DRAFT USER MANUAL
Clubhouse Computer Appendix B
CHC User's Manual - Rev B 10-1
2000, Inforetech Golf Technology 2000 Inc.
Appendix B – Sepecifications and
Regulatory Information
Specifications
The Inforetech system uses two computers:
• The Linux computer that communicates with the base station,
handsets, and charging station.
• The Windows NT computer (acting as a server) is networked
to the Linux computer, and provides the user interface to the
Linux system.
One (or more) computers can act as clients to the NT server to provide access
to the system from other offices at the golf course.
Linux Computer Specifications
The following table shows the specifications for the Linux Computer.
Processor Intel Celeron 400 MHz
RAM 32 MB
Hard Disk Drive 4 GB
CD-ROM 20X
Video Card 4 MB
Network Card NE2000 compatible
Communications
Card RS-485 PCI card. Model OMG-ULTRA-485
Operating System Debian Linux 2.1
Clubhouse Computer Appendix B
CHC User's Manual - Rev B 10-2
2000, Inforetech Golf Technology 2000 Inc.
Club House Computer Specifications
The following table shows the specifications for the Clubhouse Computer.
Processor Intel Pentium II 266 MHz (455 MHz preferred)
RAM 256 MB
L1 cache 23 KB
L2 cache 512 KB
Motherboard PCI and ISA
Hard Disk Drive 4 GB or larger
CD-ROM 20X
Video Card 4 MB
Serial Ports Two, 16650 compatible
Parallel One, bidrectional
USB ports Two
Video Card ATI 3D Rage Pro AGP 2x with 4 MB or 8 MB
Modem 56.6 kbps
Monitor 19", 1600 x 1200 pixels, 256 colors
Network Card NE2000 compatible
Audio Card Sound Blaster 16-bit compatible
Communications
Card RS-485 PCI card. Model OMG-ULTRA-485
Operating System Microsoft Windows NT 4.0 Workstation
Printer Color Printer with parallel connection.
Keyboard 101-keys
Mouse 3-button
Remote Presentation Computer Specifications
Same specifications as Clubhouse Computer, except without RS-485 card.
Clubhouse Computer Appendix B
CHC User's Manual - Rev B 10-3
2000, Inforetech Golf Technology 2000 Inc.
Regulatory Information
FCC Registration
The InFOREmer 2000 Handsets and Base Station have been tested and
comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Caution:
Any changes or modifications to the handsets or base station, not
expressly approved by Inforetech Golf 2000 Inc. could void the
user's authority to operate the equipment.
Industry Canada Regulations
With respect to the InFOREmer Handsets and Base Station, this Class A
digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.
Handset Compliance and Labeling
The following is a statement of compliance for the handset:
Inforetech Golf Technology 2000 Inc.
FCCD: OXKINFORMER2000
ISC:XXX XXX XXXX
This device complies with Part15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
Clubhouse Computer Appendix B
CHC User's Manual - Rev B 10-4
2000, Inforetech Golf Technology 2000 Inc.
The following is an example of the label attached to the handset:
Inforetech Golf Technology 2000 Inc.
FCCD: OXKINFORMER2000
ISC:XXX XXX XXXX
Base Station Compliance and Labeling
FCC and IS Labels
The following is an example of the label attached to the Base Station:
Inforetech Golf Technology 2000 Inc.
FCCD: OXKBSI200
ISC:XXX XXX XXXX
This device complies with Part15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
