TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

107 107

G 38

G 129

G 123

G 124

G 275

G 258

G 257

G 58 G 6 - G 18

G 710

G 68

G 122

G 121 G 272 G 103

G 271

G 273

G 108 G 276

G 275

G 106

G 270

001

GAGGIA

G 340

G/6 Guarniz. porta filtro mm. 9

G/18 Guarniz. Tell mm. 8,5

G/38 OR per elettrovalvola

G/55 Spessore portafiltro

G/58 Guarnizione rame

G/68 Doccia a rete

G/103 Portafiltro cromato

G/106 Vite fissaggio manopola

G/108 Manopola porta filtro U.T.

G/121 Vite inox per doccia

G/122 Vite inox per porta doccia

G/123 Vite brugola

G/124 Rondella per brugola

G/128 Vite fissaggio elettrov.

G/129 Piastra porta elettrov.

G/131 Bobina Parker V 230

G/257

Guarniz. attacco gr. U.T. quadra

G/258 Flangia attacco gr. rame

G/262 Bobina Parker V 24

G/270 Beccuccio a 1 via

G/271 Beccuccio a 2 vie

G/272 Molla ferma filtro

G/273

Beccuccio 2 vie con divisore

G/275 Rondella vite manopola

G/276 Benzing per manopola

G/340 Portafiltro con manopola

G/360 Portafiltro prova pressione

G/356 Bobina Parker V 110

G/640

Corpo elettrovalvola Parker

G/710 Blocchetto porta doccia

9mm. portafilter gasket

8.5mm. portafilter gasket

Solenoid valve O-ring

Portafilter gasket shim

Gasket

Shower screen with screen net

Portafilter

Grip fixing screw

U.T. Portafilter knob

SS screw for shower screen

SS screw for shower screen holder

Group fixing allen screw

Washer for allen screw

Fixing screw for solenoid valve

Plate for solenoid valve

Parker coil 230V

Group connection square gasket

"Ele" group copper flange

Parker coil 24 V

1-way spout

2-way spout

Filter stop spring

2-way spout with divider

Handle screw washer

Handle benzing

Complete portafilter

Pressure test portafilter

Parker coil 110 V

Parker solenoid valve body

Shower screen holder plate

G 55

G

G 640

G 131 - G 262 - G 356

G 128

10/03

GRUPPO ELETTROVALVOLA - PORTAFILTRO

G 360

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

108

108

G 290

G 291

G 23

G 293

G 20

G 294

G 34

G 295

G 22

G 21

G 302

G 303

G 304

G 305

G 306

G 307

G 300

G 301

G 315 - G 316 - G 317

G 308 G 309

G 109

G 138

G 137

G 114-G 120

002

G 113 - G 119

GAGGIA

G/20 Guarnizione vapore

G/21

OR rubinetto vapore acqua

G/22

OR rub. vapore acqua al silic.

G/23

OR rub. vapore e acqua

G/34 OR asta rubinetto

G/109 Pulsante per elettrov.

G/113

Manometro atm. 3 mod. Ele

G/114

Manometro atm. 15 mod. Ele

G/119

Manometro atm. 3 Ele inox

G/120

Manometro atm. 15 Ele inox

G/137 Relè V 24

G/138 Relè V 230

G/290 Raccordo rubinetto Ele

G/291 Molla porta guarnizione

G/293 Portaguarnizione

G/294 Asta otturatore

G/295 Asta rubinetto

G/297 Dado 3/8"

G/298 Asta filettata mod. Ele

G/299 Ghiera mod. Ele

G/300 Molla rett. per volantino

G/301 Volantino mod. Ele

G/302 Snodo per rubinetto

G/303 Molla snodo

G/304 Tappo per snodo

G/305 Sfera

G/306 Molla premisfera

G/307 Bussola

G/308 Tubo vapore

G/309 Tubo acqua

G/310 Assieme rubinetto ELE

G/315 Adesivo vapore

G/316 Adesivo acqua

G/317 Adesivo scaldatazze

ø 15x6x6 steam gasket

Steam/water valve big O-ring

Steam/water valve small O-ring

Steam/water valve O-ring

Valve Stem 102 O-ring

Solenoid valve switch

3 atm. pressure gauge "Ele"

