Owner’s Manual
February 2015 Printed in Taiwan 190-01839-00_0A
DRAFT
All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the
right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such
changes or improvements. Go to www.garmin.com for current updates and supplemental information concerning the use of this product.
Garmin®, the Garmin logo, ANT+®, and vívofit® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Garmin Connect™
,
Garmin Express™
, and USB ANT Stick™
are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission
of Garmin.
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. Mac® is a trademark of Apple
Inc. Windows® is a registered trademark of Microsoft Corporation in the United States and other countries. Other trademarks and trade names are those of their
respective owners.
This product is ANT+® certified. Visit www.thisisant.com/directory for a list of compatible products and apps.
DRAFT
Introduction
WARNING
See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
Always consult your physician before you begin or modify any
exercise program.
Getting Started
Before you can use the device, you must set up the device on
your computer or compatible mobile device.
1Go to www.garminconnect.com/.
2Select an option:
• If you are using a computer to set up your device, plug the
wireless USB ANT Stick™
into an empty USB port, and
download and install the Garmin Express™
setup software
(Downloading the Software).
• If you are using a mobile device to set up your device,
install and open the Garmin Connect™
Mobile app
(Downloading the Mobile App).
3Select the device key
to turn on the device.
When you turn on the device for the first time, it is in pairing
mode. If your device is not in pairing mode when you turn it
on, you must hold the device key until PAIR appears.
NOTE: Until you pair your device and complete the setup
process, the device has limited functionality.
4Follow the instructions on your computer or mobile device to
pair your device and complete the setup process.
Downloading the Software
1From your computer, go to www.garminconnect.com/.
2Select an option:
• If you are using a Windows® operating system, select
Download for Windows, and follow the on-screen
instructions.
• If you are using a Mac® operating system, select
Download for Mac, and follow the on-screen instructions.
Downloading the Mobile App
You can use the Garmin Connect Mobile app to pair your device
and complete the setup process. This allows you to share and
analyze data and download software updates from your mobile
device. Unlike other Bluetooth® devices that are paired from the
Bluetooth settings on your mobile device, your device must be
paired directly through the Garmin Connect Mobile app.
NOTE: Your mobile device must support Bluetooth Smart in
order to pair with your device and synchronize data. See the
application store for your mobile device for compatibility
information.
1From your mobile device, go to www.garminconnect.com
2Select Get the App, and follow the on-screen instructions.
Sending Data to Your Computer
Before you send data to your computer, you must plug the USB
ANT Stick into a computer USB port, and you must download
the Garmin Express setup software (Downloading the Software).
1Bring the device within 3 m (10 ft.) of your computer.
2Hold the device key until SYNC appears.
3View your data at Garmin Connect.
Pairing Your Device with Multiple Computers
You can pair your device with multiple computers. For example,
you can pair your device with your home and work computers.
1Plug the USB ANT Stick into a computer USB port.
2Download the Garmin Express setup software for Windows
or Mac (Downloading the Software).
3Hold the device key until PAIR appears.
4Follow the instructions on your computer to pair your device
and complete the setup process.
5If necessary, repeat steps 1-4 for each additional computer.
NOTE: You can pair only one computer at a time.
Sending Data to Your Mobile Device
Before you can send data to your mobile device, you must pair
the device with a compatible mobile device (Downloading the
Mobile App).
Your device synchronizes with the Garmin Connect Mobile app
periodically. You can also send data to your mobile device at
any time.
1Bring the device within 3 m (10 ft.) of your mobile device.
2Hold the device key until SYNC appears.
3View your data in the Garmin Connect Mobile app.
Pairing Multiple Mobile Devices
You can pair your device with multiple mobile devices. For
example, you can pair your device with a smartphone and a
tablet.
1Install and open the Garmin Connect Mobile app on your
mobile device (Downloading the Mobile App).
2Hold the device key until PAIR appears.
3Follow the instructions on your mobile device to pair your
device and complete the setup process.
4If necessary, repeat steps 1-3 for each additional mobile
device.
NOTE: You can pair only one mobile device at a time.
Wearing the Device
1Select ZKDW fits best on you
.
2Make sure the pegs on the clasp are fully inserted
.
When both pegs are fully inserted, the device fits securely
.
3Turn the clasp to the locked position.
Red marks on the clasp indicate the unlocked position.
NOTE: To prevent loss, the clasp must be turned to the
locked position.
4.
Icons
Icons appear at the bottom of the display. Each icon represents
a different feature. You can select the device key to cycle
through the different device features.
Introduction 1
DRAFT
Device Information
Specifications
Battery type Two user-replaceable CR1632 batteries
Battery life Up to 1 yr.
