User Manual
IMPORTANT SAFETY AND
PRODUCT INFORMATION
WARNING
Failure to heed the following warnings
could result in an accident or medical
event resulting in death or serious injury.
Dive Warnings
• The diving features of this device are
for use by certified divers only. This
device should not be used as a sole
dive computer. Failure to input the
appropriate dive-related information
into the device can lead to serious
personal injury or death.
•Make sure that you fully understand
the use, displays, and limitations of
your device. If you have questions
about this manual or the device,
always resolve any discrepancies or
confusion before diving with the
device. Always remember that you are
responsible for your own safety.
• There is always a risk of
decompression sickness (DCS) for any
dive profile even if you follow the dive
plan provided by the dive tables or a
diving device. No procedure, diving
device, or dive table will eliminate the
possibility of DCS or oxygen toxicity.
An individual's physiological make up
can vary from day to day. This device
cannot account for these variations.
You are strongly advised to remain
well within the limits provided by this
device to minimize the risk of DCS.
You should consult a physician
regarding your fitness before diving.
• This device can calculate
decompression stop requirements.
These calculations are at best an
estimate of the real physiological
decompression requirements. Dives
requiring staged decompression are
substantially more risky than dives that
stay well within no-stop limits. Diving
with rebreathers, diving with mixed
gases, performing staged
decompression dives, and diving in
overhead environments greatly
increases the risk of scuba diving.
•If you have a pacemaker or other
implantable medical device, consult
1
your physician before you dive. Scuba
diving creates physical stresses on the
body, which may not be suitable for
pacemakers and other implantable
medical devices.
• Always use backup instruments,
including a depth gauge, submersible
pressure gauge, and timer or watch.
You should have access to
decompression tables when diving with
this device.
•Perform pre-dive safety checks, such
as checking proper device function and
settings, display function, battery level,
and tank pressure.
• Check your device regularly during a
dive. If there is any apparent
malfunction, terminate the dive
immediately and safely return to the
surface.
• This device should not be shared
between multiple users for diving
purposes. Diver profiles are user
specific, and using another diver's
profile can result in misleading
information that could lead to injury or
death.
• For safety reasons, you should never
dive alone. Dive with a designated
buddy. You should also stay with
others for an extended time after a
dive, because the potential onset of
DCS may be delayed or triggered by
surface activities.
• This device is not intended for
commercial or professional dive
activities. It is for recreational purposes
only. Commercial or professional dive
activities can expose the user to
extreme depths or conditions that
increase the risk of DCS.
• Do not dive with a gas if you have not
personally verified its contents and
input the analyzed value to the device.
Failure to verify tank contents and
input the appropriate gas values to the
device will result in incorrect dive
planning information and could result
in serious injury or death.
• Diving with more than one gas mixture
presents a much greater risk than
diving with a single gas mixture.
Mistakes related to the use of multiple
gas mixtures may lead to serious injury
or death.
2
• After analyzing your gas, always round
down the result when inputting it to the
device. For example, if the analyzed
gas is 31.7% oxygen, input the gas as
31%. This buffer will result in more
conservative and safer calculations.
• Always ensure a safe ascent. A rapid
ascent increases the risk of DCS.
•Disabling the deco lockout feature on
the device can result in an increased
risk of DCS, which can result in
personal injury or death. Disable this
feature at your own risk.
• Violating a required decompression
stop may result in serious injury or
death. Never ascend above the
displayed decompression stop depth.
• Always perform a safety stop between
3 and 5 meters for 3 minutes, even if
no decompression stop is required.
• The maximum operating depth (MOD)
should not be exceeded. Disregarding
the alarm may result in serious injury
or death.
• Diving with a partial pressure of
oxygen (PO2) greater than 1.6, a
central nervous system (CNS) oxygen
toxicity exposure of 80% or greater, or
daily oxygen tolerance units (OTU) of
300 or greater can be hazardous, and
could result in serious injury or death.
