User Manual
0
Smart series
GSM/GPRS Digital Mobile Phone
User’s Guide
Product Name: mobile Phone
Product Model: U5E
SHENZHEN GOTRON ELECTRONIC CO.,LTD.
RM 24B,BLOCK C OF ELECTRONIC &TECHNOLOGY BUILDING, 2070 SHENNAN
MIDDLE ROAD, SHENZHEN, CHINA
1
Content
1 THE BASICS ............................................................. 5
1.1 OVERVIEW ............................................................. 5
1.2 SAFETY GUIDE ....................................................... 6
1.3 SAFETY WARNINGS AND NOTICES ........................ 7
1.3.1 General attention ................................................ 7
1.3.2 Notices when using your phone .......................... 8
1.3.3 Notices when using the battery ......................... 11
1.3.4 Charging your phone ........................................ 13
1.3.5 Cleaning and maintenance ............................... 17
2 GETTING STARTED ................................................... 18
2.1 COMPONENT NAME AND EXPLANATION.................. 18
2.1.1 Technical parameters ................................. 18
2.1.2 Icons ............................................................. 19
2.2 KEY EXPLANATIONS ............................................. 21
2.3 USING THE TOUCHSCREEN ................................. 22
2.4 CONNECTING TO THE NETWORK......................... 22
2.4.1 Inserting and removing the SIM card ................ 22
2.4.2 Turning your phone on and off .......................... 23
2.4.3 Unlocking the SIM card .................................... 24
2.4.4 Unlocking your phone ....................................... 24
2.4.5 Connecting to the network ................................ 25
2
2.4.6 Making a call .................................................... 25
2.4.7 Making a domestic call ..................................... 26
2.4.8 Making an international call ............................ 26
2.4.9 Making a call from the list ................................ 27
2.4.10 Making an emergency call .............................. 27
2.4.11 Call menu ........................................................ 28
3 FUNCTIONAL MENU ................................................. 31
3.1 FILE MANAGEMENT ............................................ 31
3.2 SENDING AN EMAIL ............................................. 32
3.3 DIALING ............................................................... 33
3.4 3G VIDEO CALL ................................................... 34
3.5 CALCULATOR ...................................................... 35
3.6 BROWSER............................................................ 36
3.7 VOICE RECORDER .............................................. 37
3.8 CALENDAR .......................................................... 39
3.9 SETTINGS ............................................................ 41
3.10 CLOCK ............................................................... 43
3.11 RADIO ................................................................ 45
3.12 GOOGLE SEARCH ............................................. 47
3.13 CONTACTS ........................................................ 47
3.14 GALLERY ........................................................... 49
3.15 CAMERA ............................................................ 50
3.16 MESSAGING ...................................................... 51
3
3.17 NOTIFICATION MENU ........................................ 53
3.18 DOWNLOAD CONTENT ...................................... 54
3.19 MUSIC ................................................................ 55
3.20 CALL RECORDS ................................................ 57
3.21 WIDGET ............................................................. 58
3.22 SELECTING WALLPAPER SOURCE ................... 59
3.23 LOCAL SEARCH ................................................. 60
3.24 NOTE ................................................................. 61
3.25 FLASHLIGHT ...................................................... 62
3.26 DOCUMENTS TO GO ......................................... 63
3.27 MOBOPLAYER .................................................... 64
3.28 MAP ................................................................... 65
3.29 NAVIGATION ...................................................... 67
3.30 VOICE SEARCH ................................................. 68
3.31 VIDEOS .............................................................. 69
3.32 SIM CARD APPLICATION ................................... 70
3.33 GMAIL ............................................................... 70
3.34 GOOGLE TALK .................................................. 72
3.35 TODO ................................................................ 72
3.36 BACKUP AND RESET .......................................... 73
3.37 FILM WORKSPACE ............................................. 74
3.38 PLAY STORE ....................................................... 75
4. TEXT INPUT ......................................................... 76
4
5 SD CARD INTRODUCTION ................................. 79
6 FAQS AND SOLUTIONS ...................................... 83
5
1 The Basics
1.1 Overview
Thank you for choosing the GSM/GPRS digital
mobile phone. After reading this guide you will be able
to fully master the use of your phone and appreciate
all its functions and ease of use.
Not only does the smartphone provide you with
basic call functions such as call Register, but also with
many practical functions and services, to improve the
time you spend working and playing.
The color screen mobile phone complies with the
GSM/GPRS technology and has been approved by
certification authorities both domestically and abroad.
The availability of some services and features
described in this manual depends on the network and
your subscription. Therefore, some menu items may
not be available in your phone. The shortcuts to
menus and features may also vary from phone to
phone.
Our company reserves the right to revise this
manual content without prior notice.
6
1.2 Safety guide
If your mobile phone is lost or stolen, please
contact the telecommunications authorities or a
sales agent immediately to have a hold on the
phone and the SIM card. This will prevent
economic loss caused by unauthorized calls
made from your mobile phone.
When you contact the telecommunications
authorities or a sales agent, they will need to
know the IMEI number of our mobile phone
(remove battery to expose number located on the
label on back of phone). Please copy this number
and keep in a safe place for future use.
In order to avoid the misuse of your mobile
phone please take the following preventative
measures:
- Set the PIN number of your mobile phone’s
SIM card and change this number
immediately if it becomes known to a third
party.
