Model: P90D23MXL-A7
Microwave Oven User's manual
Please read these instructions carefully before installing and operating the oven.
Record in the space below the SERIAL NO. found on the nameplate on your oven and retain
this information for future reference.
SERIAL NO.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 S A 1:1
工 艺 日 期 2012-04-26 共 15 页 第 2 页
广东格兰仕微波炉电器制造有限公司
1. Do not attempt to operate this oven with the door-open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the oven door
close properly and that there is no damage to the:
a. Door (bent),
b. Hinges and latches (broken or loosened),
c. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
CONTENT
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 2
IMPORTANT SAFETY INSTRUCTIONS ..............................................................................3
INSTALLATION GUIDE.........................................................................................................5
GROUNDING INSTRUCTIONS............................................................................................5
UTENSILS GUIDE ................................................................................................................6
COOKING TECHNIQUES.....................................................................................................7
SPECIFICATIONS ................................................................................................................8
PART NAMES.......................................................................................................................9
CONTROL PANEL ..............................................................................................................10
HOW TO SET THE OVEN CONTROLS ............................................................................. 11
Setting Digital Clock.................................................................................................... 11
Quick Start................................................................................................................... 11
Microwave Cooking..................................................................................................... 11
Multi Stage Cooking ....................................................................................................12
Time Defrost................................................................................................................13
Weight Defrost ............................................................................................................13
Auto Cook ...................................................................................................................13
Child Lock ...................................................................................................................14
CLEANING AND CARE ......................................................................................................15
P
PR
RE
EC
CA
AU
UT
TI
IO
ON
NS
S
T
TO
O
A
AV
VO
OI
ID
D
P
PO
OS
SS
SI
IB
BL
LE
E
E
EX
XP
PO
OS
SU
UR
RE
E
T
TO
O
E
EX
XC
CE
ES
SS
SI
IV
VE
E
M
MI
IC
CR
RO
OW
WA
AV
VE
E
E
EN
NE
ER
RG
GY
Y
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 3 页
广东格兰仕微波炉电器制造有限公司
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
1. Read all instructions before using the appliance.
5. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" on page 1.
6. This appliance must be grounded. Connect only to properly grounded outlet. See "grounding
instructions " on page 3.
7. Install or locate this appliance only in accordance with the provided installation instructions.
8. Some products such as whole eggs and sealed containers -for example, closed glass jars- are able
to explode and should not be heated in this oven.
9. Use this appliance only for its intended use as described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
10. As with any appliance, close supervision is necessary when used by children.
11. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible
materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c. If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the
power cord or shut off power at the fuse or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food
in the cavity when not in use.
12. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the
container is removed from the microwave oven is not always present. THEIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID. To reduce the risk of injury to person:
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway through heating it.
c. Do not use straight-sided containers with narrow necks.
d. After heating, allow the container to stand in the microwave oven for a short time before removing
the container.
e. Use extreme care when inserting a spoon or other utensil into the container.
13. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in microwave oven.
14. Pierce foods with heavy skins such as potatoes, whole squash, apples and chestnuts before
cooking.
I
IM
MP
PO
OR
RT
TA
AN
NT
T
S
SA
AF
FE
ET
TY
Y
I
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
NS
S
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 4 页
广东格兰仕微波炉电器制造有限公司
15. The contents of feeding bottles and baby jars should be stirred or shaken and the temperature
should be checked before serving in order to avoid burns.
16. Cooking utensils may become hot because of heat transferred from the heated food. Potholders
may be needed to handle the utensil.
17. Do not cover or block any openings on the appliance.
18. Do not store or use this appliance outdoors. Do not use this product near water, for example, near a
kitchen sink, in a wet basement, near a swimming pool, or similar locations.
19. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if it
has been damaged or dropped.
20. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord hang
over edge of table or counter.
21. Use only thermometers, which are specifically designed for use in microwave ovens.
22. Do not operate any heating or cooking appliance beneath this appliance.
23. Be certain the glass tray and roller rings are in place when you operate the oven.
24. This appliance should be serviced only by qualified service personnel, contact nearest authorized
service facility for examination, repair, or adjustment.
25. When cleaning surfaces of door and oven that comes together on closing the door, use only mild,
nonabrasive soaps, or detergents applied with a sponge or soft cloth.
SAVE THESE INSTRUCTIONS
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 5 页
广东格兰仕微波炉电器制造有限公司
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current.