15 atm. pressure gauge "Ele"

3 atm. pressure gauge "Ele" SS

15 atm. pressure gauge "Ele" SS

"Ele" 24V relay

"Ele" 230V relay

"Grimac" connector

"Ele" valve spring

Gasket holder

Shutter stem

Valve stem

3/8" nut

Thread bar for "Ele" handle

Ring nut for "Ele" valve

Square spring for knob

Water/steam knob for "Ele"

Art. joint for valve

Spring for art. joint

Cap for art. joint

Ball for steam pipe

Ball stop spring

Bushing

"Ele" steam pipe

"Ele" water pipe

"Ele" valve assembly

Steam symbol

Water symbol

Cup heater symbol

05/07

RUBINETTI - RELÈ - MANOMETRI

G 299

G 298

G 297

G 310

TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

109 109

003

GAGGIA

G/6 Guarniz. porta filtro mm. 9

G/18 Guarniz. porta filtro Tell

G/33 OR 150 flangia gr. Tell

G/38 OR per elettrovalvola

G/55 Spessore portafiltro

G/58 Guarnizione rame

G/68 Doccia con rete

G/121 Vite inox per doccia

G/122 Vite inox porta doccia

G/129 Piastra porta elettrov.

G/131 Bobina Parker V 230

G/262 Bobina Parker V 24

G/356 Bobina Parker V 110/60Hz

G/640

Corpo elettrovalvola Parker

G/710 Blocchetto porta doccia

9mm. portafilter gasket

8.5mm portafilter gasket

Gr. flange 150 O-ring "Tell"

Solenoid valve O-ring

Portafilter gasket shim

Gasket

Shower screen with screen net

SS screw for shower screen

SS screw for shower screen holder

Plate for solenoid valve

Parker coil 230V

Parker coil 24V

Parker coil 110V/60Hz

Parker solenoid valve body

Shower screen holder plate

G

01/98

G 38

G 129G 33

G 58

G 6 - G 18

G 122

G 710

G 68

G 121

G 55

G 131- G 262 - G 356

G 640

GRUPPO ELETTROVALVOLA

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

110

110

G/15 Guarnizione

ø 15x6x3

G/32 OR 113 snodo rubinetto

G/34 OR 102 asta rubinetto

G/41 Guarnizione

G/92 Valvola per caldaia

G/134 Fresa per rubinetto P.T.

G/135 Fresa per rubinetto U.T.

G/206 Benzing per volantino

G/207 Rondella per volantino

G/208

Asta filettata per volantino

G/209 Ghiera per rubinetto

G/210 Manopola rubinetto

G/211 Ghiera manopola

G/212 Tappo manopola

G/213 Tubo vap. snodato U.T.

G/286 Asta rubinetto

G/287 Portaguarnizione

G/288 Raccordo filetto originale

G/291 Molla rubinetto Tell

G/297 Controdado 3/8"

MAC/505

Molla dos. grande (aristarco)

MAC/506

Molla dos. piccolo (aristarco)

G 297

G 34

G 286

G 15

G 287

G 291

G 41

G 288

MAC 506

MAC 505

G 212

G 211

G 206

G 207

G 209

G 208

G 92

G 32

G 134 - G 135

004

G 210

GAGGIA

ø 15x6x3 steam gasket

113 O-ring valve

Valve stem 102 O-ring

Water/steam gasket

Valve for boiler

Lever machine steam valve cutter

Steam valve cutter

Valve knob benzing

Valve knob washer

Thread rod for knob

Valve ring nut

Steam/water valve grip

Ring nut for grip

Cap for grip

"Tell" art. steam pipe

"Ele" valve stem

"Ele" gasket holder

"Ele" valve body connector

"Ele" valve spring

3/8" nut

Big Gaggia meter spring

Little Gaggia meter spring

G 213

01/98

FRESE - RUBINETTI

TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

111 111

G/43 Guarniz. resist. grande

G/44 Guarniz. resist. piccola

G/47 Guarniz. resist. tonda Teflon

G/48

Guarniz. flangia caldaia t.a.

