Model: P10034AL-XAA
Microwave Oven User's manual
Please read these instructions carefully before installing and operating the oven.
Record in the space below the SERIAL NO. found on the nameplate on your oven and retain
this information for future reference.
SERIAL NO.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 2 页
佛山市顺德区格兰仕
微波炉电器有限公司
1. Do not attempt to operate this oven with the door-open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the oven door
close properly and that there is no damage to the:
1. Door (bent),
2. Hinges and latches (broken or loosened),
3. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
CONTENT
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 2
IMPORTANT SAFETY INSTRUCTIONS ..............................................................................3
INSTALLATION GUIDE.........................................................................................................5
GROUNDING INSTRUCTIONS............................................................................................5
UTENSILS GUIDE ................................................................................................................6
COOKING TECHNIQUES.....................................................................................................7
SPECIFICATIONS ................................................................................................................8
PART NAMES.......................................................................................................................9
CONTROL PANEL ..............................................................................................................10
OPERATION INSTRUCTIONS ........................................................................................... 11
SETTING THE CLOCK............................................................................................... 11
TIME COOK................................................................................................................ 11
POWER LEVEL SETTING.......................................................................................... 11
TIME DEFROST .........................................................................................................12
TIME COOK 1&2 ........................................................................................................12
WEIGHT DEFROST....................................................................................................13
SETTING CHILD LOCK..............................................................................................13
QUICK COOK SETTINGS ..................................................................................................13
ADD 30 SECONDS.....................................................................................................14
1-6 QUICK COOK.......................................................................................................14
POPCORN..................................................................................................................14
BEVERAGE ................................................................................................................14
FOOD TESTING .........................................................................................................15
CANCEL PAD .............................................................................................................15
CANCEL PAD .............................................................................................................15
KEY ADHESION PROTECTING.................................................................................15
CHECK VERSION FUNCTION...................................................................................15
CLEANING AND CARE ......................................................................................................16
P
PR
RE
EC
CA
AU
UT
TI
IO
ON
NS
S
T
TO
O
A
AV
VO
OI
ID
D
P
PO
OS
SS
SI
IB
BL
LE
E
E
EX
XP
PO
OS
SU
UR
RE
E
T
TO
O
E
EX
XC
CE
ES
SS
SI
IV
VE
E
M
MI
IC
CR
RO
OW
WA
AV
VE
E
E
EN
NE
ER
RG
GY
Y
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 3 页
佛山市顺德区格兰仕
微波炉电器有限公司
3
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" on page 1.
3. This appliance must be grounded. Connect only to properly grounded outlet. See "GROUNDING
INSTRUCTIONS” on page 4.
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Some products such as whole eggs and sealed containers -for example, closed glass jars- are able
to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible
materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c. If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the
power cord or shut off power at the fuse or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food in
the cavity when not in use.
9. Liquids, such as water, coffee, or tea can be overheated beyond the boiling point without appearing
to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present. THEIS COULD RESULT IN VERY HOT
LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID. To reduce the risk of injury to person:
1) Do not overheat the liquid.
2) Stir the liquid both before and halfway through heating it.
3) Do not use straight-sided containers with narrow necks.
I
IM
MP
PO
OR
RT
TA
AN
NT
T
S
SA
AF
FE
ET
TY
Y
I
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
NS
S
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 4 页
佛山市顺德区格兰仕
微波炉电器有限公司
4
4) After heating, allow the container to stand in the microwave oven for a short time before removing
the container.
5) Use extreme care when inserting a spoon or other utensil into the container.
10. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in microwave
oven.
11. Pierce foods with heavy skins such as potatoes, whole squash, apples and chestnuts before
cooking.
12. The contents of feeding bottles and baby jars should be stirred or shaken and the temperature
should be checked before serving in order to avoid burns.
13. Cooking utensils may become hot because of heat transferred from the heated food. Potholders
may be needed to handle the utensil.
14. Do not cover or block any openings on the appliance.
15. Do not store or use this appliance outdoors. Do not use this product near water, for example, near a
kitchen sink, in a wet basement, near a swimming pool, or similar locations.
16. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if it
has been damaged or dropped.
17. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord hang
over edge of table or counter.
18. Use only thermometers, which are specifically designed for use in microwave ovens.
19. Do not operate any heating or cooking appliance beneath this appliance.
20. Be certain the glass tray and roller rings are in place when you operate the oven
21. This appliance should be serviced only by qualified service personnel, contact nearest authorized
service facility for examination, repair, or adjustment.
22. When cleaning surfaces of door and oven that comes together on closing the door, use only mild,
nonabrasive soaps, or detergents applied with a sponge or soft cloth.
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 5 页
佛山市顺德区格兰仕
微波炉电器有限公司
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current.
WARNING Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood,
or if doubt exists as to whether the appliance is properly grounded, and either:
1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade
grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of
the extension cord shall be equal to or greater than the electrical rating of the appliance, or 2) Do not
use an extension cord. If the power supply cord is too short, have a qualified electrician or serviceman
install an outlet near the appliance.
ELECTRICAL REQUIREMENTS
The electrical requirements are a 120 volt 60 Hz, AC only, 20 amp. It is recommended that a separate
I
IN
NS
ST
TA
AL
LL
LA
AT
TI
IO
ON
N
G
GU
UI
ID
DE
E
G
GR
RO
OU
UN
ND
DI
IN
NG
G
I
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
NS
S
1. Make sure that all the packing materials
are removed from the inside of the door.
2. Check the oven for any damage, such
as misaligned or bent door, damaged
door seals and sealing surface, broken
or loose door hinges and latches and
dents inside the cavity or on the door. If
there is any damage, do not operate the
oven but contact qualified service
personnel.
3. This microwave oven must be placed
on a flat, stable surface to hold its
weight and the heaviest food likely to be
cooked in the oven.
4. Do not place the oven where heat,
moisture, or high humidity are
generated, or near combustible
materials.
5. For correct operation, the oven must
have sufficient airflow. Allow 20cm of
space above the oven, 10cm at back
and 5cm at both sides. Do not cover or
block any openings on the appliance.
Do not remove feet on which oven
stands.
6. Do not operate the oven without glass
tray, roller support, and shaft in their
proper positions.
7. Make sure that the power supply cord is
undamaged and does not run under the
oven or over any hot or sharp surface.
8. The socket must be readily accessible
so that it can be easily unplugged in an
emergency.
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 6 页
佛山市顺德区格兰仕
微波炉电器有限公司
circuit serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must
be plugged into a wall receptacle that is properly installed and grounded.
Power Supply Cord
1. A short power supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in
their use.
3. If long cord or extension cord is used：
a) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and The longer cord should
be arranged so that it will not drape over the counter top or table top where it can be
pulled on by children or tripped over unintentionally.
Notes:
If you have any questions about the grounding or electrical instructions, consult a qualified
electrician or service person.
Neither the manufacturer nor the dealer can accept any liability for damage to the oven or
personal injury resulting from failure to observe the electrical connection procedures.
Radio or TV Interference
Should there be any interference caused by the microwave oven to your radio or TV, check that the
microwave oven is on a different circuit, relocated the radio or TV as far away from the oven as
feasible or check position and signal of receiving antenna.
This section lists which utensils can be used in the microwave, which ones have limited use for short
periods, and which ones should not be used in the microwave.
9 RECOMMENDED
Microwave browning dish — Use to brown the exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with your browning dish.
Microwaveable plastic wrap — Use to retain steam. Leave a small opening for some steam to escape
and avoid placing it directly on the food.
Paper towels and napkins — Use for short-term heating and covering; these absorb excess moisture
and prevent spattering. Do not use recycled paper towels, which may contain metal and could ignite.
Glass and glass-ceramic bowls and dishes — Use for heating or cooking.
Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled paper,
which may contain metal and could ignite.
Wax paper — Use as a cover to prevent spattering.