Terminate the dive if you reach oxygen
toxicity levels.
• Traveling to a higher elevation,
including air travel, can temporarily
cause a change in the equilibrium of
dissolved nitrogen in the body. Always
acclimatize to new altitudes before and
after diving, because failure to do so
may result in personal injury or death.
Battery Warnings
A lithium-ion battery can be used in this
device.
If these guidelines are not followed,
batteries may experience a shortened life
span or may present a risk of damage to
the device, fire, chemical burn, electrolyte
leak, and/or injury.
• Do not disassemble, modify,
remanufacture, puncture or damage
the device or batteries.
•Do not remove or attempt to remove
the non-user-replaceable battery.
• Do not expose the device or batteries
to fire, explosion, or other hazard.
3
Health Warnings
• If you have a pacemaker or other
internal electronic device, consult your
physician before using a heart rate
monitor.
•The Garmin® optical wrist heart rate
monitor emits green light and flashes
occasionally. Consult your physician if
you have epilepsy or are sensitive to
flashing lights.
• Always consult your physician before
beginning or modifying any exercise
program.
• The Garmin device, accessories, heart
rate monitor, and related data are
intended to be used only for
recreational purposes and not for
medical purposes, and are not
intended to diagnose, monitor, treat,
cure, or prevent any disease or
condition.
• The heart rate readings are for
reference only, and no responsibility is
accepted for the consequences of any
erroneous readings.
• While the Garmin optical wrist heart
rate monitor technology typically
provides an accurate estimate of a
user's heart rate, there are inherent
limitations with the technology that
may cause some of the heart rate
readings to be inaccurate under certain
circumstances, including the user's
physical characteristics, fit of the
device, and type and intensity of
activity.
• Garmin activity trackers rely on
sensors that track your movement and
other metrics. The data and
information provided by these devices
is intended to be a close estimation of
your activity and metrics tracked, but
may not be completely accurate,
including step, sleep, distance, heart
rate, and calorie data.
Navigation Warnings
If your Garmin device uses or accepts
mapping products, follow these guidelines
to ensure safe navigating.
•Always carefully compare information
displayed on the device to all available
navigation sources, including
information from visual sightings, local
waterway rules and restrictions, and
maps. For safety, always resolve any
4
discrepancies or questions before
continuing navigation, and defer to
posed signs and conditions.
• Use this device only as a navigational
aid. Do not attempt to use the device
for any purpose requiring precise
measurement of direction, distance,
location, or topography.
Off-Road Navigation Warnings
If your Garmin device is able to suggest
off-road routes for various outdoor
activities, such as biking, hiking, and all-
terrain vehicles, follow these guidelines to
ensure safe off-road navigation.
•Always use your best judgment and
exercise common sense when making
off-road navigational decisions. The
Garmin device is designed to provide
route suggestions only. It is not a
replacement for attentiveness and
proper preparation for outdoor
activities. Do not follow the route
suggestions if they suggest an illegal
course or would put you in an unsafe
situation.
• Always carefully compare information
displayed on the device to all available
navigation sources, including trail
signs, trail conditions, weather
conditions, and other factors that may
affect safety while navigating. For
safety, always resolve any
discrepancies before continuing
navigation, and defer to posted signs
and conditions.
• Always be mindful of the effects of the
environment and the inherent risks of
the activity before embarking on off-
road activities, especially the impact
that weather and weather-related trail
conditions can have on the safety of
your activity. Ensure that you have the
proper gear and supplies for your
activity before navigating along
unfamiliar paths and trails.
NOTICE
Failure to heed the following notice could
result in personal or property damage, or
negatively impact the device functionality.
Battery Notices
• Do not leave the device exposed to a
heat source or in a high-temperature
location, such as in the sun in an
unattended vehicle. To prevent the
5
possibility of damage, remove the
device from the vehicle or store it out
of direct sunlight, such as in the glove
box.
