ge.com

49-80341 11-05 JR

JKP20–27 ″Single Wall Oven

JTP20–30 ″Single Wall Oven

JKP25–27″Single Wall Oven

JTP25–30″Single Wall Oven

JKP28–27 ″Double Wall Oven

JTP28–30 ″Double Wall Oven

JKP48–27 ″Double Wall Oven

JTP48–30 ″Double Wall Oven

JKP50–27 ″Double Wall Oven

JTP50–30 ″Double Wall Oven

Owner’s Manual

Safety Instructions . . . . . . .2–4

Operating Instructions

Clock and Timer . . . . . . . . . . .13

Control Lockout . . . . . . . . . . .13

Controls . . . . . . . . . . . . . . . . . . .5

Oven . . . . . . . . . . . . . . . . .11, 12

Sabbath Feature . . . . . . . . . .9, 10

Self-Cleaning Oven . . . . . .16, 17

Special Features . . . . . . . . . . .6–8

Thermostat . . . . . . . . . . . . . . .15

Timed Baking and Roasting . .14

Care and Cleaning

Broiler Pan and Grid . . . . . . . .19

Control Panel . . . . . . . . . . . . .18

Glass Surfaces . . . . . . . . . . . . .21

Heating Element . . . . . . . . . . .21

Knob . . . . . . . . . . . . . . . . . . . .18

Lift-Off Oven Door . . . . . .18, 19

Light Bulb . . . . . . . . . . . . . . . .20

Oven Interior . . . . . . . . . . . . . .21

Packaging Tape . . . . . . . . . . . .18

Painted Surfaces . . . . . . . . . . .21

Shelves . . . . . . . . . . . . . . . . . . .19

Stainless Steel Surfaces . . . . . .21

Troubleshooting Tips . . . .22–24

Consumer Support

Consumer Support . . Back Cover

Product Registration . . . . .25, 26

Warranty . . . . . . . . . . . . . . . . .27

Wall Oven

Built-In Electric

Write the model and serial

numbers here:

Model # __________________

Serial #____________________

You can find them on a label

on the side trim or on the front

of the (lower) oven behind the

oven door.

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire or

explosion, electric shock, or to prevent property damage, personal injury, or loss of life.

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to

publish a list of substances known to the state to cause cancer, birth defects or other reproductive

harm, and requires businesses to warn customers of potential exposure to such substances.

The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during

the cleaning cycle. Exposure can be minimized by venting with an open window or using a ventilation

fan or hood.

When using electrical appliances, basic safety precautions should be followed, including the following:

■Use this appliance only for its intended

purpose as described in this Owner’s

Manual.

■Be sure your appliance is properly

installed and grounded by a qualified

technician in accordance with the

provided installation instructions.

■ Do not attempt to repair or replace any

part of your oven unless it is specifically

recommended in this manual. All other

servicing should be referred to a qualified

technician.

■ Have the installer show you the location

of the circuit breaker or fuse. Mark it for

easy reference.

■ Before performing any service, disconnect

the oven power supply at the household

distribution panel by removing the fuse or

switching off the circuit breaker.

■ Do not leave children alone—children

should not be left alone or unattended in

an area where an appliance is in use. They

should never be allowed to sit or stand on

any part of the appliance.

■ Do not allow anyone to climb, stand or

hang on the door. They could damage the

oven, or cause severe personal injury.

■ Be sure the oven is securely installed in a

cabinet that is firmly attached to the house

structure. Never allow anyone to climb, sit,

stand or hang on the oven door.

■ Never leave the oven door open when you

are not watching the oven.

■ Always keep combustible wall coverings,

curtains or drapes a safe distance from

your oven.

■ Always keep dish towels, dish cloths, pot

holders and other linens a safe distance

from your oven.

■ Always keep wooden and plastic utensils

and canned food a safe distance away from

your oven.

■ Teach children not to play with the

controls or any other part of the oven.

■ Large scratches or impacts to glass doors

can lead to broken or shattered glass.

SAFETY PRECAUTIONS

2

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

3

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

ge.com

■ Do not store flammable materials in

an oven.

■ CAUTION: Items of interest to

children should not be stored in cabinets

above an oven; children climbing on the

oven to reach items could be seriously

injured.

■ Never wear loose-fitting or hanging

garments while using the appliance. Be

careful when reaching for items stored

in cabinets over the oven. Flammable

material could be ignited if brought in

contact with hot surfaces or heating

elements and may cause severe burns.

■ Use only dry pot holders—moist or damp

pot holders on hot surfaces may result in

burns from steam. Do not let pot holders

touch hot heating elements. Do not use a

towel or other bulky cloth.

■ For your safety, never use your appliance

for warming or heating the room.

■ Do not let cooking grease or other

flammable materials accumulate in

or near the oven.

■ Do not use water on grease fires. Never

pick up a flaming pan. Turn the controls

off.

■Flame in the oven can be smothered

completely by closing the oven door and

turning the oven off or by using a multi-

purpose dry chemical or foam-type fire

extinguisher.

■ Never leave jars or cans of fat drippings in

or near your oven.

■ Do not store or use combustible materials,

gasoline or other flammable vapors and

liquids in the vicinity of this or any other

appliance.

■ Stand away from the oven when opening

the oven door. Hot air or steam which

escapes can cause burns to hands, face

and/or eyes.

■ Do not heat unopened food containers.

Pressure could build up and the container

could burst, causing an injury.

■ Keep the oven vent unobstructed.

■ Keep the oven free from grease buildup.

■ Place the oven shelf in the desired position

while the oven is cool. If shelves must be

handled when hot, do not let pot holder

contact the heating elements.

■ When using cooking or roasting bags

in the oven, follow the manufacturer’s

directions.

■ Do not touch the heating elements or the

interior surface of the oven. These surfaces

may be hot enough to burn even though

they are dark in color. During and after

use, do not touch, or let clothing or other

flammable materials contact any interior

area of the oven; allow sufficient time for

cooling first.

■Potentially hot surfaces include oven vent

openings, surfaces near the openings,

crevices around the oven door, the edges

of the window and metal trim parts above

the door.

■REMEMBER: The inside surface of the oven

may be hot when the door is opened.

WARNING!

SAFETY PRECAUTIONS

■ Pulling out the shelf to the stop-lock is a

convenience in lifting heavy foods. It is

also a precaution against burns from

touching hot surfaces of the door or

oven walls.

■ Do not use the oven to dry newspapers.

If overheated, they can catch on fire.

■ Do not use the oven for a storage area.

Items stored in an oven can ignite.

■ Do not leave paper products, cooking

utensils or food in the oven when not

in use.

■ After broiling, always take the broiler pan

out of the oven and clean it. Leftover

grease in the broiler pan can catch fire

next time you use the pan.

■ Clean only parts listed in this Owner’s

Manual.

■ Do not use aluminum foil to line oven

bottoms, except as suggested in this

manual. Improper installation of

aluminum foil may result in a risk

of electric shock or fire.

Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry

to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against

foodborne illness.

COOK MEAT AND POULTRY THOROUGHLY…

■Do not clean the door gasket. The door

gasket is essential for a good seal. Care

should be taken not to rub, damage or

move the gasket.