WARNING Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely
understood, or if doubt exists as to whether the appliance is properly grounded, and either:
1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a
3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The
marked rating of the extension cord shall be equal to or greater than the electrical rating of the
appliance, or 2) Do not use an extension cord. If the power supply cord is too short, have a
qualified electrician or serviceman install an outlet near the appliance.
I
IN
NS
ST
TA
AL
LL
LA
AT
TI
IO
ON
N
G
GU
UI
ID
DE
E
G
GR
RO
OU
UN
ND
DI
IN
NG
G
I
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
NS
S
1. Make sure that all the packing materials
are removed from the inside of the door.
2. Check the oven for any damage, such
as misaligned or bent door, damaged
door seals and sealing surface, broken
or loose door hinges and latches and
dents inside the cavity or on the door. If
there is any damage, do not operate the
oven but contact qualified service
personnel.
3. This microwave oven must be placed on
a flat, stable surface to hold its weight
and the heaviest food likely to be
cooked in the oven.
4. Do not place the oven where heat,
moisture, or high humidity are
generated, or near combustible
materials.
5. For correct operation, the oven must
have sufficient airflow. Allow 20cm of
space above the oven, 10cm at back
and 5cm at both sides. Do not cover or
block any openings on the appliance.
Do not remove feet on which oven
stands.
6. Do not operate the oven without glass
tray, roller support, and shaft in their
proper positions.
7. Make sure that the power supply cord is
undamaged and does not run under the
oven or over any hot or sharp surface.
8. The socket must be readily accessible
so that it can be easily unplugged in an
emergency.
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 6 页
广东格兰仕微波炉电器制造有限公司
ELECTRICAL REQUIREMENTS
The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. It is recommended that a separate
circuit serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must
be plugged into a wall receptacle that is properly installed and grounded.
Power Supply Cord
1. A short power supply cord is provided to reduce the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.
3. If long cord or extension cord is used：
a) The marked electrical rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and The longer cord should be arranged
so that it will not drape over the counter top or table top where it can be pulled on by children or tripped
over unintentionally.
Notes:
If you have any questions about the grounding or electrical instructions, consult a qualified electrician or
service person.
Neither Galanz nor the dealer can accept any liability for damage to the oven or personal injury resulting
from failure to observe the electrical connection procedures.
This section lists which utensils can be used in the microwave, which ones have limited use for short
periods, and which ones should not be used in the microwave.
9 RECOMMENDED
Microwave browning dish — Use to brown the exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with your browning dish.
Microwaveable plastic wrap — Use to retain steam. Leave a small opening for some steam to escape
and avoid placing it directly on the food.
Paper towels and napkins — Use for short-term heating and covering; these absorb excess moisture
and prevent spattering. Do not use recycled paper towels, which may contain metal and could ignite.
Glass and glass-ceramic bowls and dishes — Use for heating or cooking.
Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled paper,
which may contain metal and could ignite.
U
UT
TE
EN
NS
SI
IL
LS
S
G
GU
UI
ID
DE
E
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 7 页
广东格兰仕微波炉电器制造有限公司
Wax paper — Use as a cover to prevent spattering.
Thermometers — Use only those labeled "Microwave Safe" and follow all directions. Check the food in
several places. Conventional thermometers may be used on microwave food once the food has been
removed from the oven.
Λ
LIMITED USE
Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil
can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm) between aluminum
foil and cavity.
Ceramic, porcelain, and stoneware— Use these if they are labeled "Microwave Safe". If they are not
labeled, test them to make sure they can be used safely.
Plastic — Use only if labeled "Microwave Safe". Other plastics can melt.
8
Not Recommended
Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can shatter and cause
damage and injury.
Paper bags — These are a fire hazard, except for popcorn bags that are designed for microwave use.
Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.
Plastic storage and food containers — Containers such as margarine tubs can melt in the microwave.
Metal utensils — These can damage your oven. Remove all metal before cooking.
Note:
Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.
Your microwave makes cooking easier than conventional cooking, provided you keep these
considerations in mind:
STIRRING
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside
of the dish absorbs more energy and heats more quickly, so stir from the outside to the center. The oven
will turn off when you open the door to stir your food.
ARRANGEMENT
C
CO
OO
OK
KI
IN
NG
G
T
TE
EC
CH
HN
NI
IQ
QU
UE
ES
S
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 8 页
广东格兰仕微波炉电器制造有限公司
Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts toward
the outside of the turntable where they receive more microwave energy. To prevent overcooking, place
delicate areas, such as asparagus tips, toward the center of the turntable.