G/50

Guarniz. caldaia 10 fori "Tell"

G/51

Guarniz. flangia caldaietta

G/52

Guarniz. caldaietta Teflon "Tell"

G 44 G 43

G 47

G 48

G 50

G 51

G 52

005

GAGGIA

Big heating element gasket

Small heating element gasket

Teflon heating element gasket

T.a. boiler flange gasket

"Tell" 10 hole boiler gasket

Small boiler flange gasket

"Tell" teflon small boiler gasket

G

01/98

GUARNIZIONI

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

112

112

006

GAGGIA A LEVA

G/6

Guarniz. porta filtro mm. 9

G/46 Guarniz. flangia gr. 4 fori

G/54 Spessore per pistone

G/55 Spessore per guarniz.

G/70 Filtro 1 tazza 7 gr.

G/71 Filtro 2 tazze 14 gr.

G/72 Filtro cieco

G/73 Molla gruppo

G/93 Cremagliera con snodo

G/94 Perno dentato

G/95

Cuscinetto macchina a leva

G/102 Sfera per cricchetto

G/103 Portafiltro cromato

G/105 Manopola porta filtro

G/106 Vite fiss. manopola

G/201 Prigioniero gr. 8x34

G/270 Beccuccio a 1 via

G/271 Beccuccio a 2 vie

G/272 Molla ferma filtro

G/273

Beccuccio 2 vie con divisore

G/275 Rondella vite manopola

G/276 Benzing per manopola

9mm. portafilter gasket

4 hole group flange gasket

Piston shim

Portafilter gasket shim

1-cup filter with edge, 7 g.

2-cup filter with edge, 14 g.

Blind filter

Group lever spring

Rack with articulated joint

Toothed peg

Lever machine bearing

Ball for lifter

Portafilter

Portafilter group

Grip fixing screw

8x34 flange stud bolt

1-way spout

2-way spout

Filter stop spring

2-way spout with divider

Handle screw washer

Handle benzing

G 102

G 73

G 95

G 94

G 95

G 93

G 272 G 276

G 275

G 106

G 105

G 103

G 55

G 6

G 71

G 70

G 271

G 273

G 270

G 54

G 54

G 46

G 201

12/00

G 72

GRUPPO A LEVA

TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

113 113

G 91

G 32

G 90

G 89

G 259

G 104

G 107

007

G 320

G 321

G 322

G 323

G 324

G 325

G 326

G 349

GAGGIA

G 255

G/32 OR per vetro livello

G/89 Copri livello in plastica

G/90 Vetro livello Tell

G/91 Vetro livello T.D.S.

G/104 Volantino

G/107 Interruttore a scatto Tell

G/255 Vetro livello U.T. Ele

G/259 Termoc. automatico gas

G/320 RL401 E V 230 (11) DM 643

G/321

RL 401 E V 110 (11) DM 643/1

G/322

RL401 E V 24 (11) DM 643/2

G/323

RL40 GR

V 230 (8) DM 644

G/325

RL60 1 DT V 230 11 pernini

G/326

RL60 1 DT V 24 11 pernini

G/349

RL30 1 E 2 C V 230 11 pernini

V/96 Rubinetto termocoppia gas

attacco 3/8"

113 O-ring valve

Plastic level cover for "Ele"

"Tell" level glass

Level glass T.D.S.

Vapor knob

"Tell" machine snap switch

"Ele" level glass

Automatic gas system

thermocouple

RL401 E 230V (11) DM643

RL401 E 110V (11) DM643/1

RL401 E 24V (11) DM643/2

RL401 E 230V (8) DM644

RL60-1 DT (11) 230V

RL60-1 DT (11) 24V

RL30 1E 2C 230V. (11)

3/8 gas fitting thermocou-

ple valve

G

12/00

V 96

AUTOLIVELLO-TERMOCOPPIE-INTERRUTTORI

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

114

114

008

G/113 Manometro atm. 3 "Ele"

G/114 Manometro atm. 15 "Ele"