• Do not operate the device outside of
the temperature ranges specified in the
printed manual in the product
packaging.
•When storing the device for an
extended time period, store within the
temperature ranges specified in the
printed manual in the product
packaging.
• Do not use a power and/or data cable
that is not approved or supplied by
Garmin.
• Contact your local waste disposal
department to dispose of the device/
batteries in accordance with applicable
local laws and regulations.
GPS Notice
The navigation device may experience
degraded performance if you use it in
proximity to any device that uses a
terrestrial broadband network operating
close to the frequencies used by any
Global Navigation Satellite System
(GNSS), such as the Global Positioning
Service (GPS). Use of such devices may
impair reception of GNSS signals.
Product Environmental Programs
Information about the Garmin product
recycling program and WEEE, RoHS,
REACH, and other compliance programs
can be found at www.garmin.com
/aboutGarmin/environment.
Declaration of Conformity
Hereby, Garmin declares that this product
is in compliance with the Directive
2014/53/EU. The full text of the EU
declaration of conformity is available at
the following internet address:
www.garmin.com/compliance.
Innovation, Science and Economic
Development Canada Compliance
This device complies with Innovation,
Science and Economic Development
Canada license-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must
accept any interference, including
interference that may cause undesired
operation of the device.
6
Radio Wave Exposure and SAR
Information
This product has been designed to
comply with applicable safety
requirements for exposure to radio
waves. These requirements are based on
scientific guidelines that include safety
margins designed to assure the safety of
all persons, regardless of age and health.
The radio wave exposure guidelines
employ a unit of measurement known as
the specific absorption rate (SAR). Tests
for SAR are conducted using
standardized methods with the product
transmitting at its highest certified power
level in all used frequency bands. The
product is designed to meet the relevant
guidelines for exposure to radio waves.
This device has been evaluated for and
shown compliant with the FCC and
ISEDC radio frequency (RF) exposure
limits. The unit of measurement for RF
exposure is SAR. The highest SAR value
for this product when tested for use on
the body is 0.28 W/kg (averaged over 1g)
with a value of 0.32 W/kg (averaged over
1 g) for simultaneous SAR.
SAR data information for residents in
countries that have adopted the SAR limit
recommended by the International
Commission of Non-Ionizing Radiation
Protection (ICNIRP), which is 0.08 W/kg
averaged over the whole body or 2.00
W/kg averaged over ten (10) gram of
tissue (for example, European Union,
Japan, Brazil and New Zealand): The
highest SAR value for this product when
tested for use on the body is 0.28 W/kg
(averaged over 1g) with a value of 0.32
W/kg (averaged over 1 g) for
simultaneous SAR.
FCC Compliance
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to
provide reasonable protection against
7
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and may cause harmful
interference to radio communications if
not installed and used in accordance with
the instructions. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one of the following
measures:
• Reorient or relocate the receiving
antenna.
•Increase the separation between the
equipment and the receiver.
• Connect the equipment into an outlet
that is on a different circuit from the
GPS device.
• Consult the dealer or an experienced
radio/TV technician for help.
This product does not contain any user-
serviceable parts. Repairs should only be
made by an authorized Garmin service
center. Unauthorized repairs or
modifications could result in permanent
damage to the equipment, and void your
warranty and your authority to operate
this device under Part 15 regulations.
Software License Agreement
BY USING THE DEVICE, YOU AGREE
TO BE BOUND BY THE TERMS AND
CONDITIONS OF THE FOLLOWING
SOFTWARE LICENSE AGREEMENT.
PLEASE READ THIS AGREEMENT
CAREFULLY.
Garmin Ltd. and its subsidiaries
(“Garmin”) grant you a limited license to
use the software embedded in this device
(the “Software”) in binary executable form
in the normal operation of the product.
Title, ownership rights, and intellectual
property rights in and to the Software
remain in Garmin and/or its third-party
providers.