U
UT
TE
EN
NS
SI
IL
LS
S
G
GU
UI
ID
DE
E
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 7 页
佛山市顺德区格兰仕
微波炉电器有限公司
Thermometers — Use only those labeled "Microwave Safe" and follow all directions. Check the food in
several places. Conventional thermometers may be used on microwave food once the food has been
removed from the oven.
Λ
LIMITED USE
Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil
can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm) between aluminum
foil and cavity.
Ceramic, porcelain, and stoneware— Use these if they are labeled "Microwave Safe". If they are not
labeled, test them to make sure they can be used safely.
Plastic — Use only if labeled "Microwave Safe". Other plastics can melt.
8
Not Recommended
Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can shatter and cause
damage and injury.
Paper bags — These are a fire hazard, except for popcorn bags that are designed for microwave use.
Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.
Plastic storage and food containers — Containers such as margarine tubs can melt in the microwave.
Metal utensils — These can damage your oven. Remove all metal before cooking.
Note: Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.
Your microwave makes cooking easier than conventional cooking, provided you keep these
considerations in mind:
STIRRING
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside
of the dish absorbs more energy and heats more quickly, so stir from the outside to the center. The oven
will turn off when you open the door to stir your food.
ARRANGEMENT
Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts toward
the outside of the turntable where they receive more microwave energy. To prevent overcooking, place
delicate areas, such as asparagus tips, toward the center of the turntable.
SHIELDING
C
CO
OO
OK
KI
IN
NG
G
T
TE
EC
CH
HN
NI
IQ
QU
UE
ES
S
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 8 页
佛山市顺德区格兰仕
微波炉电器有限公司
Shield food with narrow strips of aluminum foil to prevent overcooking. Areas that need shielding include
poultry wing tips, the ends of poultry legs, and corners of square baking dishes. Use only small amounts
of aluminum foil. Larger amounts can damage your oven.
TURNING
Turn foods over midway through cooking to expose all parts to microwave energy. This is especially
important with large foods such as roasts.
STANDING
Foods cooked in the microwave build up internal heat and continue to cook for a few minutes after
heating stops. Let foods stand to complete cooking, especially foods such as cakes and whole
vegetables. Roasts need this time to complete cooking in the center without overcooking the outer areas.
All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is complete. Let
liquids stand a moment before serving. When heating baby food, stir well at removal and test the
temperature before serving.
ADDING MOISTURE
Microwave energy is attracted to water molecules. Food that is uneven in moisture content should be
covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry food
to help it cook.
Power Consumption: 120V~60Hz, 1450W (MICROWAVE)
Output: 1000W
Operation Frequency: 2450MHz
Outside Dimensions(H×W×D): 11 13/16×21 1/4×16 1/2in.
Oven Cavity Dimensions(H×W×D): 9 7/16×14 13/16×16 in.
Oven Capacity: 1.2cu.ft
Net Weight: Approx. 38.1lb.
S
SP
PE
EC
CI
IF
FI
IC
CA
AT
TI
IO
ON
NS
S
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 9 页
佛山市顺德区格兰仕
微波炉电器有限公司
P
PA
AR
RT
T
N
NA
AM
ME
ES
S
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Control Panel
6. Wave Guide (Please do not remove the mica plate covering the wave guide.)
7. Glass Tray
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 10 页
佛山市顺德区格兰仕
微波炉电器有限公司
Q MENU ACTION SCREEN
Cooking time, power, indicators and present time are
displayed.
Q POPCORN&BEVERAGE
Instant settings to cook popular foods.
Q WEIGHT DEFROST
Programmed defrosting based on the weight of the
foods to be defrosted.
Q POWER LEVEL
Use to set microwave power levels.
Q TIME DEFROST
Quick defrost function that alternates defrost and
stand times to quickly and effectively defrost foods.
Q ADD 30 SEC.
Touch to add the cooking time. Touch to set the
add30 seconds quick cook.
Q TIME COOK
Touch to set time cook function.
Q NUMBER PADS
Touch to set time or amount.
Q CLOCK
Use to set current time.
Q TIMER
Timer functions independently, even while a cooking
program is in process.