■Do not use oven cleaners. No commercial

oven cleaner or oven liner protective

coating of any kind should be used in or

around any part of the oven. Residue from

oven cleaners will damage the inside of the

oven when the self-clean cycle is used.

■Before self-cleaning the oven, remove the

broiler pan, grid and other cookware.

■Be sure to wipe up excess spillage before

starting the self-cleaning operation.

■If the self-cleaning mode malfunctions,

turn the oven off and disconnect the

power supply. Have it serviced by a

qualified technician.

SELF-CLEANING OVEN

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

4

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting Tips

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

SAFETY PRECAUTIONS

Consumer Support

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Using the oven controls. ge.com

Oven Control, Clock and Timer Features and Settings

BAKE Pad

Press this pad to select the bake function.

BROIL HI/LO Pad

Press this pad to select the broil function.

SELF CLEAN STD/LOW Pad

Press this pad to select the self-cleaning

function. See the Using the self-cleaning oven

section.

START Pad

Must be pressed to start any cooking or

cleaning function.

Display

Shows the time of day, oven temperature,

whether the oven is in the bake, broil or self-

cleaning mode and the times set for the

timer or automatic oven operations.

If “F — and a number or letter” flash in the display

and the oven control signals, this indicates a

function error code. Press the CLEAR/OFF pad. Allow the

oven to cool for one hour. Put the oven back into operation. If

the function error code repeats, disconnect the power to the

oven and call for service.

If your oven was set for a timed oven operation and

a power outage occurred, the clock and all programmed

functions must be reset.

The time of day will flash in the display when there

has been a power outage.

OVEN LIGHT ON/OFF Pad

Press this pad to turn the oven light on or off.

DELAY START Pad

Use along with COOKING TIME or SELF

CLEAN pads to set the oven to start and stop

automatically at a time you set.

COOKING TIME Pad

Press this pad and then press the HOUR and

MIN + and – pads to set the amount of time

you want your food to cook. The oven will

shut off automatically when the cooking time

has run out unless the Cook and Hold

feature was set.

CLEAR/OFF Pad

Press this pad to cancel ALL oven

operations except the clock and timer.

TEMP + and – Pads

Press these pads to set the cooking

temperature you want to use.

CLOCK Pad

Press this pad before setting the clock.

HOUR and MIN + and – Pads

Press these pads to set times up to 9 hours

and 59 minutes—for example, the time of

day on the clock, the timer, the starting and

length of cooking time for timed bake and

the starting and length of cleaning time

for self-clean.

KITCHEN TIMER ON/OFF Pad

Press this pad to select the timer feature.

Double oven control shown

Lower Oven Control Settings on models with a knob

OVEN Knob

Turn this knob to

the temperature

setting you want.

The OVEN CYCLE light glows until the oven reaches your

selected temperature, then goes off and on with the oven

element(s) during cooking.

5

Throughout this manual, features and appearance may vary from your model.

Special features of your oven control.

Your new touch pad control has additional features that you may choose to use. The following are the features

and how you may activate them.

The special feature modes can only be activated while the display is showing the time of day. They remain

in the control’s memory until the steps are repeated.

When the display shows your choice, press the START pad. The special features will remain in memory after

a power failure, except for the Sabbath feature, which will have to be reset.

12-Hour Shut-Off

With this feature, should you forget and leave the

oven on, the control will automatically turn off the

oven after 12 hours during baking functions or

after 3 hours during a broil function.

If you wish to turn OFF this feature, follow

the steps below.

Press the upper oven BAKE and

BROIL HI/LO pads at the same time

for 3 seconds until the display

shows SF.

Press the DELAY START pad until

no shdn (no shut-off) appears in the

display.

Press the START pad to lock in the

no shdn (no shut-off) feature and

leave the control set in this special

features mode.

NOTE:

■On models with touch pad controls for both

ovens, this activates this special feature for

both ovens.

■On models with oven knob(s), this feature is

not available for the lower oven.

Fahrenheit or Celsius Temperature Selection

Your oven control is set to use the Fahrenheit

temperature selections but you may change this

to use the Celsius selections.

Press the upper oven BAKE and

BROIL HI/LO pads at the same time

for 3 seconds until the display

shows SF.

Press the BROIL HI/LO and COOKING

TIME pads at the same time. The

display will show F(Fahrenheit).

Press the BROIL HI/LO and COOKING

TIME pads again at the same time.

The display will show C(Celsius).

Press the START pad.

NOTE:

■On models with touch pad controls for both

ovens, the new setting will be displayed for

both ovens.

■On models with oven knob(s), this feature is

not available for the lower oven.

6

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

7

ge.com

Tones at the End of a Timed Cycle

At the end of a timed cycle, 3 short beeps will

sound followed by one beep every 6 seconds until

the CLEAR/OFF pad is pressed. This continuous

6-second beep may be canceled.

To cancel the 6-second beep:

Press the upper oven BAKE and

BROIL HI/LO pads at the same time

for 3 seconds until the display

shows SF.

Press the KITCHEN TIMER ON/OFF

pad. The display shows CON BEEP

(continuous beep). Press the

KITCHEN TIMER ON/OFF pad again.

The display shows BEEP. (This

cancels the one beep every 6

seconds.)

Press the START pad.

NOTE:

■On models with touch pad controls for both

ovens, this cancels the end of cycle tone for

both ovens.

■On models with oven knob(s), this feature is

not available for the lower oven.

12-Hour, 24-Hour or Clock Black-Out

Your control is set to use a 12-hour clock.

If you would prefer to have a 24-hour

military time clock or black out the clock

display, follow the steps below.

Press the upper oven BAKE and

BROIL HI/LO pads at the same time

for 3 seconds, until the display

shows SF.

Press the CLOCK pad once. The

display will show 12 hr. If this is

the choice you want, press the

START pad.

Press the CLOCK pad again to

change to the 24-hour military time

clock. The display will show 24 hr. If

this is the choice you want, press the

START pad.

Press the CLOCK pad again to black

out the clock display. The display

will show OFF. If this is the choice

you want, press the START pad.

NOTE: If the clock is in the black-out mode, you

will not be able to use the Delay Start function.

Cook and Hold

Your new control has a cook and hold feature that

keeps cooked foods warm for up to 3 hours after

Timed Baking or Roasting is finished.

NOTE: This feature can only be programmed to

work with Timed Baking or Roasting. (See the

Using the timed baking and roasting features

section.) After Timed Baking or Roasting has

automatically stopped, the programmed Cook

and Hold will automatically start.

To activate this feature for use after

Timed Baking or Roasting, follow the

steps below.

Both touch pad ovens follow the

same step 1. First press the upper

oven BAKE and BROIL HI/LO pads at

the same time for 3 seconds until

the display shows SF. Then proceed

with steps 2 through 3, using the

pads for the upper or lower oven.

Press the COOKING TIME pad. The

display will show Hld OFF.

Press the COOKING TIME pad again

to activate the feature. The display

will show Hld ON.

Press the START pad to activate the

cook and hold feature and leave the

control set in this special features

mode.

NOTE: On models with oven knob(s), this feature

is not available for the lower oven.