- Please keep the phone out of sight when
leaving it in a vehicle. It is best to carry the
phone with you, or lock it in the trunk.
- Set call barring.
7
1.3 Safety warnings and notices
Before using your mobile phone, read and
understand the following notices carefully to ensure
you will use it safely and properly.
1.3.1 General attention
Only the battery and battery charger specified
by our company should be used in your
phone. Other products might result in battery
leakage, overheating, fire or explosion.
To avoid your phone malfunctioning, or
catching fire, please do not violently impact,
jolt or throw your phone.
Please do not place the battery, mobile phone,
or charger in a microwave oven or
high-pressure equipment. Otherwise it could
lead to unexpected accidents such as
damage to the circuitry or fire hazard.
Please do not use your phone near flammable
or explosive gases, otherwise it could cause
malfunction of your phone or fire hazard.
Please do not subject your phone to high
temperatures, high humidity or dusty places;
otherwise this may lead to the malfunction of
8
your phone.
Keep your phone out of the reach of small
children. Your phone is not a toy. Children
could hurt themselves.
To avoid your phone falling and
malfunctioning or being damaged, please do
not place it on uneven or unstable surfaces.
1.3.2 Notices when using your phone
The apparatus shall not be exposed to
dripping or splashing and that no objects
filled with liquids, such as vases, shall be
placed on the apparatus.
The adapter plug is used as the disconnect
device, it shall remain readily operable.
Turn off your mobile phone where the phone
is not allowed, such as, on the airplane or in
hospitals. Using the mobile phone in those
places may impact the normal operation of
electronic devices and medical instruments.
Follow relevant regulations when using your
mobile phone in those places. Your mobile
phone has the auto turn-on feature. Check
your alarm clock settings to confirm that your
mobile phone will not be turned on
9
automatically during flight.
Please do not use your mobile phone near
the weak signal or high precision electronic
devices. RF interference might cause
malfunctioning of such electronic devices and
other problems. Special tips must be paid
near the following equipment: hearing aids,
pace makers and other medical electronic
devices, fire detectors, automatic doors and
other automatic control installations. To find
out the effect of mobile phones on a
pacemaker or other pieces of electronic
medical equipment please contact the
manufacturers or local sales agents of the
equipment.
Please do not subject the LCD to impact or
use the screen to strike things, as this will
damage the LCD board and cause leakage of
the liquid crystal. There is a risk of blindness
if the liquid crystal substance gets into the
eyes. If this occurs rinse eyes immediately
with clear water (under no circumstances rub
your eyes) and go immediately to a hospital
for treatment.
10
Do not disassemble or modify your mobile
phone, as it will lead to damage to the phone
such as battery leakage or circuitry failure.
Under very rare circumstances using the
mobile phone in certain model cars may
negatively affect the internal electronic
equipment. In order to assure your safety
under such circumstances please do not use
the mobile phone.
Please do not use needles, pen tips, or other
sharp objects on the keypad as this may
damage the mobile phone or cause it to
malfunction.
In the event of antenna malfunction, do not
use your phone, as it could be harmful to
human body.
Avoid letting the phone come into close
contact with magnetic objects such as
magnetic cards as the radiation waves of the
mobile phone may erase the information
stored on floppy disks, pay cards and credit
cards.
Please keep small metal objects, such as
thumbtacks far away from the receiver. When
11
the receiver is in use it becomes magnetic
and may attract these small metal objects
and thus these may cause injury or damage
the mobile phone.
Avoid having the mobile phone come into
contact with water or other liquids. If liquids
enter the phone, this could cause a short
circuit, battery leakage or other malfunction.
1.3.3 Notices when using the battery
The battery has a limited service life. The
remaining life gets shorter as the times of
charging increase. If the battery becomes
feeble even after the charging, this indicates
the service life is over and you have to use a
new battery.
Do not dispose of old batteries with everyday
domestic garbage. Please dispose of old
batteries at the directed places with specific
rules for their disposal.
Batteries (battery pack or batteries installed)
shall not be exposed to excessive heat such
as sunshine, fire or the like. Please do not
throw batteries into a fire, as this will cause
the batter to catch fire and explode.
12
When installing the battery, do not use force
or pressure, as this will cause the battery to
leak, overheat, crack and catch fire.
Please do not use wires, needles or other
metal objects to short-circuit the battery. Also,
do not put the battery near necklaces or other
metal objects, as this will cause the battery to
leak, overheat, crack and catch fire.
Please do not solder the contact points of the
battery, as this will cause the battery to leak,
overheat, crack and catch fire.
If the liquid in the batteries goes into the eyes,
there is a risk of blindness. If this occurs do
not rub the eyes, but immediately rinse eyes
with clear water and go to the hospital for
treatment.
Please do not disassemble or modify the
battery, as this will cause the battery to leak,
overheat, crack and catch fire.
Please do not use or place the batteries near
high temperature places such as near a fire
or heating vessel, as this will cause the
battery to leak, overheat, crack and catch
fire.
13
If the battery overheats, changes color, or
becomes distorted during use, charging, or
storage, please stop using and replace it with
a new battery.