Q CANCEL/OFF
Touch to cancel cooking program.
Q START/PAUSE
Touch to start or pause cooking program.
C
CO
ON
NT
TR
RO
OL
L
P
PA
AN
NE
EL
L
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 11 页
佛山市顺德区格兰仕
微波炉电器有限公司
SIGNALS DURING OVEN SETTINGS
ONE SIGNAL: Oven accepts the entry.
TWO SIGNALS: Oven does not accept the entry, check and try again.
When plug in, “88:88”display, and “PF” display after 10 seconds, press any pad to cancel it, or press
CANCEL/OFF pad once, the display turn to blank.
During cooking program, press START/PAUSE or open the door to pause the program, then press
START/PAUSE to resume. Press CANCEL/OFF once to cancel the program. During the setting mode,
the system will return to waiting mode, if there have not any operate in 10 seconds.
End will display with beeps to remind the program is over, and it will sound every 60 seconds until you
press CANCEL/OFF pad or open the door.
SETTING THE CLOCK
1. Touch CLOCK pad.
2. Use the number pads to enter the correct time.
3. Touch CLOCK pad again.
NOTE: This is a 12-hour clock. During cooking, you can press CLOCK to check the clock time.
TIME COOK
1. Place food into oven, and close the door.
2. Press TIME COOK pad once.
3. Press number pads to enter the cooking time (The maximum is 99 minutes and 99 seconds).
4. Press START/PAUSE to confirm
Note: During cooking program, the default power is 100%, you can change it
POWER LEVEL SETTING
You can setting the power level after enter the cooking time or during the program by pressing the
POWER LEVEL and number pads. When the add 30 seconds, 1-6 quick start, time cook and time
defrost program is working or pausing, you can change the power level. But during grill, weight defrost
O
OP
PE
ER
RA
AT
TI
IO
ON
N
I
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
NS
S
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 12 页
佛山市顺德区格兰仕
微波炉电器有限公司
and popcorn, beverage program you cannot change the power level. You also can check the power level
by pressing POWER LEVEL.
Suppose to setting the power level during the cooking or after setting the cooking time in time cook or
time defrost program:
1. Press POWER LEVEL pad after setting the cooking time or during the cooking mode.
2. Press number pad to set the power level. The system will return to the mode before the power level
setting after 3 seconds,
Use single digits to set a cooking power level:
Number pad Cooking power
1,0 100%
9 90%
8 80%
7 70%
6 60%
5 50%
4 40%
3 30%
2 20%
1 10%
TIME DEFROST
1. Place food into oven, and close the door.
2. Touch TIME DEFROST.
3. Enter desired defrosting time by touching correct number pads (max. 99:99).
4. Touch START/PAUSE.
NOTE: The default power level is 30%, and it can be changed by user. During the defrost program, open
the door, “door” display, and “TIME”,”DEF” will flash after 2 seconds until the door is closed, then press
START/PAUSE to confirm.
TIME COOK 1&2
1. Place food into oven, and close the door.
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 13 页
佛山市顺德区格兰仕
微波炉电器有限公司
2. Enter the first cooking program.
3. Enter the second cooking program. The system enter the multi-stage program.”tc-2”display for a
second, then “:0”, “set” and “time” flash. Then enter the cooking time .
4. Press START/PAUSE to confirm.
WEIGHT DEFROST
1. Place food into oven and close the door.
2. Touch WEIGHT DEFROST pad.
3. Press the number pads to enter weight (max. 6.0lb.).
4. Touch START/PAUSE pad.
NOTE:
·Weight must be in pounds and ounces. Ounce weights less than 10 must be preceded by a 0. If label
gives weight in pounds only, change the fraction of a pound to ounces using the chart given above.
·During defrosting the system will sound to remind user to turn food over, press weight defrost once or
open the door directly to turn food over.
SETTING CHILD LOCK
The safety lock prevents unsupervised operation by children.
To set, in standby mode, press and hold CANCEL/OFF for 3 seconds. LOC is indicated on the display
for 2 seconds with beeps.
