GN Audio USA BT121 Jabra BT121 Bluetooth Headset User Manual
GN Netcom Inc Jabra BT121 Bluetooth Headset
user manual
Bluetooth
®
headset
User manual
www.jabra.com
www.jabra.com
© 2007 GN US, Inc. All rights reserved. Jabra® is a registered
trademark of GN A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth®
word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by GN US, Inc. is under license.
(Design and specifications subject to change without notice).
FCC ID: BCE-BT121
Fig. 2
Fig. 1 Fig. 5
1 2
1
2
Fig. 3
Fig. 4
3
4
1 2
1 2 3
3 Sec 5 Sec
English
US
1
2
US
Jabra BT121 Bluetooth headset 3
US
1. Thank you
Thank you for purchasing the Jabra BT121 Bluetooth® headset.
We hope you enjoy it!
This instruction manual will get you started and ready to make the most
of your headset.
Remember, driving comes first, not the call!
Using a mobile phone while driving can distract you and increase the
likelihood of an accident. If driving conditions demand it (such as bad
weather, high traffic density, presence of children in the car, difficult road
conditions), pull off the road and park before making or answering calls. Also,
try to keep conversations short and do not make notes or read documents.
Always drive safely and follow local laws.
2. About your Jabra BT121
Volume down
Volume up
Adjustable earhook
Indicator light (LED) and answer/end button
Charging socket
1
2
3
1. Thank you. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2. About your Jabra BT121 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3. What your new headset can do . . . . . . . . . . . . . . . . . . . . . .4
4. Getting started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
5. Charge your headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
6. Turning your headset on and off . . . . . . . . . . . . . . . . . . . . .4
7. Pair it with your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
8. Wear it how you like it . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
9. How to. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
10. What the lights mean. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
11. Troubleshooting & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
12. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
13. Taking care of your headset. . . . . . . . . . . . . . . . . . . . . . . . . .8
14. Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
15. Certification and safety approvals. . . . . . . . . . . . . . . . . . . .9
16. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1
4
5
3
4
2
5
4
US
Jabra BT121 Bluetooth headset 5
US
7. Pair it with your phone
Headsets are connected to phones using a procedure called pairing.
By following a few simple steps, a phone can be paired with a headset
in a matter of minutes. (See figure below).
1. Put the headset in pairing mode
• When you turn on your Jabra BT121 for the first time, the headset will
automatically start up on pairing mode - i.e. It is discoverable for your
phone. When the headset is in pairing mode the LED is constantly lit.
2. Set your Bluetooth phone to ‘discover’ the Jabra BT121
• Follow your phone’s instruction guide. First make sure that Bluetooth is
activated on your mobile phone. Then set your phone to discover the
headset. This usually involves going to a “setup”, “connect” or “Bluetooth”
menu on your phone and selecting the option to “discover” or “add” a
Bluetooth device.*
3. Your phone will find the Jabra BT121
• Your phone will find the headset under name “Bluetooth headset”. Your
phone then asks if you want to pair with the headset. Accept by pressing
“Yes” or “OK” on the phone and confirm with the passkey or PIN=0000
(4 zeros). Your phone will confirm when pairing is complete.
3. What your new headset can do
Your Jabra BT121 lets you do all this (dependent on your phone
supporting the function):
• Answer calls
• End calls
• Reject calls*
• Voice dialing*
• Last number redialing*
• Call waiting*
• Place call on hold*
* Phone dependent
Specifications
• Talk time up to 8 hours/standby time up to 170 hours
• Rechargeable battery with charging option from AC power supply, PC via
USB cable or car charger (PC USB cable and car charger sold separately)
• Weight
1/2 oz (14g)
• Operating range up to 33 feet (10 meters)
• Headset and hands-free Bluetooth profiles
• Bluetooth specification (see glossary page 10) version 2.0
4. Getting started
The Jabra BT121 is easy to operate. The answer/end button on the headset
performs different functions depending on how long you press it.
5. Charge your headset
Make sure that your Jabra BT121 headset is fully charged for 2 hours before
you start using it. Use the AC power supply to charge from a power socket.
Connect your headset as shown in fig. 2. When the light indicator (LED) is
solid blue, your headset is charging. When the solid blue LED light turns off,
it is fully charged. (Follow step 1-2 in fig. 2).
