User Manual

Wireless Bluetooth Earbuds
1.Please do not overuse this earphone or put it under heavy pressure,
keep away from wet and heat.
2.Keep away from WIFI, router or other high frequency transmitting
equipment to prevent interruption of signal receiving.
3.Please use this earphone under its working range (10meters), and the
effect would be better if there is no obstacle between the connected
devices.
4.Use this Bluetooth earphone to connect any device with Bluetooth
function
Warnings:
Bluetooth usage:
1.Making phone calls:
Be sure the earphone connected with your mobile phone, and then you can
make phone calls. When making calls, there is only one side earphone
working, and there s incoming call, it would broadcast calling numbers.
You answer the call by slightly press the power button one time and refuse
to answer by quick press the power button 2 times. When the earphones
are in music mode, you dial your latest number by quick press the power
button 2 times(redial the latest number).
2. Listening to music:
Be sure the earphone connected with your mobile phone, then you can
listen to music on your music list. Shortly press the power button to stop
the music and replay by press again.
3.power off.
Long press the power button until led in red when not use, the Bluetooth
device enter off mode. lt would be power off automatically when the
earphone away from your Bluetooth device over 5 minutes. No need to
worry power exhausted.
4.Charging:
There is reminding sound when battery is low, and the led would flash in
red at the same time. When taking charge, the led would be in red, and
turns in blue when fully charged.
Note:the earphone would be forced to shut down when charging even if
they are power ON before charging.
NOTE: THERE would be only one earbud working when making/answering
phone calls, but both sides could control power off/play/pause function
individually when connected, the other one would be synchronized.
Memory function supports connecting devices automatically if being
Spectfications:
About pairing:
True wireless stereo (TWS), real no wires design, individual left and right
channel, HIFI sound, both the left and right earbud are Bluetooth enabled,
could be used separately, or used as one pair.
1.Pairing with one earbud: long press the multi-function button until the led
flashing in red and blue alternately, then turn on the Bluetooth on your
device and select”HBQ-i7tws”on your list, there would be reminding voice
saying”connected”, then you could enjoy music or making phones calls, it
supports reporting incoming calls.
2.Pairing with both sides:
a.long press the multi-function buttons of both sides at the same time until
the led flashing in red and blue alternately;
b.then double click EITHER side to enter pairing mode, there would be
reminding voice”ready to pair”;
c.turn on the Bluetooth on your device and choose”HBQ-I7TWS”to
connect, when the led flash slowly in blue, they pair successfully. Battery
status display on your cellphone
Bluetooth version:
Bluetooth Mode:
Bluetooth Frequency:
Bluetooth Range:
Battery capacity:
Talk/Play time:
Standby time:
V4.2+EDR (both sides), ultra low consumption
A2DP1.3/HFP1.6/HSP1.2/AVRCP1.6/D11.3.
2.4GHZ
10 meters with no obstacles
Earbud: 50mah rechargeable Li-ion battery
Charging dock:800mah (optional)
Single earbud mode:Up to 4.5 hours
One Pair earbuds mode:Up to 3 hours
Single earbud mode:100 hours
One Pair earbuds mode:60 hours
3 4
2
EP-052 Manual
5
4
6
1
32
Dust-proof mesh
Multi-function button
MIC
Charging port
1
2
3
4
FCC ID:2AMD8EP-052
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