Changing the Speed of the + or – Pads

As you use the + or – pads when setting a time

or temperature, you may notice the display

changes slowly. This special feature allows you to

change the speed. To set the speed you prefer,

follow the steps below.

Press the upper oven BAKE and

BROIL HI/LO pads at the same time

for 3 seconds, until the display

shows SF.

Press any +pad. The display will

show you a set speed between 1

and 5.

Press any +pad to increase the

speed up to the number 5.

Press any –pad to decrease the

speed down to the number 1.

Press START to activate the setting

and leave the control set in this

special features mode.

8

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

Special features of your oven control.

NOTE: To understand how the oven control works,

practice using regular (non-Sabbath) Immediate Start

and Automatic Stop before entering the Sabbath mode.

Make sure the clock shows the correct time

of day.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the DELAY START pad until SAb bAtH

appears in the display.

Press the START pad and ⊃ will appear

in the display.

Press the COOKING TIME pad.

Press the HOUR and MIN + or –pads to

set the desired length of cooking time

between 1 minute and 9 hours and 59

minutes. The cooking time that you

entered will be displayed.

Press the START pad.

Press the BAKE pad. No signal will

be given.

The preset starting temperature will

automatically be set to 350°. Tap the

TEMP + or –pads to increase or decrease

the temperature in 5° increments.

(The TEMP + or –pad should be tapped

for each temperature change; pressing

and holding these pads will not allow

accurate temperature setting.) The

temperature can be set between 170°

and 550°. No signal or temperature

will be given.

Press the START pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃will appear in the display indicating

that the oven is baking/roasting.

If ⊃does not appear in the display,

start again at step 7.

To adjust the oven temperature, press the

BAKE pad and tap the TEMP + or –pads to

increase or decrease the temperature in 5°

increments. (The TEMP + or –pad should be

tapped for each temperature change; pressing

and holding these pads will not allow accurate

temperature setting.) Press the START pad.

When cooking is finished, the display will

change from ⊃to ⊃and 0:00 will appear,

indicating that the oven has turned OFF

but is still set in Sabbath. Remove the

cooked food.

⊃

⊃

⊃

9

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

How to Set Sabbath Feature for Timed Baking/Roasting

– Immediate Start and Automatic Stop

Using the Sabbath Feature.

(Designed for use on the Jewish Sabbath and Holidays.) (on some models) ge.com

The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning

or Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the

door is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch on

the control panel, the oven light may be turned on and left on.

How to Set Sabbath Feature for Regular Baking/Roasting

NOTE: To understand how the oven control works,

practice using regular baking (non-Sabbath) before

entering Sabbath mode.

Make sure the clock shows the correct time

of day.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the DELAY START pad until

SAb bAtH appears in the display.

Press the START pad and ⊃ will appear

in the display.

Press the BAKE pad. No signal will

be given.

The preset starting temperature will

automatically be set to 350°. Tap the

TEMP + or – pads to increase or decrease

the temperature in 5° increments. (The

TEMP + or –pad should be tapped for

each temperature change; pressing and

holding these pads will not allow

accurate temperature setting.) The

temperature can be set between 170°

and 550°. No signal or temperature will

be given.

Press the START pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃will appear in the display indicating

that the oven is baking/roasting. If ⊃

does not appear in the display, start

again at step 4.

To adjust the oven temperature, press the

BAKE pad and tap the TEMP + or –pads to

increase or decrease the temperature in 5°

increments. (The TEMP + or –pad should be

tapped for each temperature change; pressing

and holding these pads will not allow accurate

temperature setting.) Press the START pad.

NOTE: The CLEAR/OFF and COOKING TIME

pads are active during the Sabbath feature.

⊃

⊃

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃the oven is

baking/roasting.

⊃

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃the oven is

baking/roasting.

⊃

Using the Sabbath feature.

How to Exit the Sabbath Feature

Press the CLEAR/OFF pad.

If the oven is cooking, wait

for a random delay period of

approximately 30 seconds to 1

minute, until only ⊃ is in the display.

Press and hold both the BAKE and

BROIL HI/LO pads, at the same time,

until the display shows SF.

Tap the DELAY START pad until

12 shdn or no shdn appears in the

display. 12 shdn indicates that the

oven will automatically turn off after

12 hours. no shdn indicates that the

oven will not automatically turn off.

Press the START pad.

NOTE: If a power outage occurred while

the oven was in Sabbath mode, the oven

will automatically turn off and the oven

control must be reset.

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

10

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Using the oven. ge.com

To avoid possible burns, place the shelves in the desired position before you turn the oven on.

Before you begin…

The shelves have stop-locks, so that when

placed correctly on the supports, they will

stop before coming completely out, and

will not tilt.

When placing and removing cookware,

pull the shelf out to the bump on the

shelf support.

To remove a shelf, pull it toward you, tilt

the front end up and pull it out.

To replace, place the end of the shelf

(stop-locks) on the support, tilt up the

front and push the shelf in.

NOTE: 30 ″ovens (shown) have 6 shelf positions.

27 ″ovens have 4 shelf positions.

How to Set the Oven for Baking or Roasting

Press the BAKE pad.

Press the TEMP + or –pads to set

the desired temperature.

Press the START pad.

Check food for doneness at

minimum time on recipe. Cook longer

if necessary.

Press the CLEAR/OFF pad when

cooking is complete.

NOTE: On some models, the lower oven is

controlled with a knob. To set the oven for

baking, turn the knob to the desired setting or

temperature. Turn the knob to OFF when baking

is complete.

NOTE: A cooling fan may automatically turn on

and off to cool internal parts. This is normal, and

the fan may continue to run even after the oven is

turned off.

Oven Shelf Positions

Type of Food 27” 30”

Frozen pies B or C C or D

(on cookie sheet)

Angel food cake A B

Bundt or pound cakes B B

Biscuits, muffins, B or C C or D

brownies, cookies,

cupcakes, layer

cakes, pies

Casseroles B or C C or D

Preheating and Pan Placement

Preheat the oven if the recipe calls for it.

To preheat, set the oven at the correct

temperature. Preheating is necessary for

good results when baking cakes, cookies,

pastry and breads.

For ovens without a preheat indicator light or

tone, preheat 10 minutes.

Baking results will be better if baking

pans are centered in the oven as much as

possible. Pans should not touch each

other or the walls of the oven. If you

need to use two shelves, stagger the pans

so one is not directly above the other,

and leave approximately 11⁄2″between

pans, from the front, back and sides of

the wall.

Aluminum Foil

You can use aluminum foil to line the

broiler pan and broiler grid. However,

you must mold the foil tightly to the grid

and cut slits in it just like the grid.

Aluminum foil may also be used to catch a

spillover.

Never entirely cover a shelf with

aluminum foil. This will disturb the heat

circulation and result in poor baking.

A smaller sheet of foil may be used to

catch a spillover by placing it on a lower

shelf several inches below the food.

Cut slits in the foil just like the grid.

11

How to Set the Oven for Broiling

Leave the door open to the broil stop position.

The door stays open by itself, yet the proper

temperature is maintained in the oven.

NOTE: Food can be broiled with the door

closed but it may not brown as well because

the oven heating element will cycle on and off.

Place the meat or fish on the broiler

grid in the broiler pan.

