GOLD FINGERS TECHNOLOGY BTS07 Bluetooth speaker User Manual Bts07 Bluetooth Speaker
GOLD FINGERS TECHNOLOGY CO.,LTD Bluetooth speaker Bts07 Bluetooth Speaker
User Manaual
Bts07 Bluetooth Speaker
User Manual
1. Notice
Don’t keep playing the device at maximum volume, or your hearing will get hurt. 80% or a lower
volume is recommended.
Avoid storage at high temperatures such as in a hot vehicle or under direct sunlight,which will
damage device performance and reduce battery life.
Always store the Bluetooth device with power off and make sure it is in safety protected.
Please use 5V 1A charger to charge it, charging will last about 5-6 hours.
If the LED indicator is not lighted when turn on the device, please charge it.
2. Performance characteristics
1).The device is mono BT speaker with enhanced bass sound effect.
2).Adopts high fidelity design, you can enjoy more natural and exquisite sound.
3). Built-in Lithium battery is used, battery status can be indicated on iPhone.
3. Operation instruction
Ⅰ. Function instruction
①Next song/VOL+(Long press)
②Play/Pause/Answer Call(Bluetooth)
③Previous song/VOL-(Long press)
④Power switch
⑤5V charging input port
⑥Line in
II.Connection diagram
Ⅲ.Operation instruction
The Bluetooth device adopts rechargeable battery. Please fully charge the battery before using for
the first time .
On/Off: Long press “ ” 2 seconds to turn on the Bluetooth device, it will enter into pairing
mode automatically after 5 seconds. LED indicator will flash with red and blue in pairing mode.
Long press“ ” 2 seconds again, Bluetooth device will be turned off.
Bluetooth mode: Turn on the device, after paired,short press“ ” to play/pause; short press
“ ” to select songs; Long press “ ” to adjust sound volume.
Hands free function:
Answering a call: Short Press“ ”when you receiving an incoming call. Short press“ ” again to
end the call. Long press“ ” to adjust volume
Bluetooth Selfie Function:
Open the Camera APP of your mobile phone, then short press“ ” button on this Bluetooth
device to take a picture.
(Compatible with iOS 4.0 and Android 4.0 or above system. For smartphones cannot work with th
is device, please set the volume button as shutter button or simply download the app"Camera 360"
from Google Play. )
Ⅳ.Pairing
Connect the device with mobile phone via Bluetooth, the pairing name is “BTS07".It's connected
successfully when you heard"paired".
4. Technical data
Bluetooth Version:V3.0
Rating power: 3W
Range: 10m
Play time: 6~8H
Standby time:260H
Product size: 82x51.5x52.5mm
Net weight: 200g
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