To cancel, in standby mode, press and hold CANCEL/OFF for 3 seconds. UNLO indication display for 2
seconds with beeps. The system will return to normal.
The QUICK COOK settings allow you to cook or reheat food automatically without entering power level
or time. The default power level is 100%. And you can change it by your desire.
Q
QU
UI
IC
CK
K
C
CO
OO
OK
K
S
SE
ET
TT
TI
IN
NG
GS
S
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 14 页
佛山市顺德区格兰仕
微波炉电器有限公司
ADD 30 SECONDS
Touch add 30 seconds pad.” 30”, “time”, “micro” display, the system will start immediately.
During the cooking program (except popcorn, beverage and weight defrost), Add cooking time 30
seconds press add 30 seconds every time until 99 minutes and 99 seconds.
1-6 QUICK COOK
In waiting mode, touch the number pad (1-6) once. The number, “time” and “micro” display, the system
will start immediately.
Touch Display
1 1:00
2 2:00
3 3:00
4 4:00
5 5:00
6 6:00
POPCORN
Touch POPCORN once. “3.0”, “set”, “oz” display, the system will start immediately.
You can select the serving by touching POPCORN a number of times in 15 seconds. After the 15 second,
“set”, “oz” disappear, you cannot change the serving. During cooking program, “door” display for 2
seconds when the door is opened, close the door and press START/PAUSE to confirm.
BEVERAGE
Touch BEVERAGE once. “4.0”, “set”, “oz” display, the system will start immediately.
You can select the serving by touching BEVERAGE a number of times in 15 seconds. After the 15
second, “set”, “oz” disappear, you cannot change the serving. During cooking program, “door” display for
2 seconds when the door is opened, close the door and press START/PAUSE to confirm.
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 15 页
佛山市顺德区格兰仕
微波炉电器有限公司
FOOD TESTING
If the food be placed into oven before select the food menu, the 5 minutes will start when the door is
closed. You can enter the cooking program in the 5 minutes
When the program is over, pause or cancel, the 5 minutes will restart, user can setting other program. If
the user open the door to turn food or place food in, the 5 minutes will start when the door is closed.
When the 5 minutes is over, the user should open and close the door or press cancel/off once, then
enter the other cooking program.
CANCEL PAD
In any mode (except the timer setting),press cancel/off pad to cancel the setting, the system will return to
waiting mode.
CANCEL PAD
In any mode (except the timer setting),press cancel/off pad to cancel the setting, the system will return to
waiting mode.
KEY ADHESION PROTECTING
In any mode, if the membrane switch closed for 60 seconds, the system will stop and return to waiting
mode, and “fall” display with beeps, and it will sound every minute until the fault is cleared.
CHECK VERSION FUNCTION
In waiting mode, press”7”, “8” and ”START/PAUSE” together, the version of oven will display for 3
seconds, and the model number will display the next 3 seconds.
JS1M0609-18034-004
标记 处数 更改单号 签 字 日期
说明书
SED340XAH-PA0C0A
(P10034AL-XAA)
设 计 孙晴晴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A
1:1
工 艺 日 期 2011-9-19 共 16 页 第 16 页
佛山市顺德区格兰仕
微波炉电器有限公司
16
1. Turn off the oven and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray
and other harsh cleaners as they may stain, streak or dull the door surface.
3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the window on both sides with a damp cloth to remove any spills or spatters.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the
control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity conditions. In such case, it is
normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe
the bottom surface of the oven with mild detergent. The roller ring may be washed in mild sudsy
water or dishwasher. When removing the roller ring from cavity floor for cleaning, be sure to
replace in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in
a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
11. The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven
in a clean condition could lead to deterioration of the surface that could adversely affect the life of
the appliance and possibly result in a hazardous situation.
12. Please do not dispose this appliance into the domestic rubbish bin, it should be disposed to the
particular disposal center provided by the municipalities.
C
CL
LE
EA
AN
NI
IN
NG
G
A
AN
ND
D
C
CA
AR
RE
E