6. Turning your headset on and off
• To turn on your headset press the answer/end button until you see a
burst of blue flashes on the indicator light (LED)
• To turn off your headset press and hold the answer/end button until you
see a burst of blue flashes on the indicator light (LED)
Instruction: Duration of press
Tap Press briefly
Press Approx: 1 second
Press and hold Approx: 5 seconds
In case of unsuccessful pairing, put the Jabra BT121 into pairing mode
manually. Make sure the headset is o . Press and hold the answer/end button
for approximately 5 seconds until the LED has a constant light. The LED will
ash before the light is constant – keep holding down the button until light is
constant.
* Phone dependent
34
6
US
Jabra BT121 Bluetooth headset 7
US
Call waiting and placing a call on hold*
This lets you place a call on hold during a conversation and answer a
waiting call.
• Press the answer/end button once to place the active call on hold
and answer the waiting call.
• Press the answer/end button to switch between the two calls.
• Tap the answer/end button to end the active conversation.
* Phone dependent
10. What the lights mean
11. Troubleshooting & FAQ
I hear crackling noises
For the best audio quality, always wear your headset on the same side of
the body as your mobile phone.
I cannot hear anything in my headset
• Increase the volume on the headset.
• Ensure that the headset is paired with the phone.
• Make sure that the phone is connected to the headset – if it does not
connect either from the phone’s Bluetooth menu or by tapping the
answer/end button, follow the pairing procedure (See section 3).
I have pairing problems even though my phone indicates otherwise
You may have deleted your headset pairing connection in your mobile
phone. Follow the pairing instructions in section 3.
Will the Jabra BT121 work with other Bluetooth equipment?
The Jabra BT121 is designed to work with Bluetooth mobile phones. It can
also work with other Bluetooth devices that are compliant with Bluetooth
version 1.1 or 1.2 and support a headset and/or hands-free profile.
I cannot use Reject call, call on hold, Redial or voice dialing
These functions are dependent on your phone supporting them.
Please check your phone’s manual for further details.
8. Wear it how you like it
The Jabra BT121 is ready to wear on your right ear. If you prefer the left,
gently pull out the earhook, rotate the ear hook 180°, and insert. (See fig. 4).
The earhook can be adjusted to fit your ear better – adjust the back edge of
the earhook for a more secure fit.
For optimal performance, wear the Jabra BT121 and your mobile phone on
the same side of your body or within line of sight. In general, you will get
better performance when there are no obstructions between your headset
and your mobile phone. (See fig. 5).
9. How to...
Answer a call
• Tap the answer/end button on your headset to answer a call.
End a call
• Tap the answer/end button to end an active call.
Make a call
• When you make a call from your mobile phone, the call will (subject to
phone settings) automatically transfer to your headset. If your phone
does not support this function, tap on the answer/end button on the
Jabra BT121 to receive the call in the headset.
Reject a call*
• Press the answer/end button when the phone rings to reject an
incoming call. Depending on your phone settings, the person who called
you will either be forwarded to your voice mail or hear a busy signal.
Activate voice dialing*
• Tap the answer/end button. For best results, record the voice-dialing tag
through your headset if your phone allows you to do so. Please consult
your phone’s user manual for more information about using
this feature.
Redial last number*
• Press the answer/end button.
Adjust sound and volume
• Press the volume up or down (+ or -) to adjust the volume.
(See fig. 1,
1
&
2
).
What this means about your headset
Flashing every second: active on a call
Flashing every three seconds: in standby mode
Flashing three times rapidly: running low on battery
Charging
In pairing mode – see section 7
What you see
Flashing blue light
Flashing blue light
Flashing blue light
Solid blue light
Solid blue light
8
US
Jabra BT121 Bluetooth headset 9
US
distributors, retailers, or other resellers of the Product. This warranty applies
only to new Jabra products purchased from authorized retail sellers. This
warranty does not apply to: "open box purchases”, resales by private parties or
any other third party purchases by unauthorized distributors. Transfer of Jabra
products through any unauthorized distributor renders our manufacturer’s
warranty null and void. BUYER BEWARE: any Jabra product sold by a private
party or unauthorized distributor and not by an authorized Jabra retail seller
is sold on an “as is” or “with all faults" basis with respect to Jabra. As such, the
entire risk as to the quality and performance of such products will be with
the buyer if the unauthorized distributor will not cover the costs of repairing
defects. Should such products prove defective following their purchase, the
buyer or unauthorized distributor, and not the manufacturer or its authorized
retail sellers, assumes the entire cost of all necessary servicing or repair.
