User Manual

GDL 51
Portable SiriusXM® and GPS Receiver
User’s Guide
© 2017 Garmin Ltd. or its subsidiaries. All rights reserved.
This manual reflects the operation of System Software version 2.00, or later. Some differences in operation may be
observed when comparing the information in this manual to later software versions.
Garmin International, Inc.
1200 E. 151st Street, Olathe, KS 66062 USA
Aircraft On Ground (AOG) Hotline: (913) 397-0836
Aviation Dealer Technical Support Line (Toll Free): (888) 606-5482
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park, Southampton, Hampshire SO40 9LR U.K.
Garmin aviation product support and warranty information can be found at www.flygarmin.com.
Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated,
downloaded or stored in any storage medium, for any purpose without the express written permission of Garmin. Garmin
hereby grants permission to download a single copy of this manual and of any revision to this manual onto a hard drive
or other electronic storage medium to be viewed for personal use, provided that such electronic or printed copy of this
manual or revision must contain the complete text of this copyright notice and provided further that any unauthorized
commercial distribution of this manual or any revision hereto is strictly prohibited.
This part shall comply with Garmin Banned and Restricted Substances document, 001-00211-00.
Garmin
®
is a registered trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the
express permission of Garmin. iPad
®
, iPhone
®
, iPod
®
, and iPod touch are trademarks of Apple Inc., registered in the
USA and other countries. Android
TM
is a trademark of Google Inc. Sirius, XM, SiriusXM, and all related marks and logos
are trademarks of Sirius XM Radio Inc. All other marks, channel names, and logos are the property of their respective
owners. All rights reserved. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of
such marks by Garmin is under license.
July 2017 Printed in the United States or Taiwan
i
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
WARNING: The attitude information provided by the GDL 51 is not intended
to be used as a source of attitude information for flight in instrument
meteorological conditions.
WARNING: This unit provides the ability to receive weather information
through external sources. Use weather data only as an aid to situational
awareness. Such weather information is merely supplemental and advisory
in nature and is not intended to be relied upon as safety-critical information
in connection with any aviation, vehicle, or marine usage. The user should
always exercise caution and common sense when confronted with severe
weather conditions.
WARNING: Do not use data link weather information for maneuvering in,
near, or around areas of hazardous weather. Information contained within data
link weather products may not accurately depict current weather conditions.
WARNING: For safety reasons, GDL 51 operational procedures must be
learned on the ground.
WARNING: Use the GDL 51 only as an aid for VFR navigation. Do not
attempt to use the GDL 51 for any purpose requiring precise measurement
of direction, distance, location, or topography. This product should not be
used to determine ground proximity for aircraft navigation.
ii
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
WARNING: The altitude calculated by the GPS receiver is geometric height
above Mean Sea Level and could vary significantly from the altitude displayed
by pressure altimeters.
WARNING: The pressure altitude information provided by the
GDL 51 in a pressurized airplane will not be accurate. Use the connected
display device to disable pressure information from the GDL 51.
WARNING: The GDL 51 has a very high degree of functional integrity.
However, the pilot must recognize that providing monitoring and/or self-
test capability for all conceivable system failures is not practical. Although
unlikely, it may be possible for erroneous operation to occur without a fault
indication shown by the GDL 51. It is thus the responsibility of the pilot to
detect such an occurrence by means of cross-checking with all redundant
or correlated information available in the cockpit.
WARNING: The GDL 51 contains a lithium-ion battery. To prevent damage,
remove the unit from the aircraft or vehicle when exiting or store it out of
direct sunlight.
WARNING: The United States government operates the Global Positioning
System and is solely responsible for its accuracy and maintenance. The GPS
system is subject to changes which could affect the accuracy and performance
of all GPS equipment.
iii
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
WARNING: When installing the GDL 51 in an aircraft, place the unit securely
so that it does not interfere with aircraft operating controls or obstruct the
pilot’s view.
CAUTION: The Garmin GDL 51 does not contain any user-serviceable
parts. Repairs should only be made by an authorized Garmin service center.
Unauthorized repairs or modifications could void both the warranty and the
pilot’s authority to operate this device under FAA/FCC regulations.