If the liquid from the battery comes in contact
with skin or clothing this could cause burning
of the skin. Immediately use clear water to
rinse and seek medical tips if necessary.
If the battery leaks or gives off a strange odor,
please remove the battery from the vicinity of
the open fire to avoid a fire or explosion.
Please do no let the battery become wet as
this will cause the battery to overheat, smoke
and corrode.
Please do not use or place batteries in places
of high temperature such as in direct sunlight,
as this will cause the battery to leak and
overheat, lower performance, and shorten
the battery’s life.
Please do not continuously charge for more
than 24 hours.
1.3.4 Charging your phone
Connect the connector of charger to the mobile
phone. The battery level indicator flashes on the
14
screen. Even if the phone has been turned off, the
charging image still appears, indicating that the
battery is being charged. If the phone is overused
when the current is insufficient, it may take longer
time for the charging indicator to appear on the
screen after the charging begins.
When the battery level indicator does not flash
and indicates the battery is full, this indicates the
charging has been completed. If the phone is off
during charging, the charging being completed
image also appears on the screen. The charging
process often takes 3 to 4 hours. During the
charging, the battery, phone and charger gets
warm, this is a normal phenomenon.
Upon the completion of charging, disconnect the
charger from AC power socket, and from the
mobile phone.
Notes:
During charging, the phone must be placed in
well-ventilated environment. Always use the
charger supplied by your phone manufacturer.
Using an unauthorized charger might cause
danger and invalidate the authorization and
warranty clauses for your phone.
15
The standby time and call duration provided by
the manufacturer are based on ideal operating
environment. In practice, the battery's operating
time varies depending on network conditions,
operating environment and usage methods.
Make sure the battery has been installed before
charging. It is best not to remove the battery while
charging.
Upon completion of charging, disconnect the
charger from your phone and the power supply.
If you have not disconnected the charger from your
phone and the power supply, the charger will continue
to charge the battery after about 5 to 8 hours when the
batter level decreases substantially. We advise you
not to do like this, as it lowers your phone performance
and shortens your phone life.
Notices when using your charger
Please use AC 100-240 volts. The use of any
other voltage will cause battery leakage, fire
and cause damage to the mobile phone and
charger.
It is forbidden to short circuit the charger, as
this will cause electrical shock, smoking and
16
damage to the charger.
Please do no use the charger if the power
cord is damaged, as this will cause fire or
electrical shock.
Please immediately clean any dust gathered
on the electrical outlet.
Please do no place vessels with water near
the charger in order to avoid water splashing
onto the charger and causing an electrical
shortage, leakage or other malfunction.
If the charger comes in contact with water or
other liquid the power must immediately be
switched off to avoid an electrical short or
shock, fire or malfunction of the charger.
Please do not disassemble or modify the
charger, as it will lead to bodily harm,
electrical shock, fire or damage to the
charger.
Please do not use the charger in the
bathroom or other excessively moist areas,
as this will cause electrical chock, fire or
damage to the charger.
Please do not touch the charger with wet
hands, as this will cause electrical shock.
17
Do not modify or place heavy objects on the
power cord, as this will cause electrical shock
or fire.
Before cleaning or carrying out maintenance
please unplug the charger from the electrical
outlet.
When unplugging charger, do not pull on the
cord, but rather hold on to the body of the
charger, as pulling on the cord will damage
the cord and lead to electrical shock or fire.
1.3.5 Cleaning and maintenance
The mobile phone, battery, and charger are
not water resistant. Please do not use them
in the bathroom or other excessively moist
areas and likewise avoid allowing them to get
wet in the rain.
Use a soft, dry cloth to clean the mobile
phone, battery and charger.
Please do not use alcohol, thinner, benzene
or other solvents to wipe the mobile phone.
A dirty outlet will cause poor electrical contact,
lose of power and even inability to recharge.
Please clean regularly.
18
2 Getting Started
2.1 Component name and explanation
2.1.1 Technical parameters
Handset
Model: U5E
Name: Mobile Phone
Lithium-ion battery
S/N: KPD1BB17GS/6-A
Nominal voltage: DC3.7V
Maximum charge voltage: DC4.35V
Capacity : 2200mAh
Travel charger
Model: D3-501000
Input: 100-240V~50/60Hz, 0.2A
19
2.1.2 Icons
In the standby mode, the following icons may
appear in standby screen:
Icon Description
Indicate the intensity of network signals.
Show missed calls.
Location by satellite.
Receive a new message.
An application is being downloaded.
The downloading is over.
The alarm clock has been set and
activated.
A call is in progress.
The phone is playing a song.
Show battery level.
20
Enable USB.
The access is blocked.
Get connected to the wireless network
Turn on the Bluetooth.
No SIM card is installed in the phone.
GPRS data connection is on.
21
2.2 Key explanations
Key Explanations
Return key ●Return to the previous menu.
Menu key ●Show options of current menu.
Home key
●At any status, press the key to
return to the standby screen.
Power key
● Hold down this key to turn your
phone off and on.
● Generally, press this key to lock
the mobile phone.
Side volume
keys
● During the conversation, press
the two keys to adjust the volume.
● While playing an audio file,
press the two keys to adjust the
volume.
Note: In this guide, the phrase “press the key” refers to
pressing and thereafter releasing a key. “Hold down a
key” refers to pressing a key and keeping it depressed
for 2 seconds or longer.