Follow suggested shelf positions in

the Broiling Guide.

The size, weight, thickness, starting

temperature and your preference of

doneness will affect broiling times. This

guide is based on meats at refrigerator

temperature.

Press the BROIL HI/LO pad once for

HI Broil.

To change to LO Broil, press the

BROIL HI/LO pad again.

Press the START pad.

When broiling is finished, press the

CLEAR/OFF pad.

NOTE: On some models, the lower oven is

controlled with a knob. To set the oven for broiling,

turn the knob to BROIL. Turn the knob to OFF

when broiling is complete.

Broiling Guide

27” 27” Ovens 27” Ovens 30” Ovens 30” Ovens 30” Ovens

Quantity and/ Ovens Shelf First Side Second Side Shelf First Side Second Side

Food or Thickness Position Time (min.) Time (min.) Position Time (min.) Time (min.) Comments

Ground Beef 1 lb. (4 patties) C 10 7 E 10 7 Space evenly. Up

Well Done 1/2 to 3/4″thick E 10 9 to 8 patties take

about the same

time.

Beef Steaks

Rare † 1″thick C 6 5 E 8 6 Steaks less than

Medium 1 to 11⁄2lbs. C 8 6 E 10 8 1″thick cook

Well Done C 12 11 E 12 10 through before

browning.

Rare † 11⁄2″thick C 10 7–8 E 10 8 Pan frying is

Medium 2 to 21⁄2lbs. C 15 14–16 E 15 14–16 recommended.

Well Done C 25 20–25 E 25 20–25 Slash fat.

Chicken 1 whole A 35 10–15 C 25 10 Reduce time about

2 to 21⁄2lbs., 5 to 10 minutes

split lengthwise per side for cut-up

chicken. Brush

each side with

melted butter.

Broil skin-side-

down first.

Lobster Tails 2–4 B 13–16 Do not C 13–16 Do not Cut through back of

6 to 8 oz. each turn over. turn over. shell. Spread open.

Brush with melted

butter before

broiling and after

half of broiling

time.

Fish Fillets 1/4 to 1/2″thick C 5 5 E 5 5 Handle and turn

very carefully.

Brush with lemon

butter before and

during cooking, if

desired. Preheat

broiler to increase

browning.

Ham Slices 1″thick B 8 8 D 8 8 Increase time 5 to

(precooked) 10 minutes per

side for 11⁄2″thick

or home-cured ham.

Pork Chops 2 (1/2″thick) C 10 10 E 10 10 Slash fat.

Well Done 2 (1″thick) about 1 lb. B 13 13 D 15 15

Lamb Chops

Medium 2 (1″thick) about 10 C 10 9 E 10 9 Slash fat.

Well Done to 12 oz. C 12 10 E 12 10

Medium 2 (11⁄2″thick) about 1 lb. C 14 12 E 14 12

Well Done B 17 12–14 E 17 12–14

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

Using the oven.

12

If your oven is connected to 208 volts,

rare steaks may be broiled by

preheating the broiler and positioning

the oven shelf one position higher.

† The U.S. Department of Agriculture says “Rare beef is popular, but you should know that cooking it to only 140°F means some food poisoning

organisms may survive.” (Source: Safe Food Book. Your Kitchen Guide. USDA Rev. June 1985.)

Your control will allow you to lock out the touch

pads so they cannot be activated when pressed.

NOTE: On models with touch pad controls

for both ovens, this activates this feature for

both ovens.

To lock/unlock the controls:

Press the HOUR and MIN – pads at

the same time for 3 seconds until

the display shows LOC ON.

To unlock the control, press the

HOUR and MIN – pads at the same

time for 3 seconds until the display

shows LOC OFF.

When this feature is on and the touch

pads are pressed, the control will beep

and the display will show LOC ON.

■ The control lockout mode affects all touch

pads. No touch pads will work when this

feature is activated.

■ On models with oven knob(s), this feature is

not available for the lower oven.

■ This adjustment will be retained in memory

after a power failure.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Using the clock and timer. ge.com

13

To Set the Clock

The clock must be set to the correct time

of day for the automatic oven timing

functions to work properly. The time of

day cannot be changed during a timed

baking or self-cleaning cycle.

Press the CLOCK pad.

Press the HOUR and MIN + or

–pads to set the time of day.

Press the START pad.

Make sure the clock is set to the

correct time of day.

To Set the Timer

Press the KITCHEN TIMER

ON/OFF pad.

Press the HOUR and MIN + or

–pads until the amount of time

you want shows in the display.

The maximum time you can enter

in minutes is 59. Cooking times

more than 59 minutes should be

changed to hours and minutes.

For example, enter 90 minutes as

1 hour, 30 minutes.

If you make a mistake, press

KITCHEN TIMER ON/OFF and

begin again.

Press the START pad.

After pressing the START pad, SET disappears;

this tells you the time is counting down, although

the display does not change until one minute

has passed. Seconds will not be shown in the

display until the last minute is counting down.

When the timer reaches :00, the

control will beep 3 times followed

by one beep every 6 seconds until

the KITCHEN TIMER ON/OFF pad

is pressed.

The 6-second tone can be canceled by following

the steps in the Special features of your oven

control section under Tones at the End of a

Timed Cycle.

The timer is a minute timer only.

The timer does not control oven

operations. The maximum setting on

the timer is 9 hours and 59 minutes.

To Reset the Timer

If the display is still showing the time

remaining, you may change it by pressing

the KITCHEN TIMER ON/OFF pad, then

press the HOUR and MIN + or –pads

until the time you want appears in the

display.

If the remaining time is not in the display

(clock, delay start or cooking time are in

the display), recall the remaining time by

pressing the KITCHEN TIMER ON/OFF pad

and then pressing the HOUR and MIN +

or –pads to enter the new time you

want.

To Cancel the Timer

Press KITCHEN TIMER ON/OFF pad twice.

Control Lockout

Using the timed baking and roasting features. (on some models)

On models with touch pad controls for both ovens, you can use timed baking in one oven while using self-clean

in the other; you can also use timed baking in both ovens at the same time.

NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit for

more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that

the oven light is off because heat from the bulb will speed harmful bacteria growth.

How to Set an Immediate Start and Automatic Stop

The oven will turn on immediately and cook for a

selected length of time. At the end of the cooking

time the oven will turn off automatically.

Make sure the clock shows the correct

time of day.

Press the BAKE pad.

Using the TEMP + or –pads, enter

the desired temperature.

Press the COOKING TIME pad.

NOTE: If your recipe requires preheating, you

may need to add additional time to the length of

the cooking time.

Using the HOUR and MIN + or –

pads, enter the desired baking time.

The maximum time you can enter

in minutes is 59. Cooking times

more than 59 minutes should be

changed to hours and minutes.

For example, enter 90 minutes as

1 hour, 30 minutes.

The oven temperature and the cooking

time that you entered will be displayed.

Press the START pad.

The display shows the oven temperature

that you set and the cooking time

countdown. The display starts changing

once the temperature reaches 100°F.

NOTE: When using both ovens at the same

time, the times showing in the display will

be for the last oven set. To display the time

set for the first oven set, press the COOKING

TIME pad for that oven.