You acknowledge that the Software is the
property of Garmin and/or its third-party
providers and is protected under the
United States of America copyright laws
and international copyright treaties. You
further acknowledge that the structure,
organization, and code of the Software,
8
for which source code is not provided, are
valuable trade secrets of Garmin and/or
its third-party providers and that the
Software in source code form remains a
valuable trade secret of Garmin and/or its
third-party providers. You agree not to
decompile, disassemble, modify, reverse
assemble, reverse engineer, or reduce to
human readable form the Software or any
part thereof or create any derivative
works based on the Software. You agree
not to export or re-export the Software to
any country in violation of the export
control laws of the United States of
America or the export control laws of any
other applicable country.
Map Data Information
Garmin uses a combination of
governmental and private data sources.
Virtually all data sources contain some
inaccurate or incomplete data. In some
countries, complete and accurate map
information is either not available or is
prohibitively expensive.
Limited Warranty
THIS LIMITED WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU
MAY HAVE OTHER LEGAL RIGHTS,
WHICH VARY FROM STATE TO STATE
(OR BY COUNTRY OR PROVINCE).
GARMIN DOES NOT EXCLUDE, LIMIT
OR SUSPEND OTHER LEGAL RIGHTS
YOU MAY HAVE UNDER THE LAWS OF
YOUR STATE (OR COUNTRY OR
PROVINCE). FOR A FULL
UNDERSTANDING OF YOUR RIGHTS
YOU SHOULD CONSULT THE LAWS
OF YOUR STATE, COUNTRY OR
PROVINCE.
Non-aviation products are warranted to
be free from defects in materials or
workmanship for one year from the date
of purchase. Within this period, Garmin
will, at its sole option, repair or replace
any components that fail in normal use.
Such repairs or replacement will be made
at no charge to the customer for parts or
labor, provided that the customer shall be
responsible for any transportation cost.
This Limited Warranty does not apply to:
(i) cosmetic damage, such as scratches,
nicks and dents; (ii) consumable parts,
such as batteries, unless product damage
has occurred due to a defect in materials
or workmanship; (iii) damage caused by
9
accident, abuse, misuse, water, flood,
fire, or other acts of nature or external
causes; (iv) damage caused by service
performed by anyone who is not an
authorized service provider of Garmin; (v)
damage to a product that has been
modified or altered without the written
permission of Garmin, or (vi) damage to a
product that has been connected to
power and/or data cables that are not
supplied by Garmin. In addition, Garmin
reserves the right to refuse warranty
claims against products or services that
are obtained and/or used in contravention
of the laws of any country. Garmin
navigation products are intended to be
used only as a travel aid and must not be
used for any purpose requiring precise
measurement of direction, distance,
location or topography. Garmin makes no
warranty as to the accuracy or
completeness of map data.
This Limited Warranty also does not
apply to, and Garmin is not responsible
for, any degradation in the performance
of any Garmin navigation product
resulting from its use in proximity to any
handset or other device that utilizes a
terrestrial broadband network operating
on frequencies that are close to the
frequencies used by any Global
Navigation Satellite System (GNSS) such
as the Global Positioning Service (GPS).
Use of such devices may impair reception
of GNSS signals.
TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW,
THE WARRANTIES AND REMEDIES
CONTAINED IN THIS LIMITED
WARRANTY ARE EXCLUSIVE AND IN
LIEU OF, AND GARMIN EXPRESSLY
DISCLAIMS, ALL OTHER WARRANTIES
AND REMEDIES, WHETHER EXPRESS,
IMPLIED, STATUTORY, OR
OTHERWISE, INCLUDING WITHOUT
LIMITATION ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE,
STATUTORY REMEDY OR
OTHERWISE. THIS LIMITED
WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE
OTHER LEGAL RIGHTS, WHICH VARY
FROM STATE TO STATE AND FROM
COUNTRY TO COUNTRY. IF IMPLIED
WARRANTIES CANNOT BE
10
DISCLAIMED UNDER THE LAWS OF
YOUR STATE OR COUNTRY, THEN
SUCH WARRANTIES ARE LIMITED IN
DURATION TO THE DURATION OF
THIS LIMITED WARRANTY. SOME
STATES (AND COUNTRIES AND
PROVINCES) DO NOT ALLOW
LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY
TO YOU.
