GL Technologies AR750 GL.iNet 750M Travel AC Router User Manual GL AR750AC

GL Technologies (Hong Kong) Limited GL.iNet 750M Travel AC Router GL AR750AC

User Manual

User manual
Introduction
Congratulations on receiving your GL-AR750. As part of our Green Initiative, we do not include printed user
documentation with our product packaging. This policy saves paper, lowers shipping costs, reduces carbon
emissions and results in a cleaner environment.
Documentation
All product and accessory documentation can be found at the GLI Support Centre: http://www.gl-inet.com/docsOn
this site you will gain access to GLI technical resources and information about GLI products. To use your new GLI
Mini Router you will need to follow the simple steps which you can see from
http://www.gl-inet.com/docs/wiki/#!mini/index.md
Default System Settings
Product LAN Default IP Address LAN Fall-back IP Address
GL-AR750 DHCP 192.168.8.1
Initial Set-up
Interfaces described as followed:
Power to the GLI Mini Router is provided by connect the power lead (supplied) to the power adaptor (buy
separately) and then to the power interface on the GLI Mini Router.
Once power is provided to the GLI Mini Router the LED’s will provide status on its operation based on the
following:
LED Indicator Description
LED 1 (Power) Green solid Power is applied
LED 2 (Customized) Customized This is customized LED.
LED 3 (WiFi connection) Red Indicates WiFi signal (solid) and
data transfer (flashing).
Button Definition
z Press the Reset button to toggle the WiFi signal ON or OFF.
z Press and hold the Reset button for at least 8 seconds, then release your finger to reset the router to factory
default state. Wait until the router reboots, which could take about 3 minutes.
z The function of “switch” is configurable by user.
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the users’
authority to operate the equipment.
FCC Caution
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNNING: The minimum separation generally be used is at least 20 cm,
even if the calculations indicate that the MPE distance would be lesser.