The oven will continue to cook for the

programmed amount of time, then shut

off automatically, unless the Cook and

Hold feature was set. See the Special

features of your oven control section.

Press the CLEAR/OFF pad to clear the

display.

How to Set a Delayed Start and Automatic Stop

You can set the oven control to delay-start the

oven, cook for a specific length of time and then

turn off automatically.

Make sure the clock shows the correct

time of day.

Press the BAKE pad.

Using the TEMP + or –pads, enter

the desired temperature.

Press the COOKING TIME pad.

NOTE: If your recipe requires preheating, you

may need to add additional time to the length of

the cooking time.

Using the HOUR and MIN + or –

pads, enter the desired baking time.

The maximum time you can enter

in minutes is 59. Cooking times

more than 59 minutes should be

changed to hours and minutes.

For example, enter 90 minutes as

1 hour, 30 minutes.

The oven temperature and the cooking

time that you entered will be displayed.

Press the DELAY START pad.

Using the HOUR and MIN + or –

pads, enter the time of day you

want the oven to turn on and

start cooking.

Press the START pad.

NOTE: An attention tone will sound if you are

using timed baking and do not press the START

pad after entering the baking temperature.

If you would like to check the times you

have set, press the DELAY START pad to

check the start time you have set or press

the COOKING TIME pad to check the

length of cooking time you have set.

When the oven turns on at the time of

day you have set, the display will show the

changing temperature (starting at 100°F)

and the cooking time countdown. The

display starts changing once the

temperature reaches 100°F.

NOTE: When using both ovens at the same

time, the times showing in the display will

be for the last oven set. To display the time

set for the first oven set, press the COOKING

TIME pad for that oven.

The oven will continue to cook for the

programmed amount of time, then shut

off automatically, unless the Cook and

Hold feature was set. See the Special

features of your oven control section.

Press the CLEAR/OFF pad to clear the

display.

14

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

15

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Adjust the oven thermostat—Do it yourself! ge.com

You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to

become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat yourself.

Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven.

These thermometers may vary 20–40 degrees.

NOTE: This adjustment will only affect baking and roasting temperatures; it does not affect broiling or self-cleaning

temperatures. The adjustment will be retained in memory after a power failure.

To Adjust the Oven Thermostat (on some models)

Both touch pad ovens follow the

same step 1. First press the upper

oven BAKE and BROIL HI/LO pads at

the same time for 3 seconds until

the display shows SF. Then proceed

with steps 2 through 4, using the

pads for the upper or lower oven.

Press the BAKE pad. A two-digit

number shows in the display.

The oven temperature can be

adjusted up to (+) 35°F hotter or

(-) 35°F cooler. Press the TEMP +

pad to increase the temperature in

1-degree increments. Press the

TEMP – pad to decrease the

temperature in 1-degree increments.

When you have made the

adjustment, press the START pad to

go back to the time of day display.

Use your oven as you would

normally.

To Adjust the Oven Thermostat (on some models)

Pull the OVEN knob off the shaft, look

at the back of the knob and note the

current setting before making any

adjustment. The knob is factory set with

the top screw directly under the pointer.

Pull off the OVEN knob.

Loosen both screws on back of

the knob.

Hold both parts of the knob as

shown in the illustration of the back

of the OVEN knob and turn so the

lower screw moves in the desired

direction.

You will hear and feel the notches as

you turn the knob. Each notch changes

temperature about 10° Fahrenheit.

Tighten the screws.

Return the OVEN knob to the oven.

Re-check oven performance before making any

additional adjustments.

The type of margarine will affect baking performance!

Most recipes for baking have been developed using high-fat products such as butter or margarine (80% fat). If you

decrease the fat, the recipe may not give the same results as with a higher-fat product.

Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low-fat spreads. The lower the fat

content of a spread product, the more noticeable these differences become.

Federal standards require products labeled “margarine” to contain at least 80% fat by weight. Low-fat spreads, on the

other hand, contain less fat and more water. The high moisture content of these spreads affect the texture and flavor

of baked goods. For best results with your old favorite recipes, use margarine, butter or stick spreads containing

at least 70% vegetable oil.

Turn the disk counterclockwise to

increase the oven temperature.

Turn the disk clockwise to decrease

the oven temperature.

Using the self-cleaning oven. (on some models)

The oven door must be closed and all controls must be set correctly for the cycle to work properly.

Before a Clean Cycle

We recommend venting your kitchen

with an open window or using a

ventilation fan or hood during the

first self-clean cycle.

Remove the broiler pan, broiler grid, all

cookware and any aluminum foil from

the oven.

The oven shelves can be self-cleaned, but

they will darken, lose their luster and

become hard to slide.

Do not use abrasives or oven cleaners.

Clean the top, sides and outside of the

oven door with soap and water.

Make sure the oven light bulb cover

(on some models) is in place and the

oven light is off.

IMPORTANT: The health of some birds

is extremely sensitive to the fumes given

off during the self-cleaning cycle of any

oven. Move birds to another well

ventilated room.

■On models with touch pad controls

for both ovens, you can set a clean

cycle in both ovens at the same time.

The last oven set will automatically

delay its start until the end of the first

oven’s clean cycle.

■On models with touch pad controls for

both ovens, you can use timed baking

in one oven and self-clean the other at

the same time.

■On models with a knob, the lower

oven does not have the self-clean

feature.

Wipe up heavy soil on the oven

bottom. (appearance may vary)

How to Set the Oven for Cleaning

Press the SELF CLEAN STD/LOW pad

once for a 4-hour clean time or

twice for a 3-hour clean time.

A 3-hour self-clean time is

recommended for use when

cleaning small, contained spills. A

self-clean time of 4 hours or longer

is recommended for a dirtier oven.

If a time other than 4 hours or

3 hours is needed, use the HOUR

and MIN + or –pads and enter

the desired clean time.

You can change the clean time to any

time between 3 hours and 5 hours,

depending on how dirty your oven is.

Press the START pad.

The door locks automatically. The display

will show the clean time remaining. It will

not be possible to open the oven door

until the temperature drops below the

lock temperature and the LOCKED light

goes off.

When the LOCKED light goes off, you will

be able to open the door.

■The word LOCK will flash and the oven

control will signal if you set the clean

cycle and forget to close the oven door.

■To stop a clean cycle, press the

CLEAR/OFF pad. When the LOCKED light

goes off indicating the oven has cooled

below the locking temperature, you

will be able to open the door.

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

16

17

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

ge.com

The oven door must be closed and all controls must be set correctly for the cycle to work properly.

How to Delay the Start of Cleaning

Press the SELF CLEAN STD/LOW pad

once for a 4-hour clean time or

twice for a 3-hour clean time.

A 3-hour self-clean time is

recommended for use when

cleaning small, contained spills. A

self-clean time of 4 hours or longer

is recommended for a dirtier oven.

If a time other than 4 hours or

3 hours is needed, use the HOUR

and MIN + or –pads and enter

the desired clean time.

You can change the clean time to any

time between 3 hours and 5 hours,

depending on how dirty your oven is.

Press the DELAY START pad.

Using the HOUR and MIN + or –

pads, enter the time of day you want

the clean cycle to start.

Press the START pad.