Operating temperature
range
From -10º to 60ºC (from 14º to 140ºF)
Radio frequency/protocol 2.4 GHz ANT+ wireless communications
protocol
Bluetooth Smart wireless technology
Water rating 5 ATM*
*The device withstands pressure equivalent to a depth of 50 m.
For more information, go to www.garmin.com/waterrating.
Specifications
 )
/
  

*
.
*.
For more information, go to www.garmin.com/waterrating.
User Replaceable Batteries
WARNING
Do not use a sharp object to remove batteries.
Keep the battery away from children.
Never put batteries in mouth. If swallowed, contact your
physician or local poison control center.
Replaceable coin cell batteries may contain perchlorate
material. Special handling may apply. See www.dtsc.ca.gov
/hazardouswaste/perchlorate.
CAUTION
Contact your local waste disposal department to properly
recycle the batteries.
Replacing the Device Batteries
1Remove the module from the band.
2Use a small Phillips screwdriver to remove the four screws on
the front of the module.
3Remove the cover and batteries.
4Insert the new batteries.
NOTE: Do not damage or lose the gasket.
5Replace the front cover and the four screws.
6Insert the module into the band.
The device key on the module must be aligned with the key
on the band.
After you replace the device batteries, you must pair the device
with your computer or mobile device again.
4 Device Information
DRAFT
Images are not final
Device Care
NOTICE
Avoid extreme shock and harsh treatment, because it can
degrade the life of the product.
Avoid pressing the keys under water.
Do not use a sharp object to clean the device.
Avoid chemical cleaners, solvents, and insect repellents that can
damage plastic components and finishes.
Thoroughly rinse the device with fresh water after exposure to
chlorine, salt water, sunscreen, cosmetics, alcohol, or other
harsh chemicals. Prolonged exposure to these substances can
damage the case.
Do not store the device where prolonged exposure to extreme
temperatures can occur, because it can cause permanent
damage.
Cleaning the Device
1Wipe the device using a cloth dampened with a mild
detergent solution.
2Wipe it dry.
Caring IRUWKHDFFHVVRU\GHYLFH
NOTICE
A
.
• Rinse after every use.
• Hand wash occasionally, using a tiny amount of
mild detergent, such as dishwashing liquid.
NOTE: Using too much detergent may damage the GHYLFH.
• Do not put in a dryer.
• When drying, hang it up or lay it flat.
Troubleshooting
I don't have a computer or mobile device
You can turn on the device and use it with limited functionality,
until you complete the setup process on a computer or mobile
device. Prior to setup, you can use only FHUWDLQIHDWXUHV
Your device resets once a day.

<RXUdevice does not store any history data until setup is complete.
Set up the device on a computer or compatible mobile device
(Getting Started) to use additional device features.
NOTE: Setup is a one-time process, and it allows you to use
all available device features.
My device does not display the correctO\
The device updates when you synchronize
your device to a computer or mobile device. When you change
, you should synchronize your device to EH
correct.
Select an option:
• Synchronize your device to a computer (Sending Data to
Your Computer).
• Synchronize your device to a mobile device (Sending Data
to Your Mobile Device).
The VHWWLQJVare updated automatically.
Turning on the Device
Select the device key
.
.
Software Update
When a software update is available, your device automatically
downloads the update when you synchronize your device to
your Garmin Connect account.
A countdown appears during the update process. When the
update is complete, your device restarts.
Troubleshooting 5
DRAFT
Software License Agreement
BY USING THE DEVICE, YOU AGREE TO BE BOUND BY THE
TERMS AND CONDITIONS OF THE FOLLOWING SOFTWARE
LICENSE AGREEMENT. PLEASE READ THIS AGREEMENT
CAREFULLY.
Garmin Ltd. and its subsidiaries (“Garmin”) grant you a limited
license to use the software embedded in this device (the
“Software”) in binary executable form in the normal operation of
the product. Title, ownership rights, and intellectual property
rights in and to the Software remain in Garmin and/or its third-
party providers.
You acknowledge that the Software is the property of Garmin
and/or its third-party providers and is protected under the United
States of America copyright laws and international copyright
treaties. You further acknowledge that the structure,
organization, and code of the Software, for which source code is
not provided, are valuable trade secrets of Garmin and/or its
third-party providers and that the Software in source code form
remains a valuable trade secret of Garmin and/or its third-party
providers. You agree not to decompile, disassemble, modify,
reverse assemble, reverse engineer, or reduce to human
readable form the Software or any part thereof or create any
derivative works based on the Software. You agree not to export
or re-export the Software to any country in violation of the export
control laws of the United States of America or the export control
laws of any other applicable country.
