VÍVOACTIVE® 3 MUSIC

Owner’s Manual

DRAFT

products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to www.garmin.com for current updates

and supplemental information concerning the use of this product.

Garmin®, the Garmin logo, ANT+®, Auto Lap®, Auto Pause®, Edge®, VIRB®, and vívoactive® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Connect

IQ™, Garmin Connect™, Garmin Express™, Garmin Golf™, Garmin Move IQ™, Garmin Pay™, tempe™, and Varia™ are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be

used without the express permission of Garmin.

American Heart Association® is a registered trademark of American Heart Association, Inc. Android™ is a trademark of Google, Inc. Apple® and iTunes® are trademarks of Apple Inc., registered in

the U.S. and other countries. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. Advanced heartbeat analytics by

Firstbeat. The Cooper Institute®, as well as any related trademarks, are the property of The Cooper Institute. The Verizon® name and all related product and service names are trademarks or

registered trademarks of Verizon and may not be used in any manner without the prior written consent of Verizon. Wi‑Fi® is a registered mark of Wi-Fi Alliance Corporation. Windows® is a

registered trademark of Microsoft Corporation in the United States and other countries. Other trademarks and trade names are those of their respective owners.

This product is ANT+® certified. Visit www.thisisant.com/directory for a list of compatible products and apps.

M/N: A03405

Table of Contents

Introduction.....................................................................1

Device Overview......................................................................... 1

Touchscreen Tips.................................................................. 1

Locking and Unlocking the Touchscreen.......................... 1

Using the Controls Menu....................................................... 1

Icons........................................................................................... 1

Smart Features............................................................... 1

Setting Up Your Smartwatch Features....................................... 1

Pairing Your Smartphone.......................................................2

Connecting to Verizon Services............................................. 2

Adding Contacts.....................................................................2

Sending a Message............................................................... 2

Connected Features................................................................... 2

Phone Notifications................................................................ 2

Enabling Bluetooth Notifications....................................... 2

Viewing Notifications......................................................... 2

Replying to a Text Message..............................................2

Receiving an Incoming Phone Call................................... 3

Managing Notifications...................................................... 3

Turning Off Bluetooth Technology.................................... 3

Using Do Not Disturb Mode................................................... 3

Finding Your Phone............................................................... 3

Connect IQ Features.................................................................. 3

Downloading Connect IQ Features........................................ 3

Downloading Connect IQ Features Using Your Computer.... 3

Wi‑Fi® Connected Features....................................................... 3

Setting Up Wi‑Fi Connectivity................................................ 3

Connecting to a Wi‑Fi Network.............................................. 3

Garmin Pay..................................................................... 4

Setting Up Your Garmin Pay Wallet........................................... 4

Paying for a Purchase Using Your Watch.................................. 4

Adding a Card to Your Garmin Pay Wallet................................. 4

Managing Your Garmin Pay Wallet........................................4

Changing Your Garmin Pay Passcode....................................... 4

Music............................................................................... 4

Connecting to a Third-Party Provider......................................... 4

Downloading Audio Content from a Third-Party Provider...... 5

Disconnecting from a Third-Party Provider............................ 5

Downloading Personal Audio Content........................................ 5

Connecting Headphones using Bluetooth Technology............... 5

Listening to Music....................................................................... 5

Music Playback Controls............................................................ 5

Emergency and Tracking Features............................... 5

Adding Emergency Contacts...................................................... 6

Heart Rate Features....................................................... 6

Wrist-based Heart Rate.............................................................. 6

Wearing the Device................................................................6

Tips for Erratic Heart Rate Data.............................................6

Viewing the Heart Rate Widget.............................................. 6

Broadcasting Heart Rate to Garmin Devices......................... 6

Turning Off the Wrist-based Heart Rate Monitor................... 6

About Heart Rate Zones............................................................. 6

Setting Your Heart Rate Zones.............................................. 6

Heart Rate Zone Calculations................................................ 7

About VO2 Max. Estimates.........................................................7

Getting Your VO2 Max. Estimate........................................... 7

Activity Tracking............................................................ 7

Auto Goal.................................................................................... 7

Using the Move Alert.................................................................. 7

Sleep Tracking............................................................................ 7

Intensity Minutes......................................................................... 7

Earning Intensity Minutes.......................................................7

Garmin Move IQ™...................................................................... 8

Activity Tracking Settings............................................................8

Turning Off Activity Tracking.................................................. 8

Widgets........................................................................... 8

Viewing Widgets......................................................................... 8

Customizing the Widget Loop................................................ 8

About My Day........................................................................ 8

Viewing the Weather Widget..................................................8

Heart Rate Variability and Stress Level...................................... 8

Using the Stress Level Widget............................................... 8

VIRB Remote.............................................................................. 9

Controlling a VIRB Action Camera.........................................9

Apps and Activities........................................................ 9

Starting an Activity...................................................................... 9

Tips for Recording Activities.................................................. 9

Stopping an Activity.................................................................... 9

Adding a Custom Activity............................................................ 9

Adding or Removing a Favorite Activity...................................... 9

Indoor Activities.......................................................................... 9

Recording a Strength Training Activity...................................9

Calibrating the Treadmill Distance....................................... 10

Outdoor Activities......................................................................10

Going for a Run....................................................................10

Going for a Ride................................................................... 10

Viewing Your Ski Runs........................................................ 10

Going for a Pool Swim.............................................................. 10

Setting the Pool Size............................................................10

Swim Terminology............................................................... 10

Golfing...................................................................................... 11

Downloading Golf Courses.................................................. 11

Playing Golf..........................................................................11

Hole Information...................................................................11

Changing the Pin Location.............................................. 11

Viewing the Direction to the Pin...................................... 11

Viewing Layup and Dogleg Distances................................. 11

Viewing Hazards.................................................................. 11

Measuring a Shot with the Garmin AutoShot™ Feature...... 11

Keeping Score..................................................................... 12

Setting the Scoring Method............................................. 12

Tracking Golf Statistics................................................... 12

Recording Golf Statistics................................................. 12

Viewing Your Shot History................................................... 12

Viewing Your Round Summary............................................ 12

Ending a Round................................................................... 12

Golf Settings........................................................................ 12

Scoring Settings.............................................................. 12

Garmin Golf App.................................................................. 12

Training......................................................................... 12

Setting Up Your User Profile.....................................................12

Fitness Goals....................................................................... 13

Workouts...................................................................................13

Following a Workout............................................................ 13

Using Garmin Connect Training Plans.................................13

Starting Today's Workout................................................ 13

Viewing Scheduled Workouts......................................... 13

Adaptive Training Plans....................................................... 13

Personal Records..................................................................... 13

Viewing Your Personal Records.......................................... 13

Restoring a Personal Record............................................... 13

Clearing a Personal Record................................................. 14

Clearing All Personal Records............................................. 14

Navigation..................................................................... 14

Saving Your Location............................................................... 14

Deleting a Location.............................................................. 14

Navigating to a Saved Location................................................ 14

Table of Contents i

Navigating Back to Start........................................................... 14

Stopping Navigation................................................................. 14

Compass...................................................................................14

Calibrating the Compass Manually...................................... 14

History........................................................................... 14

Using History............................................................................ 14

Viewing Your Time in Each Heart Rate Zone...................... 15

Garmin Connect........................................................................15

Using Garmin Connect Mobile............................................. 15

Using Garmin Connect on Your Computer.......................... 15

Customizing Your Device............................................ 15

Changing the Watch Face........................................................ 15

Creating a Custom Watch Face........................................... 15

Customizing the Controls Menu................................................15

Activities and App Settings....................................................... 16

Customizing the Data Screens............................................ 16

Alerts.................................................................................... 16

Setting an Alert................................................................16

Auto Lap...............................................................................16

Marking Laps Using the Auto Lap Feature..................... 16

Turning On the Manual Lap Function.................................. 17

Using Auto Pause®............................................................. 17

Using Auto Scroll................................................................. 17

Phone and Bluetooth Settings.................................................. 17

System Settings........................................................................ 17

Time Settings....................................................................... 17

Time Zones..................................................................... 17

Setting the Time Manually...............................................17

Setting the Alarm.............................................................17

Deleting an Alarm............................................................17

Starting the Countdown Timer........................................ 17

Using the Stopwatch....................................................... 18

Backlight Settings................................................................ 18

Changing the Units of Measure........................................... 18

Garmin Connect Settings..........................................................18

Device Settings on Your Garmin Connect Account............. 18

User Settings on Your Garmin Connect Account................ 18

Wireless Sensors......................................................... 18

Pairing Your Wireless Sensors................................................. 18

Foot Pod................................................................................... 19

Calibrating Your Foot Pod....................................................19

Improving Foot Pod Calibration........................................... 19

Using an Optional Bike Speed or Cadence Sensor.................. 19

Calibrating Your Speed Sensor........................................... 19

Situational Awareness.............................................................. 19

tempe........................................................................................ 19

Device Information....................................................... 19

Charging the Device................................................................. 19

Product Updates....................................................................... 19

Updating the Software Using Garmin Connect Mobile........ 20

Updating the Software Using Garmin Express.................... 20

Viewing Device Information...................................................... 20

Viewing E-label Regulatory and Compliance Information.... 20

Specifications............................................................................20

Device Care.............................................................................. 20

Cleaning the Device............................................................. 20

Replacing the Bands................................................................ 20

Troubleshooting........................................................... 20

Is my smartphone compatible with my device?........................ 20

My phone will not connect to the device................................... 20

My headphones will not connect to the device......................... 21

My music cuts out or my headphones do not stay connected.. 21

My device is in the wrong language......................................... 21

My device does not display the correct time............................. 21

Maximizing Battery Life.............................................................21

Restarting the Device............................................................... 21

Restoring All Default Settings................................................... 21

Acquiring Satellite Signals........................................................ 21

Improving GPS Satellite Reception......................................21

Activity Tracking........................................................................21

My daily step count does not appear................................... 22

My step count does not seem accurate............................... 22

The floors climbed amount does not seem accurate........... 22

Improving the Accuracy of Intensity Minutes and Calories.. 22

The temperature reading is not accurate.................................. 22

Getting More Information.......................................................... 22

Appendix....................................................................... 22

Data Fields................................................................................22

VO2 Max. Standard Ratings..................................................... 23

Wheel Size and Circumference................................................ 23

Symbol Definitions.................................................................... 24

Index.............................................................................. 25

ii Table of Contents

Introduction

WARNING

See the Important Safety and Product Information guide in the

product box for product warnings and other important

information.

Always consult your physician before you begin or modify any

exercise program.

Device Overview

ÀTouchscreen: Swipe up or down to scroll through widgets,

features, and menus.

Tap to select.

Swipe right to go back to the previous screen.

During an activity, swipe right to view the watch face and

widgets.

During an activity, double-tap to mark a new lap, start a new

set of reps, or advance to the next stage of a workout.

Hold to view a menu of device settings and options for the

current screen.

ÁKey: Press to turn on the device.

Hold for 2 seconds to view the controls menu, including

device power.

Hold for 5 seconds to request assistance (Emergency and

Tracking Features, page 5).

Press to return to the watch face from any screen, except

during an activity.

During an activity, press to pause the activity.

Touchscreen Tips

• Hold your finger on the touchscreen to view an options menu.

• Drag up or down to scroll through lists and menus.

• Swipe up or down to scroll quickly.

• Tap to select a button, a list item, or a menu item.

• From the watch face, swipe up or down to scroll through the

widgets on the device.

• From a widget, tap to view additional widget screens, if

available.

• During an activity, swipe up or down to view the next data

screen.

• During an activity, swipe right to view the watch face and

widgets, and swipe left to return to the activity data fields.

• Perform each menu selection as a separate action.

Locking and Unlocking the Touchscreen

You can lock the touchscreen to prevent inadvertent screen

touches.

1Hold the key.

2Select .

The touchscreen locks and does not respond to touches until

you unlock it.

3Hold the key to unlock the touchscreen.

Using the Controls Menu

The controls menu contains customizable shortcuts, such as

locking the touchscreen and turning the device off.

TIP: You can check the Verizon® connectivity signal strength or

Bluetooth® connection status.

NOTE: You can add, reorder, and remove the shortcuts in the

controls menu (Customizing the Controls Menu, page 15).

1From any screen, hold the key for 2 seconds.

2Select an option.

Icons

A flashing icon means the device is searching for a signal. A

solid icon means the signal was found or the sensor is

connected.

GPS status

Smartphone connection status

Heart rate monitor status

Foot pod status

LiveTrack status

Speed and cadence sensor status

Varia™ bike light status

Varia bike radar status

tempe™ sensor status

VIRB VIRB® camera status

vívoactive alarm status

Smart Features

Setting Up Your Smartwatch Features

To take full advantage of the vívoactive 3 Music smartwatch

features, complete these tasks.

• Pair your smartphone with the Garmin Connect™ app (Pairing

Your Smartphone, page 2).

• Connect with Verizon activation setup (Connecting to Verizon

Services, page 2).

• Add contacts (Adding Contacts, page 2).

• Send a message (Sending a Message, page 2).

• Set up safety features using the Garmin Connect app

(Emergency and Tracking Features, page 5).

• Download a music app using the Connect IQ™ store (Connect

IQ Features, page 3), and download songs onto the watch

(Music, page 4).

• Connect your Bluetooth headphones (Connecting

Headphones using Bluetooth Technology, page 5).

Introduction 1

• Set up your Garmin Pay™ wallet (Setting Up Your

Garmin Pay Wallet, page 4).

TIP: You should check the battery life and charge the device

before leaving on your first phone-free adventure (Charging the

Device, page 19).

Pairing Your Smartphone

To set up the vívoactive device, it must be paired directly

through the Garmin Connect app, instead of from the Bluetooth

settings on your smartphone.

