eTrex®
owner’s manual
for use with models 10, 20, 30
© 2011 Garmin Ltd. or its subsidiaries
All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without
the written consent of Garmin. Garmin reserves the right to change or improve its products and to make
changes in the content of this manual without obligation to notify any person or organization of such
changes or improvements. Go to www.garmin.com for current updates and supplemental information
concerning the use of this product.
Garmin
®
, the Garmin logo, eTrex
®
, BlueChart
®
, and City Navigator
®
are trademarks of Garmin Ltd.
or its subsidiaries, registered in the USA and other countries. ANT
™
, ANT+
™
, BaseCamp
™
, chirp
™
,
HomePort
™
, and Thumb Stick
™
are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may
not be used without the express permission of Garmin.
Windows
®
is a registered trademark of Microsoft Corporation in the United States and/or other countries.
Mac
®
is a registered trademarks of Apple Computer, Inc. microSD
™
is a trademark of SD-3C, LLC. Other
trademarks and trade names are those of their respective owners.
eTrex Owner’s Manual 3
Table of Contents
Table of Contents
Getting Started ........................5
Device Overview............................5
Using the eTrex Keys ....................6
Battery Information ........................7
Turning the Device On or Off .........8
Satellite Signals .............................8
Registering Your Device ................8
Waypoints, Routes, and
Tracks ......................................9
Waypoints ......................................9
Using Sight ‘N Go ........................10
Where To? Menu ......................... 11
Routes .........................................12
Tracks ..........................................14
Navigation .............................16
Navigating to a Destination..........16
Map..............................................16
Compass .....................................17
Elevation Plot...............................19
Trip Computer ..............................20
Geocaches ............................21
Downloading Geocaches.............21
Filtering the Geocache List ..........21
Navigating to a Geocache ...........22
Logging the Attempt.....................22
chirp™ ..........................................23
Applications ..........................24
Sharing Data................................24
Setting a Proximity Alarm ............24
Calculating the Size of an Area ...25
Using the Calculator ....................25
Viewing the Calendar and
Almanacs ..................................25
Setting an Alarm ..........................26
Opening the Stopwatch ...............26
Satellite Page ..............................26
Customizing Your Device ....28
Customizing the Main Menu ........28
Customizing Specic Pages ........28
Proles.........................................29
System Settings...........................30
Display Settings ...........................30
4 eTrex Owner’s Manual
Table of Contents
Setting the Device Tones .............31
Map Settings................................31
Tracks Settings ............................32
Changing the Units of Measure ...33
Time Settings ...............................33
Position Format Settings .............33
Heading Settings .........................34
Altimeter Settings ........................34
Geocaching Settings ...................35
Routing Settings ..........................36
Marine Map Settings....................37
Fitness .........................................38
Resetting Data .............................38
Changing the Page Sequence.....39
Device Information ...............40
Adjusting the Screen ...................40
Updating the Software .................40
Viewing Device Information .........40
Specications ..............................41
About the Batteries ......................41
Caring for the Device ...................42
Data Management .......................43
Appendix ...............................46
Optional Accessories ...................46
Data Field Options .......................47
Troubleshooting ...........................52
Index ......................................54
eTrex Owner’s Manual 5
Getting Started
Getting Started
‹
WARNING
See the Important Safety and Product
Information guide in the product
box for product warnings and other
important information.
When using your device the rst time,
you should complete these tasks to set
up the device and get to know the basic
features.
1. Install the batteries (page 7).
2. Turn on the device (page 8).
3. Acquire satellites (page 8).
4. Register the device (page 8).
5. Mark a waypoint (page 9).
6. Create a route (page 12).
7. Record a track (page 14).
8. Navigate to a destination (page 16).
9. Calibrate the compass (page 17).
Device Overview
➊
➎
➍➌
➋
➊
Zoom keys
➋
Back key
➌
Thumb Stick™
➍
Menu key
➎
/Backlight key
6 eTrex Owner’s Manual
Getting Started
➏
➒
➑
➐
➏
Mini-USB port (under weather cap)
➐
Battery cover
➑
Battery cover locking ring
➒
Mounting spine
Using the eTrex Keys
• Move the Thumb Stick up, down,
left, and right to highlight menu
selections or to move around the
map.
• Press the center of the Thumb Stick
to select the highlighted item.
• Press back to move back one step
in the menu structure.
• Press menu to display a list of
commonly-used functions for the
current page. Press menu twice
to access the main menu from any
page.
• Press ▲ and ▼ to zoom in and out
on the map.
eTrex Owner’s Manual 7
Getting Started
Battery Information
‹
WARNING
The temperature rating for the device
(-4°F to 158°F, or -20 to 70°C) may
exceed the usable range of some
batteries. Alkaline batteries can rupture
at high temperatures.
notice
Alkaline batteries lose a signicant
amount of their capacity as temperature
decreases. Therefore, use lithium
batteries when operating the device in
below-freezing conditions.
Installing AA Batteries
The device operates on two AA
batteries. You can use alkaline, NiMH,
or lithium batteries. Use NiMH or
lithium batteries for best results.
1. Turn the D-ring counter-clockwise,
and pull up to remove the cover.
2. Insert the batteries, observing
polarity.
3. Replace the battery cover, and turn
the D-ring clockwise.
4. Hold .
5. Select Setup > System > Battery
Type.
6. Select Alkaline, Lithium, or
Rechargeable NiMH.
8 eTrex Owner’s Manual
Getting Started
Turning the Device On or
Off
Hold .
Satellite Signals
After the device is turned on, it begins
acquiring satellite signals. The device
may need a clear view of the sky to
acquire satellite signals. When the
GPS bars on the backlight page
(page 40) are solid green, your device
has acquired satellite signals. The time
and date are set automatically based on
the GPS position.
For more information about GPS, go to
http://www.garmin.com/aboutGPS.
Registering Your Device
• Go to http://my.garmin.com.
• Keep the original sales receipt, or a
photocopy, in a safe place.
eTrex Owner’s Manual 9
Waypoints, Routes, and Tracks
Waypoints, Routes,
and Tracks
Waypoints
Waypoints are locations you record and
store in the device.
Creating a Waypoint
You can save your current location as
a waypoint.
1. Select Mark Waypoint.
2. Select an option:
• To save the waypoint without
changes, select Done.
• To make changes to the
waypoint, select an item to edit,
and select Done.