G/117 Manometro rett. atm. 3

G/118 Manometro rett. atm. 15

G/119 Manometro atm. 3 "Ele"

80-D90-E90

G/120 Manometro atm. 15 "Ele"

80-D90-E90

G/362 Pulsantiera 5 tasti

3 Atm. pressure gauge "Ele"

15 Atm. pressure gauge "Ele"

3 Atm. rect. pressure gauge

15 Atm. rect. pressure gauge

3 Atm. pressure gauge "Ele" SS

15 Atm. pressure gauge "Ele" SS

5 - key push-button panel

12/00

MANOMETRI GAGGIA

G 113

G 119

G 114

G 120 G 118

G 117

G 362

TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

115 115

009

GAGGIA

Heating element O-ring

Heating element gasket

"Ele" heat. element gasket

"Tell" mod. 1 gr. heating

element 750W 230V

"Tell" mod. 2 gr. heating

element 2000W 230V

2 gr. heat. elem. 2000W 380V

1 gr. heat. elem. 1300W 110V/60Hz

"Ele" 1 gr. 6 poles heat.

elem. 2000W 230/380V

"Ele" 2 gr. 6 poles heat.

elem. 4000W 230/380V

"Ele" 3 gr. 6 poles heat.

elem. 5000W 230/380V

"Ele" 4 gr. 6 poles heat.

elem. 6000W 230/380V

"Tell" 3 gr. heat. elem. 3500W

"Ele" 2 gr. 6 poles heat. elem. 4000W

"Tell" 2 gr. heat. elem. 1250W 110V

"Tell" 3 gr. heat. elem. 1750W 110V

"Tell" 2 gr. heat. elem. 3000W 240V

"Tell" 4 gr. heat. elem. 4000W 240V

1 gr. heat. elem. 2000W 240V

G/39 OR per resistenza U.T.

G/44 Guarnizione resistenza

G/47 Guarniz. per resist. "Ele" U.T.

G/170 Resistenza mod. "Tell" gr. 1

750 W 230 V

G/180 Resistenza mod. "Tell" gr. 2

2000 W 230 V

G/181 Resist. 2 gr. 2000 W 380 V

G/183

Resist. 1 gr. "Ele" 1300W 110/60 V

G/185 Resistenza 1 gr. 6 poli "Ele"

2000 W 230/380 V

G/186 Resistenza 2 gr. 6 poli "Ele"

4000 W 230/380 V

G/187 Resistenza 3 gr. 6 poli "Ele"

5000 W 230/380 V

G/188 Resistenza 4 gr. 6 poli "Ele"

6000 W 230/380 V

G/190

Resist. 3 gr. "Tell" 3500 W 240 V

G/191

Resist. 2 gr. 6 poli "Ele" 4000 W 110 V

G/192

Resist. 2 gr. "Tell" 1250 W 110 V

G/193

Resist. 3 gr. "Tell" 1750 W 110 V

G/194

Resist. 2 gr. "Tell" 3000 W 240 V

G/195

Resist. 4 gr. "Tell" 4000 W 240 V

G/196

Resist. 1 gr. "Ele" 2000 W 240 V

G

05/07

RESISTENZE

G/198

Resist. 3 gr. "Ele" 7000 W 240 V

G/199

Resist. 4 gr. "Ele" 8000 W 240 V

G/346

Resistenza 1500 W "Asso" 230 V

G/346/1

Resistenza 1500 W "Asso" 110 V

G/347

Resistenza 2000 W "Asso" 230 V

G/347/1

Resistenza 2000 W "Asso" 110 V

G/350

Resistenza TE/TD 2500 W 230 V

"Ele" 3 gr. heat. elem. 7000W 240V

"Ele" 4 gr. heat. elem. 8000W 240V

Heating element 1500W 230V "Asso"

Heating element 1500W 110V "Asso"

Heating element 2000W 230V "Asso"

Heating element 2000W 110V "Asso"

Heating element TE/TD 2500W 230V

G 346 - G 346/1

G 347 - G 347/1

mod. TELL

G 39 - G 47

G 39 - G 47G 183 - G 185 - G 186 - G 187 - G 188

G 191 - G 196 - G 198 - G 199

mod. ELE

G 350

G 44G 170 - G 180 - G 181 - G 190

G 192 - G 193 - G 194 - G 195

mod. ASSO

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

116

116

G 620

G 621

G 622

G 637 G 730

G 612

G 611

G 606

G 721

G 605

G 18

G 710

G 122

G 630

G 121

G 272 G 103

G 271

G 273

G 70

G 71 G 108

G 275

G 276

G 106

G 133

G 600

G 708

G 610

G 38

010

BABY GAGGIA PRIMO MOD.