22
The descriptions and functions of keys depend on
the model of your phone.
2.3 Using the touchscreen
Your phone provides many touch keys in the Main
screen. To use these keys correctly, calibrate the touch
screen in advance (see “Calibrator”). Meanwhile please
follow the instructions:
■Do not touch the screen with wet hands.
■Do not touch the screen with great forces.
■Do not touch the screen with metallic or conductive
objects.
2.4 Connecting to the network
2.4.1 Inserting and removing the SIM card
Turn off the phone; remove the battery and unplug
other external power supplies. Insert the SIM card
into the SIM holder as shown in the phone.
When you need to remove the SIM card, turn off the
phone, remove the battery and then remove the SIM
card from the holder.
Warning: Do turn off your phone before removing the
SIM card. Never insert or remove the SIM card when an
external power supply is connected, as this may cause
damage to the SIM card.
23
2.4.2 Turning your phone on and off
To turn on the phone, hold down the POWER key
on the top; to turn off the phone, hold down the POWER
key.
If you have turned on your phone without inserting
the SIM card, the phone will prompt you to install the SIM
card. With the SIM card already inserted, your phone
automatically verifies the availability of the SIM Card.
Then, the screen shows the following:
Enter PIN1 —— if your have set the SIM card
password.
Enter phone password —— if you have set your
phone password
Search for network—— the phone searches for the
appropriate network.
Notes：
If when you turn on the mobile phone, an exclamation
mark appears on the screen and does not disappear,
this is possibly caused by misoperation, that is, you
press the Power key and the Volume Up key at the same
time. Such misoperation activates the recovery mode,
hence the occurrence of exclamation mark. If you just
turn off the phone, next time when you turn it on, it will
still come to the recovery mode.
24
Solution：
Press the Home key when the exclamation mark and
robot appear, a menu will pop up. Use the Menu key to
select "reboot system now" to restart the phone.
2.4.3 Unlocking the SIM card
The PIN 1 (personal identification number) secures
your SIM card from being misused by others. If you have
selected this function, you must enter the PIN1 code each
time you turn on the phone so that you may unlock the
SIM card and then make or answer calls. You can
deactivate SIM card protection (see “Safety settings”). In
this case, the misuse of your SIM card cannot be
prevented.
Press the Hang Up key to turn on your phone;
Enter your PIN1 code. Clear the incorrect digits by
using the right soft key, and press OK for
confirmation. e.g. if your PIN1 is 1234, please enter:
1 2 3 4
If you enter incorrect numbers for three times in
succession, your SIM card will be locked and your phone
will ask you to enter PUK 1 number. If you do not know
the PUK1 code, do not try. Instead, contact your network
service provider. See “Safety settings”.
Note: your network service provider sets a standard
PIN1 code (4 to 8 digits) for your SIM card. You should
immediately change this number. See “Safety settings”.
2.4.4 Unlocking your phone
To prevent unauthorized use, you can set phone
25
protection. If you have selected this function, you must
draw unlocking pattern each time you turn on your phone,
to unlock the phone and then make or answer calls. You
may clear the unlocking pattern (see “Safety settings”).
In this case, the unauthorized use of your phone cannot
be protected.
If you forget your phone password, you must contact
the retailer or local authorized service center to unlock
your phone.
2.4.5 Connecting to the network
Once your SIM card is unlocked, your phone
searches for available network automatically (the screen
will show the network searching is underway). If your
phone has found the available network, the name of
network service provider appears at the center of
screen.
Note: Making an emergency call 。Note: If “only for
emergency calls” appears on the screen, it indicates that
you are beyond the network coverage (service area),
and that you can still make emergency calls depending
on the signal intensity.
2.4.6 Making a call
When the logo of network service provider appears
on the screen, you can make or answer a call. The bars
at the upper left corner of screen indicate the intensity of
26
network signal.
Conversation quality is significantly affected by
obstacles, thus moving within a small area while making
or answering a call can improve the conversation quality.
2.4.7 Making a domestic call
In the Dial screen, enter a number, and press the
Dial key to make a call. To change the number, delete
the digits you have entered. During dialing, the animation
appears on the screen. After the call is picked up, the
screen will show call status information. If the connection
alert tone has been set, your phone will ring the alert
tone (network dependent).
To end a call, press the Hang Up key.
Zone code Phone number Dial key
2.4.8 Making an international call
To make an international call, hold down the 0 key
on the Dialing screen until the international prefix "+” for
appears. This allows you to dial an international number
without knowing its international fix (e.g. 00 for China).
Following the entry of international prefix, enter the
country code and complete phone number. For the
country codes, follow the general conventions, for
example, 49 for Germany, 44 for UK, and 46 for Sweden.
Like making an international call via a fixed
telephone, omit the “0” at the head of a city code.
27
For example, to call our hotline from another
country, you can dial:
+86 21 114
+ Country code Complete phone number
Dial key
2.4.9 Making a call from the list
All calls dialed and received are stored within a list
in your phone. Those dialed and received recently are
exhibited at the top of the list (see “Call Register”). All the
numbers are sorted by Dialed Calls, Received Calls and
Missed Calls. Your phone also provides options for you
to view all calls. When the call Register is full, the old
numbers will be deleted automatically. To view the list,
do the following:
To view the dialed calls, press the Dial key
You can dial any number from the list by pressing
the Dial key.