1From the app store on your smartphone, install and open the

Garmin Connect app.

2Select an option to enable pairing mode on your device:

• If this is the first time you are setting up your device, press

the key to turn on the device.

• If you previously skipped the pairing process or paired

your device with a different smartphone, hold the

touchscreen, and select Settings > Phone > Pair Phone

to manually enter pairing mode.

3Select an option to add your device to your Garmin Connect

account:

• If this is the first device you have paired with the Garmin

Connect Mobile app, follow the on-screen instructions.

• If you have already paired another device with the Garmin

Connect Mobile app, from the settings menu, select

Garmin Devices > Add Device, and follow the on-screen

instructions.

Connecting to Verizon Services

1From the Garmin Connect app, select or .

2Select Garmin Devices, and select your device.

3Select LTE Connectivity.

4Follow the on-screen instructions.

Adding Contacts

You can add up to 20 contacts from the Garmin Connect app

and sync the contacts to your device. Three of these contacts

can be used as emergency contacts (Adding Emergency

Contacts, page 6). Contact emails can be used with the

LiveTrack feature.

1From the Garmin Connect app, select or .

2Select Contacts.

3Follow the on-screen instructions.

After you add contacts, you must sync your data to apply the

changes to your device (Using Garmin Connect Mobile,

page 15).

Sending a Message

Messages are limited to 320 characters.

1From the watch face, swipe right.

2Select to set up text messaging.

3Select .

4Follow the on-screen instructions.

5Select an option:

• Enter a number, and select .

• Select one or more contacts, and select Done.

6Select an option:

• Select and send a quick reply message.

• Select to send your location.

• Select to select and send an emoji.

• Select to enter a message, and select Send.

Connected Features

Connected features are available for your vívoactive device

when you connect the device to a compatible smartphone using

Bluetooth wireless technology. Some features require you to

install the Garmin Connect Mobile app on the connected

smartphone. Go to www.garmin.com/apps for more information.

Some features are also available when you connect your device

to a wireless network.

Phone notifications: Displays phone notifications and

messages on your vívoactive device.

LiveTrack: Allows friends and family to follow your races and

training activities in real time. You can invite followers using

email or social media, allowing them to view your live data on

a Garmin Connect tracking page.

Activity uploads to Garmin Connect: Automatically sends

your activity to your Garmin Connect account as soon as you

finish recording the activity.

Connect IQ: Allows you to extend your device features with new

watch faces, widgets, apps, and data fields.

Software Updates: Allows you to update your device software.

Weather: Allows you to view current weather conditions and

weather forecasts.

Bluetooth sensors: Allows you to connect Bluetooth

compatible sensors, such as a heart rate monitor.

Find my phone: Locates your lost smartphone that is paired

with your vívoactive device and currently within range.

Find my device: Locates your lost vívoactive device that is

paired with your smarphone and currently within range.

Phone Notifications

Phone notifications require a compatible smartphone to be in

range and paired with the device. When your phone receives

messages, it sends notifications to your device.

Enabling Bluetooth Notifications

Before you can enable notifications, you must pair the vívoactive

device with a compatible smartphone (Pairing Your Smartphone,

page 2).

1Hold the touchscreen.

2Select Settings > Phone > Notifications.

3Select During Activity to set preferences for notifications

that appear when recording an activity.

4Select a notification preference.

5Select Not During Activity to set preferences for

notifications that appear when in watch mode.

6Select a notification preference.

7Select Timeout.

8Select a timeout duration.

Viewing Notifications

1From the watch face, swipe to view the notifications widget.

2Select a notification.

3Scroll to read the full notification.

4Select an option:

• To act on the notification, select an action, such as

Dismiss or Reply.

The available actions depend on the type of notification

and your phone operating system.

• To return to the notification list, swipe right.

Replying to a Text Message

NOTE: This feature is available only for smartphones with

Android™.

When you receive a text message notification on your vívoactive

device, you can send a quick reply by selecting from a list of

2 Smart Features

messages. You can customize messages in the Garmin

Connect Mobile app.

NOTE: This feature sends text messages using your phone.

Regular text message limits and charges may apply. Contact

your mobile carrier for more information.

1Swipe to view the notifications widget.

2Select a text message notification.

3Select Reply.

4Select a message from the list.

Your phone sends the selected message as a text message.

Receiving an Incoming Phone Call

When you receive a phone call on your connected smartphone,

the vívoactive device displays the name or phone number of the

caller. You can accept or decline the call. If your device is

connected to a smartphone with Android, you can also decline

with a text message by selecting from a list of messages on your

vívoactive device.

• To accept the call, select .

• To decline the call, select .

• To decline the call and immediately send a text message

reply, select , and select a message from the list.

Managing Notifications

You can use your compatible smartphone to manage

notifications that appear on your vívoactive device.

Select an option:

• If you are using an Apple® smartphone, use the

notifications settings on your smartphone to select the

items to show on the device.

• If you are using a smartphone with Android, from the

Garmin Connect Mobile app, select Settings > Smart

Notifications.

Turning Off Bluetooth Technology

1Hold the touchscreen.

2Select Settings > Phone > Status > Off to turn off Bluetooth

wireless technology on your vívoactive device.

Refer to the owner's manual for your mobile device to turn off

Bluetooth wireless technology on your mobile device.

Using Do Not Disturb Mode

You can use do not disturb mode to turn off vibrations and the

backlight for alerts and notifications. For example, you can use

this mode while sleeping or watching a movie.

• To manually turn on or off do not disturb mode, hold the key,

and select .

• To automatically turn on do not disturb mode during your

sleep hours, go to the device settings in the Garmin Connect

Mobile app, and select Sounds & Alerts > Do Not Disturb

During Sleep.

Finding Your Phone

You can use this feature to help locate a lost smartphone that is

paired using Bluetooth wireless technology and currently within

range.

1Hold the key.

2Select .

Signal strength bars appear on the vívoactive screen, and an

audible alert sounds on your smartphone. The bars increase

as you move closer to your smartphone.

3Press the key to stop searching.

Connect IQ Features

You can add Connect IQ features to your watch from Garmin®

and other providers using the Connect IQ website. You can

customize your device with watch faces, data fields, widgets,

and apps.

Watch Faces: Allow you to customize the appearance of the

clock.

Data Fields: Allow you to download new data fields that present

sensor, activity, and history data in new ways. You can add

Connect IQ data fields to built-in features and pages.

Widgets: Provide information at a glance, including sensor data

and notifications.

Apps: Add interactive features to your watch, such as new

outdoor and fitness activity types.

Downloading Connect IQ Features

Before you can download Connect IQ features from the Garmin

Connect Mobile app, you must pair your vívoactive device with

your smartphone.

1From the settings in the Garmin Connect Mobile app, select

Connect IQ Store.

2If necessary, select your device.

3Select a Connect IQ feature.

4Follow the on-screen instructions.

Downloading Connect IQ Features Using Your

Computer

1Connect the device to your computer using a USB cable.

2Go to apps.garmin.com, and sign in.

3Select a Connect IQ feature, and download it.

4Follow the on-screen instructions.

Wi‑Fi® Connected Features

The vívoactive device has Wi‑Fi connected features.

Activity uploads to your Garmin Connect account:

Automatically sends your activity to your Garmin Connect

account as soon as you finish recording the activity.

Workouts and training plans: Allows you to browse for and

select workouts and training plans on the Garmin Connect

site. The next time your device has a Wi‑Fi connection, the

files are wirelessly sent to your device.

Software updates: Your device downloads and installs the

latest software update automatically when a Wi‑Fi connection

is available.

Setting Up Wi‑Fi Connectivity

1Select an option:

• Download the Garmin Connect Mobile app, and pair your

smartphone (Pairing Your Smartphone, page 2).

• Go to www.garmin.com/express, and download the

Garmin Express™ application.

2Follow the on-screen instructions to set up Wi‑Fi connectivity.

Connecting to a Wi‑Fi Network

You must connect your device to the Garmin Connect Mobile

app on your smartphone or to the Garmin Express application

on your computer before you can connect to a Wi‑Fi network

(Setting Up Wi

‑

Fi Connectivity, page 3).

You can connect the device to a Wi‑Fi network to help increase

the transfer speed of larger files.

1Move within range of a Wi‑Fi network.

2From the Garmin Connect Mobile app, select or .

3Select Garmin Devices, and select your device.

4Select General > Wi-Fi Networks > Add a Network.

5Select an available Wi‑Fi network, and enter the login details.

Smart Features 3

Garmin Pay

The Garmin Pay feature allows you to use your watch to pay for

purchases in participating stores using credit or debit cards from

a participating financial institution.

Setting Up Your Garmin Pay Wallet

You can add one or more participating credit or debit cards to

your Garmin Pay wallet. Go to garmin.com/garminpay/banks to

find participating financial institutions.

1From the Garmin Connect Mobile app, select or .

2Select Garmin Devices, and select your device.

3Select Garmin Pay > Create Your Wallet.

4Follow the on-screen instructions.

Paying for a Purchase Using Your Watch

Before you can use your watch to pay for purchases, you must

set up at least one payment card.

You can use your watch to pay for purchases in a participating

store.

1Hold the key.

2Select .

3Enter your four-digit passcode.

NOTE: If you enter your passcode incorrectly three times,

your wallet locks, and you must reset your passcode in the

Garmin Connect Mobile app.

Your most recently used payment card appears.

4If you have added multiple cards to your Garmin Pay wallet,

swipe to change to another card (optional).

5Within 60 seconds, hold your watch near the payment reader,

with the watch facing the reader.

The watch vibrates and displays a check mark when it is

finished communicating with the reader.

6If necessary, follow the instructions on the card reader to

complete the transaction.

TIP: After you successfully enter your passcode, you can make

payments without a passcode for 24 hours while you continue to

wear your watch. If you remove the watch from your wrist or

disable heart rate monitoring, you must enter the passcode

again before making a payment.

Adding a Card to Your Garmin Pay Wallet

You can add up to ten credit or debit cards to your Garmin Pay

wallet.

1From the vívoactive device page in the Garmin Connect

Mobile app, select Garmin Pay > .

2Follow the on-screen instructions to enter the card

information and add the card to your wallet.

After the card is added, you can select the card on your watch

when you make a payment.

Managing Your Garmin Pay Wallet

You can view detailed information about each of your payment

cards, and you can suspend, activate, or delete a card. You can

also suspend or delete your whole Garmin Pay wallet.

NOTE: In some countries, participating financial institutions may

restrict the wallet features.

1From the vívoactive device page in the Garmin Connect

Mobile app, select Garmin Pay > Manage Your Wallet.

2Select an option:

• To suspend a specific card, select the card, and select

Suspend.

The card must be active to make purchases using your

vívoactive device.

• To temporarily suspend all cards in your wallet, select

Suspend Wallet.

You cannot pay using your vívoactive device until you

unsuspend at least one card using the app.

• To unsuspend your suspended wallet, select Unsuspend

Wallet.

• To delete a specific card, select the card, and select

Delete.

The card is completely deleted from your wallet. If you

want to add this card to your wallet in the future, you must

enter the card information again.

• To delete all cards in your wallet, select Delete Wallet.

Your Garmin Pay wallet and all the card information

associated with it are deleted. You cannot pay using your

vívoactive device until you create a new wallet and add a

card.

Changing Your Garmin Pay Passcode

You must know your current passcode to change it. Your

passcode cannot be recovered. If you forget your passcode, you

must delete your wallet, create a new one, and reenter your card

information.

You can change the passcode required to access your

Garmin Pay wallet on your vívoactive device.

1From the vívoactive device page in the Garmin Connect

Mobile app, select Garmin Pay > Reset Passcode.

2Follow the on-screen instructions.

The next time you pay using your vívoactive device, you must

enter the new passcode.

Music

NOTE: This section is about three different music playback

options.

• Third-party provider music

• Personal audio content

• Music stored on your phone

On a vívoactive 3 Music device, you can download audio

content to your device from your computer or from a third-party

provider, so you can listen when your smartphone is not nearby.

To listen to audio content stored on your device, you must

connect headphones with Bluetooth technology.

You can also control music playback on your paired smartphone

using your device.

Connecting to a Third-Party Provider

Before you can download music or other audio files to your

compatible watch from a supported third-party provider, you

must connect to the provider using the Garmin Connect app.

1From the Garmin Connect app, select or .

2Select Garmin Devices, and select your device.

3Select Music.

4Select Get Music Apps, locate a provider, and follow the on-

screen instructions.

4 Garmin Pay

NOTE: If you have already installed a provider, you can

select it and follow the on-screen instructions.

Downloading Audio Content from a Third-Party

Provider

Before you can download audio content from a third-party

provider, you must connect to a Wi‑Fi network (Connecting to a

‑

Fi Network, page 3).

1Open the music controls widget.

2Select > Manage > Music Providers.

3Select a connected provider.

4Select a playlist or other item to download to the device.

5Swipe right, and select .

6When you are prompted to sync with the service, select .

7Connect the device to an external power source.

Downloading audio content can drain the battery.

The selected playlists and other items are downloaded to the

device.

Disconnecting from a Third-Party Provider

1From the Garmin Connect Mobile app, select or .

2Select Garmin Devices, and select your device.

3Select Music.

4Select an installed third-party provider, and follow the on-

screen instructions to disconnect the third-party provider from

your device.

Downloading Personal Audio Content

Before you can send your personal music to your device, you

must install the Garmin Express application on your computer

(www.garmin.com/express).

You can load your personal audio files, such as .mp3 and .aac

files, to a vívoactive 3 Music device from your computer.

1Connect the device to your computer using the included USB

cable.

2On your computer, open the Garmin Express application,

select your device, and select Music.