Finding a Waypoint
1. Select Where To? > Waypoints.
2. Select a waypoint.
Editing a Waypoint
Before you can edit a waypoint, you
must create a waypoint.
1. Select Waypoint Manager.
2. Select a waypoint.
3. Select an item to edit.
4. Enter the new information.
5. Select Done.
Deleting a Waypoint
1. Select Waypoint Manager.
2. Select a waypoint.
3. Select menu > Delete > Yes.
10 eTrex Owner’s Manual
Waypoints, Routes, and Tracks
Increasing the Accuracy of a
Waypoint Location
Waypoint averaging allows you to
increase the accuracy of a waypoint
location by collecting multiple samples
of the waypoint location.
1. Select Waypoint Averaging.
2. Select a waypoint.
3. Move to the location.
4. Select Start.
5. When the Sample Condence status
bar reaches 100%, select Save.
For best results, collect four to
eight samples for the waypoint,
waiting at least 90 minutes between
samples.
Using Sight ‘N Go
Sight ‘N Go is available on the
eTrex 30.
You can point the device at an object in
the distance, lock in the direction, and
then navigate to the object.
1. Select Sight ‘N Go.
2. Point the device at an object or in
the direction of a location.
3. Select Lock Direction > Project
Waypoint.
4. Select a unit of measure.
5. Enter the distance to the object, and
select Done > Save.
eTrex Owner’s Manual 11
Waypoints, Routes, and Tracks
Where To? Menu
You can use the Where To? menu to
nd a destination to navigate to. Not all
Where To? categories are available in
all areas and maps.
Additional Maps
You can use additional maps on
the eTrex 20 and eTrex 30, such
as BirdsEye™ satellite imagery,
BlueChart® g2, TOPO, and City
Navigator® detailed maps. Detailed
maps may contain additional points of
interest, such as restaurants or marine
services. For more information, go to
http://buy.garmin.com or contact your
Garmin dealer.
Finding a Location by Name
Depending on the maps loaded on
your device, you can search for cities,
geographic points, and various points
of interest (POIs), such as restaurants,
hotels, and auto services.
1. Select Where To?.
2. Select a category.
3. Select menu > Spell Search.
4. Enter all or part of the name, and
select Done.
Finding a Location Near
Another Location
1. Select Where To? > menu >
Search Near.
2. Select an option.
3. If necessary, select a location.
12 eTrex Owner’s Manual
Waypoints, Routes, and Tracks
Finding an Address
You can use optional City Navigator
maps to search for addresses.
1. Select Where To? > Addresses.
2. If necessary, enter the country or
state.
3. Enter the city or postal code.
NOTE: Not all map data provides
postal code searching.
4. Select the city.
5. Enter the house number.
6. Enter the street.
Routes
A route is a sequence of waypoints that
leads you to your nal destination.
Creating a Route
1. Select Route Planner > Create
Route > Select First Point.
2. Select a category.
3. Select the rst point in the route.
4. Select Use > Select Next Point.
5. Repeat steps 2–4 until the route is
complete.
6. Select back to save the route.
Editing the Name of a Route
1. Select Route Planner.
2. Select a route.
3. Select Change Name.
4. Enter the new name.
5. Select Done.
eTrex Owner’s Manual 13
Waypoints, Routes, and Tracks
Editing a Route
1. Select Route Planner.
2. Select a route.
3. Select Edit Route.
4. Select a point.
5. Select an option:
• To view the point on the map,
select Review.
• To change the order of the point
on the route, select Move Down
or Move Up.
• To add an additional point on
the route, select Insert.
The additional point is inserted
before the point you are editing.
• To remove the point from the
route, select Remove.
6. Select back to save the route.
Viewing a Route on the Map
1. Select Route Planner.
2. Select a route.
3. Select View Map.
Deleting a Route
1. Select Route Planner.
2. Select a route.
3. Select Delete Route.
Viewing the Active Route
1. While navigating a route, select
Active Route.
2. Select a point in the route to view
additional details.
Reversing a Route
1. Select Route Planner.
2. Select a route.
3. Select Reverse Route.
14 eTrex Owner’s Manual
Waypoints, Routes, and Tracks
Tracks
A track is a recording of your path.
The track log contains information
about points along the recorded path,
including time, location, and elevation
for each point.
Recording Track Logs
1. Select Setup > Tracks > Track
Log.
2. Select Record, Do Not Show or
Record, Show On Map.
If you select Record, Show On
Map, a line on the map indicates
your track.
3. Select Record Method.
4. Select an option:
• To record tracks at a variable
rate that creates an optimum
representation of your tracks,
select Auto.
• To record tracks at a specied
distance, select Distance.
• To record tracks at a specied
time, select Time.
5. Select Record Interval.
6. Complete an action:
• Select an option to record tracks
more or less often.
NOTE: Using the Most Often
interval provides the most track
detail, but lls up the device
memory quicker.
• Enter a time or distance, and
select Done.
As you move with the device turned
on, a track log is created.
eTrex Owner’s Manual 15
Waypoints, Routes, and Tracks
Saving the Current Track
The track being recorded is called the
current track.
1. Select Track Manager > Current
Track.
2. Select what you want to save:
• Select Save Track.
• Select Save Portion, and select
a portion.
Viewing Track Information
1. Select Track Manager.
2. Select a track.
3. Select View Map.
The beginning and the end of the
track are marked by ags.
4. Select menu > Review Track.
Information about the track is
listed.
Viewing the Elevation Plot of a
Track
1. Select Track Manager.
2. Select a track.
3. Select Elevation Plot.
Archiving a Saved Track
You can archive saved tracks to save
memory space.
1. Select Track Manager.
2. Select a saved track.
3. Select Archive.
Clearing the Current Track
Select Setup > Reset > Clear
Current Track > Yes.
Deleting a Track
1. Select Track Manager.
2. Select a track.
3. Select Delete > Yes.
16 eTrex Owner’s Manual
Navigation
Navigation
You can navigate a route, a track,
to a waypoint, to a geocache, or to
any saved location in the device.
You can use the map (page 16) or
compass (page 17) to navigate to your
destination.
Navigating to a
Destination
You can navigate to a destination using
the map or compass.
1. Select Where To?.
2. Select a category.
3. Select a destination.
4. Select Go.
The map page opens with your
route marked with a magenta line.