The door locks automatically. The display

will show the start time. It will not be

possible to open the oven door until

the temperature drops below the lock

temperature and the LOCKED light

goes off.

When the LOCKED light goes off, you will

be able to open the door.

NOTE: On models with touch pad controls for

both ovens, you can set a delay clean in both

ovens at the same time. The second oven set will

automatically delay the start of cleaning until the

end of the first oven’s clean cycle.

To recall the start time of the second oven set,

press the DELAY START pad on the controls for

the second oven.

After a Clean Cycle

You may notice some white ash in the

oven. Wipe it up with a damp cloth after

the oven cools.

If white spots remain, remove them with a

soap-filled scouring pad and rinse thoroughly with

a vinegar and water mixture.

These deposits are usually a salt

residue that cannot be removed by

the clean cycle.

If the oven is not clean after one clean

cycle, repeat the cycle.

■You cannot set the oven for cooking

until the oven is cool enough for the

door to unlock.

■ If the shelves become hard to

slide, wipe the shelf supports with

cooking oil.

18

Safety InstructionsOperating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

Carefully grasp a corner of the protective

shipping film with your fingers and slowly

peel it from the appliance surface. Do

not use any sharp items to remove the

film. Remove all of the film before using

the appliance for the first time.

To assure no damage is done to the

finish of the product, the safest way to

remove the adhesive from packaging

tape on new appliances is an application

of a household liquid dishwashing

detergent. Apply with a soft cloth and

allow to soak.

NOTE: The adhesive must be removed from all

parts. It cannot be removed if it is baked on.

Care and cleaning of the oven.

Be sure electrical power is off and all surfaces are cool before cleaning any part of the oven.

How to Remove Protective Shipping Film and Packaging Tape

The door is very heavy. Be careful when

removing and lifting the door.

Do not lift the door by the handle.

To remove the door:

Fully open the door.

Pull the hinge locks down toward

the door frame, to the unlocked

position. A tool, such as a small

flat-blade screwdriver, may be

required.

Firmly grasp both sides of the door

at the top.

Close door to the door removal

position, which is halfway between

the broil stop position and fully

closed.

Lift door up and out until the hinge

arm is clear of the slot.

To replace the door:

Firmly grasp both sides of the door

at the top.

With the

door at the

same angle as

the removal

position, seat the

indentation of

the hinge arm

into the bottom

edge of the hinge

slot. The notch in the hinge arm

must be fully seated into the bottom

of the slot.

Fully open the door. If the door will

not fully open, the indentation is

not seated correctly in the bottom

edge of the slot.

Push the hinge locks up against the

front frame of the oven cavity, to the

locked position.

Close the oven door.

Lift-Off Oven Door

Removal position

Indentation

Bottom

edge

of slot

Hinge lock

Slot

Push hinge locks up to lock

Pull hinge locks down to unlock

Hinge lock

Hinge arm

Hinge

arm

Control Knob (on some models)

The control knobs may be removed for easier

cleaning.

Make sure the knobs are in the OFF

positions and pull them straight off the

stems for cleaning.

The knobs can be cleaned in a

dishwasher or they may also be washed

with soap and water. Make sure the inside

of the knobs are dry before replacing.

Replace the knobs in the OFF position to

ensure proper placement.

Control Panel

It’s a good idea to wipe the control

panel after each use. Clean with mild

soap and water or vinegar and water,

rinse with clean water and polish dry

with a soft cloth.

Do not use abrasive cleansers, strong

liquid cleansers, plastic scouring pads or

oven cleaners on the control panel—they

will damage the finish. A 50/50 solution

of vinegar and hot water works well.

Spring clip

Clear groove

in stem

Molded rib

Broiler Pan & Grid

Do not clean the broiler pan or grid in a

self-cleaning oven.

After broiling, remove the broiler pan

from the oven. Remove the grid from the

pan. Carefully pour out the grease from

the pan into a proper container.

Wash and rinse the broiler pan and grid

in hot water with a soap-filled or plastic

scouring pad.

If food has burned on, sprinkle the grid

with detergent while hot and cover with

wet paper towels or a dishcloth. Soaking

the pan will remove burned-on foods.

Both the broiler pan and grid may be

cleaned with a commercial oven cleaner.

Both the broiler pan and grid can also be

cleaned in a dishwasher.

After broiling, remove the broiler

pan from the oven.

Do not store a soiled broiler pan and

grid anywhere in the oven.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Do not rub or clean the door gasket—

it has an extremely low resistance to

abrasion.

If you notice the gasket becoming worn,

frayed or damaged in any way or if it has

become displaced on the door, you should

have it replaced.

Oven Shelves

Clean the oven shelves with an abrasive

cleanser or soap-filled scouring pad.

After cleaning, rinse the shelves with

clean water and dry with a clean cloth.

NOTE: The oven shelves may be cleaned in the

self-cleaning oven. However, the shelves will

darken in color, lose their luster and become hard

to slide if cleaned during the self-cleaning cycle.

You can wipe the shelf supports with cooking

oil after self-cleaning to make the shelves slide

more easily.

19

ge.com

To clean the inside of the door:

■ Because the area inside the gasket is

cleaned during the self-clean cycle, you

do not need to clean this by hand.

■ The area outside the gasket and

the door liner can be cleaned with a

soap-filled scouring or plastic pad,

hot water and detergent. Rinse well

with a vinegar and water solution.

To clean the outside of the door:

■ Use soap and water to thoroughly

clean the top, sides and front of the

oven door. Rinse well. You may also

use a glass cleaner to clean the glass

on the outside of the door. Do not let

water drip into the vent openings.

■ If any stain on the door vent trim is

persistent, use a soft abrasive cleaner

and a sponge-scrubber for best results.

■ Spillage of marinades, fruit juices,

tomato sauces and basting materials

containing acids may cause

discoloration and should be wiped up

immediately. When surface is cool,

clean and rinse.

■ Do not use oven cleaners, cleaning

powders or harsh abrasives on the

outside of the door.

Door (on models with a knob for the lower oven)

Do not allow food spills with a high

sugar or acid content (such as

tomatoes, sauerkraut, fruit juices or

pie filling) to remain on the surface.

They may cause a dull spot even

after cleaning.

To clean the inside of the door:

■ Soap and water will normally do the

job. Heavy spattering or spillovers may

require cleaning with a mild abrasive

cleaner. Soap-filled scouring pads may

also be used.

If necessary, you may use an oven cleaner. Follow

the package directions.

■ Clean the inside of the oven window

with a mild non-scratching cleaner and

a damp cloth.

To clean the outside of the door:

■ Use soap and water to thoroughly

clean the top, sides and front of the

oven door. Rinse well. You may also use

a glass cleaner to clean the glass on the

outside of the door. Do not let water

drip into the vent openings.

■ Spillage of marinades, fruit

juices, tomato sauces and basting

materials containing acids may cause

discoloration and should be wiped

up immediately. When surface is

cool, clean and rinse.

■ Do not use oven cleaners, cleaning

powders or harsh abrasives on the

outside of the door.

Door (on self-clean ovens)

Care and cleaning of the oven.

20

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

Oven Light Bulbs (on some models)

NOTE: The glass cover (on some

models) should be removed only when

cold. Wearing latex gloves may offer a

better grip.