TIP: For Windows® computers, you can select and browse

to the folder with your audio files. For Apple computers, the

Garmin Express application uses your iTunes® library.

3In the My Music or iTunes Library list, select an audio file

category, such as songs or playlists.

4Select the checkboxes for the audio files, and select Send to

Device.

5If necessary, in the vívoactive 3 Music list, select a category,

select the checkboxes, and select Remove From Device to

remove audio files.

Connecting Headphones using Bluetooth

Technology

To listen to music loaded onto your vívoactive 3 Music device,

you must connect headphones using Bluetooth technology.

1Bring the headphones within 2 m (6.6 ft.) of your device.

2Enable pairing mode on the headphones.

3Hold the touchscreen.

4Select Settings > Sensors & Accessories > Add New >

Headphones.

5Select your headphones to complete the pairing process.

Listening to Music

1Open the music controls widget.

2Connect your headphones with Bluetooth technology

(Connecting Headphones using Bluetooth Technology,

page 5).

3Select > .

NOTE: The icon at the top indicates the music source. You

can tap to change the source.

4Select an option:

• To listen to music from a third-party provider, select the

name of the provider.

• To listen to music downloaded to the watch from your

computer, select My Music (Downloading Personal Audio

Content, page 5).

• To listen to music from your smartphone, select Control

Music on Phone.

5Select to open the music playback controls.

Music Playback Controls

Manage Select to manage content from third-party providers.

Select to switch the music Source.

Select to browse the audio files and playlists for the selected

source.

Select to adjust the volume.

Select to play and pause the current audio file.

Select to skip to the next audio file in the playlist.

Hold to fast forward through the current audio file.

Select to restart the current audio file.

Select twice to skip to the previous audio file in the playlist.

Hold to rewind through the current audio file.

Select to change the repeat mode.

Select to change the shuffle mode.

Emergency and Tracking Features

CAUTION

Incident detection and assistance are supplemental features and

should not be relied on as a primary method to obtain

emergency assistance. The device and app do not contact

emergency services on your behalf.

The vívoactive device has emergency and tracking features that

must be set up with the Garmin Connect app. To use these

features, you must have Verizon connectivity or be connected to

the Garmin Connect app.

LiveTrack: Allows friends and family to follow your races and

training activities in real time. You can invite followers using

email or social media, allowing them to view your live data on

a Garmin Connect tracking page.

Incident detection: Sends a message to your emergency

contacts when the vívoactive device detects an incident

during a walk, run, or bike activity.

Emergency and Tracking Features 5

Assistance: Allows you to send an automated text message

with your name and GPS location to your emergency

contacts.

Adding Emergency Contacts

Emergency contact phone numbers are used for the incident

detection and assistance features.

1From the Garmin Connect app, select or .

2Select Safety & Tracking > Incident Detection &

Assistance > Add Emergency Contact.

3Follow the on-screen instructions.

Heart Rate Features

The vívoactive device has a wrist-based heart rate monitor and

is also compatible with chest heart rate monitors (sold

separately). You can view heart rate data on the heart rate

widget. If both wrist-based heart rate and chest heart rate data

are available, your device uses the chest heart rate data.

Wrist-based Heart Rate

Wearing the Device

• Wear the device above your wrist bone.

NOTE: The device should be snug but comfortable. For more

accurate heart rate readings on the vívoactive device, it

should not move while running or exercising.

NOTE: The optical sensor is located on the back of the

device.

• See Tips for Erratic Heart Rate Data, page 6 for more

information about wrist-based heart rate.

• For more information about accuracy, go to garmin.com

/ataccuracy.

Tips for Erratic Heart Rate Data

If the heart rate data is erratic or does not appear, you can try

these tips.

• Clean and dry your arm before putting on the device.

• Avoid wearing sunscreen, lotion, and insect repellent under

the device.

• Avoid scratching the heart rate sensor on the back of the

device.

• Wear the device above your wrist bone. The device should

be snug but comfortable.

• Wait until the icon is solid before starting your activity.

• Warm up for 5 to 10 minutes and get a heart rate reading

before starting your activity.

NOTE: In cold environments, warm up indoors.

• Rinse the device with fresh water after each workout.

Viewing the Heart Rate Widget

The heart rate widget displays your current heart rate in beats

per minute (bpm) and a graph of your heart rate. The graph

shows your recent heart rate activity, high and low heart rate,

and color-coded bars to indicate the time spent in each heart

rate zone (About Heart Rate Zones, page 6).

1From the watch face, swipe to view the heart rate widget.

2Tap the touchscreen to view your average resting heart rate

(RHR) values for the last 7 days.

Broadcasting Heart Rate to Garmin Devices

You can broadcast your heart rate data from your vívoactive

device and view it on paired Garmin devices. For example, you

can broadcast your heart rate data to an Edge® device while

cycling, or to a VIRB action camera during an activity.

NOTE: Broadcasting heart rate data decreases battery life.

1Hold the touchscreen.

2Select Settings > Sensors & Accessories > Heart Rate.

3Select an option:

• Select Broadcast In Activity to broadcast heart rate data

during timed activities (Starting an Activity, page 9).

• Select Broadcast to start broadcasting heart rate data

now.

4Pair your vívoactive device with your Garmin ANT+®

compatible device.

NOTE: The pairing instructions differ for each Garmin

compatible device. See your owner's manual.

Turning Off the Wrist-based Heart Rate Monitor

For the vívoactive device, the default value for the Heart Rate

setting is Auto. The device automatically uses the wrist-based

heart rate monitor unless you pair a chest heart rate monitor to

the device.

NOTE: Disabling the wrist-based heart rate monitor also

disables the on-wrist detection feature for Garmin Pay

payments, and you must enter a passcode before making each

payment (Garmin Pay, page 4).

1Hold the touchscreen.

2Select Settings > Sensors & Accessories > Heart Rate >

Off.

About Heart Rate Zones

Many athletes use heart rate zones to measure and increase

their cardiovascular strength and improve their level of fitness. A

heart rate zone is a set range of heartbeats per minute. The five

commonly accepted heart rate zones are numbered from 1 to 5

according to increasing intensity. Generally, heart rate zones are

calculated based on percentages of your maximum heart rate.

Setting Your Heart Rate Zones

The device uses your user profile information from the initial

setup to determine your default heart rate zones. The device

has separate heart rate zones for running and cycling. For the

most accurate calorie data during your activity, you should set

your maximum heart rate. You can also set each heart rate

zone. You can manually adjust your zones on the device or

using your Garmin Connect account.

1Hold the touchscreen.

2Select Settings > User Profile > Heart Rate Zones.

3Select Default to view the default values (optional).

The default values can be applied to running and cycling.

4Select Running or Cycling.

5Select Preference > Set Custom.

6 Heart Rate Features

6Select Max. HR, and enter your maximum heart rate.

7Select a zone, and enter a value for each zone.

Heart Rate Zone Calculations

Zone % of

Maximum

Heart Rate

Perceived Exertion Benefits

1 50–60% Relaxed, easy pace,

rhythmic breathing

Beginning-level

aerobic training,

reduces stress

2 60–70% Comfortable pace,

slightly deeper

breathing, conversation

possible

Basic cardiovascular

training, good

recovery pace

3 70–80% Moderate pace, more

difficult to hold

conversation

Improved aerobic

capacity, optimal

cardiovascular training

4 80–90% Fast pace and a bit

uncomfortable, breathing

forceful

Improved anaerobic

capacity and

threshold, improved

speed

5 90–100% Sprinting pace,

unsustainable for long

period of time, labored

breathing

Anaerobic and

muscular endurance,

increased power

About VO2 Max. Estimates

VO2 max. is the maximum volume of oxygen (in milliliters) you

can consume per minute per kilogram of body weight at your

maximum performance. In simple terms, VO2 max. is an

indication of athletic performance and should increase as your

level of fitness improves.

On the device, your VO2 max. estimate appears as a number

and description. On your Garmin Connect account, you can view

additional details about your VO2 max. estimate, including your

fitness age. Your fitness age gives you an idea of how your

fitness compares with a person of the same gender and different

age. As you exercise, your fitness age can decrease over time.

VO2 max. data is provided by FirstBeat. VO2 max. analysis is

provided with permission from The Cooper Institute®. For more

information, see the appendix (VO2 Max. Standard Ratings,

page 23), and go to www.CooperInstitute.org.

Getting Your VO2 Max. Estimate

The device requires heart rate data and a timed, (up to 15

minutes) brisk walk or run to display your VO2 max. estimate.

1Hold the touchscreen.

2Select My Stats > VO2 Max.

If you have already recorded a brisk walk or run outdoors,

your VO2 max. estimate may appear. The device displays

the date your VO2 max. estimate was last updated. The

device updates your VO2 max. estimate each time you

complete an outdoor walk or run of 15 minutes or longer. You

can manually start a VO2 max. test to get an updated

estimate.

3To start a VO2 max. test, swipe up, and select Test Now.

4Follow the on-screen instructions to get your VO2 max.

estimate.

A message appears when the test is complete.

Activity Tracking

The activity tracking feature records your daily step count,

distance traveled, intensity minutes, floors climbed, calories

burned, and sleep statistics for each recorded day. Your calories

burned includes your base metabolism plus activity calories.

The number of steps taken during the day appears on the steps

widget. The step count is updated periodically.

For more information about activity tracking and fitness metric

accuracy, go to garmin.com/ataccuracy.

Auto Goal

Your device creates a daily step goal automatically, based on

your previous activity levels. As you move during the day, the

device shows your progress toward your daily goal À.

If you choose not to use the auto goal feature, you can set a

personalized step goal on your Garmin Connect account.

Using the Move Alert

Sitting for prolonged periods of time can trigger undesirable

metabolic state changes. The move alert reminds you to keep

moving. After one hour of inactivity, Move! and the red bar

appear. Additional segments appear after every 15 minutes of

inactivity. The device also vibrates if vibration is turned on

(System Settings, page 17).

Go for a short walk (at least a couple of minutes) to reset the

move alert.

Sleep Tracking

While you are sleeping, the device automatically detects your

sleep and monitors your movement during your normal sleep

hours. You can set your normal sleep hours in the user settings

on your Garmin Connect account. Sleep statistics include total

hours of sleep, sleep levels, and sleep movement. You can view

your sleep statistics on your Garmin Connect account.

NOTE: Naps are not added to your sleep statistics. You can use

do not disturb mode to turn off notifications and alerts, with the

exception of alarms (Using Do Not Disturb Mode, page 3).

Intensity Minutes

To improve your health, organizations such as the U.S. Centers

for Disease Control and Prevention, the American Heart

Association®, and the World Health Organization, recommend at

least 150 minutes per week of moderate intensity activity, such

as brisk walking, or 75 minutes per week of vigorous intensity

activity, such as running.

The device monitors your activity intensity and tracks your time

spent participating in moderate to vigorous intensity activities

(heart rate data is required to quantify vigorous intensity). You

can work toward achieving your weekly intensity minutes goal by

participating in at least 10 consecutive minutes of moderate to

vigorous intensity activities. The device adds the amount of

moderate activity minutes with the amount of vigorous activity

minutes. Your total vigorous intensity minutes are doubled when

added.

Earning Intensity Minutes

Your vívoactive device calculates intensity minutes by

comparing your heart rate data to your average resting heart

rate. If heart rate is turned off, the device calculates moderate

intensity minutes by analyzing your steps per minute.

• Start a timed activity for the most accurate calculation of

intensity minutes.

• Exercise for at least 10 consecutive minutes at a moderate or

vigorous intensity level.

• Wear your device all day and night for the most accurate

resting heart rate.

Activity Tracking 7

Garmin Move IQ™

When your movements match familiar exercise patterns, the

Move IQ feature automatically detects the event and displays it

in your timeline. The Move IQ events show activity type and

duration, but they do not appear in your activities list or

newsfeed.

The Move IQ feature can automatically start a timed activity for

walking and running using time thresholds you set in the Garmin

Connect Mobile app. These activities are added to your activities

list.

Activity Tracking Settings

Hold the touchscreen, and select Settings > Activity

Tracking.

Status: Turns off the activity tracking features.

Move Alert: Displays a message and the move bar on the

digital watch face and steps screen. The device also vibrates

to alert you.

Goal Alerts: Allows you to turn on and off goal alerts, or turn

them off only during activities. Goal alerts appear for your

daily steps goal, daily floors climbed goal, and weekly

intensity minutes goal.

Intensity Minutes: Allows you to set a heart rate zone for

moderate intensity minutes and a higher heart rate zone for

vigorous intensity minutes. You can also use the default

algorithm.

Move IQ: Allows you to turn on and off Move IQ events.

Turning Off Activity Tracking

When you turn off activity tracking, your steps, floors climbed,

intensity minutes, sleep tracking, and Move IQ events are not

recorded.

1Hold the touchscreen.

2Select Settings > Activity Tracking > Status > Off.

Widgets

Your device comes preloaded with widgets that provide at-a-

glance information. Some widgets require a Bluetooth

connection to a compatible smartphone.

Some widgets are not visible by default. You can add them to

the widget loop manually.

Calendar: Displays upcoming meetings from your smartphone

calendar.

Calories: Displays your calorie information for the current day.

Floors climbed: Tracks your floors climbed and progress

toward your goal.

Golf: Displays golf information for your last round.

Heart rate: Displays your current heart rate in beats per minute

(bpm) and a graph of your heart rate.

Intensity minutes: Tracks your time spent participating in

moderate to vigorous activities, your weekly intensity minutes

goal, and progress toward your goal.

Last sport: Displays a brief summary of your last recorded

sport.

Music controls: Provides music player controls for your

smartphone or on-device music.

My day: Displays a dynamic summary of your activity today. The

metrics include timed activities, intensity minutes, floors

climbed, steps, calories burned, and more.