G/18

Guarniz. porta filtro mm. 8,5

G/38 OR

G/70 Filtro 1 tazza 7 grammi

G/71 Filtro 2 tazze 14 grammi

G/72 Filtro cieco

G/103 Portafiltro

G/106 Vite

G/108 Manopola porta filtro

G/121 Vite inox

G/122 Vite inox

G/130 Gommino scottadito

G/133 Elettrovalvola V 230

G/270

Beccuccio a 1 via curvato

G/271 Beccuccio 2 vie

G/272 Molla

G/273

Beccuccio 2 vie con divisore

G/275 Rondella spaccata

G/276 Rondella

G/340

Portafiltro completo 1° mod.

G/360 Portafiltro prova pressione

G/600 Portagomma a gomito

G/601 Raccordo a gomito

G/605 OR 156

G/606 OR 119

G/610 Valvola di superpressione

G/611 Termostato vapore

G/612 Termostato con sonda

G/620 Interruttore 10 A V 230

G/621 Spia luminosa gialla V 230

G/622 Spia luminosa rossa V 230

G/630 Doccia

G/637 Volantino vapore

G/708 Brugola

G/710 Blocchetto porta doccia

G/721 Caldaietta 230 V

G/730 Molla volantino

V/6 Dosatore in acciaio

V/12 Pressino in plastica

V/80/1

Pompa a membrana 68 W 230 V

8.5mm. portafilter gasket

Solenoid valve O-ring

1-cup filter with edge, 7 g.

2-cup filter with edge, 14 g.

Blind filter

Portafilter

Grip fixing screw

SS screw for shower screen holder

SS screw for shower screen

SS screw for shower screen holder

Compl. solen. valve for "Baby" Gaggia

1-way bent spout

2-way spout

Filter stop spring

2-way spout with divider

Handle screw washer

Handle benzing

1

st

mod. complete portafilter

Pressure test portafilter

Elbow rubber holder

Elbow fitting

156 O-ring

119 O-ring

Over-pressure valve

Steam thermostat

Coffee pressure switch with probe

230V switch panel

230V yellow pilot lamp

230V red pilot lamp

Group body

Steam knob

Steam valve boiler screw

Shower screen holder plate

"Baby" boiler 230V

"Baby" konb spring

Metal misuring spoon

Bakelite coffee pressure

Diaphram pump 68W 230V

05/07

V 6

V 12

G 72

V 80/1 G 601

G 270

G 360

G 340

TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

117 117

G 601

V 80/1

G 730

G 755 - G 756

G 700

G 701

G 703

G 702

G 708

G 611

V 6

V 12

G 70

G 71 G 733 G 736

G 272

G 121

G 630

G 720

G 707

G 18

G 122

G 706

G 705

G 708 G 709

G 713

011

G 735

G 734

NUOVA BABY GAGGIA

8.5mm. portafilter gasket

1-cup filter with edge, 7 g.

2-cup filter with edge, 14 g.

