GE

imagination at work

GE

Lighting Solutions

Industrial Lighting

Duraglow™ 400 (DG5)

Applications

• For over 20 ft. (6 meter) applications assembly,

maintainance or storage areas, hangers, recreation

centers, and other high bay applications

Housing

• Symmetrical heavy-duty die-cast aluminum ballast

housing

Finish

• Polyester powder gray or white paint finish

Ratings

• 1598 Listed Suitable for Damp Locations

• Listed to Canadian standards and codes

Mounting

• Threaded slide-in mounting adapter for easy mounting

• Single casting integral hook/loop and mounting plate is

available

Reflectors

• ALGLAS™ finish on faceted reflector

Unique Features

• Open, ventilated optical assembly

• Unique optical sliding disconnect

• 55° C ambient standard

• In-line EZ Connect™ plugin adapter port allows for:

— hook/loop, cord & NEMA plug

— plug-in modular wiring systems

— plug-in fuse kits

• Adjustable mogul base socket - E39 standard

• Safety chain provisions

• Shipped as components: Ballast, Optical - Magnapack

available for ballast

• Pulse start system for metal halide available

GE Indoor Lighting luminaires are designed to produce optimum illumination from the lamp, optical system and ballast,

while providing specific light patterns for specific applications. These reliable systems help to improve safety and

energy savings, while enhancing productivity and efficiency, to put your industrial workplace in the best possible light.

Product Features

Ordering Number Logic

Duraglow™ 400 (DG5)

D G 5

_ _ _ - _ - _ _ - _ - _ - _ - _ _ - _ _ - _ _ - _

XX = Select

Code

Below

DG5 = Duraglow

400

Luminaire

V7 = Open and

ventilated

17-in.

Reflector

V2 = Open and

ventilated

22-in.

Reflector

Note: Do not

use open

opticals

with lamps

specified for

use in enclosed

opticals only

A = 65°C maximum

ambient**

B = Time Delay

Automatically

Switched

Quartz

F = Fusing*

G = Secondary

Wiring Access.

7/8 in. dia.

knockout

Q = Non-Time

Delay

Automatically

Switched

Quartz

R = Quartz.

S = Exclusionary

mogul

base socket

for MH

open fixtures

T = E40 / European

Socket

*(Not available

with multivolt)

**65°C available

for 250 and 400

watt Auto Reg

Ballast only.

See Ballast

Selection

Table

A = Autoreg

D = Systems

3 Bilevel

Autoreg

G =

CANADIAN

Mag-Reg

(Grounded

Socket

Shell)

H = HPF

Reactor

or Lag

M = Mag- Reg

= 250

= 320

= 350

= 400

E = Energy Act

Compliant

Pulse MH

(EPMH)

S = HPS

For

International

Markets only

M = MH

P = Pulse

Start

MH

Note: Lamp is

vertical base

up. Lamp not

included.

XX = Select Code Below

11 = Pendant mounting

13 = Provision for Slide-on Primary Electrical

Disconnect. Order TWOBP Box (Thru Feed

Capability Only) Separately.

14 = Provision for Slide-on Primary Electrical

Disconnect. (Pendant and Thru Feed

Capability) Order PED Box Separately

15 = Prewire with EZ-Loop, Cord and Plug Part of

“Power Hook”. Order Receptacle/Hook Box

Separately. (Not CSA/CUL)

31 = Prewire with EZ-Hook, 3-ft (0.9 Meters) #16/3

Cord, and Nema Plug

33 = Prewire with EZ-Loop, 3-ft (0.9 Meters) #16/3

Cord, and Nema Plug (Order locking receptacle

hook box separately.)