Notifications: Alerts you to incoming calls, texts, social network

updates, and more, based on your smartphone notification

settings.

Steps: Tracks your daily step count, step goal, and data for

previous days.

Stress: Displays your current stress level and a graph of your

stress level. You can do a breathing activity to help you relax.

VIRB controls: Provides camera controls when you have a

VIRB device paired with your vívoactive device.

Weather: Displays the current temperature and weather

forecast.

Viewing Widgets

From the watch face, swipe up or down.

Customizing the Widget Loop

1Hold the touchscreen.

2Select Settings > Widgets.

3Select an option:

• Select an item to show or hide it from the app list or

rearrange the app list.

• Select Add to add an item to the widget loop.

About My Day

The My Day widget is a daily snapshot of your activity. This is a

dynamic summary that updates throughout the day. As soon as

you climb a flight of stairs or record an activity, it appears in the

widget. The metrics include recorded activities, intensity minutes

for the week, floors climbed, steps, calories burned, and more.

You can tap the touchscreen for an option to improve accuracy

or to view additional metrics.

Viewing the Weather Widget

1From the watch face, swipe to view the weather widget.

2Tap the touchscreen to view hourly and daily weather data.

3Scroll down to view daily weather data.

Heart Rate Variability and Stress Level

Your device analyzes your heart rate variability while you are

inactive to determine your overall stress. Training, physical

activity, sleep, nutrition, and general life stress all impact your

stress level. The stress level range is from 0 to 100, where 0 to

25 is a resting state, 26 to 50 is low stress, 51 to 75 is medium

stress, and 76 to 100 is a high stress state. Knowing your stress

level can help you identify stressful moments throughout your

day. For best results, you should wear the device while sleeping.

You can sync your device with your Garmin Connect account to

view your all-day stress level, long-term trends, and additional

details.

Using the Stress Level Widget

The stress level widget displays your current stress level and a

graph of your stress level for the last several hours. It can also

guide you through a breathing activity to help you relax.

1While you are sitting or inactive, swipe to view the stress

level widget.

TIP: If you are too active for the watch to determine your

stress level, a message appears instead of a stress level

number. You can check your stress level again after several

minutes of inactivity.

2Tap the touchscreen to view a graph of your stress level for

the last four hours.

8 Widgets

Blue bars indicate periods of rest. Yellow bars indicate

periods of stress. Gray bars indicate times that you were too

active to determine your stress level.

3To start a breathing activity, swipe up, select Yes, and enter

a duration for the breathing activity in minutes.

VIRB Remote

The VIRB remote function allows you to control your VIRB

action camera using your device. Go to www.garmin.com/VIRB

to purchase a VIRB action camera.

Controlling a VIRB Action Camera

Before you can use the VIRB remote function, you must enable

the remote setting on your VIRB camera. See the VIRB Series

Owner's Manual for more information. You must also set the

VIRB widget to be shown in the widget loop (Customizing the

Widget Loop, page 8).

1Turn on your VIRB camera.

2On your vívoactive device, swipe to view the VIRB widget.

3Wait while the device connects to your VIRB camera.

4Select an option:

• To record video, tap the touchscreen.

The video counter appears on the vívoactive screen.

• To stop recording video, tap the touchscreen.

• To take a photo, swipe right, and tap the touchscreen.

Apps and Activities

Your device includes a variety of preloaded apps and activities.

Apps: Apps provide interactive features for your device, such as

navigating to saved locations.

Activities: Your device comes preloaded with indoor and

outdoor activity apps, including running, cycling, strength

training, golfing, and more. When you start an activity, the

device displays and records sensor data, which you can save

and share with the Garmin Connect community.

For more information about activity tracking and fitness metric

accuracy, go togarmin.com/ataccuracy.

Connect IQ Apps: You can add features to your watch by

installing apps from the Connect IQ mobile app (Connect IQ

Features, page 3).

Starting an Activity

When you start an activity, GPS turns on automatically (if

required).

1Press the key.

2If this is the first time you have started an activity, select the

checkbox next to each activity to add to your favorites, and

select Done.

3Select an option:

• Select an activity from your favorites.

• Select , and select an activity from the extended activity

list.

4If the activity requires GPS signals, go outside to an area with

a clear view of the sky.

TIP: If appears on a gray background, the activity does

not require GPS signals.

5Wait until Ready appears on the screen.

The device is ready after it establishes your heart rate,

acquires GPS signals (if required), and connects to your

wireless sensors (if required).

6Press the key to start the activity timer.

The device records activity data only while the activity timer is

running.

Tips for Recording Activities

• Charge the device before starting an activity (Charging the

Device, page 19).

• Swipe up or down to view additional data pages.

Stopping an Activity

1Press the key.

2Select Done.

3Select an option:

• To save the activity, select .

• To discard the activity, select .

Adding a Custom Activity

You can create a custom activity and add it to the activity list.

1Press the key.

2Select > > Create.

3Select an activity type.

4If necessary, edit the activity app settings (Activities and App

Settings, page 16).

5When you are finished editing, select Done.

6Select an option:

• To add the activity to your favorites list, select .

• To add the activity to the extended list, select .

Adding or Removing a Favorite Activity

The list of your favorite activities appears when you press the

key from the watch face, and it provides quick access to the

activities you use most. The first time you press the key to start

an activity, the device prompts you to select your favorite

activities. You can add or remove favorite activities at any time.

1Hold the touchscreen.

2Select Settings > Activities & Apps.

Your favorite activities appear at the top of the list with a

white background. Other activities appear in the extended list

with a black background.

3Select an option:

• To add a favorite activity, select the activity, and select

Add Favorite.

• To remove a favorite activity, select the activity, and select

Remove Favorite.

Indoor Activities

The vívoactive device can be used for training indoors, such as

running on an indoor track or using a stationary bike. GPS is

turned off for indoor activities.

When running or walking with GPS turned off, speed, distance,

and cadence are calculated using the accelerometer in the

device. The accelerometer is self-calibrating. The accuracy of

the speed, distance, and cadence data improves after a few

outdoor runs or walks using GPS.

TIP: Holding the handrails of the treadmill reduces accuracy.

You can use an optional foot pod to record pace, distance, and

cadence.

When cycling with GPS turned off, speed and distance are not

available unless you have an optional sensor that sends speed

and distance data to the device (such as a speed or cadence

sensor).

Recording a Strength Training Activity

You can record sets during a strength training activity. A set is

multiple repetitions (reps) of a single move.

Apps and Activities 9

1Press the key.

2Select Strength.

3Press the key to start the activity timer.

4Start your first set.

The device counts your reps. Your rep count appears when

you complete at least 6 reps.

TIP: The device can only count reps of a single move for

each set. When you want to change moves, you should finish

the set and start a new one.

5Double tap the touchscreen to finish the set.

The watch displays the total reps for the set. After several

seconds, the rest timer appears.

6If necessary, hold the touchscreen, select Edit Last Set, and

edit the number of reps.

7When you are done resting, double tap the touchscreen to

start your next set.

8Repeat for each strength training set until your activity is

complete.

9After your last set, press the key to stop the timer.

10Select Done > to finish and save the activity.

Calibrating the Treadmill Distance

To record more accurate distances for your treadmill runs, you

can calibrate the treadmill distance after you run at least 1.5 km

(1 mi.) on a treadmill. If you use different treadmills, you can

manually calibrate the treadmill distance on each treadmill or

after each run.

1Start a treadmill activity (Starting an Activity, page 9), and run

at least 1.5 km (1 mi.) on the treadmill.

2After you complete your run, press the key, and select Done.

3Select an option:

• To calibrate the treadmill distance the first time, select .

The device prompts you to complete the treadmill

calibration.

• To manually calibrate the treadmill distance after the first-

time calibration, select > Calibrate.

4Check the treadmill display for the distance traveled, and

enter the distance on your device.

Outdoor Activities

The vívoactive device comes preloaded with apps for outdoor

activities, such as running and biking. GPS is turned on for

outdoor activities. You can add apps using default activities,

such as cardio or rowing.

Going for a Run

Before you can use a wireless sensor for your run, you must pair

the sensor with your device (Pairing Your Wireless Sensors,

page 18).

1Put on your wireless sensors, such as a foot pod or heart rate

monitor (optional).

2Press the key.

3Select Run.

4When using optional wireless sensors, wait while the device

connects to the sensors.

5Go outside, and wait while the device locates satellites.

6Press the key to start the activity timer.

The device records activity data only while the activity timer is

running.

7Start your activity.

8Swipe up or down to scroll through data screens.

9After you complete your activity, press the key, and select

to save the activity.

Going for a Ride

Before you can use a wireless sensor for your ride, you must

pair the sensor with your device (Pairing Your Wireless Sensors,

page 18).

1Pair your wireless sensors, such as a heart rate monitor,

speed sensor, or cadence sensor (optional).

2Press the key.

3Select Bike.

4When using optional wireless sensors, wait while the device

connects to the sensors.

5Go outside, and wait while the device locates satellites.

6Press the key to start the activity timer.

The device records activity data only while the activity timer is

running.

7Start your activity.

8Swipe up or down to scroll through data screens.

9After you complete your activity, press the key, and select

to save the activity.

Viewing Your Ski Runs

Your device records the details of each downhill skiing or

snowboarding run using the auto run feature. This feature is

turned on by default for downhill skiing and snowboarding. It

automatically records new ski runs based on your movement.

The timer pauses when you stop moving downhill and when you

are on a chairlift. The timer remains paused during the chairlift

ride. You can start moving downhill to restart the timer. You can

view run details from the paused screen or while the timer is

running.

1Start a skiing or snowboarding activity.

2Hold the touchscreen.

3Select View Runs.

4Select and to view details of your last run, your current run,

and your total runs.

The run screens include time, distance traveled, maximum

speed, average speed, and total descent.

Going for a Pool Swim

NOTE: Heart rate is not available while swimming.

1Press the key.

2Select Pool Swim.

3Select your pool size, or enter a custom size.

4Press the key to start the activity timer.

The device records activity data only while the activity timer is

running.

5Start your activity.

The device automatically records swim intervals and lengths.

6Press the key when you rest.

The display inverts color, and the rest screen appears.

7Press the key to restart the interval timer.

8After you complete your activity, hold the key to stop the

activity timer, and hold the key again to save the activity.

Setting the Pool Size

1Press the key.

2Select Pool Swim > Pool Size.

3Select your pool size, or enter a custom size.

Swim Terminology

Length: One trip down the pool.

Interval: One or more consecutive lengths. A new interval starts

after a rest.

10 Apps and Activities

Stroke: A stroke is counted every time your arm wearing the

device completes a full cycle.

Swolf: Your swolf score is the sum of the time for one pool

length and the number of strokes for that length. For

example, 30 seconds plus 15 strokes equals a swolf score of

45. Swolf is a measurement of swimming efficiency and, like

golf, a lower score is better.

Golfing

Downloading Golf Courses

Before you play a course for the first time, you must download it

using the Garmin Connect Mobile app.

1From the Garmin Connect Mobile app, select Download Golf

Courses > .

2Select a golf course.

3Select Download.

After the course finishes downloading, it appears in the list of

courses on your vívoactive device.

Playing Golf

Before you play a course for the first time, you must download it

using your smartphone (Downloading Golf Courses, page 11).

Downloaded courses are updated automatically. Before you play

golf, you should charge the device (Charging the Device,

page 19).

1Press the key.

2Select Golf.

3Wait while the device locates satellites.

4Select a course from the list of available courses.

5Swipe up or down to scroll through the holes.

The device automatically transitions when you move to the

next hole.

Hole Information

The device calculates the distance to the front and back of the

green, and to the selected pin location (Changing the Pin

Location, page 11).

ÀCurrent hole number

ÁDistance to the back of the green

ÂDistance to the selected pin location

ÃDistance to the front of the green

ÄPar for the hole

ÅMap of the green

Changing the Pin Location

While playing a game, you can take a closer look at the green

and move the pin location.

1Select the map.

A larger view of the green appears.

2Swipe up or down to scroll through the pin locations.

indicates the selected pin location.

3Press the key to accept the pin location.

The distances on the hole information screen are updated to

reflect the new pin location. The pin location is saved for only

the current round.

Viewing the Direction to the Pin

The PinPointer feature is a compass that provides directional

assistance when you are unable to see the green. This feature

can help you line up a shot even if you are in the woods or in a

deep sand trap.

NOTE: Do not use the PinPointer feature while in a golf cart.

Interference from the golf cart can affect the accuracy of the

compass.

1Press the key.

2Select .

The arrow points to the pin location.

Viewing Layup and Dogleg Distances

You can view a list of layup and dogleg distances for par 4 and 5

holes.

1Press the key.

2Select .

NOTE: Distances and locations are removed from the list as

you pass them.

Viewing Hazards

You can view distances to hazards along the fairway for par 4

and 5 holes. Hazards that affect shot selection are displayed

individually or in groups to help you determine the distance to

layup or carry.

1From the hole information screen, press the key, and select

• The distances to the front À and back Á of the nearest

hazard appear on the screen.

• The hazard type Â is listed at the top of the screen.

• The green is represented as a half circle Ã at the top of

the screen. The line below the green represents the center

of the fairway.

• Hazards Ä are shown below the green in approximate

locations relative to the fairway.

2Swipe to view other hazards for the current hole.

Measuring a Shot with the Garmin AutoShot™ Feature

Your vívoactive device features automatic shot detection and

recording. Each time you take a shot along the fairway, the

device records your shot distance so you can view it later

(Viewing Your Shot History, page 12).

TIP: Automatic shot detection works best when you wear the

device on your leading wrist and make good contact with the

ball. Putts are not detected.

1Begin playing a round.

When the device detects a shot, your distance from the shot

location appears in the banner À at the top of the screen.