Blind filter

SS screw for shower screen

SS screw for shower screen holder

Filter stop spring

Pressure test portafilter

Elbow fitting

Steam thermostat 150°

Shower screen

3-way solenoid valve

Coffee switch

Water switch

Steam switch

Water pilot lamp

2-way solenoid for "Baby"

Coil 230V

Boiler O-ring

Steam valve boiler screw

Group securing screw

Shower screen holder plate

Valve O-ring

Coffee microswitch

G/720 Caldaietta V 230 Baby

G/730 Molla volantino

G/733 Vite

G/734 Rondella

G/735 Grower

G/736 Manopola

G/737 Portafiltro completo

G/755

Volantino vapore Nuova Baby

G/756

Volantino vapore Gran Gaggia

V/6 Dosatore inox

V/12 Pressino in plastica

V/80/1

Pompa membrana 68 W 230 V

G/18

Guarniz. porta filtro mm. 8,5

G/70 Filtro 1 tazza 7 grammi

G/71 Filtro 2 tazze 14 grammi

G/72 Filtro cieco

G/121 Vite inox

G/122 Vite inox

G/272 Molla

G/360 Portafiltro prova pressione

G/601 Raccordo a gomito

G/611 Termostato vapore 150°

G/630 Doccia

G/699 Elettrovalvola 3 vie

G/700 Pulsante caffè

G/701 Pulsante acqua

G/702 Pulsante vapore

G/703 Spia luminosa acqua

G/705 Elettrovalvola 2 vie Baby

G/706 Bobina V 230

G/707 OR

G/708 Brugola

G/709 Brugola

G/710 Blocchetto porta doccia

G/711 OR rubinetto

G/713 Micro

Espresso "Baby" boiler 230V

"Baby" knob spring

Screw for grip

Washer for grip

Grower for grip

New "Baby" grip with cap

Complete portafilter

Steam knob "New Baby"

Small steam knob

Metal misuring spoon

Bakelite coffee pressure

Membrane pump 68W 230V

G

10/03

G 711

G 699

G 72

G 710

G 737

G 360

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

118

118

012

G 611

G 708

G 720

G 613

G 707

V 6

V 12

G 122

G 18

G 710

G 70

G 71

G 733

G 734

G 735

G 736 G 737

G 272

G 121

G 630

G 708

G 711

G 757

G 709

G 709

G 713

G 712

G 601

G 718

ESPRESSO GAGGIA

G/18

Guarniz. porta filtro mm. 8,5

G/70 Filtro 1 tazza 7 grammi

G/71 Filtro 2 tazze 14 grammi

G/72 Filtro cieco

G/121 Vite inox

G/122 Vite inox

G/272 Molla

G/360 Portafiltro prova pressione

G/601 Raccordo a gomito

G/611 Termostato vapore 150°

G/613 Termostato caffè 107°

G/630 Doccia

G/707 OR caldaia

G/708 Brugola

G/709 Brugola

G/710 Blocchetto porta doccia

G/711 OR rubinetto

G/712 Volantino vapore

G/713 Micro

G/718 Molla volantino

G/720 Caldaietta V 230

G/733 Vite

G/734 Rondella

G/735 Grower

G/736 Manopola Nuova baby

G/737 Portafiltro completo

G/757 Rubinetto

V/6 Dosatore inox

V/12 Pressino in plastica

V/80/1

Pompa a membr. V 230 W 68

8.5mm. portafilter gasket

1-cup filter with edge, 7 g.

2-cup filter with edge, 14 g.

Blind filter

SS screw for shower screen

SS screw for shower screen holder

Filter stop spring

Pressure test portafilter

Elbow fitting

Steam thermostat 150°

Coffee thermostat

Shower screen

Boiler O-ring

Steam valve boiler screw

Group securing screw

Shower screen holder plate

Valve O-ring

"Dandy" espresso steam handle

Coffee microswitch

Knob spring

Espresso "Baby" boiler 230 V

Screw for grip

Washer for grip

Grower for grip

New "Baby" grip with cap

Complete portafilter

Espresso "Dandy" valve

Metal measuring spoon

Bakelite coffee pressure

Diaphram pump 230V 68W

10/03

G 72

V 80/1

G 360

TAV.

