Garmin 03430 Low Power Transmitter 2402-2480 MHz User Manual

Garmin International Inc Low Power Transmitter 2402-2480 MHz

Contents

User Manual

Hello appears when the device turns on.
5Open the Garmin Connect Mobile app, and
follow the instructions to complete the
pairing and setup process.
After you pair successfully, a message
appears, and your device syncs automatically
with your smartphone.
Using the Device
Double-
tap
Double-tap the touchscreen À to
wake the device.
NOTE: The screen turns off when
not in use. When the screen is off,
the device is still active and
recording data.
Wrist
gesture
Rotate and lift your wrist toward
your body to turn the screen on.
Rotate your wrist away from your
body to turn the screen off.
Press Press Á to open and close
the menu from the main watch
face.
Press to return to the previous
screen.
Swipe Swipe the touchscreen up or down
to scroll through widgets and menu
options.
Tap Tap the touchscreen to make a
selection.
Quick Start Manual 3
NOTICE
To prevent corrosion, thoroughly clean and dry
the contacts and the surrounding area before
charging or connecting to a computer. Refer to
the cleaning instructions in the owner's manual.
1Pinch the sides of the charging clip À to
open the arms on the clip.
2Align the clip with the contacts Á, and
release the arms of the clip.
3Plug the USB cable into a power source.
4Charge the device completely.
Specifications
Operating temperature range: From -20º to
50ºC (from -4º to 122ºF)
Charging temperature range: From 0º to 45ºC
(from 32º to 113ºF)
Getting the Owner's Manual
The owner's manual includes instructions for
using device features and accessing regulatory
information.
Go to www.garmin.com/
manuals /.
8 Quick Start Manual
Getting More Information
• Go to support.garmin.com for additional
manuals, articles, and software updates.
• Go to www.garmin.com/intosports.
• Go to www.garmin.com/learningcenter.
• Go to buy.garmin.com, or contact your
Garmin dealer for information about
optional accessories and replacement
parts.
• Go to www.garmin.com/ataccuracy.
Quick Start Manual 9
support.garmin.com
© 2018 Garmin Ltd. or its subsidiaries
Garmin®, the Garmin logo, ANT+®, and ® are
trademarks of Garmin Ltd. or its subsidiaries,
registered in the USA and other countries. Garmin
Connect™ are trademarks of Garmin Ltd. or its
subsidiaries. This trademark may not be used without
the express permission of Garmin.
The word mark and logos are owned by the Inc. and
any use of such marks by Garmin is under license.
Advanced heartbeat analytics by Firstbeat. Other
trademarks and trade names are those of their
respective owners.
M/N: A03430
Printed in Taiwan
March 2018
190-00000-00