Apps and Activities 11

TIP: You can tap the banner to hide it for 10 seconds.

2Walk or drive to your ball.

3Make your next shot.

The device records the distance of your last shot.

Keeping Score

1While playing golf, press the key.

2Select .

3If necessary, hold the touchscreen to set up scoring or

change par for the hole.

4Swipe up or down to change holes.

5Tap the center of the screen.

6Select or to set the score.

Setting the Scoring Method

You can change the method the device uses to keep score.

1From the scorecard, hold the touchscreen.

2Select Golf Settings > Scoring > Scoring Method.

3Select a scoring method.

About Stableford Scoring

When you select the Stableford scoring method (Setting the

Scoring Method, page 12), points are awarded based on the

number of strokes taken relative to par. At the end of a round,

the highest score wins. The device awards points as specified

by the United States Golf Association.

The scorecard for a Stableford scored game shows points

instead of strokes.

Points Strokes Taken Relative to Par

0 2 or more over

1 1 over

2 Par

3 1 under

4 2 under

5 3 under

Tracking Golf Statistics

When you enable statistics tracking on the device, you can view

your statistics for the current round (Viewing Your Round

Summary, page 12). You can compare rounds and track

improvements using the Garmin Golf™ app.

1From the scorecard, hold the touchscreen.

2Select Golf Settings > Scoring > Stat Tracking.

Recording Golf Statistics

Before you can record statistics, you must enable statistics

tracking (Tracking Golf Statistics, page 12).

1From the scorecard, tap the center of the screen.

2Set the number of strokes taken, and select Next.

3Set the number of putts taken, and select Done.

4Select an option:

• If your ball hit the fairway, select .

• If your ball missed the fairway, select or .

Viewing Your Shot History

1After playing a hole, press the key.

2Select to view information for your last shot.

3Select to view information about each shot for a hole.

Viewing Your Round Summary

During a round, you can view your score, statistics, and step

information.

1Press the key.

2Select .

Ending a Round

1Press the key.

2Select End.

3Select an option:

• To view your statistics and round information, tap your

score.

• To save the round and return to watch mode, select Save.

• To edit your scorecard, select Edit Score.

• To discard the round and return to watch mode, select

Discard.

• To pause the round and resume it at a later time, select

Pause.

Golf Settings

From the watch face, hold the touchscreen, and select Settings

> Activities & Apps > Golf > Golf Settings.

Scoring: Allows you to set the scoring options (Scoring

Settings, page 12).

Driver Distance: Sets the average distance the ball travels on

your drive.

Big Numbers: Changes the size of the numbers on the hole

view screen.

Scoring Settings

From the watch face, hold the touchscreen, and select Settings

> Activities & Apps > Golf > Golf Settings > Scoring.

Status: Sets score keeping to on or off automatically when you

start a round. The Always Ask option prompts you when you

begin a round.

Stat Tracking: Enables statistics tracking for the number of

putts, greens in regulation, and fairways hit while playing golf.

2 Players: Sets the scorecard to keep score for two players.

NOTE: This setting is only available during a round. You

must enable this setting each time you begin a round.

Scoring Method: Changes the method the device uses to keep

score.

Handicap Scoring: Sets your player handicap.

Garmin Golf App

The Garmin Golf app allows golfers to compete with each other

at different courses. More than 41,000 courses have a weekly

leaderboard that anyone can join. You can set up a tournament

event and invite players to compete. You can upload scorecards

from your compatible Garmin device to view detailed statistics

and shot analyses.

The Garmin Golf app syncs your data with your Garmin Connect

account. You can download the Garmin Golf app from the app

store on your smartphone.

Training

Setting Up Your User Profile

You can update your gender, birth year, height, weight, wrist,

and heart rate zone (Setting Your Heart Rate Zones, page 6)

settings. The device uses this information to calculate accurate

training data.

12 Training

1Hold the touchscreen.

2Select Settings > User Profile.

3Select an option.

Fitness Goals

Knowing your heart rate zones can help you measure and

improve your fitness by understanding and applying these

principles.

• Your heart rate is a good measure of exercise intensity.

• Training in certain heart rate zones can help you improve

cardiovascular capacity and strength.

If you know your maximum heart rate, you can use the table

(Heart Rate Zone Calculations, page 7) to determine the best

heart rate zone for your fitness objectives.

If you do not know your maximum heart rate, use one of the

calculators available on the Internet. Some gyms and health

centers can provide a test that measures maximum heart rate.

The default maximum heart rate is 220 minus your age.

Workouts

Your device can guide you through multiple-step workouts that

include goals for each workout step, such as distance, time,

reps, or other metrics. Your device includes several preloaded

workouts for multiple activities, including strength, cardio,

running, and biking. You can create and find more workouts and

training plans using Garmin Connect and transfer them to your

device.

You can create a scheduled training plan using the calendar in

Garmin Connect and send the scheduled workouts to your

device.

Following a Workout

Your device can guide you through multiple steps in a workout.

1Press the key.

2Select an activity.

3Select Workouts.

NOTE: This option appears only when you have workouts

loaded on your device for the selected activity.

4Select a workout.

5Select Do Workout.

6Press the key to start the activity timer.

The device briefly displays the goals for the first step of your

workout.

7After you complete the workout step, double-tap the

touchscreen to start the next step.

A summary of the workout step appears. After several

seconds, the rest timer and the goals for the next step

appear.

8While resting, swipe down to view notes and additional

details about the next workout step (optional).

9Double-tap the touchscreen to start the next step.

10Repeat steps 6 through 9 until you complete all of the steps

in the workout.

TIP: If you want to stop the workout early, you can press the

key to stop the activity timer.

11If necessary, select to end the cool down step.

12After you complete your activity, press the key, and select

to save the activity.

Using Garmin Connect Training Plans

Before you can download and use a training plan from Garmin

Connect, you must have a Garmin Connect account (Garmin

Connect, page 15), and you must pair the vívoactive device

with a compatible smartphone.

1From the Garmin Connect Mobile app, select Training >

Training Plans > Find a Plan.

2Select and schedule a training plan.

3Select , and follow the on-screen instructions.

4Review the training plan in your calendar.

Starting Today's Workout

After you send a training plan to your device, the Garmin Coach

widget appears in your widget loop.

1From the watch face, swipe to view the Garmin Coach

widget.

If a workout for this activity is scheduled for today, the device

shows the workout name and prompts you to start it.

2Select a workout.

3Select View to view the workout steps, and swipe right when

you are finished viewing the steps (optional).

4Select Do Workout.

5Follow the on-screen instructions.

Viewing Scheduled Workouts

You can view workouts scheduled in your training calendar and

start a workout.

1Press the key.

2Select an activity.

3Select Workouts > Training Calendar.

Your scheduled workouts appear, sorted by date.

4Select a workout.

5Select an option:

• To view the steps for the workout, select View.

• To start the workout, select Do Workout.

Adaptive Training Plans

Your Garmin Connect account has an adaptive training plan and

Garmin coach to fit your training goals. For example, you can

answer a few questions and find a plan to help you complete a 5

km race. The plan adjusts to your current level of fitness,

coaching and schedule preferences, and race date. When you

start a plan, the Garmin Coach widget is added to the widget

loop on your vívoactive device.

Personal Records

When you complete an activity, the device displays any new

personal records you achieved during that activity. Personal

records include your fastest time over several typical race

distances and longest run or ride.

Viewing Your Personal Records

1Hold the touchscreen.

2Select My Stats > Records.

3Select a sport.

4Select a record.

5Select View Record.

Restoring a Personal Record

You can set each personal record back to the one previously

recorded.

1Hold the touchscreen.

2Select My Stats > Records.

3Select a sport.

4Select a record to restore.

5Select Previous > Yes.

NOTE: This does not delete any saved activities.

Training 13

Clearing a Personal Record

1Hold the touchscreen.

2Select My Stats > Records.

3Select a sport.

4Select a record to delete.

5Select Clear Record > Yes.

NOTE: This does not delete any saved activities.

Clearing All Personal Records

1Hold the touchscreen.

2Select My Stats > Records.

NOTE: This does not delete any saved activities.

3Select a sport.

4Select Clear All Records > Yes.

The records are deleted for that sport only.

Navigation

You can use the GPS navigation features on your device to

save locations, navigate to locations, and find your way home.

Saving Your Location

Before you can navigate to a saved location, your device must

locate satellites.

A location is a point that you record and store in the device. If

you want to remember landmarks or return to a certain spot, you

can mark a location.

1Go to the place where you want to mark a location.

2Press the key.

3Select Navigate > Save Location.

After the device acquires GPS signals, the location

information appears.

4Select Save.

5Select an icon.

Deleting a Location

1Press the key.

2Select Navigate > Saved Locations.

3Select a location.

4Select Delete > Yes.

Navigating to a Saved Location

Before you can navigate to a saved location, your device must

locate satellites.

1Press the key.

2Select Navigate > Saved Locations.

3Select a location, and select Go To.

4Select an activity.

The compass appears.

5Move forward.

The compass arrow points toward the saved location.

TIP: For more accurate navigation, orient the top of the

screen toward the direction in which you are moving.

6Press the key to start the activity timer.

Navigating Back to Start

Before you can navigate back to start, you must locate satellites,

start the timer, and start your activity.

At any time during your activity, you can return to your starting

location. For example, if you are running in a new city, and you

are unsure how to get back to the trail head or hotel, you can

navigate back to your starting location. This feature is not

available for all activities.

1Hold the touchscreen.

2Select Stop Navigation.

3Hold the touchscreen.

4Select Navigation > Back to Start.

The compass appears.

5Move forward.

The compass arrow points toward your starting point.

TIP: For more accurate navigation, orient your device toward

the direction in which you are navigating.

Stopping Navigation

• To stop navigation and continue your activity, hold the

touchscreen, and select Stop Navigation.

• To stop navigation and end your activity, press the key, and

select Done.

Compass

The device has a 3-axis compass with automatic calibration.

The compass features and appearance change depending on

your activity, whether GPS is enabled, and whether you are

navigating to a destination.

Calibrating the Compass Manually

NOTICE

Calibrate the electronic compass outdoors. To improve heading

accuracy, do not stand near objects that influence magnetic

fields, such as vehicles, buildings, and overhead power lines.

Your device was already calibrated at the factory, and the

device uses automatic calibration by default. If you experience

irregular compass behavior, for example, after moving long

distances or after extreme temperature changes, you can

manually calibrate the compass.

1Hold the touchscreen.

2Select Settings > Sensors & Accessories > Compass >

Calibrate > Start.

3Follow the on-screen instructions.

TIP: Move your wrist in a small figure eight motion until a

message appears.

History

Your device stores up to 14 days of activity tracking and heart

rate monitoring data, and up to seven timed activities. You can

view your last seven timed activities on your device. You can

synchronize your data to view unlimited activities, activity

tracking data, and heart rate monitoring data on your Garmin

Connect account (Using Garmin Connect Mobile, page 15)

(Using Garmin Connect on Your Computer, page 15).

When the device memory is full, your oldest data is overwritten.

Using History

1Hold the touchscreen.

2Select History.

3Select an activity.

4Select an option:

• Select Details to view additional information about the

activity.

• Select Laps to select a lap and view additional information

about each lap.

• Select Delete to delete the selected activity.

14 Navigation

Viewing Your Time in Each Heart Rate Zone

Before you can view heart rate zone data, you must complete an

activity with heart rate and save the activity.

Viewing your time in each heart rate zone can help you adjust

your training intensity.

1Hold the touchscreen.

2Select History.

3Select an activity.

4Select HR Zones.

Garmin Connect

Your Garmin Connect account allows you to track your

performance and connect with your friends. It gives you the tools

to track, analyze, share, and encourage each other. You can

record the events of your active lifestyle, including runs, walks,

rides, swims, hikes, golf games, and more.

You can create your free Garmin Connect account when you

pair your device with your phone using the Garmin Connect

Mobile app. You can also create an account when you set up

the Garmin Express application (www.garmin.com/express).

Store your activities: After you complete and save a timed

activity with your device, you can upload that activity to your

Garmin Connect account and keep it as long as you want.

Analyze your data: You can view more detailed information

about your fitness and outdoor activities, including time,

distance, heart rate, calories burned, cadence, an overhead

map view, and pace and speed charts. You can view more

detailed information about your golf games, including

scorecards, statistics, and course information. You can also

view customizable reports.

NOTE: To view some data, you must pair an optional

wireless sensor with your device (Pairing Your Wireless

Sensors, page 18).

Track your progress: You can track your daily steps, join a

friendly competition with your connections, and meet your

goals.

Share your activities: You can connect with friends to follow

each other's activities or post links to your activities on your

favorite social networking sites.

Manage your settings: You can customize your device and

user settings on your Garmin Connect account.

Using Garmin Connect Mobile

After you pair your device with your smartphone (Pairing Your

Smartphone, page 2), you can use the Garmin Connect Mobile

app to upload all of your activity data to your Garmin Connect

account.

1Verify the Garmin Connect Mobile app is running on your

smartphone.

2Bring your device within 10 m (30 ft.) of your smartphone.

Your device automatically syncs your data with the Garmin

Connect Mobile app and your Garmin Connect account.

Using Garmin Connect on Your Computer

The Garmin Express application connects your device to your

Garmin Connect account using a computer. You can use the

Garmin Express application to upload your activity data to your

Garmin Connect account and to send data, such as workouts or

training plans, from Garmin Connect website to your device. You

can also install device software updates and manage your

Connect IQ apps.

1Connect the device to your computer using the USB cable.

2Go to www.garmin.com/express.

3Download and install the Garmin Express application.

4Open the Garmin Express application, and select Add

Device.

5Follow the on-screen instructions.