5. Navigate using the map (page 16)
or compass (page 17).
Stopping Navigation
Select Where To? > Stop
Navigation.
Map
represents your location on the map.
As you travel, moves. When you are
navigating to a destination, your route
is marked with a magenta line on the
map.
To customize the map settings, see
page 31. To customize the map
dashboard and data elds, see page 28.
Browsing the Map
1. Select Map.
2. Select one or more options:
• Use the Thumb Stick to pan the
map to view different areas.
• Select ▲ and ▼ to zoom in and
out of the map.
eTrex Owner’s Manual 17
Navigation
• Select a location on the map,
and the bar at the top of the
screen shows information about
the selected location.
Navigating a Driving Route
Driving route navigation is only
available on the eTrex 20 and eTrex 30.
Before you can use the map, you must
purchase and load City Navigator
maps. If you plan to use an auto mount
accessory with the device, you must
also purchase and install the mount in
your vehicle.
1. Select Prole Change >
Automotive.
2. Use the map to navigate to the
destination.
3. Follow the turns in the text bar
along the top of the map.
Compass
The eTrex 30 has a 3-axis, electronic
compass.
You can use a bearing pointer or a
course pointer to navigate to your
destination.
TIP: When the device is using the
automotive prole, the compass
displays GPS heading, not magnetic
heading.
Calibrating the Compass
notice
Calibrate the electronic compass
outdoors. To improve heading
accuracy, do not stand near objects that
inuence magnetic elds, such as cars,
buildings, or overhead power lines.
18 eTrex Owner’s Manual
Navigation
You should calibrate the compass after
moving long distances, experiencing
temperature changes, or changing the
batteries.
1. Select Compass > menu >
Calibrate Compass > Start.
2. Follow the on-screen instructions.
Navigating with the Bearing
Pointer
When navigating to a destination,
points to your destination, regardless of
the direction you are moving.
1. Begin navigation to a destination
(page 16).
2. Select Compass.
3. Turn until points toward the
top of the compass, and continue
moving in that direction to the
destination.
About the Course Pointer
The course pointer is most useful if you
are navigating on water or where there
are no major obstacles in your path.
➋
➊
➍
➌
The course pointer
➊
indicates your
relationship to a course line
➋
leading
to the destination. The course line
to your destination is based on your
original starting point.
As you drift from the intended course
to the destination, the course deviation
indicator
➌
(CDI) provides the
indication of drift (right or left) from
the course.
The scale
➍
refers to the distance
eTrex Owner’s Manual 19
Navigation
between dots on the course deviation
indicator.
Navigating with the Course Pointer
Before you can navigate with the
course pointer, you must change the
pointer setting to Course (CDI)
(page 34).
1. Begin navigation to a destination
(page 16).
2. Select Compass.
3. Use the course pointer to navigate
to the destination (page 18).
Elevation Plot
Elevation plotting is available on the
eTrex 30.
By default, the elevation plot displays
the elevation for an elapsed time. To
customize the elevation plot, see
page 34.
Select Elevation Plot.
Changing the Plot Type
You can change the elevation plot to
display pressure and elevation over
time or distance.
1. Select Elevation Plot > menu >
Change Plot Type.
2. Select an option.
Viewing Details about a Point
on the Plot
Select an individual point on the
plot.
Details about the point appear at the
top of the plot.
Resetting the Elevation Plot
Select Elevation Plot > menu >
Reset > Clear Current Track >
Yes.
20 eTrex Owner’s Manual
Navigation
Calibrating the Barometric
Altimeter
You can manually calibrate the
barometric altimeter if you know
the correct elevation or the correct
barometric pressure.
1. Go to a location where the elevation
or barometric pressure is known.
2. Select Elevation Plot > menu >
Calibrate Altimeter.
3. Follow the on-screen instructions.
Trip Computer
The trip computer displays your current
speed, average speed, maximum
speed, trip odometer, and other helpful
statistics.
To customize the trip computer, see
page 28.
Resetting the Trip Data
For accurate information, reset the trip
information before beginning a trip.
Select Trip Computer > menu >
Reset > Reset Trip Data > Yes.
All of the trip computer values are
set to zero.
eTrex Owner’s Manual 21
Geocaches
Geocaches
A geocache is like a hidden treasure.
Geocaching is when you hunt for
hidden treasures using GPS coordinates
posted online by those hiding the
geocache.
Downloading Geocaches
1. Connect your device to a computer
(page 44).
2. Go to www.OpenCaching.com.
3. If necessary, create an account.
4. Sign in.
5. Follow the on-screen instructions
to nd and download geocaches to
your device.
Filtering the Geocache
List
You can lter your geocache list based
on certain factors, such as the level of
difculty.
1. Select Geocaches > menu > Apply
Filter > Quick Filter.
2. Select items to lter.
3. Select an option:
• To apply the lter to the
geocache list, select Search.
• To save the lter, select back.
Creating and Saving a
Geocache Filter
You can create and save custom lters
for geocaches based on specic factors
you select. After you set up the lter,
you can apply it in the geocaches list.
1. Select Setup > Geocaches > Filter
Setup > Create Filter.
22 eTrex Owner’s Manual
Geocaches
2. Select items to lter.
3. Select an option:
• To apply the lter to the
geocache list, select Search.
• To save the lter, select back.
After it is saved, the lter is
automatically named. You can
access the custom lter from the
geocaches list.
Editing a Custom Geocache
Filter
1. Select Setup > Geocaches > Filter
Setup.
2. Select a lter.
3. Select an item to edit.
Navigating to a Geocache
1. Select Geocaches.
2. Select a geocache.
3. Select Go.
4. Navigate using the map (page 16)
or compass (page 17).
Logging the Attempt
After you have attempted to nd a
geocache, you can log your results.
1. Select Geocaches > menu > Log
Attempt.
2. Select Found, Did Not Find, or
Needs Repair.
3. Select an option:
• To begin navigation to a
geocache nearest you, select
Find Next Closest.
• To end the logging, select Done.
eTrex Owner’s Manual 23
Geocaches
• To enter a comment about
looking for the cache or
the cache itself, select Add
Comment, enter a comment,
and select Done.
chirp™
chirp programming and searching is
available on the eTrex 30.
A chirp is a small Garmin accessory
that you can program and leave in a
geocache. Only the owner of the chirp
can program a chirp, but anyone can
nd a chirp in a geocache. For more
information about programming a
chirp, see the chirp Owner’s Manual at
http://www.garmin.com.