NOTE: Temporary Flight Restriction (TFR) data is provided by the FAA and
may not be updated outside of normal business hours. Confirm data currency
through alternate sources and contact the local FSS for interpretation of TFR
data. This product has not been endorsed or otherwise approved by the
National Geospatial-Intelligence Agency, or the United States Department
of Defense (10 U.S.C. 425).
NOTE: All visual depictions contained within this document, including images
of the GDL 51 and the bezel, displays, and screens of other products are
subject to change and may not reflect the most current software or hardware.
Depictions of equipment may differ slightly from the actual equipment.
NOTE: This product, its packaging, and its components contain chemicals
known to the State of California to cause cancer, birth defects, or reproductive
harm. This notice is being provided in accordance with California’s Proposition
65. If you have any questions or would like additional information, please
refer to our web site at www.garmin.com/prop65.
iv
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and may cause harmful interference to radio communications if not installed and used in accordance
with the instructions. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet that is on a different circuit from the unit.
• Consult the dealer or an experienced radio/TV technician for help.
Innovation, Science and Economic Development Canada Compliance
This device complies with Innovation, Science and Economic Development Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause undesired operation
of the device.
Innovation, Sciences et Développment économique Canada - Conformité
Cet appareil est conforme aux normes RSS sans licence du ministére Innovation, Sciences et
Développement économique Canada. Son fonctionnement est soumis aux deux conditions suivantes
: (1) ce périphérique ne doit pas causer d’interférences et (2) doit accepter toute interférence,
y compris les interférences pouvant entraîner un fonctionnement indésirable de l’appareil.
M/N: A02895
1
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
1 UNIT OVERVIEW
Micro-USB Connector
Optional External SXM
Antenna Connection
Power Button
Optional External GPS
Antenna Connection
Data/Power Port
Audio Out Port
Figure 1 GDL 51 Interface
2
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
1.1 Power and Charging
The unit will always turn on when external power is applied.
Power source via the micro-USB connector:
• 5.0V ± 0.25V; 1.0A (powered on and slow charge)
• 5.0V ± 0.25V; 2.0A (powered off and fast charge)
Power Source via the power/data connector:
• 10-32V; 0.75A Max (powered on and slow charge)
• 10-32V; 1.0A Max (powered off and fast charge)
NOTE:
If powered ON from a standard USB wall charger the unit will
auto detect the wall charger and go into standby mode. In standby
mode, the battery LED will be solid red if charging, or off if the battery is
fully charged. Press the power button for normal operation. Maximum
total power while in standby mode is 10W. Total charge time is ~2
hours in this state.
NOTE:
The battery saver feature will turn off the unit when external
power is removed if all three of the following conditions are true:
1. Ground Speed less than 20kts OR No GPS fix
2. No Connext connection
3. Running on battery only
3
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
NOTE:
When the battery saver feature is active and the above three
conditions are met, the green battery LED will flash if the unit is about
to shut down. Press the power button once to cancel the battery
saver feature and keep the unit on.
2 OPERATION
2.1 Power Button Functions
• ON/OFF – single press
• Clear Paired Devices
o See Section 2.2 Bluetooth Setup
• USB Mass Storage Mode – 3 second press
o While the unit is booting up, hold the Power Button for 3 seconds.
o GPS, SXM LEDs will flash orange while in this state.
o Limited functionality, can be used to install SW upgrades.
(see Section 2.3)
o Press the power button to exit this mode.
• Reset the Unit – Hold for more than 10 seconds.
4
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
2.2 Bluetooth Setup
1. When the GDL 51 is powered on, the GDL 51 will go into pairing mode.
Directions for connecting the GDL 51 to a specific display can be found in
the display’s pilot’s guide.
2. The Connext LED will be solid blue when the display device is connected.
Two Bluetooth display devices may be connected to the GDL at the same
time.
3. A Bluetooth Audio device may also be connected to the GDL 51. Directions
for connecting an audio device are included in the pilot’s guide of the
connected display.
NOTE: If having issues making a Bluetooth connection hold the power
button down for 5 seconds. The blue LED will begin blinking. Release the
power button and then press the Power button again for 5 seconds. Power
cycle the GDL 51 and retry making a Bluetooth connection. If the problem
persists, consult the GDL 51 Installation Manual.