Limited Warranty
This Garmin product is warranted to be free from defects in
materials or workmanship for one year from the date of
purchase. Within this period, Garmin will, at its sole option,
repair or replace any components that fail in normal use. Such
repairs or replacement will be made at no charge to the
customer for parts or labor, provided that the customer shall be
responsible for any transportation cost. This warranty does not
apply to: (i) cosmetic damage, such as scratches, nicks and
dents; (ii) consumable parts, such as batteries, unless product
damage has occurred due to a defect in materials or
workmanship; (iii) damage caused by accident, abuse, misuse,
water, flood, fire, or other acts of nature or external causes; (iv)
damage caused by service performed by anyone who is not an
authorized service provider of Garmin; or (v) damage to a
product that has been modified or altered without the written
permission of Garmin, or (vi) damage to a product that has been
connected to power and/or data cables that are not supplied by
Garmin. In addition, Garmin reserves the right to refuse warranty
claims against products or services that are obtained and/or
used in contravention of the laws of any country.
Our navigation products are intended to be used only as a travel
aid and must not be used for any purpose requiring precise
measurement of direction, distance, location or topography.
Garmin makes no warranty as to the accuracy or completeness
of map data.
Repairs have a 90 day warranty. If the unit sent in is still under
its original warranty, then the new warranty is 90 days or to the
end of the original 1 year warranty, depending upon which is
longer.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN
ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES
EXPRESS, IMPLIED, OR STATUTORY, INCLUDING ANY
LIABILITY ARISING UNDER ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY
FROM STATE TO STATE.
IN NO EVENT SHALL Garmin BE LIABLE FOR ANY
INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, WHETHER RESULTING FROM THE USE,
MISUSE, OR INABILITY TO USE THIS PRODUCT OR FROM
DEFECTS IN THE PRODUCT. SOME STATES DO NOT
ALLOW THE EXCLUSION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS
MAY NOT APPLY TO YOU.
Garmin retains the exclusive right to repair or replace (with a
new or newly-overhauled replacement product) the device or
software or offer a full refund of the purchase price at its sole
discretion. SUCH REMEDY SHALL BE YOUR SOLE AND
EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.
To obtain warranty service, contact your local Garmin authorized
dealer or call Garmin Product Support for shipping instructions
and an RMA tracking number. Securely pack the device and a
copy of the original sales receipt, which is required as the proof
of purchase for warranty repairs. Write the tracking number
clearly on the outside of the package. Send the device, freight
charges prepaid, to any Garmin warranty service station.
Online Auction Purchases: Products purchased through online
auctions are not eligible for rebates or other special offers from
Garmin warranty coverage. Online auction confirmations are not
accepted for warranty verification. To obtain warranty service,
an original or copy of the sales receipt from the original retailer
is required. Garmin will not replace missing components from
any package purchased through an online auction.
International Purchases: A separate warranty may be provided
by international distributors for devices purchased outside the
United States depending on the country. If applicable, this
warranty is provided by the local in-country distributor and this
distributor provides local service for your device. Distributor
warranties are only valid in the area of intended distribution.
Devices purchased in the United States or Canada must be
returned to the Garmin service center in the United Kingdom,
the United States, Canada, or Taiwan for service.
Australian Purchases: Our goods come with guarantees that
cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. The benefits under
our Limited Warranty are in addition to other rights and remedies
under applicable law in relation to the products. Garmin
Australasia, 30 Clay Place, Eastern Creek, NSW, Australia,
2766. Phone: 1800 235 822.
6 Appendix
DRAFT
DRAFT
www.garmin.com/support
+43 (0) 820 220230 + 32 2 672 52 54
0800 770 4960 1-866-429-9296
+385 1 5508 272
+385 1 5508 271
+420 221 985466
+420 221 985465
+ 45 4810 5050 + 358 9 6937 9758
+ 331 55 69 33 99 + 39 02 36 699699
(+52) 001-855-792-7671 0800 0233937
+47 815 69 555 00800 4412 454
+44 2380 662 915
(+35) 1214 447 460 +386 4 27 92 500
0861 GARMIN (427 646)
+27 (0)11 251 9999 +34 93 275 44 97
+ 46 7744 52020 +886 2 2642-9199 ext 2
0808 238 0000
+44 (0) 870 8501242
+49 (0)180 6 427646
20 ct./Anruf. a. d.
deutschen Festnetz,
Mobilfunk max. 60 ct./Anruf
913-397-8200
1-800-800-1020
© 2015 Garmin Ltd. or its subsidiaries
DRAFT

Navigation menu