Customizing Your Device

Changing the Watch Face

You can choose from several preloaded watch faces or use a

Connect IQ watch face that is downloaded to your device

(Connect IQ Features, page 3). You can also customize a

preloaded watch face or create a new one (Creating a Custom

Watch Face, page 15).

1From the watch face, hold the touchscreen.

2Select Watch Face.

3Swipe up or down to scroll through the available watch faces.

4Tap the screen to select the watch face.

5Select Apply to activate the displayed watch face.

Creating a Custom Watch Face

You can customize the style and data fields for the watch face.

1From the watch face, hold the touchscreen.

2Select Watch Face.

3Select an option:

• To customize an existing watch face, select the watch

face, and select Customize.

• To create a new watch face, swipe to the bottom of the

watch face list, and select Create New.

4Swipe up or down to scroll through the analog and digital

dials, and tap the screen to select the displayed dial.

5Select each data field you want to customize, and select the

data to display in it.

A green border indicates the customizable data fields for this

dial.

6Swipe left to customize the watch face hands.

NOTE: This option is available only for analog dials.

7Swipe up or down to scroll through the hand styles, and tap

the screen to select the displayed hands.

8Swipe left, and select an accent color.

9Select .

10Select Done.

The device sets the new watch face as your active watch

face.

Customizing the Controls Menu

You can add, remove, and change the order of the shortcut

menu options in the controls menu (Using the Controls Menu,

page 1).

1Hold the key.

Customizing Your Device 15

The controls menu appears.

2Hold the touchscreen.

The controls menu switches to edit mode.

3Select the shortcut you want to customize.

4Select an option:

• To change the location of the shortcut in the controls

menu, select the location where you want it to appear, or

drag the shortcut to a new location.

• To remove the shortcut from the controls menu, select .

5If necessary, select to add a shortcut to the controls menu.

NOTE: This option is available only after you remove at least

one shortcut from the menu.

Activities and App Settings

These settings allow you to customize each preloaded activity

app based on your needs. For example, you can customize data

pages and enable alerts and training features. Not all settings

are available for all activity types.

Press the key, select an activity, and select Settings.

Data Screens: Enables you to customize data screens and add

new data screens for the activity (Customizing the Data

Screens, page 16).

Alerts: Sets the training alerts for the activity (Alerts, page 16).

Laps: Sets the options for the Auto Lap® feature (Marking Laps

Using the Auto Lap Feature, page 16), and turns on the

manual lap function (Turning On the Manual Lap Function,

page 17).

Auto Pause: Sets the device to stop recording data when you

stop moving or when you drop below a specified speed

(Using Auto Pause®, page 17).

Auto Scroll: Enables you to move through all of the activity data

screens automatically while the timer is running (Using Auto

Scroll, page 17).

GPS: Sets the mode for the GPS antenna. Using GLONASS

provides increased performance in challenging environments

and faster position acquisition. Using the GLONASS option

can reduce battery life more than using the GPS option only.

Pool Size: Sets the pool length for pool swimming.

Background: Sets the background color of each activity to

black or white.

Accent Color: Sets the accent color of each activity to help

identify which activity is active.

Customizing the Data Screens

You can customize data screens based on your training goals or

optional accessories. For example, you can customize one of

the data screens to display your lap pace or heart rate zone.

1Press the key.

2Select an activity.

3Select Settings > Data Screens.

4Select one or more options:

• To adjust the style and number of data fields on each data

screen, select Layout.

• To customize the fields on a data screen, select the

screen, and select Edit Data Fields.

• To show or hide a data screen, select the toggle switch

next to the screen.

• To show or hide the heart rate zone gauge screen, select

HR Zone Gauge.

Alerts

You can set alerts for each activity, which can help you to train

toward specific goals. Some alerts are available only for specific

activities. Some alerts require optional accessories, such as a

heart rate monitor or cadence sensor. There are three types of

alerts: event alerts, range alerts, and recurring alerts.

Event alert: An event alert notifies you once. The event is a

specific value. For example, you can set the device to alert

you when you burn a specified number of calories.

Range alert: A range alert notifies you each time the device is

above or below a specified range of values. For example, you

can set the device to alert you when your heart rate is below

60 beats per minute (bpm) and over 210 bpm.

Recurring alert: A recurring alert notifies you each time the

device records a specified value or interval. For example, you

can set the device to alert you every 30 minutes.

Alert Name Alert Type Description

Cadence Range You can set minimum and maximum

cadence values.

Calories Event,

recurring

You can set the number of calories.

Custom Recurring You can select an existing message or

create a custom message and select an

alert type.

Distance Recurring You can set a distance interval.

Heart Rate Range You can set minimum and maximum

heart rate values or select zone changes.

Pace Range You can set minimum and maximum

pace values.

Run/Walk Recurring You can set timed walking breaks at

regular intervals.

Speed Range You can set minimum and maximum

speed values.

Stroke Rate Range You can set high or low strokes per

minute.

Time Event,

recurring

You can set a time interval.

Setting an Alert

1Press the key.

NOTE: This feature is not available for all activities.

2Select an activity.

3Select Settings > Alerts.

4Select an option:

• To add a new alert for the activity, select Add New.

• To edit an existing alert, select the alert name.

5If necessary, select the type of alert.

6Select a zone, enter the minimum and maximum values, or

enter a custom value for the alert.

7If necessary, turn on the alert.

For event and recurring alerts, a message appears each time

you reach the alert value (Alerts, page 16). For range alerts, a

message appears each time you exceed or drop below the

specified range (minimum and maximum values).

Auto Lap

Marking Laps Using the Auto Lap Feature

You can set your device to use the Auto Lap feature to mark a

lap at a specific distance automatically. This feature is helpful for

comparing your performance over different parts of an activity

(for example, every 1 mile or 5 kilometers).

1Press the key.

2Select an activity.

NOTE: This feature is not available for all activities.

3Select Settings > Laps.

4Select an option:

• To turn the Auto Lap feature on or off, select the toggle

switch.

16 Customizing Your Device

• To adjust the distance between laps, select Auto Lap.

Each time you complete a lap, a message appears that displays

the time for that lap. The device also vibrates if vibration is

turned on (System Settings, page 17).

Turning On the Manual Lap Function

You can mark laps at any time or distance by double tapping the

touchscreen during timed activities such as running and biking.

1Press the key.

2Select an activity.

NOTE: This feature is not available for all activities.

3Select Settings > Laps > Manual Lap.

Each time you mark a lap, a message appears that displays the

time for that lap. The device also vibrates if vibration is turned on

(System Settings, page 17).

The lap function stays on for the selected activity until you turn

off the lap function.

Using Auto Pause®

You can use the Auto Pause feature to pause the timer

automatically when you stop moving or when your pace or

speed drops below a specified value. This feature is helpful if

your activity includes stop lights or other places where you need

to slow down or stop.

NOTE: The device does not record activity data while the timer

is stopped or paused.

1Press the key.

2Select an activity.

3Select Settings > Auto Pause.

NOTE: This feature is not available for all activities.

4Select an option:

NOTE: Not all options are available for all activities.

• To pause the timer automatically when you stop moving,

select When Stopped.

• To pause the timer automatically when your pace drops

below a specified value, select Pace.

• To pause the timer automatically when your speed drops

below a specified value, select Speed.

Using Auto Scroll

You can use the auto scroll feature to cycle through all of the

data screens automatically while the timer is running.

1Press the key.

2Select an activity.

3Select Settings > Auto Scroll.

NOTE: This feature is not available for all activities.

4Select a display speed.

Phone and Bluetooth Settings

Hold the touchscreen, and select Settings > Phone.

Status: Displays the current Bluetooth connection status and

allows you to turn Bluetooth wireless technology on or off.

Notifications: The device turns smart notifications on and off

automatically based on your selections (Enabling Bluetooth

Notifications, page 2).

Pair Phone: Connects your device with a compatible

smartphone equipped with Bluetooth wireless technology.

Connected Alerts: Alerts you when your paired smartphone

connects and disconnects.

Stop LiveTrack: Allows you to stop a LiveTrack session while

one is in progress.

Sync: Allows you to transfer the data between your device and

the Garmin Connect Mobile app.

System Settings

Hold the touchscreen, and select Settings > System.

Auto Lock: Automatically locks the touchscreen to prevent

inadvertent screen touches. You can press the key to unlock

the touchscreen.

Language: Sets the language of the device interface.

Time: Sets the time format and source for local time (Time

Settings, page 17).

Date: Alllows you to manually set the date and date format.

Backlight: Sets the backlight mode, timeout, and brightness

(Backlight Settings, page 18).

Vibration: Turns vibration on or off and sets the vibration

intensity.

Do Not Disturb: Turns on or off do not disturb mode.

Units: Sets the measurement units used to display data

(Changing the Units of Measure, page 18).

Data Recording: Sets how the device records activity data. The

Smart recording option (default) allows for longer activity

recordings. The Every Second recording option provides

more detailed activity recordings, but may require you to

charge the battery more frequently.

USB Mode: Sets the device to use media transfer mode or

Garmin mode when connected to a computer.

Reset: Allows you to reset the default settings or delete

personal data and reset the settings (Restoring All Default

Settings, page 21).

NOTE: If you have set up a Garmin Pay wallet, restoring

default settings also deletes the wallet from your device.

Software Update: Allows you to check for software updates.

About: Displays the unit ID, software version, regulatory

information, and license agreement.

Time Settings

Hold the touchscreen, and select Settings > System > Time.

Time Format: Sets the device to show time in a 12-hour or a

24-hour format.

Time Source: Allows you to set the time manually or

automatically based on your paired mobile device.

Time Zones

Each time you turn on the device and acquire satellites or sync

with your smartphone, the device automatically detects your

time zone and the current time of day.

Setting the Time Manually

By default, the time is set automatically when the vívoactive

device is paired with a mobile device.

1Hold the touchscreen.

2Select Settings > System > Time > Time Source > Manual.

3Select Time, and enter the time of day.

Setting the Alarm

1Hold the touchscreen.

2Select Clocks > Alarms > Add New.

3Select Time, and enter a time.

4Select Repeat, and select an option.

Deleting an Alarm

1Hold the touchscreen.

2Select Clocks > Alarms.

3Select an alarm, and select Remove.

Starting the Countdown Timer

1Hold the touchscreen.

2Select Clocks > Timer.

Customizing Your Device 17

3Enter the time.

4Select Start.

5If necessary, select the touchscreen for more options.

Using the Stopwatch

1Hold the touchscreen.

2Select Clocks > Stopwatch.

3Press the key.

Backlight Settings

Hold the touchscreen, and select Settings > System >

Backlight.

Mode: Sets the backlight to turn on when you interact with the

device, which includes receiving a notification or using the

key or touchscreen.

Gesture: Sets the backlight to turn on when you rotate your

wrist toward your body to view the device. You can use the

Only During Activity option to use this feature only during

timed activities.

Timeout: Sets the length of time before the backlight turns off.

Brightness: Sets the brightness level of the backlight. During an

activity, the backlight uses the brightest setting.

Changing the Units of Measure

You can customize units of measure for distance, pace and

speed, elevation, weight, height, and temperature.

1Hold the touchscreen.

2Select Settings > System > Units.

3Select a measurement type.

4Select a unit of measure.

Garmin Connect Settings

You can change your device settings from your Garmin Connect

account, using either the Garmin Connect Mobile app or the

Garmin Connect website. Some settings are available only using

your Garmin Connect account and cannot be changed on your

device.

• In the Garmin Connect Mobile app, select the image of your

device, and select Device Settings.

• On the Garmin Connect website, from the devices widget,

select Device Settings.

After customizing settings, sync your data to apply the changes

to your device (Using Garmin Connect Mobile, page 15, Using

Garmin Connect on Your Computer, page 15).

Device Settings on Your Garmin Connect Account

From your Garmin Connect account, select your device to view

the device settings.

NOTE: Some settings appear in a subcategory in the settings

menu. App or website updates may change these settings

menus.

Activity Tracking: Turns activity tracking features on and off.

Appearance: Allows you to change the watch face, widgets,

and shortcuts that appear in the controls menu (Customizing

the Controls Menu, page 15).

Auto Activity Start: Allows your device to create and save

timed activities automatically when the Move IQ feature

detects you have been walking or running for a minimum time

threshold. You can set the minimum time threshold for

running and walking.

Automatic App Updates: Allows your device to receive

Connect IQ app updates automatically.

Data Recording: Sets how the device records activity data. The

Smart recording option (default) allows for longer activity

recordings. The Every Second recording option provides

more detailed activity recordings, but may require you to

charge the battery more frequently.

Date Format: Sets the month and day format.

Distance: Sets the device to display the distance traveled in

kilometers or miles.

Goals: Allows you to set a custom goal for daily steps and floors

climbed. You can use the Auto Goal setting to allow your

device to determine your step goal automatically. You can

also set the weekly intensity minutes goal.

Goal Animations: Allows you to turn on and off goal

animations, or turn them off only during activities. Goal

animations appear for your daily steps goal, daily floors

climbed goal, and weekly intensity minutes goal.

Heart Rate Zones: Allows you to estimate your maximum heart

rate and determine custom heart rate zones.

Language: Sets the language of the device interface.

Move Alert: Displays a message and the move bar on the

digital watch face and steps screen. The device also vibrates

if vibrations are turned on.

Move IQ: Allows you to turn on and off Move IQ events. The

Move IQ feature automatically detects activity patterns, such

as walking, running, cycling, swimming, and elliptical training.

Preferred Activity Tracker: Sets this device to be your primary

activity tracking device when more than one device is

connected to the app.

Sounds & Alerts: Allows you to customize alarms and phone

notifications. You can also turn on and off the Do Not Disturb

During Sleep feature.