2.3 Software Updates
Software updates for the GDL 51 can be received through your Garmin display
device or from www.garmin.com/products/webupdater/. See the display device
documentation for details. Instructions for using Webupdater can be found on
the Garmin website.
5
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
Figure 2 GDL 51 LEDs
Table 1 GDL 51 Status LEDs
LED Color/
State* Battery Connext GPS SXM
OFF Unit off No active connection No GPS fix No signal
RED Charging (solid)
Fault (flashing) Not used Fault Fault
ORANGE Battery <=20% N/A Firmware update Firmware update
GREEN
Battery >= 20%
OR
External power is
applied
Battery saver feature
(flashing)
N/A GPS fix Marginal good
signal
BLUE N/A
Active connection
OR pairing list cleared
(flashing)
N/A N/A
*LEDs are auto-dimming.
6
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
3 INSTALLATION
The GDL 51 may be connected to a compatible display device by either a
wireless Bluetooth connection or directly through a serial cable. The GDL 51
supports two connections to Bluetooth display devices. The GDL 51 can also be
physically wired to two displays.
3.1 Interface Cables
3.1.1 GDL 51 to aera 660 Power/Data Cable
011-03854-91
Power Connector
To GDL 51
Data/Power Port
To aera 660
Mount
Figure 3 GDL 51 to aera 660 Power/Data Cable (010-12373-02)
7
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
3.1.2 GDL 51 to Bare Wire Power/Data Cable
Table 2 GDL 51 to Bare Wire Power/Data Cable Connections
Connection Wire Color AWG
Vin 10-32 VDC Red 26
Not Used Gray --
Rx B (Data In) White/Orange 28
Tx B (Data Out) Orange 28
Rx A (Data In) White/Green 28
Tx A (Data Out) Green 28
Ground Black 26
EMI
FILTER
Figure 4 GDL 51 to Bare Wire Power/Data Cable (010-11686-40)
8
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
3.2 External Antennas (Optional)
The GDL 51 includes internal GPS and SiriusXM antennas, but can use optional
external antennas.
NOTE: The GDL 51 can receive GPS information when interfaced with
certain Garmin GPS receivers. Refer to your specific Garmin display manual
to determine if this is supported.
3.3 GDL 51 Location and Mounting
3.3.1 Location
For best reception position the GDL 51 where it has a clear view of the sky. For
proper performance of the attitude function, the GDL 51 should be placed as close as
possible to the center of the aircraft (along its longitudinal axis) with the FWD arrow
pointing in the direction of flight. If the unit is placed on the glare shield it may get
very hot due to the direct sunlight and reduce the operating life of the unit. The GDL
51 antenna, internal or external, should be mounted at least 3.3 feet (1 meter) away
from the path of any high powered transmitter antenna, such as a transponder or VHF
radio antenna. The GDL 51 should be mounted at least 6 inches (10.24 cm) away
from a magnetic compass.
9
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
WARNING: It is the sole responsibility of the owner/operator of the GDL 51
to place this mount and secure the unit so that it will not interfere with the
aircraft’s operating controls and safety devices, or cause damage or personal
injury in the event of an accident or turbulence. Do not mount the GDL 51
where the pilot or passengers are likely to impact it in an accident, collision,
or turbulence. The mounting hardware provided by Garmin is not warranted
against turbulence, collision damage, or related consequences.
3.3.2 GDL 51 Mounting
A mounting plate is included to provide a fixed mount inside the aircraft, if
desired. The GDL 51 has a rubber pad that keeps the unit from sliding around, if
the mounting plate is not used. The GDL 51 may be mounted in a remote location
away from the cockpit, but may require the use of an external antenna for best
GPS and SiriusXM reception.
1. Locate the proposed mounting position. Ensure that the cabling will reach
the required connections with room to secure the cables in a safe manner.
Cables may be inserted into the slot in the included suction cup to assist in
routing cables.
2. Place the mounting plate in position and mark the location of the four
mounting holes.
3. Drill holes for the mounting screws with the appropriately sized bit.
4. Attach the mounting plate with four #8 flat head 100° screws (not supplied).
10
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
5. Ensure that the FWD arrow on the serial number tag is pointing in the
direction of flight.