CAUTION: Before replacing your

oven light bulb, disconnect the electrical

power to the oven at the main fuse or

circuit breaker panel.

Be sure to let the light cover and bulb

cool completely.

For your safety, do not touch a hot bulb

with bare hands or a damp cloth.

To remove:

Turn the glass cover

counterclockwise 1/4 turn until the

tabs of the glass cover clear the

grooves of the socket.

Using gloves or a dry cloth, remove

the bulb by pulling it straight out.

To replace:

Use a new 130-volt Halogen bulb,

not to exceed 50 watts.

Using gloves or a dry cloth, remove

the bulb from its packaging. Do not

touch the bulb with bare fingers.

Push the bulb straight into the

receptacle all the way.

Place the tabs of the glass cover into

the grooves of the socket. Turn the

glass cover clockwise 1/4 turn.

For improved lighting inside the

oven, clean the glass cover

frequently using a wet cloth. This

should be done when the oven is

completely cool.

Reconnect electrical power to

the oven.

Bulb

Socket

Tab

Glass cover

Receptacle

Use gloves

or cloth

Receptacle

Oven Light Bulb (on some models)

NOTE: The glass cover (on some models) should

be removed only when cold. Wearing latex gloves

may offer a better grip.

Before replacing the bulb, disconnect

electrical power to the oven at the main

fuse or circuit breaker panel. Let the

bulb cool completely before removing it.

For your safety, do not touch a hot bulb

with a damp cloth. If you do, the bulb

will break.

To remove:

Turn the glass cover counterclockwise

1/4 turn until the tabs of the glass cover

clear the grooves of the socket. Remove

the bulb.

To replace:

Put in a new 40-watt appliance bulb.

Place the tabs of the glass cover into the

grooves of the socket. Turn the glass

cover clockwise 1/4 turn.

NOTE:

■A 40-watt appliance bulb is smaller than a

standard 40-watt household bulb.

■Install and tighten the cover clockwise.

■Reconnect electrical power to the oven.

■For improved lighting inside the oven, clean

the glass cover frequently using a wet cloth.

This should be done when the oven is

completely cool.

Bulb

Socket

Tab

Maximum

length

31⁄2”

Glass cover

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Non-Self-Clean Oven Interior (on some models)

With proper care, the porcelain enamel

finish on the inside of the oven—top,

bottom, sides, back and inside of the

door—will stay new-looking for years.

Let the oven cool before cleaning. We

recommend that you wear rubber gloves

when cleaning the oven.

Soap and water will normally do the job.

Heavy spattering or spillovers may

require cleaning with a mild abrasive

cleaner. Soap-filled scouring pads may

also be used.

Do not allow food spills with a high sugar or acid

content (such as tomatoes, sauerkraut, fruit juices

or pie filling) to remain on the surface. They may

cause a dull spot even after cleaning.

Household ammonia may make the

cleaning job easier. Place 1/2 cup in a

shallow glass or pottery container in a

cold oven overnight.

The ammonia fumes will help loosen the

burned-on grease and food.

If necessary, you may use an oven cleaner.

Follow the package directions.

■Do not spray oven cleaner on the electrical

controls and switches because it could cause a

short circuit and result in sparking or fire.

■Do not allow a film from the cleaner to build up

on the temperature sensor—it could cause the

oven to heat improperly. (The sensor is located

at the top of the oven.) Carefully wipe the

sensor clean after each oven cleaning, being

careful not to move the sensor as a change in

its position could affect how the oven bakes.

■Do not spray any oven cleaner on the oven

door, handles or any exterior surface of the

oven, cabinets or painted surfaces. The cleaner

can damage these surfaces.

21

ge.com

Do not use a steel wool pad; it will scratch

the surface.

To clean the stainless steel surface,

use warm sudsy water or a stainless steel

cleaner or polish. Always wipe the surface

in the direction of the grain. Follow the

cleaner instructions for cleaning the

stainless steel surface.

To inquire about purchasing stainless

steel appliance cleaner or polish, or to

find the location of a dealer nearest you,

please call our toll-free number:

National Parts Center

1.800.626.2002

ge.com

Stainless Steel Surfaces

(on some models)

Oven Heating Elements

Do not clean the bake element or the broil

element. Any soil will burn off when the

elements are heated.

To clean the oven floor, gently lift

the bake element. Clean with warm

soapy water.

Glass Surfaces

To clean the outside glass finish, use a

glass cleaner. Rinse and polish with a

dry cloth.

Do not allow the water or cleaner

to run down inside the oven door

while cleaning.

Painted Surfaces

Clean with soap and water or a vinegar

and water solution.

Do not use commercial oven cleaners,

cleansing powders, steel wool or harsh

abrasives on any painted surface.

Before you call for service…

Troubleshooting Tips

Save time and money! Review the charts on the following

pages first and you may not need to call for service.

Problem Possible Causes What To Do

Control signals after You forgot to enter a •Press the BAKE pad and desired temperature or the

entering cooking time bake temperature or SELF CLEAN STD/LOW pad and desired clean time.

or delay start cleaning time.

Food does not bake Oven controls improperly set. •See the Using the oven section.

or roast properly Shelf position is incorrect •See the Using the oven section.

or the shelf is not level.

Incorrect cookware or •See the Using the oven section.

cookware of improper

size being used.

Oven thermostat •See the Adjust the oven thermostat—Do it yourself!

needs adjustment. section.

Food does not Oven controls improperly set. •Make sure you press the BROIL HI/LO pad.

broil properly Improper shelf •See the Broiling Guide.

position being used.

Food being cooked •Use the broiling pan and grid that came with your oven.

in a hot pan. Make sure it is cool.

Cookware not suited •Use the broiling pan and grid that came with your oven.

for broiling.

Aluminum foil used on the •See the Using the oven section.

the broiling pan and grid has

not been fitted properly and

slit as recommended.

In some areas the power •Preheat the broil element for 10 minutes.

(voltage) may be low.

•Broil for the longest period of time recommended in

the Broiling Guide.

Clock and timer A fuse in your home •Replace the fuse or reset the circuit breaker.

do not work may be blown or the

circuit breaker tripped.

Oven controls improperly set. •See the Using the clock, timer and control lockout

section.

Oven light does Light bulb is loose or defective. •Tighten or replace the bulb.

not work Pad operating light is broken. •Call for service.

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

22

23

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

ge.com

Problem Possible Causes What To Do

Oven temperature too Oven thermostat •See the Adjust the oven thermostat—Do it yourself!

hot or too cold needs adjustment. section.

Oven will not work A fuse in your home may •Replace the fuse or reset the circuit breaker.

be blown or the circuit

breaker tripped.

Oven controls improperly set. •See the Using the oven section.

Oven will not self-clean The oven temperature •Allow the oven to cool and reset the controls.

is too high to set a

self-clean operation.

Oven controls improperly set. •See the Using the self-cleaning oven section.

“Crackling” or This is the sound of the •This is normal.

“popping” sound metal heating and cooling

during both the cooking

and cleaning functions.

Excessive smoking Excessive soil. •Press the CLEAR/OFF pad. Open the windows to rid

during clean cycle the room of smoke. Wait until the LOCKED light goes

off. Wipe up the excess soil and reset the clean cycle.