SHIELDING
Shield food with narrow strips of aluminum foil to prevent overcooking. Areas that need shielding include
poultry wing tips, the ends of poultry legs, and corners of square baking dishes. Use only small amounts
of aluminum foil. Larger amounts can damage your oven.
TURNING
Turn foods over midway through cooking to expose all parts to microwave energy. This is especially
important with large foods such as roasts.
STANDING
Foods cooked in the microwave build up internal heat and continue to cook for a few minutes after
heating stops. Let foods stand to complete cooking, especially foods such as cakes and whole
vegetables. Roasts need this time to complete cooking in the center without overcooking the outer areas.
All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is complete. Let
liquids stand a moment before serving. When heating baby food, stir well at removal and test the
temperature before serving.
ADDING MOISTURE
Microwave energy is attracted to water molecules. Food that is uneven in moisture content should be
covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry food
to help it cook.
Power Consumption: 120V~60Hz, 1350W (Microwave)
Output: 900W
Operation Frequency: 2450MHz
Outside Dimensions(H×W×D): 12×19 5/6×15 5/9in.
Oven Cavity Dimensions(H×W×D): 8 11/16×13 3/8×12 5/8 in.
Oven Capacity: 0.81cu.ft
Cooking Uniformity: Turntable System
Net Weight: Approx. 32 lb.
S
SP
PE
EC
CI
IF
FI
IC
CA
AT
TI
IO
ON
NS
S
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 9 页
广东格兰仕微波炉电器制造有限公司
1. Door Safety Lock System
2. Oven Window
3. Control Panel
4. Glass Turntable
5. Turntable support
6. Shaft
P
PA
AR
RT
T
N
NA
AM
ME
ES
S
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 10 页
广东格兰仕微波炉电器制造有限公司
C
CO
ON
NT
TR
RO
OL
L
P
PA
AN
NE
EL
L
z TIME COOK
Use to set cooking time.
z TIME DEFROST
Press the button to program defrosting based on
the time entered.
z WEIGHT DEFROST
Programmed defrosting based on the weight of the
foods to be defrosted.
z DISPLAY
Cooking time, power, indicators and present time
are displayed.
z POWER
Press the button to set microwave power level.
z CLOCK
Use to set clock time.
z KITCHEN TIMER
Use to set the kitchen timer.
z QUICK COOK BUTTON
Instant settings to cook popular foods.
z NUMBER PADS(0-9)
Touch to set time or amount.
z STOP/CANCEL
Press to cancel setting or reset the oven before
setting a cooking program.
Press once to temporarily stop cooking, or twice to
cancel cooking altogether.
It is also used for setting child lock.
z MEMORY
Use this button to set a multistage cooking
program.
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 11 页
广东格兰仕微波炉电器制造有限公司
SETTING DIGITAL CLOCK
With the oven ready for input, press the CLOCK button to set the digital clock in 12 or 24 hours cycle.
1. Choose to set the clock in 12 or 24-hour cycle by touching the CLOCK.
2. Use the number pads to enter time.
3. Press CLOCK to confirm.
QUICK START
Use this feature to program the oven to start at 100% power conveniently. The max time can be set is
10minutes. During cooking, you can also press this pad to add cooking time.
1. Open the door and place the food into the oven, close it.
2. Press Start/Quick Start button in quick succession to set the cooking time. The oven will auto-start
immediately.
MICROWAVE COOKING
The longest cooking time is 99 minutes 99 seconds.
You can select cooking power by touching POWER LEVEL:
Press The Button Cooking Power
Once 100%
Twice 80%
3 times 60%
4 times 40%
5 times 20%
6 times 0%
For example, suppose you want to cook for 1 minute at 60% of microwave power.
1. Place food in the oven.
2. Press TIME COOK button.
3. Use the number pads to enter time.
4. Press POWER button to select cooking power.
5. Close the oven door.
H
HO
OW
W
T
TO
O
S
SE
ET
T
T
TH
HE
E
O
OV
VE
EN
N
C
CO
ON
NT
TR
RO
OL
LS
S
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 12 页
广东格兰仕微波炉电器制造有限公司
6. Press START/QUICK START.
+30SEC
If the you feeling in the microwave cooking cooking time too short, you can press +30 SEC butoon
to adding time, according to a increase every 30 seconds
EXPRESS COOK
Cook for a small amount of food fast cooking.