Enable chirp Searching
1. Select Setup > Geocaches.
2. Select chirp™ Searching > On.
Finding a Geocache with a
chirp
1. Select Geocaches > menu > Show
chirp™ Details.
2. Begin navigating to a geocache
(page 22).
When you are within 33 feet (10 m)
of the geocache that contains
a chirp, details about the chirp
appear.
3. If available, select Go to navigate
to the next stage of the geocache.
24 eTrex Owner’s Manual
Applications
Applications
Sharing Data
The eTrex 30 can share information
wirelessly.
Your device can send or receive data
when connected to another compatible
device. You can share waypoints,
geocaches, routes, and tracks.
Sending and Receiving Data
Wirelessly
Before you can share data wirelessly,
you must be within 10 feet (3 m) of a
compatible Garmin device.
1. Select Share Wirelessly.
2. Select Send or Receive.
3. Follow the on-screen instructions.
Setting a Proximity Alarm
Proximity alarms alert you when
you are within a specied range of a
particular location.
1. Select Proximity Alarms.
2. Select Create Alarm.
3. Select a category.
4. Select a location.
5. Select Use.
6. Enter a radius.
7. Select Done.
When you enter a proximity alarm
area, the device sounds a tone
(eTrex 20/30).
eTrex Owner’s Manual 25
Applications
Calculating the Size of an
Area
1. Select Area Calculation > Start.
2. Walk around the perimeter of the
area you want to calculate.
3. Select Calculate when nished.
Using the Calculator
The device has a standard calculator
and a degree calculator.
1. Select Calculator.
2. Complete an action:
• Use the standard calculator.
• Select menu > Scientic to
use the scientic calculator
functions.
• Select menu > Degrees to
calculate degrees.
Viewing the Calendar and
Almanacs
You can view device activity, such as
when a waypoint was saved, almanac
information for the sun and moon, and
the best times for hunting and shing.
1. Select an option:
• To view device activity for
specic days, select Calendar.
• To view the sunrise, sunset,
moonrise, and moonset
information, select Sun and
Moon.
• To view the predicted best times
for hunting and shing, select,
Hunt and Fish.
2. If necessary, select ▲ or ▼ to view
a different month.
3. Select a day.
26 eTrex Owner’s Manual
Applications
Setting an Alarm
If you are not currently using the
device, you can set the device to turn
on at a specic time.
1. Select Alarm Clock.
2. Select the clock numbers to set the
time, and select Done.
3. Select Turn Alarm On.
4. Select an option.
The alarm sounds at the selected time.
If the device is off at the alarm time,
the device turns on and sounds the
alarm.
Opening the Stopwatch
Select Stopwatch.
Satellite Page
The satellite page shows your current
location, GPS accuracy, satellite
locations, and signal strength.
Changing the Satellite View
1. Select Satellite > menu.
2. If necessary, select Track Up to
change the view of the satellites to
be oriented with your current track
toward the top of the screen.
3. If necessary, select Multicolor
to assign a specic color to the
satellite in the view and to the
signal strength bar of that satellite
(eTrex 20/30).
Turning Off GPS
Select Satellite > menu > Use
With GPS Off.
28 eTrex Owner’s Manual
Customizing Your Device
Customizing Your
Device
Customizing the Main
Menu
Select menu > Change Item
Order to change the item order on
the main menu.
Customizing Specic
Pages
Data elds display information about
your location or other specied data.
Dashboards are a custom grouping of
data that can be helpful to a specic or
general task, such as geocaching.
You can customize the data elds and
dashboards of the map, compass, and
trip computer.
Enabling the Map Data Fields
1. Select Map > menu > Setup Map
> Data Fields.
2. Select a number and style of data
elds.
Changing the Data Fields
Before you can change the map data
elds, you must enable them (page 28).
1. Select Map > menu > Change
Data Fields.
2. Select a data eld to customize.
3. Select a data eld type.
For data eld descriptions, see
page 47.
4. Select back to save the changes.
eTrex Owner’s Manual 29
Customizing Your Device
Customizing Dashboards
1. Open the page for which you want
to customize the dashboard.
2. Select an option:
• From the map, select menu >
Setup Map > Data Fields >
Dashboard.
• From the compass or trip
computer, select menu >
Change Dashboard.
3. Select a dashboard.
Proles
Proles are collections of settings that
optimize your device based on how
you are using it. For example, your
settings and views can be different
when you are using the device for
geocaching and for navigating on
water.
When you are using a prole and you
change settings such as data elds or
units of measurement, the changes
are saved automatically as part of the
prole.
Selecting a Prole
1. Select Prole Change.
2. Select a prole.
Creating a Custom Prole
You can customize your settings and
data elds for a particular activity or
trip.
1. Customize the settings as necessary
(page 28).
2. Customize the data elds as
necessary (page 28).
3. Select Setup > Proles.
4. Select Create Prole > OK.
30 eTrex Owner’s Manual
Customizing Your Device
Editing a Prole Name
1. Select Setup > Proles.
2. Select a prole.
3. Select Edit Name.
4. Enter the new name.
5. Select Done.
Deleting a Prole
1. Select Setup > Proles.
2. Select a prole.
3. Select Delete > Yes.
System Settings
Select Setup > System.
• GPS—sets the GPS to Normal,
WAAS/EGNOS (Wide Area
Augmentation System/European
Geostationary Navigation Overlay
Service), or Demo Mode (GPS
off). For information about WAAS,
go to http://www.garmin.com/
aboutGPS/waas.html.
• Language—sets the text language
on the device.
NOTE: Changing the text language
does not change the language of
user-entered data or map data, such
as street names.
• Battery Type—allows you to
select the type of AA battery you
are using.
Display Settings
Select Setup > Display.
• Backlight Timeout—adjusts the
length of time before the backlight
turns off.
NOTE: To adjust the backlight
brightness, see page 40.
• Colors (eTrex 20/30)—sets the
colors that display in Night and
Day mode.
◦ Mode—sets a light background
(Day), a dark background
eTrex Owner’s Manual 31
Customizing Your Device
(Night), or automatically
switches between the two based
on the sunrise time and the
sunset time for your current
location (Auto).
◦ Day Background Color—sets
the background image used in
day mode.