Text Responses: Allows you to customize the list of automatic

text message responses. This feature is available only for

smartphones with Android.

Time Format: Sets the device to display time in a 12-hour or 24-

hour format.

Wrist Worn On: Allows you to customize which wrist the device

is worn on.

NOTE: This setting is used for strength training and gestures.

User Settings on Your Garmin Connect Account

From your Garmin Connect account, select Settings > User

Settings.

TIP: Some user settings are available in the vívoactive Device

Settings menu.

Personal Information: Allows you to enter your personal

details, such as birth date, gender, height, and weight.

Sleep: Allows you to enter your normal sleep hours.

Stride Length: Allows your device to more accurately calculate

the distance traveled using your custom step length for

walking and running. You can enter a known distance and

the number of steps it takes to cover the distance, and

Garmin Connect can calculate your step length.

Units: Allows you to set statute or metric units of measure.

Wireless Sensors

Your device can be used with wireless ANT+ or Bluetooth

sensors. For more information about compatibility and

purchasing optional sensors, go to buy.garmin.com.

Pairing Your Wireless Sensors

The first time you connect a wireless ANT+ or Bluetooth sensor

to your Garmin device, you must pair the device and sensor.

After they are paired, the device connects to the sensor

automatically when you start an activity and the sensor is active

and within range.

18 Wireless Sensors

TIP: Some ANT+ sensors pair with your device automatically

when you start an activity with the sensor turned on and near

the device.

1Move at least 10 m (33 ft.) away from other wireless sensors.

2If you are pairing a heart rate monitor, put on the heart rate

monitor.

The heart rate monitor does not send or receive data until

you put it on.

3Hold the touchscreen.

4Select Settings > Sensors & Accessories > Add New.

5Bring the device within 3 m (10 ft.) of the sensor, and wait

while the device pairs with the sensor.

After the device connects to the sensor, an icon appears at

the top of the screen.

Foot Pod

Your device is compatible with the foot pod. You can use the

foot pod to record pace and distance instead of using GPS when

you are training indoors or when your GPS signal is weak. The

foot pod is on standby and ready to send data (like the heart

rate monitor).

After 30 minutes of inactivity, the foot pod powers off to

conserve the battery. When the battery is low, a message

appears on your device. Approximately five hours of battery life

remain.

Calibrating Your Foot Pod

Before you can calibrate your foot pod, you must pair your

device with the foot pod (Pairing Your Wireless Sensors,

page 18).

Manual calibration is recommended if you know your calibration

factor. If you have calibrated a foot pod with another Garmin

product, you may know your calibration factor.

1Hold the touchscreen.

2Select Settings > Sensors & Accessories > Foot Pod >

Calib. Factor.

3Adjust the calibration factor:

• Increase the calibration factor if your distance is too low.

• Decrease the calibration factor if your distance is too high.

Improving Foot Pod Calibration

Before you can calibrate your device, you must acquire GPS

signals and pair your device with the foot pod (Pairing Your

Wireless Sensors, page 18).

The foot pod is self-calibrating, but you can improve the

accuracy of the speed and distance data with a few outdoor runs

using GPS.

1Stand outside for 5 minutes with a clear view of the sky.

2Start a running activity.

3Run on a track without stopping for 10 minutes.

4Stop your activity, and save it.

Based on the recorded data, the foot pod calibration value

changes, if necessary. You should not need to calibrate the

foot pod again unless your running style changes.

Using an Optional Bike Speed or Cadence

Sensor

You can use a compatible bike speed or cadence sensor to

send data to your device.

• Pair the sensor with your device (Pairing Your Wireless

Sensors, page 18).

• Set your wheel size (Calibrating Your Speed Sensor,

page 19).

• Go for a ride (Going for a Ride, page 10).

Calibrating Your Speed Sensor

Before you can calibrate your speed sensor, you must pair your

device with a compatible speed sensor (Pairing Your Wireless

Sensors, page 18).

Manual calibration is optional and can improve accuracy.

1Hold the touchscreen.

2Select Settings > Sensors & Accessories > Speed/

Cadence > Wheel Size.

3Select an option:

• Select Auto to automatically calculate your wheel size and

calibrate your speed sensor.

• Select Manual, and enter your wheel size to manually

calibrate your speed sensor (Wheel Size and

Circumference, page 23).

Situational Awareness

Your vívoactive device can be used with Varia smart bike lights

and rearview radar to improve situational awareness. See the

owner's manual for your Varia device for more information.

NOTE: You may need to update the vívoactive software before

pairing Varia devices (Updating the Software Using Garmin

Connect Mobile, page 20).

tempe

The tempe is an ANT+ wireless temperature sensor. You can

attach the sensor to a secure strap or loop where it is exposed

to ambient air, and therefore, provides a consistent source of

accurate temperature data. You must pair the tempe with your

device to display temperature data from the tempe.

Device Information

Charging the Device

WARNING

This device contains a lithium-ion battery. See the Important

Safety and Product Information guide in the product box for

product warnings and other important information.

NOTICE

To prevent corrosion, thoroughly clean and dry the contacts and

the surrounding area before charging or connecting to a

computer. Refer to the cleaning instructions in the appendix.

1Plug the small end of the USB cable into the charging port on

your device.

2Plug the large end of the USB cable into a USB port on your

computer.

3Charge the device completely.

Product Updates

On your computer, install Garmin Express (www.garmin.com

/express). On your smartphone, install the Garmin Connect

Mobile app.

Device Information 19

This provides easy access to these services for Garmin devices:

• Software updates

• Course updates

• Data uploads to Garmin Connect

• Product registration

Updating the Software Using Garmin Connect Mobile

Before you can update your device software using the Garmin

Connect Mobile app, you must have a Garmin Connect account,

and you must pair the device with a compatible smartphone

(Pairing Your Smartphone, page 2).

Sync your device with the Garmin Connect Mobile app (Using

Garmin Connect Mobile, page 15).

When new software is available, the Garmin Connect Mobile

app automatically sends the update to your device. The

update is applied when you are not actively using the device.

When the update is complete, your device restarts.

Updating the Software Using Garmin Express

Before you can update your device software, you must

download and install the Garmin Express application and add

your device (Using Garmin Connect on Your Computer,

page 15).

1Connect the device to your computer using the USB cable.

When new software is available, the Garmin Express

application sends it to your device.

2After the Garmin Express application finishes sending the

update, disconnect the device from your computer.

Your device installs the update.

Viewing E- label & Device Information

You can view the E-label, additional regulatory information,

unit ID, software version, and license agreement as follows:

1Hold the touchscreen.

2Select Settings > System > About.

Specifications

Battery type Rechargeable, built-in lithium-polymer battery

Operating

temperature range

From -20º to 60ºC (from -4º to 140ºF)

Charging

temperature range

From 0º to 45ºC (from 32º to 113ºF)

Wireless

frequencies/

protocols

2.4 GHz @ 8 dBm nominal

• ANT+ wireless communications protocol

• Bluetooth 4.2 technology

13.56 MHz @ -40 dBm nominal, NFC wireless

technology

782 MHz @ 23 dBm nominal and 1732 MHz @ 23

dBm nominal, LTE wireless technology

Water rating Swim, 5 ATM*

*The device withstands pressure equivalent to a depth of 50 m.

For more information, go to www.garmin.com/waterrating.

Device Care

NOTICE

Avoid extreme shock and harsh treatment, because it can

degrade the life of the product.

Avoid pressing the keys under water.

Do not use a sharp object to clean the device.

Never use a hard or sharp object to operate the touchscreen, or

damage may result.

Avoid chemical cleaners, solvents, and insect repellents that can

damage plastic components and finishes.

Thoroughly rinse the device with fresh water after exposure to

chlorine, salt water, sunscreen, cosmetics, alcohol, or other

harsh chemicals. Prolonged exposure to these substances can

damage the case.

Do not store the device where prolonged exposure to extreme

temperatures can occur, because it can cause permanent

damage.

Cleaning the Device

NOTICE

Even small amounts of sweat or moisture can cause corrosion

of the electrical contacts when connected to a charger.

Corrosion can prevent charging and data transfer.

1Wipe the device using a cloth dampened with a mild

detergent solution.

2Wipe it dry.

After cleaning, allow the device to dry completely.

TIP: For more information, go to www.garmin.com/fitandcare.

Replacing the Bands

The device is compatible with 20 mm wide, standard, quick-

release bands. Go to buy.garmin.com, or contact your Garmin

dealer for information about optional accessories.

1Slide the quick-release pin À on the spring bar to remove the

band.

2Insert one side of the spring bar for the new band into the

device.

3Slide the quick-release pin, and align the spring bar with the

opposite side of the device.

4Repeat steps 1 through 3 to replace the other band.

Troubleshooting

Is my smartphone compatible with my

device?

The vívoactive device is compatible with smartphones using

Bluetooth wireless technology.

Go to www.garmin.com/ble for compatibility information.

My phone will not connect to the device

• Enable Bluetooth wireless technology on your smartphone.

• Bring your phone within 10 m (33 ft.) of the device.

20 Troubleshooting

• On your smartphone, open the Garmin Connect Mobile app,

select or , and select Garmin Devices > Add Device to

enter pairing mode.

• On your device, hold the key, and select to turn on

Bluetooth technology and enter pairing mode.

My headphones will not connect to the

device

If your headphones were previously connected to your

smartphone using Bluetooth technology, they may connect to

your smartphone before connecting to your device. You can try

these tips.

• Turn off Bluetooth technology on your smartphone.

Refer to the owner's manual for your smartphone for more

information.

• Stay 10 m (33 ft.) away from your smartphone while

connecting headphones to your device.

• Pair your headphones with your device (Connecting

Headphones using Bluetooth Technology, page 5).

My music cuts out or my headphones do not

stay connected

When using a vívoactive 3 Music device connected to

headphones using Bluetooth technology, the signal is strongest

when there is a direct line of sight between the device and the

antenna on the headphones.

• If the signal passes through your body, you may experience

signal loss or your headphones may become disconnected.

• It is recommended to wear your headphones with the

antenna on the same side of your body as your vívoactive 3

Music device.

My device is in the wrong language

You can change the device language selection if you have

accidently selected the wrong language on the device.

1Hold the touchscreen.

2Scroll down to the last item in the list, and select it.

3Scroll down to the last item in the list, and select it.

4Scroll down to the second item in the list, and select it.

5Select your language.

My device does not display the correct time

The device updates the time and date when it syncs with your

smartphone or when the device acquires GPS signals. You

should sync your device to receive the correct time when you

change time zones, and to update for daylight saving time.

1Hold the touchscreen, and select Settings > System > Time.

2Verify the Auto option is enabled.

3Select an option:

• Confirm that your smartphone displays the correct local

time, and sync your device to the smartphone (Using

Garmin Connect Mobile, page 15).

• Start an outdoor activity, go outdoors to an open area with

a clear view of the sky, and wait while the device acquires

satellite signals.

The time and date are updated automatically.

Maximizing Battery Life

You can do several things to extend the life of the battery.

• Reduce the backlight timeout (Backlight Settings, page 18).

• Reduce the backlight brightness (Backlight Settings,

page 18).

• Turn off Bluetooth wireless technology when you are not

using connected features (Turning Off Bluetooth Technology,

page 3).

• Turn off activity tracking (Activity Tracking, page 7).

• Limit the smartphone notifications the device displays

(Managing Notifications, page 3).

• Stop broadcasting heart rate data to paired Garmin devices

(Broadcasting Heart Rate to Garmin Devices, page 6).

• Turn off wrist-based heart rate monitoring (Turning Off the

Wrist-based Heart Rate Monitor, page 6).

Restarting the Device

If the device stops responding, you may need to restart it.

NOTE: Restarting the device may erase your data or settings.

1Hold the key for 15 seconds.

The device turns off.

2Hold the key for one second to turn on the device.

Restoring All Default Settings

You can reset all of the device settings to the factory default

values.

1Hold the touchscreen.

2Select Settings > System > Reset.

3Select an option:

• To reset all of the device settings to the factory default

values and delete all user-entered information and activity

history, select Delete Data and Reset Settings.

NOTE: If you have set up a Garmin Pay wallet, this option

deletes the wallet from your device. If you have music

stored on your device, this option deletes your stored

music.

• To reset all of the device settings to the factory default

values and save all user-entered information and activity

history, select Reset Default Settings.

Acquiring Satellite Signals

The device may need a clear view of the sky to acquire satellite

signals.

1Go outdoors to an open area.

The front of the device should be oriented toward the sky.

2Wait while the device locates satellites.

It may take 30–60 seconds to locate satellite signals.

Improving GPS Satellite Reception

• Frequently sync the device to your Garmin Connect account:

◦ Connect your device to a computer using the USB cable

and the Garmin Express application.

◦ Sync your device to the Garmin Connect Mobile app using

your Bluetooth enabled smartphone.

◦ Connect your device to your Garmin Connect account

using a Wi‑Fi wireless network.

While connected to your Garmin Connect account, the device

downloads several days of satellite data, allowing it to quickly

locate satellite signals.

• Take your device outside to an open area away from tall

buildings and trees.

• Remain stationary for a few minutes.

Activity Tracking

For more information about activity tracking accuracy, go to

garmin.com/ataccuracy.

Troubleshooting 21

My daily step count does not appear

The daily step count is reset every night at midnight.

If dashes appear instead of your step count, allow the device

to acquire satellite signals and set the time automatically.

My step count does not seem accurate

If your step count does not seem accurate, you can try these

tips.

• Wear the device on your non-dominant wrist.

• Carry the device in your pocket when pushing a stroller or

lawn mower.

• Carry the device in your pocket when actively using your

hands or arms only.

NOTE: The device may interpret some repetitive motions,

such as washing dishes, folding laundry, or clapping your

hands, as steps.