When the call list appears, press OK to see details,
or go to Options -> Save to place the number into your
Phonebook.
2.4.10 Making an emergency call
If you are beyond the network coverage (see
network-signal-intensity bars at the upper left corner of
the screen), you can still make emergency calls. If your
network service provider does not provide roaming
service to the area, the screen will show “only for
emergency calls”, alerting you that you can only make
28
such calls. If you are within the network coverage, you
can also make emergency calls even without the SIM
card.
2.4.11 Call menu
The Call menu is only visible during an active call,
and features such as Call Waiting, Call Diverting, and
Multiple-party Call are network dependent. Contact your
network service provider.
The call options include:
29
Mute
Do not send local voice.
Handsfree
Switch on the loudspeaker to amplify the voice.
Hold
Put the current call on hold or retrieve the call on
hold.
30
End a call.
End the current call.
New call
Make another new call.
More
*Start voice recording
Start voice recording.
31
3 Functional Menu
（※The following features depends on specific models）
3.1 File Management
The file management is composed of sdcard and
sdcard 2, while sdcard is the memory of the phone,
sdcard 2 is the external SD card. In the file management,
files can be searched rapid, deleted or edited in each
card and new filescan be created.
32
3.2 Sending an Email
You can send an Email to anyone who has an Email
address.
Entering the procedure and set an account, you can
click the account so that you come into the account
already created, you can also activate, compile and
create an account and then delete the operating. The
email can be sent and received just like in a computer.
This procedure requires the network support.
33
3.3 Dialing
When dialing, you can have a quick acess to the call
records, contacts and digit dial keyboard (used for
manual dialing) by the menu key on the screen.
34
3.4 3G video call
Click a number portrait in the phonebook, and you
can do these things instantly: dial, send a message and
make a video call. During the video call, you can select
applications such as adjusting it to mute mode, switching
to robot portrait, turning off the voice and intercepting
photos to SD card.
35
3.5 Calculator
Your phone provides a calculator with 4 basic
functions for the convenience of your calculating.
Press this button , and you delete the input
and output in bitwise.
Notice: this calcutor is of limited accuracy and
sometimes it causes error, please forgive us for the
inconvenience.
36
3.6 Browser
The browser allows you to surf on the net and
browse the page just like on the computer. You can
create on the phone a bookmark and synchronize it with
computer. You can have a quick access to your favorite
sites on the main screen.
37
You could view web pages in longitudinal or
transverse mode. The page rotates according to the
rotation of the phone and automatically adjusts to fit the
page.
3.7 Voice Recorder
The recorder could be used to record audio files.
38
To start voice recording: Tap
To end voice recording: Tap
To play back voice recording: Tap
39
The audio files are automatically stored on your
phone. Click the Menu key,
and you can operate and set the recorded voice. The file
can be in document management and various players
can be selected to play the voices.
3.8 Calendar
Calendar allows you to view your schedules and
events at any time. You may view schedules one by one
or several ones at the same time.
Select to show calendar by day, week or month. If
“by week (or month)”, the calendar will be shown by
week (or month). This application is convenient for you
to view schedule or add events.
40
41
3.9 Settings
Reach the menu and customize your phone settings.
SIM card management: SIM card can be managed and
made settings.
WLAN: WLAN can be turned on and off and made
some settings.
Bluetooth: Bluetooth can be turned on and off and
42
settings are made.
The information flow usage: It makes you in full
awareness of the usage of the information.
More: Click more and you will set up flight mode
and VPN and more.
Audio profiles: General, silent, meeting and outdorr
optional. In the meanwhile, customized setting-up of
some scene modes are allowed.
Select a mode and enter the customized setting-up,
operational are vibration, volume, ring tones,
notifications and key beep, etc.
Display: Customized setting-up of the phone
luminance, wallpaper, the screen and screen time-out
and font size is allowed.
Storage: The internal memory of the storage card
and of the phone is shown.
Battery: The usage detail of the batteryis shown.
Applications: View, manage and delete the
applications on your phone.
Account and synchronization: Set the
synchronization of your phone account with your phone.
Location service: Set the service during the
locating.
Safety: Set unlocking pattern; lock the SIM card;
43
set the SD card.
Language and keypad: Select a language and
input method.
Backup and reset: Reset DRM and restore factory
settings to clear all personal data on your phone.
Date and time: Set current time and date.
Schedule power on/off: set the time to turn on or off
your phone.
Auxiliary function: Some auxiliary functions can be
set.
Developers’ options: Set some options used by
developers.
About phone: View the model, service status,
mobile software and hardware information, etc.
3.10 Clock
Clock
Enter the menu to display the current time.
44
Alarms
Your phone provides many groups of alarm clocks.
Select one of them to edit and customize alarm clock.
45
3.11 Radio
Wear your earpieces of radio before searching for
channels.
46
Glossary:
Channel list: Display the list of FM radio channels.
You can select to play one of them. (the list can contain
20 channels maximum)
Search: Select this option to automatically search
47
for channels and generate the list of channels.
Loudspeaker: Press the button to use the radio
loudspeaker.
and : Tap to move to another channel.