◦ Day Highlight Color—sets
the color for selections in day
mode.
◦ Night Background Color—
sets the background image used
in night mode.
◦ Night Highlight Color—sets
the color for selections in night
mode.
• Screen Capture—allows you to
take screen captures on the device.
Setting the Device Tones
You can customize tones for messages,
keys, turn warnings, and alarms.
1. Select Setup > Tones.
2. Select a tone for each audible type.
Map Settings
Select Setup > Map.
• Orientation—adjusts how the map
is shown on the page.
◦ North Up—shows north at the
top of the page.
◦ Track Up—shows your current
direction of travel toward the
top of the page.
◦ Automotive Mode—shows an
automotive perspective with the
direction of travel at the top.
• Guidance Text—allows you to
select when to show guidance text
on the map.
32 eTrex Owner’s Manual
Customizing Your Device
• Data Fields—selects the number
and size of the data elds to display
on the map.
• Advanced Map Setup—sets the
zoom levels, the text size, and the
detail level of the map.
◦ Auto Zoom—automatically
selects the appropriate zoom
level for optimal use on your
map. When Off is selected, you
must zoom in or out manually.
◦ Zoom Levels—selects the zoom
level for map items.
◦ Text Size—selects the text size
for map items.
◦ Detail—selects the amount
of detail shown on the map.
Showing more detail may cause
the map to redraw more slowly.
◦ Shaded Relief—shows detail
relief on the map (if available)
or turns off shading.
• Map Information—allows you to
enable or disable the maps currently
loaded on the device. To purchase
additional maps, see page 11.
Tracks Settings
Select Setup > Tracks.
• Track Log—turns track recording
on or off.
• Record Method—selects a track
recording method. Auto records the
tracks at a variable rate to create
an optimum representation of your
tracks.
• Recording Interval—selects a
track log recording rate. Recording
points more frequently creates a
more-detailed track, but lls the
track log faster.
eTrex Owner’s Manual 33
Customizing Your Device
• Auto Archive—selects an
automatic archive method to
organize your tracks. Tracks are
saved and cleared automatically
based on the user setting.
• Color (eTrex 20/30)—changes the
color of the track line on the map.
Changing the Units of
Measure
You can customize units of measure
for distance and speed, elevation, and
pressure.
1. Select Setup > Units.
2. Select a measurement type.
3. Select a unit of measure for the
setting.
Time Settings
Select Setup > Time.
• Time Format—allows you to
select a 12-hour or a 24-hour
display time.
• Time Zone—allows you to select
the time zone for the device. You
can select Automatic to set the
time zone automatically based on
your GPS position.
Position Format Settings
NOTE: Do not change the position
format or the map datum coordinate
system unless you are using a map or
chart that species a different position
format.
Select Setup > Position Format.
• Position Format—sets the position
format in which a given location
reading appears.
34 eTrex Owner’s Manual
Customizing Your Device
• Map Datum—sets the coordinate
system on which the map is
structured.
• Map Spheroid—shows the
coordinate system the device is
using. The default coordinate
system is WGS 84.
Heading Settings
This function is available on the
eTrex 30.
Select Setup > Heading.
• Display—sets the type of
directional heading on the compass.
• North Reference—sets the north
reference of the compass.
• Go To Line (Pointer)—allows you
to select how the course appears.
◦ Bearing (Small or Large)—
sets the direction to your
destination.
◦ Course (CDI)—the course
deviation indicator displays
your relationship to a course
line leading to a destination.
• Compass—switches from an
electronic compass to a GPS
compass when you are traveling
at a higher rate of speed for a set
period of time (Auto), or turns the
compass off.
• Calibrate Compass—page 17.
Altimeter Settings
This function is available on the
eTrex 30.
Select Setup > Altimeter.
• Auto Calibration—allows the
altimeter to self-calibrate each time
you turn the device on.
eTrex Owner’s Manual 35
Customizing Your Device
• Barometer Mode
◦ Variable Elevation—allows the
barometer to measure changes
in elevation while you are
moving.
◦ Fixed Elevation—assumes
the device is stationary at a
xed elevation. Therefore, the
barometric pressure should
change only due to weather.
• Pressure Trending
◦ Save When Power On—
records pressure data only when
the device is turned on. This
can be useful when you are
watching for pressure fronts.
◦ Save Always—records pressure
data every 15 minutes, even
when the device is turned off.
• Plot Type
◦ Elevation/Time—records
elevation changes over a period
of time.
◦ Elevation/Distance—records
elevation changes over a
distance.
◦ Barometric Pressure—records
barometric pressure over a
period of time.
◦ Ambient Pressure—records
ambient pressure changes over a
period of time.
• Calibrate Altimeter—page 20.
Geocaching Settings
Select Setup > Geocaches.
• Geocache List—allows you to
display the geocache list by names
or codes.
36 eTrex Owner’s Manual
Customizing Your Device
• Found Geocaches—allows you
to edit the number of geocaches
found. This number automatically
increases as you log a nd
(page 22).
• Filter Setup— page 21.
• chirp™ Searching—page 23.
• Program chirp™—programs the
chirp accessory. See the chirp
Owner’s Manual at
http://www.garmin.com.
Routing Settings
The device calculates routes optimized
for the type of activity you are doing.
The routing settings available vary
based on the activity selected.
Select Setup > Routing.
• Guidance Method—allows you
to select a guidance method for
calculating your route.
◦ Off Road—calculates point-to-
point routes.
◦ On Road For Time (requires
routable maps)—calculates on-
road routes that require minimal
time to drive.
◦ On Road For Distance
(requires routable maps)—
calculates on-road routes that
are shorter in distance.
• Calculate Routes for—allows you
to select a transportation method in
order to optimize your route.
eTrex Owner’s Manual 37
Customizing Your Device
• Lock On Road—locks the
position icon, which represents
your position on the map, onto the
nearest road.
• Off Road Transitions—available
only for some activities.
◦ Auto—automatically routes you
to the next point.
◦ Manual—allows you to select
the next point on the route.
◦ Distance—routes you to the
next point on the route when
you are within a specied
distance of your current point.
• Avoidance Setup—(available only
for some guidance methods) allows
you to select the road type you want
to avoid.
Marine Map Settings
This function is available on the
eTrex 20 and eTrex 30.
Select Setup > Marine.
