For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
Dimensions and Installation Information (in inches)
† Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
GSH25JFX
GE® 25.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Overall
Dimensions
Height to top of hinge (in.) A69-3/4
Height to top of case (in.) B68-3/4
Case depth without door (in.) C†28
Case depth less door handle (in.) D†31-1/4
Case depth with door handle (in.) E†33-5/8
Depth with fresh food door open 90° (in.) F†49-3/8
Width (in.) G35-3/4
Width with door open 90° inc. door handle (in.) H38-1/4
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 5/09 310101
GSHC2IFX
GSHC5IFX
Features and Benefits
• ExternalTemperatureControlswithChildLock-Combinestheeaseof0-9temperature
settings, with the sophistication of electronic controls
• AdjustableHumidityVegetable/FruitCrispers-Provideidealstorageenvironmentforfruits
and vegetables
• AdjustableTemperatureDeliDrawer-Keepmeatsandcheesesdelicious
• SnackPan-Convenientlystoresre-wrappedmeats,cheesesandothersnacks
• AdjustableGallonDoorBins-Providesadditionalstoragespaceformilkandothergallon-
size containers
• AdjustableSpillproofGlassShelves-Helpscontainspillsforeaseofcleaning
• GEWaterFiltrationSystem-Deliverscleangreat-tastingwaterandicethroughthe
LightTouch!Dispenser
• F r o s t G u a r d ™ Technology - Protects frozen items from freezer burn by monitoring freezer
door openings and defrosting only when needed
• AutoEnergySaver-Sensesfreezerandfreshdooropeningsandadjustsrefrigeration
operation cycles accordingly
• NeverClean™ Condenser - Condenser coils are encased, so they don't require cleaning in
normal operating environments
• DeluxeQuietDesign-Significantlyreducesoperatingnoise
• ModelGSH25JFXWW-Whiteonwhite
• ModelGSH25JFXCC-Bisqueonbisque
• ModelGSH25JFXBB-Blackonblack
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
GSH25JFX
GE® 25.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Specification Revised 5/09 310101
*