6. Insert the GDL 51 into the mounting plate and then push down gently so it
snaps into place.
WITH MOUNTING BRACKET
2X 1.18830.16
38.102X 1.500
.177 4.50 THRU ALL
.344 8.74 X 100°
NOTE 3
Figure 5 GDL 51 w/Mounting Bracket
11
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
4 APPENDIX
4.1 Contact Garmin
If you have questions concerning unit operation or repair, Garmin aviation
product support and warranty information can be found at www.flygarmin.com.
When contacting Garmin, please have the following information:
• System configuration (products, antennas, mounting locations, etc.)
• Model No., part number, and serial number
• Software versions
• Description of the problem
• Efforts made to isolate/solve the problem
4.2 Servicing Your Unit
The Garmin GDL 51 has no user-serviceable parts. The GDL 51 is sealed to
protect the unit. Any attempt to open the case to change or modify the unit in any
way voids your warranty and may result in permanent damage to the equipment.
4.3 GDL 51 Physical Specifications
Operating Temperature Range: -20˚C to 60˚C (-4º F to +140º F)
Unit dimensions: WxHxD: 4.9” x 1.3” x 3.4” (12.44 x 3.30 x 8.64 cm)
Weight: 0.75 lbs (0.45 kg)
12
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
4.4 Software License Agreement
BY USING THE GDL 51, YOU AGREE TO BE BOUND BY THE TERMS AND
CONDITIONS OF THE FOLLOWING SOFTWARE LICENSE AGREEMENT.
PLEASE READ THIS AGREEMENT CAREFULLY.
Garmin grants you a limited license to use the software embedded in this
device (the “Software”) in binary executable form in the normal operation of the
product. Title, ownership rights, and intellectual property rights in and to the
Software remain with Garmin.
You acknowledge that the Software is the property of Garmin and is protected
under the United States of America copyright laws and international copyright
treaties. You further acknowledge that the structure, organization, and code of
the Software are valuable trade secrets of Garmin and that the Software in source
code form remains a valuable trade secret of Garmin. You agree not to decompile,
disassemble, modify, reverse assemble, reverse engineer, or reduce to human
readable form the Software or any part thereof or create any derivative works
based on the Software. You agree not to export or re-export the Software to any
country in violation of the export control laws of the United States of America.
13
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
4.5 Battery Information
If these guidelines are not followed, the internal Lithium Ion battery may
experience a shortened life span or may present a risk of damage to the unit, fire,
chemical burn, electrolyte leak, and/or injury.
• Do not leave the unit exposed to a heat source or in a high temperature location,
such as in the sun in an unattended aircraft on a hot day. To prevent damage,
remove the unit from the aircraft or store it out of direct sunlight.
• Do not disassemble, puncture, damage, or incinerate the unit/battery.
• When storing the unit for a limited length of time (less than 30 days), store
within the following temperature range: -4° to 122°F (-20° to 50°C). When
storing the unit for an extended time, store within the following temperature
range: -4° to 86°F (-20° to 30°C).
• Do not operate the unit outside of the following temperature range:
-4° to 140°F (-20° to 60°C).
• Do not remove or attempt to remove the non-user-replaceable battery.
• Do not immerse or expose unit to water or other liquids.
• Do not use a power and data cable that is not approved or supplied by Garmin.
• Contact your local waste disposal department to dispose of the device in
accordance with applicable laws and regulations.
14
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
4.6 Product Registration
Help us better support you by completing your online registration today! Have
the serial number of your product handy and connect to the Garmin web site
(http://my.garmin.com). Look for the Product Registration link on the Home page.
Also, be sure to record your serial number in the space provided.
To obtain accessories for your unit, please contact your Garmin dealer or visit
garmin.com/aviation.
Help us better support you by completing our on-line registration form today!
Registration ensures that you will be notified of product updates and new
products and provides lost or stolen unit tracking. Please, have the serial
number of your unit handy, connect to our web site (www.garmin.com) and
look for our Product Registration link on the Home page.
Use the line below to record the serial number in case it is lost, is stolen, or
needs service. The serial number is located on the bottom of your unit.
Serial Number: ________________________
4.7 ACTIVATING A SiriusXM SUBSCRIPTION
SiriusXM offers several subscription options. Go to http://www.siriusxm.com/
sxmaviation to determine which subscription package is best for your needs.