Therefore, buyers are strongly encouraged to purchase Jabra products only
from Jabra authorized retail sellers. THE FOREGOING WARRANTIES ARE THE
SOLE WARRANTIES, EXPRESS OR IMPLIED, GIVEN BY JABRA IN CONNECTION
WITH THE PRODUCT, AND JABRA DISCLAIMS ALL OTHER WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. JABRA
SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES IN CONNECTION WITH THE PRODUCT, EVEN IF JABRA HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.THE LIABILITY OF JABRA
HEREUNDER FOR ALL CLAIMS SHALL NOT EXCEED THE AMOUNT PAID BY
PURCHASER TO JABRA FOR THE PRODUCT GIVING RISE TO JABRA’S LIABILITY.
15. Certi cation and safety approvals
FCC
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Users are not permitted to make changes or modify the device in any way.
Changes or modifications not expressly approved by Jabra (GN US, Inc.) will
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
12. Need more help?
1. Web: www.jabra.com
(for the latest support info and online User Manuals)
2. E-mail: Tech Support: techsupp@jabra.com
Information: info@jabra.com
3. Phone:
1 (800) 327-2230 (toll-free in USA)
1 (603) 579-5311 (Canada)
13. Taking care of your headset
• Always store the headset with the power off and safely protected.
• Avoid storage at extreme temperatures (above 45°C/113°F – including
direct sunlight – or below -10°C/14°F). This can shorten battery life and
may affect operation. High temperatures may also degrade performance.
• Do not expose the headset to rain or other liquids.
14. Warranty
Jabra limited product warranty. Jabra is a wholly owned trademark of
GN A/S. Jabra warrants to Purchaser that for a period of one (1) year after
the date of purchase (the “Warranty Period”) of any Jabra Product (“Product”)
by Purchaser, the Product will substantially conform to Jabra’s published
specifications for the Product on the date of Purchaser’s purchase of the
Product, subject to the terms herein. Purchaser shall notify Jabra of any
nonconformance during the Warranty Period and obtain a written return
material authorization (“RMA”) and an RMA number for the nonconforming
Product from Jabra and return the nonconforming Product to Jabra, freight
prepaid, with a statement describing the nonconformity. Jabra’s exclusive
obligation with respect to nonconforming Product shall be, at Jabra’s option
and expense, to repair or replace such Product so that it substantially
conforms with its published specifications on the date of Purchaser’s
purchase, or, if Jabra, in Jabra’s sole discretion, determines that it is not
possible to repair or replace the Product, Jabra may, at Jabra’s option, refund
to Purchaser the purchase price paid for the Product.THE FOREGOING IS
PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR BREACH OF WARRANTY
BY JABRA WITH RESPECT TO THE PRODUCT. The warranty set forth above
shall not apply to any Product which has not been properly used or handled
in accordance with the instructions supplied by Jabra, lost or misplaced
for any reason, or which has been modified, repaired or altered, except by
Jabra or at a Jabra authorized service facility, or which has been subjected to
faulty installation, misuse, abuse, or which the Product defect is attributable
to any failure or damage which is beyond the reasonable control of Jabra.
This warranty is available only to Purchaser, and does not extend to any
10
US
Jabra BT121 Bluetooth headset 11
US
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The device and its antenna must not be co-loaded or operating in
conjunction with any other antenna or transmitter.
Industry Canada
Operation is subject to the following two conditions: (1) This device may not
cause interference and (2) This device must accept any interference, including
interference that may cause undesired operation of the device.
The term “IC:” before the certification/registration number only signifies that
registration was performed based on a Declaration of Conformity indicating
that Industry Canada technical specifications were met. It does not imply that
Industry Canada approved the equipment.
CE
This product is CE marked according to the provisions of the R & TTE Directive
(99/5/EC).
Hereby, GN US, Inc., declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
For further information please consult http://www.jabra.com
Bluetooth
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by Jabra is under license. Other trademarks and
trade names are those of their respective owners.
16. Glossary
1 Bluetooth is a radio technology that connects devices, such as mobile
phones and headsets, without wires or cords over a short distance
(approx. 33 feet). Get more information at www.bluetooth.com
2 Bluetooth profiles are the different ways that Bluetooth devices
communicate with other devices. Bluetooth phones support either the
headset profile, the hands-free profile or both. In order to support a
certain profile, a phone manufacturer must implement certain
mandatory features within the phone’s software.
3 Pairing creates a unique and encrypted link between two Bluetooth
devices and lets them communicate with each other. Bluetooth devices
will not work if the devices have not been paired.
4 Passkey or PIN is a code that you enter on your mobile phone to pair
it with your Jabra BT121. This makes your phone and the Jabra BT121
recognize each other and automatically work together.
5 Standby mode is when the Jabra BT121 is passively waiting for a call.
When you ‘end’ a call on your mobile phone, the headset goes into
standby mode.