• Marine Chart Mode—allows you
to select a nautical chart or a shing
chart:
◦ Nautical—displays various map
features in different colors so
that the marine POIs are more
readable. The nautical chart
reects the drawing scheme of
paper charts.
◦ Fishing—(requires marine
maps) displays a detailed view
of bottom contours and depth
soundings. Simplies map
presentation for optimal use
while shing.
• Appearance—allows you to set the
appearance of marine navigation
aids on the map.
38 eTrex Owner’s Manual
Customizing Your Device
• Marine Alarm Setup
◦ Anchor Drag Alarm—alarm
sounds when you exceed a
specied drift distance while
anchored.
◦ Off Course Alarm—alarm
sounds when you are off course
by a specied distance.
◦ Deep Water/Shallow Water—
alarm sounds when you enter
water of a specic depth.
Setting up Marine Alarms
1. Select Setup > Marine > Marine
Alarm Setup.
2. Select an alarm type.
3. Select On.
If necessary, enter a distance, then
select Done.
Fitness
For more information on optional
tness accessories, see page 46.
Resetting Data
You can reset trip data, delete all
waypoints, clear the current track, or
restore default values.
1. Select Setup > Reset.
2. Select an item to reset.
Restoring Specic Settings to
Defaults
1. Select Setup.
2. Select an item to reset.
3. Select menu > Restore Defaults.
eTrex Owner’s Manual 39
Customizing Your Device
Restoring Specic Page
Settings
You can restore the settings for the
map, compass, and trip computer.
1. Open the page for which you will
restore the settings.
2. Select menu > Restore Defaults.
Restoring All Default Settings
You can reset all the setup values to the
original settings.
Select Setup > Reset > Reset All
Settings > Yes.
Changing the Page
Sequence
Before you can change the order of the
page sequence, you must add pages to
the sequence (page 39).
1. Select Setup > Page Sequence.
2. Select a page.
3. Select Move.
4. Select the new page location.
Adding a Page
1. Select Setup > Page Sequence.
2. Select Add Page.
3. Select a page to add.
Removing a Page
1. Select Setup > Page Sequence.
2. Select a page.
3. Select Remove.
40 eTrex Owner’s Manual
Device Information
Device Information
Adjusting the Screen
NOTE: The backlight brightness may
be limited when the remaining capacity
in the batteries is low.
Extensive use of screen backlighting
can signicantly reduce battery life.
1. While the device is on, press .
2. Move the Thumb Stick left and
right to adjust the brightness level.
3. Move the Thumb Stick up and
down to adjust the contrast level
(eTrex 10 only).
Adjusting the Backlight
Timeout
You can decrease the backlight timeout
to maximize battery power.
Select Setup > Display >
Backlight Timeout.
Updating the Software
Before you can update the software,
you must connect the device to your
computer (page 44).
1. Go to http://www.garmin.com
/products/webupdater.
2. Follow the on-screen instructions.
NOTE: Updating the software does not
erase any of your data or settings.
Viewing Device
Information
You can view the unit ID, software
version, and license agreement.
Select Setup > About.
eTrex Owner’s Manual 41
Device Information
Specications
Water
resistance
Rugged plastic,
waterproof to IEC 60529
IPX7
Battery type 2 AA batteries,
(alkaline, NiMH, lithium,
or precharged NiMH)
Battery Life Up to 25 hours
Operating
temperature
range
From -4°F to 158°F
(-20°C to 70°C)
About the Batteries
‹
WARNING
The temperature rating for the device
(page 41) may exceed the usable range
of some batteries. Alkaline batteries
can rupture at high temperatures.
Do not use a sharp object to remove
batteries.
‹
CAUTION
Contact your local waste disposal
department to properly recycle the
batteries.
notice
Alkaline batteries lose a signicant
amount of their capacity as temperature
decreases. Therefore, use lithium
batteries when operating the device in
below-freezing conditions.
Maximizing Battery Life
You can do various things to increase
the battery life.
• Leave the backlight off when not
needed.
• Lower the backlight brightness
(page 40).
• Decrease the backlight timeout
(page 40).
42 eTrex Owner’s Manual
Device Information
Long-Term Storage
When you do not plan to use the
device for several months, remove the
batteries. Stored data is not lost when
batteries are removed.
Caring for the Device
notice
Avoid chemical cleaners and solvents
which can damage plastic components.
Cleaning the Device
1. Dampen a clean cloth with a mild
detergent solution.
2. Wipe the device with the damp
cloth.
3. Thoroughly dry the device.
Cleaning the Screen
1. Dampen a soft, clean, lint-free cloth
with water, isopropyl alcohol, or
eyeglass lens cleaner.
2. Wipe the screen with the cloth.
3. Thoroughly dry the screen.
Water Immersion
notice
The device is waterproof to IEC
Standard 60529 IPX7. It can withstand
immersion in 1 meter of water for
30 minutes. However, prolonged
submersion can cause damage to the
device. After submersion, be certain to
wipe dry and air dry the device before
using or charging.
Extreme Temperatures
notice
Do not store the device where
prolonged exposure to extreme
temperatures can occur because it can
cause permanent damage.
eTrex Owner’s Manual 43
Device Information
Data Management
NOTE: The device is not compatible
with Windows® 95, 98, Me, or NT. It is
also not compatible with Mac® OS 10.3
and earlier.
File Types
The device supports these le types.
• Files from BaseCamp™ or
HomePort™
Go to http://www.garmin.com.
• GPI custom POI les from the
Garmin POI Loader
• GPX geocache les
Installing a microSD Card
The eTrex 20 and eTrex 30 can use
microSD cards for additional storage.
Also, some maps are available
preloaded on memory cards. Go
to http://buy.garmin.com for more
information.
1. Turn the D-ring counter-clockwise,
and pull up to remove the cover.
2. Remove the batteries or battery.
3. Slide the card holder
➊
toward
the bottom of the device and lift
up, as instructed in the battery
compartment.
➊➋
44 eTrex Owner’s Manual
Device Information
4. Place the microSD card
➋
in the
device with the gold contacts facing
down.
5. Close the card holder.
6. Slide the card holder toward the top
of the device to lock it.
7. Replace the batteries (page 7).
8. Replace the battery cover, and turn
the D-ring clockwise.
Connecting the Device to a
Computer
notice
To prevent corrosion, thoroughly
dry the mini-USB port, the weather
cap, and the surrounding area before
charging or connecting to a computer.