.
3.12 Google Search
You can locally search for the information you need.
3.13 Contacts
The “contacts ” lets you easily call your colleagurs or
friends, or send emails or short messages to them. You
may add contacts directly from your phone, or
synchronize “contacts” with any application on your
computer. You may open “contacts ” directly from the
Main screen, or open it via the “Dialing” application.
48
Add a contact:
To add a contact, directly enter the name and phone
number, or import the name and phone number from the
SIM card. (The number of contacts you can add is
limited by the memory of your phone.)
Search for contacts:
49
To search for a contact, press the Search key in
search screen, and a search box will pop up. In the
search box, enter the key words, such as first name,
second name and company name. While you are
entering the key word, the matching contacts
immediately appear.
Edit a contact:
To edit details of a contact, select “Edit a contact”.
Delete a contact:
To delete the current contact, select “Delete a
contact”.
From the menu, you can also synchronize with or
share an account or import or export a contact.
3.14 Gallery
Gallery is a picture manager that typically exhibits
miniatures, supports the features of “save picture”, “set
pictures as desktop” and “share picture”.
50
3.15 Camera
Your phone provides the camera and video recorder
features. Wherever you go, you can take high-resolution
photos and videos. It also supports advanced camera
features such as image stabilization, face embelishment,
51
panorama shooting, high dynamic range and zero delay
shutter, which can also be customized.
3.16 Messaging
Messaging lets you send text and multimedia
52
messages to any contact that has an SMS device. The
multimedia messages include photos, video clips (for
iPhone 3GS or other new style phones), contacts
information, and voice memos. What’s more, you can
send messages to several contacts at the same time.
Note: Perhaps Messaging is not available in all
countries and regions. Probably you need pay for using
53
Messaging. For more information, consult your network
operator.
As long as you are within the network, you can use
“Messaging”. As long as you can make a call, you can
send messages. You probably have to pay for sending or
receiving messages, depending on your network
operator.
Send a message: Tap it, enter the number and
name of the contact or select the contact from Contacts.
Tap the text box above keypad, enter the information and
then tap “Send”.
After selecting the number, you can select such
options as Call, Add subject, Attach, Insert facial
expression, and more.
Tap Settings to set ringtone, Delivery reports, and
maximum quantity of messages.
3.17 Notification Menu
Slide and pull down menu on the main interface, you
can see the message notice and choose whether to turn
on or off WIFI, Bluetooth, GPS, off-line mode. In the data
connection, the current SIM is available to make data
connection of GPRS. Slide it around you can see the
options of profile for your convenience.
54
3.18 Download Content
You can download through the browser things and
pictures you want and list them in the Download Content
menu.
55
3.19 Music
Music is used for enjoying the stored audio files.
Select Music, you can see the menus of “ List of played
songs”, “Songs”, “Specialists” and “Artists”.
56
To pause playing a song Tap
To resume playing a song Tap ►
57
To skip to the next song
or reading material Tap
Return to the previous
song or reading material Tap
To move fast backward or
forward
Touch and hold or . The
3.20 Call Records
Come into the call records, you can view missed
calls, reveived calls and outgoing calls. The calling time
is viewed in each record and features such as calling,
sending messages and adding to new contacts can be
set. Deleting call records and seting up speed dial can
be done in the menu.
58
3.21 Widget
The widget is on the right of applications in Main
Menu, holding down this widget, you can drag it
anywhere you want in the main screen. It is convenient
for you to enter that procedure.
59
3.22 Selecting Wallpaper Source
Hold down the main screen, the options of selecting
wallpaper source will appear, then you can set up
wallpapers you like.
60
3.23 Local search
You can find some merchants and service facilities
near a location, which you can find through GPS
navigation.
61
3.24 Note
Add note,Convenient you to check,delete and sort at any
time.
62
3.25 Flashlight
Enter flashlight app,click the turn on button,can open to
light,user-friendly.
63
3.26 Documents To Go
Convenient you seee,edit&create Microsoft Word,Excel
and PowerPoint file and review Adobe PDF and Attached.
64
3.27 MoboPlayer
A smart view play that support various format video,you
can easily paly stored video files.
65
3.28 Map
The Map application provides the street maps,
pictures, mixed views, and street views of many countries
and regions in the world. You can get real-time traffic
conditions, as well as detailed directions of driving, public
transit, or walking. To get the direction of driving, find the
starting point, and then enter the destination.
66
The maps, directions and location-based information
are provided by relevant data services. These data
services may vary from time to time, and be not available
in some regions, thus the provided maps, directions and
location-based information may be invalid, incorrect or
incomplete.
If the location service is closed when you open the
“Map”, the system may ask you to enable the service. But
you can use the “map” without enabling the location
service.
67
3.29 Navigation
By virtue of GPS signal receiver, your current
location is shown on the electronic map. If you have set
the destination, the system will tell you the route. This
saves your time.
Signals from GPS satellites can be received only
when you are using your phone outdoors or at the
window through which you can see the sky.
How to use the feature: In the Main screen, select
“Settings”, click “Location and Safety”, tick “Use GPS
satellite”, and then reach the navigation menu. Note that
it may take 10 minutes or more for your phone to
determine your current location for the first time.
68
3.30 Voice Search
Support voice search,through voice search website on
google.
