SHENZHEN SAGE HUMAN ELECTRONICS CO.,LTD FM Transmitter Manual
Manual
FM TRANSMITTER
USER’S MANUAL
Model : C09
OPERATION MANUAL
1
Charging Port
LCD Display
3.5mm Jack Port
2
5
3
Flash Drive Port
4
1
2
Play
CH
Previous
Next
3
FEATURES
FM transmitter.
Charges your device via USB port
Supports 3.5mm jack port
Flash drive port
LCD display screen
Input voltage:12-24V, output power: 5V DC/2.1A
Supports MP3 and WMA format files
1
2
3
4
5
SPECIFICATIONS
2
1
4
FM TRANSMITTER FUNCTION
1Plug the FM transmitter into your vehicle’s cigarette lighter
Connect your device to your FM transmitter using the supplied 3.5 mm jack.
Tune your radio to an unused FM station, then match the same frequency on your FM transmitter
unit. To change frequency press the “CH” button on the side of your FM transmitter, then press
the “ ” button to increase frequency, or “ ” to decrease frequency. The FM transmitter will
play music through your car stereo.
Note: You can play music while charging your mobile phone.
2
3
5
FCC NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference
that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority
to operate this equipment.
QUICK GUIDE
PLAY/STOP
ADJUST THE
VOLUME
CHANGE
FREQUENCY
CHOOSE MUSIC
CHANGE PLAY
MODE
Press “PLAY” button : play the music
Press “PLAY” button a second time: stop the music
Hold down “ ” button: increase the Volume
Hold down “ ” button: decrease the Volume
Press “CH” first, then press “ ” button: increase the frequency
Press “CH” first, then press “ ” button: decrease the frequency
Press “ ” button: play the next song;
Press “ ” button: play the previous song;
Hold down “play/pause” button to switch the play modes:
All, Folder, Random and One
FUNCTION ON FM TRANSMITTER
SKU 20054 REV012014