MODULAR PREWIRE

41 = ACS with 3-ft (0.9 meter) cord & EZ-Hook

69 = ACS with 6-ft (1.8 meter) cord & EZ-Hook

43 = ACS with 3-ft (0.9 meter) cord & EZ-Loop

70 = ACS with 6-ft (1.8 meter) cord & EZ-Loop

PLUG-N-GO

51 = Plug-N-Go with 3 ft. (0.9 meter) Cord & Hook

71 = Plug-N-Go with 6 ft. (1.8meter) Cord & Hook

53 = Plug-N-Go with 3 ft. (0.9 meter) Cord & Loop

72 = Plug-N-Go with 6 ft. (1.8 meter) Cord & Loop

Note: ACS = Flex 3+

Plug-N-Go = FSC Series

G = Gray

W = White 60 Hz

0 = 120/208/

240/277

MULTIVOLT

1 = 120

2 = 208

3 = 240

4 = 277

5 = 480

D

= 347

F = 120X347

T = 220

50 Hz

6 = 220

R = 230

Y = 240

G = 380

OPTIONS

WATTAGE LIGHT

SOURCE BALLAST

TYPE

VOLTAGE MOUNTING CODE

COLOR

PHOTOMETRY

CODE

OPTICAL

CODE

*Note: 320 watt available — contact factory

V2 OPTICAL - Open & Ventilated 22 in. Reflector

MH, requires “S” Option EX39 base socket

Light Spacing Socket Photometric Optical Photometry

Wattage Source Criteria Position Curve Code Code

400 EPMH 0.7 7 174978 V2 ES

400 EPMH 0.9 11 179165 V2 EX

250 - 400 HPS 0.7 2 174982 V2 EN

V7 OPTICAL - Open & Ventilated 17 in. Reflector

MH, requires “S” Option EX39 base socket

Light Spacing Socket Photometric Optical Photometry

Wattage Source Criteria Position Curve Code Code

350, 400 EPMH 1.1 11 174980 V7 EX

350, 400 EPMH 1.3 9 174981 V7 EU

350, 400 EPMH 1.6 5 177098 V7 EQ

350, 400 EPMH(Coated) 1.2 11 175933 V7 EX

350, 400 EPMH(Coated) 1.5 9 175320 V7 EU

350, 400 EPMH(Coated) 1.9 5 175930 V7 EQ

250 - 400 HPS 1.0 5 174984 V7 EQ

250 - 400 HPS 1.4 3 174985 V7 EO

250 - 400 HPS 1.9 1 175641 V7 EM

Photometric Selection Table

Exclusionary base socket is available for use with Metal Halide lamps in open

fixtures to comply with NEC 2005 regulations (GELS “S” Option). Customer should

consult or review local electrical codes for compliance.

OLP-2997 (Rev. 06/07/12)

GE Lighting Solutions • 1-888-MY-GE-LED • www.gelightingsolutions.com

1 - 8 8 8 - 6 9 - 4 3 - 5 3 3

GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. The GE brand and logo are trademarks of the General Electric Company.

© 2012 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.

Product Dimensions

• Approximate Net Weight: Ballast and Optical 25-37 lbs (11-17) kgs)

DATA

DIMENSIONS

When optical assembly contains a quartz socket (switched or

non-switched), an additional 1.125 inches (29mm) must be added

to the overall height due to double stack disconnect.

NOTES

See explanation on ”Optical Flexibility“

NOTE: N/A = Not Available

* H is HPF-Linear Reactor available as 277 volt only.

Cannot be used with Automatic Switch Quartz Option.

** For International only.

CANADIAN NOTES:

1. “A”, Autoreg, and “D”, Bilevel Autoreg available 120, 277 or 347 volts only

2. 208, 240, and 480 volts require CWI ballast. Use “G” when available. Contact factory for all others.

3. Multivolt not available

4. 208, 240 and 480 volts with “G” ballast not available with switched quartz.

Ballast Selection Table

Ballast Type / Voltage

60HZ 50HZ

120, 208 120

Light 240, 277 x

Wattage Source Multivolt 480 347 347 220 220 230 240 380

250 HPS A,M A,D,G,M A,D,G A A,H A,H,M A,H A,H M

400 HPS A,M A,D,GM A,D,G A A,H A,H,M A,H,M A,H,M M

250** MH,P N/A N/A N/A A A A A A N/A

400** MH,P N/A N/A N/A A A A A A N/A

PULSE START METAL HALIDE LIGHT SOURCE

BALLAST SELECTION TABLE

250 EPMH A A A N/A N/A N/A N/A N/A N/A

320 EPMH A A A N/A N/A N/A N/A N/A N/A

350 EPMH A A A N/A N/A N/A N/A N/A N/A

400 EPMH A A A N/A N/A N/A N/A N/A N/A