69
3.31 Videos
A videos software,can detect mobile video and auto
generate play list,you can easily paly stored video files.
70
3.32 SIM Card Application
This function is provided by the network provider.I f the
SIM card and network providers do not support this kind of
service,the function will not be able to use.Please contact the
network provider to get more information.
3.33 GMail
Gmail is a free web mail service in Google.It can be
permanently retained the important mail,documents and
pictures.It can make the communication more simple,effective
and fun.Gmail will automatically send e-mail to the group and
reply directly to dialogue,so you can easily enter the emails to
71
reply,just like chart.Now,you also can chart with other with
Gmail.
No pop-up window or banner advertising in Gmail,and
almost no spam in it.With the Google search,you will easy to
find the important information.
72
3.34 Google Talk
Google Talk is a downloadable chat application developed
by Google. Check out what Google Talk can do:
3.35 ToDo
Add todo,can write schedule notice and set deadline
data.Review schedule and finish schedule more
Convenient.
73
3.36 Backup and Reset
Backup personal data and applications to sdcard,can restore
at anytime if want.
74
3.37 Film Workspace
<Film Workspace> is a perfect video edit
software,let you can put together your stored music,photo
and short video form a falm,enjoy your life.
75
3.38 Play store
You can download and install the required application
in the store.
Install the application program
Follow the steps below,you can download and install
the application:
76
First,enter the list of mobile phone application and
open the Play Store.
Second,you will find the recommendation,latest and
necessary options when you enter the store.You also can
find a search button on the lower right corner.You can get
the class of all application when you click on the category
options,and get it if you click on the button of ranking.You
also can get everything about the application which you
want.
Third,you can knew the brief introduction and user
rating after you found the application which you want.It
good for you to make a evaluation on the program.
Last,click on the button of install which at the bottom of
the screen after you have found the application which you
want to install.The Play Store will download it.And next,you
can install it.
4. Text Input
Enter text via the keypad. Examples of text include
contact details, emails, short messages, and websites.
The keypad provides the functions of spelling prediction,
spelling correction and learning while using.
77
The smart keypad may give you prompts of correct
spelling, depending on which application you are using.
Enter text：
1 Tap the text box (memo, or new contact) to call the
keypad.
2 Tap the keys on keypad.
At the initial stage, you can tap keys using either of
your index fingers. Once you get familiar with the keypad,
you can try tapping keys using both of your thumbs.
While tapping a key, the corresponding letter will
appear above your thumb or another finger. If you are
tapping a wrong key, you may slide to the correct one.
Only when your tapping finger leaves a key, can the
corresponding letter be entered in the text box.
78
To delete a character
Tap 。
To enter an
upper-case letter Ta p , and then tap that
letter.
To enter a digit
Tap , and then tap that digit.
To enter a symbol
Tap , and then tap that
symbol.
Quickly enter a space Press the space key twice
successively.
To toggle input
methods Hold down to to bring up
79
the keyboard.
5 SD Card Introduction
Your mobile phone supports SD card to expand the
memory. Install the SD card according to the indication.
As one of storages for your phone, SD card has
been set as the default storage at factory. You can
directly use it without making any settings.
Use as flash disk: If “Phone——Data Wire——PC”
is well connected, the PC will prompt “New hardware is
found”, and “MT65xx Android Phone requires to be
installed” will appear in the dialog box。
After checking and confirmation, reconnect “Phone -
Data Wire - PC”, and pull down notification menu in the
standby interface:
80
Select “connected as USB Storage, and the following
screen pops up.
81
Select “USB storage device”, and such dialogue box
pops up:
You can synchronize files on the computer with those
on the phone according to your needs or you can manage
files on the storage card.
Select “MTP storage” to support the phone to function as a
U-disk. If your computer is not supported by WIN7, you
need to install MTP drive (you can directly update window
82
player to the latest wmp11 which comes with MTP drive).
Follow the prompts appearing in the phone to operate,
so that data uploading and downloading with U disk can
be achieved.
Select “Camera PTP”, you can export photos on the
phone to the computer.
Note:
Your mobile phone supports the plug-in feature.
Without turning off your phone, however, it does not
support inserting or remove T card. Generally, it is not
recommended to remove and install the SD card.
83
6 FAQs and Solutions
If you have any questions about the phone, please
find the solutions from the table below.
FAQs Causes Solutions
Poor
reception
When you use your
phone at poor
reception areas, for
example, near high
rise buildings or base
rooms, the radio wave
cannot be transmitted
effectively.
Avoid this as far as
you can.
When you use your
phone at network
traffic congestion,
such as working time
and off-duty time, the
congestion can result
in poor reception.
Avoid this as far as
you can.
This is related to the
distance to base
station in question.
You may ask the
network service
provider to provide
service coverage
map.
Echoes or
noises
The trunk line of
network is in bad
condition. It is a
regional problem.
Hang off the call and
dial again. Choose
another better line.
In some areas, the
call lines are in bad
condition.
84
Shorter
standby time
The standby time is
relevant to network
settings.
In poor reception
areas, turn off your
phone temporarily.
Replace the batteries Change with a new
battery.
When no signals are
received, your phone
will continue
searching for base
stations, thus
consuming a large
amount of battery
power and reducing
standby time.