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

Macchina tipo

119 119

G 613

G 611

G 757

G 712

G 740

V 80/1

G 601

G 699

G 711

V 6

V 12

G 70

G 71

G 733

G 734

G 735

G 736

G 630

G 121

G 122

013

G 720

G 707

DANDY GAGGIA

G/18

Guarniz. porta filtro mm. 8,5

G/70 Filtro 1 tazza 7 grammi

G/71 Filtro 2 tazze 14 grammi

G/72 Filtro cieco

G/121 Vite inox

G/122 Vite inox

G/272 Molla ferma filtro

G/360 Portafiltro prova pressione

G/601 Raccordo a gomito

G/611 Termostato vapore 150°

G/613 Termostato caffè 107°

G/630 Doccia

G/699 Elettrovalvola 3 vie 230 V

G/707 OR caldaia

G/709 Brugola

G/710 Blocchetto porta doccia

G/711 OR rubinetto

G/712 Volantino vapore

G/720 Caldaietta V 230

G/733 Vite

G/734 Rondella

G/735 Grower

G/736 Manopola nuove baby

G/737 Portafiltro completo

8.5mm. portafilter gasket

1-cup filter with edge, 7 g.

2-cup filter with edge, 14 g.

Blind filter

SS screw for shower screen

SS screw for shower screen holder

Spring

Pressure test portafilter

Elbow fitting

Steam thermostat 150°

Coffee thermostat

Shower screen

3-way solen. for "New Baby/Dandy" 230V

Boiler O-ring

Group securing screw

Shower screen

Valve O-ring

"Dandy" espresso steam handle

Espresso "Baby" boiler 230V

Screw for grip

Washer for grip

Grower for grip

New "Baby" grip with cap

Complete portafilter

"Dandy" thermostat

Espresso "Dandy" valve

Metal measuring spoon

Bakelite coffee pressor

Diaphram pump 230V 68W

G 18

G 272

G 710

G 709

G/740 Termostato

G/757 Rubinetto

V/6 Dosatore inox

V/12 Pressino in plastica

V/80/1

Pompa a membr. V 230 W 68

G

10/03

G 72

G 360

G 737

CODICE

CODES

DENOMINAZIONE

DENOMINATION

CODICE

CODES

DENOMINAZIONE

DENOMINATION

TAV.

Macchina tipo

120

120

014

V 12

G 70

G 71

G 121

G 733

G 734

G 735

G 736 G 737

G 18

G 710

G 122

G 709

G 707 G 708

G 711

G 704

V 80/1

G 601

G 718

G 717

G 272

COFFEE GAGGIA

G/18

Guarniz. porta filtro mm. 8,5

G/70 Filtro 1 tazza 7 grammi

G/71 Filtro 2 tazze 14 grammi

G/72 Filtro cieco

G/121 Vite inox

G/122 Vite inox

G/272 Molla fermofiltro

G/360 Portafiltro prova pressione

G/601 Raccordo

G/611 Termostato vapore 150°

G/613 Termostato caffè 107°

G/630 Doccetta

G/704 Microinterruttore

G/707 OR caldaia

G/708 Brugola

G/709 Brugola

G/710 Blocchetto porta doccia

G/711 OR rubinetto

G/717 Volantino vapore

G/718 Molla volantino

G/719 OR Vyton asta rubinetto

G/720 Caldaietta 230 V

G/733 Vite

G/734 Rondella

G/735 Grower

G/736 Manopola nuove baby

G/737 Portafiltro completo

G/758 Rubinetto

V/6 Dosatore inox

V/6/1 Dosatore di plastica

V/12 Pressino in plastica

V/80/1

Pompa a membr. V 230 68 W

G 719

G 611

G 613

G 720

G 758

8.5mm. portafilter gasket

1-cup filter with edge, 7 g.

2-cup filter with edge, 14 g.

Blind filter

SS screw for shower screen

SS screw for shower screen holder

Filter stop spring

Pressure test portafilter

Elbow fitting

Steam thermostat 150°

Coffee thermostat

Shower screen

Microswitch

Boiler O-ring

Steam valve boiler screw

Group securing screw

Shower screen holder plate

Valve O-ring

Coffee steam knob

Knob spring

New "Baby" Vyton valve O-ring

Espresso "Baby" boiler 230V

Screw for grip

Washer for grip

Grower for grip

New "Baby" grip with cap

Complet portafilter

Coffee valve

Metal measuring spoon

Bakelite measuring spoon

Bakelite coffee pressure

Diaphram pump 230V 68W

V 6

V 6/1

10/03

G 72

G 630

G 360
