Garmin®ANT+TMadapterforiPhone®

Introduction

TheGarmin®ANT+TMadapterforiPhone®willbeusedinconjunctionwiththeiOS

mobilefitnessapplicationtoallowiPhone/iPodtocommunicatewithANT+

compatibledevices,suchasheartratemonitors,speed/cadencesensors,footpods

andpowermeters.

Operation

 

ConnectGarmin®ANT+TMadapterforiPhone®directlytothebottomoftheiPhone

Specifications



ANTspecification

RadioStandardANT+AP2

FrequencyBand2.457GHz

ChannelSpacing1MHz

Channel1

TransmissionGFSK

ModulationGFSK

AntennaTypeChipantennawithmaxgain1.7dBi(peak)

Temperature‐15to60℃

Voltage3.3V(providedbyiPhone)

OutputPower0~‐18dBm

InterfaceUARTtoiPhone



Model Name : Garmin ANT + adapter for iPhone

Brand Name : Garmin

FCC Statement :

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

IC Statement :

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.