Use your phone at
strong signal areas or
Turn off the phone
temporarily.
Failed to turn
on your phone
The battery power is
used up.
Check the battery
power level or charge
the battery.
SIM card error The SIM card is
damaged.
Contact your network
service provider.
The SIM card is not
properly installed.
Ensure the SIM card
is properly installed.
The metallic face of
the SIM card is
contaminated.
Wipe the face with a
clean cloth.
Failed to
connect to the
network
The SIM card is
invalid.
Contact your network
service provider.
Beyond the GSM
coverage.
Consult the network
service provider for
service areas.
The signal is feeble. Retry at a stronger
signal area.
Failed to
make a call
The call barring
feature is used.
Cancel the call
barring settings.
The fixed dialing
number feature is
used.
Cancel the fixed
dialing number
settings.
85
PIN code
error
Enter incorrect PIN
codes for three times
in succession.
Contact your network
service provider.
Failed to
charge the
battery
The battery or the
charger is damaged.
Change a new battery
or charger.
Poor connection. Check whether the
plug is properly
connected.
Failed to add
contacts to
phonebook
The storage space of
phonebook is used
up.
Delete some contacts
from the phonebook.
Failed to set
up some
features
Your network service
provider does not
provide the services,
or you haven’t
subscribed them.
Contact your network
service provider.
86
Environmental Conditions:
Working temperature 25 ℃
Working humidity 75+/-20% RH
Caution:
The plug considered as disconnect device of adapter.
Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
Hereby, Shenzhen GOTRON Electronic CO.,LTD., declares
that this Mobile phone/U5S+ ,U5E ,U5S is in compliance with
the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local
regulations:
hand in the non-working electrical
equipments to an appropriate waste
disposal centre.
87
The following standards have been applied for the
investigation of compliance:
ETSI EN 301 489-1 V1.9.2: 2011
ETSI EN 301 489-3 V1.6.1: 2013
ETSI EN 301 489-7 V1.3.1: 2005
ETSI EN 301 489-17 V2.2.1: 2012
ETSI EN 301 489-24 V1.5.1: 2010
ETSI EN 301 511 V9.0.2: 2003
ETSI EN 300 328 V1.8.1: 2012
ETSI EN 300 440-1 V1.6.1: 2010
ETSI EN 300 440-2 V1.4.1: 2010
ETSI EN 301 908-1 V6.2.1: 2013
ETSI EN 301 908-2 V6.2.1: 2013
EN 62479: 2010
EN 50566:2013
EN 50360:2001+A1:2012
EN 62209-1:2006
EN 62209-2:2010
EN 60950-1：2006 +A11: 2009 +A1: 2010+A12:2011
EN 50332-1: 2000
EN 50332-2: 2003
EN 62471: 2008
88
Use careful with the earphone maybe possible excessive sound
pressure from earphones and headphones can cause hearing
loss The product shall only be connected to a USB interface of
version USB2.0 or higher and that the connection to a power
USB is prohibited. Adapter shall be installed near the
equipment and shall be easily accessible.
Only can use adapter as below:
Shenzhen Diasinger Digital Co.,LTD
Adapter model: D3-501000
I/P: 100-240V~50/60Hz, 0.2A, O/P: 5V, 1A
The plug considered as disconnect device of adapter
The RF distance between body and mobile phone is 10mm
89
FCC and IC Note:
This device complies with Part 15 of the FCC rules and
Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY
RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS OR CHANGE TO
THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE
COULD VOID THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
90
IC Note : Cet appareil est conforme à la Partie 15 des
règlements de la FCC et aux normes RSS de l’Industrie du
Canada. Son fonctionnement est soumis aux deux conditions
suivantes : (1) cet appareil ne doit pas causer des
interférences nuisibles, et (2) cet appareil doit accepter toute
interférence reçue, y compris les interférences qui peuvent
provoquer un fonctionnement indésirable.
Le fabricant n'est pas responsable des toutes interférences
radio ou télévision causées par des modifications non
autorisées apportées à cet appareil. De telles modifications
peuvent empêcher l’utilisateur d’utiliser l'appareil.
91
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
92
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one
gram of tissue. Device types U5E (FCC ID: SW9-U5E) has
also been tested against this SAR limit. The highest SAR value
reported under this standard during product certification for use
at the head is 0.19W/kg and when properly worn on the body is
0.49W/kg. This device was tested for typical body-worn
operations with the back of the handset kept 1.5cm from the
body. To maintain compliance with FCC RF exposure
requirements, use accessories that maintain a 1.5cm separation
distance between the user's body and the back of the handset.
The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be
avoided.
93
IC RF Exposure Information and Statement
The SAR limit of Canada (IC) is 1.6 W/kg averaged over one
gram of tissue. Device types K2 (IC ID: 12421A-K2) has also
been tested against this SAR limit. The highest SAR value
reported under this standard during product certification for use
at the head is 0.19W/kg and when properly worn on the body is
0.49W/kg. This device was tested for typical body-worn
operations with the back of the handset kept 1.5cm from the
body. To maintain compliance with IC RF exposure
requirements, use accessories that maintain a 1.5cm separation
distance between the user's body and the back of the handset.
The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not
comply with IC RF exposure requirements, and should be
avoided.