1. Connect the USB cable to a USB
port on your computer.
2. Pull up the weather cap
➊
from the
mini-USB port
➋
.
➊
➋
3. Plug the small end of the USB
cable into the mini-USB port.
Your device and memory card
(optional) appear as removable
drives in My Computer on Windows
computers and as mounted volumes on
Mac computers.
Transferring Files to Your
Computer
Before you can transfer les, you must
connect the device to your computer
(page 44).
1. Browse your computer for the le.
2. Select the le.
3. Select Edit > Copy.
eTrex Owner’s Manual 45
Device Information
4. Open the “Garmin” or memory card
drive/volume.
5. Select Edit > Paste.
TIP: You must put geocache les in
the Garmin\GPX folder.
Deleting Files
notice
If you do not know the purpose of
a le, do not delete it. Your device
memory contains important system
les that should not be deleted. Be
especially cautious of folders entitled
“Garmin.”
Before you can delete les, you must
connect the device to your computer
(page 44).
1. Open the “Garmin” drive or
volume.
2. If necessary, open a folder or
volume.
3. Select the les.
4. Press the Delete key on your
keyboard.
Disconnecting the USB Cable
1. Complete an action:
• For Windows computers, click
the eject icon in your system
tray.
• For Mac computers, drag the
volume icon to the Trash .
2. Disconnect the device from your
computer.
46 eTrex Owner’s Manual
Appendix
Appendix
Optional Accessories
Optional accessories, such as mounts,
maps, tness accessories, and
replacement parts, are available at
http://buy.garmin.com or from your
Garmin dealer.
Optional Maps
You can purchase additional maps,
such as BirdsEye satellite imagery,
Garmin custom maps, Inland Lakes,
TOPO, BlueChart g2, and City
Navigator maps.
Optional Fitness Accessories
Fitness accessories are available for
the eTrex 30. Before you can use the
tness accessory with your device, you
must install the accessory according
to the instructions included with the
accessory.
You can use optional tness accessories
including a heart rate monitor or a
cadence sensor with your device.
These accessories use ANT+™ wireless
technology to send data to the device.
Using Optional Fitness
Accessories
1. Bring the device within range (10
ft. or 3 m) of the ANT+ accessory.
2. Select Setup > Fitness.
3. Select Heart Rate Monitor or
Bike Cadence Sensor.
4. Select Search for New.
5. Customize your data elds to view
the heart rate or cadence data
(page 28).
eTrex Owner’s Manual 47
Appendix
Tips for Pairing ANT+ Accessories
with Your Garmin Device
• Verify that the ANT+ accessory
is compatible with your Garmin
device.
• Before you pair the ANT+
accessory with your Garmin device,
move (33 ft. or 10 m) away from
other ANT+ accessories.
• Bring the Garmin device within
range (10 ft. or 3 m) of the ANT+
accessory.
• After you pair the rst time, your
Garmin device automatically
recognizes the ANT+ accessory
each time it is activated. This
process occurs automatically when
you turn on the Garmin device and
only takes a few seconds when
the accessories are activated and
functioning correctly.
• When paired, your Garmin device
receives data from only your
accessory, and you can go near
other accessories.
Data Field Options
Not all data elds are available for all
models.
Data Field Description
Accuracy of
GPS
The margin of
error for your exact
location. For example,
your GPS location
is accurate to within
+/- 12 ft.
Ambient
Pressure
The uncalibrated
environmental
pressure.
Ascent -
Average
The average vertical
distance of ascent.
Ascent -
Maximum
The maximum ascent
rate in feet or meters
per minute.
Ascent - Total The total elevation
distance ascended.
48 eTrex Owner’s Manual
Appendix
Data Field Description
Barometer The calibrated current
pressure.
Battery Level The remaining battery
power.
Bearing The direction from
your current location
to a destination.
Cadence
(cadence
accessory
required)
Revolutions of the
crank arm or strides
per minute.
Course The direction from
your starting location
to a destination.
Descent -
Average
The average vertical
distance of descent.
Descent -
Maximum
The maximum
descent rate in feet or
meters per minute.
Descent - Total The total elevation
distance descended.
Distance to
Destination
The distance to your
nal destination.
Data Field Description
Distance to
Next
The remaining
distance to the next
waypoint on the route.
Elevation The altitude of your
current location above
or below sea level.
Elevation -
Maximum
The highest elevation
reached.
Elevation -
Minimum
The lowest elevation
reached.
ETA at
Destination
The estimated time
of day you will reach
your nal destination.
ETA at Next The estimated time of
day you will reach the
next waypoint on the
route.
Glide Ratio The ratio of horizontal
distance traveled to
the change in vertical
distance.
eTrex Owner’s Manual 49
Appendix
Data Field Description
Glide Ratio to
Dest.
The glide ratio
required to descend
from your current
position and elevation
to the destination
elevation.
GPS Signal
Strength
The strength of the
GPS signal.
Heading The direction you are
moving.
Heart Rate
(heart rate
monitor
required)
Your heart rate in
beats per minute
(bpm).
Location
(lat/lon)
Displays the current
position in the default
position format
regardless of the
selected settings.
Location
(selected)
Displays the current
position in the
selected position
format.
Data Field Description
Odometer A running tally of
distance traveled for
all trips.
Off Course The distance to
the left or the right
by which you have
strayed from the
original path of travel.
Pointer The data eld arrow
points in the direction
of the next waypoint
or turn.
Speed The current rate of
speed at which you
are moving since last
reset.
Speed -
Maximum
The maximum speed
reached since last
reset.
Speed -
Moving Avg.
The average speed
of the device while
moving since last
reset.
50 eTrex Owner’s Manual
Appendix
Data Field Description
Speed -
Overall Avg.
Your average speed
since last reset.
Sunrise The time of sunrise
based on your GPS
position.
Sunset The time of sunset
based on your GPS
position.
Time of Day The current time of
day based on your
time settings (format,
time zone, and
daylight saving time).
Time to
Destination
The estimated time
needed to reach your
nal destination.
Time to Next The estimated time
needed to reach the
next waypoint on the
route.
To Course The direction in which
you must move to
return to the route.
Data Field Description
Trip Odometer A running tally of the
distance traveled
since the last reset.
Trip Time -
Moving
A running tally of time
since the last reset.
Trip Time -
Stopped
The time spent not
moving since the last
reset.
