GUANGZHOU ADS AUDIO SCIENCE and TECHNOLOGY TROLLEY-0003 TROLLEY SPEAKER User Manual
GUANGZHOU ADS AUDIO SCIENCE & TECHNOLOGY CO., LTD. TROLLEY SPEAKER
User Manual
SBX-104
* RF warning for Portable device:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
can be used in portable exposure condition without restriction.
Content
Technical specifications
Instructions
1.The white RCA socket L is for LEFT channel input, the red RCA socket
R is for RIGHT channel in put
2.The 3.5 line-in socket is for audio source from PC through 3.5 JACK input.
3.Please connect the system according to the diagram above and refer to
component instruction when connecting.
4.Please do not plug the power cable before the connecting is finished.
5.Please raise the volume to what will be needed before starting the system.
6.Please make sure all cables are firmly connected, in case any looses,
no sound or noise may takes place.
7.Please make sure the power is off when plug or unplug the power cord to
or from AC outlet.
Impedance: 4
Frequency response: 55Hz~20KHz(+1/-3dB)
S/N Ratio: 71dB
Harmonic distortion %: 1
Voltage ~120V/240V 50/60Hz
1
Content
1
Technical specifications
Safety Precaution 2
5
System connection
5
Operation
6
Instructions & Bluetooth Operation
4
Top panel functions and contro 3
Remote functions
Back panel functions and contro 4
Bluetooth Operation
1.Pls press the bluetooth key on remote or press the input key on
speaker panel, switch the speaker to bluetooth channel. When you
hear DingDong sound, the speaker work under bluetooth.
2.Press the mobile phone menu , open the bluetooth and scan the
device. When you find a QFX SBX-104 name, press match ,
then they will match automatically. Once it's succeed, you can play the music.
FM frequency: 87.50-108.00MHz
5.Do not dismantle the casing: Serious
electric shock may occur if touching
internal parts carelessly. Prevent
metal pieces or liquid from dropping
inside the machine from openings.
4.Power line protection:
Prevent power line from being stepped on
or pinched by heavy objects. Special
attention should be paid to plug of power
Cord, outlets on backboard and sockets on
wall. Never pull or drag power line.
3.This machine cannot bear heavy load:
Avoid sunray hitting directly, and stays
away from various heating sources such
as stove, radiator and so on. Don't be
close to the environments with much dust,
high temperature, strong light and strong
magnetic field etc.
2.Caution for Electrical Shock:
Wet hands are unallowable to plug in or
out power plug to avoid electrical shock.
Don't suffer raining or watering! Vases or
other vessels containing water cannot be
placed on the main unit.
1.Power:
When working/recharing under AC power,
please operate only under power indicated
in the instruction or marked on device.
~120V/240V
6.The plug as the device completely cut
off from the power supply, It should keep
easy operation.
If the unit will not be used for a longtime,
Please un plug the power cord from AC power
Outlet.
System connection
Installation and play
50/60Hz
Operation
1.Turn on the unit, connect to sound sources and play.
Safety Precaution
2.Insert USB/SD card to read Mp3 tracks;.press MODE key to select USB/SD
input or FM radio, FM programmes scan & save automatically.
CAUTION
Backboard egressing of heat
please do not touch
FM ANT
120V 60Hz 240V 50Hz
~ 120V/240V 50/60Hz
AUDIO IN
LINE OUT
L
R
L
R
12
11
13
14
FM SCANFM SCAN
CH- CH- CH+CH+
2
1
3
5
4
6
7
9
8
10
15
1.Mute key
8.Tracks select key
2.Prev folder key
4. EQ mode key
10.Standby key
11. Next folder key
3.Folder Repeat key
13.Play/pause/Fm scan key
5.Volume increase key
7.Volume decreasa key
6.Previous/Fm ch- key
14.Next/Fm ch+ key
15.Mode key-To select Input signal source
9.Scan key
12. Rpeat key
CAUTION
Backboard egressing of heat
please do not touch
FM ANT
120V 60Hz 240V 50Hz
~ 120V/240V 50/60Hz
1.Line input
4.ON/OFF switch
6.Power cord
5.Antenna
3.Power supply socket
2
1
3
567
9
8
4
12
11
13
10
Back panel functions and controlBack panel functions and control
Top Panel functions and control
14. Repeat key
11. Next & vol+ key
13. Play/ Pause & FM scan key
4. Preview & vol- key
12. Mode key -To select input signal source.
5. USB & SD jack
Remote functions
3. MIC volume control
1. Echo control
7. MIC jack
6.Equalizer for left and right channels
Functions
2. Led switch
14
8. Bass control
9. Treble control
10. Master volume control
Line IN
LINE OUT
L
R
L
R
6
2.Line output
