SUSE® Linux Enterprise Server 12
SUSE® Linux Enterprise Server 11
Red Hat® Enterprise Linux 7
Red Hat® Enterprise Linux 6
Citrix® XenServer®
Oracle® Linux 7
Oracle® Linux 6
Oracle® VM 3
Operating system release link http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Operating system notes Support of other Linux derivatives on demand
Server Management
Option ServerView embedded Lifecycle Management (eLCM)
Lifecycle management
ServerView Suite - Maintain
iRMC Advanced Pack incl. Advanced Video Redirection (AVR), video capturing and Virtual Media
ServerView Suite - Dynamize
Virtual-IO Manager (VIOM)
Server Management notes Regarding dependencies for ServerView Suite software products see dedicated product data sheets.
Dimensions / Weight
Rack (W x D x H) 483 mm (Bezel) / 435mm (Body) x 770.7 x 43 mm
Mounting Depth Rack 748.2 mm
Height Unit Rack 1 U
19” rackmount Yes
Mounting Cable depth rack 200 mm (1,000 mm Rack recommended)
Weight up to 16 kg
Weight notes Actual weight may vary depending on conguration
Rack integration kit Rack integration kit as option
Environment
Operating ambient temperature 5 - 40 °C (41 - 104 °F)
Operating temperature note Cool-safe® Advanced Thermal Design (above 35 °C or below 10 °C) depending on conguration. For detailed
information see relevant system congurator.
Operating relative humidity 10 - 85 % (non condensing)
Operating environment FTS 04230 – Guideline for Data Center (installation specication)
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 7 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Components
Environment
Operating environment link http://docs.ts.fujitsu.com/dl.aspx?id=589915e9-1bf8-40f7-8ba4-7cac9371f2f0
Noise emission Measured according to ISO 7779 and declared according to ISO 9296
Sound pressure (LpAm) Noise minimum conguration: 35 dB(A) (idle) / 44 dB(A) (operating)
Noise typical conguration: 35 dB(A) (idle) / 44 dB(A) (operating)
Sound power (LWAd; 1B = 10dB) Noise minimum conguration: 5.2 B (idle) / 6.2 B (operating)
Noise typical conguration: 5.2 B (idle) / 6.2 B (operating)
Noise notes Noise emissions depends on operation modes, system conguration and ambient temperature.
Operating mode measured based on OLTIS with 50% load. *OLTIS = FUJITSU Load Prole which stresses all
components of a server with a given load level.
Electrical values
Power supply conguration 1 x hot-plug power supply or 2 x hot-plug power supply for redundancy
Hot-plug power supply redundancy Optional
Active power (max. conguration) 816 W
Apparent power (max. conguration) 825 VA
Heat emission (max. conguration) 2937.6 kJ/h (2784.3 BTU/h)
Rated current max. 8.5 A (100 V) / 3.5 A (240 V)
Active power note To estimate the power consumption of different congurations use the Power Calculator of the System Architect:
http://congurator.ts.fujitsu.com/public/
Power supply 450W hot-plug, 94% (Platinum efciency), 100-240V, 50 / 60Hz
800W hot-plug, 94% (Platinum efciency), 100-240V, 50 / 60Hz
800W hot-plug, 96% (Titanium efciency), 200-240V, 50 / 60Hz
Power supply notes Power Safeguard adapts system performance in case the power requirements exceeds supply limits.
!96% Titanium Power supply unit is only released for 200-240V
Compliance
Global CB
RoHS (Substance limitations in accordance with global RoHS regulations)
WEEE (Waste electrical and electronical equipment)
Europe CE
USA/Canada CSAc/us
ICES-003 / NMB-003 Class A
FCC Class A
Japan VCCI:V3 Class A + JIS 61000-3-2
South Korea KC (planned)
China CCC (planned)
Australia/New Zealand C-Tick (planned)
Taiwan CNS 13438 class A - planned
Compliance link https://sp.ts.fujitsu.com/sites/certicates
Compliance notes There is general compliance with the safety requirements of all European countries and North America. National
approvals required in order to satisfy statutory regulations or for other reasons can be applied for on request.
