QuickStartGuide(WB‐800)



Step1:GettingStarted



Step2:Hotspotconnectionandonlineconnection



Plugitin



1.Connectyourmobile

devicewiththeaudio

connectorbyWIFIsetting.

Andthen,youcanenjoythe

localmusic.

2.Inputthe192.168.78.1IP

address, and setup the

online connection.

3.ConnecttheWIFIconnectortoyourhomeWIFIrouterstepby

step.

Andthen,youcanenjoytheonlinemusic.

Lightindicator

BlueLightRedLight

FlashReadyforconnectionFailtoconnection

LightingSuccesstoconnectionNA



TheNameoftheaudioconnector

ThisconnectorcanupgradeHIFIsystem(Activespeaker)toWIFIsystem.



Step3:Connection(forIOS&android)



3.1iOS(Localandonlineplayback)



3.2Androiddevice(localcontentsplayback)



HTCSmartphone–OneX,M700,Desire,Butterfly



Note:

1. Forotherbrandandroidmobilephone,pleaseconnectbythesimilarways.

2. FortheAndroiddevice,pleaseremembertousemusicplayersupportingDLNA.Therearetwomostpopularmediaplayersupporting

theDLNA:

 



3.3:Androiddevice(onlinecontentsplayback)

Onlineplayback,pleaseusethemusicplayersupportingtheDLNA,egimediashare.



Sonysmartphone–XperiaSerialSamsungsmartphone–GalaxySerial



3.4WindowsPCbyWiFiMusicUtility

.PleasedownloadWiFiMusicAPPfromWebsitehttp://db.tt/GWVl2JX7,theninstallonyourWindowsdevice.

(SupportXP/Vista/7/8)

.TheWiFiMusiciconwillappearonyourdesktopafterinstalledtheAPP.

.Powerontheaudioconnector,andconnectyourPCwiththeWIFIaudioconnectorbysettingtheWIFI.

.StarttheWIFImusicAPK,theWIFIMusiciconwillappearontherightbottomofthewindow.AndthePCwill

automaticallydetecttheavailablespeaker.



.Selecttheaudioconnectorinthelistoftheavailablespeaker.

.AndnowyoucanenjoythewholeWindowsAudiostoredinthePCthroughtheWiFiAudioConnector.

.Ifyouwanttoenjoytheonlineaudio,plssetyourPCbythefollowingstep.



TheWiFiMusicicononthedeskThelistoftheavailablespeaker

WindowPCconnectionwiththeaudioconnector

1.Inputthe192.168.78.1 IP

address.

2.ConnecttheWIFIconnectortoyourhomeWIFIrouterstepby

step.

Andthen,youcantransmittheonlineaudio.



ProductParameter



FCCStatement:

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)Thisdevice

maynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat

maycauseundesiredoperation.



ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15ofthe

FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential

installation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedin

accordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto

radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotry

tocorrecttheinterferencebyoneormoreofthefollowingmeasures:

—Reorientorrelocatethereceivingantenna.

—Increasetheseparationbetweentheequipmentandreceiver.

—Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

—Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



Caution:Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe

user'sauthoritytooperatetheequipment.



ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolledenvironment.

Thisequipmentshouldbeinstalledandoperatedwithminimumdistance20cmbetweentheradiator&yourbody.



SupportOS¾ IOS5.0orup

¾ iTunes10.1orup

¾ Android4.0orup

¾ WindowsXP/Vista/7/8



AudioFormatMP3,WAV,MMA,AAC,M4A,AIFF,AppleLossless

WIFI802.1b/g/n

OperationRange70meters

AudiooutputAUX/SPDIF(Optical)

S/N89dB

THD+N‐85dBFs

Power DC5V/5 0 0 m A 