Oven door will not Oven too hot. •Allow the oven to cool below locking temperature.

open after a

clean cycle

Oven not clean after a Oven controls improperly set. •See the Using the self-cleaning oven section.

clean cycle Oven was heavily soiled. •Clean up heavy spillovers before starting the clean

cycle. Heavily soiled ovens may need to self-clean

again or for a longer period of time.

“LOCK DOOR” flashes The self-clean cycle •Close the oven door.

in the display has been selected but

the door is not closed.

LOCKED light is on The oven door is locked •Press the CLEAR/OFF pad. Allow the oven to cool.

when you want to cook because the temperature

inside the oven has not

dropped below the

locking temperature.

Problem Possible Causes What To Do

“F— and a number You have a function •Press the CLEAR/OFF pad. Allow the oven to cool for

or letter” flash error code. one hour. Put the oven back into operation.

in the display If the function •Disconnect all power to the oven for at least 30

code repeats. seconds and then reconnect power. If the function

error code repeats, call for service.

Display goes blank A fuse in your home may •Replace the fuse or reset the circuit breaker.

be blown or the circuit

breaker tripped.

The clock is in the •See the Special features of your oven control section.

black-out mode.

Display flashes Power failure. •Reset the clock.

Unable to get the Oven control pads were •The BAKE and BROIL HI/LO pads must be pressed

display to show “SF” not pressed properly. at the same time and held for 3 seconds.

Power outage, Power outage or surge. •Reset the clock. If the oven was in use, you must reset

clock flashes it by pressing the CLEAR/OFF pad, setting the clock

and resetting any cooking function.

“Burning” or “oily” This is normal in a •To speed the process, set a self-clean cycle for a

odor emitting from new oven and will minimum of 3 hours. See the Using the self-cleaning

the vent disappear in time. oven section.

Strong odor An odor from the insulation •This is temporary.

around the inside of the

oven is normal for the first

few times the oven is used.

Fan noise A cooling fan may •This is normal. The cooling fan will turn on

automatically turn on. to cool internal parts. It may run for up to 1-1/2

hours in 30″models and up to 2 hours in 27″models

after the oven is turned off.

24

Before you call for service…

Troubleshooting Tips

Safety Instructions

Operating Instructions

Care and CleaningTroubleshooting TipsConsumer Support

25

General Electric Company

Warranty Registration Department

P.O. Box 32150

Louisville, KY 40232-2150

GE Service Protection Plus™

GE, a name recognized worldwide for quality and dependability, offers you

Service Protection Plus™—comprehensive protection on all your appliances—

No Matter What Brand!

Benefits Include:

•Backed by GE

•All brands covered

•Unlimited service calls

•All parts and labor costs included

•No out-of-pocket expenses

•No hidden deductibles

•One 800 number to call

You will be completely satisfied with our service protection or you may request your money back

on the remaining value of your contract. No questions asked. It’s that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!

Plus there’s no extra charge for emergency service and low monthly financing is available. Even

icemaker coverage and food spoilage protection is offered. You can rest easy, knowing that all your

valuable household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224

for more information.

*All brands covered, up to 20 years old, in the continental U.S.

We’ll Cover Any Appliance.

Anywhere. Anytime.*

Please place in envelope and mail to:

✁Cut here

26

Consumer Product Ownership Registration

Important

Mail

Today!

GE Consumer & Industrial

Appliances

General Electric Company

Louisville, KY 40225

ge.com

First

Name

Mr. ■■Ms. ■■Mrs. ■■Miss ■■

Street

Address

City State

Date Placed

In Use

Month Day Year

Zip

Code

Apt. #

Last

Name

Phone

Number __

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product and thank you for placing your confidence in us.

We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Important: If you did not get a registration card with your

product, detach and return the form below to

ensure that your product is registered, or register

online at ge.com.

123

Model Number Serial Number

✁Cut here

Complete and mail

your Consumer

Product Ownership

Registration today.

Have the peace of

mind of knowing we

can contact you in

the unlikely event of

a

safety modification.

After mailing the

registration below,

store this document

in a safe place. It

contains information

you will need should

you require service.

Our service number is

800.GE.CARES

(800.432.2737).

Read your Owner’s

Manual carefully.

It will help you

operate your new

appliance properly.

Model Number Serial Number

E-mail Address*

* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important

communications from GE Appliances (GEA).

■■ Check here if you do not want to receive communications from GEA’s carefully selected partners.

FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR

WARRANTY RIGHTS.

For more information about GEA’s privacy and data usage policy, go to ge.com and click on

“Privacy Policy” or call 800.626.2224.

27

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

GE Built-In Electric Oven Warranty.

For The Period Of: GE Will Replace:

One Year Any part of the oven which fails due to a defect in materials or workmanship.

From the date of the During this limited one-year warranty, GE will also provide, free of charge, all labor

original purchase and in-home service to replace the defective part.

■Service trips to your home to teach you how to

use the product.

■Improper installation, delivery or maintenance.

■Failure of the product if it is abused, misused,

or used for other than the intended purpose

or used commercially.

■Replacement of house fuses or resetting of circuit

breakers.

■Damage to the product caused by accident, fire, floods

or acts of God.

■Incidental or consequential damage caused by possible

defects with this appliance.

■Damage caused after delivery.

■Product not accessible to provide required service.

What GE Will Not Cover:

This warranty is extended to the original purchaser and any succeeding owner for products purchased for

home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is not

available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE

Service location for service. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty

gives you specific legal rights, and you may also have other rights which vary from state to state. To know

what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

All warranty service provided by our Factory Service Centers, or

an authorized Customer Care®technician. To schedule service,

on-line, 24 hours a day, visit us at ge.com, or call 800.GE.CARES

(800.432.2737). Please have serial number and model number

available when calling for service.

Staple your receipt here.

Proof of the original purchase

date is needed to obtain service

under the warranty.

EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in this Limited

Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,

are limited to one year or the shortest period allowed by law.

Printed in the United States

Consumer Support.

GE Appliances Website ge.com

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,

any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,

order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™”

your questions, and so much more...

Schedule Service ge.com

Expert GE repair service is only one step away from your door. Get on-line and schedule your service at

your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal

business hours.

Real Life Design Studio ge.com

GE supports the Universal Design concept—products, services and environments that can be used by

people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and

mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen

design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call

800.TDD.GEAC (800.833.4322).

Extended Warranties ge.com

Purchase a GE extended warranty and learn about special discounts that are available while your warranty

is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.

GE Consumer Home Services will still be there after your warranty expires.

Parts and Accessories ge.com

Individuals qualified to service their own appliances can have parts or accessories sent directly to their

homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or

by phone at 800.626.2002 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally

should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause

unsafe operation.

Contact Us ge.com

If you are not satisfied with the service you receive from GE, contact us on our Website with all the details

including your phone number, or write to: General Manager, Customer Relations

GE Appliances, Appliance Park

Louisville, KY 40225

Register Your Appliance ge.com

Register your new appliance on-line—at your convenience! Timely product registration will allow for

enhanced communication and prompt service under the terms of your warranty, should the need arise.

You may also mail in the pre-printed registration card included in the packing material.