* Warning:
This is a class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
Optical drives Blu-ray Disc™ Triple Writer, (6x BD-RW, 8x DVD, 24x CD), ultraslim, SATA I
DVD Super Multi ultra slim , (8x DVD; 24x CD), ultraslim, SATA I
HDD SATA, 6 Gb/s, 250 GB, 7,200 rpm, 512n, hot-plug, 2.5-inch, business critical
Hard disk drives HDD SATA, 6 Gb/s, 6 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 4 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 3 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 8 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Hard disk drives HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, 512e, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512n, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512e, hot-plug, 2.5-inch, business critical
Hard disk drives HDD SAS, 12 Gb/s, 900 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 900 GB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 15,000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 15,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, 512n, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 450 GB, 15,000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 450 GB, 15,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 450 GB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 15,000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 15,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 10,000 rpm, 512n, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 6 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 4 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 2 TB , 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 2 TB , 7,200 rpm, 512e, hot-plug, 2.5-inch, business critical
HDD SAS, 12 Gb/s, 1.8 TB, 10,000 rpm, 512e, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.8 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, 512n, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 1 TB, 7,200 rpm, 512e, hot-plug, 2.5-inch, business critical
HDD SAS, 6 Gb/s, 900 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 600 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 500 GB, 7,200 rpm, hot-plug, 2.5-inch, business critical
Hard disk drives HDD SAS, 6 Gb/s, 300 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 4 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 3 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
Hard disk drives HDD SAS, 6 Gb/s, 2 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 1.2 TB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 1 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 1 TB, 7,200 rpm, hot-plug, 2.5-inch, business critical
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 9 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Solid-State-Drive SSD SATA, 6 Gb/s, 960 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 960 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 800 GB, Read-Intensive Endurance, hot-plug, 3.5-inch, enterprise, 0.3 DWPD (drive writes per day
for 5 years)
SSD SATA, 6 Gb/s, 800 GB, Mainstream Endurance, hot-plug, 3.5-inch, enterprise
SSD SATA, 6 Gb/s, 800 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise
SSD SATA, 6 Gb/s, 800 GB, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Read-Intensive Endurance, hot-plug, 3.5-inch, enterprise, 0.3 DWPD (drive writes per day
for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 400 GB, Mainstream Endurance, hot-plug, 3.5-inch, enterprise
SSD SATA, 6 Gb/s, 400 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise
SSD SATA, 6 Gb/s, 240 GB, Read-Intensive Endurance, hot-plug, 3.5-inch, enterprise, 0.3 DWPD (drive writes per day
for 5 years)
SSD SATA, 6 Gb/s, 240 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 240 GB, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 240 GB, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 200 GB, Mainstream Endurance, hot-plug, 3.5-inch, enterprise
SSD SATA, 6 Gb/s, 200 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise
SSD SATA, 6 Gb/s, 120 GB, Read-Intensive Endurance, hot-plug, 3.5-inch, enterprise, 0.3 DWPD (drive writes per day
for 5 years)
SSD SATA, 6 Gb/s, 120 GB, Read-Intensive Endurance, hot-plug, 2.5-inch, enterprise, 0.3 DWPD (drive writes per day
for 5 years)
SSD SATA, 6 Gb/s, 120 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 120 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 1.92 TB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 1.92 TB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
Solid-State-Drive SSD SAS, 12 Gb/s, 800 GB, Mainstream Endurance, hot-plug, 3.5-inch, enterprise, 10 DWPD (drive writes per day for 5
years)
SSD SAS, 12 Gb/s, 800 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise, 10 DWPD (drive writes per day for 5
years)
SSD SAS, 12 Gb/s, 400 GB, Mainstream Endurance, hot-plug, 3.5-inch, enterprise, 10 DWPD (drive writes per day for 5
years)
SSD SAS, 12 Gb/s, 400 GB, Mainstream Endurance, hot-plug, 2.5-inch, enterprise, 10 DWPD (drive writes per day for 5
years)
PCIe SSD & SATA DOM SSD PCIe-SSD SFF, 800 GB, MLC, 2.5-inch, Flash drive, 10 DWPD (drive writes per day for 5 years)
PCIe-SSD SFF, 2 TB, MLC, 2.5-inch, Flash drive, 10 DWPD (drive writes per day for 5 years)
PCIe-SSD SFF, 1.6 TB, MLC, 2.5-inch, Flash drive, 10 DWPD (drive writes per day for 5 years)
PCIe-SSD AIC, 5.2 TB, MLC, Standard Height, Half-Length, Flash drive, 6.7 DWPD (drive writes per day for 5 years)
PCIe-SSD AIC, 2.6 TB, MLC, Low Prole, Flash drive, 6.7 DWPD (drive writes per day for 5 years)
PCIe-SSD AIC, 1.3 TB, MLC, Low Prole, Flash drive, 6.7 DWPD (drive writes per day for 5 years)
DOM SATA, 6 Gb/s, 128 GB, non hot plug, enterprise, 0.054 DWPD (drive writes per day for 5 years)
DOM SATA, 6 Gb/s, 64 GB, non hot plug, enterprise, 384 TBW (based on JEDEC 218)
DOM SATA, 6 Gb/s, 64 GB, non hot plug, enterprise, 0.054 DWPD (drive writes per day for 5 years)
SCSI / SAS Controller LSI PSAS CP400e LP SAS Ctrl. 12 Gbit/s 8 ports ext. PCIe 3.0 x8
Fujitsu PSAS CP400i SAS Ctrl. 12 Gbit/s 8 ports int. PCIe 3.0 x8
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 10 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
RAID Controller Fujitsu PRAID EP420i, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB, Optional FBU based on LSI SAS3108
Fujitsu PRAID EP400i, RAID 5/6 Ctrl., SAS/SATA/PCIe-NVMe 12 Gbit/s, 16 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU based on LSI SAS3108
Fujitsu PRAID CP400i, RAID Ctrl., SAS/SATA 12 Gbit/s, 8 ports int.
