GN Audio USA PHS002W Bluetooth Speaker User Manual
GN Netcom Inc Bluetooth Speaker
user manual
Jabra Speak 510
GET STARTED UNDER
jabra.com/speak510
MINUTES
5
For more information, please visit
www.jabra.com
NEED MORE HELP?
Why wait? Go to our support page and find all the answers you’re looking for
24-hours a day. www.jabra.com/speak510
81-03637 B
www.jabra.com
Made in China
MODEL: PHS002W
© 2012 GN Netcom A/S. All rights reserved. Jabra® is a registered trade-
mark of GN Netcom A/S. All other trademarks included herein are the
property of their respective owners. The Bluetooth® word mark and logos
are owned by the Bluetooth SIG, Inc. and any use of such marks by GN
Netcom A/S is under license. (Design and specifications subject to change
without notice).
ENGLISH
1 CONNECT TO PC
1. Plug the Jabra Speak 510 USB cable into any available USB port on your
PC. The Jabra Speak 510 will turn on automatically when connected to
the PC.
2. Select the Jabra Speak 510
as the audio device in
your softphone.
2 CONNECT TO MOBILE PHONE
1. Press and hold (2 secs) the On/o
button until the lights ash, to turn
on the Jabra Speak 510.
2. Press and hold (2 secs) the
Bluetooth button on the Jabra
Speak 510 until the Bluetooth
light ashes blue and you hear the
connection instructions.
Then release the button.
3. Enable Bluetooth on your mobile
phone, and select the Jabra Speak
510 from the list of available
Bluetooth devices. If prompted for a
password enter 0000.
Note: You can connect and use both a PC and mobile phone simultaneously.
21
On/o Press and hold (2 sec) the On/o
button until the lights ash
Make call
Call will automatically transfer to the
Jabra Speak 510. If not, tap the Call
button
Answer call Tap the Call button
End call Tap the End/reject call button
Reject call Tap the End/reject call button
Speaker volume up/
down Tap the Volume + or Volume - button
Battery level Tap the Battery level button to
display the current battery level
Connect with new
Bluetooth device
Press and hold (2 secs) the Bluetooth
button to connect with a new
Bluetooth device
Reconnect/disconnect
with Bluetooth device
Tap the Bluetooth button to
reconnect/disconnect with a
Bluetooth device
Mute/un-mute
microphone Tap the Mute button
3 USING THE JABRA SPEAK 510
End/reject call
Volume +
Battery level
Volume -
Bluetooth
Call
Mute
On/o
USB cable
Headset port
IMPORTANT
For full Jabra Speak 510 call functionality with your PC, download and install
Jabra PC Suite from www.jabra.com/pcsuite
43