IN NO EVENT SHALL GARMIN BE
LIABLE IN A CLAIM FOR BREACH OF
WARRANTY FOR ANY INCIDENTAL,
SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES,
WHETHER RESULTING FROM THE
USE, MISUSE OR INABILITY TO USE
THIS PRODUCT OR FROM DEFECTS
IN THE PRODUCT. SOME STATES
(AND COUNTRIES AND PROVINCES)
DO NOT ALLOW THE EXCLUSION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO
YOU.
If during the warranty period you submit a
claim for warranty service in accordance
with this Limited Warranty, then Garmin
will, at its option: (i) repair the device
using new parts or previously used parts
that satisfy Garmin's quality standards, (ii)
replace the device with a new device or a
refurbished device that meets Garmin's
quality standards, or (iii) exchange the
device for a full refund of your purchase
price. SUCH REMEDY SHALL BE YOUR
SOLE AND EXCLUSIVE REMEDY FOR
ANY BREACH OF WARRANTY.
Repaired or replaced devices have a 90
day warranty. If the unit sent in is still
under its original warranty, then the new
warranty is 90 days or to the end of the
original 1 year warranty, whichever is
longer.
Before seeking warranty service, please
access and review the online help
resources available on
support.garmin.com. If your device is still
not functioning properly after making use
of these resources, contact a Garmin
Authorized service facility in the original
country of purchase or follow the
instructions on support.garmin.com to
obtain warranty service. If you are in the
11
United States, you can also call
1-800-800-1020.
If you seek warranty service outside of
the original country of purchase, Garmin
cannot guarantee that the parts and
products needed to repair or replace your
product will be available due to
differences in product offerings and
applicable standards, laws and
regulations. In that case, Garmin may, in
its sole discretion and subject to
applicable laws, repair or replace your
product with comparable Garmin products
and parts, or require you to ship your
product to a Garmin Authorized service
facility in the country of original purchase
or to a Garmin Authorized service facility
in another country that can service your
product, in which case you will be
responsible for complying with all
applicable import and export laws and
regulations and for paying all custom
duties, V.A.T., shipping fees and other
associated taxes and charges. In some
cases, Garmin and its dealers may be
unable to service your product in a
country outside of the original country of
purchase or return a repaired or replaced
product to you in that country due to
applicable standards, laws or regulations
in that country.
Online Auction Purchases: Products
purchased through online auctions are
not eligible for rebates or other special
offers from Garmin warranty coverage.
Online auction confirmations are not
accepted for warranty verification. To
obtain warranty service, an original or
copy of the sales receipt from the original
retailer is required. Garmin will not
replace missing components from any
package purchased through an online
auction.
International Purchases: A separate
warranty may be provided by international
distributors for devices purchased outside
the United States depending on the
country. If applicable, this warranty is
provided by the local in-country distributor
and this distributor provides local service
for your device. Distributor warranties are
only valid in the area of intended
distribution.
Australian Purchases: Our goods come
with guarantees that cannot be excluded
under the Australian Consumer Law. You
12
are entitled to a replacement or refund for
a major failure and for compensation for
any other reasonably foreseeable loss or
damage. You are also entitled to have the
goods repaired or replaced if the goods
fail to be of acceptable quality and the
failure does not amount to a major failure.
The benefits under our Limited Warranty
are in addition to other rights and
remedies under applicable law in relation
to the products. Garmin Australasia, 30
Clay Place, Eastern Creek, NSW 2766,
Australia. Phone: 1800 235 822.
13
© 2017 Garmin Ltd. or its subsidiaries
Printed in Taiwan
October 2017
190-02068-23_0A