RAID level: 0, 1, 1E, 10, 5, 50, No FBU support
Fibre Channel controller Fibre Channel Host Bus Adapter 1 x 8 Gbit/s Qlogic QLE2560 MMF LC-style
Fibre Channel Host Bus Adapter 2 x 8 Gbit/s Qlogic QLE2562 MMF LC-style
Fibre Channel Host Bus Adapter 1 x 8 Gbit/s Emulex LPe1250 MMF LC-style
Fibre Channel Host Bus Adapter 2 x 8 Gbit/s Emulex LPe12002 MMF LC-style
Fibre Channel Host Bus Adapter 1 x 16 Gbit/s Emulex LPe16000B LC-style
Fibre Channel Host Bus Adapter 2 x 16 Gbit/s Emulex LPe16002B LC-style
Fibre Channel Host Bus Adapter 1 x 16 Gbit/s Qlogic QLE2670 LC-style
Fibre Channel Host Bus Adapter 2 x 16 Gbit/s Qlogic QLE2672 LC-style
Communication, Network Converged Network Adapter 1 x 40 Gbit/s PCIe 3.0 x8 QSFP+ ( Emulex )
Converged Network Adapter 2 x 10 Gbit/s PCIe 3.0 x8 SFP+ ( Emulex )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe 2.0 x8 SFP+ ( Fujitsu )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe 2.1 x8 RJ45 ( Intel® )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe 3.0 x8 10Gbit/s Eth (RJ45) ( Emulex )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe 3.0 x8 SFP+ ( Emulex )
Ethernet Ctrl. 2 x 1 Gbit/s PCIe 2.1 x4 RJ45 ( Intel® )
Ethernet Ctrl. 4 x 1 Gbit/s PCIe 2.1 x4 RJ45 ( Intel® )
InniBand HCA 1 x 100 Gbit/s PCIe 3.0 x16 QSFP for the US market max. one IB HCA 100Gb controller can be installed
( Mellanox )
InniBand HCA 1 x 40 Gbit/s PCIe 2.0 x8 QSFP ( Intel® )
InniBand HCA 1 x 40 Gbit/s PCIe 3.0 x8 QSFP ( Mellanox )
InniBand HCA 1 x 56 Gbit/s PCIe 3.0 x8 QSFP for the US market max. one IB HCA 56Gb controller can be installed (
Mellanox )
InniBand HCA 2 x 100 Gbit/s PCIe 3.0 x16 QSFP for the US market max. one IB HCA 100Gb controller can be installed
( Mellanox )
InniBand HCA 2 x 40 Gbit/s PCIe 3.0 x8 QSFP ( Mellanox )
InniBand HCA 2 x 56 Gbit/s PCIe 3.0 x8 QSFP for the US market max. one IB HCA 56Gb controller can be installed (
Mellanox )
Interface modul for Dynamic LoM 2 x 10 Gbit/s RJ45 ( Emulex )
Interface modul for Dynamic LoM 2 x 10 Gbit/s SFP+ ( Emulex )
Interface modul for Dynamic LoM 2 x 1 Gbit/s RJ45 ( Emulex )
Interface modul for Dynamic LoM 4 x 1 Gbit/s RJ45 ( Emulex )
Rack infrastructure Rackmount kit full extraction (815mm), tool less mounting, length variable 559-914mm
Rackmount kit full extraction (815mm), tool less mounting, length variable 559-914mm
Cable Management 1U for PRIMECENTER- and 3rd-party racks
Warranty
Warranty period 3 years
Warranty type Onsite warranty
Warranty Terms & Conditions http://support.ts.fujitsu.com/warranty/Index.asp?LNG=COM
Product Related Services - the perfect extension
Support Pack Options X - Globally available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
Recommended Service X - 24x7, Onsite Response Time: 4h - For locations outside of EMEIA please contact your local Fujitsu partner.
Service Lifecycle 5 years after end of product life
Service Weblink http://ts.fujitsu.com/Supportservice
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 11 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Data Sheet FUJITSU Server PRIMERGY RX2530 M1 Dual socket 1U rack server
Page 12 / 12 http://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx2530m1/
Fujitsu platform solutions
In addition to Fujitsu PRIMERGY RX2530 M1,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a-
Service. How much you benet from Fujitsu
technologies and services depends on the
level of cooperation you choose. This takes IT
exibility and efciency to the next level.
Computing Products
www.fujitsu.com/global/products/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu PRIMERGY RX2530
M1, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
http://www.fujitsu.com/global/products/
computing/servers/primergy/rack/rx2530m1/
Fujitsu green policy innovation
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see http://ts.fujitsu.
com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner
More information
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