15
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
Before you can activate your SiriusXM subscription, you must have the
radio ID. The radio ID is available in the product box, the unit’s S/N tag, and
on the System Information Page of a connected device. See the owner’s manual
provided with your device for more information.
1. Contact SiriusXM by phone at (866) 528-7474 or go to
http://care.siriusxm.com to subscribe.
2. Provide the necessary information to the SiriusXM representative or
on the web site to activate your antenna.
3. Verify the functionality of the activated services:
• For SiriusXM weather, on a connected device, view the Weather Products
list and confirm that your subscribed services are listed. See the owner’s
manual provided with your device for more information.
• For SiriusXM radio, on a connected device, go to the SiriusXM Audio
Page and confirm that radio channels are available. See the owner’s
manual provided with your device for more information.
4. If the service is not activated within the hour, go to http://care.siriusxm.
com/refresh or contact SiriusXM by phone at 1-855-MYREFRESH
(697-3373).
NOTE: For the unit to receive the SiriusXM signal, it must be powered on,
facing skyward, and tuned to channel 1.
16
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
4.8 SiriusXM Satellite Radio Service Agreement
4.8.1 SiriusXM Satellite Radio Inc.
Hardware and required monthly subscription sold separately. USER
ACKNOWLEDGES THAT GARMIN HAS NO CONTROL OVER THE TERMS AND
REQUIREMENTS OF THE SUBSCRIPTION. COMPATIBILITY OF HARDWARE
EQUIPMENT WITH THEN-CURRENT SUBSCRIPTION OFFERING OF
SERVICE PROVIDER IS ALSO BEYOND GARMIN’S CONTROL. GARMIN SHALL
HAVE NO LIABILITY IF CHANGES IN SERVICE PROVIDER’S SUBSCRIPTION
OFFERING NEGATIVELY IMPACTS OR RENDERS IMPOSSIBLE THE USE
OF PURCHASED GARMIN HARDWARE EQUIPMENT WITH THE SERVICE
PROVIDER’S OFFERING IN THE FUTURE. Subscription fee is consumer
only. Other fees and taxes, including a one-time activation fee may apply. All
programming fees and weather data subject to change. SiriusXM weather data
and individual product availability vary by hardware equipment. Reception of
the SiriusXM signal may vary depending on location. Subscriptions subject to
Customer Agreement included with the SiriusXM Welcome Kit and available at
www.siriusxm.com. USER ACKNOWLEDGES THAT GARMIN IS AN INTENDED
THIRD PARTY BENEFICIARY OF SUCH CUSTOMER AGREEMENT, AND THAT
ALL DISCLAIMERS CONTAINED THEREIN EQUALLY APPLY AS IF SUCH
DISCLAIMERS WERE MADE DIRECTLY BY GARMIN. Available only in the 48
contiguous United States.
17
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
THE USER AGREES THAT THE SiriusXM WEATHER SERVICE OFFERING
IS PROVIDED “AS IS”, THAT YOUR GARMIN HARDWARE EQUIPMENT
ONLY ALLOWS THE DISPLAY OF SUCH SERVICE OFFERING, AND THAT
ANY CHANGES BY THE SERVICE PROVIDER MAY INTERFERE WITH THE
ABILITY OF YOUR GARMIN HARDWARE EQUIPMENT TO RECEIVE OR
DISPLAY SUCH SERVICE OFFERING. FURTHER, SUCH SERVICE OFFERING
CONTAINS INFORMATION FURNISHED BY OTHERS WHO ARE NOT UNDER
THE CONTROL OF GARMIN, AND THEREFORE THE SERVICE OFFERING
IS ACCORDINGLY FURNISHED WITHOUT ANY WARRANTY OF GARMIN,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
18
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
4.8.2 Caution - Advisory Only
THE WEATHER INFORMATION IS SUBJECT TO SERVICE INTERRUPTIONS
AND MAY CONTAIN ERRORS OR INACCURACIES AND CONSEQUENTLY
SHOULD NOT BE RELIED UPON EXCLUSIVELY. YOU ARE URGED TO CHECK
ALTERNATE WEATHER INFORMATION SOURCES PRIOR TO MAKING
SAFETY RELATED DECISIONS. YOU ACKNOWLEDGE AND AGREE THAT
YOU SHALL BE SOLELY RESPONSIBLE FOR USE OF THE INFORMATION
AND ALL DECISIONS TAKEN WITH RESPECT THERETO. BY USING THIS
SERVICE, YOU RELEASE AND WAIVE ANY CLAIMS AGAINST SiriusXM RADIO
INC., THE WEATHER COMPANY, NAVCAST INCORPORATED, AND GARMIN
SWITZERLAND GmbH AND ALL OF THEIR RESPECTIVE AFFILIATES WITH
REGARD TO THIS SERVICE.