1. Place food in the oven.
2. Press number pads to once.
3. Close the oven door.
4. Press START/QUICK START.
KITCHEN TIMER
The kitchen timer is used to set a countdown time for the convenience of the user to use it as a reminder
of the thing that he want to do.
For example: if the user want to set the timer of 20 minutes.
1. Place food in the oven.
2. Press KITCHEN TIMER once.
3. Use the number pads to set the needed time.
4. Close the oven door.
5. Press START/QUICK START.
MULTI STAGE COOKING
Your oven can be programmed for up to 3 automatic cooking sequences. Some recipes may require
setting a multi-stage program involving defrosting.
Suppose you want to set the following cooking program.
1S: Time defrost
2S: Microwave cooking
3S: Microwave cooking
1. Place food in the oven.
2. Input a speed defrosting program without starting.
3. Press MEMORY button once.
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 13 页
广东格兰仕微波炉电器制造有限公司
4. Input a microwave cooking program without starting.
5. Press MEMORY button
6. Input another microwave cooking program.
7. Close the oven door.
8. Press START/QUICK START button.
TIME DEFROST
You can input a speed defrost program based on time.The longest defrosting time is 95 minutes 99
seconds.
For example, suppose you want to defrost food for 20 minutes.
1. Place the food to be defrosted into the oven.
2. Press TIME SPEED once.
3. Press number pads to enter defrosting time.
4. Close the oven door.
5. Press START/QUICK START.
WEIGHT DEFROST
The oven could be used to defrost food on the weight you entered. The defrosting time and power level
are automatically set once the weight is programmed. The maximum weight of food is 1 OZ~99 OZ.
Steps:
1. Place the food to be defrosted into the oven.
2. Press WEIGHT DEFROST once.
3. Press WEIGHT DEFROST to select a weight matches up to your food.
4. Close the oven door.
5. Touch START/QUICK START.
AUTO COOK
For food or the following cooking mode, it is not necessary to program the duration and the cooking
power. It is sufficient to indicate the type of food that you wish to cook as well as the weight of this food.
You may need to turn food over at the middle of cooking time to obtain uniform cooking.
For example: to cook 8OZ.of pizza.
1. Press the PIZZ button to once.
2. Press WEIGHT DEFROST to select food weight matches up to your food.
3. Close the oven door.
4. Touch START/QUICK START.
Auto Cook Menu
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 14 页
广东格兰仕微波炉电器制造有限公司
CODE Menu Note
1 POPCORN(oz.)
2 POTATO (lb.)
3 PIZZA (oz.)
4 FROZEN
VEGETABLE (oz.)
5 BEVERAGE (lb.)
6 DINNER PLATE (oz.)
1. The detailed weight that oven can cook, please refer to the digits
on display screen of oven.
2. The result of auto cook depends on factors such as the shape and
size of food, your personal preference as to the doneness of
certain foods and even how well you happen to place food in the
oven. If you find the result at any rate not quite satisfactory, please
adjust the cooking time a little bit accordingly.
CHILD LOCK
Use to prevent unsupervised operation of the oven by little children. The CHILD LOCK indicator will
show up on display screen, and the oven can not be operated while the CHILD LOCK is set.
To set the CHILD LOCK: Press and hold the STOP/CANCEL button for 3 seconds, a beep sounds and
LOCK indicator lights.
To cancel the CHILD LOCK: Press and hold the STOP/CANCEL button for 3 seconds until lock indicator
on display goes off.
JS1M0609-19214-004
标记 处数 更改单号 签 字 日期
说明书
SSD239A7U-PA0C0A
(P90D23MXL-A7)
设 计 陈琴 标准化 谭银珠 图 样 标 记 数量 重量 比例
校 对 审 定 李志刚
审 核 王少云 SA
1:1
工 艺 日 期 2012-04-26 共 15 页 第 15 页
广东格兰仕微波炉电器制造有限公司
1. Turn off the oven and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray
and other harsh cleaners as they may stain, streak or dull the door surface.
3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp
cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the
control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the
bottom surface of the oven with mild detergent. The roller ring may be washed in mild sudsy water
or dishwasher. When removing the roller ring from cavity floor for cleaning, be sure to replace in the
proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in
a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
11. The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven
in a clean condition could lead to deterioration of the surface that could adversely affect the life of
the appliance and possibly result in a hazardous situation.
12. Please do not dispose this appliance into the domestic rubbish bin, it should be disposed to the
particular disposal center provided by the municipalities.
C
CL
LE
EA
AN
NI
IN
NG
G
A
AN
ND
D
C
CA
AR
RE
E
