Garmin 03130 Low Power Transmitter User Manual 1

Garmin International Inc Low Power Transmitter 1

Contents

User Manual 1

Instructions ...................................................... 5
Introduction
WARNING
See the Important Safety and Product
Information guide in the product box for product
warnings and other important information.
Waking Up
Wake up by shaking it vertically or
running a few steps.
Pairing with Your
Compatible Device
Pairing is the connecting of WKLV ® wireless
sensors with a compatible device. This
procedure contains instructions
®If you have another
compatible device, see your owner's manual.
1Wake up the GHYLFH.
Instructions 5
2From the FRPSDWLEOH device, select ,
and select a run profile.
3Bring the devices close to each other.
4Wait while the deviceV connect.
If necessary, you can select Menu >
Settings > Sensors and Accessories >
Add New > Search All to pair and manage
wireless sensors.
A message appears,
indicates that the dHYLFH is connected.
After the initial pairing, the device automatically
connects to HDFK RWKHU when you XVH WKHP and
the dHYLFH is active and within range.
Dynamics
You can use the dHYLFH with your RWKHU compatible
device to provide real-time feedback about your
DFWLYLW\ The dHYLFH has an LQWHUQDO VHQVRU
that measures movement in order to
calculate six metrics.
NOTE: The dynamics features are
available on only some Garmin® devices.
6 Instructions
.
Specifications
Battery type User-replaceable CR1632
Battery life 1 yr. (approximately 1 hr./
day)
Instructions 7
Operating
temperature
range
From -10 to 50 C (from
14 to 122 F)
Radio frequency/
protocol
2.4 GHz ANT+ wireless
communications protocol
Water rating 1 ATM*
*The device withstands pressure equivalent to
a depth of 10 m. For more information, go to
www.garmin.com/waterrating.
Replacing the Battery
1Remove the dHYLFH from the flexible silicone
cRYHULQJ by stretching the material
2On the back of the dHYLFH, twist the cover À
counter-clockwise to unlock it.
8 Instructions
3Remove the cover and the battery Á.
TIP: You can use a piece of tape or a
magnet to remove the battery from the
cover.
4Wait 30 seconds.
5Insert the new battery into the cover,
observing polarity.
NOTE: Do not damage or lose the O-ring
gasket.
6Replace the cover, and rotate clockwise to
lock it.
NOTE: Do not pinch the O-ring gasket. The
O-ring gasket should not be visible when
the cover is locked.
7Insert the dHYLFH into the flexible silicone clip
by stretching the material around the dHYLFH.
The icon on the dHYLFH must be
aligned with the RWKHU icon.
Device Care
NOTICE
Avoid extreme shock and harsh treatment,
because it can degrade the life of the product.
Instructions 9
Avoid chemical cleaners, solvents, and insect
repellents that can damage plastic components
and finishes.
Cleaning the Device
NOTICE
Avoid washing the dHYLFH in the washing machine.
The dHYLFH is designed to withstand occasional,
accidental machine washing at a medium or
cool temperature. Frequent machine washing,
hot washing temperatures, or the dryer may
damage the dHYLFH.
1Wipe the device using a cloth dampened
with a mild detergent solution.
2Wipe it dry.
AVERTISSEMENT
Consultez le guide Informations importantes
sur le produit et la sécurité inclus dans
l'emballage du produit pour prendre
connaissance des avertissements et autres
informations sur le produit.