19
190-02087-00 Rev. A
Garmin GDL 51 User’s Guide
4.8.3 User Safety
If you use SiriusXM Services it is your responsibility to exercise prudent
discretion and observe all safety measures required by law and your own common
sense. You assume the entire risk related to your use of the Services. SiriusXM
and Garmin assume no responsibility for accidents resulting from or associated
with use of the Services. Your Radio Service includes weather information, and
you acknowledge that such information is not for “safety for life”, but is merely
supplemental and advisory in nature, and therefore cannot be relied upon as safety-
critical in connection with any aircraft, or automobile usage. This information
is provided “as is” and SiriusXM and Garmin disclaim any and all warranties,
express and implied, with respect thereto or the transmission or reception thereof.
SiriusXM and Garmin further do not warrant the accuracy, reliability, completeness
or timeliness of the weather information disclosed on the Radio Service. In no
event will SiriusXM and Garmin, their data suppliers, service providers, marketing/
distribution, software or Internet partners or hardware manufacturers be liable
to you or to any third party for any direct, indirect, incidental, consequential,
special, exemplary or punitive damages or lost profits resulting from use of or
interruptions in the transmission or reception of the Services.
20
Garmin GDL 51 User’s Guide
190-02087-00 Rev. A
4.8.4 Limits On Our Responsibility
a) DISCLAIMERS.
EXCEPT AS EXPRESSLY PROVIDED HEREIN, WE MAKE NO WARRANTY
OR REPRESENTATION, EITHER EXPRESS OR IMPLIED, REGARDING THE
RADIO SERVICE. YOUR USE OF THE SERVICE IS AT YOUR SOLE RISK. THE
CONTENT AND FUNCTIONALITY OF THE SERVICE IS PROVIDED “AS IS”
WITHOUT ANY WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. ALL
SUCH WARRANTIES OR REPRESENTATIONS (INCLUDING, WITHOUT
LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, TITLE AND NON-INFRINGEMENT) ARE
HEREBY DISCLAIMED.
b) LIMITATIONS OF LIABILITY.
WE ARE NOT RESPONSIBLE FOR ANY SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OR LOSSES RELATING TO THE USE OF THE
RADIO SERVICE, WHETHER BASED ON NEGLIGENCE OR OTHERWISE.
OUR TOTAL LIABILITY TO YOU AND ANY OTHER PERSONS RECEIVING
OUR SERVICES, REGARDLESS OF THE CAUSE, WILL IN NO EVENT EXCEED
THE AMOUNTS THAT YOU HAVE PAID TO US FOR THE SERVICE THAT YOU
RECEIVED DURING THE SIX (6) MONTH PERIOD IMMEDIATELY PRIOR TO THE
SPECIFIC EVENT THAT GAVE RISE TO THE APPLICABLE DAMAGE OR LOSS.
THIS ALLOCATION OF RISK IS REFLECTED IN OUR PRICES. YOU MAY HAVE
GREATER RIGHTS THAN DESCRIBED ABOVE UNDER YOUR STATE’S LAWS.
© 2017 GARMIN Corporation
Garmin International, Inc.
1200 E. 151st Street
Olathe, KS 66062 USA
Aircraft On Ground (AOG) Hotline: (913) 397-0836
Aviation Dealer Technical Support Line (Toll Free): (888) 606-5482
Garmin Aviation Product Support: (866) 739-5687
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park
Southampton, Hampshire SO40 9LR U.K.
Garmin aviation product support and warranty information can be found at
www.flygarmin.com.
Part Number 190-02087-00 Rev. A

Navigation menu