The floors climbed amount does not seem accurate

Your device uses an internal barometer to measure elevation

changes as you climb floors. A floor climbed is equal to 3 m

(10 ft.).

• Avoid holding handrails or skipping steps while climbing

stairs.

• In windy environments, cover the device with your sleeve or

jacket as strong gusts can cause erratic readings.

Improving the Accuracy of Intensity Minutes and

Calories

You can improve the accuracy of these estimates by walking or

running outside for 15 minutes.

1From the watch face, swipe to view the My Day widget.

2Select .

3Follow the on-screen instructions.

The temperature reading is not accurate

Your body temperature affects the temperature reading for the

internal temperature sensor. To get the most accurate

temperature reading, you should remove the watch from your

wrist and wait 20 to 30 minutes.

You can also use an optional tempe external temperature

sensor to view accurate ambient temperature readings while

wearing the watch.

Getting More Information

• Go to support.garmin.com for additional manuals, articles,

and software updates.

• Go to www.garmin.com/intosports.

• Go to www.garmin.com/learningcenter.

• Go to buy.garmin.com, or contact your Garmin dealer for

information about optional accessories and replacement

parts.

Appendix

Data Fields

Some data fields require ANT+ accessories to display data.

24-Hour Max.: The maximum temperature recorded in the last

24 hours.

24-Hour Min.: The minimum temperature recorded in the last

24 hours.

30s Avg. Vertical Speed: The 30-second moving average of

vertical speed.

500m Pace: The current rowing pace per 500 meters.

Average Cadence: Cycling. The average cadence for the

current activity.

Average Cadence: Running. The average cadence for the

current activity.

Average Distance Per Stroke: The average distance traveled

per stroke during the current activity.

Average HR: The average heart rate for the current activity.

Average HR %Max.: The average percentage of maximum

heart rate for the current activity.

Average Lap Time: The average lap time for the current

activity.

Average Pace: The average pace for the current activity.

Average Speed: The average speed for the current activity.

Average Stroke Rate: The average number of strokes per

minute (spm) during the current activity.

Average Strokes/Length: The average number of strokes per

length during the current activity.

Average SWOLF: The average swolf score for the current

activity. Your swolf score is the sum of the time for one length

plus the number of strokes for that length (Swim

Terminology, page 10).

Avg. 500m Pace: The average rowing pace per 500 meters for

the current activity.

Cadence: Cycling. The number of revolutions of the crank arm.

Your device must be connected to a cadence accessory for

this data to appear.

Cadence: Running. The steps per minute (right and left).

Calories: The amount of total calories burned.

Distance: The distance traveled for the current track or activity.

Distance Per Stroke: The distance traveled per stroke.

Elapsed Time: The total time recorded. For example, if you start

the timer and run for 10 minutes, then stop the timer for 5

minutes, then start the timer and run for 20 minutes, your

elapsed time is 35 minutes.

Elevation: The altitude of your current location above or below

sea level.

Floors Climbed: The total number of floors climbed up for the

day.

Floors Descended: The total number of floors climbed down for

the day.

Floors per Minute: The number of floors climbed up per minute.

Heading: The direction you are moving.

Heart Rate: Your heart rate in beats per minute (bpm). Your

device must be connected to a compatible heart rate monitor.

HR %Max.: The percentage of maximum heart rate.

HR Zone: The current range of your heart rate (1 to 5). The

default zones are based on your user profile and maximum

heart rate (220 minus your age).

Interval Distance: The distance traveled for the current interval.

Interval Distance Per Stroke: The average distance traveled

per stroke during the current interval.

Interval Lengths: The number of pool lengths completed during

the current interval.

Interval Pace: The average pace for the current interval.

Interval Stroke Rate: The average number of strokes per

minute (spm) during the current interval.

Interval Strokes: The total number of strokes for the current

interval.

Interval Strokes/Length: The average number of strokes per

length during the current interval.

Interval SWOLF: The average swolf score for the current

interval.

22 Appendix

Interval Time: The stopwatch time for the current interval.

Lap 500m Pace: The average rowing pace per 500 meters for

the current lap.

Lap Cadence: Cycling. The average cadence for the current

lap.

Lap Cadence: Running. The average cadence for the current

lap.

Lap Distance: The distance traveled for the current lap.

Lap HR: The average heart rate for the current lap.

Lap HR %Max.: The average percentage of maximum heart

rate for the current lap.

Lap Pace: The average pace for the current lap.

Laps: The number of laps completed for the current activity.

Lap Speed: The average speed for the current lap.

Lap Steps: The number of steps during the current lap.

Lap Time: The stopwatch time for the current lap.

Last Interval Distance Per Stroke: The average distance

traveled per stroke during the last completed interval.

Last Interval Stroke Rate: The average number of strokes per

minute (spm) during the last completed interval.

Last Interval Strokes: The total number of strokes for the last

completed interval.

Last Lap 500m Pace: The average rowing pace per 500 meters

for the last lap.

Last Lap Cadence: Cycling. The average cadence for the last

completed lap.

Last Lap Cadence: Running. The average cadence for the last

completed lap.

Last Lap Distance: The distance traveled for the last completed

lap.

Last Lap Pace: The average pace for the last completed lap.

Last Lap Speed: The average speed for the last completed lap.

Last Lap Time: The stopwatch time for the last completed lap.

Last Length Pace: The average pace for your last completed

pool length.

Last Length Stroke Rate: The average number of strokes per

minute (spm) during the last completed pool length.

Last Length Strokes: The total number of strokes for the last

completed pool length.

Last Length SWOLF: The swolf score for the last completed

pool length.

Lengths: The number of pool lengths completed during the

current activity.

Maximum Speed: The top speed for the current activity.

Pace: The current pace.

Speed: The current rate of travel.

Steps: The number of steps during the current activity.

Stroke Rate: The number of strokes per minute (spm).

Strokes: The total number of strokes for the current activity.

Sunrise: The time of sunrise based on your GPS position.

Sunset: The time of sunset based on your GPS position.

Temperature: The temperature of the air. Your body

temperature affects the temperature sensor.

Time in Zone: The time elapsed in each heart rate or power

zone.

Time of Day: The time of day based on your current location

and time settings (format, time zone, daylight saving time).

Timer: The stopwatch time for the current activity.

Total Ascent: The total elevation distance ascended during the

activity or since the last reset.

Total Descent: The total elevation distance descended during

the activity or since the last reset.

Vertical Speed: The rate of ascent or descent over time.

VO2 Max. Standard Ratings

These tables include standardized classifications for VO2 max. estimates by age and gender.

Males Percentile 20–29 30–39 40–49 50–59 60–69 70–79

Superior 95 55.4 54 52.5 48.9 45.7 42.1

Excellent 80 51.1 48.3 46.4 43.4 39.5 36.7

Good 60 45.4 44 42.4 39.2 35.5 32.3

Fair 40 41.7 40.5 38.5 35.6 32.3 29.4

Poor 0–40 <41.7 <40.5 <38.5 <35.6 <32.3 <29.4

Females Percentile 20–29 30–39 40–49 50–59 60–69 70–79

Superior 95 49.6 47.4 45.3 41.1 37.8 36.7

Excellent 80 43.9 42.4 39.7 36.7 33 30.9

Good 60 39.5 37.8 36.3 33 30 28.1

Fair 40 36.1 34.4 33 30.1 27.5 25.9

Poor 0–40 <36.1 <34.4 <33 <30.1 <27.5 <25.9

Data reprinted with permission from The Cooper Institute. For more information, go to www.CooperInstitute.org.

Wheel Size and Circumference

Your speed sensor automatically detects your wheel size. If

necessary, you can manually enter your wheel circumference in

the speed sensor settings.

The tire size is marked on both sides of the tire. This is not a

comprehensive list. You can also measure the circumference of

your wheel or use one of the calculators available on the

internet.

Tire Size Wheel Circumference (mm)

20 × 1.75 1515

20 × 1-3/8 1615

22 × 1-3/8 1770

22 × 1-1/2 1785

24 × 1 1753

24 × 3/4 Tubular 1785

24 × 1-1/8 1795

24 × 1.75 1890

24 × 1-1/4 1905

Appendix 23

Tire Size Wheel Circumference (mm)

24 × 2.00 1925

24 × 2.125 1965

26 × 7/8 1920

26 × 1-1.0 1913

26 × 1 1952

26 × 1.25 1953

26 × 1-1/8 1970

26 × 1.40 2005

26 × 1.50 2010

26 × 1.75 2023

26 × 1.95 2050

26 × 2.00 2055

26 × 1-3/8 2068

26 × 2.10 2068

26 × 2.125 2070

26 × 2.35 2083

26 × 1-1/2 2100

26 × 3.00 2170

27 × 1 2145

27 × 1-1/8 2155

27 × 1-1/4 2161

27 × 1-3/8 2169

29 x 2.1 2288

29 x 2.2 2298

29 x 2.3 2326

650 x 20C 1938

650 x 23C 1944

650 × 35A 2090

650 × 38B 2105

650 × 38A 2125

700 × 18C 2070

700 × 19C 2080

700 × 20C 2086

700 × 23C 2096

700 × 25C 2105

700C Tubular 2130

700 × 28C 2136

700 × 30C 2146

700 × 32C 2155

700 × 35C 2168

700 × 38C 2180

700 × 40C 2200

700 × 44C 2235

700 × 45C 2242

700 × 47C 2268

Symbol Definitions

These symbols may appear on the device or accessory labels.

WEEE disposal and recycling symbol. The WEEE symbol is

attached to the product in compliance with the EU directive

2012/19/EU on Waste Electrical and Electronic Equipment

(WEEE). It is intended to deter the improper disposal of this

product and to promote reuse and recycling.

24 Appendix

Index

accessories 18, 22

activities 9, 10, 16

adding 9

custom 9

favorites 9

saving 9

starting 9

activity tracking 7, 8

alarms 16, 17

alerts 16

ANT+ sensors 18, 19

applications 2, 3, 5, 12

smartphone 2, 9

assistance 5

Auto Lap 16

Auto Pause 17

auto scroll 17

backlight 1, 18

bands 20

battery

charging 19

maximizing 3, 18, 21

bike sensors 19

Bluetooth sensors 18

Bluetooth technology 2, 3, 5, 17, 20

headphones 5, 21

Bluetooth Technology 3

cadence

alerts 16

sensors 19

calendar 13

calibrating, compass 14

calorie, alerts 16

calories 22

charging 19

cleaning the device 20

clock 17

compass 11, 14

calibrating 14

computer 5

Connect IQ 2, 3

contacts 2

adding 2, 6

controls menu 15

countdown timer 17

courses

downloading 11

playing 11

selecting 11

customizing the device 12, 15, 16

cycling 10

data

storing 12, 15

transferring 12, 15

uploading 15

data fields 1, 3, 10, 16, 22

deleting

history 14

personal records 14

distance, alerts 16

dogleg 11

emergency contacts 2, 5, 6

foot pod 1, 19

Garmin Connect 2, 3, 5, 13, 15, 18, 20

storing data 15

Garmin Express 3

updating software 19

Garmin Pay 4

goals 18

golf round, ending 12

GPS 1

signal 21

green view, pin location 11

hazards 11

headphones 21

Bluetooth technology 5, 21

connecting 5

heart rate 1, 6

alerts 16

monitor 6

pairing sensors 6

zones 6, 7, 13, 15

history 10, 14

sending to computer 12, 15

viewing 12

icons 1

incident detection 5

indoor training 9, 10

intensity minutes 7, 22

intervals 10

keys 1, 20

laps 14, 17

layup 11

lengths 10

license 20

LiveTrack 5

locations 14

deleting 14

locking, screen 1, 17

main menu, customizing 8

maps 14

measuring a shot 11

menu 1

messages 2

music 1, 4

loading 5

playing 5

services 2, 4, 5

music controls 5

navigation 14

stopping 14

NFC 4

notifications 2, 3

phone calls 3

text messages 2

pairing

ANT+ sensors 6

sensors 18

smartphone 2, 20

payments 4

personal records 13

deleting 14

phone calls 3

pin location, green view 11

pool size

custom 10

setting 10

power (force), alerts 16

profiles, user 12

replacement parts 20

resetting the device 21

satellite signals 1, 21

saving activities 9, 10

scorecard 12

scoring 12

screen 18

settings 8, 12, 16–18, 21

device 18

shortcuts 1, 15

skiing

alpine 10

snowboarding 10

sleep mode 3, 7

smartphone 1, 3, 5, 8, 12, 20

applications 2, 3, 9

pairing 2, 20

snowboarding 10

software

updating 19, 20

version 20

specifications 20

speed and cadence sensors 1, 19

statistics 12

stopwatch 18

storing data 12, 15

stress level 8

strokes 10

swimming 10

swolf score 10

system settings 17

tempe 19, 22

temperature 19, 22

text messages 2

time 17

alerts 16

settings 17

time of day 17, 21

time zones 17

timer 9, 10

countdown 17

touchscreen 1

tracking 5

training 2

calendar 13

pages 10

plans 13

treadmill 10

troubleshooting 6, 20–22

unit ID 20

units of measure 18

updates, software 20

uploading data 15

USB 20

user profile 12

VIRB remote 9

VO2 max. 7, 23

wallet 1, 4

watch face 1

watch faces 3, 15

weather 8

wheel sizes 19, 23

Wi-Fi, connecting 3

Wi‑Fi, connecting 3

widgets 1, 3, 6, 8

workouts 13

zones

heart rate 6

time 17

Index 25

support.garmin.com

October 2018

190-02379-xx_01

Garmin A3405 Body-Worn Transmitter User Manual 2

Garmin International Inc Body-Worn Transmitter 2

Contents

User Manual 2

Navigation menu

Namespaces

Views

Navigation