Trip Time -
Total
A running tally of
distance traveled
since the last reset.
Turn The angle of
difference (in
degrees) between
the bearing to your
destination and your
current course. L
means turn left. R
means turn right.
Velocity Made
Good
The speed at which
you are closing on a
destination along a
route.
eTrex Owner’s Manual 51
Appendix
Data Field Description
Vert. Speed to
Dest.
The measurement
of your rate of
ascent or descent
to a predetermined
altitude.
Vertical Speed Your rate of altitude
gain or loss over time.
Waypoint at
Dest.
The last point on
a route to your
destination.
Waypoint at
Next
The next point on
your route.
52 eTrex Owner’s Manual
Appendix
Troubleshooting
Problem Solution
The device does not
respond. How do I
reset the device?
1. Remove the batteries.
2. Reinstall the batteries.
NOTE: This does not erase any of your data or settings.
I want to reset all the
customized settings
back to the factory
defaults.
Select Setup > Reset > Reset All Settings.
My device does not
acquire satellite
signals.
1. Take your device out of buildings and parking
garages, and away from tall buildings and trees.
2. Turn on the device.
3. Remain stationary for several minutes.
The batteries do not
last long.
To learn how to maximize the battery life, see page 41.
How do I know my
device is in USB mass
storage mode?
On the device, an image of the device connected to a
computer appears.
On your computer, you should see a new removable
disk drive in My Computer on Windows computers and a
mounted volume on Mac computers.
eTrex Owner’s Manual 53
Appendix
Problem Solution
My device is
connected to the
computer, but it will not
go into mass storage
mode.
You may have loaded a corrupted le.
1. Disconnect the device from your computer.
2. Turn off the device.
3. Hold while you connect the device to your
computer.
4. Continue holding for 30 seconds or until the device
goes into mass storage mode.
I cannot see any new
removable drives in
my list of drives.
If you have several network drives mapped on your
computer, Windows may have trouble assigning drive
letters to your Garmin drives. See the Help le for your
operating system to learn how to assign drive letters.
I need replacement
parts or accessories.
Go to http://buy.garmin.com, or contact your Garmin
dealer.
I want to buy an
external GPS antenna.
Go to http://buy.garmin.com, or contact your Garmin
dealer.
54 eTrex Owner’s Manual
Index
Index
A
AA batteries
selecting the type 30
accessories 46, 53
tness 46
acquiring satellite
signals 52
active route 13
addresses 12
advanced map setup 32
alarms
clock 26
marine 38
proximity 24
tones for 31
almanac
hunting and shing 25
sunrise and sunset 25
altimeter
calibrating 20
plot type 35
settings 34
ANT+ accessories 46
area calculation 25
automotive mode 31
auto mounts 17
auto zoom 32
B
backlight
timeout 40
barometer 19
BaseCamp 43
batteries 30, 48
about 41
information 7, 41
installing 7
life 41
long term storage 42
maximizing life 41
selecting the type 7
storage 7
warnings 7
BirdsEye satellite
imagery 11
BlueChart g2 maps 11
C
calculator 25
calendar 25
calibrating
altimeter 20
compass 18
caring for the device 42
long-term storage 42
chirp 23
City Navigator maps 17
compass 17
calibrating 18
navigating 18
restore 39
setup options 34
connecting
to another device 24
USB cable 44
wireless accessories 46
course pointer 19
creating
routes 12
waypoints 9
customizing
data elds 28
eTrex Owner’s Manual 55
Index
device settings 30–39
proles 29
D
data elds 28
options 47
deleting
les 45
proles 30
routes 13
tracks 15
waypoints 9
display
backlight timeout 30
screen capture 30
settings 30
downloading
geocaches 21
software 40
driving routes 37
E
editing
proles 30
routes 12
waypoints 9
elevation plot 19, 20
barometric altimeter 20
of a track 15
F
le types 43
nding
addresses 12
near your location 11
shing times 25
tness options 46
G
geocaches 21, 35
downloading 21
lter list 21
logging attempt 22
navigating to 22
settings 35
GPS signals 8, 26, 30, 47,
49, 52
turning off 26
H
heading settings 34
HomePort 43
hunting times 25
K
keys 5, 6
L
language 30
locking ring 6
M
main menu
customizing 28
map 16, 17
additional 11
datum 34
detail 32
information 32
optional 46
restore 39
setup 32
viewing routes 13
marine settings 37–38
measuring area 25
memory card 43
microSD card 43
moon phase 25
56 eTrex Owner’s Manual
Index
myGarmin 8
N
navigating 16
driving routes 17
to a geocache 22
to waypoints 9
with bearing pointer 18
with course pointer 19
north up 31
O
orientation, map 31
P
pages 39
adding 39
removing 39
position format 33
power key 8
proles 29
changing 29
creating 29
selecting 29
proximity alarms 24
R
recording tracks 14, 32
registering your device 8
resetting
all settings 52
data 38
device 52
elevation plot 20
restoring default settings
39
routes 12–13
active route 13
avoidance 37
creating 12
deleting 13
editing 13
navigating 13
settings 36
S
satellite signals 8, 26, 47,
49, 52
system settings 30
turning off GPS 26, 27
saving
tracks 15
sharing data 24
Sight N’ Go 10
software
updating 40
version 40
stopwatch 26
storing the device 42
sunrise and sunset times
25, 50
system settings 30
T
text size, maps 32
time
alarms 26
data elds 50
settings 33
sunrise and sunset
25, 50
zone 33
tones 31
eTrex Owner’s Manual 57
Index
tracks 14–16
archiving 15
clearing current 15
deleting 15
proles 15
recording 14, 32
saving 15
setup 32
viewing 15
track up 31
transferring les 44
using USB 44
wirelessly 24
trip computer 20
restore 39
troubleshooting 52
U
unit ID 40
units of measure 33
updating software 40
USB cable 52
connecting 44
disconnecting 45
W
waypoints 9–10
averaging 10
creating 9
deleting 9
editing 9
navigating to 16
WebUpdater 40
Where To? 11
Z
zooming 32
© 2011 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, USA
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9LR UK
Garmin Corporation
No. 68, Zhangshu 2nd Road, Xizhi Dist., New Taipei City, 221, Taiwan (R.O.C.)
www.garmin.com
July 2011 190-01198-00 Rev. B Printed in Taiwan
